Adams Rite

2019 Pricelist

U.S. & Canada eective February 1, 2019

Adams Rite

2019 Pricelist

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

2019 Price List Adams Rite Architectural Hardware

DEADLOCKS

RT1050 RITE Touch®Digital Glass Door Lock --------------------------------- 4

1830 Bottom Rail Deadlock (Swingbolt) -----------------------------------------4

MS1837 Series MS® Two-Point Deadlock -------------------------------------- 4

MS1847 Series MS® Deadlock/Deadlatch -------------------------------------- 5

MS1850S, MS1850S-X5X Series MS® Deadlock -----------------------------5

1850S-X2X Series Short Throw Deadlock ------------------------------------- 6

MS1850SN, MS1850SN-45X Series MS® Deadlock (ANSI Size) --------- 6

MS1861 Series MS® Bottom Rail Deadlock ------------------------------------- 6

1875 Two-Point Deadlock ------------------------------------------------------------ 7

MS+1890 Series MS® Deadlock/Deadlacth ----------------------------------- 7

MS1950, MS1950-X5X Series MS® Deadlock --------------------------------- 8

2190, 2290 Dual Force® Interconnected Deadbolt/Deadlatch for

Aluminum Stile Doors (2190); for Wood or Hollow Metal (2290) -------9

2331 Heavy Duty Deadbolt ---------------------------------------------------------10

4070 Series Short Throw Deadbolt (Projection Style)---------------------10

5017 Deadlock/Deadlatch for Wood Doors -----------------------------------10

5500 Deadlock for Sliding Wood Doors --------------------------------------- 11

4189, 4190 Flush Locksets (Including Deadlock)

----------------------------------------------------------- moved to Flushlock section

4430, 4431 Flush Locksets (Including Deadlock)

----------------------------------------------------------- moved to Flushlock section

DEADLATCHES

4300 Steel Hawk® Electriﬁed Deadlatch ------------------------------------- 11

4300 RITE Pack® ----------------------------------------------------------------------- 12

4510 Standard Duty Deadlatch ----------------------------------------------------12

4530 Standard Duty Deadlatch ---------------------------------------------------13

4781 Two-Point Deadlatch with Paddle ----------------------------------------13

4900 Heavy Duty Deadlatch ------------------------------------------------------- 1 4

4920AN Heavy Duty Deadlatch (ANSI Size) -----------------------------------1 4

FLUSHLOCKS

1870 Cylinder-Operated Flushbolt -----------------------------------------------15

1870HM Cylinder-Operated Flushbolt ------------------------------------------15

1877 Cylinder-Operated Flushbolt -----------------------------------------------16

MS1880, MS1881 Two-Point Flushlocks ----------------------------------------16

MS2180 Auto-Release Two-Point Flushbolt ----------------------------------16

4189, 4190 Flush Locksets (Including Deadlock) ----------------------------17

4430, 4431 Flush Locksets (Including Deadlock) ---------------------------18

B1921, B1923 Reinforcing Pivots

----------------------------------- moved to Cylinders and Accessories section

EXIT DEVICES

8099 Dummy Pushbar ---------------------------------------------------------------18

3100, 8100 Surface Vertical Rod Exit Device --------------------------------- 1 9

8200 Narrow Stile Surface Vertical Rod Exit Device ----------------------19

3300, 8300 Mortise Exit Device -------------------------------------------------20

8400 Narrow Stile Mortise Exit Device ----------------------------------------- 2 1

3600, 8500 Metal Door Concealed Vertical Rod Exit Device --------- 22

8600 Narrow Stile Concealed Vertical Rod Exit Device ----------------- 22

3700, 8700 Rim Exit Device ------------------------------------------------------- 23

8800 Narrow Stile Rim Exit Device --------------------------------------------- 23

3900, 8900 Wood Door Concealed Vertical Rod Exit Device -------- 24

Accessories for 3000/8000 Series Exit Devices -------------------------- 24

Kitted Options for 3000/8000 Series Exit Devices ---------------------- 24

Modiﬁcation Options for 3000/8000 Series Exit Devices --------------25

EX SERIES

EX88 Interlocking Rim Exit Device ----------------------------------------------25

EX89 Pullman Rim Exit Device---------------------------------------------------- 25

EX76 Concealed Vetical Rod Exit Device ------------------------------------- 25

EX80 Dummy Push Bar -------------------------------------------------------------25

Accessories for EX Series Exit Devices ---------------------------------------- 25

ELECTRIC STRIKES

7100, 7101 Electric Strikes ------------------------------------------------------26

7110, 7111 Electric Strikes -----------------------------------------------------------26

7130, 7131 Electric Strikes ---------------------------------------------------------26

7140 Electric Strike ------------------------------------------------------------------ 27

7160 Electric Strike ------------------------------------------------------------------ 27

7170 Electric Strike ------------------------------------------------------------------- 27

7100 Series Electric Strikes Components -----------------------------------28

7240 Fire-Rated Electric Strike -------------------------------------------------- 2 9

7270 Fire-Rated Electric Strike -------------------------------------------------- 29

7400, 7401 Ultraline® Electric Strikes ----------------------------------------- 29

7410, 7411 Ultraline® Electric Strikes ------------------------------------------- 30

7430, 7431 Ultraline® Electric Strikes ------------------------------------------30

7440 Ultraline® Electric Strikes -------------------------------------------------30

74R1 Ultraline® Electric Strike ----------------------------------------------------- 31

74R2 Ultraline® Electric Strike ----------------------------------------------------31

7400 Series Electric Strikes Components ----------------------------------- 32

7800 Series Electric Strike -------------------------------------------------------- 33

7800 Series Electric Strikes Components ----------------------------------- 3 3

TRIM

1000 Series Turns --------------------------------------------------------------------- 34

3000 Fixed Pull ------------------------------------------------------------------------ 34

3080 Series Entry Trim -------------------------------------------------------------- 35

3090 eForce® Keyless Entry ----------------------------------------------------- 3 6

A100-3090H Keyless Entry and Aperio® Hub Pre-Paired Kit ---------- 36

4060 Turn -------------------------------------------------------------------------------- 3 7

4550 MS® Deadlock Lever -------------------------------------------------------- 37

4560, 4565 Series Deadlatch Handles ----------------------------------------38

4568, 4569 Eurostyle Deadlatch Handles -----------------------------------39

4590 Deadlatch Paddle-------------------------------------------------------------40

4591 Deadlatch Paddle --------------------------------------------------------------41

4600 Heavy Duty Designer Deadlatch Handles -------------------------- 42

CYLINDERS & ACCESSORIES

4024, 4025, 4026 Cylinder Pulls ------------------------------------------------ 43

4036 Mortise Cylinder -------------------------------------------------------------- 43

MS4043 Cylinder Guard ----------------------------------------------------------- 44

4066 Thumbturn --------------------------------------------------------------------- 44

4580 Cam Disc ------------------------------------------------------------------------ 4 4

4581 Universal Cam Disc ---------------------------------------------------------- 45

8650 Cylinder Escutcheon Kit --------------------------------------------------- 45

8736 Rim Cylinder ------------------------------------------------------------------- 45

4014 Two-Point Conversion Kit -------------------------------------------------- 45

4015 Threshold Bolt ------------------------------------------------------------------ 45

4016 Header Bolt --------------------------------------------------------------------- 46

4085 Header Bolt (Pairs of Doors Only) --------------------------------------- 4 6

4089 Exit Indicator ------------------------------------------------------------------- 46

4104 Mounting Bridges ------------------------------------------------------------- 47

91-0965 Universal Mounting Tab Kits

for Installing MS® Locks & Latches --------------------------------------------- 47

B1921, B1923 Reinforcing Pivots ------------------------------------------------- 47

STRIKES

2190 Dual Force® Interconnected

Deadbolt/Deadlatch Strikes ------------------------------------------------------ 47

2290 Dual Force® Interconnected

Deadbolt/Deadlatch Strikes ------------------------------------------------------ 47

4000 Series MS® Deadlock Strikes --------------------------------------------48

4800, MS 4804 Series Strikes ---------------------------------------------------- 4 8

4901, 4902 Deadlatch Strikes --------------------------------------------------- 49

4304 Deadlatch Strike--------------------------------------------------------------- 49

CYLINDERS & ACCESSORIES CONT.

THICK DOOR KITS

2190, 2290 Dual Force® Interconnected

Deadbolt/Deadlatch Thick Door Kit -------------------------------------------50

4568, 4569 Eurostyle Deadlatch Handles Thick Door Kits ------------ 50

FACEPLATES

MS1850S Deadlocks Faceplates ------------------------------------------------50

MS1850S, MS1950 Deadlock (Standard Bolt) Faceplates --------------- 5 0

MS1850S, MS1950 Deadlock

(Hookbolt and Short Bolt) Faceplates ------------------------------------------51

MS1850SN Deadlock (Standard Bolt) Faceplates --------------------------- 51

MS1850SN Deadlock (Hookbolt) Faceplates --------------------------------- 51

1870 Flushbolt Faceplates ----------------------------------------------------------51

MS+1890 Deadlock Faceplates -------------------------------------------------- 52

2190 Dual Force® Interconnected

Deadbolt/Deadlatch Faceplates -------------------------------------------------52

2331 Heavy Duty Deadbolt Faceplates --------------------------------------- 52

3300 Fire-Rated Mortise Exit Device Faceplates --------------------------52

4070 Short Throw Deadbolt Faceplates -------------------------------------- 52

4500 Standard Duty Deadlatch Faceplates --------------------------------- 52

4530 Standard Duty Deadlatch Faceplates----------------------------------53

4900 Heavy Duty Deadlatch Faceplates ------------------------------------- 53

4900 Heavy Duty Deadlatch Special Faceplates --------------------------5 3

4920, 8300 Faceplates ------------------------------------------------------------53

7100, 7160 Electric Strikes Faceplates ---------------------------------------- 53

7101 Electric Strike Faceplates ---------------------------------------------------53

7110 Electric Strike Faceplates --------------------------------------------------- 53

7111 Electric Strike Faceplates ---------------------------------------------------- 53

7130 Electric Strike Faceplates --------------------------------------------------- 5 4

7131 Electric Strike Faceplates---------------------------------------------------- 54

7140, 7170 Electric Strike Faceplates ------------------------------------------ 5 4

POWER

PS-1 Power Supply -------------------------------------------------------------------- 54

PS-LR Power Supply ----------------------------------------------------------------- 54

PS-SE Power Supply ----------------------------------------------------------------- 54

4612 Power Transfer Device-------------------------------------------------------55

4603, 4605, 4606 Accessories for Power -----------------------------------55

DEMO MOUNTS

DEADLOCKS & DEADLATCHES

RT1050 RITE Touch® Digital Glass Door Lock -------------------------------55

2190 Dual Force® Interconnected Deadbolt/Deadlatch ---------------- 55

4300 Steel Hawk® Electriﬁed Deadlatch (eLatch)------------------------- 55

EXIT DEVICES

8400 Narrow Stile Mortise Exit Device ----------------------------------------55

ELECTRIC STRIKES

7400 Ultraline® Electric Strikes -------------------------------------------------56

TRIM

3090, 3090P/C eForce® Keyless Entry -------------------------------------- 56

A100-3090H Keyless Entry and Aperio® Hub Wholesale Kit ---------- 56

4600 Heavy Duty Designer Deadlatch Handles --------------------------56

GENERAL INFORMATION

Adams Rite Limited Warranty/Terms and Conditions -------------------- 57

Canadian Terms & Conditions ---------------------------------------------------- 57

TABLE OF CONTENTS

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

RT1050 RITE Touch® Digital Glass Door Lock

MODELS PRICE

RT1050D Digital glass door lock with thumbturn, for single doors, or pairs of doors with one inactive leaf $649

RT1050L Digital glass door lock with lever, for single doors, or pairs of doors with one inactive leaf $649

RT-5C-1050 Extra cards (package of 5 cards) $61

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT MODEL TRIM

RT 1050 D

1050 For glass doors D Thumbturn

L Accessibility lever

1830 Bottom Rail Deadlock (Swingbolt)

MODEL & FINISHES 313, 628

1830 Deadlock with 31/32", or 1-1/8" cylinder height $139

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. DASH NO.

(SPECIFY FOR CYLINDER HEIGHT AND LOCK DEPTH) FINISH

1830 -02 -628

02 Cylinder Height 31/32" Dim. "A" 1-5/8" 628 Clear Anodized

03 Cylinder Height 1-1/8" Dim. "A" 1-25/32" 313 Dark Bronze Anodized

MS1837 Series MS® Two-Point Deadlock

MODELS & FINISHES 313, 335, 628 605, 626

MS1837 Deadlock includes 4001-011 strike, 36" cylinder height $245 $330

MS1837 Deadlock includes 4001-011 strike, contact factory for cylinder height other than 36"

up to maximum cylinder height 65"

$300 $385

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. FINISH

MS1837 -313

313 Dark Bronze Anodized 626 Satin Chrome

335 Black Anodized 628 Clear Anodized

605 Bright Brass

If cylinder height other than 36" is required, specify exact height from bottom of door to cylinder center. Maximum cylinder height 65".

DEADLOCKS

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

DEADLOCKS

MS1847 Series MS® Deadlock/Deadlatch

MODEL & FINISH 630

MS1847 Deadlock/deadlatch, stainless steel $61

HOW TO ORDERSpecify quantity and the following information. Order related products separately.

PRODUCT NO. FACE SHAPE, HUB ANGLE, LOCK OR LATCH FINISH

MS1847 -02 -630

(See Conﬁguration table below)

(Blank) -02 -06

-09 -10 -11

-13

SELF-

LATCHING

SELF-

LATCHING

VERT.

22.5° 22.5°

45° 45°

45°

630 Satin Stainless

MS1850S,

MS1850S-X5X Series MS® Deadlock

MODELS & BACKSETS 7/8" 31/32", 11/8",

OR 11/2"

MS1850S Flat faceplate, 313, 335, or 628 ﬁnish, without strike plate $82 $70

MS1851S Radius faceplate, 313, 335, or 628 ﬁnish, without strike plate $82 $70

MS1851SW Radius faceplate with weatherstrip, 313, 335, or 628 ﬁnish, without strike plate $87 $75

MS1852S Bevel faceplate, any handing, 313, 335, or 628 ﬁnish, without strike plate $82 $70

SPECIAL MODEL 7/8" 31/32", 11/8",

OR 11/2"

MS1853S-XXX-IB Without faceplate, without strike plate $74 $62

Schoolhouse function for above deadlocks add$36. Please contact factory for more information.

HOW TO ORDERSpecify quantity and the following information. Order related products separately.

PRODUCT NO. FACEPLATE BACKSET BOLT SHAPE HANDING FINISH

MS185 0S -2 1 0 -628

0S Flat 1 7/8" 1 Straight bolt 0 Non-Handed* 313 Dark Bronze Anodized

1S Radius 2 31/32" 5 Hookbolt 5 LH or RHR 335 Black Anodized

1SW Radius with weatherstrip 3 1-1/8" 6 RH or LHR 628 Clear Anodized

2S Bevel 4 1-1/2"

3 Without faceplace,

without strike plate

*Any ﬂat or radius faceplate, except Schoolhouse. Select handing for bevel faceplate only.

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

1850S-X2X Series Short Throw Deadlock

MODELS & FINISHES 313, 335, 628

1850S Flat faceplate, 31/32", 1-1/8", or 1-1/2" backset, without strike plate $70

1851S Radius faceplate, 313, 335, or 628 ﬁnish, without strike plate $70

1852S Bevel faceplate, any handing, 313, 335, or 628 ﬁnish, without strike plate $70

SPECIAL MODEL PRICE

1853S-X20-IB Without faceplate, without strike plate $62

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. FACEPLATE BACKSET BOLT SHAPE HANDING FINISH

185 0S -2 2 0 -628

0S Flat 2 31/32" 2 Short Throw 0 Non-Handed* 313 Dark Bronze Anodized

1S Radius 3 1-1/8" 5 LH or RHR 628 Clear Anodized

2S Bevel 4 1-1/2" 6 RH or LHR

3 Without faceplace,

without strike plate

*Any ﬂat or radius faceplate, except Schoolhouse. Select handing for bevel faceplate only.

