©ELATIONProfessional

1

www.elationlighting.com

VALUE FUNCTION

BASIC STAND EXTEND

PAN MOVEMENT [8 BIT]

0-255 PAN Movement 630/540

PAN FINE MOVEMENT [16 BIT]

0-255 Fine Control of PAN Movement

TILT MOVEMENT [8 BIT]

0-255 TILT Movement

TILT MOVEMENT [16 BIT]

0-255 Fine Control of TILT Movement

PAN CONTINUOUS MOVEMENT

0-127 NO FUNCTION

128-189 PAN Clockwise from FAST to SLOW

190-193 NO Rotation

194-255 PAN Counter-Clockwise from SLOW to FAST

TILT CONTINUOUS MOVEMENT

0-127 NO FUNCTION

128-189 TILT Clockwise from FAST to SLOW

190-193 NO Rotation

194-255 TILT Counter-Clockwise from SLOW to FAST

RED

0-255 0 to 100%

GREEN

0-255 0 to 100%

BLUE

0-255 0 to 100%

WHITE

0-255 0 to 100%

8 8 10

668

779

446

557

335

2

223

ELATION© ACL 360i™

DMX Channel Values / Functions Version 1 (20 DMX Channels)

Specifications are subject to change without any prior written notice.

MODE / CHANNEL

111

4

ELATION | ACL 360i™ | dmx traits

©ELATIONProfessional

2

www.elationlighting.com

VALUE FUNCTION

BASIC STAND EXTEND

ELATION© ACL 360i™

DMX Channel Values / Functions Version 1 (20 DMX Channels)

Specifications are subject to change without any prior written notice.

MODE / CHANNEL

COLOR PRESETS

0 OFF

1-4 COLOR PRESET 01

5-8 COLOR PRESET 02

9-12 COLOR PRESET 03

13-16 COLOR PRESET 04

17-20 COLOR PRESET 05

21-24 COLOR PRESET 06

25-28 COLOR PRESET 07

29-32 COLOR PRESET 08

33-36 COLOR PRESET 09

37-40 COLOR PRESET 10

41-44 COLOR PRESET 11

45-48 COLOR PRESET 12

49-52 COLOR PRESET 13

53-56 COLOR PRESET 14

57-60 COLOR PRESET 15

61-64 COLOR PRESET 16

65-68 COLOR PRESET 17

69-72 COLOR PRESET 18

73-76 COLOR PRESET 19

77-80 COLOR PRESET 20

81-84 COLOR PRESET 21

85-88 COLOR PRESET 22

89-92 COLOR PRESET 23

93-96 COLOR PRESET 24

97-100 COLOR PRESET 25

101-104 COLOR PRESET 26

105-108 COLOR PRESET 27

109-112 COLOR PRESET 28

113-116 COLOR PRESET 29

117-120 COLOR PRESET 30

121-124 COLOR PRESET 31

125-128 COLOR PRESET 32

9 9 11

©ELATIONProfessional

3

www.elationlighting.com

VALUE FUNCTION

BASIC STAND EXTEND

ELATION© ACL 360i™

DMX Channel Values / Functions Version 1 (20 DMX Channels)

Specifications are subject to change without any prior written notice.

MODE / CHANNEL

COLOR PRESETS [continued]

129-132 COLOR PRESET 33

133-136 COLOR PRESET 34

137-140 COLOR PRESET 35

141-144 COLOR PRESET 36

145-148 COLOR PRESET 37

149-152 COLOR PRESET 38

153-156 COLOR PRESET 39

157-160 COLOR PRESET 40

161-164 COLOR PRESET 41

165-168 COLOR PRESET 42

169-172 COLOR PRESET 43

173-176 COLOR PRESET 44

177-180 COLOR PRESET 45

181-184 COLOR PRESET 46

185-188 COLOR PRESET 47

189-192 COLOR PRESET 48

193-196 COLOR PRESET 49

197-200 COLOR PRESET 50

201-204 COLOR PRESET 51

205-208 COLOR PRESET 52

209-212 COLOR PRESET 53

213-216 COLOR PRESET 54

217-220 COLOR PRESET 55

221-224 COLOR PRESET 56

225-228 COLOR PRESET 57

229-232 COLOR PRESET 58

233-236 COLOR PRESET 59

237-240 COLOR PRESET 60

241-244 COLOR PRESET 61

245-248 COLOR PRESET 62

249-252 COLOR PRESET 63

253-255 COLOR PRESET 64

FLASH / STROBE

0-31 LED OFF

32-63 LED ON

64-95 Strobe Effect SLOW to FAST

96-127 LED ON

128-159 Pulse Effect in Sequences

160-191 Random Strobe Effect SLOW to FAST (Each Side x4)

192-223 Random Strobe Effect SLOW to FAST (Individual LEDs)

224-255 LED ON

DIMMER INTENSITY

0-255 Intensity 0 to 100%

DIMMER INTENSITY FINE

0-255

Dimmer Intensity FINE Adjustment

11 11 13

12 14

9 9 11

10 10 12

©ELATIONProfessional

4

www.elationlighting.com

VALUE FUNCTION

BASIC STAND EXTEND

ELATION© ACL 360i™

DMX Channel Values / Functions Version 1 (20 DMX Channels)

Specifications are subject to change without any prior written notice.

MODE / CHANNEL

COLOR MACROS

0 NO FUNCTION

1-14 LED OFF

15-30 COLOR MACRO 01

31-46 COLOR MACRO 02

47-62 COLOR MACRO 03

63-78 COLOR MACRO 04

79-94 COLOR MACRO 05

95-110 COLOR MACRO 06

111-126 COLOR MACRO 07

127-142 COLOR MACRO 08

143-158 COLOR MACRO 09

159-174 COLOR MACRO 10

175-190 COLOR MACRO 11

191-206 COLOR MACRO 12

207-222 COLOR MACRO 13

223-238 COLOR MACRO 14

239-255 COLOR MACRO CROSSFADE

COLOR MACRO SPEED

0-255 Auto Program Macro Speed SLOW to FAST

COLOR MACRO FADE

0-255 0-100%

DIMMING CURVE MODES

0-20 STANDARD

21-40 STAGE

41-60 TV

61-80 ARCHITECTURAL

81-100 THEATRE

101-255 Default to Unit Setting

PAN / TILT MOVEMENT SPEED

0-225 MAX to MIN SPEED

226-235 Blackout By Movement

236-255 NO FUNCTION

LAMP ON/OFF, RESET, INTERNAL PROGRAMS

0-79 Normal

80-84 ALL Motor Reset

85-99 NO FUNCTION

100-119 Internal Program 1 (scene1~8)

120-139 Internal Program 2 (scene9~16)

140-159 Internal Program 3 (scene17~24)

160-179 Internal Program 4 (scene25~32)

180-199 Internal Program 5 (scene33~40)

200-219 Internal Program 6 (scene41~48)

220-239 Internal Program 7 (scene49~56)

240-255 NO FUNCTION

16 18 20

16 18

15 17 19

12 13 15

161413

14 15 17
