User manual
AirHarmony-1000 Installation Guide
Part Number: UGD-D01006
System Release: 14.1
Revision: A4
Published: August 2015
© Copyright by Airspan Networks Inc., 2015. All rights reserved worldwide.
Legal Notices
The information contained within this document is proprietary and is subject to all relevant copyright, patent and other laws
protecting intellectual property, as well as any specific agreements protecting Airspan Networks Inc. rights in the aforesaid
information. Neither this document nor the information contained herein may be published, reproduced or disclosed to third
parties, in whole or in part, without the express, prior, written permission of Airspan Networks Inc. In addition, any use of this
document or the information contained herein for the purposes other than those for which it is disclosed is strictly forbidden.
Airspan Networks Inc. reserves the right, without prior notice or liability, to make changes in equipment design or specifications.
Information supplied by Airspan Networks Inc. is believed to be accurate and reliable. However, no responsibility is assumed by
Airspan Networks Inc. for the use thereof nor for the rights of third parties which may be effected in any way by the use of
thereof.
Any representation(s) in this document concerning performance of Airspan Networks Inc. product(s) are for informational
purposes only and are not warranties of future performance, either expressed or implied. Airspan Networks Inc. standard
limited warranty, stated in its sales contract or order confirmation form, is the only warranty offered by Airspan Networks Inc. in
relation thereto.
This document may contain flaws, omissions or typesetting errors; no warranty is granted nor liability assumed in relation
thereto unless specifically undertaken in Airspan Networks Inc. sales contract or order confirmation. Information contained
herein is periodically updated and changes will be incorporated into subsequent editions. If you have encountered an error,
please notify Airspan Networks Inc. All specifications are subject to change without prior notice.
Product performance figures quoted within this document are indicative and for information purposes only.
Acknowledgements
© Intel Corporation http://www.intel.com/
© Microsoft Corporation http://www.microsoft.com
UGD-D01006 Airspan Commercial and Internal Use i
Table of Contents
Document Information ............................................................................. 1
Abstract .................................................................................................................. 1
Revision History ..................................................................................................... 1
Warnings and Cautions ........................................................................... 2
Human Exposure to Radio Frequencies ................................................................ 2
Radio Interference ................................................................................................. 2
Avoiding Radio Interference ................................................................................... 2
Modifications .......................................................................................................... 2
General .................................................................................................................. 2
Safety ..................................................................................................................... 2
Warning of Hazardous Voltages ............................................................................ 3
Adherence to European Directive 1999/519/EC .................................................... 3
Warning Symbols ................................................................................................... 3
Service Information ................................................................................................ 4
UL Information ....................................................................................................... 4
Lightning Protection ............................................................................................... 4
DECLARATION OF CONFORMITY ........................................................ 5
GPS Compliance ................................................................................................... 6
Maximum Output TX Power .................................................................... 7
Power Consumption ............................................................................................... 7
Antenna System ..................................................................................................... 7
Front Mounted Sector Antenna .............................................................................. 7
SelectaBeam Multi-beam Antenna ......................................................................... 8
AirHarmony-1000 Antenna Usage Options ............................................................ 8
About This Document ........................................................................... 10
Purpose ................................................................................................................ 10
Intended Audience ............................................................................................... 10
Document Conventions ........................................................................................ 10
Document Organization ....................................................................................... 11
Related Reading .................................................................................................. 11
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use ii
Customer Care Help Desk .................................................................... 12
Airspan Encourages Comments .......................................................................... 12
1 Introduction ....................................................................................... 13
1.1 AirHarmony-1000 .......................................................................................... 13
1.1.1 Deployment .................................................................................................. 13
2 Getting Started .................................................................................. 15
2.1 Workflow of Installation ................................................................................. 15
2.2 AirHarmony-1000 Installation Checklist ......................................................... 16
3 Verifying Prerequisites ...................................................................... 17
3.1 Verifying Site Requirements .......................................................................... 17
3.2 Verify Installation Requirements .................................................................... 17
3.2.1 Verify the Tools ............................................................................................ 17
3.2.2 Verify the Parts and Kits ............................................................................... 17
3.2.3 Power Supply ............................................................................................... 19
3.2.4 Verify Components ....................................................................................... 19
3.2.5 Physical Dimensions .................................................................................... 22
3.2.6 Environmental .............................................................................................. 23
