Overview DT 34 2 Series

: Adj Overview Dt 34-2 Series Overview DT 34-2 Series binaries

Open the PDF directly: View PDF .
Page Count: 4

28 www.duratruss.com

DT 34/2-021

Code:1724100019

DT 34/2-025

Code:1723100034

DT 34/2-029

Code: 1724100020

DT 34/2-050

Code:1724100009

DT 34/2-075

Code: 1724100049

DT 34/2-100

Code: 1724100010

DT 34/2-150

Code: 1724100011

DT 34/2-200

Code: 1724100012

DT 34/2-250

Code: 1724100013

DT 34/2-300

Code: 1724100014

DT 34/2-350

Code: 1724100015

DT 34/2-400

Code: 1724100016

DT 34/2-450

Code: 1724100017

DT 34/2-500

Code: 1724100018

L290mm KG 2,5

L250mm KG 2,2

L210mm KG 2,0

KG 4,7

L750mm

KG 3,5

L500mm

KG 5,6

L1000mm

KG 8,3

L1500mm

KG 10,6

L2000mm

KG 12,8

L2500mm

KG 14,23000mm

L

KG 17,5

L3500mm

KG 18,6

L4000mm

KG 20,9

L4500mm

KG 23,0

L5000mm

Tube diameter: 50mmx2mm (2 x 0.08 inch)

Cross brace diameter: 20mmx2mm (0.8 x 0.08 inch)

Material: Alloy EN-AW 6082 T6 (AlMgSi1 T6)

8x

Connectors Set

incl. with each Truss part

4x 8x

TECHNICAL DATA

DT 34/2

W

H

220mm

290mm

400mm

194mm

220mm

257mm

290mm

353mm

400mm

400mm

400mm

580mm

148mm

290mm

290mm220mm

220mm

530mm

580mm

Compatible to DT 34 | DT 34/3 | D34/4.

The dierence in the DT 34/X series is the pipe wall

thickness and the resulting load.

DT34/2 Tube diameter: 50mmx2mm (2 x 0.08 inch)

