Advance Security TR58 Remote Control User Manual
Advance Security Inc Remote Control
User Manual
12014 Voxx Electronics Corporation. All rights reserved.
PROFESSIONAL
SERIES
Owner’s Guide
For Models:
ca6554
IMPORTANT NOTE: The operation of the Security and Convenience System as described in this manual is
applicable to most vehicles. However, due to the conguration of some vehicles, some functions AND/OR
SAFETY PRECAUTIONS may not apply. Please see your installing dealer for more information.
Deluxe Vehicle Security and
Remote Start System with 2 Way Conrming
LCD Remote Control
2ca6554 Owners revA
Table of Contents
Using Your Remote Control .................................................................... 3
Arming the Security System .............................................................. 3
Passive Arming Bypass .....................................................................3
Bypassing the Shock Sensor ............................................................ 3
Hidden Alarm Function ...................................................................... 3
Disarming the Security System ......................................................... 3
Two Stage Door Unlock (optional) .....................................................4
Activating Trunk Release (optional) ...................................................4
Activating Optional AUX 1 (optional) .................................................4
Entering AUX Mode and Activating Additional AUX Outputs ............. 4
Using the Progressive Car Finder Feature ........................................ 5
Using the Personal Protection Alarm .................................................5
Programmed Transmitter Notication ................................................5
Valet Mode ........................................................................................5
Eliminating Arm / Disarm Notication Chirps ..................................... 5
Manually Overriding the Security System ......................................... 6
Car Jack Mode .................................................................................. 6
Using Your Remote Vehicle Starter ....................................................... 7
Remote Start Ready Mode ................................................................ 7
Cancelling Remote Start Ready Mode .............................................. 7
Remote Starting Your Vehicle ............................................................ 8
Remote Start Shutdown .................................................................... 8
Entering Your Vehicle while it is Running via Remote Start .............. 8
Preheating or Precooling the Vehicle’s Interior ................................. 8
User Programmable Run Time / Run Time Extension ....................... 9
Using the “Quick-Stop” Feature ......................................................... 9
Operating the 2 / 3 Hour Start Up Timer Mode .................................. 9
Turbo Timer Mode (optional) ........................................................... 10
Operating the Daily Start Timer ....................................................... 11
Temperature Start Mode .................................................................. 11
Remote Start Safety Features ......................................................... 11
LED and Siren/Horn Indications...........................................................12
Additional 2-Way LCD Remote Control Functions ............................. 13
LCD Remote Control ICON’s ................................................................ 15
Transmitter Button Functions .............................................................. 16
Replacing Remote Control Batteries ................................................... 18
Warranty Information ............................................................................ 19
32014 Voxx Electronics Corporation. All rights reserved.
Arming the Security System
To arm the system, exit the vehicle, close all doors, then press the button. The
parking lights will ash 2 times, indicating the system is armed, has locked the doors
(if equipped and connected) and activated the starter disable feature. The LED status
indicator will blink steadily, once per second.
NOTE: The system is equipped with a feature called Silent Choice. If enabled, the
system requires a second press of the button to activate an audible arming
response from the vehicle.
Passive Arming Bypass
If passive arming is enabled on your system, while the system is disarmed, press
+ , the system will respond with 1 chirp and the LED will turn on. The security
system will remain in this temporally bypassed state for as long as you wish. To exit
passive bypass, press the or button and the system will return to normal status.
Bypassing The Shock Sensor
To arm the system and ignore the shock sensor press button, then within 5
seconds press + , the system will respond with 1 long chirp.
NOTE: The system will only change the shock sensor setting for one arm cycle and
will be defaulted back to normal operation the next time the system is armed.
Hidden Alarm Function
Press the button rst, within 3 seconds press the button to activate the hidden
alarm function. The security system will arm with “Hidden Alarm Function” in which the
siren / horn will be silenced if the system is triggered.
Disarming the Security System
To disarm the system press the button. The parking lights will ash 1 time,
indicating the system is disarmed and has unlocked the doors (if equipped and
connected).
