Advance Clock 0003251 0.6" LED Desk Clock with Fluorescent Lamp User Manual 3251 4571 74 ins sheet

Advance Clock Co. (Far East) Ltd. 0.6" LED Desk Clock with Fluorescent Lamp 3251 4571 74 ins sheet

User Manual

Digital Alarm Clock
Model Nos: 3251, 4571 - 4574
OWNER'S MANUAL
© 2004 Advance Clock Co., Ltd.
CONTROL LOCATIONS
1.  ALARM ON/OFF SWITCH
2. DESK LAMP ON/OFF SWITCH
3.  MINUTE BUTTON
4.  HOUR BUTTON
5.  SNOOZE BUTTON
6. TIME BUTTON
7. ALARM BUTTON
8. ARMS
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B ISM equipment, pursuant to Part 18 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-  Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio TV technician for help.
Note: This product may cause interference to radio equipment and should not be
installed near maritime safety communications equipment or other critical navigation or
communication equipment operating between 0.45-30 MHz.
POWER SUPPLY
Your clock is designed to operate on alternating 120 Volts 60 Hz power supply.
Fluorescent lamp type 6" inch F4T5D.
P.M. INDICATOR
A glowing dot appears in the lower left hand corner of the display indicating that the time shown is P.M.
ALARM ON INDICATOR
A glowing dot appears in the upper left hand corner of the display indicating that the alarm has been set.
SETTING THE TIME
Move the ALARM ON/OFF switch (1) to the "OFF" position. To set the time, press and hold the TIME button
(6) and HOUR button (4) to advance the hour display. Then press and hold the TIME button (6) and the
MINUTE button (3) to advance the minutes until the correct time is displayed. Be sure to set it correctly in the
AM or PM mode. The PM indicator will be "ON" when the clock is reading PM time and "OFF" when reading
AM time.
SETTING THE ALARM
Move the ALARM ON/OFF switch (1) to the "OFF" position. To set the alarm, press and hold the ALARM
button (7) and the HOUR button (4) to advance the hour display. Then press and hold the ALARM button (7)
and the MINUTE button (3) until the correct alarm time is displayed. Be sure to set it correctly in the AM or PM
mode.
ALARM OPERATION
Move the ALARM ON/OFF switch (1) to "ON" position. The alarm ON indicator will light and the alarm will
sound at the preset alarm time. To deactivate the alarm, move ALARM ON/OFF switch (1) to the "OFF"
position.
SNOOZE REPEAT ALARM OPERATION
When the alarm sounds, simply press the control cover or the SNOOZE button (5) to deactivate the alarm.
The alarm will activate again after 9 minutes. To completely deactivate the alarm, move the ALARM ON/OFF
switch (1) to the "OFF" position.
DESK LAMP FUNCTION
Move the LIGHT ON/OFF switch (2) to the "ON" position. The fluorescent lamp will illuminate. To switch off the
light, turn off LIGHT ON/OFF switch (2) to the "OFF" position. Extend and rotate the ARMS (8) to the desired
position.
BATTERY BACK UP
In the event of a power failure, this unit will automatically switch to a battery stand-by circuit when a battery is
installed. Open the BATTERY COMPARTMENT on the bottom of the unit and install a 9-volt battery. Under
battery operation, the clock will keep the time running and the alarm will sound at the preset time. Only the
clock display will not light to save battery energy. If you have a long power failure you may need to make a
slight adjustment to the clock time after AC power returns. The clock uses an internal battery powered clock
circuit that is less accurate than the power line frequency. Just follow Setting The Time instructions, the alarm
time will remain correct.
CLOCK COMPANY LTD.
ETL LISTED
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
¡
¡
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user of the presence of uninsulated "dangerous
voltage" within the product's enclosure: that may be of sufficient
magnitude to constitute a risk of electric shock to person.
The exclamation point within an equilateral triangle is intended to alert
the user of the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
CAUTION:
TO PREVENT ELECTRIC SHOCK DO NOT USE THIS
(POLARIZED) PLUG WITH AN EXTENSION CORD, RECEPTACLE, OR
OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO
PREVENT BLADE EXPOSURE.
ATTENTION:
POUR PRÉVENIR LES CHOCS ÉLECTRIQUES NE PAS
UTILISER CETTE FICHE POLARISÉE AVEC UN PROLONGATEUR, UNE
PRISE DE COURANT, OU UNE AUTRE SORTIE DE COURANT SAUF SI
LES LAMES PEUVENT ÉTRE INSÉRÉES À FOND SANS EN LAISSER
AUCUNE PARTIE À DÉCOUVERT.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC ELECTRIQUE
NE PAS OUVRIR
CUS
CM
34 5 6 7
MIN HOUR SNOOZE TIME ALARM
ALARM
SNOOZE
PM
A
L
A
R
M
L
I
G
H
T
O
F
F
O
N
1
3
2
8
O
N
O
F
F
CONTROL COVER