MS1850SN,

MS1850SN-45X

Series MS® Deadlock (ANSI Size)

MODELS 313, 335, 628

MS1850SN Flat faceplate, 1-1/2" backset, without strike plate $99

MS1851SN Radius faceplate, 1-1/2" backset, without strike plate $99

MS1852SN Bevel faceplate, any handing, 1-1/2" backset, without strike plate $99

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. FACEPLATE ANSI SIZE BOLT SHAPE HANDING FINISH

MS185 0 SN -41 0 -628

0 Flat 41 Straight bolt 0 Non-Handed* 313 Dark Bronze Anodized

1 Radius 45 Hookbolt 5 LH or RHR 335 Black Anodized

2 Bevel 6 RH or LHR 628 Clear Anodized

*Any ﬂat or radius faceplate, except Schoolhouse. Select handing for bevel faceplate only.

MS1861 Series MS® Bottom Rail Deadlock

MODELS & FINISH 603

MS1861-01 One-point deadlock, vertical bolt operation only $145

MS1861-02 Two-point deadlock, horizontal and vertical operation $180

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. BOLT OPERATION FINISH PACKAGING

MS1861 -01 -603 -IB

01 Vertical Bolt Only 603 Zinc plated steel IB Individually Boxed

02 Vertical and Horizontal Bolts

If tube spacers are required, please specify quantity and length.

DEADLOCKS

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

1875 Two Point Deadlock

MODEL & FINISH 603

1875 Two-point deadlock for roll-up doors $180

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. PACKAGING

1875 -IB

IB Individually Boxed

MS+1890 Series MS® Deadlock/Deadlatch

MODELS & FINISHES 313, 335, 628

MS+1890 Flat faceplate, 31/32", 1-1/8", or 1-1/2" backset $243

MS+1891 Radius faceplate, 31/32", 1-1/8", or 1-1/2" backset $243

MS+1891W Radius faceplate with weatherstrip, 31/32", 1-1/8", or 1-1/2" backset $253

MS+1892 Bevel faceplate, any handing, 31/32", 1-1/8", or 1-1/2" backset $243

SPECIAL MODELS PRICE

MS+1890, MS+1891, MS+1892 Flat, radius, or bevel faceplate, complete with ﬂat / center hung 4" or 4-1/2" strike plate $256

MS+1893-XX-IB Without faceplate, without strike plate $187

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. FACEPLATE BACKSET STRIKE SHAPE/LIP LENGTH HANDING FINISH

MS+189 1 -3 02 6 -628

0 Flat 2 31/32" 01 Flat/Standard Jamb 5 LH or RHR 313 Dark Bronze Anodized

1 Radius 3 1-1/8" 02 Radius/Standard Stile 6 RH or LHR 335 Black Anodized

1W Radius with weatherstrip 4 1-1/2" 17 Flat/Center Hung 4" Jamb 628 Clear Anodized

2 Bevel 21 Flat/Center Hung 4-1/2" Jamb

3 Without faceplace,

without strike plate

For door thickness other than 1-3/4", please contact factory.

DEADLOCKS

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

MS1950,

MS1950-X5X Series MS® Deadlock

MODELS 313, 335, 628

MS1950 Flat faceplate, 31/32", 1-1/8", or 1-1/2" backset, without strike plate $128

MS1951 Radius faceplate, 31/32", 1-1/8", or 1-1/2" backset, without strike plate $128

MS1951W Radius faceplate with weatherstrip, 31/32", 1-1/8", or 1-1/2" backset, without strike plate $133

MS1952 Bevel faceplate, any handing,31/32", 1-1/8", or 1-1/2" backset, without strike plate $128

SPECIAL MODEL PRICE

MS1953S-XXX-IB Without faceplate, without strike plate $120

Schoolhouse function for above deadlocks add$36. Please contact factory for more information.

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. FACEPLATE BACKSET BOLT SHAPE HANDING FINISH

MS195 0 -2 1 0 -628

0 Flat 2 31/32" 1 Straight bolt 0 Non-Handed* 313 Dark Bronze Anodized

1 Radius 3 1-1/8" 5 Hookbolt 5 LH or RHR 335 Black Anodized

1W Radius with weatherstrip 4 1-1/2" 6 RH or LHR 628 Clear Anodized

2 Bevel

3 Without faceplace,

without strike plate

*Any ﬂat or radius faceplate, except Schoolhouse. Select handing for bevel faceplate only.

DEADLOCKS

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

2190, 2290 Dual Force® Interconnected Deadbolt/Deadlatch

for Aluminum Doors (2190); for Wood or Hollow Metal (2290)

STANDARD

TRIM SET

ELECTRIFIED

TRIM SET

LOW PROFILE

TRIM

MODELS & TRIM SETS

10B,

US4,

US32D

US3,

US32

10B,

US4,

US32D

US3,

US32

10B,

US4,

US32D

US3,

US32

STANDARD

LEVER

2190, 2290 Deadbolt/Deadlatch with standard

lever (01, 02, 03), complete with strike plate $627 $709 $791 $873 $552 $634

2190 Deadbolt/Deadlatch with standard lever

(01, 02, 03), complete with ﬂat/center hung 4" or 4-1/2" strike plate $642 $724 $806 $888 $567 $649

2190, 2290 Deadbolt/Deadlatch with standard

lever (01, 02, 03), without strike plate $601 $683 $765 $847 $526 $608

DESIGNER

LEVER

2190, 2290 Deadbolt/Deadlatch with designer lever

series (MD through MW), complete with strike plate $673 $755 $837 $919 $598 $680

2190 Deadbolt/Deadlatch with with designer

lever series (MD through MW), complete with ﬂat/

center hung 4" or 4-1/2" strike plate

$693 $775 $857 $939 $618 $700

2190, 2290 Deadbolt/Deadlatch with designer lever

series (MD through MW), without strike plate $647 $729 $811 $893 $572 $654

MODELS & FINISHES 313, 335, 628 N/A

2190, 2290 Boxed Lock

Less lever trim, with adjustable faceplate and choice of standard or radius strike $296

EK-2190 Electriﬁcation Kit for 2190, 2290; 12/24 VAC/VDC (not compatible with low proﬁle trim) $174

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT

NO. BACKSET STRIKE FACEPLATE FINISH TRIM HANDLE DESIGNATION TRIM AND HANDLE

FINISH

2190 -3 1 1 -1 01 32D

3 1-1/8" 0 None 1 Clear Anodized 628 0 None 00 No Handle 03 Bright Brass (US3)

4 1-1/2" 1 Standard Flat 2 Dark Bronze Anodized 313 1 With Trim Set STANDARD SERIES: 04 Satin Brass (US4)

2 Radius Strike 3 Black Anodized 335 2 With Electriﬁed Trim Set 01 Curve 10B Dark Bronze

3 Flat/Center Hung 4" 3 Low Proﬁle Trim 02 Round 32 Bright Stainless (US32)

4 Flat/Center Hung 4-1/2" 03 Square 32D Satin Stainless (US32D)

DESIGNER SERIES:

MD MG MJ MV (Handed)

ME MI MN (Handed) MW

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT

NO. BACKSET STRIKE FACEPLATE FINISH TRIM HANDLE DESIGNATION TRIM AND HANDLE

FINISH

2290 -3 1 1 -1 01 32D

3 1-1/8" 0 None 0 US to match trim ﬁnish 0 None 00 No Handle 03 Bright Brass (US3)

4 1-1/2" 1 Standard Flat 1 Clear Anodized 628 1 With Trim Set STANDARD SERIES: 04 Satin Brass (US4)

2 Dark Bronze Anodized 313 2 With Electriﬁed Trim Set 01 Curve 10B Dark Bronze

3 Low Proﬁle Trim 02 Round 32 Bright Stainless (US32)

03 Square 32D Satin Stainless (US32D)

DESIGNER SERIES:

MD MG MJ MV (Handed)

ME MI MN (Handed) MW

DEADLOCKS

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

2331 Heavy Duty Deadbolt

MODEL & FINISHES 121, 626 605, 625

2331 Deadbolt, 1-3/4" backset, complete with strike $306 $336

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. FINISH

2331 -626

121 To Match 313 Dark Bronze Anodized

605 Bright Brass

625 Bright Chrome

626 Satin Chrome

4070 Series Short Throw Deadbolt (Projection Style)

MODELS & FINISHES 313, 335, 628

4070 Flat faceplate, 7/8", 31/32", or 1-1/8" backset, without strike plate $169

4071 Radius faceplate, 7/8", 31/32", or 1-1/8" backset, without strike plate $169

4072 Bevel faceplate, any handing, 7/8", 31/32", or 1-1/8" backset, without strike plate $169

SPECIAL MODEL PRICE

4073-XX-IB Without faceplate, without strike plate $159

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. FACEPLATE BACKSET HANDING FINISH

407 2 -2 6 -628

0 Flat 1 7/8" 0 Non-Handed* 313 Dark Bronze Anodized

1 Radius 2 31/32" 5 LH or RHR 335 Black Anodized

2 Bevel 3 1-1/8" 6 RH or LHR 628 Clear Anodized

3 Without faceplace,

without strike plate

*Any ﬂat or radius faceplate. Select handing for bevel faceplate only.

5017 Deadlock/Deadlatch for Wood Doors

MODELS & FINISH 630

5017-00 Standard stainless steel deadlock $62

5017-02 Self-latching deadlock/deadlatch $62

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. LATCH CONFIGURATION

5017 -00

00 Standard

02 Self Latching

DEADLOCKS

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

5500 Deadlock for Sliding Wood Doors

MODELS 119, 626

5500-20 Lockset, strike, and trim included for 1-1/4", sliding wood doors $133

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. DOOR THICKNESS FINISH

5500 -20 -626

20 1-1/4" Thick 626 Satin Chrome

119 to Match 335 Black Anodized

DEADLATCHES

4300 Steel Hawk® Electriﬁed Deadlatch

MODELS & FINISHES 313, 335, 628

4300 Electriﬁed deadlatch 31/32", 1-1/8", or 1-1/2" backset $431

4300M Monitored option, 31/32", 1-1/8", or 1-1/2" backset $493

SPECIAL MODELS 313, 335, 628

4300 Electriﬁed deadlatch complete with ﬂat / center hung 4" or 4-1/2" strike plate $451

4300M Electriﬁed deadlatch with monitored option, complete with ﬂat / center hung 4" or 4-1/2" strike plate $513

HOW TO ORDER SPECIFY QUANTITY AND THE FOLLOWING

INFORMATION. ORDER RELATED PRODUCTS SEPARATELY

PRODUCT NO. BACKSET MONITORING STRIKE STIRKE SHAPE/LIP LENGTH FACEPLATE FINISH

4300 -3 M -2 01 -628

2 31/32" 0 None 1 Surface Mount (4304) 01 Flat/Standard Jamb 313 Dark Bronze Anodized

3 1-1/8" M Monitored 2 Mortised (4901) 4-5/8 02 Radius/Standard Stiles** 335 Black Anodized

4 1-1/2" 17 Flat/Center Hung 4" Jamb** 628 Clear Anodized

21 Flat/Center Hung 4-1/2" Jamb**

** See ACCESSORIES for available 4901 strike options.

4300 RITE Pack®

MODELS 313, 628

4300-20 31/32" backset, ﬂat and radius, 313 and 628 ﬁnish faceplates, surface mount or mortise strike $442

4300-30 1-1/8" backset, ﬂat and radius, 313 and 628 ﬁnish faceplates, surface mount or mortise strike $442

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. BACKSET MONITORING STRIKE RITE PACK

4300 -3 0 -1 RP

2 31/32" 0 None 1 Surface Mount (4304)

3 1-1/8" 2 Mortised (4901) 4-5/8"

DEADLOCKS | DEADLATCHES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

4510 Standard Duty Deadlatch

MODELS & FINISHES 313, 335, 628

4510 Flat faceplate, 7/8", 31/32", 1-1/8", or 1-1/2" backset, complete with strike plate $85

4511 Radius faceplate, 7/8", 31/32", 1-1/8", or 1-1/2" backset, complete with strike plate $85

4511W Radius faceplate with weatherstrip, 7/8", 31/32", 1-1/8", or 1-1/2" backset, complete with strike plate $90

4512 Bevel faceplate, 7/8", 31/32", 1-1/8", or 1-1/2" backset, complete with strike plate $85

SPECIAL MODELS

4510, 4511, 4512 Flat, radius or bevel faceplate complete with ﬂat / center hung 4" or 4-1/2" strike plate $105

4511W Radius faceplate with weatherstrip complete with ﬂat / center hung 4" or 4-1/2" strike plate $110

4510, 4511, 4512 With faceplate, without strike plate $68

4511W Radius faceplate with weatherstrip, without strike plate $73

4513-XX-IB Without faceplate, without strike plate $60

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. FACEPLATE BACKSET HANDING STRIKE SIZE STRIKE SHAPE/LIP LENGTH FACEPLATE FINISH

451 1 -3 6 -2 01 -628

0 Flat 1 7/8" 5 LH or RHR 1 Mortised

(4901) 4-5/8" 01 Flat/Standard Jamb 313 Dark Bronze

Anodized

1 Radius 2 31/32" 6 RH or LHR 2 Mortised

(4902) 2-5/8" 02 Radius/Standard Stiles 335 Black Anodized

1W Radius with

weatherstrip 3 1-1/8" 17 Flat/Center Hung 4" Jamb 628 Clear Anodized

2 Bevel 4 1-1/2" 21 Flat/Center Hung 4-1/2" Jamb

3 Without faceplate,

without strike plate

DEADLATCHES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

4530 Standard Duty Deadlatch

MODELS & FINISHES 313, 335, 628

4530 Flat faceplate, 7/8", 31/32", or 1-1/8" backset, complete with strike plate $103

4531 Radius faceplate, 7/8", 31/32", or 1-1/8" backset, complete with strike plate $103

4532 Bevel faceplate, 7/8", 31/32", or 1-1/8" backset, complete with strike plate $103

SPECIAL MODELS

4530, 4531, 4532 Flat, radius or bevel faceplate complete with ﬂat / center hung 4" or 4-1/2" strike plate $123

4530, 4531, 4532 With faceplate without strike plate $86

4533-XX-IB Without faceplate, without strike plate $78

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. FACEPLATE BACKSET HANDING STRIKE SIZE STRIKE SHAPE/LIP LENGTH FACEPLATE FINISH

453 1 -3 6 -1 01 -628

0 Flat 1 7/8" 5 LH or RHR 1 Mortised (4901) 4-5/8" 01 Flat/Standard Jamb 313 Dark Bronze Anodized

1 Radius 2 31/32" 6 RH or LHR 2 Mortised (4902) 2-5/8" 02 Radius/Standard Stiles 335 Black Anodized

2 Bevel 3 1-1/8" 17 Flat/Center Hung 4" Jamb 628 Clear Anodized

3 Without

faceplate,

without

strike plate

21 Flat/Center Hung 4-1/2" Jamb

4781 Two-Point Deadlatch with Paddle

MODEL & FINISHES 313, 335, 628 US26D

4781 Paddle includes dogging feature $332 $445

4781T Paddle with top rod only (less bottom rod) $301 $414

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. OPERATION PADDLE FINISH

4781 T -021 -628

T Top rod only 021 Push to LEFT 313 Dark Bronze Anodized US26D Satin Chrome

– Standard rod 041 Push to RIGHT 335 Black Anodized

628 Clear Anodized

DEADLATCHES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

4900 Heavy Duty Deadlatch

MODELS & FINISHES 313, 335, 628

4900 Flat and radius faceplates, 31/32", 1-1/8", or 1-1/2" backset, complete with strike plate $115

4911W Radius with weatherseal faceplate, 31/32", 1-1/8", or 1-1/2" backset, complete with strike plate $120

SPECIAL MODELS

4900 Flat and radius faceplates complete with ﬂat / center hung 4" or 4-1/2" strike plate $135

4911W Radius with weatherstrip faceplate complete with ﬂat / center hung 4" or 4-1/2" strike plate $140

4900 Flat and radius faceplate, without strike plate $98

4911W Radius with weatherstrip faceplate, without strike plate $103

4913-XX-IB Without faceplate, without strike plate $90

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. FACEPLATE BACKSET HANDING STRIKE SIZE STRIKE SHAPE/LIP LENGTH FACEPLATE FINISH

49 00 -3 5 -2 01 -628

00 Standard 2 31/32" 5 LH or RHR 1 Mortised

(4901) 4-5/8" 01 Flat/Standard Jamb 313 Dark Bronze

Anodized

11W Radius with

Weatherstrip 3 1-1/8"

6 RH or LHR 2 Mortised

(4902) 2-5/8"

02 Radius/Standard Stile 335 Black Anodized

13 Without faceplate,

without strike plate 4 1-1/2" 17 Flat/Center Hung 4" Jamb 628 Clear Anodized

21 Flat/Center Hung 4-1/2" Jamb

4920AN Heavy Duty Deadlatch (ANSI Size)

MODELS & FINISHES 313, 335, 628

4920AN Flat faceplate, 1-1/2" or 2-3/4" backset, complete with 4506 strike plate $141

SPECIAL MODELS

4920AN Flat faceplate, without strike plate $104

4923AN-XX-IB Without faceplate, without strike plate $82

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. FACEPLATE BACKSET HANDING STRIKE FACEPLATE FINISH

492 0AN 4 6 -602 -313

OAN Flat 4 1-1/2" 5 LH or RHR 000 Less Strike 313 Dark Bronze

Anodized

3AN Without faceplate,

without strike plate 5 2-3/4" 6 RH or LHR 602 4506 Strike 335 Black Anodized

628 Clear Anodized

DEADLATCHES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

FLUSHLOCKS

1870 Cylinder-Operated Flushbolt

MODELS & CYLINDER HEIGHT STANDARD 12"

CYLINDER HEIGHT

OVER 12" SPECIFY

1870 Flat faceplate, 313, 335, or 628 ﬁnish $119 $170

1871 Radius faceplate, 313, 335, or 628 ﬁnish $119 $170

1871W Radius faceplate with weatherstrip, 313, 335, or 628 ﬁnish $124 $175

1872 Bevel faceplate, 313, 335, or 628 ﬁnish $119 $170

For cylinder height greater than 12" up to maximum cylinder height 65" please contact factory.

