Adams Rite 2018 Price List FEB

User Manual: Adams Rite Adams Rite 2018 Price List Price Book

Open the PDF directly: View PDF PDF.
Page Count: 60

Adams Rite
2018 Pricelist
Eective February 1, 2018
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
3
2018 Price List
Adams Rite
Architectural Hardware
Table of Contents ___________________________________________________________________3 – 4
Products
DEADLOCKS
RT1050 RITE Touch®Digital Glass Door Lock ______________________________________________ 5
1830 Bottom Rail Deadlock (Swingbolt) ___________________________________________________ 5
MS1837 Series MS® Two-Point Deadlock __________________________________________________ 5
MS1847 Series MS® Deadlock/Deadlatch _________________________________________________ 6
MS1850S, MS1850S-X5X Series MS® Deadlock ____________________________________________ 6
1850S-X2X Series Short Throw Deadlock _________________________________________________ 7
MS1850SN, MS1850SN-45X Series MS® Deadlock (ANSI Size) _______________________________ 7
MS1861 Series MS® Bottom Rail Deadlock _________________________________________________ 7
1875 Two-Point Deadlock _______________________________________________________________ 8
MS+1890 Series MS® Deadlock/Deadlacth ________________________________________________ 8
MS1950, MS1950-X5X Series MS® Deadlock _______________________________________________ 9
2190, 2290 Dual Force® Interconnected Deadbolt/Deadlatch for
Aluminum Stile Doors (2190); for Wood or Hollow Metal (2290) ____________________________ 10
2331 Heavy Duty Deadbolt ______________________________________________________________11
4070 Series Short Throw Deadbolt (Projection Style) _______________________________________11
5017 Wood Door Deadlock/Deadlatch ____________________________________________________11
5055 Wood Door Deadlock for Sliding Doors _____________________________________________ 12
4189, 4190 Flush Locksets (Including Deadlock) ___________________ moved to Flushlock section
4430, 4431 Flush Locksets (Including Deadlock) ___________________ moved to Flushlock section
DEADLATCHES
4300 Steel Hawk® Electrified Deadlatch _________________________________________________ 12
4300 RITE Pack® ______________________________________________________________________ 13
4510 Standard Duty Deadlatch__________________________________________________________ 13
4530 Standard Duty Deadlatch _________________________________________________________ 14
4781 Two-Point Deadlatch with Paddle __________________________________________________ 14
4900 Heavy Duty Deadlatch ____________________________________________________________ 15
4920AN Heavy Duty Deadlatch (ANSI Size) _______________________________________________ 15
FLUSHLOCKS
1870 Cylinder-Operated Flushbolt ______________________________________________________ 16
1870HM Cylinder-Operated Flushbolt ___________________________________________________ 16
1877 Cylinder-Operated Flushbolt _______________________________________________________ 17
MS1880, MS1881 Two-Point Flushlocks __________________________________________________ 17
MS2180 Auto-Release Two-Point Flushbolt ______________________________________________ 17
4189, 4190 Flush Locksets (Including Deadlock) __________________________________________ 18
4430, 4431 Flush Locksets (Including Deadlock) __________________________________________ 19
B1921, B1923 Reinforcing Pivots __________________ moved to Cylinders and Accessories section
EXIT DEVICES
8099 Dummy Pushbar _________________________________________________________________ 19
3100, 8100 Surface Vertical Rod Exit Device _____________________________________________20
8200 Narrow Stile Surface Vertical Rod Exit Device _______________________________________ 20
3300, 8300 Mortise Exit Device ________________________________________________________ 21
8400 Narrow Stile Mortise Exit Device___________________________________________________ 22
3600, 8500 Metal Door Concealed Vertical Rod Exit Device _______________________________ 23
8600 Narrow Stile Concealed Vertical Rod Exit Device ____________________________________23
3700, 8700 Rim Exit Device ____________________________________________________________ 24
8800 Narrow Stile Rim Exit Device ______________________________________________________ 24
3900, 8900 Wood Door Concealed Vertical Rod Exit Device _______________________________ 25
Accessories for 3000/8000 Series Exit Devices __________________________________________25
Kitted Options for 3000/8000 Series Exit Devices ________________________________________ 25
Modification Options for 3000/8000 Series Exit Devices __________________________________ 26
NEW EX SERIES
EX80 Dummy Push Bar ________________________________________________________________ 26
EX88 Interlocking Rim Exit Device ______________________________________________________26
EX89 Pullman Rim Exit Device __________________________________________________________26
EX76 Concealed Vetical Rod Exit Device _________________________________________________ 26
Accessories for EX Series Exit Devices ___________________________________________________ 26
ELECTRIC STRIKES
7100, 7101 Electric Strikes _____________________________________________________________ 27
7110, 7111 Electric Strikes ______________________________________________________________ 27
7130, 7131 Electric Strikes _____________________________________________________________ 27
7140 Electric Strike ___________________________________________________________________ 28
7160 Electric Strike ___________________________________________________________________ 28
7170 Electric Strike ____________________________________________________________________ 28
7100 Series Electric Strikes Components ________________________________________________ 29
7240 Fire-Rated Electric Strike _________________________________________________________30
7270 Fire-Rated Electric Strike _________________________________________________________30
7400, 7401 Ultraline® Electric Strikes ___________________________________________________30
7410, 7411 Ultraline® Electric Strikes ____________________________________________________ 31
7430, 7431 Ultraline® Electric Strikes ___________________________________________________ 31
7440 Ultraline® Electric Strikes _________________________________________________________ 31
74R1 Ultraline® Electric Strikes _________________________________________________________32
74R2 Ultraline® Electric Strikes _________________________________________________________32
7400 Series Electric Strikes Components ________________________________________________ 33
TABLE OF CONTENTS
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
4TABLE OF CONTENTS
TRIM
1000 Series Turns _____________________________________________________________________ 34
3000 Fixed Pull _______________________________________________________________________ 34
3080 Series Entry Trim _________________________________________________________________ 35
3090, 3090P/C eForce® Keyless Entry __________________________________________________ 36
A100-3090H Keyless Entry and Aperio® Hub Wholesale Kit ________________________________ 36
4060 Turn ____________________________________________________________________________ 37
4550 MS® Deadlock Lever ______________________________________________________________ 37
4560, 4565 Series Deadlatch Handles ___________________________________________________ 38
4568, 4569 Eurostyle Deadlatch Handles ________________________________________________39
4590 Deadlatch Paddle ________________________________________________________________40
4591 Deadlatch Paddle ________________________________________________________________ 41
4600 Heavy Duty Designer Deadlatch Handles __________________________________________ 42
CYLINDERS AND ACCESSORIES
4024, 4025, 4029 Cylinder Pulls _______________________________________________________ 43
4036 Mortise Cylinder ________________________________________________________________ 43
MS4043 Cylinder Guard _______________________________________________________________ 44
4066 Thumbturn ______________________________________________________________________ 44
4580 Cam Disc _______________________________________________________________________ 44
4581 Universal Cam Disc ______________________________________________________________ 45
8650 Cylinder Escutcheon Kit __________________________________________________________ 45
8736 Rim Cylinder ____________________________________________________________________ 45
4014 Two-Point Conversion Kit _________________________________________________________ 45
4015 Threshold Bolt ___________________________________________________________________45
4016 Header Bolt______________________________________________________________________ 46
4085 Header Bolt (Pairs of Doors Only) __________________________________________________ 46
4089 Exit Indicator ____________________________________________________________________ 46
4104 Mounting Bridges ________________________________________________________________ 47
91-0965 Universal Mounting Tab Kits for Installing MS® Locks & Latches ____________________ 47
B1921, B1923 Reinforcing Pivots ________________________________________________________ 47
STRIKES
2190 Dual Force® Interconnected Deadbolt/Deadlatch Strikes _____________________________ 47
2290 Dual Force® Interconnected Deadbolt/Deadlatch Strikes ____________________________ 47
4000 Series MS® Deadlock Strikes ______________________________________________________ 48
4800, MS 4804 Series Strikes __________________________________________________________ 48
4901, 4902 Deadlatch Strikes __________________________________________________________ 49
4304 Deadlatch Strike _________________________________________________________________ 49
THICK DOOR KITS
2190, 2290 Dual Force® Interconnected Deadbolt/Deadlatch Thick Door Kit ________________50
4568, 4569 Eurostyle Deadlatch Handles Thick Door Kits _________________________________ 50
FACEPLATES
MS1850S Deadlocks Faceplates ________________________________________________________50
MS1850S, MS1950 Deadlock (Standard Bolt) Faceplates __________________________________50
MS1850S, MS1950 Deadlock (Hookbolt and Short Bolt) Faceplates ________________________ 51
MS1850SN Deadlock (Standard Bolt) Faceplates__________________________________________ 51
MS1850SN Deadlock (Hookbolt) Faceplates ______________________________________________ 51
1870 Flushbolt Faceplates ______________________________________________________________ 51
MS+1890 Deadlock Faceplates _________________________________________________________ 52
2190 Dual Force® Interconnected Deadbolt/Deadlatch Faceplates __________________________52
2331 Heavy Duty Deadbolt Faceplates __________________________________________________ 52
3300 Fire-Rated Mortise Exit Device Faceplates __________________________________________52
4070 Short Throw Deadbolt Faceplates __________________________________________________ 52
4500 Standard Duty Deadlatch Faceplates_______________________________________________ 52
4530 Standard Duty Deadlatch Faceplates _______________________________________________ 53
4900 Heavy Duty Deadlatch Faceplates _________________________________________________ 53
4900 Heavy Duty Deadlatch Special Faceplates __________________________________________ 53
4920, 8300 Faceplates ________________________________________________________________53
7100, 7160 Electric Strikes Faceplates ___________________________________________________ 53
7101 Electric Strike Faceplates __________________________________________________________ 53
7110 Electric Strike Faceplates __________________________________________________________ 53
7111 Electric Strike Faceplates __________________________________________________________53
7130 Electric Strike Faceplates _________________________________________________________ 54
7131 Electric Strike Faceplates __________________________________________________________54
7140, 7170 Electric Strike Faceplates ____________________________________________________54
POWER
PS-1 Power Supply ____________________________________________________________________55
PS-LR Power Supply ___________________________________________________________________55
PS-SE Power Supply ___________________________________________________________________ 55
4612 Power Transfer Device ____________________________________________________________ 55
4603, 4605, 4606 Accessories for Power ________________________________________________ 55
DEMO MOUNTS
DEADLOCKS & DEADLATCHES
RT1050 RITE Touch® Digital Glass Door Lock _____________________________________________ 56
2190 Dual Force® Interconnected Deadbolt/Deadlatch ____________________________________56
4300 Steel Hawk® Electrified Deadlatch (eLatch) _________________________________________56
ELECTRIC STRIKES
7400 Ultraline® Electric Strikes ________________________________________________________56
EXIT DEVICES
8400 Narrow Stile Mortise Exit Device___________________________________________________ 56
TRIM
3090, 3090P/C eForce® Keyless Entry __________________________________________________ 57
A100-3090H Keyless Entry and Aperio® Hub Wholesale Kit ________________________________ 57
4600 Heavy Duty Designer Deadlatch Handles __________________________________________ 57
General Information
Adams Rite Limited Warranty/Terms and Conditions ______________________________________58
Canadian Terms & Conditions __________________________________________________________58
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
5
RT1050 RITE Touch® Digital Glass Door Lock
MODELS
RT1050D  Digital glass door lock with thumbturn, for single doors, or pairs of doors with one inactive leaf $630
RT1050L  Digital glass door lock with lever, for single doors, or pairs of doors with one inactive leaf $630
RT5C1050  Extra cards (package of 5 cards) $60
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
RITE TOUCH MODEL TRIM
RT 1050 D
1050  For glass doors D  Thumbturn
L  Accessibility lever
1830 Bottom Rail Deadlock (Swingbolt)
sw 1830
MODEL & FINISHES 313, 628
1830  Deadlock with 31/32", or 1-1/8" cylinder height $139
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. DASH NO.
SPECIFY FOR CYLINDER HEIGHT AND LOCK DEPTH FINISH
1830 -02 -628
02  Cylinder Height 31/32" Dim. "A" 1-5/8" 628  Clear Anodized
03  Cylinder Height 1-1/8" Dim. "A" 1-25/32" 313  Dark Bronze Anodized
MS1837 Series MS® Two-Point Deadlock
MODELS & FINISHES 313, 335,
628 605, 626
MS1837  Deadlock includes 4001-011 strike, 36" cylinder height $245 $330
MS1837  Deadlock includes 4001-011 strike, contact factory for cylinder height other than 36"
up to maximum cylinder height 65" $300 $385
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. FINISH
MS1837 -313
313  Dark Bronze Anodized 626  Satin Chrome
335  Black Anodized 628  Clear Anodized
605  Bright Brass
If cylinder height other than 36" is required, specify exact height from bottom of door to cylinder center. Maximum cylinder height 65".
DEADLOCKS
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
6
MS1847 Series MS® Deadlock/Deadlatch
MODEL & FINISH 630
MS1847  Deadlock/deadlatch, stainless steel $61
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. FACE SHAPE, HUB ANGLE, LOCK OR LATCH FINISH
MS1847 -02 -630
(See Configuration table below)
(Blank) -02 -06
-09 -10 -11
-13
SELF-
LATCHING
SELF-
LATCHING
VERT.
VERT.
22.5° 22.5°
45° 45°
45°
630  Satin Stainless
MS1850S,
MS1850S-X5X Series MS® Deadlock
MODELS & BACKSETS 7/8" 31/32", 11/8", OR
11/2"
MS1850S  Flat faceplate, 313, 335, or 628 finish, without strike plate $82 $70
MS1851S  Radius faceplate, 313, 335, or 628 finish, without strike plate $82 $70
MS1851SW  Radius faceplate with weatherstrip, 313, 335, or 628 finish, without strike plate $87 $75
MS1852S  Bevel faceplate, any handing, 313, 335, or 628 finish, without strike plate $82 $70
SPECIAL MODEL 7/8" 31/32", 11/8", OR
11/2"
MS1853SXXXIB  Without faceplate, without strike plate $74 $62
Schoolhouse function for above deadlocks add$36. Please contact factory for more information.
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. FACEPLATE BACKSET BOLT SHAPE HANDING FINISH
MS185 0S -2 1 0 -628
0S  Flat 1  7/8" 1  Straight bolt 0  Non-Handed* 313  Dark Bronze Anodized
1S  Radius 2  31/32" 5  Hookbolt 5  LH or RHR 335  Black Anodized
1SW  Radius with weatherstrip 3  1-1/8" 6  RH or LHR 628  Clear Anodized
2S  Bevel 4  1-1/2"
3  Without faceplace,
without strike plate
*Any flat or radius faceplate, except Schoolhouse. Select handing for bevel faceplate only.
DEADLOCKS
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
7
1850S-X2X Series Short Throw Deadlock
MODELS & FINISHES 313, 335, 628
1850S  Flat faceplate, 31/32", 1-1/8", or 1-1/2" backset, without strike plate $70
1851S  Radius faceplate, 313, 335, or 628 finish, without strike plate $70
1852S  Bevel faceplate, any handing, 313, 335, or 628 finish, without strike plate $70
SPECIAL MODEL
1853SX20IB  Without faceplate, without strike plate $62
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. FACEPLATE BACKSET BOLT SHAPE HANDING FINISH
185 0S 2-2 0-628
0S  Flat 2  31/32" 2  Short Throw 0  Non-Handed* 313  Dark Bronze Anodized
1S  Radius 3  1-1/8" 5  LH or RHR 628  Clear Anodized
2S  Bevel 4  1-1/2" 6  RH or LHR
3  Without faceplace,
without strike plate
*Any flat or radius faceplate, except Schoolhouse. Select handing for bevel faceplate only.
