PRODUCT MUST BE INSTALLED
ACCORDING TO ALL APPLICABLE
BUILDING AND LIFE SAFETY CODES
www.adamsrite.com
Phone: 800-626-7590
800-872-3267
Fax: 866-582-4641
800-232-7329
C
L
C
L
C
L
RADIUS WEATHER STRIP
BEVEL RIGHT
BEVEL LEFT
RADIUS
FLAT
AVAILABLE FACEPLATES
"A"
"C"
.68"
(17.27)
"B"
C
L
LOCK & STILE
.92"
(23.4)
LOCK & CYLINDER
INSTALLATION
ALTERNATE MOUNTING METHODS
6.885
"
(174.88)
1.010
"
HOLE
1.25"
(31.75)
FLOOR
34" - 44"
FROM
FINISHED
1.594"
(40.49)
R.156
(3.97)
4 PLCS
LOCK STILE PREPARATION
BACKSET
C
L
C
L
6.00"
(152.40)
6.81"
(22.35)
.34" (8.64)
6.38
"
(162.05)
HOOKBOLT OR
SHORTBOLT = .81" (20.57)
REGULAR BOLT
= 1.41" (35.81)
.54"
(13.72)
.75" (19.05)
(5.59)
.22"
.88"
(22.35)
.62"
(15.75)
1.00
" (25.40)
"A"
BACKSET MUST BE
MEASURED AT THE
C
L
OF STILE
C
L
CYLINDER
ADAMS RITE
MOUNTING BRIDGE
(SEE CATALOG)
LOCK IS SECURED TO BACK WEB
OF STILE BY MEANS OF TWO (2)
#10 (M5) FLAT HEAD MACHINE
SCREWS & TWO (2) TUBE SPACERS
OF PROPER LENGTH TO POSITION
LOCK. TO DETERMINE TUBE SPACER
LENGTH (L) USE THE FOLLOWING
FORMULA:
"L"
"C"
A
BACKSET
TR
B
B
TR
C
L
C
L
.182" ± .005
(4.62 ±.13)
R
.120
±.005
(3.04
0.13)
.800" ± .005
(20.32 ± .13)
THE MS SERIES LOCKS ARE OPERABLE BY
ANY STANDARD 1 5/32" DIAMETER (29.37)
MORTISE CYLINDER WITH SPECIAL MS
CAM DIMENSIONED AS ABOVE. CYLINDERS
WITH MS CAMS CAN BE READILY OBTAINED
FROM MOST CYLINDER MANUFACTURERS.
(25.65)
+.015
-.000
+.015
-.000
+.20
-.00
+.30
-.00
FLAT
RADIUS
BEVELED
SCREWS WILL BE FURNISHED
APPROX. 1/4" LONGER THAN
THE SPACER.
L = C -.25
(6.35)
METHOD #1
METHOD #2
CYLINDER TRIM RING
TRIM RING THICKNESS (TR)
WILL VARY WITH SPECIFIC
CYLINDER MAKE, NUMBER
OF PINS & SPECIFIC DOOR
THICKNESS. TO DETERMINE
TRIM RING THICKNESS, USE
THE FOLLOWING FORMULA:
TR = A + .125 - B
(3.17)
Page of
1 1
INSTALLATION INSTRUCTIONS
Rev.
Appvd: MP
ECN: 11955A
Date: 06-19-12
G
MS1950, MS1850A, & MS1850S
80-0180-5
