Acrox Technologies Co., Ltd. Dongle for Wireless Mouse Manual
Manual
Installing the batteries and removing the nano
receiver
1 Take the battery cover o.
2 Remove the nano receiver.
3 Insert the included AA battery into the battery compartment. Make sure
that the + and - signs match the symbols in the compartment.
4 Replace the battery cover.
Tip: Store the nano receiver in the mouse when it is not in use.
Connecting your mouse to your computer
1 Plug the nano receiver into a USB port on your computer.
2 Slide the ON/OFF switch on your mouse to ON.
The computer automatically detects the mouse and you can
immediately begin using it.
If the mouse does not work:
• Move your mouse closer to your computer.
• Re-plug the nano receiver into the USB port on your computer, then
press the connect button on the mouse. The LED indicator on the
mouse ashes steadily while in pairing mode (10 seconds). After
pairing successfully, the LED indicator lights solid for 10 seconds,
then turns o.
• Check the battery in your mouse. The LED indicator blinks for
10 seconds when the battery is low.
Quick Setup Guide
Wireless Optical Mouse | NS-PNM5003-BK / NS-PNM5003-BU / NS-PNM5003-SV
Package contents
• Wired USB mouse
• Nano receiver
• AA battery (1)
• Quick Setup Guide
Before using your new product, please read these instructions to prevent any damage.
System requirements
• Windows® 8, Windows® 7, Windows Vista®, Windows® XP, or
Mac OS 10.X or higher
• One available USB port
Features
Nano receiver
Connect
button
ON/OFF
switch
Battery cover
Pull
AA battery
Left button
Right button
Scroll wheel
LED indicator
NS-PNM5003-BK_NS-PNM5003-BU_NS-PNM5003-SV_13-1099_QSG_V1.ai 1 1/3/2014 9:44:39 AMNS-PNM5003-BK_NS-PNM5003-BU_NS-PNM5003-SV_13-1099_QSG_V1.ai 1 1/3/2014 9:44:39 AM
V1
FINAL
FOR PRINT
Specications
Mouse:
• Dimension (L×W×H): 3.89 × 2.44 × 1.44 in. (9.9 × 6.2 × 3.67 cm)
• Weight: 1.86 oz. (.05 kg)
• Battery: 1 AA alkaline battery
• Battery life: 6 months (based on average usage)
• Radio frequency: 2.4Ghz
• Operating distance: 33 feet (10 meters)
• Rating: 3V C.C. - 10mA
Nano receiver:
• Dimension (L×W×H): .7 × .6 × .2 in. (1.8 × 1.4 × .6 cm)
• Weight: 1.2 g ± 0.5g
• Interface: USB 1.1, 2.0 , 3.0
Troubleshooting
My mouse is not working.
• Move your mouse and computer closer together.
• Make sure that your computer meets the system requirements.
• Only use the mouse on a clean, at, non-slippery surface to ensure
smooth and accurate cursor action.
• If your mouse stops working:
• Make sure that your mouse and nano receiver are paired by pressing
the connect button on the mouse.
• Replace the mouse battery.
• Try connecting your nano receiver into a dierent USB port on your
computer.
• Avoid using your mouse on reective, transparent, or metallic surfaces.
V1 ENGLISH 13-1099
Legal notices
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
RSS-Gen and RSS-210 statement
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause interference,
and (2) this device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne
doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
RSS-102 statement
This equipment complies with Industry Canada radiation exposure limits set forth for an
uncontrolled environment.
Cet équipement est conforme à l'exposition aux rayonnements Industry Canada limites établies
pour un environnement non contrôlé.
One-year limited warranty
For complete warranty, visit www.insigniaproducts.com.
Contact Insignia
1-877-467-4289 (U.S. and Canada) or 01-800-926-3000 (Mexico)
www.insigniaproducts.com
INSIGNIA is a registered trademark of BBY Solutions, Inc. Registered in some countries.
Distributed by Best Buy Purchasing, LLC, 7601 Penn Ave South, Richeld, MN 55423 U.S.A.
©2014 BBY Solutions, Inc. All Rights Reserved.
LED indicator
Cleaning your mouse
• Wipe the mouse with a damp, lint-free cloth.
Function
Power ON
Low battery warning
Pairing
Pairing failed
Paired successfully
Description
LED is on for 10 seconds, then turns o.
LED blinks for 10 seconds.
LED blinks for 10 seconds after pressing the
Connect button.
After pressing the Connect button, the LED
blinks for 10 seconds, then turns o.
After pressing the Connect button, the LED
blinks, then lights solid for 10 seconds.
LED
indicator
