Users Manual
![](/img.php?id=2731347&img=bg1.png)
.
TO REMOTE START THE VEHICLE:
When you want to start your vehicle,
• Press on the two way or button on the standard transmitter. Press Twice
if the unit is programmed for safety start
• The parking light will activate to indicate the remote start received the signal.
• The engine will start in approximately 5 seconds.
• Once the engine is running, after couple seconds the parking lights will turn on
and the climate controls will activate and adjust the vehicle’s interior
temperature to your preset setting.
• The vehicle will run for a programmable 5 to 30 minute cycle before shutting
down.
NOTE: The Remote Start Unit will not start the vehicle if any one of the following
conditions exists:
1. The hood is opened.
2. The brake pedal is pressed.
3. The optional remote start enable toggle is switched to the “OFF” position. (If
installed)
4. The gear selector is in any gear other then “PARK” or “NEUTRAL”.
SAFE START (Child safety mode)
Factory default is set to press the or button once on the transmitter to start the
vehicle. Safety Start feature can be programmed to eliminate an accidental remote start:
1. The user presses the transmitter or buttons twice within 3 seconds to start the
vehicle.
NOTE: Contact your installing dealer to de-activate this feature for one push start
OPERATE THE VEHICLE WHILE RUNNING FROM THE REMOTE START:
To operate the vehicle while the engine is running from the remote start,
• Insert the ignition key and turn it to “ON” (not the start) position.
• Press the brake pedal.
Note: If the brake pedal is pressed before the key is in the ON position, the engine will
shut down.
TEMPORARY STOP FEATURE:
This feature allows the vehicle to remain running after the key has been removed from
the ignition. This feature is useful for occasions when you wish to exit and lock the
vehicle for short periods of time, but would like to leave the motor running and the
climate control on.
• Before turning off the engine, press the or button on the transmitter and
the LED indicator will flash 3 times to confirm enter.
• Turn the ignition key to OFF position. (The engine will stay running.)
• The engine will run until the pre-programmed time elapsed or shutdown input is
received.
TO TURN OFF THE REMOTE START:
When the engine is running (by remote start), if you want to stop it,
Press or button TWICE on the remote transmitter under the remote start
mode.
.
Press the brake pedal
The vehicle will shut down and turn off the parking light to indicate the engine
has stopped.
SHUT-DOWN INPUT FOR REMOTE STARTER:
If any of the following conditions exist while the system is operating, the
engine will not start or will shut down immediately:
1. The hood is opened.
2. The brake pedal is pressed.
3. Engine is over-revved. {“Tachometer checking type” only}
4. The pre-programmed run time (5 /10 / 20 / 30 minutes) has elapsed.
5. Press or button twice on the remote transmitter under remote
start mode.
6. The vehicle refused to start running after {3} unsuccessful attempts.
E
ncore Automotive Systems, LLC.
All rights reserved
.
For Warranty information, Please go to www.encoreautomotivesystems.com and
download the complete user’s manual. For customer service, please call us toll free @
(855) GO-ENCORE 855.463.6267. 8:00-5:00 PST Thanks for your purchase!
ENCORE
LIMITED LIFETIME WARRANTY PROVISIONS
( U.S. ,Continental U.S. and Canada Only)
1. Encore Automotive Systems LLC. WARRANTS that this new unit has been
thoroughly inspected and tested at the factory prior to delivery. Your Encore
equipment is guaranteed for “life” to the original purchaser/user of the
equipment and the original vehicle in which it was installed by an authorized
installer under the following conditions: If the product proves defective
(according to Encore’s testing) within the first year, the defective unit may be
exchanged or repaired free of charge. “Proof of Purchase” (dated sales receipt)
must accompany all warranty returns; otherwise, your return will be rejected
and sent back. After one (1) year, the purchaser should ship the unit prepaid to
Encore with a money order in the amount of $30.00 to cover shipping and
handling charges
2. Exclusion to the Limited Lifetime Warranty Provision: All two-way LCD and two-
way OLED remote transceivers are excluded from the Limited Lifetime Warranty
noted in paragraph no.1. All two-way LCD and two-way OLED remote
transceivers are guaranteed to the original purchaser for a period of one year
from date of purchase. If the product proves to be defective within the first
year, the defective unit may be exchanged or repaired free of charge. All other
provisions stated on this card apply.
