Advance Security T49 Car Alarm Transmitter User Manual CA Elite 6 series Install rev A 4 13 09

Advance Security Inc Car Alarm Transmitter CA Elite 6 series Install rev A 4 13 09

user manual

1
2010 Audiovox Electronics Corporation. All rights reserved.
PROFESSIONAL
SERIES
CATX4
Owners Guide
IMPORTANT NOTE: The operation of the Security and Convenience System as described in this manual is
applicable to most vehicles. However, due to the configuration of some vehicles, some functions AND/OR
SAFETY PRECAUTIONS may not apply. Please see your installing dealer for more information.
Vehicle Security and
Keyless Entry System
2 2010 Audiovox Electronics Corporation. All rights reserved.
Table of Contents
Using Your Remote Control ............................................................... 3
Arming the Security System ............................................................ 3
Passive Arming Bypass ................................................................... 3
Bypassing the Shock Sensor .......................................................... 3
Hidden Alarm Function...................................................................... 3
Disarming the Security System........................................................ 3
Valet Mode ........................................................................................ 4
Manually Overriding the Security System ....................................... 4
Eliminating Arm/Disarm Notification Chirps ...................................... 4
Activating Trunk Release (optional) ................................................ 4
Using the Car Finder Feature ........................................................... 4
Using the Personal Protection Alarm ............................................... 5
Car Jack Mode .................................................................................. 5
LED and Siren/Horn Indications ......................................................... 6
Transmitter Button Functions ........................................................... 7
Replacing Remote Control Batteries ............................................... 7
Warranty Information........................................................................... 8
3
2010 Audiovox Electronics Corporation. All rights reserved.
Arming the Security System
To arm the system, exit the vehicle, close all doors, then press the button. The
parking lights will flash 2 times, indicating the system is armed, has locked the
doors (if equipped and connected) and activated the starter disable feature. The
LED status indicator will blink steadily, once per second.
NOTE: The system is defaulted with Silent Choice enabled, which requires a
second press of the button to activate an audible arming response from the
vehicle.
Passive Arming Bypass
If passive arming is enabled on your system, while the system is disarmed, press
2 times within 5 seconds, the system will respond with 1 chirp and the LED will
turn on. The security system will remain in this temporally bypassed state for as
long as you wish. To exit passive bypass, press the or button and the system
will return to normal status.
Bypassing The Shock Sensor
To arm the system and ignore the shock sensor press button, then within 5
seconds press + , the system will respond with 1 long chirp.
NOTE: The system will only change the shock sensor setting for one arm cycle
and will be defaulted back to normal operation the next time the system is armed.
Hidden Alarm Function
Press the button first, within 3 seconds press the button to activate the
hidden alarm function. The security system will arm with “Hidden Alarm Function”
in which the siren / horn will be silenced if the system is triggered.
Disarming the Security System
To disarm the system press the button. The parking lights will flash 1 time,
indicating the system is disarmed and has unlocked the doors (if equipped and
connected).
NOTE: The system is defaulted with Silent Choice enabled, which requires a
second press of the button to activate an audible arming response from the
vehicle.
*Throughout this manual, ‘press’ refers to pressing for less than 1 second; ‘press and hold’ refers to pressing for more
than 2 seconds.
Using Your Remote Control
4 2010 Audiovox Electronics Corporation. All rights reserved.
Valet Mode
To engage valet mode:
1. Turn the ignition key to the ON position.
2. Press and hold the emergency override button.
3. The LED will light solid indicating that the system is in valet mode.
When valet mode is activated the status LED will light solid, and all security and
remote start functions will be disabled.
To disengage valet mode:
1. Turn the ignition key to the ON position.
2. Press and release the emergency override button.
3. The LED will turn off indicating that the system has exited valet mode.
Manually Overriding the Security System
Your system can be disarmed without the use of the transmitter. This is necessary,
since you will need the ability to operate your vehicle if the transmitter is lost or its
battery fails. To by-pass the alarm system;
1. Open the vehicle door. The alarm will sound.
2. Turn the ignition key to the ON position.
3. Within 5 seconds, press and release the valet push button switch.
The alarm system will stop sounding and enter the (by-passed) mode. You can
now start and operate the vehicle normally.
Eliminating Arm / Disarm Notification Chirps
System ARM/DISARM chirps can be toggled ON or OFF without entering the
programming feature banks.
1. Turn the ignition ON then OFF.
2. Press and release the valet/programming button 3 times. The system
will respond with 1 chirp for ON or 2 chirps for OFF.
Activating the Trunk Release Feature (Optional)
If this feature is enabled on your system, pressing and holding the button for 3
seconds will open the vehicle’s trunk or hatch.
Using the Progressive Car Finder Feature
Press the button to locate your vehicle. The system will sound 5 times at low
