Users Manual
ZDP100 Instructions
101002
HomePro
by ADVANCED CONTROL TECHNOLOGIES, INC.
0607-01
1
Radio Frequency Controlled, 300W, 120 VAC,
Plug-In Lamp Module
ZDP100
HomePro
RF Home Automation
Button functions
1. Adds module under the command of Wireless Control-
ler.
2. Local ON and OFF (push and release).
3. Local dimming (hold down).
ZDP100 PLUG-IN LAMP MODULE
The ZDP100 plug-in Lamp Module is a component of the HomePro lighting control system. Plug the Lamp Module
into a wall outlet and plug a lamp into the Lamp Module. Inclusion of the Lamp Module on the ZTH100 Wireless
Controller menu allows remote ON/OFF control and dimming of lamps connected.
This plug-in Lamp Module is designed to work with other HomePro lamp and appliance controls. Z-Wave nodes of
other types can be added to the system and will also act as repeaters if they support this function of repeating the signal
received to other modules in the system.
As part of a HomePro network, the ZDP100 can act as a wireless repeater to insure that commands intended for
another device in the network are received. This is useful when the device would otherwise be out of the radio range
of the wireless controller.
There are no field repairable assemblies on this unit. It is covered by a one year limited warranty. If service is needed,
the unit must be returned where purchased.
INSTALLATION
Plug this Lamp Module into the wall outlet near the lamp to be controlled, and plug the lamp into the Lamp Module.
See the ZTH100 Wireless Controller operating instructions to add this module under the command of the Wireless
Controller. Make sure the lamp(s) to be controlled total no more than 300 watts. WARNING: Plugging a non-resistive
load such as florescent lighting or a device with a motor may result in damage to the Lamp Module and will void the
warranty.
Lamp Module Button
The Lamp Module has a button on the face (see picture above) that switches an attached lamp ON and OFF, and
adjusts its dimming level by holding it down, and it is also used to configure the module to operate from the wireless
controller. With the Wireless Controller, the Lamp Module can be switched ON and OFF, and can be included
in groups of lights (a group can also be a single module) that operate at the same time, and in scenes that set a
lighting mood.
Switch power ON and OFF locally
When the button is pressed and released quickly, the power will toggle. This means that power will be turned OFF
if it was ON and turned ON if it was OFF. When switching the Lamp Module ON or OFF, the light will dim UP (or
DOWN) in approximately 2 seconds until the final level is reached.
Dimming
If the button is constantly pressed the light will be dimmed. The dimming function will also toggle. Constantly
pressing the button the Lamp Module will dim either UP or DOWN until it reaches the maximum or minimum value.
The second time the button is held down, the dimming will change direction. When the power level reaches either
full power or minimum power the dimming will stop until the button has been released and is pressed again.
ZDP100 Instructions
101002
HomePro
by ADVANCED CONTROL TECHNOLOGIES, INC.
0607-01
2
Child Protection
The Lamp Module can be set in a child protect mode by the Wireless Controller. When this mode is active, a user
will have to press the button on the Lamp Module 3 times rapidly to activate the attached load. The module operates
normally when controlled by the Wireless Controller..
Other functions
The button on the Lamp Module also plays a role as a reset in addition to adding module to groups and scenes.
This is described in more detail in the Wireless Controller instructions.
Software fuse
This Lamp Module is designed to protect itself against loads that exceed it’s maximum power rating. The
application of a load that exceeds that rating is quickly sensed by the dimmer and it responds by immediately
shutting off all power to that load.
If the dimmer doesn’t seem to work, or if it only works momentarily, check to see that the total lamp wattage doesn’t
exceed the 300W rating of the Lamp Module. If a properly sized load is restored to the dimmer, it can be operated
normally once again.
Over-current protection
The Lamp Module hardware has an over current detection circuit, which is final protection against overload.
If the software fuse should fail to shut down the dimmer when overloaded, backup protection is provided by an
internal fuse. This fuse is not user serviceable. Check your home circuit breakers before concluding that the
product must be returned to manufacturer for repair at a nominal charge.
Operation Note
When a light bulb reaches the end of it’s life and burns out, it sometimes creates a momentary short circuit. The
high current that results may cause the dimmer to properly respond by turning off. Should this happen, replace
the bulb with a new one. The dimmer can now be operated to restore power to the light.
WARRANTY
Advanced Control Technologies, Inc. gives this expressed warranty (along with extended warranty endorsements, where applicable) in lieu
of all other warranties, express or implied, including (without limitation), warranties of merchantability and fitness for a particular purpose.
This constitutes Advanced Control Technologies, Inc.’s sole warranty and obligation with regard to our products as well as the Customer’s
sole remedy.
Advanced Control Technologies, Inc. expressly disclaims all liability and responsibility for any special, indirect or consequential damages
or any further loss of any kind whatsoever resulting from the use of our product. The Customer’s sole and exclusive remedy and the limit
of Advanced Control Technologies, Inc.’s liability for any loss whatsoever, shall not exceed the purchase price paid by the Customer for the
product to which a claim is made.
Some states do not allow limitations of incidental or consequential damages or on how long an implied warranty lasts, so the above limitations
may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
All products manufactured by Advanced Control Technologies, Inc. are warranted to be free from defects in material and workmanship in
accordance with and subject to the following terms and conditions:
1. This warranty is limited to the original Customer only. It cannot be transferred or assigned to third parties unless the intent to
transfer to a third party is expressly indicated in a purchase order and/or warranty processing arrangements have been agreed
upon in writing by Advanced Control Technologies, Inc.
2. Advanced Control Technologies, Inc. will correct any defects in material or workmanship which appear within one (1) year from the
date of purchase. Advanced Control Technologies, Inc. will repair or replace, at our option, any defective products, provided that
our inspection discloses that such defects developed under normal and proper use. This warranty does not extend to goods
subjected to misuse, neglect, accident or improper installation, or to maintenance or repair of products which have been altered or
repaired by anyone except Advanced Control Technologies, Inc. unless otherwise stated in writing.
3. An appropriate charge (50% of product list price) will be made for testing, repairs, replacement and shipping for returned product
which is not defective or found to be defective as the result of improper use, maintenance or neglect.
4. Information in our descriptive literature is based on product specifications that are current at the time of publication. Product
specifications, designs and descriptive literature are subject to change as improvements are introduced. Although we announce
changes as they occur, we cannot guarantee notification to every Customer. Advanced Control Technologies, Inc. warrants
delivered product to conform to the most current specifications, designs and descriptive literature.
ZDP100 Instructions
101002
HomePro
by ADVANCED CONTROL TECHNOLOGIES, INC.
0607-01
3
FCC NOTICE
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
IC NOTICE
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this
device must accept any interference, including interference that may cause undesired operation of the
device.
Power 120 VAC, 60 Hz
Signal (Frequency) 908.42 MHz
Maximum Load 300 W, for incandescent lamps only
Range Up to 100 feet line of sight between the Wireless Controller and /or the
closest HomePro plug-In Lamp Module or Appliance Module
