Acrox Technologies MPK0050708 RF Laser Mouse User Manual Rev
Acrox Technologies Co., Ltd. RF Laser Mouse Users Manual Rev
Users Manual Rev
BRUSSELS HANNOVER BARCELONA TOKYO MILAN AMSTERDAM SINGAPORE LONDON PARIS NEW YORK LOS ANGELES TORONTO HONG KONG SYDNEY
Wireless Rechargeable
Notebook Laser Mouse
USER’S GUIDE
Making Your Mobile Life Easier.®
Making Your Mobile Life Easier.®
Visit our Web site at: www.targus.com
Features and specifications are subject to change without notice.
© 2005 Targus Group International, Inc. and Targus Inc.
AMW15US/400-0285-001A
3
TARGUS WIRELESS
RECHARGEABLE
NOTEBOOK LASER MOUSE
Introduction
Congratulations on your purchase of a Targus Wireless
Rechargeable Notebook Laser Mouse. This compact mini
mouse incorporates new laser tracking technology, offering
20 times more sensitivity than a traditional LED
mouse. The images the laser receives are more detailed,
with higher contrast. The mouse can track more reliably,
even on reflective surfaces, and its small footprint makes it
ideal for portable computing.
Note: While the mouse is functioning, no laser light is
visible to the naked eye. Be careful not to look
directly into the emitter hole while the mouse is
active.
Package Contents
Wireless Laser Mouse USB receiver
USB charge cable USB extension cable
2 AAA rechargeable batteries Carrying pouch
AMW15US.fm Page 3 Tuesday, August 16, 2005 1:33 PM
LASER
4
Targus Wireless Rechargeable Notebook Laser Mouse
System Requirements
Hardware
•USB port
Operating System
•Windows
® 98SE/ME/2000/XP or Mac OS X and above
Connecting the Mouse Receiver
To connect the mouse receiver:
1 Plug the USB receiver into an available USB port on
your computer.
2 Your computer’s operating system identifies the receiver
and begins installing the default driver.
If applicable, follow any on-screen procedures to
complete the native driver installation.
Installing the Batteries
1 If the mouse is on, slide the on/off switch on the bottom
of the mouse to the “off” position.
AMW15US.fm Page 4 Tuesday, August 16, 2005 1:33 PM
5
Targus Wireless Rechargeable Notebook Laser Mouse
2 Remove the battery cover from the top of the mouse by
pressing the battery cover hinge located on the bottom
of the mouse and sliding it off.
Mouse Bottom
NOTE: The battery cover is also the top cover of the
mouse.
On/Off switch
Connect
button
Laser
Battery cover
hinge
AMW15US.fm Page 5 Tuesday, August 16, 2005 1:33 PM
6
Targus Wireless Rechargeable Notebook Laser Mouse
3 Insert the supplied batteries, making sure that the
positive (+) and negative (-) ends of each battery match
the polarity indicators inside the battery housing.
WARNING: When replacing the batteries, use only
heavy-duty NiMH rechargeable batteries. Never use
alkaline batteries.
Avoid mixing new and used batteries in a device.
4 Slide the battery cover back into position until it “clicks”
firmly into place.
5 Turn on the mouse by sliding the on/off switch on the
bottom of the mouse to the “on” position.
Note: While the mouse is functioning, no laser light is
visible to the naked eye. Be careful not to look
directly into the emitter hole while the mouse is
active.
Charging the Batteries
For best results, you should charge the mouse at least 4
hours before using it. You can do this via the supplied USB
charge cable. To do this:
1 Connect the cable’s USB connector into an available
USB port on your computer
2 Connect the other end to the mouse.
NOTE: To continuously charge the mouse via the USB
charge cable, your computer must be on and awake.
For best results, turn off your computer’s power
management feature while charging the mouse.
AMW15US.fm Page 6 Tuesday, August 16, 2005 1:33 PM
7
Targus Wireless Rechargeable Notebook Laser Mouse
Synchronization
After your computer detects the USB receiver you must
establish a communications link between the mouse and its
receiver BEFORE you can use the mouse. To do this, follow
the instructions below:
1 Press and release the connect button located at the
bottom of the receiver.
Receiver
The receiver’s status light blinks when the receiver is
activated.
2 Press and release the connect button, located on the
bottom of the mouse.
You are now ready to use the mouse.
Note: Due to the improved tracking speed of the
laser engine, users may find the cursor
movement is faster than a conventional
mouse. Cursor settings can be changed from
your computer’s Control Panel.
Connect button
AMW15US.fm Page 7 Tuesday, August 16, 2005 1:33 PM
LASER
8
Targus Wireless Rechargeable Notebook Laser Mouse
Mouse Power Management
To power the mouse on and off, slide the on/off switch at
the bottom of the mouse to the desired position.