4 Before Installation of AirHarmony-1000 ............................................. 24
4.1 Connection of GPS Antenna ......................................................................... 24
4.2 Weather-proofing of the Antenna Connections ............................................. 24
5 Installing AirHarmony-1000 ............................................................... 26
5.1 Pole Mount Assembly .................................................................................... 26
5.1.1 Installing AirHarmony-1000 Back-to-Back .................................................... 29
5.2 Wall Mount Assembly .................................................................................... 30
5.3 Securing AirHarmony-1000 to the Mounting Plate ........................................ 32
5.4 Front Mount Antenna Tilt Adjustment ............................................................ 33
5.5 LED Display .................................................................................................. 34
5.6 Connecting the Ground Cable ....................................................................... 34
5.7 Installing AC/DC Converter ........................................................................... 36
5.7.1 AC/DC Converter Pole Mount Assembly ...................................................... 36
5.7.2 AC/DC Converter Wall Mount Assembly ...................................................... 37
6 Cable Connections ............................................................................ 39
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use iii
6.1 Connecting the AC/DC Power Converter to AirHarmony-1000 ..................... 39
6.1.1 Power Cable Preparation ............................................................................. 39
6.2 Wiring AC Power Cable on the AC/DC Converter ......................................... 41
6.3 Wiring AC Power Input Cable ........................................................................ 43
6.4 Fiber Ethernet (SFP) Cable Installation ......................................................... 44
6.4.1 SFP Cable Connection ................................................................................. 44
6.5 Copper Ethernet Cable Installation................................................................ 46
6.5.1 Hardware Requirements .............................................................................. 46
6.5.2 Tool Requirements ....................................................................................... 47
6.5.3 Assembly Instructions .................................................................................. 47
7 Additional Installations (Non-Standard) ............................................. 50
7.1 Front Antenna Assembly ............................................................................... 50
7.2 Connecting RF Jumper Cables to External Antenna ..................................... 50
A Job Sheet .......................................................................................... 52
B Checklist ........................................................................................... 53
C Abbreviations .................................................................................... 54
Figures
Figure 1: AirHarmony-1000 with front mounted antenna and AirHarmony-1000 with sun-shield .......... 9
Figure 2: AirHarmony-1000 assembled with Front Mount antenna and GPS ...................................... 14
Figure 3: Workflow ................................................................................................................................ 15
Figure 4: AirHarmony-1000 Unit, bottom termination ........................................................................... 22
Figure 5: AirHarmony-1000 Unit, Top, RF ports ................................................................................... 22
Figure 6: Attaching GPS antenna to unit .............................................................................................. 24
Figure 7: Verify connection of RF cable ................................................................................................ 25
Figure 8: Weather-proof the connection ............................................................................................... 25
Figure 9: Pole mounting assembly preparation .................................................................................... 26
Figure 10: Mounting plate on pole ........................................................................................................ 27
Figure 11: Assemble clamp bands (4 required) .................................................................................... 27
Figure 12: Press down locking mechanism .......................................................................................... 27
Figure 13: Tighten clamp bands ........................................................................................................... 28
Figure 14: Pole mounting – exploded view ........................................................................................... 28
Figure 15: Mounted on pole .................................................................................................................. 29
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use iv
Figure 16: Back-2-Back Assembly ........................................................................................................ 30
Figure 17: Positioning wall mounting plate ........................................................................................... 31
Figure 18: Wall mounting plate fastened on wall .................................................................................. 31
Figure 19: Lift unit to top of mounting plate........................................................................................... 32
Figure 20: unit engages into slots on the top of mounting plate ........................................................... 32
Figure 21: AirHarmony-1000 unit engaged into the bottom slots ......................................................... 33
Figure 22: Tilt adjustment body ............................................................................................................. 33
Figure 23: Tilt adjustment antenna ....................................................................................................... 34
Figure 24: Attaching ground cable to AirHarmony-1000 ....................................................................... 35
Figure 25: attach ground cable to pole (example) ................................................................................ 35
Figure 26: Assemble clamp bands (2 required) .................................................................................... 36
Figure 27: Press down locking mechanism .......................................................................................... 36
Figure 28: Tighten clamp bands ........................................................................................................... 37
Figure 29: Pole mounting – exploded view ........................................................................................... 37
Figure 30: Wall mount – exploded view ................................................................................................ 38
Figure 31: Wall mount ........................................................................................................................... 38
Figure 32: AC/DC Converter with DC power connector ....................................................................... 39
Figure 33: DC Power connector pre-assembled on converter .............................................................. 39
