Turn your PCs into intercoms!
IPW-1A
Network Intercom Adaptor
Network Intercom Adaptor
IPW-1A
Network Intercom Adaptor
Install intercoms
anywhere
communication is needed
Step 1
:
Step 2
:
Wire each intercom to adaptor and
connect
to nearest network drop
Communicate between an innite
An EASY
&
affordable IP Solution
An EASY
&
affordable IP Solution
Automatically record audio to PCUnlock doors from inside or off site
Keep track of history with event logging Send out public announcements
CENTRAL MONITORING
Communicate to intercoms from a
central location or off site facility
SERVICE ENTRANCES
Unlock doors at auxiliary entrances
from reception or security offices
Step 3:
Communicate with intercoms
using PC software (included)
amount of stations and computers!
Send out public announcements
PARKING & GARAGES
Control unmanned booth stations
to increase staff efficiency
AFTER HOURS
&
HOLIDAYS
Assist employees or visitors remotely
when reception or security is closed
1700 130th Ave. NE
Bellevue, WA 98005
Ph: (800) 692-0200
Fax: (425) 455-0071
www.aiphone.com
# 98225 IPW-1A Brochure 02/2010
Distributed by:
GS-35F-0065L Aiphone Co. Ltd.
ISO-14001
Certied
Aiphone Corp.
ISO 9001:2000
Certied
Aiphone Co. Ltd.
Deming
Prize
IPW-1A Network Intercom Adaptor
electric
door strike
2 wires
PT-1211C
power supply
(included)
Intercom Station IPW-1A*PC
One IPW-1A per station. Intercom Station, door strike & PC sold separately.
Diagram is for illustrative purposes only. Refer to instructions for installation directions.
*
CommuniCenter Software
(included)
Quick door release from safely inside building
Switch between
“AVAILABLE”
&
“UNAVAILABLE”
when away
Simply mouse click on
“TALK”
to communicate with connected station
Broadcast announcements to stations within the system
Listen to activity at selected station for secure, discreet monitoring
Control any intercom station on the system network
Case
Aluminum
, 1-1/2” x 4-1/4” x 4-15/16”
Door Release
Form C dry contact, 30V AC / DC 1.0A (resistive)
Software Processor 1GHz or faster
256MB of RAM
Windows® XP (SP2) or Windows® Vista
Power Source 15V AC
Connections RJ45
(10/100 Mbit Ethernet)
, RS-232C
Specications (one IPW-1A per intercom station)
IPW-1A Contents
IP adaptor,
PT-1211C
- 15V AC power supply,
CommuniCenter software CD,
mounting bracket + hardware,
connectors & instructions
(intercom stations sold separately)
Compatible intercom stations (sold separately)
IF-DA
Plastic cover
Surface mount
IE-JA
Stainless Steel
faceplate
Flush mount
IE-DC
Plastic and
aluminum cover
Surface mount
IE-SS
Stainless Steel
Flush mount
AX-DM
Plastic cover
Mullion mount
IE-SSR
Stainless Steel with
red mushroom call button
Flush mount