NOTE: The system is equipped with a feature called Silent Choice. If enabled, the
system requires a second press of the button to activate an audible disarming
response from the vehicle. If your system is set up for 2 step unlock, a third press of
unlock will activate the audible response.
*Throughout this manual, ‘press’ refers to pressing for less than 1 second; ‘press and hold’ refers to pressing for more
than 2 seconds.
Using Your Remote Control
4ca6554 Owners revA
Two Stage Door Unlock (Optional)
If this feature is enabled on your system, pressing the button one time will unlock
only the driver’s door. Press again within three seconds to unlock the remaining
doors.
Activating the Trunk Release Feature (Optional)
If this feature is enabled on your system, pressing and holding the button for 3
seconds will open the vehicle’s trunk or hatch.
Activating the AUX 1 Output (Optional)
If this feature is enabled on your system, pressing the and buttons
simultaneously will activate an optional feature. This feature can be programmed for a
wide range of functions like power window or sunroof automation, please consult your
installing dealer to determine the functionality of your system.
Entering AUX Mode and Activating the Additional AUX 2 - 5 Outputs (Optional)
To access the additional AUX outputs, AUX 2, AUX 3, AUX 4, and AUX 5, you must
rst enter the transmitters AUX Mode. This will “shift” the functions of the transmitter
buttons from their standard operation to control of the AUX outputs.
AUX Mode - 1 Way transmitter: Press and Hold and for 2
seconds, the transmitter LED will ash 1 time. AUX Mode will remain active
for 15 seconds. AUX Mode will exit after 15 seconds of inactivity or by
pressing and again for 2 seconds, the transmitter LED will ash 2
times to conrm exit.
AUX Mode - 2 Way transmitter: Press and Hold for 2 seconds, the
transmitter LCD screen will display “AU”. AUX Mode will remain active
for 15 seconds. AUX Mode will exit after 15 seconds of inactivity or by
pressing again for 2 seconds.
Activating outputs while in AUX Mode:
AUX 2: Press and Hold for 3 seconds.
AUX 3: Press and Hold for 3 seconds.
AUX 4: Press and Hold for 3 seconds.
AUX 5: Press and Hold for 3 seconds.
52014 Voxx Electronics Corporation. All rights reserved.
Using the Progressive Car Finder Feature
Press the button to locate your vehicle. The system will ash the parking lights
and sound 5 times at low volume, increasing in volume each time the button is
pressed.
Using the Personal Protection Alarm (Panic)
Press and hold the button for 3 seconds to activate the personal protection alarm.
During panic mode, the normal function of the transmitter buttons will be suspended.
The transmitter’s and buttons can be used to lock and unlock the door (if the
option is installed). To stop the alarm, press and hold the button on the transmitter
again for 3 seconds. The system will automatically stop after 30 seconds.
Programmed Transmitter Notication
As a security precaution each time the vehicle’s ignition is turn on the status LED
light with ash the number of transmitters programmed into the system. This helps
to identify unauthorized transmitters from accessing your vehicle. If you believe an
unauthorized transmitter has been programmed to your system, contact your installing
dealer for assistance.
Valet Mode
When valet mode is activated the status LED will light solid, and all security
functions will be disabled. To enter or exit valet mode simply follow the 4 steps
outlined below:
1. Turn the vehicle’s ignition ON.
2. Push and hold the programming/valet button.
3. The LED will turn on solid when valet mode is active
4. Release the programming/valet button.
Eliminating Arm / Disarm Notication Chirps
System ARM/DISARM chirps can be toggled ON or OFF without entering the
programming feature banks.
1. Turn the ignition ON then OFF.
2. Press and release the valet/programming button 3 times. The system
will respond with 1 chirp for ON or 2 chirps for OFF.
6ca6554 Owners revA
Car Jack Mode
This feature must be turned on in system programming, please consult your
installing dealer.
Triggering Car Jack mode: While the ignition is ON and press and hold + for
2 seconds, the parking lights will ash 1 time and the system will act as follows;
1. 50 seconds after being triggered the siren will chirp for 15 seconds,
during this 15 seconds you will be alerted to push the valet button to
turn off Car Jack mode. If Car Jack mode is not turned off at this time it
will advance to the next step.