50mm

ø

LOAD CHART - EN-1090

Length (m) 2 4 6 8 10 12

Point load (kg) 1919 987 670 507 394 308

Deection (mm) 2,6 11 25,6 46,9 73,6 103,6

Distrib. load (kg/m) 1422 493 223 127 79 51

Deection (mm) 2,4 13,7 31,8 58 90,5 126,4

C

o

l

o

r

y

o

u

r

t

r

u

s

s

i

n

e

v

e

r

y

R

A

L

c

o

l

o

r

Powder

Coating

LOAD CHART - EN-1090

29

specications subject to change without notice

45° 6,9

KG

2 way corner 45°

W

LH

1000mm 1000mm 290mm

60° 7,4

KG

2 way corner 60°

W

LH

1000mm 1000mm 290mm

90° 4,5

KG

2 way corner 90°

W

LH

500mm 500mm 290mm

DT 34/2-C19-L45

CODE: 1724200012

DT 34/2-C41-X

CODE: 1724200020

90° 7,4

KG

4 way X-joint

W

LH

500mm 500mm 290mm

DT 34/2-C23-L135

CODE: 1724200016

135° 5,2

KG

2 way corner 135°

W

LC

500mm 500mm 290mm

DT 34/2-C30R-L90

CODE: 1724300021

90° 5,9

KG

3 way rounded Corner 90° + down

W

LH

500mm 500mm 500mm

DT 34/2-C20-L60

CODE: 1724200013

DT 34/2-C51-XD

CODE: 1724200021

90° 8,8

KG

5 way X-joint + down

W

LH

500mm 500mm 500mm

DT 34/2-C30-LD90

CODE: 1724200017

90° 5,9

KG

3 way corner 90°

W

LH

500mm 500mm 500mm

DT 34/2-C21-L90

CODE: 1724200014

DT 34/2-C61

CODE: 1724200022

90° 10,2

KG

6 way corner

W

LH

500mm 500mm 500mm

DT 34/2-T35-T

CODE: 1724200018

90° 5,9

KG

3 way T-joint

W

LH

500mm 500mm 290mm

120° 5,1

KG

2 way corner 120°

W

LH

500mm 500mm 290mm

DT 34/2-C22-L120

CODE: 1724200015

DT 34/2-C21R-L90

CODE: 1724200052

90° 4,5

KG

2 way rounded Corner 90°

W

LH

500mm 500mm 290mm

DT 34/2-T40-TD

CODE: 1724200019

90° 7,4

KG

4 way T-joint + down

W

LH

500mm 500mm 500mm

FOUR TUBE

SYSTEM

30 www.duratruss.com

1,5

KG

wall plate female

W

LH

305mm 305mm 5mm

5,6

KG

H290mm

1,5

KG

base plate female

W

LH

305mm 305mm 5mm

1,5

KG

wall plate male

W

LH

305mm 305mm 5mm

DT 34-WPF

CODE: 1724400004

DT 20/40-SAFETY CLIP

CODE: 1744000010

for DT 22 -> 44

DT 34-BOX CORNER

CODE: 1724200024

incl. 8 half connectors

W

L290mm 290mm

DT 30/40-STEEL PIN-M8

CODE: 1749000007

for DT 31 -> 44

DT 34-BPF

CODE: 1724400003

DT 30/40-CC

CODE: 1723400008

for DT 31 -> 44

DT 30/40-HCBC

CODE: 1724200025

incl. M12 bolt, steel pin, clip for

box corner DT 34+44 M12

DT CORNER BOOK

CODE: 1723400019

90° 2,5

KG

for DT 33 & DT 34

W

LH

500mm 500mm 220mm

DT 34-WPM

CODE: 1724400067

DT 30/40-STEEL PIN

CODE: 1749000006

for DT 31 -> 44

DT 30/40-FCBC

CODE: 1723400014

for box corner DT 34 female connector

DT TRUSS CARRIER-29/60

CODE: 1749000001

for DT 31 -> 34

DT 30/40-TERMINAL PIECE

CODE: 1749000008

for DT 31 -> 44

DT 34-NIVELER FOOT

CODE: 1733000045

1,5

KG

base plate male

W

LH

305mm 305mm 5mm

DT 34-BPM

CODE: 1724400002

DT 30/40-SHORT PIN

CODE: 1749000013

for DT 31 -> 44

DT 34/2

31

specications subject to change without notice

L

63,0

KG

to store 10x BPS 8080

W

LH

958mm 958mm 819mm

DT DOLLY-BPS 8080

CODE: 1720000014

39,0

KG

to store 4x BPS 650

W

LH

725mm 500mm 725mm

DT DOLLY-BPS 650

CODE: 1720000015

DT 34/2-CIRCLE

Model | Construction Code Number of parts:

DT 34/2-Circle Part-2m-90dgr 1724300014 1 circle is 4 parts

DT 34/2-Circle Part-3m-90dgr 1724300015 1 circle is 4 parts

DT 34/2-Circle Part-4m-90dgr 1724300016 1 circle is 4 parts

DT 34/2-Circle Part-5m-45dgr 1724300017 1 circle is 8 parts

DT 34/2-Circle Part-6m-45dgr 1724300018 1 circle is 8 parts

DT 34/2-Circle Part-7m-45dgr 1724300019 1 circle is 8 parts

DT 34/2-Circle Part-8m-45dgr 1724300020 1 circle is 8 parts

FOUR TUBE

SYSTEM

37,5

KG

for DT 33, 34, 43, 44

Material: steel | incl. Half connectors

W

LH

650mm 650mm 15mm

DT BPS-650

CODE: 1720000003

DT TRUSS ADAPTER-30/40

CODE: 1745000047

Truss Adapter for DT 30-40

Max. Load: 1000 Kg

8,5

KG

for DT 33 & DT34

max. load capacity: 500 Kg

W H

250mm 310mm 400mm

DT 30-WALL MOUNT

CODE: 1723400029

L

DT BPS-8080

CODE: 1720000004

72,5

KG

for DT 33, 34, 43, 44

Material: steel | incl. Half connectors

W

LH

800mm 800mm 15mm