HOW TO ORDERSpecify quantity and the following information. Order related products separately.

PRODUCT NO. FACEPLATE SHAPE BACKSET HANDING* FINISH

187 0 -2 0 -628

0 Flat 2 31/32" 0 Non-Handed* 313 Dark Bronze Anodized

1 Radius 3 1-1/8" 5 LH or RHR 335 Black Anodized

1W Radius with weatherstrip 6 RH or LHR 628 Clear Anodized

2 Bevel

*Any ﬂat or radius faceplate. Select handing for bevel faceplate only.

1870HM Cylinder-Operated Flushbolt

MODEL & CYLINDER HEIGHT STANDARD 131/2"

CYLINDER HEIGHT

OVER 131/2" SPECIFY

1870HM For hollow metal, 313, 335, or 628 ﬁnish, 1-1/4" backset $160 $211

For cylinder height greater than 13-1/2" up to maximum cylinder height 65" please contact factory.

HOW TO ORDERSpecify quantity and the following information. Order related products separately.

PRODUCT NO. FACEPLATE SHAPE FINISH

187 0HM -628

0HM Flat 313 Dark Bronze Anodized

335 Black Anodized

628 Clear Anodized

1877 Cylinder-Operated Flushbolt

MODEL & CYLINDER HEIGHT STANDARD 131/2"

CYLINDER HEIGHT

OVER 131/2" SPECIFY

1877 For wood, 313 or 628 ﬁnish, 1-1/4" backset $199 $250

1877 For wood, 605 or 626 ﬁnish, 1-1/4" backset $281 $332

For cylinder height greater than 13-1/2" up to maximum cylinder height 57-1/2" please contact factory.

HOW TO ORDERSpecify quantity and the following information. Order related products separately.

PRODUCT NO. FINISH

1877 -628

313 Dark Bronze Anodized 626 Satin Chrome

605 Bright Brass 628 Clear Anodized

FLUSHLOCKS

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

MS1880, MS1881 Two-Point Flushbolts

MODELS & FINISHES 119, 121, 682

MS1880 Flushbolt with hourglass shaped turn $152

MS1881 Flushbolt with teardrop shaped turn $152

KITTED OPTION

MODEL

TDK-1880 Tall door kit for doors over 84", up to 144" maximum $29

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. TURN SHAPE CYLINDER HEIGHT* FINISH

MS188 0 -01 -682

MS188 0 Hourglass 01 31" to 35" 119 to Match 335 Black Anodized

1 Teardrop 02 35-1/16" to 39" 121 to Match 313 Dark Bronze Anodized

03 39-1/16" 43" 682 Satin Chrome

04 43-1/16" to 47"

05 47-1/16" to 51"

*Distance from ﬂoor to cylinder centerline.

MS2180 Auto-Release Two-Point Flushbolt

MODELS & FINISHES 119, 121, 130

MS2180 Hourglass shaped turn, 7', 8', 9', 10' door height $228

MS2181 Teardrop shaped turn, 7', 8', 9', 10' door height $228

MS2182 Flush operator, 7', 8', 9', 10' door height $228

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. TURN SHAPE DOOR HEIGHT

(FROM FLOOR TO TOP OF DOOR) FINISH TO MATCH

MS218 0 -07 -130

0 Hourglass 07 Up to 7' Door 119 to Match 335 Black Anodized

1 Teardrop 08 Up to 8' Door 121 to Match 313 Dark Bronze Anodized

2 Flush Operator 09 Up to 9' Door 130 to Match 628 Clear Anodized

10 Up to 10' Door

FLUSHLOCKS

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

4189, 4190 Flush Locksets (Including Deadlock)

MODELS & FINISHES STANDARD

LOCK FACE

STAINLESS STEEL

LOCK FACE

4189-IB Flush lockset, 119, 121, or 130 ﬁnish, individually boxed $100 $110

4190-IB Flush lockset, 119, 121, or 130 ﬁnish, individually boxed with cylinder $131 $141

4195-IB Dummy ﬂushset, 119, 121, or 130 ﬁnish, individually boxed $69 $79

SPECIAL MODEL

4189-00 Flush operator without lock $79

4190-00 Flush operator without lock $110

KITTED OPTIONS

MODELS GRAY

4413-01, 4413-02 Grip pull for use with 4189, 4190 $24

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT

NO.

LOCKSET

EXTERIOR LOCK FACE STILE

THICKNESS FINISH KEYING OPTIONS* PACKAGING

41 90 -09 -1 -130 -01 IB

89 Without Cylinder 00 Without Lock 1 1" to 1-3/8" 119 To match 335

Black Anodized 00 Without Cylinder IB Individually Boxed

90 With Cylinder 09 Radius 2 1-7/16" to 1-5/8" 121 To match 313

Dark Bronze Anodized 01 Keyed Dierent

95 Dummy

09S Radius

Stainless

Steel

3 1-11/16" to 2" 130 To match 628

Clear Anodized 02 Keyed alike in pairs

10 Square

10S Square

Stainless

Steel

*Keyed alike 50 are availiable by special order in quantity of 50 locksets only. Please contact factory for ordering information.

FLUSHLOCKS

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

4430, 4431 Flush Locksets (Including Deadlock)

MODELS & FINISH STANDARD

LOCK FACE

STAINLESS STEEL

LOCK FACE

4430-IB ABS ﬂush lockset, individually boxed $69 $79

4431-IB ABS ﬂush lockset with cylinder, individually boxed $105 $115

4432-IB ABS dummy ﬂushset, individually boxed $34 $44

SPECIAL MODEL

4430-00 ABS operator without lock $49

4431-00 ABS operator without lock $85

KITTED OPTIONS

MODELS & FINISHES 335

4453-02-335-IB Grip pull for use with 4430, 4431 $37

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. LOCKSET EXTERIOR LOCK FACE STILE THICKNESS KEYING OPTIONS* PACKAGING

44 31 -09 -05 -01 -IB

30 Without Cylinder 00 Without Lock 00 1" to 1-5/16" 00 Without Cylinder IB Individually Boxed

31 With Cylinder 09 Radius 05 1-3/8" to 1-5/8" 01 Keyed Dierent

32 Dummy 09S Radius Stainless Steel 08 1-3/4" to 2" 02 Keyed alike in pairs

10 Square

10S Square Stainless Steel

*Keyed alike 50 are availiable by special order in quantity of 50 locksets only. Please contact factory for ordering information.

EXIT DEVICES

Alarm option cannot be combined with any other Device Option or Monitoring Option. Split ﬁnishes (faceplate/pushbar) are not

available. Matching end cap option available for US ﬁnishes only. Please contact factory for speciﬁc ordering questions.

8099 Dummy Pushbar

MODELS & FINISHES 313, 335, 628 US4, US32D US3, US32

8099-00 Dummy pushbar without mechanism, for doors NOT requiring an exit device. $245 $517 $580

8099-M0 Active dummy bar without latching mechanism, without monitoring switches. $320 — —

8099-M1 Active dummy bar with monitoring switch but without latching mechanism. May

be wired normally open or normally closed to operate maglock, alarm or similar. $378 $650 $713

8099-M2 Active dummy bar with two monitoring switches but without

latching mechanism. May be wired normally open or normally

closed to operate maglock, alarm or similar.

$442 $714 $777

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. MONITOR DOOR TYPE PUSHBAR FINISH WIDTH US FINISH

8099 -M1 -3 0 36 -US32

00 Inactive Dummy Bar 3 Aluminum 0 US Finish 30 30 inches US3 Bright Brass

M0 Active Dummy Bar, no monitoring switches 4 Wood or hollow metal 1 Clear Anodized 628 36 36 inches US4 Satin Brass

M1 Active Dummy Bar, one monitoring switch 2 Dark Bronze Anodized 313 42 42 inches US32 Bright Stainless

M2 Active Dummy Bar, two monitoring switches 3 Black Anodized 335 48 48 inches US32D Satin Stainless

FLUSHLOCKS | EXIT DEVICES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

Option Pricing on pages 25 &26

3100, 8100 Surface Vertical Rod Exit Device

MODELS & FINISHES 313, 335, 628 US4, US32D US3, US32

8100 Surface vertical rod exit device for wood and hollow metal $969 $1,289 $1,459

8100T Top rod only (less bottom rod) SVR exit device $889 $1,209 $1,379

3100 Fire-rated surface vertical rod exit device for wood and hollow metal $1,235 $1,555 $1,725

3100T Fire-rated top rod only (less bottom rod) for metal doors $1,156 $1,476 $1,646

3100W Fire-rated top rod only (less bottom rod) for wood doors $1,156 $1,476 $1,646

KITTED OPTIONS

MODELS & FINISHES 313, 335, 628 US4, US32D US3, US32

3055 Tall door kit for doors up to 10' tall, for use with 3100 $134 $170 $201

HOW TO ORDER Specify quantity and the following information. Order related products separately.

MODEL PUSHBAR FINISH ROD TYPE DEVICE OPTIONS MONITORING

OPTION

DOOR OPENING WIDTH

On pair of doors, specify HALF

of the total exit opening

US FINISH

END CAPS

OPTION

FOR US FINISH

81 00 - SE M2 -30 -US32D MEC

31 Fire-Rated 00 US Finish T Top Rod only LR Electric Latch

Retraction (solenoid) M Single Switch 30 30 inches US3 Bright Brass MEC Matching

End Caps

81 Life-Safety 11 Clear Anodized 628 W Top Rod only -

Wood doors

SE Motorized Latch

Retraction M2 Dual Switch 36 36 inches US4 Satin Brass

22 Dark Bronze

Anodized 313 – Standard rod C Cylinder Dogging (non-ﬁre

rated devices ONLY)

(BLANK)

No Monitor 42 42 inches US32 Bright Stainless

33 Black Anodized 335 ED Electric Dogging 48 48 inches US32D Satin Stainless

(BLANK) No Option AXXB Alarmed Exit Device where XX

is door opening width

* Please note that 30" exit devices cannot accommodate monitoring options, except when ordered in conjunction with the SE option.

8200 Narrow Stile Surface Vertical Rod Exit Device

MODELS & FINISHES 313, 335, 628 US4, US32D US3, US32

8200 Narrow stile surface vertical rod exit device $911 $1,230 $1,401

8200T Top rod only (less bottom rod) SVR exit device $831 $1,150 $1,321

SPECIAL MODELS 313, 335, 628 US4, US32D US3, US32

8200-99 SVR exit device, less rods $803 $1,117 $1284

KITTED OPTIONS

MODELS & FINISHES 313, 335, 628 US4, US32D US3, US32

8055-01 Tall door kit for doors up to 10' tall, for use with 8100, 8200 $124 $160 $191

HOW TO ORDER Specify quantity and the following information. Order related products separately.

MODEL PUSHBAR FINISH ROD TYPE DEVICE OPTIONS MONITORING

OPTION

DOOR OPENING WIDTH

On pair of doors, specify HALF

of the total exit opening

US FINISH END CAPS OPTION

FOR US FINISH

82 00 - ED M2 -36 -US3

82 Life-Safety 00 US Finish T Top Rod only LR Electric Latch

Retraction (solenoid) M Single Switch 30 30 inches US3 Bright Brass MEC Matching

End Caps

11 Clear Anodized 628 – Standard rod SE Motorized Latch Retraction M2 Dual Switch 36 36 inches US4 Satin Brass

22 Dark Bronze

Anodized 313 C Cylinder Dogging (BLANK)

No Option 42 42 inches US32 Bright Stainless

33 Black Anodized 335 ED Electric Dogging 48 48 inches US32D Satin Stainless

(BLANK) No Option AXXB Alarmed Exit Device where XX

is door opening width

EXIT DEVICES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

Option Pricing on pages 25 &26

3300, 8300 Mortise Exit Device

MODELS & FINISHES 313, 335, 628 US4, US32D US3, US32

8300 Mortise exit device for wood and hollow metal $751 $1,070 $1,177

3300 Fire-rated mortise exit device for wood and hollow metal $1,070 $1,389 $1,496

KITTED OPTIONS

MODELS & FINISH US32D

4009-01 Open back strike for 1-3/4" thick doors $139

For complete list of kitted options for mortise exit devices, please refer to 8400 Narrow Stile Mortise Exit Devices on next page.

HOW TO ORDER Specify quantity and the following information. Order related products separately.

MODEL FACEPLATE

FINISH

FACE

SHAPE DEVICE OPTIONS MONITORING

OPTION

DOOR

HANDING

PUSHBAR

FINISH

DOOR OPENING WIDTH

On pair of doors, specify

HALF of the total exit opening

US FINISH

END CAPS

OPTION FOR

US FINISH

83 3 0 ED M -7 3 A36B

33 Fire-Rated 0 US Finish

0 Flat

(3300

only)

LR Electric Latch

Retraction

(solenoid)

M Single Switch 7 RHR 0 US Finish 30 30 inches US3 Bright Brass MEC Matching

End Caps

83 Life-Safety

1 Clear

Anodized

628

2 Bevel

(8300

only)

SE Motorized Latch

Retraction M2 Dual Switch 8 LHR 1 Clear

Anodized 628 36 36 inches US4 Satin Brass

2 Dark Bronze

Anodized

313

C Cylinder Dogging

(non-ﬁre rated

devices ONLY)

(BLANK)

No Monitor

2 Dark Bronze

Anodized 313 42 42 inches US32 Bright

Stainless

3 Black

Anodized

335

ED Electric Dogging

3 Black

Anodized

335

48 48 inches US32D Satin

Stainless

- Without Options AXXB Alarmed Exit Device where

XX is door opening width

*Please note that 30" exit devices cannot accommodate monitoring options, except when ordered in conjunction with the SE option.

EXIT DEVICES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

Option Pricing on pages 25 &26

8400 Narrow Stile Mortise Exit Device

MODEL & FINISHES 313, 335, 628 US4, US32D US3, US32

8400 Narrow stile mortise exit device $671 $990 $1,097

Please contact factory for information on the 8475 Midpanel Mortise Exit Device. Pricing is standard pricing plus unique door cutting charge for custom cut length.

KITTED OPTIONS

MODELS US32D

8455-01 Long face strike for covering MS strike prep $101

8460-17-630 Long lip strike for jambs that project outward 2-1/4" beyond the centerline of door $77

91-0995-02-IP 2" thick door kit for use with 8300, 8400 $18

91-0995-03-IP 2-1/4" thick door kit for use with 8300, 8400 $18

91-0995-04-IP 2-1/2" thick door kit for use with 8300, 8400 $21

91-0995-05-IP 2-3/4" thick door kit for use with 8300, 8400 $26

91-0995-06-IP 3" thick door kit for use with 8300, 8400 $26

91-0325-01 Thermal door kit, 1/4" cladding, for use with 8400 $82

91-0325-02 Thermal door kit, 1/2" cladding, for use with 8400 $149

HOW TO ORDER Specify quantity and the following information. Order related products separately.