2. Following the 15 second chirps (total time now 65 seconds) the siren
will go into full sound and the parking lights will start ashing.
3. 90 seconds after trigger in, addition to the siren and parking lights, the
system will activate the starter kill. THE SYSTEM WILL REMAIN IN THIS
STATE UNTIL THE BATTERY IS DEPLETED.
OVERRIDE THE SYSTEM TO TURN OFF CAR JACK MODE: Turn the ignition OFF
then On and press the valet button within 10 seconds.
Manually Overriding the Security System
Your system can be disarmed without the use of the transmitter. This is necessary,
since you will need the ability to operate your vehicle if the transmitter is lost or its
battery fails. To by-pass the alarm system;
1. Open the vehicle door. The alarm will sound.
2. Turn the ignition key to the ON position.
3. Within 10 seconds, press and release the valet push button switch.
The alarm system will stop sounding and enter the (by-passed) mode. You can now
start and operate the vehicle normally.
72014 Voxx Electronics Corporation. All rights reserved.
Using Your Remote Starter
Remote Start Ready Mode - Manual Transmission Vehicles Only
To activate the remote start function, the system must rst be in Remote Start Ready
Mode. Follow the steps below to enter remote start ready mode.
1. While the engine is running by the ignition key;
a. Set the parking brake
b. Place the transmission in neutral.
2. With your foot off the brake pedal, press and release the button 2
times within 2 seconds. The LED will ash 3 times and the parking
lights will turn on to conrm the system has entered quick stop mode.
3. Remove the keys from the ignition, the vehicle will remain running in
quick stop mode.
4. Exit the vehicle and close all vehicle doors.
5. Within 1 minute of step 1, press the button to lock the vehicle’s
doors. The vehicle will shutdown and sound 2 short chirps then 1 long
chirp to conrm ready mode is set.
Remote Start Ready Mode must be enabled if your vehicle is equipped with a
manual transmission.
Cancelling Remote Start Ready Mode
The system will exit remote start ready mode if any of the following occur:
Open any door
Open the hood or trunk (if connected)
Press the brake
Release the parking brake
Turn the ignition ON
8ca6554 Owners revA
Remote Starting Your Vehicle
To activate the remote vehicle start function, press and release the button 2 times
within 2 seconds. The system will sound, the parking lights will ash 1 time and the
system will check the vehicle to ensure it is safe to start. If all safety parameters are
correct, the vehicle will start within 5 seconds. The vehicle’s parking lights will turn on
(or ash depending on system settings) as a visual indication that the vehicle has
started and is running.
If your vehicle stalls or does not start, the system will pause 5 seconds, then try
2 more times to start the vehicle (a total of 3 attempts). The system will pause
5 seconds between each start attempt. If the vehicle does not start after the 3rd
attempt, the system will abort the remote vehicle start process.
Remote Start Shutdown
Press and hold the button for 3 seconds to turn the vehicle off.
Entering the Vehicle while it is Running via Remote Vehicle Start
1. Unlock the vehicle’s doors.
2. Enter the vehicle. DO NOT PRESS THE BRAKE PEDAL!
3. Insert the key into the ignition switch and turn to the ON or RUN
position.
4. Press the brake pedal. The remote vehicle starter will disengage and
the vehicle will operate normally.
Preheating or Precooling the Vehicle’s interior
Before exiting the vehicle, set the temperature controls to the desired setting and
operation. After the system starts the vehicle, the heater or air conditioner will
activate and heat or cool the vehicle’s interior to your setting.
92014 Voxx Electronics Corporation. All rights reserved.
Using the “Quick-stop” Feature
If you want to make a short stop and keep your vehicle running (to keep the interior
warm or cool), the quick-stop feature allows you to do this while keeping your vehicle
secure and your keys with you.
To engage quick stop:
1. Stop the vehicle and place the transmission in PARK.
2. With your foot off the brake pedal, press and release the button 2
times within 2 seconds. The LED will ash 3 times to conrm quick
stop is entered.
