Advantech Co UTX-3115 COMPUTER User Manual V4 12 EC User Manual
Advantech Co Ltd COMPUTER V4 12 EC User Manual
Users Manual.pdf
User Manual
UTX-3115
UTX-3115 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2014
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
Declaration of Conformity
FCC Class B
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful inter-
ference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be determined by turning the equip-
ment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Part No. XXXXXXXXXX Edition 1
Printed in Taiwan September 2014
Warning! Any changes or modifications made to the equipment which are not
expressly approved by the relevant standards authority could void your
authority to operate the equipment.
Caution! Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dis-
pose of used batteries according to the manufacturer’s instructions.
iii UTX-3115 User Manual
Federal Communication Commission Interference
Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-
lowing two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B dig-
ital device, pursuant to Part 15 of the FCC Rules. These limits are designed to pro-
vide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interfer-
ence to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be determined by turning the equip-
ment off and on, the user is encouraged to try to correct the interference by one of
the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
Operations in the 5.15-5.25GHz band are restricted to indoor usage only.
FOR MOBILE DEVICE USAGE (>20cm/low power)
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncon-
trolled environment. This equipment should be installed and operated with minimum
distance 20cm between the radiator & your body.
FOR COUNTRY CODE SELECTION USAGE (WLAN DEVICES)
Note: The country code selection is for non-US model only and is not available to all
US model. Per FCC regulation, all WiFi product marketed in US must fixed to US
operation channels only.
UTX-3115 User Manual iv
Technical Support and Assistance
1. Visit the Advantech website at http://support.advantech.com where you can find
the latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
–Product name and serial number
–Description of your peripheral attachments
–Description of your software (operating system, version, application software,
etc.)
–A complete description of the problem
–The exact wording of any error messages
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service
personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to work according to
the user's manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
Warning! 1. Input voltage rated 12-19 VDC, 3.75 ~ 2.63 A (DC Mode).\
2. Packing: please carry the unit with both hands, handle with care.
3. Maintenance: to properly maintain and clean the surfaces, use only
approved products or clean with a dry applicator.
v UTX-3115 User Manual
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR ABOVE 60° C
(140° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.
16. If your computer is losing dramatic time or the BIOS configuration reset to
default, the battery has no power.
17. CLASSIFICATION:
–Supply by Class I adapter
–No applied part
–Continuous Operation
–Not AP or APG category
18. Follow the national requirement to dispose unit.
19. Maintenance: to properly maintain and clean the surfaces, use only the
approved products or clean with a dry cloth.
20. Contact information:
No.1, Alley 20, Lane 26, Rueiguang Road Neihu District, Taipei, Taiwan 114,
R.O.C
TEL: (02)27927818
21.
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.
Caution! 1. Do not replace power adaptor yourself. Please contact a qualified
technician or your retail.
2. The computer is provided with a battery-powered real-time clock
circuit. There is a danger of explosion if battery is incorrectly
replaced. Replace only with same or equivalent type recom-
mended by the manufacture. Discard used batteries according to
the manufacturer’s instructions.
Note! Attention, consult ACCOMPANYING DOCUMENTS.
UTX-3115 User Manual vi
Industry Canada Statement
This device complies with RSS-210 of the Industry Canada Rules. Operation is sub-
ject to the following two conditions: (1) This device may not cause harmful interfer-
ence, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux
appareils radio exempts de licence. Son fonctionnement est sujet aux deux condi-
tions suivantes: (1) le dispositif ne doit pas produire de brouillage préjudiciable, et (2)
ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de
provoquer un fonctionnement indésirable.
Caution :
(i) the device for operation in the band 5150-5250 MHz is only for indoor use to
reduce the potential for harmful interference to co-channel mobile satellite systems;
(ii) the maximum antenna gain permitted for devices in the bands 5250-5350 MHz
and 5470-5725 MHz shall comply with the e.i.r.p. limit; and
(iii) the maximum antenna gain permitted for devices in the band 5725-5825 MHz
shall comply with the e.i.r.p. limits specified for point-to-point and non point-to-point
operation as appropriate.