MS1850SN,
MS1850SN-45X Series MS® Deadlock (ANSI Size)
MODELS 313, 335, 628
MS1850SN  Flat faceplate, 1-1/2" backset, without strike plate $99
MS1851SN  Radius faceplate, 1-1/2" backset, without strike plate $99
MS1852SN  Bevel faceplate, any handing, 1-1/2" backset, without strike plate $99
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. FACEPLATE ANSI SIZE BOLT SHAPE HANDING FINISH
MS185 0SN -41 0-628
0  Flat 41  Straight bolt 0  Non-Handed* 313  Dark Bronze Anodized
1  Radius 45  Hookbolt 5  LH or RHR 335  Black Anodized
2  Bevel 6  RH or LHR 628  Clear Anodized
*Any flat or radius faceplate, except Schoolhouse. Select handing for bevel faceplate only.
MS1861 Series MS® Bottom Rail Deadlock
sw ms 1861
MODELS & FINISH 603
MS186101  One-point deadlock, vertical bolt operation only $145
MS186102  Two-point deadlock, horizontal and vertical operation $180
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. BOLT OPERATION FINISH PACKAGING
MS1861 -01 -603 -IB
01  Vertical Bolt Only 603  Zinc plated steel IB  Individually Boxed
02  Vertical and Horizontal Bolts
If tube spacers are required, please specify quantity and length.
DEADLOCKS
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
8
1875 Two Point Deadlock
MODEL & FINISH 603
1875  Two-point deadlock for roll-up doors $180
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. PACKAGING
1875 -IB
IB  Individually Boxed
MS+1890 Series MS® Deadlock/Deadlatch
MODELS & FINISHES 313, 335, 628
MS+1890  Flat faceplate, 31/32", 1-1/8", or 1-1/2" backset $243
MS+1891  Radius faceplate, 31/32", 1-1/8", or 1-1/2" backset $243
MS+1891W  Radius faceplate with weatherstrip, 31/32", 1-1/8", or 1-1/2" backset $253
MS+1892  Bevel faceplate, any handing, 31/32", 1-1/8", or 1-1/2" backset $243
SPECIAL MODELS
MS+1890  Flat, radius, or bevel faceplate, complete with flat / center hung 4" or 4-1/2" strike plate $255
MS+1893XXIB  Without faceplate, without strike plate $187
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. FACEPLATE BACKSET STRIKE SHAPE/LIP LENGTH HANDING FINISH
MS+189 1-3 02 6-628
0  Flat 2  31/32" 01  Flat/Standard Jamb 5  LH or RHR 313  Dark Bronze Anodized
1  Radius 3  1-1/8" 02  Radius/Standard Stile 6  RH or LHR 335  Black Anodized
1W  Radius with weatherstrip 4  1-1/2" 17  Flat/Center Hung 4" Jamb 628  Clear Anodized
2  Bevel 21  Flat/Center Hung 4-1/2" Jamb
3  Without faceplace,
without strike plate
For door thickness other than 1-3/4", please contact factory.
DEADLOCKS
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
9
MS1950,
MS1950-X5X Series MS® Deadlock
MODELS 313, 335, 628
MS1950  Flat faceplate, 31/32", 1-1/8", or 1-1/2" backset, without strike plate $128
MS1951  Radius faceplate, 31/32", 1-1/8", or 1-1/2" backset, without strike plate $128
MS1951W  Radius faceplate with weatherstrip, 31/32", 1-1/8", or 1-1/2" backset, without strike plate $133
MS1952  Bevel faceplate, any handing,31/32", 1-1/8", or 1-1/2" backset, without strike plate $128
SPECIAL MODEL
MS1953SXXXIBWithout faceplate, without strike plate $120
Schoolhouse function for above deadlocks add$36. Please contact factory for more information.
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. FACEPLATE BACKSET BOLT SHAPE HANDING FINISH
MS195 0-2 1 0 -628
0  Flat 2  31/32" 1  Straight bolt 0  Non-Handed* 313  Dark Bronze Anodized
1  Radius 3  1-1/8" 5  Hookbolt 5  LH or RHR 335  Black Anodized
1W  Radius with weatherstrip 4  1-1/2" 6  RH or LHR 628  Clear Anodized
2  Bevel
3  Without faceplace,
without strike plate
*Any flat or radius faceplate, except Schoolhouse. Select handing for bevel faceplate only.
DEADLOCKS
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
10
2190, 2290 Dual Force® Interconnected Deadbolt/Deadlatch for Aluminum Doors
(2190); for Wood or Hollow Metal (2290)
STANDARD TRIM
SET ELECTRIFIED
TRIM SET LOW PROFILE
TRIM
MODELS & TRIM SETS 10B,
US4,
US32D
US3,
US32
10B,
US4,
US32D
US3,
US32
10B,
US4,
US32D
US3,
US32
STANDARD
LEVER
2190, 2290 Deadbolt/Deadlatch with standard
lever (01, 02, 03), complete with strike plate $615 $695 $775 $855 $540 $620
2190 Deadbolt/Deadlatch with standard lever
(01, 02, 03), complete with flat/center hung 4" or 4-1/2" strike plate $630 $710 $790 $870 $555 $635
2190, 2290 Deadbolt/Deadlatch with standard
lever (01, 02, 03), without strike plate $590 $670 $750 $830 $515 $595
DESIGNER
LEVER
2190, 2290 Deadbolt/Deadlatch with designer lever
series (MD through MW), complete with strike plate $660 $740 $820 $900 $585 $665
2190 Deadbolt/Deadlatch with with designer
lever series (MD through MW), complete with flat/
center hung 4" or 4-1/2" strike plate
$675 $755 $835 $915 $600 $680
2190, 2290 Deadbolt/Deadlatch with designer lever
series (MD through MW), without strike plate $635 $715 $795 $875 $560 $640
MODELS & FINISHES 313, 335, 628 N/A
2190, 2290  Boxed Lock
Less lever trim, with adjustable faceplate and choice of standard or radius strike $290
EK2190  Electrification Kit for 2190, 2290; 12/24 VAC/VDC (not compatible with low profile trim) $169
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT
NO. BACKSET STRIKE FACEPLATE FINISH TRIM* HANDLE DESIGNATION TRIM AND HANDLE
FINISH
2190 -3 1 1 -1 01 32D
3  1-1/8" 0  None 1  Clear Anodized 628 0  None 00  No Handle 03  Bright Brass (US3)
4  1-1/2" 1  Standard Flat 2  Dark Bronze Anodized 313 1  With Trim Set* STANDARD SERIES: 04  Satin Brass (US4)
2  Radius Strike 3  Black Anodized 335 2  With Electrified Trim Set* 01  Curve 10B  Dark Bronze
3  Flat/Center Hung 4" 3  Low Profile Trim 02  Round 32  Bright Stainless (US32)
4  Flat/Center Hung 4-1/2" 03  Square 32D  Satin Stainless (US32D)
DESIGNER SERIES:
MD MG MJ MV (Handed)
ME MI MN (Handed) MW
*Trim options 1 and 2 are suitable for outswing doors only.
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT
NO. BACKSET STRIKE FACEPLATE FINISH TRIM* HANDLE DESIGNATION TRIM AND HANDLE
FINISH
2290 -3 1 1 -1 01 32D
3  1-1/8" 0  None 0  US to match trim finish 0  None 00  No Handle 03  Bright Brass (US3)
4  1-1/2" 1  Standard Flat 1  Clear Anodized 628 1  With Trim Set* STANDARD SERIES: 04  Satin Brass (US4)
2  Dark Bronze Anodized 313 2  With Electrified Trim Set* 01  Curve 10B  Dark Bronze
3  Black Anodized 335 3  Low Profile Trim 02  Round 32  Bright Stainless (US32)
03  Square 32D  Satin Stainless (US32D)
DESIGNER SERIES:
MD MG MJ MV (Handed)
ME MI MN (Handed) MW
*Trim options 1 and 2 are suitable for outswing doors only.
DEADLOCKS
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
11
2331 Heavy Duty Deadbolt
MODEL & FINISHES 121, 626 605,
625
2331  Deadbolt, 1-3/4" backset, complete with strike $306 $336
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. FINISH
2331 -626
121  To Match 313 Dark Bronze Anodized
605  Bright Brass
625  Bright Chrome
626  Satin Chrome
4070 Series Short Throw Deadbolt (Projection Style)
MODELS & FINISHES 313, 335, 628
4070  Flat faceplate, 7/8", 31/32", or 1-1/8" backset, without strike plate $169
4071  Radius faceplate, 7/8", 31/32", or 1-1/8" backset, without strike plate $169
4072  Bevel faceplate, any handing, 7/8", 31/32", or 1-1/8" backset, without strike plate $169
SPECIAL MODEL
4073XXIB  Without faceplate, without strike plate $159
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. FACEPLATE BACKSET HANDING FINISH
407 2-2 6-628
0  Flat 1  7/8" 0  Non-Handed* 313  Dark Bronze Anodized
1  Radius 2  31/32" 5  LH or RHR 335  Black Anodized
2  Bevel 3  1-1/8" 6  RH or LHR 628  Clear Anodized
3  Without faceplace,
without strike plate
*Any flat or radius faceplate. Select handing for bevel faceplate only.
5017 Wood Door Deadlock/Deadlatch
MODELS & FINISH 630
501700  Standard stainless steel deadlock $61
501702  Self-latching deadlock/deadlatch $61
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. LATCH CONFIGURATION
5017 -00
00  Standard
02  Self Latching
DEADLOCKS
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
12
5500 Wood Door Deadlock for Sliding Doors
MODELS 119, 626
550020  Lockset, strike, and trim included for 1-1/4", sliding wood doors $130
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. DOOR THICKNESS FINISH
5500 -20 -626
20  1-1/4" Thick 626  Satin Chrome
119  to Match 335 Black Anodized
DEADLATCHES
4300 Steel Hawk® Electrified Deadlatch (eLatch)
MODELS & FINISHES 313, 335, 628
4300  Electrified deadlatch 31/32", 1-1/8", or 1-1/2" backset $423
4300M  Monitored option, 31/32", 1-1/8", or 1-1/2" backset $483
SPECIAL MODELS 313, 335, 628
4300  Electrified deadlatch complete with flat / center hung 4" or 4-1/2" strike plate $443
4300M  Electrified deadlatch with monitored option, complete with flat / center hung 4" or 4-1/2" strike plate $503
HOW TO ORDERSpecify quantity and the following information. Order related products separately
PRODUCT NO. BACKSET MONITORING STRIKE STIRKE SHAPE/LIP LENGTH FACEPLATE FINISH
4300 -3 M-2 01 -628
2  31/32" 0  None 1  Surface Mount (4304) 01  Flat/Standard Jamb 313  Dark Bronze Anodized
3  1-1/8" M  Monitored 2  Mortised (4901) 4-5/8" 02  Radius/Standard Stiles** 335  Black Anodized
4  1-1/2" 17  Flat/Center Hung 4" Jamb** 628  Clear Anodized
21  Flat/Center Hung 4-1/2" Jamb**
** See ACCESSORIES for available 4901 strike options.
DEADLOCKS | DEADLATCHES
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
13
DEADLATCHES
4300 RITE Pack®
MODELS 313, 628
430020  31/32" backset, flat and radius, 313 and 628 finish faceplates, surface mount or mortise strike $433
430030  1-1/8" backset, flat and radius, 313 and 628 finish faceplates, surface mount or mortise strike $433
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. BACKSET MONITORING STRIKE RITE PACK
4300 -3 0-1 RP
2  31/32" 0  None 1  Surface Mount (4304)
3  1-1/8" 2  Mortised (4901) 4-5/8"
4510 Standard Duty Deadlatch
MODELS & FINISHES 313, 335, 628
4510  Flat faceplate, 7/8", 31/32", 1-1/8", or 1-1/2" backset, complete with strike plate $83
4511  Radius faceplate, 7/8", 31/32", 1-1/8", or 1-1/2" backset, complete with strike plate $83
4511W  Radius faceplate with weatherstrip, 7/8", 31/32", 1-1/8", or 1-1/2" backset, complete with strike plate $88
4512  Bevel faceplate, 7/8", 31/32", 1-1/8", or 1-1/2" backset, complete with strike plate $83
SPECIAL MODELS
4510  Flat, radius or bevel faceplate complete with flat / center hung 4" or 4-1/2" strike plate $103
4511W  Radius faceplate with weatherstrip complete with flat / center hung 4" or 4-1/2" strike plate $108
4510  With faceplate, without strike plate $67
4511W  Radius faceplate with weatherstrip, without strike plate $72
4513XXIB  Without faceplate, without strike plate $59
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. FACEPLATE BACKSET HANDING STRIKE SIZE STRIKE SHAPE/LIP LENGTH FACEPLATE FINISH
451 1-3 6-2 01 -628
0  Flat 1  7/8" 5  LH or RHR 1  Mortised
(4901) 4-5/8" 01  Flat/Standard Jamb 313  Dark Bronze
Anodized
1  Radius 2  31/32" 6  RH or LHR 2  Mortised
(4902) 2-5/8" 02  Radius/Standard Stiles 335  Black Anodized
1W  Radius with
weatherstrip 3  1-1/8" 17  Flat/Center Hung 4" Jamb 628  Clear Anodized
2  Bevel 4  1-1/2" 21  Flat/Center Hung 4-1/2" Jamb
3  Without faceplate,
without strike plate
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
14 DEADLATCHES
4530 Standard Duty Deadlatch
MODELS & FINISHES 313, 335, 628
4530  Flat faceplate, 7/8", 31/32", or 1-1/8" backset, complete with strike plate $101
4531  Radius faceplate, 7/8", 31/32", or 1-1/8" backset, complete with strike plate $101
4532  Bevel faceplate, 7/8", 31/32", or 1-1/8" backset, complete with strike plate $101
SPECIAL MODELS
4530  Flat, radius or bevel faceplate complete with flat / center hung 4" or 4-1/2" strike plate $121
4530  With faceplate without strike plate $85
4533XXIB  Without faceplate, without strike plate $77
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. FACEPLATE BACKSET HANDING STRIKE SIZE STRIKE SHAPE/LIP LENGTH FACEPLATE FINISH
453 1-3 6-1 01 -628
0  Flat 1  7/8" 5  LH or RHR 1  Mortised (4901) 4-5/8" 01  Flat/Standard Jamb 313  Dark Bronze Anodized
1  Radius 2  31/32" 6  RH or LHR 2  Mortised (4902) 2-5/8" 02  Radius/Standard Stiles 335  Black Anodized
2  Bevel 3  1-1/8" 17  Flat/Center Hung 4" Jamb 628  Clear Anodized
3  Without
faceplate,
without
strike plate
21  Flat/Center Hung 4-1/2" Jamb
4781 Two-Point Deadlatch with Paddle
MODEL & FINISHES 313, 335,
628 US26D
4781  Paddle includes dogging feature $322 $432
4781T  Paddle with top rod only (less bottom rod) $292 $402
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. OPERATION PADDLE FINISH
4781 T-021 -628
T  Top rod only 021  Push to LEFT 313  Dark Bronze Anodized US26D  Satin Chrome
  Standard rod 041  Push to RIGHT 335  Black Anodized
628  Clear Anodized
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
15
4900 Heavy Duty Deadlatch
MODELS & FINISHES 313, 335,
628
4900  Flat and radius faceplates, 31/32", 1-1/8", or 1-1/2" backset, complete with strike plate $113
4911W  Radius with weatherseal faceplate, 31/32", 1-1/8", or 1-1/2" backset, complete with strike plate $118
SPECIAL MODELS
4900  Flat and radius faceplates complete with flat / center hung 4" or 4-1/2" strike plate $133
4911W  Radius with weatherstrip faceplate complete with flat / center hung 4" or 4-1/2" strike plate $138
4900  Flat and radius faceplate, without strike plate $97
4911W  Radius with weatherstrip faceplate, without strike plate $102
4913XXIB  Without faceplate, without strike plate $89
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. FACEPLATE BACKSET HANDING STRIKE SIZE STRIKE SHAPE/LIP LENGTH FACEPLATE FINISH
49 00 -3 5-2 01 -628
00  Standard 2  31/32" 5  LH or RHR 1  Mortised
(4901) 4-5/8" 01  Flat/Standard Jamb 313  Dark Bronze
Anodized
11W  Radius with
Weatherstrip 3  1-1/8" 6  RH or LHR 2  Mortised
(4902) 2-5/8" 02  Radius/Standard Stile 335  Black Anodized
13  Without faceplate,
without strike plate
4  1-1/2" 17  Flat/Center Hung 4" Jamb 628  Clear Anodized
21  Flat/Center Hung 4-1/2" Jamb
4920AN Heavy Duty Deadlatch (ANSI Size)
MODELS & FINISHES 313, 335,
628
4920AN  Flat faceplate, 1-1/2" or 2-3/4" backset, complete with 4506 strike plate $138
SPECIAL MODELS
4920AN  Flat faceplate, without strike plate $102
4923ANXXIB  Without faceplate, without strike plate $80
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. FACEPLATE BACKSET HANDING STRIKE FACEPLATE FINISH
4920AN 0AN 4 6 -602 -313
OAN  Flat 4  1-1/2" 5  LH or RHR 000  Less Strike 313  Dark Bronze
Anodized
3AN  Without faceplate,
without strike plate 5  2-3/4" 6  RH or LHR 602  4506 Strike 335  Black Anodized
628  Clear Anodized
DEADLATCHES
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
16 FLUSHLOCKS
1870 Cylinder-Operated Flushbolt
sw 1870 series
MODELS & CYLINDER HEIGHT STANDARD 12"
CYLINDER HEIGHT CYLINDER HEIGHT
OVER 12" SPECIFY
1870  Flat faceplate, 313, 335, or 628 finish $117 $167
1871  Radius faceplate, 313, 335, or 628 finish $117 $167
1871W  Radius faceplate with weatherstrip, 313, 335, or 628 finish $122 $172
1872  Bevel faceplate, 313, 335, or 628 finish $117 $167
For cylinder height greater than 12" up to maximum cylinder height 65" please contact factory.
