Emergency and Assistance Intercoms
2|
IP DIRECT SYSTEM: IX Series
Stations connect directly to a network using IP addresses
• Flexible and unlimited capacity
• Calls can be forwarded to offsite location
• Multiple sites can link together
• Centralize communication into one facility
• All stations are Edge Devices
Integrate Security Components
Decrease expenses by centralizing security and communication.
Aiphone intercom systems can control a multitude of security
functions or can easily integrate into an existing infrastructure. Video
Emergency Intercom Systems
Hardwired System: IS Series
All stations homerun wire back to a central control unit
• Secure connection and flexible wiring methods
• Homerun wiring back to CCU with extended distances
• No network connection required
• System always on regardless of network status
• Security of system not dependent on network
emergency stations help evaluate and assess situations quickly.
Aiphone has a solution to fit any single or multi-building security plan
with two platforms to choose from, each with their own advantages.
Choose between Two Intercom Platforms:
Modular Towers
Aiphone’s modular tower design allows for
maximum flexibility. Choose between 2-module
towers or 3-module towers. Stack modules at
gates to provide a station at car height and a
station at truck height. Pre-installed gaskets assure
all-weather performance and product longevity.
All towers come in a variety of configurations and
colors to suit any application.
Thin Wall Boxes
Aiphone wall boxes and emergency intercoms have been
manufactured to meet the latest ADA regulations. Stations and
wall boxes feature:
4"
|3
Easy Transportation and
Installation
Save on freight costs! Ship
modules to the site or transport
them easily in a truck or van.
Move modules using a hand
truck to locations with no access
roads. Since each module is
approximately 90lbs, installation
requires only two people.
For previously installed towers
and wall boxes, Aiphone can
help with retrofit panels and
recommend third party devices
to interface between 2 or 4
conductor wires to Cat-5e/6.
Aiphone intercoms meet today’s
technology expectations in both quality
and feature benefits. They offer advantages
over a traditional phone based system:
Upgrade and Retrofit
Existing Systems
Why are Emergency
Intercom Systems Better?
• No POTS line required saving on
monthly phone bills
• Video intercom stations provide visual
monitoring in addition to communication
• Station names can be customized to
pinpoint incoming call location quickly
• Raised station lettering
• Braille signage
• Call status indicator light
• Compliant call button mounting height on towers
• Mounting box clearance of 4” deep allows
mounting heights above 27” from floor
Emergency Intercoms
PROTECT:
Office Parks Campuses
Garages/Lots
Factories
#91266
Emergency & Assistance Intercoms Brochure
0 8 / 2015
Printed in USA
Aiphone Co. Ltd.
Deming
Prize
Aiphone Corp.
ISO 9001:2008
Certified
The information in this brochure is
subject to change without notice.
Aiphone Co. Ltd.
ISO-14001
Certified
Copyright © 2015. All Rights Reserved • T: (800) 692-0200 • F: (425) 455-0071 • www.aiphone.com |
2-Module Tower
• Beacon strobe light optional
(additional power required per light)
• Optional signage on up to 3 sides
3-Module Tower
• Beacon strobe light optional
(additional power required for lights)
• Optional signage on up to 4 sides
Features:
• Approximately 90lbs per module (Easy shipping and assembly)
• ¼” steel body with zinc treatment inside and out
• Weather and vandal resistant
Features:
• 12 gauge stainless steel
• Shallow depth provides location flexibility
• Weather and vandal resistant
IS-WBCE
Wall Box
• Caged light (additional
power required per light)
• Red “EMERGENCY” lettering
• Signage adhered on 2 sides
IS-WBHE
Wall Box
• Hooded light (additional
power required per light)
• Red “EMERGENCY” lettering
• Signage adhered on 2 sides
IS-WBHA
Wall Box
• Hooded light (additional
power required per light)
• Blue “ASSISTANCE” lettering
• Signage adhered on 2 sides
IS-WBCA
Wall Box
• Caged light (additional
power required per light)
• Blue “ASSISTANCE” lettering
• Signage adhered on 2 sides
Customizable Modular Towers
Thin 4” Wall Boxes
IX Series Emergency Stations
IP Direct System: IX Series
IX-DF-2RA
Dual Button Video
Emergency Station
• Fixed camera
• Dual call buttons
IP Direct System Benefits:
• Flexible and unlimited capacity
• Calls can be forwarded to offsite location
• Multiple sites can link together
• Centralize communication into one facility
• All stations are Edge Devices
IX Series Features:
• Power over ethernet (PoE)
• 24/7 ONVIF Profile S streaming video
• ADA Compliant Lettering and Braille signage
• Each station is IP Addressable
• LED call status indicator
• 2 Form C relay outputs
• Stainless steel emergency stations
IX-SS-2RA
Dual Button Audio Only
Emergency Station
• Dual call buttons
IX-SS-RA
Single Button Audio Only
Emergency Station
• Single call button
IS Series Emergency Stations
Hardwired System: IS Series
IS-DVF-2RA
Dual Button Video
Emergency Station
• PTZ camera
• Dual call buttons
IS Series Features:
• Requires IS Series Central Control Unit
(IS-CCU, IS-SCU and/or IS-RCU)
• ADA Compliant Lettering and Braille signage
• LED call status indicator
• 2 Form C relay outputs
• Stainless steel emergency stations
Hardwired System Benefits:
• Secure connection and flexible wiring methods
• Homerun wiring back to CCU with extended distances
• No network connection required
• System always on regardless of network status
• Security of system not dependent on network
IS-SS-2RA
Dual Button Audio Only
Emergency Station
• Dual call buttons
• CCTV input
IS-SS-RA
Single Button Audio Only
Emergency Station
• Single call button
• CCTV input
Mounting Solutions for IX Series and IS Series Emergency Stations
IS-IFB
Retrofit Bracket
• Adapts Emergency
Stations to fit into
previously installed,
non‑Aiphone towers
and wall boxes