(iv) Users should also be advised that high-power radars are allocated as primary
users (i.e. priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that
these radars could cause interference and/or damage to LE-LAN devices.
Avertissement:
Le guide d’utilisation des dispositifs pour réseaux locaux doit inclure des instructions
précises sur les restrictions susmentionnées, notamment :
(i) les dispositifs fonctionnant dans la bande 5 150-5 250 MHz sont réservés unique-
ment pour une utilisation à l’intérieur afin de réduire les risques de brouillage préjudi-
ciable aux systèmes de satellites mobiles utilisant les mêmes canaux;
(ii) le gain maximal d’antenne permis pour les dispositifs utilisant les bandes 5 250-5
350 MHz et 5 470-5 725 MHz doit se conformer à la limite de p.i.r.e.;
(iii) le gain maximal d’antenne permis (pour les dispositifs utilisant la bande 5 725-5
825 MHz) doit se conformer à la limite de p.i.r.e. spécifiée pour l’exploitation point à
point et non point à point, selon le cas.
(iv) De plus, les utilisateurs devraient aussi être avisés que les utilisateurs de radars
de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu’ils ont la priorité)
pour les bandes 5 250-5 350 MHz et 5 650-5 850 MHz et que ces radars pourraient
causer du brouillage et/ou des dommages aux dispositifs LAN-EL.
FOR MOBILE DEVICE USAGE (>20cm/low power)
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncon-
trolled environment. This equipment should be installed and operated with minimum
distance 20cm between the radiator & your body.
Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies
pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec
un minimum de 20 cm de distance entre la source de rayonnement et votre corps.
vii UTX-3115 User Manual
User Manual Notice to Users for TCB Certification
FCC/Industry Canada Two Part Stmt:
English Version:
This device complies with FCC Part 15 and Industry Canada license exempt RSS
standard(s). Operation is subject to the following two conditions: (1) this device may
not cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
French Version:
Cet appareil est conforme à FCC Partie15 d’Industrie Canada RSS standard
exempts de licence (s). Son utilisation est soumise à Les deux conditions suivantes:
(1) cet appareil ne peut pas provoquer d’interférences et (2) cet appareil doit
accepter Toute interférence, y compris les interférences qui peuvent causer un mau-
vais fonctionnement du dispositif.
Per Industry Canada RSS rules:
English version:
This device complies with Health Canada’s Safety Code. The installer of this device
should ensure that RF radiation is not emitted in excess of the Health Canada’s
requirement. Information can be obtained at http://www.hc-sc.gc.ca/ewh-sem/pubs/
radiation/radio_guide-lignes_direct-eng.php
French version:
Cet appareil est conforme avec Santé Canada Code de sécurité 6. Le programme
d’installation de cet appareil doit s’assurer que les rayonnements RF n’est pas émis
au-delà de I’exigence de Santé Canada. Les informations peuvent être obtenues:
http://www.hc-sc.gc.ca/ewhsemt/pubs/radiation/radio_ guide-lignes_direct-eng.php
English Version:
“Changes or modifications not expressly approved by the party responsible for com-
pliance could void the user’s authority to operate the equipment.”
French Version:
"Les changements ou modifications non expressément approuvés par la partie
responsable de la conformité pourraient annuler l'autorité de l'utilisateur à utiliser cet
équipement."
Antenna Stmt:
English Version:
“This device has been designated to operate with the antennas listed below, and hav-
ing a maximum gain of [X] dB. Antennas not included in this list or having a gain
greater than [X] dB are strictly prohibited for use with this device. The required
antenna impedance is [Y] ohms.”
(equipment manufacturers shall provide proper values of x and y to comply with the
applicable RSS.