3. This WARRANTY will be considered void if the equipment has been misused,
neglected, improperly serviced or installed, altered, dropped or damaged by
water, contrary to the Encore OPERATIONS MANUAL. Or, if used with
accessories not approved by Encore, which may have contributed to the defect.
See note below regarding product installation**.
4. The purchaser’s remedies under this WARRANTY shall be limited to the repair or
replacement of electronic components only. THE FOLLOWING IS NOT
COVERED: Damages or deterioration to cases, batteries, covers and cabinets;
the cost of repairs, replacement and labor of which shall be borne by the
purchaser even if occurring during the WARRANTY period.
5. Any equipment or parts which are claimed to be defective under this
WARRANTY must be sent to the Encore Service center with “proof of purchase”
at the purchaser’s expense prior to such return, a Return Authorization Number
needs to be obtained. Encore will return the equipment, charges prepaid.
Warranty Service can be provided through the dealer where the equipment is
originally purchased.
6. Any unexpired WARRANTY shall be applicable to equipment and parts in the
possession of the original purchaser only.
7. THIS WARRANTY IS IN LIEU OF ANY AND ALL OTHER WARRANTIES, EXPRESSED
OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
8. Encore shall not be liable, under the foregoing WARRANTIES or otherwise, for:
Any personal injury or property damage of any kind to the purchaser or
property, its employees or agents or anyone else whomsoever resulting directly
or indirectly from the use or presence of the equipment or parts; Consequential
damages of any kind; any inability of the purchaser to use the equipment.
**IMPORTANT NOTE: Any damages resulting from an installation performed by
anyone other than a professional installation technician authorized by Encore will
void the product’s Limited Lifetime Warranty.
Remote Start Operation:
BATTERY CHANGING:
Depending on the usage, the remote batteries should be changed at least
once a year.
The 1-way remote, (E-7s) is powered by a pair of 3V, CR2016 batteries.
These batteries are available at most locations batteries are sold and can
be replaced by the user.
The Two-way (E1S Two Way) remote is powered by one CR-2032 battery
These batteries are available at most locations batteries are sold and can
be replaced by the user. Typical battery life is 6 Months
![](/img.php?id=2731347&img=bg2.png)
Two-way remote transmitter operation
E7s
Transmitter
Button
System Function Remark
Lock Doors
Panic Press & hold for 3 sec.
Unlock Doors
Trunk Release (Channel 3) Press and Hold for 2 seconds
Activate The Remote Start Push once
Stop remote start operation ** Push Twice
+ Switching code For 2nd Car
Operation.
PRESS BTN ON
Transmitter Action LED ON Transmit
( RED )
LED ON
Receive ( Green )
Transmitter
sound
SIREN (CAR)
CHIRP
+ LOCK 1 SHORT
FLASH LED ON 1 SEC.
1 1
UNLOCK
1 SHORT
FLASH LED ON 1 SEC.
2 2
START
ON
1 SHORT
FLASH FLASH 2 TIMES
4 SHORT
CHIRPS N/A
+ START
OFF
1 SHORT
FLASH FLASH 3 TIMES
3 LONG CHIRPS
N/A
(PRESS & HOLD) TRUNK 1 SHORT
FLASH N/A N/A N/A
The LED on the two way remote will flash every 3 seconds while the vehicle is running
QUICK START
USERS
GUIDE
If you do not understand any part of this quick start users
manual and would like the complete version, Please visit
our web site @ www.encoreautomotivesystems.com
E
ncore
E
-
5
Encore E
-
7
s
Remote
Transmitter
REMOTE TRANSMITTER OPERATION:
One Way Remote
CHIRP INDICATORS:
PARKING LIGHT:
Chirp Function Parking light Function
1 chirp Lock 1 flash Lock
2 chirps Unlock 2 flashes Unlock
ON Running on remote start
LED if installed
LED Function
Off Unlock
Slow Flash Locked
On (Solid) Valet Mode
PROGRAMMING TRANSMITTERS:
Note: This mode will only retain the last 4 remote transmitters programmed. If the transmitter
memory is exceeded, the security system will start deleting transmitters from memory in
chronological order.