3. Remove the keys from the ignition and exit the vehicle. Press the
button to lock the vehicle’s doors if desired.
Note: Do not leave children or animals unattended in the vehicle when using the
quick-stop feature.
User Programmable Run Time / Run Time Extension
The system has the ability to allow the user to extend the time the vehicle will be
running under control of the remote start. This will only extend the run time back to the
current run time setting during the current remote start cycle. If your system is set to
run 15 minutes and the time remaining is 4 minutes, extending the run time will reset
the countdown timer to 15 minutes and your vehicle will continue to run for another 15
minutes. Follow the steps below to extend the vehicle’s run time.
1. The remote start must already be active.
2. Press and release the button 4 times.
3. The system will chirp 1 time and ash the parking lights 4 times to
conrm that the run time has been reset.
Operating the 2 / 3 Hour Start Up Timer Mode
The system has the ability to start the vehicle every 2 or 3 hours for a 48 hour period.
This feature is especially useful in cold climates where the only means to keep the
engine and engine uids warm is to periodically start the engine. The default setting
is 3 hour, Selection between 2 or 3 hour is made in option programming.
WARNING!
Be certain that the vehicle is outdoors before using this or any remote starting
device. A running engine produces dangerous carbon monoxide fumes which can be
harmful or fatal if prolonged exposure occurs. DO NOT remote start the vehicle if it is
garaged.
10 ca6554 Owners revA
To begin the 2 / 3 hour start up timer mode:
1. Turn the vehicle’s ignition ON then OFF.
2. Press and hold the valet button.
3. Press the button 4 times, the system will;
a. When set for 3 Hour (default) - chirp 2 times and ash the
parking lights 4 times.
b. When set for 2 Hour - chirp 1 time and ash the parking
lights 2 times.
4. Release the valet button.
To exit the 2 / 3 hour start up timer mode:
1. Turn the vehicle’s Ignition ON.
OR
1. Activate the remote vehicle start feature using the remote control.
Turbo Timer
This option will keep the engine running to allow the vehicle’s turbo to properly cool
down before shutting the engine off.
To engage the Turbo Timer feature:
1. With the vehicle running via the ignition key and your foot off of the
brake pedal.
2. Engage the vehicle’s parking brake and press the and
buttons simultaneously.
3. The vehicle’s parking lights will turn on to verify the Turbo Timer
feature has been activated.
4. Turn the ignition key OFF, the vehicle will continue to run until the pre-
programmed time has elapsed (1, 3, or 5 minutes)
To disengage the turbo timer feature, press the vehicle’s brake pedal.
112014 Voxx Electronics Corporation. All rights reserved.
Remote Start Safety Features
For safety and security reasons, the system will shutdown or prevent the remote
vehicle starter from activating if any of the following occur:
1. The vehicle hood is open.
2. The brake pedal is pressed prior to turning the ignition key to the ON
position.
3. The engine is over-revved (tach checking only).
4. Valet mode is active.
Operating the Daily Start Timer
The system has the ability to start your vehicle based on a 24-hour countdown timer.
This feature requires a two-part activation sequence. From the remote, while in range
of the vehicle, pressing both the & buttons together will activate the 24 hour
countdown timer (the vehicle will start 24 hours from this time). Next, When you are
nished operating the vehicle for the day, perform the following steps to complete the
process.
1. Turn the ignition ON/OFF (vehicle must be disarmed).
2. Within 10 seconds, while pressing the brake, press and release the
button twice.
3. The vehicle will emit 2 chirps and ash the parking lights 4 times.
Temperature Start Mode
The system has the ability to start the vehicle if the temperature drops below a preset
temperature threshold. Once activated, the system will only start the vehicle one time
based on the temperature setting and will be cancelled if the vehicle is started with the
key or remote started by the transmitter. Temperature is read from the module, located
below the dashboard in most instances, and the vehicle’s interior temperature may
vary from the ambient temperature.
1. The vehicle must be armed.
2. Press and release both the & buttons together.
3. The vehicle will emit 1 chirp and ash the parking lights 1 time.
Note: This feature is defaulted OFF and must be set in option programming.