MODEL FACEPLATE

FINISH FACE SHAPE DEVICE OPTIONS MONITORING

OPTION BACKSET DOOR

HANDING

PUSHBAR

FINISH

DOOR OPENING WIDTH

On pair of doors, specify

HALF of the total exit

opening

US FINISH

END CAPS

OPTION FOR

US FINISH

84 1 4 SE M2 -4 7 1 42

84 Life-

Safety 0 US Finish 0 Flat, Radius,

Bevel

LR Electric Latch

Retraction

(solenoid)

M Switch 2 31/32" 7 RHR 0 US Finish 30 30 inches US3 Bright Brass

MEC

Matching

End Caps

1 Clear

Anodized

628

4 Radius w/

Weatherstrip*

SE Motorized

Latch

Retraction

M2 Dual

Switch 3 1-1/8" 8 LHR

1 Clear

Anodized

628

36 36 inches US4 Satin Brass

2 Dark

Bronze

Anodized

313

C Cylinder

Dogging

(BLANK)

No Monitor 4 1-1/2"

2 Dark

Bronze

Anodized

313

42 42 inches US32 Bright

Stainless

3 Black

Anodized

335

ED Electric

Dogging

3 Black

Anodized

335

48 48 inches US32D Satin

Stainless

– Without Options AXXB Alarmed Exit Device where

XX is door opening width

*Radius with weatherstrip faceplate is not available in US ﬁnishes.

EXIT DEVICES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

Option Pricing on pages 25 &26

3600, 8500 Metal Door Concealed Vertical Rod Exit Device

MODELS & FINISHES 313, 335, 628 US4, US32D US3, US32

8500 Concealed vertical rod exit device for hollow metal $708 $1,028 $1,134

8500T Top rod only (less bottom rod) CVR exit device $628 $948 $1,054

3600 Fire-rated concealed vertical rod exit device for hollow metal $1,156 $1,476 $1,582

3600T Fire-rated top rod only (less bottom rod) CVR exit device $1,076 $1,396 $1,502

KITTED OPTIONS

MODEL

3655 Tall door kit for doors taller than 66" above bar height, up to 10' $60

HOW TO ORDER Specify quantity and the following information. Order related products separately.

MODEL PUSHBAR FINISH ROD TYPE DEVICE OPTIONS MONITORING

OPTION

DOOR OPENING WIDTH

On pair of doors, specify

HALF of the total exit opening

US FINISH

END CAPS

OPTION FOR US

FINISH

85 00 T ED M -36 -US32D

36 Fire-Rated 00 US Finish T Top Rod only LR Electric Latch

Retraction (solenoid) M Single Switch 30 30 inches US3 Bright Brass MEC Matching

End Caps

85 Life-Safety 11 Clear Anodized 628 – Standard rod SE Motorized Latch

Retraction M2 Dual Switch 36 36 inches US4 Satin Brass

22 Dark Bronze

Anodized 313

C Cylinder Dogging

(non-ﬁre rated

devices only)

(BLANK)

No Monitor 42 42 inches US32 Bright Stainless

33 Black Anodized 335 ED Electric Dogging 48 48 inches US32D Satin Stainless

(BLANK) No Option AXXB Alarmed Exit Device where

XX is door opening width

*Please note that 30" exit devices cannot accommodate monitoring options, except when ordered in conjunction with the SE option.

8600 Narrow Stile Concealed Vertical Rod Exit Device

MODELS & FINISHES 313, 335, 628 US4, US32D US3, US32

8600 Narrow stile concealed vertical rod exit device $660 $980 $1,086

8600T Top rod only (less bottom rod) CVR exit device $580 $900 $1006

SPECIAL MODELS 313, 335, 628 US4, US32D US3, US32

8600-99 CVR exit device, less rods $570 $890 $996

Please contact factory for information on the 8675 Midpanel CVR Exit Device. Pricing is standard pricing plus unique door cutting charge for custom cut length.

KITTED OPTIONS

MODEL

8655 Tall door kit for doors up to 10’ for use with 8500, 8600 $57

HOW TO ORDER Specify quantity and the following information. Order related products separately.

MODEL PUSHBAR FINISH ROD TYPE DEVICE OPTIONS MONITORING

OPTION

DOOR OPENING WIDTH

On pair of doors, specify

HALF of the total exit opening

US FINISH

END CAPS

OPTION FOR US

FINISH

86 22 T SE M2 -36

86 Life-Safety 00 US Finish T Top Rod only LR Electric Latch Retraction

(solenoid) M Single Switch 30 30 inches US3 Bright Brass MEC Matching

End Caps

11 Clear Anodized 628 – Standard rod SE Motorized Latch Retraction M2 Dual Switch 36 36 inches US4 Satin Brass

22 Dark Bronze

Anodized 313 C Cylinder Dogging (BLANK)

No Monitor 42 42 inches US32 Bright Stainless

33 Black Anodized 335 ED Electric Dogging 48 48 inches US32D Satin Stainless

(BLANK) No Option AXXB Alarmed Exit Device where

XX is door opening width

EXIT DEVICES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

Option Pricing on pages 25 &26

3700, 8700 Rim Exit Device

MODELS & FINISHES 313, 335, 628 US4, US32D US3, US32

8700 Rim exit device for wood and hollow metal $485 $783 $868

3700 Fire-rated rim exit device for wood and hollow metal $804 $1,102 $1,187

KITTED OPTIONS

MODELS N/A

3889-08 Mullion for doors up to 8' for use with 8700, 3700 $541

HOW TO ORDER Specify quantity and the following information. Order related products separately.

MODEL PUSHBAR FINISH DEVICE OPTIONS MONITORING

OPTION

DOOR OPENING WIDTH

On pair of doors, specify

HALF of the total exit opening

US FINISH

END CAPS

OPTION FOR US

FINISH

VOLTAGE

(For EL Option

Only)

37 00 EL M1 -36 -US3 MEC -12

37 Fire-Rated 00 US Finish LR Electric Latch Retraction

(solenoid) (indicate 12V/24V) M Single Switch 30 30 inches US3 Bright Brass MEC Matching

End Caps 12 Volts

87 Life-Safety 01 Clear Anodized 628 SE Motorized Latch Retraction M2 Dual Switch 36 36 inches US4 Satin Brass 24 Volts

02 Dark Bronze

Anodized 313 C Cylinder Dogging (BLANK)

No Monitor 42 42 inches US32 Bright Stainless

03 Black Anodized 335 ED Electric Dogging 48 48 inches US32D Satin Stainless

– Without Options AXXB Alarmed Exit Device where

XX is door opening width

*Please note that 30" exit devices cannot accommodate monitoring options, except when ordered in conjunction with the SE option.

8800 Narrow Stile Rim Exit Device

MODEL & FINISHES 313, 335, 628 US4, US32D US3, US32

8800 Narrow stile rim exit device $463 $761 $847

KITTED OPTIONS

MODELS 313, 628

3890-08 Aluminum mullion for doors up to 8' for use with 8800 $592

3890-10 Aluminum mullion for doors up to 10' for use with 8800 $618

HOW TO ORDER Specify quantity and the following information. Order related products separately.

MODEL PUSHBAR FINISH DEVICE OPTIONS MONITORING

OPTION

DOOR OPENING WIDTH

On pair of doors, specify HALF

of the total exit opening

US FINISH

END CAPS

OPTION FOR US

FINISH

VOLTAGE

(For EL Option

Only)

88 01 C M2 -36 -12

88 Life-Safety 00 US Finish

LR Electric Latch

Retraction (solenoid)

(indicate 12V/24V)

M Single Switch 30 30 inches US3 Bright Brass MEC Matching

End Caps 12 Volts

01 Clear Anodized 628 SE Motorized Latch

Retraction M2 Dual Switch 36 36 inches US4 Sat in Brass 24 Volts

02 Dark Bronze Anodized 313 C Cylinder Dogging (BLANK)

No Monitor 42 42 inches US32 Bright

Stainless

03 Black Anodized 335 ED Electric Dogging 48 48 inches US32D Satin

Stainless

– Without Options AXXB Alarmed Exit Device

where XX is door

opening width

EXIT DEVICES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

Option Pricing on pages 25 &26

3900, 8900 Wood Door Surface Concealed Vertical Rod Exit Device

MODELS & FINISHES 313, 335, 628 US4, US32D US3, US32

8900 Surface concealed vertical rod exit device for wood $783 $1,102 $1,209

3900 Fire-rated surface concealed vertical rod for wood $1,230 $1,549 $1,656

KITTED OPTIONS

MODEL PRICE

8955-01 Tall door kit for doors up to 10’ for use with 8900 $57

3955-01 Tall door kit for doors up to 10’ for use with 3900 $57

HOW TO ORDER Specify quantity and the following information. Order related products separately.

MODEL PUSHBAR FINISH DEVICE OPTIONS MONITORING

OPTION

DOOR OPENING WIDTH

On pair of doors, specify HALF

of the total exit opening

US FINISH END CAPS OPTION FOR

US FINISH

89 00 LR M2 -36 -US32

39 Fire-Rated 00 US Finish LR Electric Latch

Retraction (solenoid) M Single Switch 30 30 inches US3 Bright Brass MEC Matching End Caps

89 Life-Safety 11 Clear Anodized 628 SE Motorized Latch Retraction M2 Dual Switch 36 36 inches US4 Satin Brass

22 Dark Bronze Anodized 313 C Cylinder Dogging

(non-ﬁre rated devices only) (BLANK) No Monitor 42 42 inches US32 Bright Stainless

33 Black Anodized 335 ED Electric Dogging 48 48 inches US32D Satin Stainless

(BLANK) No Option AXXB Alarmed Exit Device where XX is door opening width

*Please note that 30" exit devices cannot accommodate monitoring options, except when ordered in conjunction with the SE option.

Accessories for 3000/8000 Series Exit Devices

OPTIONS & FINISHES N/A US4, US32D US3, US32

ALARM Battery-operated alarmed exit device. Alarm option cannot be combined with any other device option or monitoring options. $479

C Cylinder dogging $52

ED Electric dogging $422

EL Electric latch retraction (solenoid) for use with 3700, 8700, 8800 rim exit devices only $366

ELD Electric latch retraction (solenoid) with mechanical dogging for rim exit devices only $417

LR Electric latch retraction (solenoid) for use with CVR, Mortise and SVR exit devices. $623

MEC Matching end caps. For US ﬁnishes only, not applicable to anodized ﬁnishes $82 $108

M1 Monitor/single signal switch $129

M2 Monitor/dual signal switch $191

SE Motorized latch retraction $670

KITTED options for 3000/8000 Series Exit Devices

MODELS & FINISHES N/A 313, 335, 628 US4, US32D US3, US32 119, 121, 652

ALARM EXIT KIT Kit for retroﬁtting an alarm function to an existing Adams Rite exit

device Includes new pushbar, end caps and installation hardware $608 $839 $901

91-0897-01 Single signal switch kit, retroﬁts to 3000/8000 $115

91-0897-02 Dual signal switch kit, retroﬁts to 3000/8000 $176

26-0584-XXX-MP Sex bolts, 2 per bag, 2 kits required per exit device $27

EXIT DEVICES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

MODIFICATION OPTIONS for 3000/8000 Series exit devices Please contact factory for all product modiﬁcations.

MODELS ADD

THICK DOOR For doors thicker than 1-3/4" and/or door skins plus reinforcement thicker than those speciﬁed in the Adams

Rite Master Reinforcement Sheet template, for CVR and Mortise Exit Devices $67

UNIQUE DOOR Cutting charges for non-standard custom cut lengths between 30" and 48" $88

Please note that thick door modiﬁcation options are available for 8300, 8400, and 8600 series exit devices only.

NEW EX SERIES EXIT DEVICES

EX88 Interlocking Rim Exit Device

MODEL & FINISHES 313, 335, 628

EX88 Interlocking rim exit device for aluminum, hollow metal or wood applications. $500

EX89 Pullman Rim Exit Device

MODEL & FINISHES 313, 335, 628

EX89 Pullman rim exit device for aluminum, hollow metal or wood applications. $500

EX76 Concealed Vertical Rod Exit Device

MODEL & FINISHES 313, 335, 628

EX76 CVR exit device for aluminum and hollow metal applications $713

EX80 Dummy Push Bar

MODEL & FINISHES 313, 335, 628

EX80 Dummy push bar for aluminum, hollow metal or wood applications. Includes two

monitoring switches. Field selectable for active or inactive conﬁguration $477

EX Series

OPTIONS ADD

MONITOR Dual Signal Switch $195

Alarm coming soon 2019

HOW TO ORDER Specify quantity and the following information. Order related products separately.

MODEL LENGTH FINISHES DEVICE OPTIONS*

EX89 -R 628

EX88 Interlocking Rim Exit Device R Regular (36") 313 Dark Bronze Anodized A Alarmed (coming soon)

EX89 Pullman Rim Exit Device) M Mid-Length (42") 335 Black Anodized M Monitoring

EX76 CVR Exit Device L Long (48") 628 Clear Anodized (BLANK) standard, no options

EX80 Dummy Push Bar

*Device options not applicable to Dummy Push Bar. Dummy Push Bar comes standard with dual monitoring switches.

EXIT DEVICES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

ELECTRIC STRIKES

7100, 7101 Electric Strikes

MODELS & FINISHES 313, 335, 628 626

7100 For aluminum jambs $189 $214

7101 For radius aluminum stiles $189

7100-XX7, 7100-XX9 Monitoring signal switches $291 $316

Lip Extensions up to 3" for center-hung or non-ﬂush doors add $35.

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT

NO.

FACEPLATE

SHAPE VOLTAGE CURRENT

AND DUTY FEATURES* FINISH** LIP EXTENSIONS DIM. A***

(Door Centerline to Jamb Edge)

710 0 -3 1 0 -628 -00

0 Flat 3 12 Volt 1 DC Continuous

or Intermittent 0 Standard/Fail-Secure 313 Dark Bronze Anodized 00 1-1/16" or less 05 2"

1 Radius 4 16 Volt 4 AC Intermittent 5 Fail-Safe 335 Black Anodized 01 1-1/2" 07 2-1/4"

5 24 Volt 7 Monitored/ Fail-Safe 626 Satin Chrome 02 1-5/8" 09 2-1/2"

9 Monitored/ Fail-Secure 628 Clear Anodized 03 1-3/4" 12 2-7/8"

*Fail-secure can be converted to fail-safe and vice versa. **7101 available in 313, 335, 628 only. ***Lip extensions not available on 7101.

7110, 7111 Electric Strikes

MODELS & FINISHES 652

7110 For wood jambs $223

7111 For wood jambs, long faceplate $223

7110-XX7, 7110-XX9 Monitoring signal switches $325

Lip Extensions up to 3" for center-hung or non-ﬂush doors add $35.

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT

NO.

FACEPLATE

LENGTH VOLTAGE CURRENT

AND DUTY FEATURES* FINISH LIP EXTENSIONS DIM. A

(Door Centerline to Jamb Edge)

711 0 -3 1 0 -652 -00

0 7-15/16" 3 12 Volt 1 DC Continuous

or Intermittent 0 Standard/Fail-Secure 652 Satin Chrome 00 1-1/16" or less 05 2"

1 10-1/4" 4 16 Volt 4 AC Intermittent 5 Fail-Safe 01 1-1/2" 07 2-1/4"

5 24 Volt 7 Monitored/ Fail-Safe 02 1-5/8" 09 2-1/2"

9 Monitored/ Fail-Secure 03 1-3/4" 12 2-7/8"

*Fail-secure can be ﬁeld converted to fail-safe or vice-versa.

7130, 7131 Electric Strikes

MODELS & FINISHES 313, 335, 628

7130 For aluminum jambs, pre-cut for MS lock strike plate $193

7131 For radius aluminum stiles, pre-cut for MS lock strike plate $193

Lip Extensions up to 3" for center-hung or non-ﬂush doors add $35.

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT

NO.

FACEPLATE

SHAPE VOLTAGE CURRENT

AND DUTY FEATURES* FINISH LIP EXTENSIONS DIM. A**

(Door Centerline to Jamb Edge)

713 0 -3 1 0 -313 -00

0 Flat 3 12 Volt 1 DC Continuous

or Intermittent

0 Standard/

Fail-Secure

313 Dark Bronze

Anodized 00 1-1/16" or less 05 2"

1 Radius 4 16 Volt 4 AC Intermittent 5 Fail-Safe 335 Black Anodized 01 1-1/2" 07 2-1/4"

5 24 Volt 7 Monitored/ Fail-Safe 628 Clear Anodized 02 1-5/8" 09 2-1/2"

9 Monitored/ Fail-Secure 03 1-3/4" 12 2-7/8"

*Fail-secure can be ﬁeld converted to fail-safe or vice-versa. **Lip extensions not available on 7131.