UTX-3115 User Manual viii
The antenna(s) used for this transmitter must be installed to provide a separation dis-
tance of at least [X] cm from all persons and must not be co-located or operating in
conjunction with any other antenna or transmitter. Users and installers must be pro-
vided with antenna installation instructions and transmitter operating conditions for
satisfying RF exposure compliance.
(Mfrs shall provide value of [X])
French Version:
"Ce dispositif a été désigné pour fonctionner avec les antennes énumérées ci-des-
sous, et ayant un gain maximal de [X] dB. Antennes pas inclus dans cette liste ou
présentant un gain supérieur à [X] dB sont strictement interdits pour une utilisation
avec cet appareil. L'impédance d'antenne requise est [Y] ohms. "
(fabricants de matériel doivent fournir des valeurs propres de x et y pour se con-
former à la RSS applicable).
L'antenne (s) utilisé pour cet émetteur doit être installé pour fournir une distance de
séparation d'au moins [X] cm de toutes les personnes et ne doit pas être co-locali-
sées ou opérant en conjonction avec une autre antenne ou émetteur. Les utilisateurs
et les installateurs doivent être fournis avec des instructions d'installation de
l'antenne et des conditions de fonctionnement de l'émetteur pour satisfaire la confor-
mité aux expositions RF.
(Fabricants doit fournir une valeur de [X])
European Union Declaration of Conformity Statement
We, Advantech, declare under our sole responsibility that the product, model, is in
conformity with all applicable essential requirements Necessary for CE marking, fol-
lowing the provisions of the European Council Directives 2004/108/EC (EMC Direc-
tive), 2006/95/EC (Low Voltage Directive), 1999/5/EC (Radio and
Telecommunications Terminal Equipment Directive) and 2011/65/EU (ROHS Direc-
tive).
The product is properly CE marked demonstrating this conformity and is for distribu-
tion within all member states of the EU with no restrictions.
This product follows the provisions of the European Directives 2004/108/EC, 2006/
95/EC, 1999/5/EC and 2011/65/EU.
Čeština Tento výrobek odpovídá požadavkům evropských směrnic 2004/108/EC,
2006/95/EC, 1999/5/EC a 2011/65/EU.
Dansk Dette produkt er i overensstemmelse med det europæiske direktiv 2004/108/
EC, 1999/5/EC, 2006/95/EC & 2011/65/EU.
Dutch Dit product is in navolging van de bepalingen van Europees Directief 2004/
108/EC, 1999/5/EC, 2006/95/EC & 2011/65/EU.
Eesti Antud toode vastab Euroopa direktiivides 2004/108/EC, ja 2006/95/EC ja 1999/
5/EC ja 2011/65/EU kehtestatud nõuetele.
ix UTX-3115 User Manual
Suomi Tämä tuote noudattaa EU-direktiivin 2004/108/EC, 1999/5/EC, 2006/95/EC &
2011/65/EU määräyksiä.
Français Ce produit est conforme aux exigences de la Directive Européenne 2004/
108/EC, 1999/5/EC, 2006/95/EC & 2011/65/EU.
Deutsch Dieses Produkt entspricht den Bestimmungen der Europäischen Richtlinie
2004/108/EC, 1999/5/EC 2006/95/EC & 2011/65/EU.
Ελληνικά Το παρόν προϊόν ακολουθεί τις διατάξεις των Ευρωπαϊκών Οδηγιών 2004/
108/EC, 1999/5/EC, 2006/95/EC και 2011/65/EU.
Magyar E termék megfelel a 2004/108/EC, 1999/5/EC, 2006/95/EC és 2011/65/EU
Európai Irányelv előírásainak.
Icelandic Þessi vara stenst reglugerð Evrópska Efnahags Bandalagsins númer
2004/108/EC, 2006/95/EC, & 2011/65/EU.
Italiano Questo prodotto è conforme alla Direttiva Europea 2004/108/EC, 1999/5/
EC, 2006/95/EC & 2011/65/EU.