1. Turn the Ignition 'switch ‘OFF/ON’ 4 TIMES and stay in ON position.
“Within 15 seconds”.
2. Push the Valet switch 4 times and hold it on the 4th push until a long chirp is heard then release
the valet switch. You are now in the Transmitter programming mode.
3. Press and hold any button of the transmitter until the siren responds with a confirming chirp,
indicating the signal has been stored into memory.
4. If you have additional transmitters (up to 4) that need to be programmed, repeat step 3 for each
transmitter.
Exit: Turn Ignition to 'OFF' position, or leave it for 15 seconds. 3 long chirps & 3 parking light flashes
will confirm exit.
For Customer service, Please call (855) Go-Encore
855-463-6267, 8:00-5:00 PST
WARNINGS:
As with any product that performs automatic functions, there are certain safety precautions
that you must practice and be aware of.
•Keep the transmitter out of children’s reach.
•Do not leave anyone in the vehicle while running on remote control.
•Alert servicing personnel that the vehicle can be started automatically.
•Do not start the vehicle by remote while it’s in an enclosed area or garage.
•Always apply the parking brake and lock the vehicle as you exit the vehicle.
•The vehicle windows must be rolled up.
•Should the unit malfunction, disconnect the fuse until the problem is corrected.
•The use and operations of this system is the sole responsibility of the operator.
•Some areas may have local ordinances that prohibit leaving a vehicle running on public
streets.
•
THIS DEVISE CANNOT BE USED ON ANY STANDARD TRANSMISSION VEHICLE.
FOR AUTOMATIC TRANSMISSIONS ONLY!
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:(1) This device may not cause harmful interference, and (2)
This device must accept any interference received, including interference that may
cause undesired operation.
ACTIVE LOCK:
1. Press button or + on the two way transmitter.
2. The horn, if installed will chirp once and parking lights will flash once
indicating that the system is now active. The vehicle doors will lock upon
activating when interfaced with the keyless entry system.
ACTIVE UNLOCK:
1. Press button on the transmitter.
2. The horn will chirp twice and parking light will flash twice to indicating that
the keyless system is now unlocked. The vehicle doors will unlock.
DEACTIVATING WITHOUT A TRANSMITTER
The Override function may be used if the remote transmitter is lost or
inoperative.
1. Enter the vehicle and turn the ignition switch to ‘ON’ position.
2. Within 10 seconds push and release the antenna mounted valet switch
VALET MODE:
The valet switch allows you to temporarily by-pass all system function,
eliminating the need to hand your transmitter to parking attendants or garage
mechanics. When the system is in valet mode, and remote start functions are
bypassed, Enter Valet Mode:
1. Under Unlock condition, turn the ignition to “ON” position.
2. Press and hold the antenna mounted valet switch for 2 seconds until the
LED turns on. The LED will remain on as long as the system is in ‘valet
mode’.
Exit Valet Mode:
1. Return to normal operation, turn ignition ‘on’.
2. Press and hold valet switch for 2 seconds, The LED will turn off
Indicating that the system has exited the valet mode.
IGNITION CONTROL DOOR LOCKS.
If the vehicle’s door locks have been interfaced to the security system, the
system will automatically lock the vehicle’s doors when the ignition is turned
“ON” and /or unlock the vehicle’s doors when the ignition is turned “OFF”.
TRUNK RELEASE (Additional Installation Required)
Press and hold the or button on the two way transmitter for 3 seconds to
activate the trunk release or other electric devices.
PANIC FUNCTION: One way remote ONLY
The transmitter can be used as a remote panic switch to manually trigger the system
in case of emergency.
1. Press and hold the button for 3 second. The unit will immediately sound.
2. During panic mode, the normal function of this transmitter button will be disabled.
The transmitter and buttons can be used to lock and unlock the door (if the
option is installed).
3. To stop the alarm, press and hold the transmitter button on the transmitter again for
3 seconds.
.
4. If the button is not pressed, the system will stop after 30 seconds.
THIS PRODUCT IS DESIGNED FOR PROFESSIONAL
INSTALLATION ONLY
Encore Two way
E1S (Two way)