Figure 34: Power connection - on bottom panel of AirHarmony-1000 .................................................. 40
Figure 35: Power cable assembly ......................................................................................................... 40
Figure 36: Power cable attached to AirHarmony-1000 ......................................................................... 40
Figure 37: Waterproof connector exploded view .................................................................................. 41
Figure 38: AC power cable preparation ................................................................................................ 41
Figure 39: Waterproof connector separated ......................................................................................... 41
Figure 40: Connector on cable .............................................................................................................. 41
Figure 41: Secure cable to connector ................................................................................................... 42
Figure 42: Power cable wires assembled ............................................................................................. 42
Figure 43: Numbered connector contacts ............................................................................................. 42
Figure 44: Assemble and tighten .......................................................................................................... 43
Figure 45: AC/DC converter cable connector assembly ....................................................................... 43
Figure 46: AC/DC converter wires assembled ...................................................................................... 43
Figure 47: Assemble and tighten .......................................................................................................... 43
Figure 48: Connector assembled and tightened ................................................................................... 44
Figure 49: LC duplex cable assembly ................................................................................................... 44
Figure 50: Cable connector hook up to the board connector ................................................................ 45
Figure 51: Slide on inner housing ......................................................................................................... 45
Figure 52: Slide over and click .............................................................................................................. 46
Figure 53: Ethernet cable thru connector .............................................................................................. 47
Figure 54: Ethernet cable stripped ........................................................................................................ 48
Figure 55: RJ45 wire positioning ........................................................................................................... 48
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use v
Figure 56: cable trimmed ...................................................................................................................... 48
Figure 57: RJ45 plug assembly ............................................................................................................ 48
Figure 58: RJ45 crimping ...................................................................................................................... 49
Figure 59: Crimped cable ...................................................................................................................... 49
Figure 60: RJ45 assembled .................................................................................................................. 49
Figure 61: Attaching front mount antenna assembly to AirHarmony-1000 ........................................... 50
Figure 62: Connecting RF cable ........................................................................................................... 51
Figure 63: Weather-proof the connection ............................................................................................. 51
Tables
Table 1: AirHarmony-1000 FCC Maximum Output TX Power ................................................................ 7
Table 2: AirHarmony-1000 ETSI Maximum Output TX Power ............................................................... 7
Table 3: Power Consumption .................................................................................................................. 7
Table 4: Front Mounted Sector Antenna Parameters ............................................................................. 8
Table 5: Omni Antenna Parameters ....................................................................................................... 8
Table 6: Typographic Conventions ....................................................................................................... 10
Table 7. Minimum Hardware Requirements ......................................................................................... 17
Table 8. Parts & Kits ............................................................................................................................. 17
Table 9: AirHarmony-1000 additional items .......................................................................................... 19
Table 10: AirHarmony-1000 Components ............................................................................................ 20
Table 11. AirHarmony-1000 Physical Dimensions................................................................................ 22
Table 12. AirHarmony 1000 Environment Compliance ......................................................................... 23
Table 13: LED display ........................................................................................................................... 34
Table 14: Hardware ............................................................................................................................... 46
Table 15: Tools ..................................................................................................................................... 47
AirHarmony Installation Guide
UGD-D00105 Airspan Commercial and Internal Use 1
Document Information
Abstract
This document details procedures for installing the Airspan’s AirHarmony 1000 Indoor-Pico
Enterprise-Femto eNodeB variant.
Revision History
Revision Details
Date
Summary of Changes
Rev 0.1
October 2014
Initial document
Reformatted and revised the document.
Rev A + A1
November 2014
Updates
Rev A2 +A3
February 2015
B2B mounting option
Updates
Rev A4
August 2015
Additional Antenna
Additional content
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 2
Warnings and Cautions
Human Exposure to Radio Frequencies
The AirHarmony-1000 antennas should be installed and operated from a minimum safe distance of:
AirHarmony-1000 with Front Mount Antenna: 2.5m
AirHarmony-1000 with External Antenna: 2.5m
AirHarmony-1000 with Smart Beam Antenna (SBA): 0.5m (pending)
Radio Interference
This AirHarmony-1000 generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment on and off, the technician is encouraged to try to correct
the interference by performing one or more of the following measures:
Re-orientate or relocate the unit
Increase separation between the eNodeBs and/or End Device
Connect the equipment to an outlet on a circuit different from that to which the power source
is connected
Avoiding Radio Interference
Ensure a minimum of 1-meter separation between co-located AirHarmony 1000 units.