When power is on, the mouse goes into "sleep mode" after
8 minutes of non-use. To activate the mouse, press any
mouse button.
Safety Measures
• Although this mouse is a Class 1 Laser Product and safe
for operation, avoid pointing the laser into the eyes or
looking directly into the laser emitter.
• Keep the mouse away from young children.
• Any attempt to disassemble, adjust or repair the mouse
may result in exposure to laser light or other safety
hazards.
Operating Hints
For optimal performance and RF reception:
• Place the receiver at least 8 inches (20 cm) away from all
electrical devices, such as your monitor, speakers or
external storage devices.
If necessary, use the supplied extension cable to keep
the receiver away from the computer. Plug the receiver
into the extension cable, and the extension cable to the
computer.
AMW15US.fm Page 8 Tuesday, August 16, 2005 1:33 PM
9
Targus Wireless Rechargeable Notebook Laser Mouse
• Avoid using the mouse on a metal surface. Metals, such
as iron, aluminum or copper, shield the radio frequency
transmission and may slow down the mouse’s response
time or cause the mouse to fail temporarily.
• The mouse will enter a suspend mode at the same time
your computer does. To activate the mouse press any
mouse button.
• If your computer has a metal case that contains aluminum
or magnesium, use the mouse to the side. The display
panel may interfere with the radio frequency signal if you
use the mouse directly in front of the computer.
Troubleshooting
What do I do if the mouse does not work?
• Make sure that the polarity of the batteries is correct. The
positive (+) and negative (-) ends of each battery must
match the positive (+) and negative (-) connections in the
battery housing.
• Make sure that the batteries are fully charged. Check your
computer’s suspend mode settings, as the mouse will not
charge while the computer is in suspend mode.
• Check that the receiver's USB connector is firmly
attached to the USB port on your computer.
• Make sure you have established a wireless link between
the mouse and its receiver. See “Synchronization” on
page 7.
AMW15US.fm Page 9 Tuesday, August 16, 2005 1:33 PM
10
Targus Wireless Rechargeable Notebook Laser Mouse
I do not see the laser light when the mouse is active.
• Unlike traditional optical mice, the light is not visible when
the laser mouse is active.
• To make sure the mouse is on and functioning properly,
move the mouse back and forth and check to see if the
cursor responds.
My mouse does not work on a mirror or glass sur-
face.
• Though rated for most of these kinds of surfaces,
occasionally there will be one such surface that will cause
the mouse to work improperly or not at all.
• If you are using the mouse on a reflective or mirrored
surface, move it to another surface.
What do I do if the response time of the mouse is
slow or the mouse intermittently stops working?
• Metals, such as iron, aluminum or copper may slow down
the mouse's response time or cause the mouse to fail
temporarily.
• If you are using the mouse on a metal surface, move it and
the receiver to a non-metal surface.
AMW15US.fm Page 10 Tuesday, August 16, 2005 1:33 PM
laser
11
Targus Wireless Rechargeable Notebook Laser Mouse
Technical Support
For technical questions, please visit:
US
Internet: http://www.targus.com/support
Australia
Internet: www.targus.com/au
Email: infoaust@targus.com
Telephone: 1800-641-645
New Zealand
Telephone: 0800-633-222
Product Registration
Targus recommends that you register your Targus accessory shortly
after purchasing it. To register your Targus accessory, go to:
http://www.targus.com/registration.asp
You will need to provide your full name, email address, phone
number, and company information (if applicable).
Warranty
Targus warrants this product to be free from defects in materials and
workmanship for one year. If your Targus accessory is found to be
defective within that time, we will promptly repair or replace it. This
warranty does not cover accidental damage, wear and tear, or
consequential or incidental loss. Under no conditions is Targus liable
for loss of, or damage to a computer; nor loss of, or damage to,
programs, records, or data; nor any consequential or incidental
damages, even if Targus has been informed of their possibility. This
warranty does not affect your statutory rights.
AMW15US.fm Page 11 Tuesday, August 16, 2005 1:33 PM
12
Targus Wireless Rechargeable Notebook Laser Mouse
Regulatory Compliance
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause
undesired operation.
FCC Statement
Tested to Comply
This equipment has been tested and found to comply with the limits
of a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna;
• Increase the separation between the equipment and receiver;
• Move the computer away from the receiver;
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Windows is a registered trademark of Microsoft Corporation. All trademarks and registered
trademarks are the property of their respective owners. Features and specifications subject
to change without notice. © 2005, Targus Group International, Inc. and Targus, Inc.,
Anaheim, CA 92806 USA.
AMW15US.fm Page 12 Tuesday, August 16, 2005 1:33 PM
Per FCC 15.21, you are cautioned that changes or modifications not
expressly approved by the part responsible for compliance could void
the user’s authority to operate the equipment.