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. FACEPLATE SHAPE BACKSET HANDING* FINISH
187 0-2 0-628
0  Flat 2  31/32" 0  Non-Handed* 313  Dark Bronze Anodized
1  Radius 3  1-1/8" 5  LH or RHR 335  Black Anodized
1W  Radius with weatherstrip 6  RH or LHR 628  Clear Anodized
2  Bevel
*Any flat or radius faceplate. Select handing for bevel faceplate only.
1870HM Cylinder-Operated Flushbolt
MODEL & CYLINDER HEIGHT STANDARD 131/2"
CYLINDER HEIGHT
CYLINDER HEIGHT
OVER 131/2"
SPECIFY
1870HM  For hollow metal, 313, 335, or 628 finish, 1-1/4" backset $157 $207
For cylinder height greater than 13-1/2" up to maximum cylinder height 65" please contact factory.
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. FACEPLATE SHAPE FINISH
187 0HM -628
0HM  Flat 313  Dark Bronze Anodized
335  Black Anodized
628  Clear Anodized
1877 Cylinder-Operated Flushbolt
MODEL & CYLINDER HEIGHT STANDARD 131/2"
CYLINDER HEIGHT
CYLINDER HEIGHT
OVER 131/2"
SPECIFY
1877  For wood, 313 or 628 finish, 1-1/4" backset $195 $245
1877  For wood, 605 or 626 finish, 1-1/4" backset $275 $325
For cylinder height greater than 13-1/2" up to maximum cylinder height 57-1/2" please contact factory.
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. FINISH
1877 -628
313  Dark Bronze Anodized 626  Satin Chrome
605  Bright Brass 628  Clear Anodized
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
17
FLUSHLOCKS
MS1880, MS1881 Two-Point Flushbolts
sw ms 1880
MODELS & FINISHES 119, 121, 682
MS1880  Flushbolt with hourglass shaped turn $149
MS1881  Flushbolt with teardrop shaped turn $149
KITTED OPTION
MODEL
TDK1880Tall door kit for doors over 84", up to 144" maximum $28
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. TURN SHAPE CYLINDER HEIGHT* FINISH
MS188 0-01 -682
MS188 0  Hourglass 01  31" to 35" 119  to Match 335 Black Anodized
1  Teardrop 02  35-1/16" to 39" 121  to Match 313 Dark Bronze Anodized
03  39-1/16" 43" 682  Satin Chrome
04  43-1/16" to 47"
05  47-1/16" to 51"
*Distance from floor to cylinder centerline.
MS2180 Auto-Release Two-Point Flushbolt
MODELS & FINISHES 119, 121, 130
MS2180  Hourglass shaped turn, 7', 8', 9', 10' door height $224
MS2181  Teardrop shaped turn, 7', 8', 9', 10' door height $224
MS2182  Flush operator, 7', 8', 9', 10' door height $224
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. TURN SHAPE DOOR HEIGHT
FROM FLOOR TO TOP OF DOOR FINISH TO MATCH
MS218 0-07 -130
0  Hourglass 07  Up to 7' Door 119  to Match 335 Black Anodized
1  Teardrop 08  Up to 8' Door 121  to Match 313 Dark Bronze Anodized
2  Flush Operator 09  Up to 9' Door 130  to Match 628 Clear Anodized
10  Up to 10' Door
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
18
4189, 4190 Flush Locksets (Including Deadlock)
MODELS & FINISHES STANDARD
LOCK FACE STAINLESS STEEL
LOCK FACE
4189IB  Flush lockset, 119, 121, or 130 finish, individually boxed $98 $108
4190IB  Flush lockset, 119, 121, or 130 finish, individually boxed with cylinder $128 $138
4195IB  Dummy flushset, 119, 121, or 130 finish, individually boxed $68 $78
SPECIAL MODEL
418900  Flush operator without lock $78
419000  Flush operator without lock $108
KITTED OPTIONS
MODELS GRAY
441301, 441302  Grip pull for use with 4189, 4190 $23
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT
NO.
LOCKSET
EXTERIOR LOCK FACE STILE
THICKNESS FINISH KEYING OPTIONS* PACKAGING
41 90 -09 -01 -130 -01 IB
89  Without Cylinder 00  Without Lock 01  1" to 1-3/8" 119  To match 335
Black Anodized 00  Without Cylinder IB  Individually Boxed
90  With Cylinder 09  Radius 02  1-7/16" to
1-5/8"
121  To match 313
Dark Bronze Anodized 01  Keyed Dierent
95  Dummy
09S  Radius
Stainless
Steel
03  1-11/16" to 2" 130  To match 628
Clear Anodized 02  Keyed alike in pairs
10  Square
10S  Square
Stainless
Steel
*Keyed alike 50 are availiable by special order in quantity of 50 locksets only. Please contact factory for ordering information.
FLUSHLOCKS
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
19
FLUSHLOCKS | EXIT DEVICES
4430, 4431 Flush Locksets (Including Deadlock)
MODELS & FINISH STANDARD
LOCK FACE
STAINLESS
STEEL LOCK
FACE
4430IB  ABS flush lockset, individually boxed $68 $78
4431IB  ABS flush lockset with cylinder, individually boxed $103 $113
4432IB  ABS dummy flushset, individually boxed $33 $43
SPECIAL MODEL
443000  ABS operator without lock $48
443100  ABS operator without lock $83
KITTED OPTIONS
MODELS & FINISHES 335
445302335IB  Grip pull for use with 4430, 4431 $36
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. LOCKSET EXTERIOR LOCK FACE STILE THICKNESS KEYING OPTIONS* PACKAGING
44 31 -09 -05 -01 -IB
30  Without Cylinder 00  Without Lock 00  1" to 1-5/16" 00  Without Cylinder IB  Individually Boxed
31  With Cylinder 09  Radius 05  1-3/8" to 1-5/8" 01  Keyed Dierent
32  Dummy 09S  Radius Stainless Steel 08  1-3/4" to 2" 02  Keyed alike in pairs
10  Square
10S  Square Stainless Steel
*Keyed alike 50 are availiable by special order in quantity of 50 locksets only. Please contact factory for ordering information.
EXIT DEVICES
Alarm option cannot be combined with any other Device Option or Monitoring Option. Split finishes (faceplate/pushbar) are not
available. Matching end cap option available for US finishes only. Please contact factory for specific ordering questions.
8099 Dummy Pushbar
MODELS & FINISHES 313,
335,
628
US4,
US32D US3,
US32
809900  Dummy pushbar without mechanism, for doors NOT requiring an exit device. $230 $485 $545
8099M0  Active dummy bar without latching mechanism, without monitoring switches. $300
8099M1  Active dummy bar with monitoring switch but without latching mechanism. May be
wired normally open or normally closed to operate maglock, alarm or similar. $355 $610 $670
8099M2  Active dummy bar with two monitoring switches but without latching mechanism. May
be wired normally open or normally closed to operate maglock, alarm or similar. $415 $670 $730
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. MONITOR DOOR TYPE PUSHBAR FINISH WIDTH US FINISH
8099 -M1 -3 036 -US32
00  Inactive Dummy Bar 3  Aluminum 0  US Finish 30  30 inches US3  Bright Brass
M0  Active Dummy Bar, no monitoring switches 4  Wood or hollow metal 1  Clear Anodized 628 36  36 inches US4  Satin Brass
M1  Active Dummy Bar, one monitoring switch 2  Dark Bronze Anodized 313 42  42 inches US32  Bright Stainless
M2  Active Dummy Bar, two monitoring switches 3  Black Anodized 335 48  48 inches US32D  Satin Stainless
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
20
3100, 8100 Surface Vertical Rod Exit Device
MODELS & FINISHES 313, 335, 628 US4, US32D US3, US32
8100  Surface vertical rod exit device for wood and hollow metal $910 $1,210 $1,370
8100T  Top rod only (less bottom rod) SVR exit device $835 $1,135 $1,295
3100  Fire-rated surface vertical rod exit device for wood and hollow metal $1,160 $1,460 $1,620
3100T  Fire-rated top rod only (less bottom rod) for metal doors $1,085 $1,385 $1,545
3100W  Fire-rated top rod only (less bottom rod) for wood doors $1,085 $1,385 $1,545
KITTED OPTIONS
MODELS & FINISHES 313, 335, 628 US32D US32
3055  Tall door kit for doors up to 10' tall, for use with 3100 $130 $165 $195
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
MODEL PUSHBAR FINISH ROD TYPE DEVICE OPTIONS MONITORING
OPTION
DOOR OPENING WIDTH
On pair of doors, specify HALF
of the total exit opening
US FINISH
END CAPS
OPTION
FOR US FINISH
81 00 -SE M2 -30 -US32D MEC
31  Fire Rated 00  US Finish T  Top Rod only LR  Electric Latch Retraction M  Single Switch 30  30 inches US3  Bright Brass MEC  Matching
End Caps
81  Life-Safety 11  Clear Anodized 628 W  Top Rod only -
Wood doors
SE  Silent Electrification
Latch Retraction M2  Dual Switch 36  36 inches US4  Satin Brass
22  Dark Bronze
Anodized 313  Standard rod C  Cylinder Dogging (non-fire
rated devices ONLY)
BLANK 
No Monitor 42  42 inches US32  Bright Stainless
33  Black Anodized 335 ED  Electric Dogging 48  48 inches US32D  Satin Stainless
BLANK  No Option AXXB  Alarmed Exit Device where XX
is door opening width
* Please note that 30" exit devices cannot accommodate monitoring options, except when ordered in conjunction with the SE option.
8200 Narrow Stile Surface Vertical Rod Exit Device
MODELS & FINISHES 313, 335, 628 US4, US32D US3, US32
8200  Narrow stile surface vertical rod exit device $855 $1,155 $1,315
8200T  Top rod only (less bottom rod) SVR exit device $780 $1,080 $1,240
SPECIAL MODELS 313, 335, 628 US4, US32D US3, US32
820099  SVR exit device, less rods $765 $1,065 $1,225
KITTED OPTIONS
MODELS & FINISHES 313, 335, 628 US32D US32
805501  Tall door kit for doors up to 10' tall, for use with 8100, 8200 $120 $155 $185
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
MODEL PUSHBAR FINISH ROD TYPE DEVICE OPTIONS MONITORING
OPTION
DOOR OPENING WIDTH
On pair of doors, specify HALF
of the total exit opening
US FINISH END CAPS OPTION
FOR US FINISH
82 00 -ED M2 -36 -US3
82  Life-Safety 00  US Finish T  Top Rod only LR  Electric Latch Retraction M  Single Switch 30  30 inches US3  Bright Brass MEC  Matching
End Caps
11  Clear Anodized 628   Standard rod SE  Silent Electrification
Latch Retraction M2  Dual Switch 36  36 inches US4  Satin Brass
22  Dark Bronze
Anodized 313 C  Cylinder Dogging BLANK
No Option 42  42 inches US32  Bright Stainless
33  Black Anodized 335 ED  Electric Dogging 48  48 inches US32D  Satin Stainless
BLANK  No Option AXXB  Alarmed Exit Device where XX
is door opening width
EXIT DEVICES
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
21
3300, 8300 Mortise Exit Device
MODELS & FINISHES 313, 335, 628 US4, US32D US3, US32
8300  Mortise exit device for wood and hollow metal $705 $1,005 $1,105
3300  Fire-rated mortise exit device for wood and hollow metal $1,005 $1,305 $1,405
KITTED OPTIONS
MODELS & FINISH US32D
400901Open back strike for 1-3/4" thick doors $135
For complete list of kitted options for mortise exit devices, please refer to 8400 Narrow Stile Mortise Exit Devices on next page.
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
MODEL FACEPLATE
FINISH
FACE
SHAPE DEVICE OPTIONS MONITORING
OPTION
DOOR
HANDING
PUSHBAR
FINISH
DOOR OPENING WIDTH
On pair of doors, specify
HALF of the total exit opening
US FINISH
END CAPS
OPTION FOR
US FINISH
83 3 0 ED M-7 3A36B
33  Fire Rated 0  US Finish
0  Flat
(3300
only)
LR  Electric Latch
Retraction M  Single Switch 7  RHR 0  US Finish 30  30 inches US3  Bright Brass MEC Matching
End Caps
83  Life-Safety
1  Clear
Anodized
628
2  Bevel
(8300
only)
SE  Silent Electrification
Latch Retraction M2  Dual Switch 8  LHR 1  Clear
Anodized 628 36  36 inches US4  Satin Brass
2  Dark Bronze
Anodized
313
C  Cylinder Dogging
(non-fire rated
devices ONLY)
BLANK
No Monitor
2  Dark Bronze
Anodized 313 42  42 inches US32  Bright
Stainless
3  Black
Anodized
335
ED  Electric Dogging
3  Black
Anodized
335
48  48 inches US32D  Satin
Stainless
- Without Options AXXB  Alarmed Exit Device where
XX is door opening width
*Please note that 30" exit devices cannot accommodate monitoring options, except when ordered in conjunction with the SE option.
EXIT DEVICES
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
22
8400 Narrow Stile Mortise Exit Device
MODEL & FINISHES 313, 335, 628 US4, US32D US3, US32
8400  Narrow stile mortise exit device $630 $930 $1,030
Please contact factory for information on the 8475 Midpanel Mortise Exit Device.
Pricing is standard pricing plus unique door cutting charge for custom cut length.