ELECTRIC STRIKES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

7140 Electric Strike

STANDARD

OUNTING

ANSI PREP

3/32

2.4mm

MODEL & FINISHES 313, 335, 628 626

7140 ANSI size for hollow metal and wood jambs $189 $214

7140-XX7, 7140-XX9 Monitoring signal switch $291 $316

Lip Extensions up to 3" for center-hung or non-ﬂush doors add $35.

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT

NO. VOLTAGE CURRENT AND DUTY FEATURES* FINISH LIP EXTENSIONS DIM. A

(Door Centerline to Jamb Edge)

7140 -3 1 0 -628 -00

3 12 Volt 1 DC Continuous or Intermittent 0 Standard/ Fail-Secure 313 Dark Bronze Anodized 00 1-1/16" or less 05 2"

4 16 Volt 4 AC Intermittent 5 Fail-Safe 335 Black Anodized 50 1-3/8" 07 2-1/4"

5 24 Volt 7 Monitor/Fail-Safe 626 Satin Chrome 01 1-1/2" 09 2-1/2"

9 Monitor/Fail-Secure 628 Clear Anodized 02 1-5/8" 12 2-7/8"

03 1-3/4"

*Fail-secure can be ﬁeld converted to fail-safe or vice-versa.

7160 Electric Strike

MODELS & FINISHES 313, 335, 628 626

7160 For aluminum jambs $237 $262

7160-XX7, 7160-XX9 Monitoring signal switches $339 $364

Lip Extensions up to 3" for center-hung or non-ﬂush doors add $35.

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT

NO. VOLTAGE CURRENT AND DUTY FEATURES* FINISH LIP EXTENSIONS DIM. A

(Door Centerline to Jamb Edge)

7160 -3 1 0 -628 -00

3 12 Volt 1 DC Continuous

or Intermittent

0 Standard/

Fail-Secure 313 Dark Bronze Anodized 00 1-1/16" or less 05 2"

4 16 Volt 4 AC Intermittent 5 Fail-Safe 335 Black Anodized 01 1-1/2" 07 2-1/4"

5 24 Volt 7 Monitor/Fail-Safe 626 Satin Chrome 02 1-5/8" 09 2-1/2"

9 Monitor/Fail-Secure 628 Clear Anodized 03 1-3/4" 12 2-7/8"

*Fail-secure can be ﬁeld converted to fail-safe or vice-versa.

7170 Electric Strike

S STANDARD

OUNTING

ANSI PREP

2.4mm

MODELS & FINISHES 313, 335, 628 626

7170 For hollow metal and wood jambs $237 $262

7170-XX7, 7170-XX9 Monitoring signal switches $339 $364

Lip Extensions up to 3" for center-hung or non-ﬂush doors add $35.

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT

NO. VOLTAGE CURRENT AND DUTY FEATURES* FINISH LIP EXTENSIONS DIM. A

Door Centerline to Jamb Edge

7170 -3 1 0 -628 -00

3 12 Volt 1 DC Continuous or Intermittent 0 Standard/Fail-Secure 313 Dark Bronze Anodized 00 1-1/16" or less 05 2"

4 16 Volt 4 AC Intermittent 5 Fail-Safe 335 Black Anodized 50 1-3/8" 07 2-1/4"

5 24 Volt 7 Monitor/Fail-Safe 626 Satin Chrome 01 1-1/2" 09 2-1/2"

9 Monitor/Fail-Secure 628 Clear Anodized 02 1-5/8" 12 2-7/8"

03 1-3/4"

*Fail-secure can be ﬁeld converted to fail-safe or vice-versa.

ELECTRIC STRIKES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

Modular Packaging Program – Match strike body with faceplate kit for complete electric strike.

7100 Series Electric Strike Components

STRIKE BODY KITS PRICE

7103A For use with 7100/7101, 7110/7111, 7130/7131, 7140 $157

7173A For use with 7160, 7170 $203

One strike body kit matched with one faceplate kit makes a complete electric strike assembly.

FACEPLATE KITS & FINISHES 313,335, 628 626 605

FPK00 For use with body kits: 7103A, 7173A $31 $56 $62

FPK01 For use with body kit: 7103A $31

FACEPLATE KITS & FINISHES 652 632

FPK10 For use with body kit: 7103A $66 $92

FPK11 For use with body kits: 7103A $66 $92

FACEPLATE KITS & FINISHES 313,335, 628 626 605

FPK30 For use with body kit: 7103A $36

FPK31 For use with body kits: 7103A $36

FPK40 For use with body kit: 7103A, 7173A $31 $56 $62

FPK45 For use with body kit: 7103A, for installing electric strike in previous prep, 4901, 4501 strike cover. $36

Faceplate kits contain all hardware to mount electric strike.

KITTED OPTIONS

91-0171-01-IP THROUGH -13-IP Lip extension kits for use with 7100 through 7140 $35

91-0171-50-IP Lip extension kits for use with 7100 through 7140 interior framing systems $35

91-0172-01-IP THROUGH -13-IP Lip extension kits for use with 7160 and 7170 $35

91-0172-50-IP Lip extension kits for use with 7160 and 7170 interior framing systems $35

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. VOLTAGE CURRENT AND DUTY FEATURES*

7103A 3 1 0

7103A 3 12 Volt 1 DC Continuous or Intermittent 0 Standard/Fail-Secure

7173A 4 16 Volt 4 AC Intermittent 5 Fail-Safe

5 24 Volt

*Fail-secure can be ﬁeld converted to fail-safe or vice-versa.

ELECTRIC STRIKES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

7240 Series Fire-Rated Electric Strikes

MODELS & FINISH 630

7240 Fire-rated, for cylindrical latches $357

7240-50 Lip extension for interior frame systems $392

7240-XX9 Monitoring signal switches $459

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT

NO. VOLTAGE CURRENT AND DUTY FEATURES* FINISH

LIP EXTENSIONS (DIM. A)

Door Centerline to Jam Edge for

Interior Frames

7240 -3 1 0 -630 -50

3 12 Volt 1 DC Continuous

or Intermittent 0 Fail-Secure 630 Satin Stainless 00 1-1/16" or less

5 24 Volt 4 AC Intermittent 9 Monitor/Fail-Secure 50 1-3/8"

*Not available fail-safe.

7270 Series Fire-Rated Electric Strikes

MODELS & FINISH 630

7270 Fire-rated, for mortise latches $414

7270-50 Lip extension for interior frame systems $454

7270-XX9 Monitoring signal switches $516

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT

NO. VOLTAGE CURRENT AND DUTY FEATURES* FINISH

LIP EXTENSIONS (DIM. A)

Door Centerline to Jam Edge for

Interior Frames

7270 -3 1 0 -630 -50

3 12 Volt 1 DC Continuous

or Intermittent 0 Fail-Secure 630 Satin Stainless 00 1-1/16" or less

5 24 Volt 4 AC Intermittent 9 Monitor/Fail-Secure 50 1-3/8"

*Not available fail-safe.

7400, 7401 Ultraline® Electric Strikes

MODELS & FINISHES 313, 335, 628 630 605, 606, 629 119, 121, 130

7400 For radius jambs $259 $286 $296

7400M Monitoring signal switches $361 $388 $398

7401 For radius aluminum stiles $259

7401M Monitoring signal switches $361

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT

NO.

FACEPLATE

SHAPE FEATURES FINISH

740 0 M 628

0 Flat - None 7400 ONLY 7401 ONLY

1 Radius M Monitored 313 Dark Bronze Anodized 628 Clear Anodized 119 To match 335 Black Anodized

A Modular Pack - Body Kit 335 Black Anodized 629 Bright Stainless 121 To match 313 Dark Bronze Anodized

605 Bright Brass 630 Satin Stainless 130 To match 628 Clear Anodized

606 Satin Brass

Fail-secure can be ﬁeld converted to fail-safe or vice-versa.

ELECTRIC STRIKES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

7410, 7411 Ultraline® Electric Strikes

MODELS & FINISHES 313, 335, 628 630

7410 For wood jambs, 7-15/16" faceplate $291 $317

7410M Monitoring signal switches $393 $419

7411 For wood jambs, 10-1/4" faceplate, not available in 335 Finish $291 $317

7411M Monitoring signal switches $419

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. FACEPLATE LENGTH FEATURES FINISH

741 0 - 628

0 7-15/16" - None 313 Dark Bronze Anodized 628 Clear Anodized

1 10-1/4" M Monitored 335 Black Anodized 630 Satin Stainless

Fail-secure can be ﬁeld converted to fail-safe or vice-versa.

7430, 7431 Ultraline® Electric Strikes

MODELS & FINISHES 313, 335, 628 119, 121, 130

7430 For aluminum jambs, ﬂat faceplate $265

7430M Monitoring signal switches $367

7431 For aluminum stiles, radius faceplate $265

7431M Monitoring signal switches, not available in 119 ﬁnish. $367

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. FACEPLATE SHAPE FEATURES FINISH

743 0 M 628

0 Flat - None 313 Dark Bronze Anodized 119 To match 335 Black Anodized

1 Radius M Monitored 335 Black Anodized 121 To match 313 Dark Bronze Anodized

628 Clear Anodized 130 To match 628 Clear Anodized

Fail-secure can be ﬁeld converted to fail-safe or vice-versa.

7440 Ultraline® Electric Strikes

MODELS & FINISHES 313, 335, 628 630 605, 606, 629

7440 For steel and wood, jambs and doors $259 $286 $296

7440M Monitoring signal switches $361 $388 $398

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. FEATURES FINISH

7440 M 628

- None 313 Dark Bronze Anodized 606 Satin Brass 629 Bright Stainless

M Monitored 335 Black Anodized 628 Clear Anodized 630 Satin Stainless

605 Bright Brass

Fail-secure can be ﬁeld converted to fail-safe or vice-versa.

ELECTRIC STRIKES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

74R1 Ultraline® Electric Strikes

MODELS & FINISHES 119, 121, 130

74R1 For use with rim exit devices with 3/4" latchbolt $353

74R1M Monitoring signal switches $455

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. FEATURES FINISH

74R1 M -130

- None 119 To match 335 Black Anodized

M Monitored 121 To match 313 Dark Bronze Anodized

130 To match 628 Clear Anodized

Fail-secure can be ﬁeld converted to fail-safe or vice-versa.

74R2 Ultraline® Electric Strike

MODELS & FINISHES 119, 121, 130

74R2 For use with narrow stile rim exit devices with 1/2" latchbolt $353

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. FINISH

74R2 -130

119 To match 335 Black Anodized

121 To match 313 Dark Bronze Anodized

130 To match 628 Clear Anodized

Fail-secure can be ﬁeld converted to fail-safe or vice-versa.

ELECTRIC STRIKES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

Modular Packing Program - match strike body kit with faceplate kit for complete electric strike.

Select 7400A for standard jambs and 7401A for radius stile mounting. No ﬁnish designation required for strike body kits.

7400 Series Electric Strike Components

STRIKE BODY KITS

7400A Standard body, for use in single door applications $236

7401A Radius body, for use in applications with pairs of doors $236

Match one strike body kit with one faceplate kit to make a complete electric strike assembly.

FACEPLATE KITS & FINISHES 313, 335, 628 630 605, 606, 629 119, 121,130

FPK7400 For use with body kit: 7400A $26 $52 $62

FPK7401 For use with body kit: 7401A $26

FPK7410 For use with body kit: 7400A $57 $82

FPK7411 For use with body kit: 7400A, not available in 335 ﬁnish $62 $87

FPK7430 For use with body kit: 7400A $31

FPK7431 For use with body kit: 7401A $31

FPK7440 For use with body kit: 7400A $26 $52 $62

FPK7445 For use with body kit: 7400A, not available in 335 ﬁnish.

For installing electric strike in previous prep 4901, 4501, strike cover $36

Faceplate kits contain all hardware to mount electric strike.

KITTED OPTIONS

LEK7400 Lip extension kits for use with 7400 series electric strikes, for ﬂat faceplates only $45

VA7400-12 12 VDC adapter cable for 7400 electric strikes $12

VA7400-16VDC 16 VDC adapter kit for 7400 electric strikes $20

VA7400-24 24 VDC adapter cable for 7400 electric strikes $12

WDC7400 Wood door cover plate for use when mounting 7400 in the inactive leaf of a wood door pair (to simplify the mortising operation) $13

ELX ElectroLynx™ Adapter to connect Adams Rite products to the ElectroLynx system $32

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. LIP EXTENSIONS (distance from vertical centerline of the door in the closed position to the edge of the jamb)

LEK7400 -00

01 1-1/2" 03 1-3/4" 05 2" 07 2-1/4" 09 2-1/2" 11 2-3/4" 13 3"

02 1-5/8" 04 1-7/8" 06 2-1/8" 08 2-3/8" 10 2-5/8" 12 2-7/8" 50 1-3/8"

ELECTRIC STRIKES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

7800 Series Electric Strike

MODELS & FINISHES 630 613E, 628E, BSP 606 605,629

7800 For use with Starwheel and Interlocking rim exit devices. $595 $627 $668 $681

7800L Latchbolt Monitoring $705 $737 $778 $791

7800M Monitoring signal switches $715 $747 $788 $801

Accessories

MODELS & FINISHES 630, 613E, 628E, BSP

7800-116-XXX 1/16" Spacer plate $27

7800-108-XXX 1/8" Spacer plate $30

7800-SMB Surface Mounting Box $206

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. FEATURES* FINISH

7800 M 628

– None 605 Bright Brass

L Latchbolt Monitor 606 Satin Brass

M Monitored 613E Dark Oxidized Satin Bronze Powder

628E Satin Aluminum Clear Anodized

629 Bright Stainless

630 Satin Stainless

BSP Black Suede Powder

*Fail-secure can be ﬁeld converted to fail-safe or vice-versa.

ELECTRIC STRIKES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

TRIM

1000 Series Turns

MODELS & FINISHES 119, 121, 130

1000-01, 1000-02 Turn for use with MS1847 deadlock $28

1000-11, 1000-21 Stainless steel turn and escutcheon for use with MS1847 deadlock $33

1004 Turn for use with 5015, 5017 deadlock $33

1015 Turn for use with 5015, 5017 deadlock $33

1016 Outside escutcheon $28

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT

NO. TURN TYPE SPINDLE LENGTH FINISH

1000 -21 -14 -130

TURN WITHOUT ESCUTCHEON

Furnished Unassembled

DASH CHART

NO. "L" MM NO. "L" MM

-11 17/32 13 -22 1-15/64 31

-12 39/64 15 -23 1-19/64 33

-13 43/64 17 -24 1-23/64 35

-14 47/64 19 -25 1-27/64 36

-15 51/64 20 -26 1-31/64 38

-16 55/64 22 -27 1-33/64 39

-17 59/64 23 -28 1-39/64 41

-18 63/64 25 -29 1-43/64 42

-19 1-3/64 26 -30 1-47/64 44

-20 1-7/64 28 -31 1-51/64 46

-21 1-11/64 30 -32 1-55/64 47

119 To match 335 Black Anodized

-01

Parallel Drive

-02

Pendicular Drive 121 To match 313 Dark Bronze Anodized

TURN WITH ESCUTCHEON

Furnished Assembled 130 To match 628 Clear Anodized

-11

Parallel Drive

-21

Pendicular Drive

3000 Fixed Pull

MODELS & FINISH US32D

3001 Tubular ﬁxed pull for hollow metal or wood doors $203

3002 Flat ﬁxed pull for hollow metal or wood doors $221

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. HANDLE CYLINDER HOLE EXIT DEVICE FINISH

300 1 -1 1 -US32D

1 Round 1 Without Hole 1 Mortise, Rim US32D Satin Stainless

2 Flat 2 With Hole 2 CVR

3 SVR

Not for use with the following narrow stile exit devices: 8200 SVR, 8400 Mortise, 8600 CVR, 8800 Rim exit devices.

TRIM

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

3080 Series Entry Trim

STANDARD TRIM ELECTRIFIED TRIM

MODELS & FINISHES

US4,

US32D,

10B

US3,

US32

US4,

US32D,

10B

UUS3,

US32

STANDARD LEVER

3080 Entry trim with standard lever (01, 02, 03) $354 $390 $685 $721

3080-M Entry trim with standard lever (01, 02, 03) with matching trim cover ﬁnish $446 $482 $777 $813

3080-U Entry trim with standard lever (01, 02, 03) with universal trim kit includes

tailpieces and trimplates

for use with all Adams Rite exit devices

$379 $415 $710 $746

3080-U, M Entry trim with standard lever (01, 02, 03),

matching trim cover and universal trim kit $471 $507 $802 $838

DESIGNER LEVER

3080-MX Entry trim with designer lever series

(MD through MW) $400 $436 $731 $767

3080-MX, M Entry trim with designer lever series

(MD through MW) with matching trim cover $492 $528 $823 $859

3080-MX, U Entry trim with designer lever series

(MD through MW) with universal trim kit $425 $461 $757 $792

3080-MX, U, M Entry trim with designer lever series

(MD through MW), universal trim kit and matching trim cover $517 $553 $849 $884

Tactile strip now available as a Kitted Option (below) for standard levers 01 and 03.