12 ca6554 Owners revA
LED and Siren/Horn Indications
LED Display Indications
LED Function
OFF DISARMED
SLOW FLASH ARMED
FAST FLASH PASSIVE ARMING
ON (SOLID) VALET MODE
2 FLASH... PAUSE ZONE 2 TRIGGER, HOOD/TRUNK
3 FLASH... PAUSE ZONE 3 TRIGGER, DOOR
4 FLASH... PAUSE ZONE 4 TRIGGER, SHOCK
5 FLASH... PAUSE ZONE 5 TRIGGER, IGNITION
Siren/Horn Indications
Chirps Function
1 DISARM
2 ARM
3 DOOR AJAR UPON ARMING
4 DISARM / TRIGGERED
5 CAR LOCATOR
Parking Light Flash Indications
Flashes Function
1 DISARM
2 ARM
3 DISARM / TRIGGERED
5 CAR LOCATOR
ON (SOLID) REMOTE STARTED
132014 Voxx Electronics Corporation. All rights reserved.
Check Vehicle Status
Press and release 2 times then press within 3 seconds, the transmitter will
display the current status of the vehicle.
Display Illumination
Press and hold the button for 1 second. The display will illuminate for 5 seconds.
Melody / Vibration Mode
To have the remote control vibrate, play a melody tone or both each time it receives a
response from the vehicle press and release then press and hold for 2
seconds.
Button Beeps
To toggle button beeps on or off press and release then press and hold for 2
seconds.
Battery Save Mode
While in POWER SAVE MODE the 2-way LCD transmitter will NOT look for any
incoming signals from the main unit until a button is pressed. The LCD screen will
display SAVE to indicate that power save mode is ON. To enter power save mode
press and hold for 5 seconds.
Clear Flashing Icons and Melody Sound
Press the button 3 times within 3 seconds. This will clear the melody sound and
ashing icons on the LCD screen.
Stopping LCD Trigger Melody
To stop the alarm trigger melody if the system has been triggered WITHOUT
disarming the system, press any button one time only, this will not send a command to
the vehicle at this time and the alarm will continue to sound.
Additional 2-Way LCD Remote Control Functions
14 ca6554 Owners revA
Button Lock
Press and release then press hold the for 2 seconds to toggle the button lock
on or off. When the button lock is active, the remote control will beep/vibrate 2 times
when a button is pressed indicating it is locked.
Illumination
Press and release 2 times then press and hold for 2 seconds to toggle
illumination on or off. When on, the display will illuminate when it receives or sends a
command.
2 Car Mode
To control a second security system enter 2 car mode by pressing then press
and together for 3 seconds. When the icon appears on the transmitter’s LCD
screen it will control the second security system. Use the same method to exit 2 car
mode and resume control of the original vehicle’s security system.
NOTE: A second security system must be installed and the LCD transmitter must be
learned to it before this feature will operate the additional system.
Parking Meter Countdown
The parking meter countdown timer has 6 preset times, to access the preset times
and begin countdown press and release then press and hold for 2 seconds,
each additional press of will increase the countdown time.
Adjusting the Clock and Timer Settings
The clock, alarm clock and programmable countdown timer are accessed through the
Function Menu. Press and hold for 3 seconds to access the function menu, once
you have accessed the feature menu press and release to scroll through each
feature and follow the steps below to adjust the settings for each. Press and hold
for 2 seconds to exit the menu.
Clock Hour Press to increase or to decrease
Clock Minute Press to increase or to decrease
Alarm Clock Hour Press to increase or to decrease
Alarm Clock Minute Press to increase or to decrease
Alarm Clock ON / OFF Press to turn ON or to turn OFF
Countdown Timer Hour Press to increase or to decrease
Countdown Timer Minute Press to increase or to decrease
Countdown Timer ON / OFF Press to turn ON or to turn OFF
152014 Voxx Electronics Corporation. All rights reserved.
LCD Remote Control ICON’s
LOCK UNLOCK
SYSTEM ARMED VALET MODE
TRANSMITTING
TRUNK TRIGGER DOOR TRIGGER
FULL SHOCK TRIGGER
IGNITION ON/TRIGGER
ENGINE RUNNING
2 CAR MODE
BATTERY INDICATOR BATTERY SAVE MODE
VIBRATE/SILENT MODE
HOOD TRIGGER
SYSTEM TRIGGER TIME COUNT DOWN
MELODY MODE
TIME DISPLAY
TIMER / TEMP.