KITTED OPTIONS
MODELS US32D
845501  Long face strike for covering MS strike prep $98
846017630  Long lip strike for jambs that project outward 2-1/4" beyond the centerline of door $75
91099502IP  2" thick door kit for use with 8300, 8400 $17
91099503IP  2-1/4" thick door kit for use with 8300, 8400 $17
91099504IP  2-1/2" thick door kit for use with 8300, 8400 $20
91099505IP  2-3/4" thick door kit for use with 8300, 8400 $25
91099506IP  3" thick door kit for use with 8300, 8400 $25
91032501  Thermal door kit, 1/4" cladding, for use with 8400 $80
91032502  Thermal door kit, 1/2" cladding, for use with 8400 $145
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
MODEL FACEPLATE
FINISH FACE SHAPE DEVICE OPTIONS MONITORING
OPTION BACKSET DOOR
HANDING
PUSHBAR
FINISH
DOOR OPENING WIDTH
On pair of doors, specify
HALF of the total exit
opening
US FINISH
END CAPS
OPTION FOR
US FINISH
84 1 4 SE M2 -4 7 1 42
84  Life-
Safety 0  US Finish 0  Flat, Radius,
Bevel
LR  Electric Latch
Retraction M  Switch 2  31/32" 7  RHR 0  US Finish 30  30 inches US3  Bright Brass
MEC
Matching
End Caps
1  Clear
Anodized
628
4  Radius w/
Weatherstrip*
SE  Silent
Electrification
Latch
Retraction
M2  Dual
Switch 3  1-1/8" 8  LHR
1  Clear
Anodized
628
36  36 inches US4  Satin Brass
2  Dark
Bronze
Anodized
313
C  Cylinder
Dogging
BLANK
No Monitor 4  1-1/2"
2  Dark
Bronze
Anodized
313
42  42 inches US32  Bright
Stainless
3  Black
Anodized
335
ED  Electric
Dogging
3  Black
Anodized
335
48  48 inches US32D  Satin
Stainless
  Without Options AXXB  Alarmed Exit Device where
XX is door opening width
*Radius with weatherstrip faceplate is not available in US finishes.
EXIT DEVICES
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
23
3600, 8500 Metal Door Concealed Vertical Rod Exit Device
MODELS & FINISHES 313, 335, 628 US4, US32D US3, US32
8500  Concealed vertical rod exit device for hollow metal $665 $965 $1,065
8500T  Top rod only (less bottom rod) CVR exit device $590 $890 $990
3600  Fire-rated concealed vertical rod exit device for hollow metal $1,085 $1,385 $1,485
3600T  Fire-rated top rod only (less bottom rod) CVR exit device $1,010 $1,310 $1,410
KITTED OPTIONS
MODEL
3655  Tall door kit for doors taller than 66" above bar height, up to 10' $58
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
MODEL PUSHBAR FINISH ROD TYPE DEVICE OPTIONS MONITORING
OPTION
DOOR OPENING WIDTH
On pair of doors, specify
HALF of the total exit opening
US FINISH
END CAPS
OPTION FOR US
FINISH
85 00 TED M-36 -US32D
36  Fire Rated 00  US Finish T  Top Rod only LR  Electric Latch Retraction M  Single Switch 30  30 inches US3  Bright Brass MEC  Matching
End Caps
85  Life-Safety 11  Clear Anodized 628  Standard rod SE  Silent Electrification
Latch Retraction M2  Dual Switch 36  36 inches US4  Satin Brass
22  Dark Bronze
Anodized 313
C  Cylinder Dogging
(non-fire rated
devices only)
BLANK
No Monitor 42  42 inches US32  Bright Stainless
33  Black Anodized 335 ED  Electric Dogging 48  48 inches US32D  Satin Stainless
BLANK  No Option AXXB  Alarmed Exit Device where
XX is door opening width
*Please note that 30" exit devices cannot accommodate monitoring options, except when ordered in conjunction with the SE option.
8600 Narrow Stile Concealed Vertical Rod Exit Device
MODELS & FINISHES 313, 335, 628 US4, US32D US3, US32
8600  Narrow stile concealed vertical rod exit device $620 $920 $1,020
8600T  Top rod only (less bottom rod) CVR exit device $545 $845 $945
SPECIAL MODELS 313, 335, 628 US4, US32D US3, US32
860099  CVR exit device, less rods $535 $835 $935
Please contact factory for information on the 8675 Midpanel CVR Exit Device.
Pricing is standard pricing plus unique door cutting charge for custom cut length.
KITTED OPTIONS
MODEL
8655  Tall door kit for doors up to 10’ for use with 8500, 8600 $53
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
MODEL PUSHBAR FINISH ROD TYPE DEVICE OPTIONS MONITORING
OPTION
DOOR OPENING WIDTH
On pair of doors, specify
HALF of the total exit opening
US FINISH
END CAPS
OPTION FOR US
FINISH
86 22 TSE M2 -36
86  Life-Safety 00  US Finish T  Top Rod only LR  Electric Latch Retraction M  Single Switch 30  30 inches US3  Bright Brass MEC  Matching
End Caps
11  Clear Anodized 628 –  Standard rod SE  Silent Electrification
Latch Retraction M2  Dual Switch 36  36 inches US4  Satin Brass
22  Dark Bronze
Anodized 313 C  Cylinder Dogging BLANK
No Monitor 42  42 inches US32  Bright Stainless
33  Black Anodized 335 ED  Electric Dogging 48  48 inches US32D Satin Stainless
BLANK  No Option AXXB  Alarmed Exit Device where
XX is door opening width
EXIT DEVICES
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
24 EXIT DEVICES
3700, 8700 Rim Exit Device
MODELS & FINISHES 313, 335, 628 US4, US32D US3, US32
8700  Rim exit device for wood and hollow metal $455 $735 $815
3700  Fire-rated rim exit device for wood and hollow metal $755 $1,015 $1,075
KITTED OPTIONS
MODELS N/A
388908Mullion for doors up to 8' for use with 8700, 3700 $525
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
MODEL PUSHBAR FINISH DEVICE OPTIONS MONITORING
OPTION
DOOR OPENING WIDTH
On pair of doors, specify
HALF of the total exit opening
US FINISH
END CAPS
OPTION FOR US
FINISH
VOLTAGE
(For EL Option
Only)
37 00 EL M1 -36 -US3 MEC -12
37  Fire Rated 00  US Finish EL  Electric Latch Retraction
(indicate 12V/24V) M  Single Switch 30  30 inches US3  Bright Brass MEC  Matching
End Caps 12  Volts
87  Life-Safety 01  Clear Anodized 628 SE  Silent Electrification
Latch Retraction M2  Dual Switch 36  36 inches US4  Satin Brass 24  Volts
02  Dark Bronze Anodized 313 C  Cylinder Dogging BLANK
No Monitor 42  42 inches US32  Bright Stainless
03  Black Anodized 335 ED  Electric Dogging 48  48 inches US32D  Satin Stainless
  Without Options AXXB  Alarmed Exit Device where
XX is door opening width
*Please note that 30" exit devices cannot accommodate monitoring options, except when ordered in conjunction with the SE option.
8800 Narrow Stile Rim Exit Device
MODEL & FINISHES 313, 335, 628 US4, US32D US3, US32
8800  Narrow stile rim exit device $435 $715 $795
KITTED OPTIONS
MODELS 313, 628
389008Aluminum mullion for doors up to 8' for use with 8800 $575
389010Aluminum mullion for doors up to 10' for use with 8800 $600
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
MODEL PUSHBAR FINISH DEVICE OPTIONS MONITORING
OPTION
DOOR OPENING WIDTH
On pair of doors, specify HALF
of the total exit opening
US FINISH
END CAPS
OPTION FOR US
FINISH
VOLTAGE
(For EL Option
Only)
88 01 CM2 -36 -12
88  Life-Safety 00  US Finish
EL  Electric Latch
Retraction
(indicate 12V/24V)
M  Single Switch 30  30 inches US3  Bright Brass MEC  Matching
End Caps 12  Volts
01  Clear Anodized 628 SE  Silent Electrification
Latch Retraction M2  Dual Switch 36  36 inches US4  Satin Brass 24  Volts
02  Dark Bronze Anodized 313 C  Cylinder Dogging BLANK
No Monitor 42  42 inches US32  Bright
Stainless
03  Black Anodized 335 ED  Electric Dogging 48  48 inches US32D  Satin
Stainless
  Without Options AXXB  Alarmed Exit Device
where XX is door
opening width
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
25
3900, 8900 Wood Door Surface Concealed Vertical Rod Exit Device
MODELS & FINISHES 313, 335, 628 US4, US32D US3, US32
8900  Surface concealed vertical rod exit device for wood $735 $1,035 $1,135
3900  Fire-rated surface concealed vertical rod for wood $1,155 $1,455 $1,555
KITTED OPTIONS
MODEL
895501  Tall door kit for doors up to 10’ for use with 8900 $55
395501  Tall door kit for doors up to 10’ for use with 3900 $55
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
MODEL PUSHBAR FINISH DEVICE OPTIONS MONITORING
OPTION
DOOR OPENING WIDTH
On pair of doors, specify HALF
of the total exit opening
US FINISH END CAPS OPTION FOR
US FINISH
89 00 LR M2 -36 -US32
39  Fire Rated 00  US Finish LR  Electric Latch Retraction M  Single Switch 30  30 inches US3  Bright Brass MEC  Matching End Caps
89  Life-Safety 11  Clear Anodized 628 SE  Silent Electrification
Latch Retraction M2  Dual Switch 36  36 inches US4  Satin Brass
22  Dark Bronze Anodized 313 C  Cylinder Dogging
(non-fire rated devices only) BLANK  No Monitor 42  42 inches US32  Bright Stainless
33  Black Anodized 335 ED  Electric Dogging 48  48 inches US32D  Satin Stainless
BLANK  No Option AXXB  Alarmed Exit Device where XX is door opening width
*Please note that 30" exit devices cannot accommodate monitoring options, except when ordered in conjunction with the SE option.
Accessories for 3000/8000 Series Exit Devices
OPTIONS & FINISHES N/A US4,
US32D US3,
US32
ALARM  Battery-operated alarmed exit device. Alarm option cannot be combined with any other device option or monitoring options. $465
C  Cylinder dogging $50
ED  Electric dogging $410
EL  Electric latch retraction for use with 3700, 8700, 8800 rim exit devices only $355
ELD  Electric latch retraction with mechanical dogging for rim exit devices only $405
LR  Electric latch retraction for use with CVR, Mortise and SVR exit devices. $605
MEC  Matching end caps. For US finishes only, not applicable to anodized finishes $80 $105
M1  Monitor/single signal switch $125
M2  Monitor/dual signal switch $185
SE  Silent electrification motorized latch retraction $650
KITTED options for 3000/8000 Series Exit Devices
MODELS & FINISHES N/A 313, 335,
628 US4,
US32D US3,
US32 119, 121,
652
ALARM EXIT KIT  Kit for retrofitting an alarm function to an existing Adams Rite exit
device. Includes new pushbar, end caps and installati $590 $815 $875
91089701  Single signal switch kit, retrofits to 3000/8000 $115
91089702  Dual signal switch kit, retrofits to 3000/8000 $175
260584XXXMP  Sex bolts, 2 per bag, 2 kits required per exit device $26
EXIT DEVICES
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
26
MODIFICATION OPTIONS for 3000/8000 Series exit devices Please contact factory for all product modifications.
MODELS ADD
THICK DOOR  For doors thicker than 1-3/4" and/or door skins plus reinforcement thicker than those specified in the Adams
Rite Master Reinforcement Sheet template, for CVR and Mortise Exit Devices $65
UNIQUE DOOR   Cutting charges for non-standard custom cut lengths between 30" and 48" $85
Please note that thick door modification options are available for 8300, 8400, and 8600 series exit devices only.
NEW EX SERIES EXIT DEVICES
EX88 Interlocking Rim Exit Device
MODEL & FINISHES 313, 335, 628
EX88  Interlocking rim exit device for aluminum, hollow metal or wood applications. $435
EX89 Pullman Rim Exit Device
MODEL & FINISHES 313, 335, 628
EX89  Pullman rim exit device for aluminum, hollow metal or wood applications. $435
EX76 Concealed Vertical Rod Exit Device
MODEL & FINISHES 313, 335, 628
EX76  CVR exit device for aluminum and hollow metal applications $620
EX80 Dummy Push Bar
MODEL & FINISHES 313, 335, 628
EX80  Dummy push bar for aluminum, hollow metal or wood applications. Includes two
monitoring switches. Field selectable for active or inactive configuration $415
EX Series
OPTIONS ADD
MONITOR Dual Signal Switch $185
ALARM Alarmed exit device with field selectable power source: battery operated or hard-wired $465
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
MODEL LENGTH FINISHES DEVICE OPTIONS*
EX89 -R 628
EX88  Interlocking Rim Exit Device R  Regular (36") 313  Dark Bronze Anodized A  Alarmed
EX89  Pullman Rim Exit Device) M  Mid-Length (42") 335  Black Anodized M Monitoring
EX76  CVR Exit Device L  Long (48") 628  Clear Anodized BLANK  standard, no options
EX80  Dummy Push Bar
*Device options not applicable to Dummy Push Bar. Dummy Push Bar comes standard with dual monitoring switches.
EXIT DEVICES
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
27
7100, 7101 Electric Strikes
MODELS & FINISHES 313, 335, 628 626
es 7100
7100  For aluminum jambs $184 $209
7101  For radius aluminum stiles $184
7100XX7, 7100XX9  Monitoring signal switches $284 $309
Lip Extensions up to 3" for center-hung or non-flush doors add$34.
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT
NO.
FACEPLATE
SHAPE VOLTAGE CURRENT
AND DUTY FEATURES* FINISH** LIP EXTENSIONS DIM. A***
(Door Centerline to Jamb Edge)
710 0-3 1 0 -628 -00
0  Flat 3  12 Volt 1  DC Continuous
or Intermittent 0  Standard/Fail-Secure 313  Dark Bronze Anodized 00  1-1/16" or less 05  2"
1  Radius 4  16 Volt 4  AC Intermittent 5  Fail-Safe 335  Black Anodized 01  1-1/2" 07  2-1/4"
5  24 Volt 7  Monitored/ Fail-Safe 626  Satin Chrome 02  1-5/8" 09  2-1/2"
9  Monitored/ Fail-Secure 628  Clear Anodized 03  1-3/4" 12  2-7/8"
*Fail-secure can be converted to fail-safe and vice versa. **7101 available in 313, 335, 628 only. ***Lip extensions not available on 7107.
7110, 7111 Electric Strikes
MODELS & FINISHES 652
7110  For wood jambs $219
7111  For wood jambs, long faceplate $219
7110XX7, 7110XX9  Monitoring signal switches $319
Lip Extensions up to 3" for center-hung or non-flush doors add$34.
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT
NO.
FACEPLATE
LENGTH VOLTAGE CURRENT
AND DUTY FEATURES* FINISH LIP EXTENSIONS DIM. A
(Door Centerline to Jamb Edge)
711 0-3 1 0 -652 -00
0  7-15/16" 3  12 Volt 1  DC Continuous
or Intermittent 0  Standard/Fail-Secure 652  Satin Chrome 00  1-1/16" or less 05  2"
1  10-1/4" 4  16 Volt 4  AC Intermittent 5  Fail-Safe 01  1-1/2" 07  2-1/4"
5  24 Volt 7  Monitored/ Fail-Safe 02  1-5/8" 09  2-1/2"
9  Monitored/ Fail-Secure 03  1-3/4" 12  2-7/8"
*Fail-secure can be field converted to fail-safe or vice-versa.
7130, 7131 Electric Strikes
MODELS & FINISHES 313, 335, 628
7130  For aluminum jambs, pre-cut for MS lock strike plate $189
7131  For radius aluminum stiles, pre-cut for MS lock strike plate $189
Lip Extensions up to 3" for center-hung or non-flush doors add$34.
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT
NO.
FACEPLATE
SHAPE VOLTAGE CURRENT
AND DUTY FEATURES* FINISH LIP EXTENSIONS DIM. A**
(Door Centerline to Jamb Edge)
713 0-3 1 0 -313 -00
0  Flat 3  12 Volt 1  DC Continuous
or Intermittent
0  Standard/
Fail-Secure
313  Dark Bronze
Anodized 00  1-1/16" or less 05  2"
1  Radius 4  16 Volt 4  AC Intermittent 5  Fail-Safe 335  Black Anodized 01  1-1/2" 07  2-1/4"
5  24 Volt 628  Clear Anodized 02  1-5/8" 09  2-1/2"
03  1-3/4" 12  2-7/8"
*Fail-secure can be field converted to fail-safe or vice-versa. **Lip extensions not available on 7107.
