Ademco 8DLLYNXREN remote keypad User Manual K5963C

Honeywell International Inc. remote keypad K5963C

II with FCC statements

PRELIMINARY
/<1;56HULHV
6HFXULW\6\VWHPV
,QVWDOODWLRQDQG6HWXS*XLGHIRU
/<1;5/<1;5DQG/<1;5(1
AWAY
OFF
STAY
AUX
®
K5963 5/01
®
–3–
Table of Contents
SYSTEM FEATURES....................................................................................................................... 4
MOUNTING THE CONTROL ......................................................................................................... 5
WIRING CONNECTIONS................................................................................................................ 6
AC POWER AND BACKUP BATTERY ......................................................................................... 9
INSTALLING WIRELESS ZONES................................................................................................ 11
MECHANICS OF PROGRAMMING............................................................................................. 14
ZONE RESPONSE TYPE DEFINITIONS...................................................................................... 15
DATA FIELD DESCRIPTIONS ..................................................................................................... 17
*56 ENHANCED ZONE PROGRAMMING MODE ..................................................................... 24
*80 DEVICE PROGRAMMING MENU MODE ........................................................................... 29
*81 ZONE LIST MENU MODE ..................................................................................................... 32
*83 ENHANCED SEQUENTIAL MODE ...................................................................................... 33
*84 ASSIGN ZONE VOICE DESCRIPTORS................................................................................ 35
*85 RECORD CUSTOM VOICE DESCRIPTORS ........................................................................ 37
REMOTE PROGRAMMING/CONTROL (DOWNLOADING) .................................................... 38
SYSTEM OPERATION .................................................................................................................. 39
TESTING THE SYSTEM................................................................................................................ 44
SYSTEM COMMUNICATION ...................................................................................................... 45
TROUBLESHOOTING GUIDE...................................................................................................... 47
REGULATORY AGENCY STATEMENTS .................................................................................. 49
SPECIFICATIONS.......................................................................................................................... 50
LYNXR/LYNXR24 PROGRAMMING DEFAULT TABLES....................................................... 51
LYNXR-EN PROGRAMMING DEFAULT TABLES................................................................... 52
INDEX ............................................................................................................................................. 55
LIMITATIONS OF THIS SYSTEM STATEMENT....................................................................... 57
WARRANTY................................................................................................................................... 58
SUMMARY OF CONNECTIONS DIAGRAM.............................................................................. 59
–49–
Regulatory Agency Statements
UL NOTICE: This is a "Grade A" residential system.
FCC ID: CFS8DLLYNXREN
RADIO FREQUENCY EMISSIONS
Federal Communications Commission (FCC) Part 15
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Industry Canada
This Class B digital apparatus complies with Canadian ICES-003.
Cet Appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
TELEPHONE/MODEM INTERFACE
Federal Communications Commission (FCC) Part 68
This equipment complies with Part 68 of the FCC rules. On the front cover of this equipment is a label that contains the FCC registration number and
Ringer Equivalence Number (REN). You must provide this information to the telephone company when requested.
This equipment uses the following USOC jack: RJ31X
This equipment may not be used on telephone-company-provided coin service. Connection to party lines is subject to state tariffs. This equipment is
hearing-aid compatible.
Industry Canada
NOTICE: The Industry Canada Label identifies certified equipment. This certification means that the equipment meets telecommunications network
protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements document(s). The Department
does not guarantee the equipment will operate to the user’s satisfaction.
Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The
equipment must also be installed using an acceptable method of connection. The customer should be aware that compliance with the above conditions may
not prevent degradation of service in some situations.
Repairs to certified equipment should be coordinated by a representative designated by the supplier. Any repairs or alterations made by the user to this
equipment, or equipment malfunctions, may give the telecommunications company to request the user to disconnect the equipment.
Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines and internal metallic water pipe
system, if present, are connected together, This precaution may be particularly important in rural areas.
Caution: Users should not attempt to make such connections themselves but should contact appropriate electric inspection authority, or electrician, as
appropriate.
Ringer Equivalence Number Notice:
The Ringer Equivalence Number (REN) assigned to each terminal device provides an indication of the maximum number of terminals allowed to be
connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum
of the Ringer Equivalence Numbers of all the devices does not exceed 5.