KITTED OPTIONS PRICE

91-0686 Adaptor kit for 3080 trim and G86 exit device $30

91-0118 Tactile strip for 3080 standard levers 01, 03 $37

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT

NO. ELECTRIFIED HANDLE HANDING CYLINDER

HOLE EXIT DEVICE VOLTAGE FEATURES TRIM COVER

FINISH FINISH

3080 E -01 -0 -3 7 -3 0 M US32D

(BLANK)

Standard

STANDARD

HANDLES 0 No Handing 3 With Hole 1 SVR Electriﬁed

Trim Only

Electriﬁed

Trim Only

– Standard

(Black) US3 Bright Brass

E Electriﬁed Trim 01 Curve 7 Left Hand* 9 Without Hole 3 Mortise 3 12 Volt DC 0 Fail-Secure M Matching Finish US4 Satin Brass

02 Round 8 Right Hand* 4 SCVR 5 24 Volt DC 5 Fail-Safe 10B Dark Bronze

03 Square 6 CVR US32 Bright Stainless

DESIGNER SERIES 7 Rim US32D Satin Stainless

MD MJ U Universal

Kit

ME MN*

(Handed)

MG MV* (Handed)

MI MW

*Handing must be speciﬁed for MN and MV Designer Levers.

TRIM

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

3090 eForce® Keyless Entry FOR DEADLATCHES

& EXITS FOR DEADLOCKS

MODELS & FINISHES 626, 121 626, 121

3090-01, 3090-02 eForce keyless entry with keypad

3090-01 3090-02

$691 $711

KITTED OPTIONS

MODELS PRICE

RSK-3090 Remote switch input connector $16

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. COMPATIBLE PRODUCTS FINISH

3090 -01 -626

01 Adams Rite latches or 8000 Series Exit Devices, Yale 7200

series, Corbin Russwin ED4000 series exit devices only 121 To match 313 Dark Bronze Anodized

02 Adams Rite MS® deadlocks 626 Satin Chrome

NOTE: Adams Rite eForce 3090P & 3090C have been discontinued as of November 16, 2018. Customers can continue to order eForce 3090-150 and the A100-3090H (Aperio).

A100-3090H Keyless Entry and Aperio® Hub Pre-Paired Kit

FOR DEADLATCHES

& EXITS FOR DEADLOCKS

MODELS & FINISHES 121, 626 121, 626

A100-3090HC Keyless entry paired with hub, iCLASS reader $1,760 $1,780

A100-3090HP Keyless entry paired with hub, PROX reader $1,760 $1,780

Special pricing program discounts apply to Aperio products. Please contact your sales representative for pricing information.

KITTED OPTIONS

MODELS PRICE

DPS-C-38G A100 Door Position Switch $36

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. CREDENTIAL COMPATIBLE PRODUCTS FINISH

A100-3090H C -1 -626

P 125 kHz HID® Prox

1 Adams Rite latches or 8000 Series Exit Devices, Yale

7200 series, Corbin Russwin ED4000 series exit

devices only (select REX enabled version).

121 To match 313 Dark

Bronze Anodized

C 13.56 MHz HID iCLASS 2 Adams Rite MS® deadlocks 626 Satin Chrome

NOTE: The Adams Rite A100 narrow stile trim is available as either a pre-paired lock and hub kit (no certiﬁcation required) or as a ﬁeld conﬁgurable component (requires Aperio® Certiﬁed

Integrator certiﬁcation). Pre-paired kits support limited features, ﬁeld conﬁgured devices are required in order to support all options. Visit www.IntelligentOpenings.com to learn more.

TRIM

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

4060 Turn

MODEL & FINISH 130

4060 Turn for 1875 deadlock, 1-1/2", 1-3/4", or 2" door thickness $62

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. DOOR THICKNESS FINISH

4060 -05 -130

05 1-1/2" 130 To match 628 Clear Anodized

06 1-3/4"

07 2"

Please contact factory regarding mounting spacers, bolts, guides and strikes for particular door designs.

4550 MS® Deadlock Lever

MODEL & FINISHES 119, 121, 130

4550, 01 Deadlock lever, 1-3/4" to 2" door thickness $198

4550, 02 Deadlock lever, 2-1/8" to 2-3/8" door thickness $238

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. DOOR HAND DOOR THICKNESS FINISH

4550 R -01 -130

R RH or RHR 01 1-3/4" to 2" 119 To match 335 Black Anodized

L LH or LHR 02 2-1/8" to 2-3/8" 121 To match 313 Dark Bronze Anodized

130 To match 628 Clear Anodized

TRIM

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

4560, 4565 Series Deadlatch Handles for 4300, 4500, 4900 Deadlatches

MODELS & FINISHES 119, 121, 130

4560-X01 For door thickness (01) 1-3/4" to 2" $53

4560-X02 For door thickness (02) 2-1/4" to 2-1/2" $73

4560-X03 For door thickness (03) 2-3/4" to 3" $73

4560-X04 For door thickness (04) 3-1/4" $73

4565-X01 For door thickness (01) 1-3/4" to 2" $53

4565-X02 For door thickness (02) 2-1/4" to 2-1/2" $73

4565-X03 For door thickness (03) 2-3/4" to 3" $73

4565-X04 For door thickness (04) 3-1/4" $73

Series Deadlatch Handles for MS+1890 Deadlock/Deadlatch

MODELS & FINISHES 119, 121, 130

4560-011 For door thickness (11) 1-3/4" $39

4560-012 For door thickness (12) 1-3/4" to 2-1/4" $49

4560-013 For door thickness (13) 2-15/16" to 2-3/4" $49

4565-011 For door thickness (11) 1-3/4" $39

4565-012 For door thickness (12) 1-3/4" to 2-1/4" $49

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. HANDLE TYPE HANDING DOOR THICKNESS FINISH

456 0 -5 01 -130

0 Lever 0 Using MS+1890 FOR 4300, 4500, 4900

SERIES DEADLATCHES FOR MS+1890 119 To match 335 Black Anodized

5 Turn 5 LH or LHR 01 1-3/4" to 2" 11 1-3/4" 121 To match 313 Dark Bronze Anodized

6 RH or RHR 02 2-1/4" to 2-1/2" 12 1-3/4" to 2-1/4" 130 To match 628 Clear Anodized

03 2-3/4" to 3" 13 2-5/16" to 2-3/4"

04 3-1/4"

TRIM

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

4568, 4569 Eurostyle Deadlatch Handles for 4300, 4500, 4900 Deadlatches

MODELS & FINISHES 119, 121, 130

4568-X01 For door thickness (01) 1-3/4" to 2" $64

4568-X02 For door thickness (02) 2-1/4" to 2-1/2" $79

4568-X03 For door thickness (03) 2-3/4" to 3" $79

4568-X04 For door thickness (04) 3-1/4" $79

4569-X01 For door thickness (01) 1-3/4" to 2" $72

4569-X02 For door thickness (02) 2-1/4" to 2-1/2" $87

4569-X03 For door thickness (03) 2-3/4" to 3" $87

4569-X04 For door thickness (04) 3-1/4" $87

Eurostyle Deadlatch Handles for MS+1890 Deadlock/Deadlatch

MODELS & FINISHES 119, 121, 130

4568-011 For door thickness (11) 1-3/4" to 1-15/16" $52

4568-012 For door thickness (12) 2" to 2-1/4" $62

4568-013 For door thickness (13) 2-15/16" to 2-3/4" $62

4568-014 For door thickness (14) 3" $62

4569-011 For door thickness (11) 1-3/4" to 1-15/16" $57

4569-012 For door thickness (12) 2" to 2-1/4" $67

4569-013 For door thickness (13) 2-15/16" to 2-3/4" $67

4569-014 For door thickness (14) 3" $67

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. LEVER TYPE HANDING DOOR THICKNESS FINISH

456 8 -5 01 -130

8 Straight 0 Using MS+1890 FOR 4300, 4500, 4900

SERIES DEADLATCHES FOR MS+1890 119 To match 335 Black Anodized

9 Return End 5 LH or LHR 01 1-3/4" to 2" 11 1-3/4" to 1-15/16" 121 To match 313 Dark Bronze Anodized

6 RH or RHR 02 2-1/4" to 2-1/2" 12 2" to 2-1/4" 130 To match 628 Clear Anodized

03 2-3/4" to 3" 13 2-5/16" to 2-3/4"

04 3-1/4" 14 3"

TRIM

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

4590 Deadlatch Paddle for 4300, 4500, 4900 Deadlatches

MODELS & FINISHES 313, 335, 628

4590-0X-00 For door thickness (00) 1-3/4" $105

4590-0X-01 For door thickness (01) 1-13/16" to 2" $125

4590-0X-02 For door thickness (02) 2-1/4" to 2-1/2" $125

4590-0X-03 For door thickness (03) 2-3/4" to 3" $125

4590-0X-04 For door thickness (04) 3-1/4" $125

Deadlatch Paddle for MS+1890, 2190 Deadlocks

MODELS & FINISHES 313, 335, 628

4590-1X-00 For door thickness (00) 1-3/4" $89

4590-1X-01 For door thickness (01) 1-3/4" to 2-1/4" $109

4590-1X-02 For door thickness (02) 2-5/16" to 2-1/2" $109

4590-1X-03 For door thickness (03) 2-9/16" to 2-3/4" $109

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. OPERATION DOOR THICKNESS FINISH*

4590 02 -00 -313

FIRST DASH

FOR LATCH SERIES OPPERATION USE FOR 4300, 4500, 4900

SERIES DEADLATCHES FOR MS+1890, 2190 313 Dark Bronze Anodized

-01 4300/4500/4900 PULL

TO LEFT

Outside of left hand reverse

door or inside of right hand

00 1-3/4" 00 1-3/4" 335 Black Anodized

-11 MS+1890/2190 01 1-13/16" to 2" 01 1-3/4" to 2-1/4" 628 Clear Anodized

-02 4300/4500/4900 PUSH

TO LEFT

Outside of left hand door or

inside of right hand reverse

02 2-1/4" to 2-1/2" 02 2-5/16" to 2-1/2"

-12 MS+1890/2190 03 2-3/4" to 3" 03 2-9/16" to 2-3/4"

-03 4300/4500/4900 PULL

TO RIGHT

Outside of right hand reverse

door or inside or left hand

04 3-1/4"

-13 MS+1890/2190

-04 4300/4500/4900 PUSH

TO RIGHT

Outside of right hand door or

inside of left hand reverse

-14 MS+1890/2190

-03 OR -13

LHR

RHR

-02 OR -12

-03 OR -13

-04 OR -14

-01 OR -11

-04 OR -14

-01 OR -11

*Finish applied to paddle assembly only, not escutcheon.

TRIM

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

4591 Deadlatch Paddle for 4300, 4500, 4900 Deadlatches

MODELS & FINISHES 313, 335, 628 US3, US26D

4591-0X-00 For door thickness (00) 1-3/4" $125 $235

4591-0X-01 For door thickness (01) 1-13/16" to 2" $146 $256

4591-0X-02 For door thickness (02) 2-1/4" to 2-1/2" $146 $256

4591-0X-03 For door thickness (03) 2-3/4" to 3" $146 $256

4591-0X-04 For door thickness (04) 3-1/4" $146 $256

Deadlatch Paddle for MS+1890, 2190 Deadlocks

MODELS & FINISHES 313, 335, 628 US3, US26D

4591-1X-00 For door thickness (00) 1-3/4" $108 $218

4591-1X-01 For door thickness (01) 1-3/4" to 2-1/4" $129 $239

4591-1X-02 For door thickness (02) 2-5/16" to 2-1/2" $129 $239

4591-1X-03 For door thickness (03) 2-9/16" to 2-3/4" $129 $239

OPTIONS

4591MA Active paddle, latch activator with monitor switch Add $118

4591M Paddle with switch, no latch activator Add $102

91-0914 Monitor switch kit for 4591, ﬁeld installation $118

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. OPTIONS* OPERATION DOOR THICKNESS FINISH**

4591 M 02 -00 -313

– Standard Paddle FIRST DASH

FOR LATCH SERIES OPPERATION USE FOR 4300, 4500, 4900

SERIES DEADLATCHES FOR MS+1890, 2190 313 Dark Bronze

Anodized

M Paddle

w/ switch only -01 4300/4500/4900

PULL

TO LEFT

Outside of left hand

reverse door or inside

of right hand

00 1-3/4" 00 1-3/4" 335 Black Anodized

MA Active paddle

w/ switch -11 MS+1890/2190 01 1-13/16" to 2" 01 1-3/4" to 2-1/4" 628 Clear Anodized

-02 4300/4500/4900 PUSH

TO LEFT

Outside of left hand

door or inside of

right hand reverse

02 2-1/4" to 2-1/2" 02 2-5/16" to 2-1/2" US3 Bright Brass

-12 MS+1890/2190 03 2-3/4" to 3" 03 2-9/16" to 2-3/4" US26D Satin Chrome

-03 4300/4500/4900 PULL

TO RIGHT

Outside of right hand

reverse door or inside

or left hand

04 3-1/4"

-13 MS+1890/2190

-04 4300/4500/4900 PUSH

TO RIGHT

Outside of right hand

door or inside of

left hand reverse

-14 MS+1890/2190

*M and MA options availble on push paddles only, not pull paddles. **Finish applied to paddle assembly only, not escutcheon.

TRIM

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

4600 Heavy Duty Designer Deadlatch Handles

LEVER OPERATOR FOR

4300, 4500, 4900 SERIES

DEADLATCHES

LEVER OPERATOR FOR

2190, 2290 INTERCONNECTED

DEADBOLT/DEADLATCH

MODELS & FINISHES 10B, US4,

US32D US3, US32 10B, US4,

US32D US3, US32

STANDARD

LEVER

4600 Trim with standard lever (01, 02, 03) $135 $170 $120 $155

4600-M Trim with standard lever (01, 02, 03) with form

'C' switch option to indicate when lever is actuated $185 $220 $170 $205

4600-THICK DOOR Trim with standard lever

(01, 02, 03) for door thickness greater than 1-7/8" $155 $190 $140 $175

DESIGNER

LEVER

4600-MX Trim with designer lever series (MD through MW) $180 $215 $165 $200

4600-MX, M Trim with designer lever series

(MD through MW) with form 'C' switch option $230 $265 $215 $250

4600-MX, THICK DOOR Trim with designer lever series

(MD through MW) for door thickness greater than 1-7/8" $200 $235 $185 $220

KITTED OPTIONS

REX-4600 Request to exit kit $39

DTK-4600 Fixed lever (dummy) kit $12

TDK-4600-XX Thick door kit. Specify door thickness.* $26

TBK-4600-XX Through-bolt mounting kit for back-to-back mounting on wood doors. Specify door thickness.* $28

*For door thickness (01) 1-3/4", (02) 2", (03) 2-1/4", (04) 2-1/2" and (05) 2-3/4".

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. REX HANDLE HANDING** DOOR THICKNESS COMPATIBLE PRODUCTS FINISH

4600 M -01 -5 1 1 -32D

(BLANK) Standard STANDARD HANDLES 5 LH or LHR 1 1-3/4" to 1-7/8" 1 2190, 2290 Interconnected Deadbolt/Deadlatch US3 Bright Brass

M Switch Option 01 Curve 6 RH or RHR 2 2" to 2-1/8" 2 4300, 4500, 4900 Series Deadlatches US4 Satin Brass

02 Round 3 2-1/4" to 2-3/8" 10B Dark Bronze

03 Square 4 2-1/2" to 2-5/8" US32 Bright Stainless

DESIGNER SERIES 5 2-3/4" to 2-7/8" US32D Satin Stainless

MD MJ

ME MN* (Handed)

MG MV* (Handed)

MI MW

*Handing must be speciﬁed for MN and MV Designer Levers. **Handing - assuming lever on interior of door.