ELECTRIC STRIKES
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
28
ARM-014-01/14
7140 Electric Strike
FITS STANDARD
MOUNTING
TAB ANSI PREP
3/32"
2.4mm
MODEL & FINISHES 313, 335, 628 626
7140  ANSI size for hollow metal and wood jambs $184 $209
Lip Extensions up to 3" for center-hung or non-flush doors add$34.
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT
NO. VOLTAG E CURRENT AND DUTY FEATURES* FINISH LIP EXTENSIONS DIM. A
(Door Centerline to Jamb Edge)
7140 -3 1 0 -628 -00
3  12 Volt 1  DC Continuous or Intermittent 0  Standard/
Fail-Secure 313  Dark Bronze Anodized 00  1-1/16"
or less 05  2"
4  16 Volt 4  AC Intermittent 5  Fail-Safe 335  Black Anodized 50  1-3/8" 07  2-1/4"
5  24 Volt
626  Satin Chrome 01  1-1/2" 09  2-1/2"
628  Clear Anodized 02  1-5/8" 12  2-7/8"
03  1-3/4"
*Fail-secure can be field converted to fail-safe or vice-versa.
7160 Electric Strike
MODELS & FINISHES 313, 335, 628 626
7160  For aluminum jambs $231 $256
7160XX7, 7160XX9  Monitoring signal switches $331 $356
Lip Extensions up to 3" for center-hung or non-flush doors add$34.
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT
NO. VOLTAG E CURRENT AND DUTY FEATURES* FINISH LIP EXTENSIONS DIM. A
(Door Centerline to Jamb Edge)
7160 -3 1 0 -628 -00
3  12 Volt 1  DC Continuous
or Intermittent
0  Standard/
Fail-Secure 313  Dark Bronze Anodized 00  1-1/16" or less 05  2"
4  16 Volt 4  AC Intermittent 5  Fail-Safe 335  Black Anodized 01  1-1/2" 07  2-1/4"
5  24 Volt 7  Monitor/Fail-Safe 626  Satin Chrome 02  1-5/8" 09  2-1/2"
9  Monitor/Fail-Secure 628  Clear Anodized 03  1-3/4" 12  2-7/8"
*Fail-secure can be field converted to fail-safe or vice-versa.
7170 Electric Strike
FITS STANDARD
MOUNTING
TAB ANSI PREP
3/32"
2.4mm
MODELS & FINISHES 313, 335, 628 626
7170  For hollow metal and wood jambs $231 $256
7170XX7, 7170XX9  Monitoring signal switches $331 $356
Lip Extensions up to 3" for center-hung or non-flush doors add$34.
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT
NO. VOLTAG E CURRENT AND DUTY FEATURES* FINISH LIP EXTENSIONS DIM. A
Door Centerline to Jamb Edge
7170 -3 1 0 -628 -00
3  12 Volt 1  DC Continuous or Intermittent 0  Standard/Fail-Secure 313  Dark Bronze Anodized 00  1-1/16" or less 05  2"
4  16 Volt 4  AC Intermittent 5  Fail-Safe 335  Black Anodized 50  1-3/8" 07  2-1/4"
5  24 Volt
7  Monitor/Fail-Safe 626  Satin Chrome 01  1-1/2" 09  2-1/2"
9  Monitor/Fail-Secure 628  Clear Anodized 02  1-5/8" 12  2-7/8"
03  1-3/4"
*Fail-secure can be field converted to fail-safe or vice-versa.
ELECTRIC STRIKES
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
29
Modular Packaging Program – Match strike body with faceplate kit for complete electric strike.
7100 Series Electric Strike Components
STRIKE BODY KITS
7103A  For use in aluminum applications $154
7173A  For use in hollow metal or wood jambs only $199
One strike body kit matched with one faceplate kit makes a complete electric strike assembly.
FACEPLATE KITS & FINISHES 313,335, 628 626 605
FPK00  For use with body kits: 7103A $30 $55 $60
FPK01  For use with body kit: 7103A $30
FACEPLATE KITS & FINISHES 652 632
FPK10  For use with body kit: 7103A $65 $90
FPK11  For use with body kits: 7103A, 7173A $65 $90
FACEPLATE KITS & FINISHES 313,335, 628 626 605
FPK30  For use with body kit: 7103A $35
FPK31  For use with body kits: 7103A $35
FPK40  For use with body kit: 7173A $30 $55 $60
FPK45  For use with body kit: 7103A, for installing electric strike in previous prep, 4901, 4501 strike cover. $35
Faceplate kits contain all hardware to mount electric strike.
KITTED OPTIONS
91017101IP THROUGH 13IP  Lip extension kits for use with 7100 through 7140 $34
91017150IP  Lip extension kits for use with 7100 through 7140 interior framing systems $34
91017201IP THROUGH 13IP  Lip extension kits for use with 7160 and 7170 $34
91017250IP  Lip extension kits for use with 7160 and 7170 interior framing systems $34
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. VOLTAGE CURRENT AND DUTY FEATURES*
7103A 3 1 0
7103A for use in aluminum 3  12 Volt 1  DC Continuous or Intermittent 0  Standard/Fail-Secure
7173A  for use in hollow
metal or wood
4  16 Volt 4  AC Intermittent 5  Fail-Safe
5  24 Volt
*Fail-secure can be field converted to fail-safe or vice-versa.
ELECTRIC STRIKES
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
30
7240 Series Fire-Rated Electric Strikes
MODELS & FINISH 630
7240  Fire-rated, for cylindrical latches $347
724050  Lip extension for interior frame systems $386
7240XX9  Monitoring signal switches $447
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT
NO. VOLTAG E CURRENT AND DUTY FEATURES* FINISH
LIP EXTENSIONS DIM. A
Door Centerline to Jam Edge for
Interior Frames
7240 -3 1 0 -630 -50
3  12 Volt 1  DC Continuous
or Intermittent 0  Fail-Secure 630  Satin Stainless 00  1-1/16" or less
5  24 Volt 4  AC Intermittent 9  Monitor/Fail-Secure 50  1-3/8"
*Not available fail-safe.
7270 Series Fire-Rated Electric Strikes
MODELS & FINISH 630
7270  Fire-rated, for mortise latches $402
727050  Lip extension for interior frame systems $441
7270XX9  Monitoring signal switches $502
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT
NO. VOLTAG E CURRENT AND DUTY FEATURES* FINISH
LIP EXTENSIONS DIM. A
Door Centerline to Jam Edge for
Interior Frames
7270 -3 1 0 -630 -50
3  12 Volt 1  DC Continuous
or Intermittent 0  Fail-Secure 630  Satin Stainless 00  1-1/16" or less
5  24 Volt 4  AC Intermittent 9  Monitor/Fail-Secure 50  1-3/8"
*Not available fail-safe.
7400, 7401 Ultraline® Electric Strikes
MODELS & FINISHES 313, 335, 628 630 605, 606, 629 119, 121, 130
7400  For radius jambs $254 $279 $289
7400M  Monitoring signal switches $354 $379 $389
7401  For radius aluminum stiles $254
7401M  Monitoring signal switches $354
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT
NO.
FACEPLATE
SHAPE FEATURES FINISH
740 0 M 628
0  Flat   None 7400 ONLY 7401 ONLY
1  Radius M  Monitored 313  Dark Bronze Anodized 628  Clear Anodized 119  To match 335 Black Anodized
A  Modular Pack - Body Kit 335  Black Anodized 629  Bright Stainless 121  To match 313 Dark Bronze Anodized
605  Bright Brass 630  Satin Stainless 130  To match 628 Clear Anodized
606  Satin Brass
Fail-secure can be field converted to fail-safe or vice-versa.
ELECTRIC STRIKES
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
31
7410, 7411 Ultraline® Electric Strikes
MODELS & FINISHES 313, 335, 628 630
7410  For wood jambs, 7-15/16" faceplate $284 $309
7410M  Monitoring signal switches $384 $409
7411  For wood jambs, 10-1/4" faceplate, not available in 335 Finish $284 $309
7411M  Monitoring signal switches $409
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. FACEPLATE LENGTH FEATURES FINISH
741 0 - 628
0  7-15/16"   None 313  Dark Bronze Anodized 628  Clear Anodized
1  10-1/4" M  Monitored 335  Black Anodized 630  Satin Stainless
Fail-secure can be field converted to fail-safe or vice-versa.
7430, 7431 Ultraline® Electric Strikes
MODELS & FINISHES 313, 335, 628 119, 121, 130
7430  For aluminum jambs, flat faceplate $259
7430M  Monitoring signal switches $359
7431  For aluminum stiles, radius faceplate $259
7431M  Monitoring signal switches, not available in 119 finish. $359
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. FACEPLATE SHAPE FEATURES FINISH
743 0 M 628
0  Flat   None 313  Dark Bronze Anodized 119  To match 335 Black Anodized
1  Radius M  Monitored 335  Black Anodized 121  To match 313 Dark Bronze Anodized
628  Clear Anodized 130  To match 628 Clear Anodized
Fail-secure can be field converted to fail-safe or vice-versa.
7440 Ultraline® Electric Strikes
MODELS & FINISHES 313, 335, 628 630 605, 606,
629
7440  For steel and wood, jambs and doors $254 $279 $289
7440M  Monitoring signal switches $354 $379 $389
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. FEATURES FINISH
7440 M628
  None 313  Dark Bronze Anodized 606  Satin Brass 629  Bright Stainless
M  Monitored 335  Black Anodized 628  Clear Anodized 630  Satin Stainless
605  Bright Brass
Fail-secure can be field converted to fail-safe or vice-versa.
ELECTRIC STRIKES
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
32
74R1 Ultraline® Electric Strikes
MODELS & FINISHES 119, 121, 130
74R1  For use with rim exit devices with 3/4" latchbolt $344
74R1M  Monitoring signal switches $444
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. FEATURES FINISH
74R1 M-130
  None 119  To match 335 Black Anodized
M  Monitored 121  To match 313 Dark Bronze Anodized
130  To match 628 Clear Anodized
Fail-secure can be field converted to fail-safe or vice-versa.
74R2 Ultraline® Electric Strike
MODELS & FINISHES 119, 121, 130
74R2  For use with narrow stile rim exit devices with 1/2" latchbolt $344
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. FINISH
74R2 -130
119  To match 335 Black Anodized
121  To match 313 Dark Bronze Anodized
130  To match 628 Clear Anodized
Fail-secure can be field converted to fail-safe or vice-versa.
ELECTRIC STRIKES
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
33
ELECTRIC STRIKES
Modular Packing Program - match strike body kit with faceplate kit for complete electric strike.
Select 7400A for standard jambs and 7401A for radius stile mounting. No finish designation required for strike body kits.
7400 Series Electric Strike Components
STRIKE BODY KITS
7400A  Standard body, for use in single door applications $229
7401A  Radius body, for use in applications with pairs of doors $229
Match one strike body kit with one faceplate kit to make a complete electric strike assembly.
FACEPLATE KITS & FINISHES 313, 335,
628 630 605, 606,
629 119, 121,130
FPK7400  For use with body kit: 7400A $25 $50 $60
FPK7401  For use with body kit: 7401A $25
FPK7410  For use with body kit: 7400A $55 $80
FPK7411  For use with body kit: 7400A, not available in 335 finish $60 $85
FPK7430  For use with body kit: 7400A $30
FPK7431  For use with body kit: 7401A $30
FPK7440  For use with body kit: 7400A $25 $50 $60
FPK7445  For use with body kit: 7400A, not available in 335 finish.
For installing electric strike in previous prep 4901, 4501, strike cover $35
Faceplate kits contain all hardware to mount electric strike.
KITTED OPTIONS
LEK7400  Lip extension kits for use with 7400 series electric strikes, for flat faceplates only $44
VA740012  12 VDC adapter cable for 7400 electric strikes $12
VA740016VDC  16 VDC adapter kit for 7400 electric strikes $19
VA740024  24 VDC adapter cable for 7400 electric strikes $12
WDC7400  Wood door cover plate for use when mounting 7400 in the inactive leaf of a wood door pair
(to simplify the mortising operation) $13
ELX  ElectroLynx™ Adapter to connect Adams Rite products to the ElectroLynx system $31
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. LIP EXTENSIONS (distance from vertical centerline of the door in the closed position to the edge of the jamb)
LEK7400- -00
01  1-1/2" 03  1-3/4" 05  2" 07  2-1/4" 09  2-1/2" 11  2-3/4" 13  3"
02  1-5/8" 04  1-7/8" 06  2-1/8" 08  2-3/8" 10  2-5/8" 12  2-7/8" 50  1-3/8"
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
34
1000 Series Turns
MODELS & FINISHES 119, 121, 130
100001, 100002  Turn for use with MS1847 deadlock $27
100011, 100021  Turn and escutcheon for use with MS1847 deadlock $32
1000S11, 1000S21  Stainless steel turn and escutcheon for use with MS1847 deadlock $37
1004  Turn for use with 5015, 5017 deadlock $32
1015  Turn for use with 5015, 5017 deadlock $32
1016  Outside escutcheon $27
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT
NO. TURN TYPE SPINDLE LENGTH FINISH
1000 -21 -14 -130
TURN WITHOUT ESCUTCHEON
Furnished Unassembled
DASH CHART
NO. " L" MM NO. "L" MM
11 17/32 13 22 1-15/64 31
12 39/64 15 23 1-19/64 33
13 43/64 17 24 1-23/64 35
14 47/64 19 25 1-27/64 36
15 51/64 20 26 1-31/64 38
16 55/64 22 27 1-33/64 39
17 59/64 23 28 1-39/64 41
18 63/64 25 29 1-43/64 42
19 1-3/64 26 30 1-47/64 44
20 1-7/64 28 31 1-51/64 46
21 1-11/64 30 32 1-55/64 47
119To match 335 Black Anodized
-01
Parallel
Drive
-02
Pendicular
Drive
121To match 313 Dark Bronze
Anodized
TURN WITH ESCUTCHEON
Furnished Assembled 130To match 628 Clear Anodized
-11
Parallel
Drive
-21
Pendicular
Drive
3000 Fixed Pull
MODELS & FINISH US32D
3001  Tubular fixed pull for hollow metal or wood doors $197
3002  Flat fixed pull for hollow metal or wood doors $215
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. HANDLE CYLINDER HOLE EXIT DEVICE FINISH
300 1-1 1-US32D
1  Round 1  Without Hole 1  Mortise, Rim US32D  Satin Stainless
2  Flat 2  With Hole 2  CVR
3  SVR
Not for use with the following narrow stile exit devices: 8200 SVR, 8400 Mortise, 8600 CVR, 8800 Rim exit devices.
TRIM
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
35
3080 Series Entry Trim
STANDARD TRIM ELECTRIFIED TRIM
MODELS & FINISHES US4,
US32D,
10B
US3,
US32
US4,
US32D,
10B
UUS3,
US32
STANDARD LEVER
3080 Entry trim with standard lever (01, 02, 03) $347 $382 $672 $707
3080M Entry trim with standard lever (01, 02, 03) with matching trim cover finish $437 $472 $762 $797
3080U Entry trim with standard lever (01, 02, 03) with universal trim kit includes
tailpieces and trimplates
for use with all Adams Rite exit devices
$372 $407 $697 $732
3080U, M Entry trim with standard lever (01, 02, 03),
matching trim cover and universal trim kit $462 $497 $787 $822
DESIGNER LEVER
3080MX Entry trim with designer lever series
(MD through MW) $392 $427 $717 $752
3080MX, M Entry trim with designer lever series
(MD through MW) with matching trim cover $482 $517 $807 $842
3080MX, U Entry trim with designer lever series
(MD through MW) with universal trim kit $417 $452 $742 $777
3080MX, U, M Entry trim with designer lever series
(MD through MW), universal trim kit and matching trim cover $507 $542 $832 $867
Tactile strip now available as a Kitted Option (below) for standard levers 01 and 03.