Latviešu Šis produkts atbilst Eiropas Direktīvu 2004/108/EC, 1999/5/EC, 2006/95/
EC un 2011/65/EU noteikumiem.
Lietuvių Šis produktas atitinka Europos direktyvų 2004/108/EC, 1999/5/EC, 2006/
95/EC, ir 2011/65/EU nuostatas.
Malti Dan il-prodott hu konformi mal-provvedimenti tad-Direttivi Ewropej 2004/108/
EC, 1999/5/EC, 2006/95/EC u 2011/65/EU.
Norsk Dette produktet er i henhold til bestemmelsene i det europeiske direktivet
2004/108/EC, 1999/5/EC, 2006/95/EC & 2011/65/EU.
Polski Niniejszy produkt jest zgodny z postanowieniami Dyrektyw Unii Europejskiej
2004/108/EC, 1999/5/EC, 2006/95/EC i 2011/65/EU.
Portuguese Este produto cumpre com as normas da Diretiva Européia 2004/108/
EC, 1999/5/EC, 2006/95/EC & 2011/65/EU.
Español Este producto cumple con las normas del Directivo Europeo 2004/108/EC,
1999/5/EC, 2006/95/EC & 2011/65/EU.
Slovensky Tento produkt je v súlade s ustanoveniami európskych direktív
2004/108/EC, 1999/5/EC, 2006/95/EC a 2011/65/EU.
Slovenščina Izdelek je skladen z določbami evropskih direktiv 2004/108/EC, 1999/
5/EC, 2006/95/EC in 2011/65/EU.
UTX-3115 User Manual x
Svenska Denna produkt har tillverkats i enlighet med EG-direktiv 2004/108/EC,
1999/5/EC 2006/95/EC & 2011/65/EU.
Türkçe Bu ürün, Avrupa Birliği’nin 2004/108/EC, 1999/5/EC, 2006/95/EC ve 2011/
65/EU yönergelerine uyar.
European Union:
The low band 5.15 -5.35 GHz is for indoor use only.
This symbol on the product indicates compliance with Directive 2002/96/EC
(WEEE). Do not dispose of product in unsorted municiple waste.
Please recycle this product in a responsible manner. Refer to local environmental
regulations for proper recycling; do not dispose of product in unsorted municipal
waste.
xi UTX-3115 User Manual
Contents
Chapter 1 Introduction..........................................1
1.1 Overview ................................................................................................... 2
1.2 System Configuration................................................................................ 3
Chapter 2 Hardware Description .........................5
2.1 General Specifications .............................................................................. 6
2.1.1 Standard PC Functions................................................................. 6
2.1.2 Power Environmental.................................................................... 6
2.2 Mechanical Specifications......................................................................... 6
2.2.1 Mechanical Specifications (Terminal) ........................................... 6
Chapter 3 Design Requirements..........................7
3.1 Environmental Specifications .................................................................... 8
UTX-3115 User Manual xii
Chapter 1
1Introduction
This Chapter briefly introduces
the UTX-3115 product.
UTX-3115 User Manual 2
1.1 Overview
Advantech UTX-3115 system is a refreshingly new idea. Essentially what Advantech
have created is an ultra compact PC standard that we want to be the future of com-
puting. Advantech UTX-3115 is an intelligent and impressive small device for small
spaces or anywhere else you can imagine. Since low power and small Intel CPUs
have come quite a long way, UTX-3115 is designed with the latest Intel SOC which
has lower power consumption but with higher CPU performance. The benefit for cus-
tomer in UTX-3000 is quiet operation and wide temperature system and is open to a
large range of applications and markets. UTX-3000 target market is generated in the
digital signage, media-centre PCs, as well as all-in-ones, and Intelligent vending
machine. At present the mini-pc market has boomed with ARM-powered Android
based machines. If you are a windows user, then it’s good news for you because
UTX-115 small system is based on the shelf Intel components and is capable of run-
ning Linux or Windows.
