ADEMCO 6150RF
ADEMCO 6150RFADEMCO 6150RF
ADEMCO 6150RF
Keypad/Transceiver
Keypad/TransceiverKeypad/Transceiver
Keypad/Transceiver
INSTALLATION AND SETUP GUIDE
GENERAL INFORMATION
The 6150RF Keypad/Transceiver is a combination unit incorp-
orating a normally-open relay output and the functions of:
• 6150 Fixed Addressable Keypad
• 5881M RF Receiver
• 5800TM Transmitter Module
The 6150RF Keypad/Transceiver may be used on any control
panel that supports the 6150 Keypad (e.g., VISTA-10P/10SE,
VISTA-15/15P, VISTA-20P/20SE/20HWSE, VISTA-40, VISTA-
50P, VISTA-128B/128BP, 4110DL, 4110XM, 4140XMP)
Wireless Features
The 6150RF supports the following:
• 5828/5828V wireless keypads.
• Up to 8 wireless keys locally (programmed directly into
6150RF) without occupying any zones supported by the
control panel.
• Button-type transmitters (e.g., 5804, 5804BD) for local
operation.
• A maximum of 16 transmitters programmed into any 5800
Series-supported control panel.
• Wireless keys with high-security (e.g., 5804E).
• RF jam detection when the receiver is enabled.
The 6150 provides the following:
• Low-battery indications for the local wireless keys.
• A nominal range of 200' for the RF transmitters (some
transmitters have a shorter range).
• Wireless key support for control panels that do not support
RF themselves (such as 4110DL).
U
UU
UL
LL
L
The 5802, 5802MN, 5802MN2, 5804, 5804BD, 5804BDV, 5804E,
5804WATCH, 5805BDV, 5814, 5816TEMP, 5819, 5819SBRS,
5819SWHS, and 5850 transmitters are not intended for UL
installations.
Programming Features
• Auto Enroll mode for programming wireless keys.
• Provides a method for deleting a serial number and re-
enrolling a new one in its place.
• Provides default settings for the wireless key functions.
Additional Features
• Sends status signals (Armed, Ready, etc.) to bi-directional
units such as 5804BDV, 5805BDV and 5828/5828V.
• Operates the on-board relay in conjunction with the receiver
(e.g., to trip a garage door opener).
Note: This particular feature is not intended for UL installations.
• Activates relays programmed into the control panel.
• Provides an End User mode to enable/disable local wireless
keys (e.g., if a user accidentally loses a wireless key). (Refer
to the 6150RF User Guide for this procedure.)
APPLICATION GUIDELINES
Use the following guidelines when planning an installation:
• Local wireless keys (wireless keys programmed directly into
the 6150RF) may be used regardless of whether the RF
receiver in the 6150RF is enabled or disabled.
• If using bi-directional devices, be sure to enable the
transmitter module in the 6150RF.
• If transmitters are programmed into the control panel, be
sure to enable the receiver. (Make sure you do not exceed
the number of receivers supported by the control panel.)
• If a local wireless key is programmed to arm/disarm or to
trigger a relay on the control panel, a user code must be
entered into the 6150RF. This user code must also be
programmed into the control panel.
• You must set the House ID only if you are using RF keypads
and/or bi-directional devices; AND the House ID Source is
the 6150RF (Local).
6150RF Application Guide
The following guide outlines how to program the wireless keys, RF receiver, and the House ID in the 6150RF for your installation.
* Two 6150RFs are needed for this application: one assigned to partition 1 and one assigned to partition 2.
** If using an RF keypad on only one partition, the 6150RF’s partition assignment must match the partition set in field 1*48.
*** If set for Local on a partition control, the 6150RF’s partition assignment must match the one programmed in the BD device.
Are you using
6150RF Programming Options
System Control Panel RF keys
beyond
system’s
capacity?
RF receivers
beyond
system’s
capacity?
RF keypads and/or Bi-
directional devices on
more than 1 partition?
Program
Wireless Keys
Into Receiver
Enable
House ID
Source***
4110DL, 4110XM, 4140XMP, VISTA-
20HWSE
N/A N/A N/A 6150RF OFF Local [0]
NO NO N/A System ON [1] System [1]
YES NO N/A 6150RF ON [1] System [1]
VISTA-10P, VISTA-10SE, VISTA-15,
VISTA-15P, VIA-30PSE
YES YES N/A 6150RF OFF [0] Local [0]
NO NO NO System ON [1] System [1]
YES NO NO 6150RF ON [1] System [1]
YES YES NO 6150RF OFF [0] Local [0]
NO YES YES* System OFF [0] Local [0]
VISTA-20SE, VISTA-20P
YES YES YES* 6150RF OFF [0] Local [0]
NO NO NO** System ON [1] System [1]
YES NO NO** 6150RF ON [1] System [1]
YES YES NO** 6150RF OFF [0] Local [0]
NO YES YES System OFF [0] Local [0]
VISTA-40, VISTA-50P, VISTA-128B,
VISTA-128BP
YES YES YES 6150RF OFF [0] Local [0]
SEE THE NEXT PAGE
FOR THE FCC INFO.
NOTE THIS WILL BE SOLD AS THE NEW '6150RF'
- 7 -
SPECIFICATIONS
Physical: 6-1/4” H x 4-7/8” W x 1” D
(158.75mm x 123.8mm x 25.4mm)
Wiring: Refer to Wiring Table on page 2
Range: 200' nominal
Frequency: 345 MHz
Voltage: 12VDC
Current: Standby 80mA
Backlighting on and
Sounder on 105mA
Relay: Normally-Open, 1A, 28VDC
Sounder: Piezo-electric (fire alarm is loud pulsing tone;
burglary/audible panic alarm is two tone
sound
FOR DETAILS ON THE LIMITATIONS OF THE ENTIRE ALARM SYSTEM, REFER TO THE INSTALLATION INSTRUCTIONS
FOR THE CONTROL PANEL WITH WHICH THIS DEVICE IS USED.
FCC ID: CFS8DL6150RFT
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
IC: 573F-6150RFT
FEDERAL COMMUNICATIONS COMMISSION (FCC) Part 15 STATEMENT
This equipment has been tested to FCC requirements and has been found acceptable for use. The FCC requires the following statement for your
information:
This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manu-
facturer's instructions, may cause interference to radio and television reception. It has been type tested and found to comply with the limits for a
Class B computing device in accordance with the specifications in Part 15 of FCC Rules, which are designed to provide reasonable protection
against such interference in a residential installation. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause interference to radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• If using an indoor antenna, have a quality outdoor antenna installed.
• Reorient the receiving antenna until interference is reduced or eliminated.
• Move the radio or television receiver away from the receiver/control.
• Move the antenna leads away from any wire runs to the receiver/control.
• Plug the receiver/control into a different outlet so that it and the radio or television receiver are on different branch circuits.
If necessary, the user should consult the dealer or an experienced radio/television technician for additional suggestions. The user or installer may
find the following booklet prepared by the Federal Communications Commission helpful: "Interference Handbook"
This booklet is available from the U.S. Government Printing Office, Washington, DC 20402.
The user shall not make any changes or modifications to the equipment unless authorized by the Installation Instructions or User's Manual.
Unauthorized changes or modifications could void the user's authority to operate the equipment.
