Acrox Technologies MU18 Bluetooth Mouse User Manual 3D Wheel Optical Mouse
Acrox Technologies Co., Ltd. Bluetooth Mouse 3D Wheel Optical Mouse
User Manual
BK4
Bluetooth Mouse
OWNER'S GUIDE
Ver.1.0
CAUTION: To use this product properly, please read the user's guide before installing.
1
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by
the party responsible for compliance could void the user's authority to
operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
2
Functional Introduction
Scrolling Wheel
Connect
Button
OFF/ON Switch
Battery Cover
Right button
Left button
LED indicator
*Mouse Indicator
Red LED Blinking
Low battery Warning
in working mode, LED will be off
after 10 sec when mouse inactivity.
Power ON
Red LED is on for 10 sec.
Red LED Blinking
LED will be light blinking during
paring and mouse didn’t work,
and light off when paired or if it
failed to pair after 3 mins
3
Battery and Power Management:
Step 1: Take the battery cover off.
Step 2: Insert the battery as shown inside the battery compartment.
Step 3: Replace the cover.
**Warning:
*Please insert the battery with the correct position according to the instruction
labeled on the mouse.
Power saving features:
To conserve the battery power, the mouse offers power
management functions as below:
1. The mouse goes into “Saving Mode” after inactivity.
2. The mouse powers down to “Sleeping Mode” after 5 minutes of
Inactivity. There may be a slight delay while the mouse re-establishes
Bluetooth connection from power saving or sleeping mode.
Establishing a Bluetooth Connection
The Bluetooth mouse can work in any Bluetooth environment. Before
connecting your Bluetooth mouse with your computer, make sure your
computer has a working Bluetooth configuration with Human Interface
AAA Battery
Pull
1st
2nd
4
Device (HID) profile. If your computer does not support Bluetooth, you
need to obtain and install a commercially available Bluetooth dongle
which converts your computer to a Bluetooth environment.
Troubleshooting
A. Mouse does not work upon installation or is not detected
Try one or more of the following:
Make sure the batteries are installed correctly and turn the switch on.
Replace a fresh set of batteries if it still does not work.
Verify that the computer is Bluetooth enabled.
Press the connection button to reset the Bluetooth connection between your
mouse and your computer. Make sure it has been detected by the Operating
Systems properly.
B. The screen cursor does not move properly
If your screen cursor lags behind the movement, then your Bluetooth
connection may not be able to transmit all of the data from the mouse
with the necessary speed. This may be caused by interference from
other radio sources, obstructions in the radio wave path, excessive
distance from the computer, or a combination of the above.
※ Try the following actions to improve your Bluetooth
connection and optimize your mouse performance:
Remove any metallic objects from the line of sight between your computer
and the Bluetooth mouse.
If you are using a computer with a built-in Bluetooth antenna, try
reorienting the computer until you get a better data rate.
If you are using a Bluetooth dongle, use a USB extension cable and place
the Bluetooth dongle onto your desktop or somewhere in sight of your
Bluetooth mouse.
Move the mouse closer to your Bluetooth dongle.
Turn off the mouse and turn it on again for better connection.
Disconnect any Bluetooth audio devices, such as headsets, that may be
5
connected to your computer.
Switch off any other devices operating in the 2.4 GHz radio spectrum,
such as Wi-Fi network, mobile telephones, etc., or move their antennas
further away from your computer.