KITTED OPTIONS
910686Adaptor kit for 3080 trim and G86 exit device $29
910118Tactile strip for 3080 standard levers 01, 03 $36
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT
NO. ELECTRIFIED HANDLE HANDING CYLINDER
HOLE EXIT DEVICE VOLTAG E FEATURES TRIM COVER
FINISH FINISH
3080 E-01 -0 -3 7-3 0 M US32D
BLANK
Standard
STANDARD
HANDLES 0  No Handing 3  With Hole 1  SVR Electrified
Trim Only
Electrified
Trim Only
   Standard
(Black) US3  Bright Brass
E  Electrified Trim 01  Curve 7  Left Hand* 9  Without Hole 3  Mortise 3  12 Volt DC 0  Fail-Secure M  Matching Finish US4  Satin Brass
02  Round 8  Right Hand* 4  SCVR 5  24 Volt DC 5  Fail-Safe 10B  Dark Bronze
03  Square 6  CVR US32  Bright Stainless
DESIGNER SERIES 7  Rim US32D  Satin Stainless
MD MJ U  Universal
Kit
ME MN*
(Handed)
MG MV* (Handed)
MI MW
*Handing must be specified for MN and MV Designer Levers.
TRIM
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
36
3090, 3090P/C eForce® Keyless Entry
FOR DEADLATCHES
AND EXITS FOR DEADLOCKS
MODELS & FINISHES 626, 121 626, 121
309001, 309002  eForce keyless entry with keypad
309001 309002
$677 $697
3090P01, 3090P02  eForce hardwired keyless entry with Prox reader
3090P01 3090P02
$922 $942
3090C01, 3090C02  eForce hardwired keyless entry with iCLASS reader
3090C01 3090C02
$962 $982
KITTED OPTIONS
MODELS
RSK3090  Remote switch input connector $16
3090CABLE  15 ft cable extension (ElectroLynx™ x pigtail) for 3090P/C $32
3090CABLEEL  15 ft cable extension (ElectroLynx™ x ElectroLynx™) for 3090P/C $38
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. CREDENTIAL COMPATIBLE PRODUCTS FINISH
3090 P-01 -626
BLANKKeypad 01Adams Rite latches or 8000 Series Exit Devices, Yale 7200 series,
Corbin Russwin ED4000 series exit devices only
121To match 313 Dark
Bronze Anodized
P125 kHz HID® Prox
C13.56 MHz HID
iCLASS 02Adams Rite MS® deadlocks 626Satin Chrome
A100-3090H Keyless Entry and Aperio® Hub Wholesale Kit
FOR DEADLATCHES
& EXITS FOR DEADLOCKS
MODELS & FINISHES 121, 626 121, 626
A1003090HC  Keyless entry paired with hub, iCLASS reader $1,760 $1,780
A1003090HP  Keyless entry paired with hub, PROX reader $1,760 $1,780
Special pricing program discounts apply to Aperio products. Please contact your sales representative for pricing information.
KITTED OPTIONS
MODELS
DPSC38G  A100 Door Position Switch $35
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. CREDENTIAL COMPATIBLE PRODUCTS FINISH
A100-3090H C-1 -626
P125 kHz HID® Prox
1Adams Rite latches or 8000 Series Exit Devices, Yale 7200
series, Corbin Russwin ED4000 series exit devices only
(select REX enabled version).
121To match 313 Dark
Bronze Anodized
C13.56 MHz HID
iCLASS 2Adams Rite MS® deadlocks 626Satin Chrome
Note: The Adams Rite A100 narrow stile trim is available as either a pre-paired lock and hub kit (no certification required) or as a field configurable component (requires Aperio® Certified Integrator
certification). Pre-paired kits support limited features, field configured devices are required in order to support all options. Visit www.IntelligentOpenings.com to learn more.
TRIM
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
37
4060 Turn
MODEL & FINISH 130
4060  Turn for 1875 deadlock, 1-1/2", 1-3/4", or 2" door thickness $60
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. DOOR THICKNESS FINISH
4060 -05 -130
051-1/2" 130To match 628 Clear Anodized
061-3/4"
072"
Please contact factory regarding mounting spacers, bolts, guides and strikes for particular door designs.
4550 MS® Deadlock Lever
MODEL & FINISHES 119, 121, 130
4550, 01  Deadlock lever, 1-3/4" to 2" door thickness $198
4550, 02  Deadlock lever, 2-1/8" to 2-3/8" door thickness $238
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. DOOR HAND DOOR THICKNESS RITECOAT FINISH
4550 R-01 -130
RRH or RHR 011-3/4" to 2" 119To match 335 Black Anodized
LLH or LHR 022-1/8" to 2-3/8" 121To match 313 Dark Bronze Anodized
130To match 628 Clear Anodized
TRIM
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
38
4560, 4565 Series Deadlatch Handles for 4300, 4500, 4900 Deadlatches
MODELS & FINISHES 119, 121, 130
4560X01  For door thickness (01) 1-3/4" to 2" $52
4560X02  For door thickness (02) 2-1/4" to 2-1/2" $72
4560X03  For door thickness (03) 2-3/4" to 3" $72
4560X04  For door thickness (04) 3-1/4" $72
4565X01  For door thickness (01) 1-3/4" to 2" $52
4565X02  For door thickness (02) 2-1/4" to 2-1/2" $72
4565X03  For door thickness (03) 2-3/4" to 3" $72
4565X04  For door thickness (04) 3-1/4" $72
Series Deadlatch Handles for MS+1890 Deadlock/Deadlatch
MODELS & FINISHES 119, 121, 130
4560011  For door thickness (11) 1-3/4" $39
4560012  For door thickness (12) 1-3/4" to 2-1/4" $49
4560013  For door thickness (13) 2-15/16" to 2-3/4" $49
4565011  For door thickness (11) 1-3/4" $39
4565012  For door thickness (12) 1-3/4" to 2-1/4" $49
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. HANDLE TYPE HANDING DOOR THICKNESS FINISH
456 0-5 01 -130
0  Lever 0  Using MS+1890 FOR 4300, 4500, 4900
SERIES DEADLATCHES FOR MS+1890 119  To match 335 Black Anodized
5  Turn 5  LH or LHR 01  1-3/4" to 2" 11  1-3/4" 121  To match 313 Dark Bronze Anodized
6  RH or RHR 02  2-1/4" to 2-1/2" 12  1-3/4" to 2-1/4" 130  To match 628 Clear Anodized
03  2-3/4" to 3" 13  2-5/16" to 2-3/4"
04  3-1/4"
TRIM
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
39
4568, 4569 Eurostyle Deadlatch Handles for 4300, 4500, 4900 Deadlatches
MODELS & FINISHES 119, 121, 130
sw 4568
4568X01  For door thickness (01) 1-3/4" to 2" $63
4568X02  For door thickness (02) 2-1/4" to 2-1/2" $78
4568X03  For door thickness (03) 2-3/4" to 3" $78
4568X04  For door thickness (04) 3-1/4" $78
4569X01  For door thickness (01) 1-3/4" to 2" $71
4569X02  For door thickness (02) 2-1/4" to 2-1/2" $86
4569X03  For door thickness (03) 2-3/4" to 3" $86
4569X04  For door thickness (04) 3-1/4" $86
Eurostyle Deadlatch Handles for MS+1890 Deadlock/Deadlatch
MODELS & FINISHES 119, 121, 130
4568011  For door thickness (11) 1-3/4" to 1-15/16" $51
4568012  For door thickness (12) 2" to 2-1/4" $61
4568013  For door thickness (13) 2-15/16" to 2-3/4" $61
4568014  For door thickness (14) 3" $61
4569011  For door thickness (11) 1-3/4" to 1-15/16" $56
4569012  For door thickness (12) 2" to 2-1/4" $66
4569013  For door thickness (13) 2-15/16" to 2-3/4" $66
4569014  For door thickness (14) 3" $66
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. LEVER TYPE HANDING DOOR THICKNESS FINISH
456 8-5 01 -130
8  Straight 0  Using MS+1890 FOR 4300, 4500, 4900
SERIES DEADLATCHES FOR MS+1890 119  To match 335 Black Anodized
9  Return End 5  LH or LHR 01  1-3/4" to 2" 11  1-3/4" to 1-15/16" 121  To match 313 Dark Bronze Anodized
6  RH or RHR 02  2-1/4" to 2-1/2" 12  2" to 2-1/4" 130  To match 628 Clear Anodized
03  2-3/4" to 3" 13  2-5/16" to 2-3/4"
04  3-1/4" 14  3"
TRIM
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
40
4590 Deadlatch Paddle for 4300, 4500, 4900 Deadlatches
MODELS & FINISHES 313, 335, 628
45900X00  For door thickness (00) 1-3/4" $103
45900X01  For door thickness (01) 1-13/16" to 2" $123
45900X02  For door thickness (02) 2-1/4" to 2-1/2" $123
45900X03  For door thickness (03) 2-3/4" to 3" $123
45900X04  For door thickness (04) 3-1/4" $123
Deadlatch Paddle for MS+1890, 2190 Deadlocks
MODELS & FINISHES 313, 335, 628
45901X00  For door thickness (00) 1-3/4" $87
45901X01  For door thickness (01) 1-3/4" to 2-1/4" $107
45901X02  For door thickness (02) 2-5/16" to 2-1/2" $107
45901X03  For door thickness (03) 2-9/16" to 2-3/4" $107
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. OPERATION DOOR THICKNESS FINISH*
4590 02 -00 -313
FIRST DASH
FOR LATCH SERIES OPPERATION USE FOR 4300, 4500, 4900
SERIES DEADLATCHES FOR MS+1890, 2190 313  Dark Bronze Anodized
01  4300/4500/4900 PULL
TO LEFT
Outside of left hand reverse
door or inside of right hand
00  1-3/4" 00  1-3/4" 335  Black Anodized
11  MS+1890/2190 01  1-13/16" to 2" 01  1-3/4" to 2-1/4" 628  Clear Anodized
02  4300/4500/4900 PUSH
TO LEFT
Outside of left hand door or
inside of right hand reverse
02  2-1/4" to 2-1/2" 02  2-5/16" to 2-1/2"
12  MS+1890/2190 03  2-3/4" to 3" 03  2-9/16" to 2-3/4"
03  4300/4500/4900 PULL
TO RIGHT
Outside of right hand reverse
door or inside or left hand
04  3-1/4"
13  MS+1890/2190
04  4300/4500/4900 PUSH
TO RIGHT
Outside of right hand door or
inside of left hand reverse
14  MS+1890/2190
-03 OR -13
LH
LHR
RH
RHR
-02 OR -12
-02 OR -12
-04 OR -14
-01 OR -11
-04 OR -14
-01 OR -11
*Finish applied to paddle assembly only, not escutcheon.
TRIM
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
41
4591 Deadlatch Paddle for 4300, 4500, 4900 Deadlatches
MODELS & FINISHES 313, 335, 628 US3, US26D
45910X00  For door thickness (00) 1-3/4" $123 $230
45910X01  For door thickness (01) 1-13/16" to 2" $143 $250
45910X02  For door thickness (02) 2-1/4" to 2-1/2" $143 $250
45910X03  For door thickness (03) 2-3/4" to 3" $143 $250
45910X04  For door thickness (04) 3-1/4" $143 $250
Deadlatch Paddle for MS+1890, 2190 Deadlocks
MODELS & FINISHES 313, 335, 628 US3, US26D
45911X00  For door thickness (00) 1-3/4" $106 $213
45911X01  For door thickness (01) 1-3/4" to 2-1/4" $126 $233
45911X02  For door thickness (02) 2-5/16" to 2-1/2" $126 $233
45911X03  For door thickness (03) 2-9/16" to 2-3/4" $126 $233
OPTIONS
4591MA  Active paddle, latch activator with monitor switch Add $116
4591M  Paddle with switch, no latch activator Add $100
910914  Monitor switch kit for 4591, field installation $116
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. OPTIONS* OPERATION DOOR THICKNESS FINISH**
4591 M02 -00 -313
–  Standard Paddle FIRST DASH
FOR LATCH SERIES OPPERATION USE FOR 4300, 4500, 4900
SERIES DEADLATCHES FOR MS+1890, 2190 313  Dark Bronze
Anodized
M  Paddle
w/ switch only 01  4300/4500/4900
PULL
TO LEFT
Outside of left hand
reverse door or inside
of right hand
00  1-3/4" 00  1-3/4" 335  Black Anodized
MA  Active paddle
w/ switch 11  MS+1890/2190 01  1-13/16" to 2" 01  1-3/4" to 2-1/4" 628  Clear Anodized
02  4300/4500/4900 PUSH
TO LEFT
Outside of left hand
door or inside of
right hand reverse
02  2-1/4" to 2-1/2" 02  2-5/16" to 2-1/2" US3  Bright Brass
12  MS+1890/2190 03  2-3/4" to 3" 03  2-9/16" to 2-3/4" US26D  Satin Chrome
03  4300/4500/4900 PULL
TO RIGHT
Outside of right hand
reverse door or inside
or left hand
04  3-1/4"
13  MS+1890/2190
04  4300/4500/4900 PUSH
TO RIGHT
Outside of right hand
door or inside of
left hand reverse
14 MS+1890/2190
*M and MA options availble on push paddles only, not pull paddles. **Finish applied to paddle assembly only, not escutcheon.
TRIM
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
42
4600 Heavy Duty Designer Deadlatch Handles
LEVER OPERATOR FOR
4300, 4500, 4900 SERIES
DEADLATCHES
LEVER OPERATOR FOR
2190, 2290 INTERCONNECTED
DEADBOLT/DEADLATCH
MODELS & FINISHES 10B, US4,
US32D US3, US32 10B, US4,
US32D US3, US32
STANDARD
LEVER
4600 Trim with standard lever (01, 02, 03) $135 $170 $120 $155
4600M Trim with standard lever (01, 02, 03) with form
'C' switch option to indicate when lever is actuated $185 $220 $170 $205
4600THICK DOOR Trim with standard lever
(01, 02, 03) for door thickness greater than 1-7/8" $155 $190 $140 $175
DESIGNER
LEVER
4600MX Trim with designer lever series (MD through MW) $180 $215 $165 $200
4600MX, M Trim with designer lever series
(MD through MW) with form 'C' switch option $230 $265 $215 $250
4600MX, THICK DOOR Trim with designer lever series
(MD through MW) for door thickness greater than 1-7/8" $200 $235 $185 $220
KITTED OPTIONS
REX4600  Request to exit kit $38
DTK4600  Fixed lever (dummy) kit $12
TDK4600X X  Thick door kit. Specify door thickness.* $25
TBK4600XX  Through-bolt mounting kit for back-to-back mounting on wood doors. Specify door thickness.* $27
*For door thickness (01) 1-3/4", (02) 2", (03) 2-1/4", (04) 2-1/2" and (05) 2-3/4".
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. REX HANDLE HANDING** DOOR THICKNESS COMPATIBLE PRODUCTS FINISH
4600 M-01 -5 1 1 -32D
BLANK Standard STANDARD HANDLES 5  LH or LHR 1  1-3/4" to 1-7/8" 1  2190, 2290 Interconnected Deadbolt/Deadlatch US3  Bright Brass
M  Switch Option 01  Curve 6  RH or RHR 2  2" to 2-1/8" 2  4300, 4500, 4900 Series Deadlatches US4  Satin Brass
02  Round 3  2-1/4" to 2-3/8" 10B  Dark Bronze
03  Square 4  2-1/2" to 2-5/8" US32  Bright Stainless
DESIGNER SERIES 5  2-3/4" to 2-7/8" US32D  Satin Stainless
MD MJ
ME MN* (Handed)
MG MV* (Handed)
MI MW
*Handing must be specified for MN and MV Designer Levers. **Handing - assuming lever on interior of door.