Benefits:
Ultra Thin Mini-ITX embedded system with CE/FCC certification
Fanless, Wide-temperature with high performance and flexibility
Independent displays supported (HDMI, micro HDMI, LVDS)
One-Stop Integrated Solution: Integrated ultra compact motherboard, chassis,
peripherals and software
Dimensions: 116 x 141 x 35 mm (4.6 x 5.6 x 1.4 in”)
3 UTX-3115 User Manual
Chapter 1 Introduction
1.2 System Configuration
The following diagram is a block drawing of the UTX-3115.
Button I/O arrangement:
48-bit LVDS
Intel Atom
E3826
DDR3L 1333 MHz SO-DIMM
Channel B
DDR3L 1333 MHz SO-DIMM
Channel A
HDMI
VGA
Chrontel 7511
LVDS
micro HDMI
1 SATA port
300 MB/s
1 USB2.0
1 Micro USB2.0
USB 2.0
1 USB 3.0 port
USB 3.0
Realtek Audio Codec
ALC892
HD Audio
GbE LAN2:
Realtek RTL8111G
1RS-232 & 1 RS-422/485
PCIe x1
GbE LAN1:
Intel I210AT
PCIe x1
mSATA
SIM Card holder
PCIe x1
Full-size Mini-PCIe
Half-size Mini-PCIe
UTX-3115 User Manual 4
Chapter 2
2Hardware Description
This Chapter describes the hard-
ware features of the UTX-3115.
UTX-3115 User Manual 6
2.1 General Specifications
2.1.1 Standard PC Functions
CPU: Intel ATOM e3826 1.46GHz
BIOS: AMI EFI 16bit
Memory: DDR3L SODIMM 1066/1333MHz up to 8GB
Audio: HD audio codec ALC892
LAN: PCI-E gIGABIT Ethernet controllers x2
LAN1: Intel i210AT; LAN2: RTL8111G
Universal serial bus (USB) port: 1 USB3.0/1 USB2.0/ 1 Micro USB2.0, 3 ports
for external I/O
Mini PCI-E bus expansion slot: 1 F/S miniPCIE support mSATA/3G card; 1 H/
S miniPCIE support WIFI card
Storage housing: 1 2.5" slim SSD
Audio: Mic-in, Line-out
LAN: Gigabit LAN x 2
2.1.2 Power Environmental
Power adaptor: AC/DC
–Input voltage: 100 Vac ~ 240 Vac
–Output voltage: 12 V @ 3 A
2.2 Mechanical Specifications
2.2.1 Mechanical Specifications (Terminal)
System Dimensions: 138.5 x 35.98 x 116.4 mm (5.5" x 1.4" x 4.6")
Carton Dimensions: 255 (L) X 235 (W) X 160 (H) mm
Gross Weight: 2.0 kg
Net Weight: 1.8 kg
138.50
116.40
Chapter 3
3Design Requirements
This Chapter describes the design
requirements of the UTX-3115.
UTX-3115 User Manual 8
3.1 Environmental Specifications
Temperature & Humidity
Operating Temperature: -20 ~ 60° C
Storage Temperature: -40 ~ 60° C
Relative Humidity: 40 ~ 95% RH (Non-condensed)
Safety
CE / UL
EMI
FCC class B approved for USA, Canada, and EU
Vibration:
With SSD: 3Grms, 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis
9 UTX-3115 User Manual
Chapter 3 Design Requirements
www.advantech.com
Please verify specifications before quoting. This guide is intended for reference
purposes only.
All product specifications are subject to change without notice.
No part of this publication may be reproduced in any form or by any means,
electronic, photocopying, recording or otherwise, without prior written permis-
sion of the publisher.
All brand and product names are trademarks or registered trademarks of their
respective companies.
© Advantech Co., Ltd. 2014