TRIM

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

CYLINDERS & ACCESSORIES

4024, 4025, 4026 Cylinder Pulls

MODELS & FINISHES 119, 121, 130

4024-00-01, 02 Cylinder pull, Schlage keyway $61

4024-06-01, -02 Cylinder pull, Weiser keyway $61

4025-00-01, 02 Cylinder pull, Schlage keyway $66

4025-06-01, 02 Standard cylinder pull, Weiser keyway $66

4025-100-02, CYL X CYL Cylinder both sides pullset, Schlage keyway $132

4025-106-02, CYL X CYL Cylinder both sides pullset, Weiser keyway $132

4026-00-01, 02 Cylinder pull for use with 5015, 5017 Wood Door Deadlock, Schlage keyway $68

4026-06-01, 02 Cylinder pull for use with 5015, 5017 Wood Door Deadlock, Weiser keyway $68

Please contact factory for special cylinder requirements.

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PULL TYPE PULL NO./CYLINDER INCLUDED KEYING FINISH

4024 -00 -01 -130

4024 Trim Plate Mounted 00 Schlage "C: Keyway 01 Keyed Dierent 119 To match 335 Black Anodized

4025 Stile Mounted with through - screws 06 Weiser Keyway 02 Keyed Alike in Pairs 121 To match 313 Dark Bronze Anodized

4026 For Wood Applications 130 To match 628 Clear Anodized

4036 Mortise Cylinder

MODEL & FINISHES 313, 335, 628

4036 Five pin cylinder.2 keys and 1/4" ring, KD, KA2 only

$43

For 3300, 3600, 8300, 8400, 8500, 8600, or entry trim.

Can be installed directly in latch case of 8400, 8300, or 3300.

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. LOCK TYPE KEY OPTIONS* FINISH

4036 -01 -01 -628

01 For MS Locks, Deadlatches, 2190 01 Keyed dierent 313 Dark Bronze Anodized

02 For 4070 Deadlock 02 Keyed alike in pairs 335 Black Anodized

03 For 2331 Deadlock 628 Clear Anodized

* Keyed alike 50 (KA50) are availiable by special order in quantity of 50 cylinders only. Please contact factory for ordering information.

CYLINDERS & ACCESSORIES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

MS4043 Cylinder Guard

MODELS & FINISHES 119, 121, 130

MS4043-00 Cylinder guard, 1/8" stile wall, 5 or 6 pin cylinder $37

MS4043-01 Cylinder guard, 1/4" stile wall, 5 or 6 pin cylinder $42

MS4043-02 Cylinder guard, 1/8" stile wall, 1-5/16" to 1-7/16" long cylinder $58

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. STILE WALL & CYLINDER FINISH

MS4043 -01 -130

STILE WALL CYLINDER 119 To match 335 Black Anodized

00 1/8" 5 or 6 pin 121 To match 313 Dark Bronze Anodized

01 1/4" 5 or 6 pin 130 To match 628 Clear Anodized

02 1/8" 1-5/16" to 1-7/16" long

4066 Thumbturn

MODEL & FINISHES 130, 313, 335

4066 Thumbturn cylinder with 1/4" ring $43

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. LOCK TYPE FINISH

4066 -01 -130

01 For MS Locks, Deadlatches 130 To match 628 Clear Anodized

02 For 4070 Deadlock 313 Dark Bronze Anodized

03 For 2331 Deadlock 335 Black Anodized

4580 Cam Disc

MODELS

4580-X00, 4580-X01 Included with lever handles, door thickness 2" or less $18

4580-X02, 4580-X03 Included with lever handles, door thickness greater than 2" $26

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. HANDING DOOR THICKNESS

4580 -5 00

5 LH 00 1-3/4"

6 RH 01 2"

02 2-1/4"

03 2-3/4"

CYLINDERS & ACCESSORIES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

4581 Universal Cam Plug

MODELS

4581-01 Universal cam disc, non-handed, for 1-3/4" door thickness (included in 4600) $25

4581-02 Universal cam disc, non-handed, for 2" door thickness $33

4581-03 Universal cam disc, non-handed, for 2-1/4" door thickness $33

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. DOOR THICKNESS

4581 01

01 1-3/4"

02 2"

03 2-1/4"

8650 Cylinder Escutcheon Kit

MODELS & FINISHES 119, 121, 130 313, 335, 628 US4, US32D US3, US32

8650 Cylinder escutcheon kit for 3600, 8500, 8600 exit devices $36 $61 $70 $80

8650 For wall thickness over 1/8" * $66 $91 $100 $110

*Please contact factory for wall thickness greater than 1/8"

8736 Rim Cylinder

MODEL & FINISHES 313, 335, 628

8736 Five-pin Rim cylinder for use with 3100, 3700, 8100, 8200, 8700, 8800 exit devices. $46

4014 Two-Point Conversion Kit

MODEL PRICE

4014-01 Two-point conversion kit for MS1861 Bottom Rail Deadlock $37

4015 Threshold Bolt

MODEL & FINISHES 603

4015-18-IB Two-point converter, threshold bolt, standard cylinder height. $44

4015-XX-IB Two-point converter, threshold bolt, specify cylinder height greater than 53", 60" maximum. $67

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. ADD DASH NUMBER FOR "UNIVERSAL SIZE" PACKAGING

4015 -18 -IB

IB Individually Boxed

Please specify cylinder height if ordering in volume quantity for a speciﬁc cylinder height.

CYLINDERS & ACCESSORIES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

4016 Header Bolt

MODEL PRICE

4016 Three-point converter, provides upper bolt for MS1850/1870 Deadlocks $57

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. LOCK BACKSET DOOR HEIGHT

4016 -30 -01

10 1-1/2" 01 7' Door

20 31/32" 02 10' Door

30 1-1/8"

4085 Header Bolt (Pairs of Doors Only)

MODELS & FINISHES PRICE

4085-01-IB Positioner bolt and header strike, speciﬁy cylinder height for 7' door height $85

4085-02-IB, 4085-03-IB, 4085-04-IB Positioner bolt and header strike, specify cylinder height for door

height greater than 7', door height 10’ maximum. $106

Contact factory for door height greater than 7'.

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. DIMENSION 'A' PACKAGING

4085 -02 -IB

01 30" - 52" IB Individually Boxed

02 52" - 67"

03 67" - 79"

04 79" - 92"

EXAMPLE

Door Height Cylinder Height A

96" - 40" = 56"

REFERENCE:

7’ Door is 84"

8’ Door is 96"

9’ Door is 108"

10’ Door is 120"

4089 Exit Indicator

MODELS & FINISHES 119, 121, 130

4089-00, 4089-01 Indicator for 1-3/4" door, includes both UBC and IBC signs $55

4089-20 Indicator for 2" to 2-1/2" door, includes both UBC and IBC signs $91

ACCESSORIES

91-0912 Adapter plate for converting MS1850/4089 installation to deadlatch and lever handle or paddle. Select 121 or 130 ﬁnish. $33

20-0255-IP Header sign "…During Business Hours" $7

20-0256-IP IBC header sign "…Building is Occupied" $7

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO OPTIONS FINISH

4089 -01 -130

00 Standard 1-3/4" Door 119 To match 335 Black Anodized

01 For Inverted Lock 121 To match 313 Dark Bronze Anodized

20 For Doors up to 2-1/2" 130 To match 628 Clear Anodized

CYLINDERS & ACCESSORIES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

4104 Mounting Bridges

MODELS PRICE

4104-01 Radius mounting bridge $10

4104-02 Flat mounting bridge $10

4104-03 Left hand bevel mounting bridge $10

4104-04 Right hand bevel mounting bridge $10

91-0965 Universal Mounting Tab Kits for Installing MS® Locks & Latches

MODELS PRICE

91-0965 Mounting tab kits for ﬂat/radius stiles $15

91-0966 Mounting tab kits for beveled stiles, includes tabs for right hand and left hand

bevel doors and mounting screws for clear and dark bronze. $15

B1921, B1923 Reinforcing Pivots

MODELS & FINISH PRICE

B1921 1/2" oset to match pivot point of 4" wide butt hinge $87

B1923 3/4" oset to match pivot point of 4-1/2" wide butt hinge $76

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. MODEL

B192 1

1 4"

3 4-1/2"

Strikes

2190 Dual Force® Interconnected Deadbolt/Deadlatch Strikes

MODELS & FINISHES 630 119, 121

2101-01 Standard ﬂat strike with dust box $26 $32

2101-02 Standard radius strike with dust box $26 $32

MODELS & FINISHES 630 121

2101-XX Strike with extended lip, 4.5" only, ﬂat strike. $41 $47

2102-01 Retroﬁt strike extended height 7-5/8" with dust box. $38 $44

2290 Dual Force® Interconnected Deadbolt/Deadlatch Strikes

MODELS & FINISHES 630 119, 121

2206-01 Standard ﬂat strike with dust box $26 $32

2206-XX Strike with extended lip, specify dimension from strike

centerline to frame face, to 4.5” maximum, ﬂat strike only $41

CYLINDERS & ACCESSORIES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

4000 Series Series MS® Deadlock Strikes

MODELS & FINISHES 630 313, 335, 628 US3, US26D 119, 121

4000 Trim Strike $27

4001 Box Strike, includes dust box $27 $47

MS4002 Armored Strike $56 $76

4003 ANSI strike, available in 121 or US26D only $68 $68

4005 Strike for 4015 Threshold Bolt $20

4006 Strike for 1830 Bottom Rail Deadlock, also available in 130 ﬁnish $43 $49

4009-01 Open back strike for 3300, 8300 Series Mortise Exit Device $139

4170 Trim strike for 4070 Short Throw Deadbolt, not available in 335 ﬁnish $27

4505-01 Flat armored box strike for MS+1890 Deadlock/Deadlatch $47 $54

4505-02 Radius armored box strike for MS+1890 Deadlock/Deadlatch $47 $54

4505-17, 4505-21 Flat long lip armored box strike $60 $66

HOW TO ORDER Specify quantity and the following information. Order related products separately.

STRIKE MODEL TRIM PLATE

SHAPE COMPATIBLE DEADLOCK TRIM PLATE

CORNERS FINISH

4001 -0 1 1 -313

4000 Trim Strike 0 Flat 1 All Standard MS® locks with 1-3/8" Bolt Throw 1 Square 313 Dark Bronze Anodized

4001 Box Strike 1 Radius 2 1850A-020 with 3/4" Bolt Throw Only 2 Round 335 Black Anodized

MS4002 Armored Strike 3 All MS-050 Hookbolt locks 628 Clear Anodized

4800, MS4804 Series Strikes

MODELS & FINISHES 603 630

MS4804-10-630 Reinforcing strike and screws, two-part with reinforcement for strengthening metal jamb $20

4801 Metal strike, specify dash number indicating shim quantity $16 $23

4802 Wood strike, specify dash number indicating shim quantity $16 $23

4810-01, 4810-02 Box strike for 5017 Wood Door Deadlock/Deadlatch $16

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. TYPE OF JAMB DIMENSION 'A' FINISH

480 1 -02 -630

1 Metal 01 3/32" 603 Zinc Plated Steel

2 Wood 02 3/16" 630 Satin Stainless

03 9/32"

CYLINDERS & ACCESSORIES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

4901, 4902 Deadlatch Strikes

MODELS & FINISHES 630 119, 121

4901-01 Flush mount ﬂat strike, mortised with dust box $17 $23

4901-02 Flush mount radius strike, mortised with dust box $17 $23

4901-XX Extended lip strike, specify lip dim 'A', 2.5" maximum* $37 $43

4902-01 Short box strike, ﬂat with dust box, mounting plate $17 $23

4902-02 Short type box strike, radius with dust box, mounting plate $17 $23

4902-XX Extended lip strike, specify lip dim 'A', 2.5" maximum* $37 $43

4506 Strike for use with 4920AN, not available in 119 ﬁnish $37 $43

*See dim. ‘A’ dash chart table below.

HOW TO ORDER Specify quantity and the following information. Order related products separately.

PRODUCT NO. STRIKE TYPE FACEPLATE SHAPE FINISH

490 1 -02 630

STANDARD LIP 119 To match 335 Black Anodized

1 Long 01 Flat 121 To match 313 Dark Bronze Anodized

2 Short 02 Radius 630 Satin Stainless Steel

LONG LIP FOR

CENTER HUNG DOOR DIM. ‘A’ LONG LIP FOR

CENTER HUNG DOOR DIM. ‘A’

03 2-1/4" Wide Jamb 1-1/8 13 3-1/2" Wide Jamb 1-3/4

05 2-1/2" Wide Jamb 1-1/4 15 3-3/4" Wide Jamb 1-7/8

07 2-3/4" Wide Jamb 1-3/8 17 4" Wide Jamb 2

09 3" Wide Jamb 1-1/2 19 4-1/4" Wide Jamb 2-1/8

11 3-1/4" Wide Jamb 1-5/8 21 4-1/2" Wide Jamb 2-1/4

4304 Deadlatch Strike

MODEL & FINISHES 630 119, 121

4304 Surface mount strike for 4300 Electriﬁed Deadlatch $21 $27

CYLINDERS & ACCESSORIES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

Thick Door Kits

2190, 2290 Dual Force® Interconnected Deadbolt/Deadlatch Thick Door Kit

MODELS PRICE

2190-TDK-XX Thick door kit for 2190, 2290 standard exterior trim set. Specify door thickness.* $63

2190-TDK-CL1, -CL2 Thick door kit for 2190, 2290 cladded doors. CL-1 for a standard 1-3/4" thick door with

1/4" cladding. CL-2 for a standard 1-3/4" thick door with 1/2" cladding. $63

TDK-4600-XX Thick door kit for 2190, 2290 low proﬁle trim set. Specify door thickness.* $26

*For door thickness (01) 1-3/4", (02) 2", (03) 2-1/4", (04) 2-1/2", (05) 2-3/4", (06) 3", (07) 3-1/4".

4568, 4569 Eurostyle Deadlatch Handle Thick Door Kits

MODELS PRICE

91-0128-02, 91-0128-03, 91-0128-04 Thick door kits for 4568, 4569 $19

26-0203-01, 26-0203-02, 26-0203-03 Thick door kits for 4568-11, 4569-11 $19

Faceplates

MS1850S Deadlock Faceplates

MODELS & FINISHES 313, 628

BFK-MS1850-10 Blank faceplate kit, ﬂat, 1" x 6-7/8" $23

BFK-MS1850-11 Blank faceplate kit, radius, 1" x 6-7/8" $23

MS1850S,

MS1950

Deadlock (Standard Bolt) Faceplates

MODELS & FINISHES 313, 335, 628 US4, US26D US3, US26

24-0384-010 Flat faceplate $8 $30 $34

24-0384-110 Radius faceplate $8 $30 $34

24-0384-210 Left hand bevel faceplate $8 $30 $34

24-0384-310 Right hand bevel faceplate $8 $30 $34

24-0384-410 Radius with weatherstrip $11

SPECIAL MODELS 313, 628

24-0384-110-313-B100, 24-0384-110-628-B100

Radius faceplates, bulk package of 100 units $659

24-0384-210-313-B100, 24-0384-210-628-B100

Left hand bevel faceplates, bulk package of 100 units $659

24-0384-310-313-B100, 24-0384-310-628-B100

Right hand bevel faceplates, bulk package of 100 units $659

24-0384-410-313-B100, 24-0384-410-628-B100

Radius with weatherstrip faceplates, bulk package of 100 units $906

Please note that all 100 faceplates in the bulk package are of the same ﬁnish.

CYLINDERS & ACCESSORIES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

MS1850S,

MS1950

Deadlock (Hookbolt and Short Bolt) Faceplates

MODELS & FINISHES 313, 335, 628 US4, US26D US3, US26

24-0384-020 Flat faceplate $8 $30 $34

24-0384-120 Radius faceplate $8 $30 $34

24-0384-220 Left hand bevel faceplate $8 $30 $34

24-0384-320 Right hand bevel faceplate $8 $30 $34

24-0384-420 Radius with weatherstrip $11

SPECIAL MODELS 313, 628

24-0384-020-313-B100, 24-0384-020-628-B100

Flat faceplates, bulk package of 100 units $659

24-0384-120-313-B100, 24-0384-120-628-B100

Radius faceplates, bulk package of 100 units $659

24-0384-220-313-B100, 24-0384-220-628-B100

Left hand bevel faceplates, bulk package of 100 units $659

24-0384-320-313-B100, 24-0384-320-628-B100

Right hand bevel faceplates, bulk package of 100 units $659

24-0384-420-313-B100, 24-0384-420-628-B100

Radius with weatherstrip faceplates, bulk package of 100 units $906

Please note that all 100 faceplates in the bulk package are of the same ﬁnish.