TRIM
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
43
4024, 4025, 4026 Cylinder Pulls
MODELS & FINISHES 119, 121, 130
40240001, 02  Cylinder pull, Schlage keyway $59
40240601, 02  Cylinder pull, Weiser keyway $59
40250001, 02  Cylinder pull, Schlage keyway $64
40250601, 02  Standard cylinder pull, Weiser keyway $64
402510002, CYL X CYL  Cylinder both sides pullset, Schlage keyway $128
402510602, CYL X CYL  Cylinder both sides pullset, Weiser keyway $128
40260001, 02  Cylinder pull for use with 5015, 5017 Wood Door Deadlock, Schlage keyway $67
40260601, 02  Cylinder pull for use with 5015, 5017 Wood Door Deadlock, Weiser keyway $67
Please contact factory for special cylinder requirements.
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PULL TYPE PULL NO./CYLINDER INCLUDED KEYING FINISH
4024 -00 -01 -130
4024  Trim Plate Mounted 00  Schlage "C: Keyway 01  Keyed Dierent 119  To match 335 Black Anodized
4025  Stile Mounted with through - screws 06  Weiser Keyway 02  Keyed Alike in Pairs 121  To match 313 Dark Bronze Anodized
4026  For Wood Applications 130  To match 628 Clear Anodized
4036 Mortise Cylinder
MODEL & FINISHES 313, 335, 628
4036  Five pin cylinder.2 keys and 1/4" ring, KD, KA2 only
$42
For 3300, 3600, 8300, 8400, 8500, 8600, or entry trim.
Can be installed directly in latch case of 8400, 8300, or 3300.
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. LOCK TYPE KEY OPTIONS* FINISH
4036 -01 -01 -628
01  For MS Locks, Deadlatches, 2190 01  Keyed dierent 313  Dark Bronze Anodized
02  For 4070 Deadlock 02  Keyed alike in pairs 335  Black Anodized
03  For 2331 Deadlock 628  Clear Anodized
* Keyed alike 50 (KA50) are availiable by special order in quantity of 50 cylinders only. Please contact factory for ordering information.
CYLINDERS & ACCESSORIES
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
44
MS4043 Cylinder Guard
MODELS & FINISHES 119, 121, 130
MS404300  Cylinder guard, 1/8" stile wall, 5 or 6 pin cylinder $36
MS404301  Cylinder guard, 1/4" stile wall, 5 or 6 pin cylinder $41
MS404302  Cylinder guard, 1/8" stile wall, 1-5/16" to 1-7/16" long cylinder $56
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. STILE WALL & CYLINDER FINISH
MS4043 -01 -130
STILE WALL CYLINDER 119  To match 335 Black Anodized
00  1/8" 5 or 6 pin 121  To match 313 Dark Bronze Anodized
01  1/4" 5 or 6 pin 130  To match 628 Clear Anodized
02  1/8" 1-5/16" to 1-7/16" long
4066 Thumbturn
MODEL & FINISHES 130, 313, 335
4066  Thumbturn cylinder with 1/4" ring $42
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. LOCK TYPE FINISH
4066 -01 -130
01  For MS Locks, Deadlatches 130  To match 628 Clear Anodized
02  For 4070 Deadlock 313  Dark Bronze Anodized
03  For 2331 Deadlock 335  Black Anodized
4580 Cam Disc
MODELS
4580X00, 4580X01  Included with lever handles, door thickness 2" or less $17
4580X02, 4580X03  Included with lever handles, door thickness greater than 2" $25
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. HANDING DOOR THICKNESS
4580 -5 00
5  LH 00  1-3/4"
6  RH 01  2"
02  2-1/4"
03  2-3/4"
CYLINDERS & ACCESSORIES
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
45
4581 Universal Cam Plug
MODELS
458101IP  Universal cam disc, non-handed, for 1-3/4" door thickness (included in 4600) $24
458102IP  Universal cam disc, non-handed, for 2" door thickness $32
458103IP  Universal cam disc, non-handed, for 2-1/4" door thickness $32
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. DOOR THICKNESS
4581 01
01  1-3/4"
02  2"
03  2-1/4"
8650 Cylinder Escutcheon Kit
MODELS & FINISHES 119, 121,
130 313, 335,
628 US4,
US32D US3, US32
8650  Cylinder escutcheon kit for 3600, 8500, 8600 exit devices $35 $60 $68 $78
8650  For wall thickness over 1/8" * $65 $90 $98 $108
*Please contact factory for wall thickness greater than 1/8"
8736 Rim Cylinder
MODEL & FINISHES 313, 335, 628
8736  Five-pin Rim cylinder for use with 3100, 3700, 8100, 8200, 8700, 8800 exit devices. $45
4014 Two-Point Conversion Kit
MODEL
401401  Two-point conversion kit for MS1861 Bottom Rail Deadlock $36
4015 Threshold Bolt
MODEL & FINISHES 603
401518IB  Two-point converter, threshold bolt, standard cylinder height. $43
4015XXIB  Two-point converter, threshold bolt, specify cylinder height greater than 53", 60" maximum. $65
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. ADD DASH NUMBER FOR "UNIVERSAL SIZE" PACKAGING
4015 -18 -IB
IB  Individually Boxed
Please specify cylinder height if ordering in volume quantity for a specific cylinder height.
CYLINDERS & ACCESSORIES
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
46
4016 Header Bolt
MODEL
4016  Three-point converter, provides upper bolt for MS1850/1870 Deadlocks $55
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. LOCK BACKSET DOOR HEIGHT
4016 -30 -01
10  1-1/2" 01  7' Door
20  31/32" 02  10' Door
30  1-1/8"
4085 Header Bolt (Pairs of Doors Only)
sw 4085
MODELS & FINISHES
408501IB  Positioner bolt and header strike, specifiy cylinder height for 7' door height $83
408502IB, 408503IB, 408504IB  Positioner bolt and header strike, specify cylinder height for door
height greater than 7', door height 10’ maximum. $103
Contact factory for door height greater than 7'.
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. DIMENSION 'A' PACKAGING
4085 -02 -IB
01  30" - 52" IB  Individually Boxed
02  52" - 67"
03  67" - 79"
04  79" - 92"
EXAMPLE
Door Height Cylinder Height A
96" -40" =56"
REFERENCE:
7’ Door is 84"
8’ Door is 96"
9’ Door is 108"
10’ Door is 120"
4089 Exit Indicator
MODELS & FINISHES 119, 121, 130
408900, 408901  Indicator for 1-3/4" door, includes both UBC and IBC signs $53
408920  Indicator for 2" to 2-1/2" door, includes both UBC and IBC signs $88
ACCESSORIES
910912  Adapter plate for converting MS1850/4089 installation to deadlatch and lever handle or paddle. Select 121 or 130 finish. $32
200255IP  Header sign "…During Business Hours" $7
200256IP  IBC header sign "…Building is Occupied" $7
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO OPTIONS FINISH
4089 -01 -130
00  Standard 1-3/4" Door 119  To match 335 Black Anodized
01  For Inverted Lock 121  To match 313 Dark Bronze Anodized
20  For Doors up to 2-1/2" 130  To match 628 Clear Anodized
CYLINDERS & ACCESSORIES
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
47
4104 Mounting Bridges
MODELS
410401  Radius mounting bridge $10
410402  Flat mounting bridge $10
410403  Left hand bevel mounting bridge $10
410404  Right hand bevel mounting bridge $10
91-0965 Universal Mounting Tab Kits for Installing MS® Locks & Latches
MODELS
910965  Mounting tab kits for flat/radius stiles $15
910966  Mounting tab kits for beveled stiles, includes tabs for right hand and left hand
bevel doors and mounting screws for clear and dark bronze. $15
B1921, B1923 Reinforcing Pivots
MODELS & FINISH
B1921  1/2" oset to match pivot point of 4" wide butt hinge $84
B1923  3/4" oset to match pivot point of 4-1/2" wide butt hinge $74
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. MODEL
B192 1
1  4"
3  4-1/2"
Strikes
2190 Dual Force® Interconnected Deadbolt/Deadlatch Strikes
MODELS & FINISHES 630 119, 121
210101  Standard flat strike with dust box $25 $31
210102  Standard radius strike with dust box $25 $31
MODELS & FINISHES 630 121
2101XX  Strike with extended lip, 4.5" only, flat strike. $40 $46
210201  Retrofit strike extended height 7-5/8" with dust box. $37 $43
2290 Dual Force® Interconnected Deadbolt/Deadlatch Strikes
MODELS & FINISHES 630 119, 121
220601  Standard flat strike with dust box $25 $31
CYLINDERS & ACCESSORIES
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
48
4000 Series Series MS® Deadlock Strikes
MODELS & FINISHES 630 313,
335,
628
US3,
US26D 119, 121
4000  Trim Strike $26
4001  Box Strike, includes dust box $26 $46
MS4002  Armored Strike $54 $74
4003  ANSI strike, available in 121 or US26D only $66 $66
4005  Strike for 4015 Threshold Bolt $19
4006  Strike for 1830 Bottom Rail Deadlock, also available in 130 finish $42 $48
400901  Open back strike for 3300, 8300 Series Mortise Exit Device $135
4170  Trim strike for 4070 Short Throw Deadbolt, not available in 335 finish $26
450501  Flat armored box strike for MS+1890 Deadlock/Deadlatch $46 $52
450502  Radius armored box strike for MS+1890 Deadlock/Deadlatch $46 $52
450517, 450521  Flat long lip armored box strike $58 $64
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
STRIKE MODEL TRIM PLATE
SHAPE COMPATIBLE DEADLOCK TRIM PLATE
CORNERS FINISH
4001 -0 1 1 -313
4000  Trim Strike 0  Flat 1  All Standard MS® locks with 1-3/8" Bolt Throw 1  Square 313  Dark Bronze Anodized
4001  Box Strike 1  Radius 2  1850A-020 with 3/4" Bolt Throw Only 2  Round 335  Black Anodized
MS4002  Armored Strike 3  All MS-050 Hookbolt locks 628  Clear Anodized
4800, MS4804 Series Strikes
MODELS & FINISHES 603 630
MS480410630  Reinforcing strike and screws, two-part with reinforcement for strengthening metal jamb $19
4801  Metal strike, specify dash number indicating shim quantity $15 $22
4802  Wood strike, specify dash number indicating shim quantity $15 $22
481001, 481002  Box strike for 5017 Wood Door Deadlock/Deadlatch $15
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. TYPE OF JAMB DIMENSION 'A' FINISH
480 1-02 -630
1  Metal 01  3/32" 603  Zinc Plated Steel
2  Wood 02  3/16" 630  Satin Stainless
03  9/32"
CYLINDERS & ACCESSORIES
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
49
4901, 4902 Deadlatch Strikes
MODELS & FINISHES 630 119, 121
490101  Flush mount flat strike, mortised with dust box $16 $22
490102  Flush mount radius strike, mortised with dust box $16 $22
4901XX  Extended lip strike, specify lip dim 'A', 2.5" maximum* $36 $42
490201  Short box strike, flat with dust box, mounting plate $16 $22
490202  Short type box strike, radius with dust box, mounting plate $16 $22
4902XX  Extended lip strike, specify lip dim 'A', 2.5" maximum* $36 $42
4506  Strike for use with 4920AN, not available in 119 finish $36 $42
*See dim. ‘A’ dash chart table below.
HOW TO ORDERSpecify quantity and the following information. Order related products separately.
PRODUCT NO. STRIKE TYPE FACEPLATE SHAPE FINISH
490 1-02 630
STANDARD LIP 119  To match 335 Black Anodized
1  Long 01  Flat 121  To match 313 Dark Bronze Anodized
2  Short 02  Radius 630  Satin Stainless Steel
LONG LIP FOR
CENTER HUNG DOOR DIM. ‘A’ LONG LIP FOR
CENTER HUNG DOOR DIM. ‘A’
03  2-1/4" Wide Jamb 1-1/8 13  3-1/2" Wide Jamb 1-3/4
05  2-1/2" Wide Jamb 1-1/4 15  3-3/4" Wide Jamb 1-7/8
07  2-3/4" Wide Jamb 1-3/8 17  4" Wide Jamb 2
09  3" Wide Jamb 1-1/2 19  4-1/4" Wide Jamb 2-1/8
11  3-1/4" Wide Jamb 1-5/8 21  4-1/2" Wide Jamb 2-1/4
4304 Deadlatch Strike
MODEL & FINISHES 630 119, 121
4304  Surface mount strike for 4300 Electrified Deadlatch $20 $26
CYLINDERS & ACCESSORIES
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
50
Thick Door Kits
2190, 2290 Dual Force® Interconnected Deadbolt/Deadlatch Thick Door Kit
MODELS
2190TDKXX  Thick door kit for 2190, 2290 standard exterior trim set. Specify door thickness.* $61
2190TDKCL1, CL2  Thick door kit for 2190, 2290 cladded doors. CL-1 for a standard 1-3/4" thick door with
1/4" cladding. CL-2 for a standard 1-3/4" thick door with 1/2" cladding. $61
TDK4600X X  Thick door kit for 2190, 2290 low profile trim set. Specify door thickness.* $25
*For door thickness (01) 1-3/4", (02) 2", (03) 2-1/4", (04) 2-1/2", (05) 2-3/4", (06) 3", (07) 3-1/4".
4568, 4569 Eurostyle Deadlatch Handle Thick Door Kits
MODELS
91012802, 91012803, 91012804  Thick door kits for 4568, 4569 $18
26020301, 26020302, 26020303  Thick door kits for 4568-11, 4569-11 $18
Faceplates
MS1850S Deadlock Faceplates
MODELS & FINISHES 313, 628
BFKMS185010  Blank faceplate kit, flat, 1" x 6-7/8" $22
BFKMS185011  Blank faceplate kit, radius, 1" x 6-7/8" $22
MS1850S,
MS1950 Deadlock (Standard Bolt) Faceplates
MODELS & FINISHES 313, 335, 628 US4, US26D US3, US26
240384010  Flat faceplate $8 $29 $33
240384110  Radius faceplate $8 $29 $33
240384210  Left hand bevel faceplate $8 $29 $33
240384310  Right hand bevel faceplate $8 $29 $33
240384410  Radius with weatherstrip $11
SPECIAL MODELS 313, 628
240384110313B100, 240384110628B100 
Radius faceplates, bulk package of 100 units $640
240384210313B100, 240384210628B100 
Left hand bevel faceplates, bulk package of 100 units $640
240384310313B100, 240384310628B100 
Right hand bevel faceplates, bulk package of 100 units $640
240384410313B100, 240384410628B100 
Radius with weatherstrip faceplates, bulk package of 100 units $880
Please note that all 100 faceplates in the bulk package are of the same finish.
CYLINDERS & ACCESSORIES
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
51
MS1850S,
MS1950 Deadlock (Hookbolt and Short Bolt) Faceplates
MODELS & FINISHES 313, 335, 628 US4, US26D US3, US26
240384020  Flat faceplate $8 $29 $33
240384120  Radius faceplate $8 $29 $33
240384220  Left hand bevel faceplate $8 $29 $33
240384320  Right hand bevel faceplate $8 $29 $33
240384420  Radius with weatherstrip $11
SPECIAL MODELS 313, 628
240384020313B100, 240384020628B100 
Flat faceplates, bulk package of 100 units $640
240384120313B100, 240384120628B100 
Radius faceplates, bulk package of 100 units $640
240384220313B100, 240384220628B100 
Left hand bevel faceplates, bulk package of 100 units $640
240384320313B100, 240384320628B100 
Right hand bevel faceplates, bulk package of 100 units $640
240384420313B100, 240384420628B100 
Radius with weatherstrip faceplates, bulk package of 100 units $880
Please note that all 100 faceplates in the bulk package are of the same finish.
