Acrox Technologies BSP01 Bluetooth Speaker User Manual 3D Wheel Optical Mouse
Acrox Technologies Co., Ltd. Bluetooth Speaker 3D Wheel Optical Mouse
User manual
Waterproof
Bluetooth Mono Speaker
USER'S GUIDE
Ver.:1.2
CAUTION: To use this product properly, please read the user's guide before installing.
1
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate
this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Radiation Exposure Statement:
The product comply with the FCC portable RF exposure limit set forth for an
uncontrolled environment and are safe for intended operation as described in
this manual. The further RF exposure reduction can be achieved if the
product can be kept as far as possible from the user body or set the device to
lower output power if such function is available.
2
Functional Introduction
1. ON/OFF/Play/Pause/Answer
7. Cover holder
2. Volume down
8. Micro-USB Connector
3. Volume up
9. Speaker
4. Power Led Indicator(RED)
10. Clip
5. BT Led Indicator(GREEN)
6. MIC
11. Hanging hook
3
ON or OFF
Power ON / OFF: Press and hold the power button about 3 seconds then
the power will turn ON. When it is on, press and hold the power button
about 3 seconds the power will OFF.
Pairing your Bluetooth Speaker
* Before using your Bluetooth Speaker for the first time, please ensure
your mobile phone or laptop is Bluetooth-Activate.
* The process for pairing your Bluetooth Speaker may differ depending
on the make and model of your mobile phone or computer
* You can normally find instructions for pairing the device in your mobile
phone or laptop user guide.
4
Step 1: Place the Bluetooth Speaker and your mobile phone no more
than one meter apart.
Step 2: Press the power button and hold about 6 seconds, get into
pairing mode.
Step 3: Consult your mobile phone or laptop user manual and activate
your device's Bluetooth function.
Step 4: Place your mobile phone or laptop within one meter of the
Bluetooth Speaker to locate the headset, which will appear as "PMF" on
the Bluetooth device list.
Step 5: choice the PMF. They will auto pairing each other completed.
Step 6: Once the Bluetooth Speaker is paired with your mobile device,
you can find the meaning of the LED light by consulting the "Status
table"
Step 7: Click "return" to go back to the mobile phone's main screen. On
certain models of mobile phones, a headphones icon will be visible.
Step 8: Your Bluetooth Speaker can now be used on outgoing or
incoming calls.
5
LED status
Power ON
Green
3 flashes
Power off
Green
3 flashes
Pairing
Green
flash150ms by 1 times
Pairing OK
Green
flash 10sec by 1 times
Pairing fail
Green
flash 5 sec per 1 flashes after 1min
power off
Back to link
Green
500ms per 1 flashes
link after 10sec per flashes
Low battery
Red
>3.6v 4sec per 1 flashes
≧3.4v power off
Calls mode
Green
5sec by 3 flashes
Call in the mode
Green /Red
Green & Red Flashes 4sec per cycle
Music mode
Green /Red
Green & Red Flashes 4sec per cycle
Charge
Function
LED
Charge
Red always ON
Power Full
N/A
6
Reminders
1. Keep away from water and moisture.
2. Keep away from heat source.
3. Do not drop, bend or crush the product.
4. Hold on to the product when removing the USB cord.
5. To reduce the risk of being shocked, please do not disassemble the
product.
WARNING: Listening to excessively loud music can damage
your hearing.
1. Avoiding hearing damage︰Repeatedly or frequently using
headphones at a volume of 80 decibels or louder can make you feel like
the volume ought to be louder. This can cause you to continually
increase the volume and can result in volume settings that pose a
danger to your hearing.
2. Using hearing safely︰To protect your health, please keep the
volume on your Headset below 80 decibels and do not listen for too long
a period of time. If you get a headache, feel dizzy or feel uncomfortable,
please cease use.
