Acrox Technologies Co., Ltd. Wireless Mouse Manual
Manual
INSTALLING THE BATTERY AND REMOVING THE USB
TRANSCEIVER
1 Take the battery cover o.
2 Remove the USB transceiver.
3 Insert the included AA battery into the battery compartment. Make sure
that the + and - signs match the symbols in the compartment.
4 Replace the battery cover.
Tip: Store the USB transceiver in the mouse when it is not in use.
CONNECTING YOUR MOUSE TO YOUR COMPUTER
1 Plug the USB transceiver into a USB port on your computer.
2 Slide the ON/OFF switch on your mouse to ON.
The computer automatically detects the mouse and you can
immediately begin using it.
If the mouse does not work:
• Move your mouse closer to your computer.
• Re-plug the USB transceiver into the USB port on your computer, then
press the connect button on the mouse. The LED indicator on the
mouse ashes steadily while in pairing mode (10 seconds). After
pairing successfully, the LED indicator lights solid for 10 seconds,
then turns o.
• Check the battery in your mouse. The LED indicator blinks for
10 seconds when the battery is low.
Quick Setup Guide | NS-PNM6003-BK / NS-PNM6003-BK-C / NS-PNM6003-BU / NS-PNM6003-BU-C / NS-PNM6003-SV /
NS-PNM6003-SV-C / NS-PNM6003-RD / NS-PNM6003-RD-C / NS-PNM6003-WH / NS-PNM6003-WH-C
Wireless Optical Mouse
Before using your new product, please read these instructions to prevent any damage.
PACKAGE CONTENTS
• Wireless Optical Mouse
• USB transceiver
• AA battery (1)
• Quick Setup Guide
SYSTEM REQUIREMENTS
• Windows® 8.1, Windows® 8, Windows® 7, Windows Vista®, or
Mac OS 10.X or higher
• One available USB port
FEATURES
• Blue sensor for enhanced tracking
USB transceiver
Connect
button
ON/OFF
switch
Battery cover
Left button
Right
button
Scroll wheel
LED indicator
Final at size: 314.33 x 148.08 mm
Final fold size: 104.77 x 148.08 mm
Pull
AA battery
NS-PNM6003-BK_BK-C_BU_BU-C_SV_SV-C_RD_RD-C_15-0056_QSG_V1_EN.ai 1 2/3/2015 3:57:24 PMNS-PNM6003-BK_BK-C_BU_BU-C_SV_SV-C_RD_RD-C_15-0056_QSG_V1_EN.ai 1 2/3/2015 3:57:24 PM
V1
FINAL
FOR PRINT
SPECIFICATIONS
Mouse:
• Dimension (L×W×H): 3.89 × 2.44 × 1.44 in. (9.9 × 6.2 × 3.67 cm)
• Weight: 1.86 oz. (.05 kg)
• Battery: 1 AA alkaline battery
• Battery life: 6 months (based on average usage)
• Radio frequency: 2.4Ghz
• Operating distance: 33 feet (10 meters)
• Rating: 1.5V C.C. - 10mA
USB transceiver:
• Dimension (L×W×H): .7 × .6 × .2 in. (1.8 × 1.4 × .6 cm)
• Weight: 1.2 g ± 0.5g
• Interface: USB 1.1, 2.0 , 3.0
TROUBLESHOOTING
My mouse is not working.
• Move your mouse and computer closer together.
• Make sure that your computer meets the system requirements.
• Only use the mouse on a clean, at, non-slippery surface to ensure
smooth and accurate cursor action.
• If your mouse stops working:
• Make sure that your mouse and USB transceiver are paired by
pressing the connect button on the mouse.
• Replace the mouse battery.
• Try connecting your USB transceiver into a dierent USB port on your
computer.
• Avoid using your mouse on reective, transparent, or metallic surfaces.
V1 ENGLISH 15-0056
LEGAL NOTICES
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority
to operate the equipment.
RSS-Gen and RSS-210 statement
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est
autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
RSS-102 statement
This equipment complies with Industry Canada radiation exposure limits set forth for an uncontrolled environment.
Cet équipement est conforme à l'exposition aux rayonnements Industry Canada limites établies pour un environnement non
contrôlé.
ONE-YEAR LIMITED WARRANTY
For complete warranty, visit www.insigniaproducts.com.
CONTACT INSIGNIA
1-877-467-4289 (U.S. and Canada) or 01-800-926-3000 (Mexico)
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its aliated companies.
Registered in some countries.
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richeld, MN 55423 U.S.A.
©2015 Best Buy. All rights reserved.
Made in China
LED INDICATOR
CLEANING YOUR MOUSE
• Wipe the mouse with a damp, lint-free cloth.
FUNCTION
Power ON
Low battery warning
Pairing
Pairing failed
Paired successfully
DESCRIPTION
LED is on for 10 seconds, then turns o.
LED blinks for 10 seconds.
LED blinks for 10 seconds after pressing the
Connect button.
After the Connect button is pressed, the LED
blinks, then lights solid for 10 seconds.
After the Connect button is pressed, the LED
blinks for 10 seconds, then turns o.
LED
indicator