volume, increasing in volume each time the button is pressed.
5
2010 Audiovox Electronics Corporation. All rights reserved.
Using the Personal Protection Alarm (Panic)
Press and hold the button for 3 seconds to activate the personal protection
alarm. During panic mode, the normal function of the transmitter buttons will be
suspended. The transmitter’s and buttons can be used to lock and unlock the
door (if the option is installed). To stop the alarm, press and hold the button on
the transmitter again for 3 seconds. The system will automatically stop after 30
seconds.
Car Jack Mode
This feature must be turned on in system programming, please consult your
installing dealer.
Triggering Car Jack mode: While the ignition is ON and press and hold + for 2
seconds, the parking lights will flash 1 time and the system will act as follows;
1. 50 seconds after being triggered the siren will chirp for 15 seconds,
during this 15 seconds you will be alerted to push the valet button to
turn off Car Jack mode. If Car Jack mode is not turned off at this time it
will advance to the next step.
2. Following the 15 second chirps (total time now 65 seconds) the siren
will go into full sound and the parking lights will start flashing.
3. 90 seconds after trigger in, addition to the siren and parking lights, the
system will activate the starter kill. THE SYSTEM WILL REMAIN IN THIS
STATE UNTIL THE BATTERY IS DEPLETED.
OVERRIDE THE SYSTEM TO TURN OFF CAR JACK MODE: Turn the ignition OFF
then On and press the valet button within 10 seconds.
6 2010 Audiovox Electronics Corporation. All rights reserved.
LED and Siren/Horn Indications
LED Display Indications
LED Function
OFF DISARMED
SLOW FLASH ARMED
FAST FLASH PASSIVE ARMING
ON (SOLID) VALET MODE
2 FLASH... PAUSE ZONE 2 TRIGGER, HOOD/TRUNK
3 FLASH... PAUSE ZONE 3 TRIGGER, DOOR
4 FLASH... PAUSE ZONE 4 TRIGGER, SHOCK
5 FLASH... PAUSE ZONE 5 TRIGGER, IGNITION
Siren/Horn Indications
Chirps Function
1 DISARM
2 ARM
3 DOOR AJAR UPON ARMING
4 DISARM / TRIGGERED
5 CAR LOCATOR
Parking Light Flash Indications
Flashes Function
1 DISARM
2 ARM
3 DISARM / TRIGGERED
5 CAR LOCATOR
7
2010 Audiovox Electronics Corporation. All rights reserved.
Transmitter Button Functions
Replacing Remote Control Batteries
1-Way 4 Button Remote Control:
The batteries (model CR2016) inside each remote control should last approximately
1 year under normal use. When the batteries become weak you will notice the
remote control range (the distance from the vehicle the remote control will work)
deteriorate and the small LED on the remote control will dim. To replace the remote
control batteries:
1. Unsnap and disassemble the halves of the remote control.
2. Remove the old batteries, observing the +/- symbols on the batteries and
replace with new CR2016 batteries.
3. Reassemble the halves of the remote control.
4. Test operation of the remote control.
8 2010 Audiovox Electronics Corporation. All rights reserved.
Code Systems, Inc. Limited Lifetime Warranty
Code Systems Inc. (“CODE”) warrants to the ORIGINAL PURCHASER of this CODE
vehicle security product (the “Product”), purchased from an authorized CODE dealer, that (except as
provided below) should this Product under normal use and conditions, be proven defective in
material or workmanship DURING THE LIFETIME OF THE VEHICLE IN WHICH IT WAS ORIGI-
NALLY INSTALLED, such defect(s) will be repaired or replaced (at CODE’s option) without charge for
parts directly related to repairs of the defect(s).
Switches, indicator lights, and transmitter cases are similarly warranted to the original
purchaser for a period of one (1) year from the date of purchase of the Product.
CODE accessories, sold separately, are covered by the applicable warranty accompa-
nying the accessory.
This warranty is non-transferable, non-assignable and is voided when: (1) the Product is
removed from the vehicle in which it was originally installed; or (2) the vehicle in which the Product
was originally installed is transferred to another party.
This warranty does not apply to any product damaged by accident, physical or electrical
abuse, improper installation, alteration, or use contrary to its intended function, fire, flood, or other
natural acts.
In order for the Product to be repaired or replaced under the terms of this warranty, the
defective Product must be returned to an authorized CODE dealer and accompanied by a copy of
the retail sales receipt. The date of purchase and year, make and model of the vehicle in which the
Product was originally installed must be clearly indicated on the sales receipt.
This warranty is exclusive and CODE MAKES NO OTHER WARRANTIES EXPRESSED
OR IMPLIED. ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MER-
CHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE
DURATION OF THIS WRITTEN WARRANTY. IN NO CASE SHALL CODE BE LIABLE FOR ANY
CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER WAR-
RANTY, EXPRESS OR IMPLIED, WHATSOEVER.
CODE does not warrant that the Product cannot be compromised or circumvented. THE EXTENT OF
CODE’S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT
PROVIDED ABOVE AND, IN NO EVENT SHALL CODE’S LIABILITY EXCEED THE PURCHASE
PRICE PAID BY THE ORIGINAL PURCHASER OF THE PRODUCT WITHOUT INSTALLATION
LABOR.
Some states do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitation may not apply to you. This warranty gives you specific legal
rights and you may also have other rights which vary from state to state
9
2010 Audiovox Electronics Corporation. All rights reserved.
10 2010 Audiovox Electronics Corporation. All rights reserved.
Audiovox Electronics Corporation.
Customer Service 1-800-421-3209
FCC COMPLIANCE
This device complies with Part 15 of the FCC rules and with RSS-210 of
Industry Canada. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including any interference
that may cause undesired operation.
Warning!
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