MS1850SN Deadlock (Standard Bolt) Faceplates
MODELS & FINISHES 313, 335, 628 US4, US26D US3, US26
240226010  Flat faceplate $10 $31 $35
240226110  Radius faceplate $10 $31 $35
240226210  Left hand bevel faceplate $10 $31 $35
240226310  Right hand bevel faceplate $10 $31 $35
MS1850SN-45X Deadlock (Hookbolt) Faceplates
MODELS & FINISHES 313, 335, 628 US4, US26D US3, US26
240226020  Flat faceplate $10 $31 $35
240226120  Radius faceplate $10 $31 $35
240226220  Left hand bevel faceplate $10 $31 $35
240226320  Right hand bevel faceplate $10 $31 $35
1870 Flushbolt Faceplates
MODELS & FINISHES 313, 335, 628
24016800  Flat faceplate $15
24016801  Radius faceplate $15
24016802  Left hand bevel faceplate $15
24016803  Right hand bevel faceplate $15
24016804  Radius with weatherstrip $18
CYLINDERS & ACCESSORIES
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
52
MS+1890 Deadlock Faceplates
MODELS & FINISHES 313, 335, 628
240270020  Flat faceplate $10
240270120  Radius faceplate $10
240270220  Left hand bevel faceplate $10
240270320  Right hand bevel faceplate $10
240270420  Radius with weatherstrip $13
2190 Dual Force® Interconnected Deadbolt/Deadlatch Faceplates
MODELS & FINISHES 313, 628
91026601313IP, 91026601628IP  Flat faceplate and radius faceplate kit for aluminum (2190) $37
91026604313IP, 91026604628IP  Flat faceplate and radius faceplate kit for wood or hollow metal (2290) $37
2331 Heavy Duty Deadbolt Faceplates
MODELS & FINISHES 121 US26D US3
220170  Flat faceplate $37 $37 $41
220032  Strike plate $37 $37 $41
3300 Fire-Rated Mortise Exit Device Faceplates
MODEL & FINISHES 335, 628
240015020  Flat faceplate $10
4070 Short Throw Deadbolt Faceplates
MODELS & FINISHES 313, 335, 628
24013600  Flat faceplate $10
24013610  Radius faceplate $10
24013620  Left hand bevel faceplate $10
24013630  Right hand bevel faceplate $10
4500 Standard Duty Deadlatch Faceplates
MODELS & FINISHES 313, 335, 628
2400170220Flat faceplate $8
2400171220Radius faceplate $8
2400172220Left hand bevel faceplate $8
2400173220Right Hand bevel faceplate $8
2400174220Radius with weatherstrip $11
SPECIAL MODELS 628
2400171220628B100Radius faceplates, bulk package of 100 units $640
Please note that all 100 faceplates in the bulk package are of the same finish.
CYLINDERS & ACCESSORIES
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
53
4530 Standard Duty Deadlatch Faceplates
MODELS & FINISHES 313, 335, 628
240016020  Flat faceplate $13
240016120  Radius faceplate $13
240016220  Left hand bevel faceplate $13
240016320  Right hand bevel faceplate $13
4900 Heavy Duty Deadlatch Faceplates
MODELS & FINISHES 313, 335, 628 US4, US26D US3, US26
24013701  Flat or bevel faceplate $8 $29 $33
24013702  Radius faceplate $8 $29 $33
24013703  Radius with weatherstrip $11
4900 Heavy Duty Deadlatch Special Faceplates
MODELS & FINISHES 313, 628
240140  Radius with weatherstrip seal (1-1/8" x 6-7/8") $16
24014401  Flat or beveled doors (1-1/8" x 7-1/4") $13
4920, 8300 Faceplates
MODEL & FINISHES 313, 335, 628
24013801  Flat or bevel faceplate $22
7100, 7160 Electric Strike Faceplates
MODEL & FINISHES 313, 335, 628
24068501  Round corner faceplate (1-1/4" x 4-7/8") $20
7101 Electric Strike Faceplates
MODEL & FINISHES 313, 335, 628
24068502  Radius faceplate (1-1/4" x 4-7/8") $20
7110 Electric Strike Faceplates
MODEL & FINISH 652
220558  Round corner faceplate (1-7/16" x 7-15/16") $20
7111 Electric Strike Faceplates
MODEL & FINISH 652
220557Round corner faceplate (1-7/16" x 10-1/4") $20
CYLINDERS & ACCESSORIES
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
54
7130 Electric Strike Faceplates
MODEL & FINISHES 313, 335, 628
24068601  Round corner faceplate (1-1/4" x 6-7/8") $25
7131 Electric Strike Faceplates
MODEL & FINISHES 313, 335,
628
24068602Radius faceplate (1-1/4" x 6-7/8") $25
7140, 7170 Electric Strike Faceplates
MODEL & FINISHES 313, 335,
628
24068701Radius faceplate (1-1/4" x 4-7/8") $20
CYLINDERS & ACCESSORIES
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
55
PS-1 Power Supply
MODEL
PS1  Power supply, 12/24 VDC boxed P/S 1 Amp $300
PS-LR Power Supply
MODEL
PS-LR  Power supply for exit devices with LR latch retraction option $760
KITTED OPTION
MODEL
BBKLR  Add-on board to the PS-LR, must be supplied with 2 each 12V - 7AH batteries (by others) $210
PS-SE Power Supply
MODEL
PSSE  Power supply for exit devices with SE latch retraction option $615
KITTED OPTION
MODEL
BBKSE  Add-on board to the PS-SE, must be supplied with 2 each 12V - 7AH batteries (by others) $210
4612 Power Transfer Device
MODELS
46121  Wire transfer, 105° swing $163
46122  Wire transfer, 180° swing $210
46121SC  Wire transfer, swing clear 90° swing $280
4612EL1  Wire transfer, 105° swing with ElectroLynx(TM) Adapter $189
4612EL1SC  Wire transfer, 90° swing with ElectroLynx(TM) Adapter $306
4603, 4605,
4606 Accessories for Power
MODELS
4603  Rectifier $15
4605  Transformer, 115 VAC to 12/24 VAC $53
4606  Plug-in transformer, 115 VAC to 24 VAC only $87
290218  Piezo electric horn $20
ELX  ElectroLynx™ Adapter to connect Adams Rite products to the ElectroLynx system $31
POWER
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
56
Deadlocks & Deadlatches
RT1050 RITE Touch® Digital Glass Door Lock
MODEL & FINISH
RT1050DDEMO  RITE Touch digital glass door lock with thumbturn, for all-glass doors $750
RT1050LDEMO  RITE Touch digital glass door lock with lever, for full-glass doors $750
2190 Dual Force® Interconnected Deadbolt/Deadlatch
MODELS & FINISH US32D
2190MOUNT  Dual Force® 2190 Interconnected Deadbolt/Deadlatch mounted complete with electrified trim set $1,000
4300 Steel Hawk® Electrified Deadlatch (eLatch)
MODELS & FINISH US32D
4300MOUNT  Steel Hawk® 4300 Electrified Deadlatch mounted complete with 4600 Heavy
Duty Designer Deadlatch Lever Trim with MN designer lever $850
Exit Devices
8400 Narrow Stile Mortise Exit Device
MODELS & FINISH 628
8400SEMOUNT  8400 Series Narrow Stile Mortise Exit Device featuring SE Silent Electrification option $1,600
Electric Strikes
7400 Ultraline® Electric Strikes
MODELS & FINISH
7440MOUNT  UltraLine 7440 Electric Strike mounted complete with 4-7/8" faceplate, 628 finish $750
74R1MOUNT  UltraLine 74R1 Electric Strike for rim exit devices with 3/4" Pullman latches mounted complete, 130 finish $750
74R2MOUNT  UltraLine 74R2 Electric Strike for rim exit devices with 1/2" Pullman latches mounted complete, 130 finish $750
DEMO MOUNTS
USA
800.872.3267 | orders.adamsrite@assaabloy.com
adamsrite.com
57
Trim
A100-3090H Keyless Entry and Aperio® Hub Wholesale Kit
MODELS & FINISH 626
A1003090CMOUNT  Aperio® A100 Keyless Entry Control and Aperio Hub with HID® iClass credentials, mounted complete
with 4900 Heavy Duty Deadlatch, 4600 Heavy Duty Designer Deadlatch Lever Trim $2,150
A1003090CKMOUNT  Aperio® A100 Keyless Entry Control and Aperio Hub with keypad and HID® iClass credentials, mounted
complete with 4900 Heavy Duty Deadlatch, 4600 Heavy Duty Designer Deadlatch Lever Trim $2,150
3090 eForce® Keyless Entry
MODELS & FINISH 626
3090MOUNT  eForce®3090-150 Keyless Entry Trim mounted complete with 4900 Heavy Duty Deadlatch $1,200
3090CMOUNT  eForce®3090P Keyless Entry Trim with HID® iClass credentials mounted complete with 4900 Heavy Duty Deadlatch $1,450
3090PMOUNT  eForce®3090P Keyless Entry Trim with HID® Prox credentials mounted complete with 4900 Heavy Duty Deadlatch $1,450
4600 Heavy Duty Designer Deadlatch Handles
MODELS & FINISH US32D
4600MOUNT  4600 Heavy Duty Designer Deadlatch Lever Trim with MN designer levers, mounted
complete with Dual Force® 2190 Deadbolt/Deadlatch (lock) $1,000
DEMO MOUNTS
Canada
800.461.3007 | cavau-sales@assaabloy.com
assaabloydss.ca
58
Limited Warranty
Products sold under the Adams Rite brand in the United States of America are warranted
free from defects in workmanship and materials under normal use and service.
This warranty does not cover defects or damage arising from improper installation,
lack of or improper maintenance, improper storage, shipping and handling,
corrosion, erosion, ordinary wear and tear, misuse, abuse, accident, unauthorized
service, or use with unauthorized non-Adams Rite products or parts.
This warranty is void if any modification is made to the product, regardless
of whether the modification causes or contributes to the alleged defect. All
modifications are made at the risk of the party making the modification.
Should any defect of manufacture (in material or workmanship) occur in its
products, Adams Rite, upon prompt notification and proof to its satisfaction that
the product was defective in manufacture for the use intended by Adams Rite,
will at its option, exchange the product, repair the product, or refund the price
charged by Adams Rite, FOB factory within the stated time frame listed below.
• All mechanical products for five (5) years from date of manufacture
• Ultraline® 7400 Electric Strikes for five (5) years from date of manufacture
• All electrical products for three (3) years from date of manufacture,
with the exception of the exit devices with the SE option
• Exit devices with the SE option for one (1) year from date of manufacture. Adams Rite
recommends that for optimal performance all exit devices with the SE option are
installed and powered using PS-SE power supplies. Installing SE exit devices with PS-SE
power supplies extends the warranty to five (5) years from date of manufacture.
General RMA Procedure
Product repair or replacement, or associated charges, will not be accepted under
this warranty unless prior authorization from Adams Rite has been given. Upon
receipt of products returned for repair or replacement, Adams Rite will determine
whether products qualify for repair or replacement under this warranty. Adams
Rite has no liability to pay any costs of repair performed by anyone other than
qualified personnel authorized by Adams Rite prior to the work being done.
Written notice of a product or component part believed to be defective as covered by
this warranty should be sent to Adams Rite, 10027 S. 51st Street, Suite 102, Phoenix,
Arizona 85044 or customer.care@assaabloy.com and should include your name and
address, an identification of the product or component part and a brief description of the
defect. Notice of a product or component part believed to be defective as covered by
this warranty may also be accepted over the telephone by Adams Rite, 800.872.3267.
Upon receipt of such notice, if the customer has an account with Adams Rite or a valid
credit card, an advance replacement product may be ordered whereby Adams Rite will
ship a replacement product to the customer free of charge. If Adams Rite does not receive
the original defective product from the customer within 60 days, Adams Rite will charge
the customer’s account or credit card for the price of the advanced replacement product
plus freight costs. Upon inspection of the returned product by Adams Rite, a decision will
be made whether or not to charge the customer for the advanced replacement Adams
Rite product. This decision will be made solely by Adams Rite in accordance with the
provisions of these Terms. Obsolete products will not be accepted for return. Return Material
Authorizations (RMAs) will be closed if the goods are not received within 60 days of issuance.
If Adams Rite receives original defective product from the customer within 60 days of
RMA issuance, and if the customer is requesting credit for the defective material, the
customer must reference the valid Adams Rite Purchase Order number upon which the
product was originally ordered. If the original Purchase Order number is not available, at
Adams Rite’s option a credit may be issued at the customer’s current cost. This decision
will be made solely by Adams Rite in accordance with the provisions of these Terms.
Transportation charges and insurance on all returned materials must be prepaid
by the purchaser when merchandise is ordered in error. On goods returned for
customer convenience, when the purchaser returns materials in compliance
with these Terms which are accepted by Adams Rite, the purchaser may be
issued a credit for 65% of the purchase price, with 35% charged by Adams Rite
for handling and reprocessing. All refunds will be in the form of a credit.
Scrap in field may be allowed on select products for customers who have prior agreement
with Adams Rite. In this case the original defective product will not have to be returned
to Adams Rite. Items allowed under this program are subject to the discretion of Adams
Rite and may change at any time. Only authorized product is allowed to be scrapped in
the field. Unauthorized product scrapped in the field will be considered ‘not returned’
and the customer will be charged for the replacement or credit will be denied.
Cancellation
As an industry leader, Adams Rite is committed to maintaining the highest standard of
quality and ensuring strict compliance to industry codes. Adams Rite’s proud history of
customer service and manufacturing agility allow quick response times to customer’s
changing needs, which may include special orders or product modifications. Please be
advised that all product modifications require special authorization to ensure the order
fully meets customer’s expectations. Customers are asked to allow for an extended
lead time on all special orders. Please note that at Adams Rite’s option, product
modifications and other special orders cannot be changed, cancelled, or returned
once a ship date has been provided on an order acknowledgement by Adams Rite.
Adams Rite prides itself on introducing new, industry-relevant, feature-rich products.
Since new solutions will surpass the capabilities of older product lines, historical
products may be subsequently discontinued. Every eort will be made to announce
new product introductions as well as product discontinuations in a manner that allows
customers advanced notice of these events. Once a product line is discontinued
orders will be fulfilled in order of receipt, although Adams Rite cannot guarantee all
orders can be filled. Repair services and spare parts for discontinued product lines
will be available for some reasonable time period. Adams Rite reserves the right to
replace discontinued product with an equivalent product as deemed by Adams Rite.
THIS WARRANTY IS IN LIEU OF ALL OTHER EXPRESS WARRANTIES. TO THE EXTENT
PERMITTED BY LAW, ALL IMPLIED WARRANTIES ARE LIMITED TO THE DURATION OF
THIS WARRANTY. ADAMS RITE IS A DIVISION OF HANCHETT ENTRY SYSTEMS, INC.
HANCHETT ENTRY SYSTEMS, INC. SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG
AN IMPLIED WARRANTY LASTS OR THE EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSIONS MAY
NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND
YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.
Contact Information
Customer Support: 1.800.872.3267
Website: adamsrite.com
Email: customer.care@assaabloy.com; phx.support@assaabloy.com;
orders.adamsrite@assaabloy.com
Customers purchasing from Door Security Solutions Canada can find
Canadian terms and conditions at www.assaabloydss.ca/terms.
LIMITED WARRANTY
Copyright © 2018, Hanchett Entry Systems, Inc., an ASSA ABLOY Group company. All rights reserved. Reproduc-
tion in whole or in part without the express written permission of Hanchett Entry Systems, Inc. is prohibited.
USA
800.872.3267
800.232.7329
adamsrite.com
customerservice.adamsrite@assaabloy.com
techsupport.adamsrite@assaabloy.com
orders.adamsrite@assaabloy.com
Canada
800.461.3007
assaabloydss.ca
Customer Support in Canada:
cavau-sales@assaabloy.com
Follow us on Twitter
at @AdamsRite
Subscribe to our YouTube
Channel at AdamsRiteMfg
Connect with us on
LinkedIn at Adams Rite
Like us on Facebook
at Adams Rite
ARM-035-1117

Navigation menu
