Actiontec Electronics SBWD100B ScreenBeam Pro Wireless Display Receiver User Manual
Actiontec Electronics Inc ScreenBeam Pro Wireless Display Receiver Users Manual
Users Manual
Wireless Display
Receiver
NEXT
B2 Connect Using Windows 8.1 or Higher
Step1 On a Miracast-enabled Android device, locate and open
the Wireless Display Application.
Note: The name of the Wireless Display Application depends on
the device type and model. Refer to the device’s carrier or
manufacturer user manual for more details.
Step2 The Wireless Display Application scans for available
receivers. Select the ScreenBeam Receiver from the list.
Step3 Wait for the device to associate with the Receiver. When
it does, the device’s screen will be displayed on the HDTV.
© 2014 Actiontec Electronics, Inc. ScreenBeamTM and the Actiontec logo are registered trade-
marks or trademarks of Actiontec Electronics, Inc., in the U.S. or other countries. All other
names are properties of their respective owners.
This product has a 1-year Limited Hardware Warranty and 90-day free software updates from date of purchase.
Local Law
This Limited Warranty Statement gives the customer specic legal rights. The customer may also have
other rights which vary from state to state in the United States, from province to province in Canada, and
from country to country elsewhere in the world.
To the extent that this Limited Warranty Statement is inconsistent with local law, this Statement shall be
deemed modied to be consistent with such local law.
Under such local law, certain disclaimers and limitations of this Warranty
Statement may not apply to the customer.
Go to http://www.actiontec.com/products/warranty.php for more information.
Go to http://international.actiontec.com/support for product
support, updates, and more information including:
• Firmware Updates • Troubleshooting • Registration • FAQs
Part No: 0530-0721-000
Step1 From the Windows desktop,
navigate to the Charms menu and
select Devices. You can also use the
shortcut keys, Windows + K.
Step2 From the Charms menu,
click the Project icon.
Step3 From the Project screen,
select Add a wireless display.
Step4 Select the ScreenBeam
Receiver from the list.
Step5 Enter the PIN as displayed
on the television screen, then
connect and display.
C Product Support & Additional Information
Declarations of Conformity (DoC)
To obtain the complete DoC form in softcopy, go to the
Actiontec Electronics Declarations of Conformity EU/EEA website
at http://international.actiontec.com/support/doc
For GNU General Public License (GPL) related information, go to
http://opensource.actiontec.com
The symbol at right is placed in accordance with the European
Union Directive 2002/96 on the Waste Electrical and
Electronic Equipment (the WEEE Directive). If
disposed of within the European Union, this product
should be treated and recycled in
accordance with the laws of your jurisdiction
implementing the WEEE Directive.
B3 Connect Using Miracast-Enabled Device
C Device Management
You can connect to ScreenBeam Pro from a Miracast-enabled
Android device, such as a smartphone, tablet, or game console (nd
the wireless display feature under Settings). Also, the device should
be running the latest software for best performance.
Device management webpage provides the ability to manage the
receiver’s settings. To access the management web interface:
1. Connect to the Receiver SSID (SSID can be found on the Ready To
Connect screen) from a wireless enabled laptop.
2. Enter the network security key: “12345678” .
3. Open a web browser on the laptop and enter this URL “https://aeis-
ink.” (which is also displayed on the Ready To Connect screen).
Note: Ignore the certificate warning message and allow it as an exception.
4. The Login Username is “Administrator “ and Password is “WiDi” .
Note: If you are running Windows 8.1 and the screens above do
not appear, go to http://www. actiontec.com/widi81 for the latest
software updates.
Installation Guide
This Installation Guide will walk you through the easy steps
to set up your ScreenBeam Pro - Business Edition Receiver.
During this process, we’ll show you how to :
A Install the Receiver
B1 Connect Using Intel WiDi App
B2 Connect Using Windows 8.1 or Higher
B3 Connect Using WiFi
Miracast-Enabled Device
C Device Management
SBBE-qsg-0530-0721-000-EN-v7.indd 1 2014/4/11 10:12:33
Welcome!
Step2 Plug one end of the power cord into the Receiver, and
the other end into a power outlet.
Step3 Plug one end of the supplied HDMI cable into the HDMI
port on the Receiver, and the other end into an available HDMI
port on the HDTV.
NEXT
Flip this Guide over to continue
A Install the Receiver
Congratulations on your purchase of the ScreenBeam Pro - Business
Edition Receiver. Once connect to your compatible mobile device,
you’ll be able to project your device’s screen wirelessly, to a selected
HDTV monitor or projector.
B1 Connect Using Intel WiDi App
Step2 The device scans for
available receivers. Select the same
receiver name as seen on the HDTV
and click Connect. (The Connect
Automatically checkbox is optional.)
Step3 Wait until the Receiver
displays a PIN on the HDTV, and a
PIN entry box on the screen of the
WiDi device. Enter the PIN in the
PIN entry box on the WiDi device,
then click Continue.
Step1 Get the Receiver, Power Adapter, and HDMI cable from
the product box.
Step1Find the Intel Wireless Display application on the device
and launch it. To nd the application, go to Windows Search on
your device and search for “Intel WiDi” in your apps.
Note: Make sure the device supports Intel Wireless Display (WiDi)
software version 3.5 or higher. To nd out what version of Intel
WiDi your device has, enter the Intel WiDi application and click
Help, then navigate to the “About WiDi” section. To obtain the
latest Intel WiDi software and drivers, go to:
http://www.intel.com/go/wirelessdisplayupdate
Step4 The HDTV displays
messages to show the status of the
connection process.
Step4 Make sure the HDTV is turned on and set to display the
input from the correct HDMI port (the one you plugged into
during Step 3).
Display Tip: If the edges of the device screen cannot be seen on
the HDTV, adjust cropping. To do this, enter the WiDi application
and click Settings. Navigate to the “Picture and Sound” section,
click Adjust cropping…, and adjust the HDTV picture by clicking
plus (+) or minus (-).
Step5 Verify that the Ready to
Connect screen appears on
the HDTV.
Step5 A Connection Successful
screen appears on your device’s
screen, as well as on the HDTV.
When Steps 1, 2, and 3 are complete, the hardware should be
connected as shown in the gure, below.
Note: The power outlet and cable may appear dierent than
those shown in the gure.
Note: If your device’s OS is Windows 8.1 or higher, proceed to
section B2 (“Connect Using Windows 8.1 or Higher”) for
connection instructions.
The Receiver is now connected to your HDTV. Proceed to one of
the next three sections of this Guide (depending on the device
you are using to connect to ScreenBeam Pro) to nish the
connection procedure.
SBBE-qsg-0530-0721-000-EN-v7.indd 2 2014/4/11 10:12:33