START MODES
ALARM CLOCK
AUX 1 OUTPUT
AUX MODE
AUX 5 OUTPUT
AUX 4 OUTPUT
AUX 3 OUTPUT
AUX 2 OUTPUT
16 ca6554 Owners revA
Transmitter Button Functions
1 Way
TransmitterLock Unlock Car Find /
Panic Start Operation Method
Lock X Press and Release
Unlock XPress and Release
2 Step UnlockX Press and Release 2 times
Trunk XPush and Hold (3 Sec)
Car FinderX
Press and Release
PanicX
Push and Hold (3 Sec)
Remote Start XPress and Release (1 or 2 times
depending on selectable option)
Remote Start
ShutdownXPush and Hold (3 Sec)
Run Time
ExtentionXPress and Release 4 times.
AUX 1XXPush and Hold (3 Sec)
Shock Bypass XX Press and Release Lock then
Press Lock + Car Find
Hidden AlarmX XPress and Release Car Find then
Press Lock
Passive Arming
Bypass XX Press and Release
Turbo TimerXXPress Unlock + Start
2 / 3 Hour StartX
Ignition ON/OFF, Press and Hold
Valet Button, Press Start 4 times
Daily Start Timer XX
Press Lock + Start
Temperature
StartXX
Press Unlock + Start While Armed
Enter AUX Mode XX Press and Hold Find + Start
Transmitter LED flashes 1 time
AUX 2X Push and Hold (3 Sec)
AUX 3X Push and Hold (3 Sec)
AUX 4X
Push and Hold (3 Sec)
AUX
5X
Push and Hold (3 Sec)
AUX 2, 3, 4, 5 - Access in AUX Mode
172014 Voxx Electronics Corporation. All rights reserved.
2 Way
TransmitterLock Unlock Car Find /
Panic StartFunctionOperation Method
Lock X Press and Release
Unlock XPress and Release
2 Step UnlockX Press and Release 2 times
Trunk XPush and Hold (3 Sec)
Car FinderX
Press and Release
PanicX
Push and Hold (3 Sec)
Remote StartX
Press and Release (1 or 2 times
depending on selectable option)
Remote Start
ShutdownXPush and Hold (3 Sec)
Run Time
ExtentionXPress and Release 4 times.
AUX 1XXPush and Hold (3 Sec)
Shock Bypass XX Press and Release Lock then
Press Lock + Car Find
Hidden AlarmX XPress and Release Car Find then
Press Lock
Passive Arming
Bypass XX Press and Release
Turbo TimerXXPress Unlock + Start
2 / 3 Hour Start X Ignition ON/OFF, Press and Hold
Valet Button, Press Start 4 times
Daily Start Timer XX
Press Lock + Start
Menu XPress and Hold
Temperature
StartXX
Press Unlock + Start While Armed
Enter AUX Mode XPress and Hold F for 2 seconds
LCD displays AU
AUX 2X Push and Hold (3 Sec)
AUX 3X Push and Hold (3 Sec)
AUX 4X
Push and Hold (3 Sec)
AUX
5X
Push and Hold (3 Sec)
AUX 2, 3, 4, 5 - Access in AUX Mode
18 ca6554 Owners revA
Replacing Remote Control Batteries
1 Way 4 Button Remote Control - Model CAT4
The batteries inside each remote control should last approximately 1 year under normal
use. When the batteries become weak you will notice the remote control range (the
distance from the vehicle the remote control will work) deteriorate and the small LED on
the remote control will dim. To replace the remote control batteries:
1. Using a coin, disassemble the halves of the remote
control.
2. Remove the old battery, observing the +/- symbols on the
batteries and replace with a new battery.
