Aeon Labs 20090416 AEON DOOR/WINDOW SENSOR User Manual Product Spec Aeon DW Sensor
Aeon Labs LLC. AEON DOOR/WINDOW SENSOR Product Spec Aeon DW Sensor
Users Manual
A
A
AE
E
EO
O
ON
N
N
L
L
LA
A
AB
B
BS
S
S
D
D
DO
O
OO
O
OR
R
R/
/
/W
W
WI
I
IN
N
ND
D
DO
O
OW
W
W
S
S
SE
E
EN
N
NS
S
SO
O
OR
R
R
(Z-Wave Magnetic Door/Window Sensor)
Product Overview:
The Aeon Labs D/W Sensor is a battery-powered Z-Wave magnetic door/window sensor with an
extremely small form factor. The D/W sensor will send radio signals up to 6 associated Z-Wave
devices within its own Z-Wave network when the main unit separates from the smaller unit.
Bidirectional mounting plate and push button allows for easy end-user installation. The Aeon
Labs D/W Sensor also has tamper prevention capabilities and low-battery alerts.
Product Highlights:
Small form factor and aesthetical design
Long battery life
Optimized antenna range
Ease of use and installation
Physical Specifications:
2.0cm x 3.4cm x 7.9cm (main body)
Technical Specifications:
USA and EU capable: 868.42mhz, 908.42mhz radio transceiver
2 year battery life with CR2 battery
Magnetic separation trigger function
Hidden tamper prevention trigger
Low battery detection
Z-Wave 5.02 protocol
300ft Z-Wave RF range (outdoor)
Operating Conditions:
-35 to +85 °C
FCC NOTE:
THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED
BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS
COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received,
including interference that may cause undesired operation.