MS1850SN Deadlock (Standard Bolt) Faceplates

MODELS & FINISHES 313, 335, 628 US4, US26D US3, US26

24-0226-010 Flat faceplate $11 $32 $36

24-0226-110 Radius faceplate $11 $32 $36

24-0226-210 Left hand bevel faceplate $11 $32 $36

24-0226-310 Right hand bevel faceplate $11 $32 $36

MS1850SN-45X Deadlock (Hookbolt) Faceplates

MODELS & FINISHES 313, 335, 628 US4, US26D US3, US26

24-0226-020 Flat faceplate $11 $32 $36

24-0226-120 Radius faceplate $11 $32 $36

24-0226-220 Left hand bevel faceplate $11 $32 $36

24-0226-320 Right hand bevel faceplate $11 $32 $36

1870 Flushbolt Faceplates

MODELS & FINISHES 313, 335, 628

24-0168-00 Flat faceplate $16

24-0168-01 Radius faceplate $16

24-0168-02 Left hand bevel faceplate $16

24-0168-03 Right hand bevel faceplate $16

24-0168-04 Radius with weatherstrip $19

CYLINDERS & ACCESSORIES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

MS+1890 Deadlock Faceplates

MODELS & FINISHES 313, 335, 628

24-0270-020 Flat faceplate $10

24-0270-120 Radius faceplate $10

24-0270-220 Left hand bevel faceplate $10

24-0270-320 Right hand bevel faceplate $10

24-0270-420 Radius with weatherstrip $13

2190 Dual Force® Interconnected Deadbolt/Deadlatch Faceplates

MODELS & FINISHES 313, 628

91-0266-01-313-IP, 91-0266-01-628-IP Flat faceplate and radius faceplate kit for aluminum (2190) $37

91-0266-04-313-IP, 91-0266-04-628-IP Flat faceplate and radius faceplate kit for wood or hollow metal (2290) $37

2331 Heavy Duty Deadbolt Faceplates

MODELS & FINISHES 121 US26D US3

22-0170 Flat faceplate $37 $37 $41

22-0032 Strike plate $37 $37 $41

3300 Fire-Rated Mortise Exit Device Faceplates

MODEL & FINISHES 335, 628

24-0015-020 Flat faceplate $10

4070 Short Throw Deadbolt Faceplates

MODELS & FINISHES 313, 335, 628

24-0136-00 Flat faceplate $10

24-0136-10 Radius faceplate $10

24-0136-20 Left hand bevel faceplate $10

24-0136-30 Right hand bevel faceplate $10

4500 Standard Duty Deadlatch Faceplates

MODELS & FINISHES 313, 335, 628

24-0017-0220 Flat faceplate $8

24-0017-1220 Radius faceplate $8

24-0017-2220 Left hand bevel faceplate $8

24-0017-3220 Right Hand bevel faceplate $8

24-0017-4220 Radius with weatherstrip $11

Please note that all 100 faceplates in the bulk package are of the same ﬁnish.

CYLINDERS & ACCESSORIES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

4530 Standard Duty Deadlatch Faceplates

MODELS & FINISHES 313, 335, 628

24-0016-020 Flat faceplate $13

24-0016-120 Radius faceplate $13

24-0016-220 Left hand bevel faceplate $13

24-0016-320 Right hand bevel faceplate $13

4900 Heavy Duty Deadlatch Faceplates

MODELS & FINISHES 313, 335, 628 US4, US26D US3, US26

24-0137-01 Flat or bevel faceplate $8 $30 $34

24-0137-02 Radius faceplate $8 $30 $34

24-0137-03 Radius with weatherstrip $11

4900 Heavy Duty Deadlatch Special Faceplates

MODELS & FINISHES 313, 628

24-0140 Radius with weatherstrip seal (1-1/8" x 6-7/8") $16

24-0144-01 Flat or beveled doors (1-1/8" x 7-1/4") $13

24-0144-03 Radius with weatherstrip (1-1/8" x 7-1/4") $16

4920, 8300 Faceplates

MODEL & FINISHES 313, 335, 628

24-0138-01 Flat or bevel faceplate $23

7100, 7160 Electric Strike Faceplates

MODEL & FINISHES 313, 335, 628

24-0685-01 Round corner faceplate (1-1/4" x 4-7/8") $21

7101 Electric Strike Faceplates

MODEL & FINISHES 313, 335, 628

24-0685-02 Radius faceplate (1-1/4" x 4-7/8") $21

7110 Electric Strike Faceplates

MODEL & FINISH 652

22-0558 Round corner faceplate (1-7/16" x 7-15/16") $21

7111 Electric Strike Faceplates

MODEL & FINISH 652

22-0557 Round corner faceplate (1-7/16" x 10-1/4") $21

CYLINDERS & ACCESSORIES

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

7130 Electric Strike Faceplates

MODEL & FINISHES 313, 335, 628

24-0686-01 Round corner faceplate (1-1/4" x 6-7/8") $26

7131 Electric Strike Faceplates

MODEL & FINISHES 313, 335, 628

24-0686-02 Radius faceplate (1-1/4" x 6-7/8") $26

7140, 7170 Electric Strike Faceplates

MODEL & FINISHES 313, 335, 628

24-0687-01 Radius faceplate (1-1/4" x 4-7/8") $21

POWER

PS-1 Power Supply

MODEL PRICE

PS-1 Power supply, 12/24 VDC boxed P/S 1 Amp $303

PS-LR Power Supply

MODEL PRICE

PS-LR Power supply for exit devices with LR latch retraction option $768

KITTED OPTION

MODEL PRICE

BBK-LR Add-on board to the PS-LR, must be supplied with 2 each 12V - 7AH batteries (by others) $212

PS-SE Power Supply

MODEL PRICE

PS-SE Power supply for exit devices with SE motorized latch retraction option $621

KITTED OPTION

MODEL PRICE

BBK-SE Add-on board to the PS-SE, must be supplied with 2 each 12V - 7AH batteries (by others) $212

CYLINDERS & ACCESSORIES | POWER

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

4612 Power Transfer Device

MODELS PRICE

4612-1 Wire transfer, 105° swing $165

4612-2 Wire transfer, 180° swing $212

4612-1SC Wire transfer, swing clear 90° swing $283

4612EL-1 Wire transfer, 105° swing with ElectroLynx(TM) Adapter $191

4612EL-1SC Wire transfer, 90° swing with ElectroLynx(TM) Adapter $309

4603, 4605,

4606

Accessories for Power

MODELS PRICE

4603 Rectiﬁer $15

4605 Transformer, 115 VAC to 12/24 VAC $54

4606 Plug-in transformer, 115 VAC to 24 VAC only $88

29-0218 Piezo electric horn $21

ELX ElectroLynx™ Adapter to connect Adams Rite products to the ElectroLynx system $31

DEMO MOUNTS

Deadlocks & Deadlatches

RT1050 RITE Touch® Digital Glass Door Lock

MODEL & FINISH PRICE

RT1050D-DEMO RITE Touch digital glass door lock with thumbturn, for all-glass doors $773

RT1050L-DEMO RITE Touch digital glass door lock with lever, for full-glass doors $773

2190 Dual Force® Interconnected Deadbolt/Deadlatch

MODELS & FINISH US32D

2190-MOUNT Dual Force® 2190 Interconnected Deadbolt/Deadlatch mounted complete with electriﬁed trim set $1,020

4300 Steel Hawk® Electriﬁed Deadlatch

MODELS & FINISH US32D

4300-MOUNT Steel Hawk® 4300 Electriﬁed Deadlatch mounted complete with 4600 Heavy Duty Designer Deadlatch Lever Trim with MN designer lever $867

Exit Devices

8400 Narrow Stile Mortise Exit Device

MODELS & FINISH 628

8400SE-MOUNT 8400 Series Narrow Stile Mortise Exit Device featuring SE motorized latch retraction option $1,640

POWER | DEMO MOUNTS

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

Electric Strikes

7400 Ultraline® Electric Strikes

MODELS & FINISH PRICE

7440-MOUNT UltraLine 7440 Electric Strike mounted complete with 4-7/8" faceplate, 628 ﬁnish $765

74R1-MOUNT UltraLine 74R1 Electric Strike for rim exit devices with 3/4" Pullman latches mounted complete, 130 ﬁnish $765

74R2-MOUNT UltraLine 74R2 Electric Strike for rim exit devices with 1/2" Pullman latches mounted complete, 130 ﬁnish $765

Trim

A100-3090H Keyless Entry and Aperio® Hub Wholesale Kit

MODELS & FINISH 626

A100-3090C-MOUNT Aperio® A100 Keyless Entry Control and Aperio Hub with HID® iClass credentials, mounted complete with

4900 Heavy Duty Deadlatch, 4600 Heavy Duty Designer Deadlatch Lever Trim $2,150

A100-3090CK-MOUNT Aperio® A100 Keyless Entry Control and Aperio Hub with keypad and HID® iClass credentials, mounted complete

with 4900 Heavy Duty Deadlatch, 4600 Heavy Duty Designer Deadlatch Lever Trim $2,150

3090 eForce® Keyless Entry

MODELS & FINISH 626

3090-MOUNT eForce®3090-150 Keyless Entry Trim mounted complete with 4900 Heavy Duty Deadlatch $1,224

3090C-MOUNT eForce®3090P Keyless Entry Trim with HID® iClass credentials mounted complete with 4900 Heavy Duty Deadlatch $1,479

3090P-MOUNT eForce®3090P Keyless Entry Trim with HID® Prox credentials mounted complete with 4900 Heavy Duty Deadlatch $1,479

4600 Heavy Duty Designer Deadlatch Handles

MODELS & FINISH US32D

4600-MOUNT 4600 Heavy Duty Designer Deadlatch Lever Trim with MN designer levers, mounted complete with Dual Force® 2190 Deadbolt/Deadlatch (lock) $1,020

DEMO MOUNTS

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

GENERAL INFORMATION

This new warranty will be eective as of

February 1, 2019 and will not be applied retroactively.

Adams Rite Limited Warranty

Adams Rite warrants that its products sold under the Adams Rite brand in the United

States of America are warranted free from defects in workmanship and materials

under normal use and service. This warranty does not cover defects or damage

arising from improper installation, lack of or improper maintenance, improper

storage, shipping and handling, corrosion, erosion, ordinary wear and tear, misuse,

abuse, accident, unauthorized service, or use with unauthorized non-Adams Rite

products or parts. This warranty is void if any modiﬁcation is made to the product,

regardless of whether the modiﬁcation causes or contributes to the alleged defect.

All modiﬁcations are made at the risk of the party making the modiﬁcation.

Should any defect of manufacture (in material or workmanship) occur in its

products, Adams Rite, upon prompt notiﬁcation and proof to its satisfaction that

the product was defective in manufacture for the use intended by Adams Rite,

will at its option, exchange the product, repair the product, or refund the price

charged by Adams Rite, FOB factory within the stated time frame listed below. .

• 10 years on all mechanical products from the date of manufacture

• 5 years on the following electromechanical product categories from the date of

manufacture, deadlocks, dead latches, exit devices*, electric strikes, trims, power

supply & accessories

* NOTE: The SE option (motorized electric latch retraction) is supported

by a 1-year electro mechanical warranty. When powered by an Adams

Rite PS-SE power supply the 1-year warranty is upgraded to 5 years

• 3 years on the following access control products from the date of

manufacture, RT1050, 3090-150, 3090P/C & A100 (Integrated Wiegand).

General RMA Procedure

Product repair or replacement, or associated charges, will not be accepted under

this warranty unless prior authorization from Adams Rite has been given. Upon

receipt of products returned for repair or replacement, Adams Rite will determine

whether products qualify for repair or replacement under this warranty. Adams

Rite has no liability to pay any costs of repair performed by anyone other than

qualiﬁed personnel authorized by Adams Rite prior to the work being done.

Written notice of a product or component part believed to be defective as covered by this

warranty should be sent to Adams Rite, 10027 S. 51st Street, Suite 102, Phoenix, Arizona

85044 or customer.care@assaabloy.com and should include your name and address, an

identiﬁcation of the product or component part and a brief description of the defect.

Notice of a product or component part believed to be defective as covered by this

warranty may also be accepted over the telephone by Adams Rite, 800.872.3267

CUSTOMER CARE FORM CCF

Upon receipt of such notice, if the customer has an account with Adams Rite or a valid

credit card, an advance replacement product may be ordered whereby Adams Rite will

ship a replacement product to the customer free of charge. If Adams Rite does not receive

the original defective product from the customer within 60 days, Adams Rite will charge

the customer’s account or credit card for the price of the advanced replacement product

plus freight costs. Upon inspection of the returned product by Adams Rite, a decision will

be made whether or not to charge the customer for the advanced replacement Adams

Rite product. This decision will be made solely by Adams Rite in accordance with the

provisions of these Terms. Obsolete products will not be accepted for return. Return Material

Authorizations (RMAs) will be closed if the goods are not received within 60 days of issuance.

If Adams Rite receives original defective product from the customer within 60 days of

RMA issuance, and if the customer is requesting credit for the defective material, the

customer must reference the valid Adams Rite Purchase Order number upon which the

product was originally ordered. If the original Purchase Order number is not available, at

Adams Rite’s option a credit may be issued at the customer’s current cost. This decision

will be made solely by Adams Rite in accordance with the provisions of these Terms.

Transportation charges and insurance on all returned materials must be prepaid

by the purchaser when merchandise is ordered in error. On goods returned for

customer convenience, when the purchaser returns materials in compliance

with these Terms which are accepted by Adams Rite, the purchaser may be

issued a credit for 65% of the purchase price, with 35% charged by Adams Rite

for handling and reprocessing. All refunds will be in the form of a credit.

Cancellation

As an industry leader, Adams Rite is committed to maintaining the highest standard of

quality and ensuring strict compliance to industry codes. Adams Rite’s proud history of

customer service and manufacturing agility allow quick response times to customer’s

changing needs, which may include special orders or product modiﬁcations. Please be

advised that all product modiﬁcations require special authorization to ensure the order

fully meets customer’s expectations. Customers are asked to allow for an extended

lead time on all special orders. Please note that at Adams Rite’s option, product

modiﬁcations and other special orders cannot be changed, canceled, or returned

once a ship date has been provided on an order acknowledgment by Adams Rite.

Adams Rite prides itself on introducing new, industry-relevant, feature-rich products.

Since new solutions will surpass the capabilities of older product lines, historical

products may be subsequently discontinued. Every eort will be made to announce

new product introductions as well as product discontinuations in a manner that allows

customers advanced notice of these events. Once a product line is discontinued

orders will be fulﬁlled in order of receipt, although Adams Rite cannot guarantee all

orders can be ﬁlled. Repair services and spare parts for discontinued product lines

will be available for some reasonable time period. Adams Rite reserves the right to

replace discontinued product with an equivalent product as deemed by Adams Rite.

THIS WARRANTY IS IN LIEU OF ALL OTHER EXPRESS WARRANTIES. TO THE

EXTENT PERMITTED BY LAW, ALL IMPLIED WARRANTIES ARE LIMITED TO THE

DURATION OF THIS WARRANTY. ADAMS RITE IS A DIVISION OF HANCHETT

ENTRY SYSTEMS, INC. HANCHETT ENTRY SYSTEMS, INC. SHALL NOT BE

LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES. SOME STATES

DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS

OR THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL

DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSIONS MAY NOT APPLY

TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU

MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.

Canada

Customers purchasing from Door Security Solutions Canada can ﬁnd

Canadian Terms and Conditions at www.assaabloy.ca/terms.

US adamsrite.com | 800.872.3267 | customerservice.adamsrite@assaabloy.com

Canada assaabloydss.ca | 800.461.3007 | sales.dss.ca@assaabloy.com

Updated: December 10, 2018

NOTES – THANK YOU

Patent pending and/or patent www.assaabloydss.com/patents.

whole or in part without the express written permission of Hanchett Entry Systems, Inc. is prohibited.

USA

800.872.3267 | f: 800.232.7329 | adamsrite.com

10027 S. 51st St., Suite 102, Phoenix, AZ 85044

customerservice.adamsrite@assaabloy.com

techsupport.adamsrite@assaabloy.com

orders.adamsrite@assaabloy.com

Canada

800.461.3007 | f. 800.461.8989 | assaabloydss.ca

160 Four Valley Dr., Vaughan, ON, Canada L4K 4T9

sales.dss.ca@assaabloy.com

orders.dss.ca@assaabloy.com

@AdamsRite AdamsRiteMfg Adams Rite

# AR-043-1118

Adams Rite 2019 Price Book List

Navigation menu

Versions of this User Manual:

Views

Navigation