3. Reassemble the halves of the remote control
4. Test operation of the remote control.
2 Way LCD Remote Control - Model CATLCD
The AAA battery inside the 2-way LCD remote control should last approximately 6
months under normal use. When the battery becomes weak you will notice the remote
control range (the distance from the vehicle the remote control will work) deteriorate and
the BATTERY icon on the LCD remote control will show 1 bar or less.
1. Gently slide the battery cover off of the remote control.
2. Remove the old AAA battery, observing the +/- symbols on the
battery, and replace with a new AAA battery.
3. Gently slide the battery cover on to the back of the remote control.
4. Test operation of the remote control.
192014 Voxx Electronics Corporation. All rights reserved.
Code Systems, Inc. Limited Lifetime Warranty
Code Systems Inc. (“CODE”) warrants to the ORIGINAL PURCHASER of this CODE vehicle
security product (the “Product”), purchased from an authorized CODE dealer, that (except as provided
below) should this Product under normal use and conditions, be proven defective in material or work-
manship DURING THE LIFETIME OF THE VEHICLE IN WHICH IT WAS ORIGINALLY INSTALLED,
such defect(s) will be repaired or replaced (at CODE’s option) without charge for parts directly related
to repairs of the defect(s).
Switches, indicator lights, and transmitter cases are similarly warranted to the original pur-
chaser for a period of one (1) year from the date of purchase of the Product.
CODE accessories, sold separately, are covered by the applicable warranty accompanying
the accessory.
This warranty is non-transferable, non-assignable and is voided when: (1) the Product is
removed from the vehicle in which it was originally installed; or (2) the vehicle in which the Product was
originally installed is transferred to another party.
This warranty does not apply to any product damaged by accident, physical or electrical
abuse, improper installation, alteration, or use contrary to its intended function, re, ood, or other natural
acts.
In order for the Product to be repaired or replaced under the terms of this warranty, the
defective Product must be returned to an authorized CODE dealer and accompanied by a copy of the
retail sales receipt. The date of purchase and year, make and model of the vehicle in which the Product
was originally installed must be clearly indicated on the sales receipt.
This warranty is exclusive and CODE MAKES NO OTHER WARRANTIES EXPRESSED OR
IMPLIED. ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANT-
ABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF
THIS WRITTEN WARRANTY. IN NO CASE SHALL CODE BE LIABLE FOR ANY CONSEQUENTIAL
OR INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY, EXPRESS OR
IMPLIED, WHATSOEVER.
CODE does not warrant that the Product cannot be compromised or circumvented. THE EXTENT OF
CODE’S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT
PROVIDED ABOVE AND, IN NO EVENT SHALL CODE’S LIABILITY EXCEED THE PURCHASE
PRICE PAID BY THE ORIGINAL PURCHASER OF THE PRODUCT WITHOUT INSTALLATION LABOR.
Some states do not allow the exclusion or limitation of incidental or consequential damages,
so the above limitation may not apply to you. This warranty gives you specic legal rights and you may
also have other rights which vary from state to state
20 ca6554 Owners revA
212014 Voxx Electronics Corporation. All rights reserved.
Voxx Electronics Corporation.
Customer Service 1-800-421-3209
WWW.CODE-ALARM.COM
FCC COMPLIANCE
This device complies with Part 15 of the FCC rules and with RSS-210 of
Industry Canada. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including any interference that
may cause undesired operation.
Warning!
Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
PATENTED: www.voxxintl.com/company/patents
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the
following measures:
. Reorient or relocate the receiving antenna.
. Increase the separation between the equipment and receiver.
. Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
. Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: To assure continued compliance, any changes or modifications not
expressly approved by the party responsible for compliance could void the user's
authority to operate this equipment. (Example - use only shielded interface cables
when connecting to computer or peripheral devices).
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
a minimum distance of 0.5 centimeters between the radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
The antennas used for this transmitter must be installed to provide a separation
distance of at least 0.5 cm from all persons and must not be co-located or
operating in conjunction with any other antenna or transmitter.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and (2) This device must accept
any interference received, including interference that may cause undesired operation.
