AeroAntenna Technology AT1595-82 ACTIVE INMARSAT ANTENNA User Manual USERS MANUAL
AeroAntenna Technology, Inc. ACTIVE INMARSAT ANTENNA USERS MANUAL
USERS MANUAL
20732 Lassen Street, Chatsworth, CA 91311
Phone: (818) 993-3842 Fax: (818) 993-4525
AT1621-20 Active Iridium Antenna
User Manual
AT15958284-01 Rev 1
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) this device may not cause
harmful interference and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
To satisfy FCC RF exposure requirements for
mobile transmitting devices, the minimum
safety distance is 55 cm (21.7 inches). This
separation distance should be maintained
between antenna and people during
operation of the antenna.
© 2013 AeroAntenna Technology, Inc. All Rights Reserved.
AeroAntenna Technology, Inc.
AT1595-82 IsatPhone Pro External Antenna User Manual Rev 1 5 Nov 2012
1 Important Safety Information Regarding Exposure to RF
Signals
WARNING
To satisfy FCC RF exposure requirements for mobile
transmitting devices, the minimum safety distance is
55 cm (21.7 inches). This separation distance should
be maintained between antenna and people during
operation of the antenna.
2 Specifications
EQUIPMENT TYPE Mobile or Fixed Base Station
INTEGRATED OPERATING
ENVIRON-MENT
[ x ] Commercial
[ x ] Light Industry & Heavy
Industry
POWER SUPPLY REQUIREMENT 9 to 36V DC, 30W maximum
RF INPUT POWER RATING
(US & CANADA)
30 dBm or 1.0 Watt peak
(conducted)
EIRP 10.93 dBW Max
DUTY CYCLE N/A
TX OPERATING
FREQUENCY RANGE 1626.5 – 1660.5 MHz
RX OPERATING
FREQUENCY RANGE 1525.0 – 1559.0 MHz
RF INPUT IMPEDANCE 50 Ohms
MODULATION G1W
EMISSION DESIGNATION 86K1G1W
ANTENNA TYPE Integral
ANTENNA CONNECTOR TYPE Inmarsat: SMA (Female)
GPS: SMA(Female)
TEMPERATURE RATING
STORAGE:
OPERATIONAL:
-40°C to +80°C
-25°C to +55°C
page 2 of 2 © 2013 AeroAntenna Technology, Inc. All Rights Reserved.
WARNING
MICROWAVE RADIATION
MINIMUM SAFE DISTANCE
0.55 METRES
