Acrox Technologies KB16 Bluetooth Keyboard User Manual
Acrox Technologies Co., Ltd. Bluetooth Keyboard Users Manual
Users Manual
Gunnison Blue Tooth Keyboard User Manual
Bluetooth Keyboard Contents
Thank you for your purchasing Bluetooth keyboard .Before you use this product, please read this manual thoroughly and use
this product correctly. After you read this manual, please keep it in place and refer to it when necessary.
Supplied with the Bluetooth Keyboard:
- Bluetooth Keyboard
- Micro USB Charging cable
Installing Hardware
Step1: Turn the Tablet power to ON, then place keyboard power switch to ON
Step2: Start device’s Bluetooth set up function to search for this Bluetooth keyboard.
Step3: Select SETTINGS > WIRELESS & NETWORKS > BLUETOOTH >ON
Step4: Press the Fn and BT Icon ( ) on keyboard. A blue LED light will flash until tablet and the keyboard are paired.
Step5: Tablet should find the “HP Bluetooth Keyboard Case T800” and then list it as an available device. If it doesn’t, simply
touch Search for devices and it will scan again.
Step6: When the “HP Bluetooth Keyboard Case T800” shows in your list of available devices, touch it to complete pairing.
Note: While pairing for the first time, some tables will trigger a random PIN code, need to input PIN on keyboard to complete
pairing.
Charge
The LED keep flashing, the keyboard is short of power. It is time to charge the keyboard.
Step1: Use the USB charging cable plug into outlet, put one end of the plug into keyboard USB charging cable.
Step2: A Blue light will illuminate to indicate the keyboard is charging. Wait until this light turns off, indicating a full charge. It
usually takes 2-4 hours to completely charge keyboard.
LED Indicator :
Definition
Indicator
Description
Charge with USB cable
Blue
No
LED solid on
When full charge, LED off
Turn on power
(no USB cable attached)
Blue
LED on after 3 seconds LED off
Bluetooth pairing
Blue
LED blinking (1 time/per sec for
2 mins)
Low power
Blue
No
When key in, LED blink
When no action, LED off
No action/No power
No
LED off
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate this
equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