Modifications
Any changes and modifications to this device that are not expressly approved by Airspan Networks
may void the user's authority to operate the equipment.
General
Only qualified personnel should be allowed to install, replace, and service the equipment.
The device cannot be sold retail, to the general public or by mail order. It must be sold to
operators.
Installation must be controlled.
Installation must be performed by licensed professionals.
Installation requires special training. The AirHarmony-1000 radio and antenna should be
installed ONLY by experienced installation professionals who are familiar with local building
and safety codes and, wherever applicable, are licensed by the appropriate government
regulatory authorities. Failure to do so may void Airspan's product warranty and may expose
the end user or the service provider to legal and financial liabilities. Airspan and its resellers
or distributors are not liable for injury, damage or violation of regulations associated with the
installation of outdoor units or antennas.
The device is to be installed in a Restricted Access Location.
Safety
1. Read this guide and follow all operating and safety instructions.
2. Keep all product information for future reference.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 3
3. This product is supplied with a grounding connection which must be connected. Do not
defeat this important safety feature.
4. Static sensitive components inside - do not remove the lid or base: No user serviceable
parts inside.
5. Position the power cord to avoid possible damage; do not overload wall outlets.
6. Do not place this product on or near a direct heat source, and avoid placing objects on
the terminal.
7. To avoid electrical shock do not install this device during adverse conditions such as rain
or inclement weather.
8. Use only a damp cloth for cleaning. Do not use liquid or aerosol cleaners. Disconnect the
power before cleaning.
9. The units should not be located too near power lines or other electrical power circuits,
where it can come into contact with such power lines or circuits.
10. The radio transceiver must be properly grounded to protect against power surges and
accumulated static electricity. It is the user’s responsibility to install this device in
accordance with the local electrical codes.
11. Installation of the AirHarmony-1000 must be contracted to a professional installer.
12. Disconnect Device. The socket outlet should be easily accessible in case you have to
disconnect the device.
13. When installed in the final configuration, the product must comply with the applicable
Safety Standards and regulatory requirements of the country in which it is installed. If
necessary, consult with the appropriate regulatory agencies and inspection authorities to
ensure compliance.
Warning of Hazardous Voltages
On AC installations, hazardous voltages exist. Use caution when verifying or working with AC power.
Remove metal jewellery that could come into contact with AC power.
On DC sections, short-circuiting the low voltage, low impedance circuits can cause severe arcing that
may result in burns or eye damage. Remove rings, watches etc. to avoid shorting DC circuits.
Note: Airspan products do not contain hazardous substances (as defined in UK Control of
Substances Hazardous to Health Regulations 1989 and the Dangerous Substances Regulations
1990). At the end of any Airspan products life cycle, the customer should consult with Airspan to
ensure that the product is disposed of in conformance with the relevant regulatory requirements.
Adherence to European Directive 1999/519/EC
European Council Recommendation 1999/519/EC details basic restrictions and reference levels on
human exposure to electromagnetic fields as advised by the ICNIRP. Adherence to these
recommended restrictions and reference levels should provide a high level of protection as regards
the established health effects that may result from exposure to electromagnetic fields.
Warning Symbols
The following symbols may be encountered during installation or troubleshooting. These warning
symbols mean danger. Bodily injury may result if you are not aware of the safety hazards involved in
working with electrical equipment and radio transmitters. Familiarize yourself with standard safety
practices before continuing.
Electro-Magnetic Radiation
High Voltage
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 4
Service Information
Refer all repairs to qualified service personnel. Do not modify any part of this device, as this will void
the warranty.
Disconnect the power to this product and return it for service if the following conditions apply:
a. The terminal does not function after following the operating instructions outlined in this
manual.
b. Liquid has been spilled, a foreign object is inside, or the terminal has been exposed to
rain.
c. The product has been dropped or the housing is damaged.
Locate the serial number of the terminal and record this on your registration card for future reference.
Also record the MAC address, located on the product sticker.
UL Information
- The equipment must be properly grounded according with NEC and other local safety code
requirements.
- Reminder to all the BWA system installers: Attention to Section 820-40 of the NEC which provides
guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected
to the grounding system of the building, as close to the point of cable entry as is practical.
- AirHarmony-1000 is designed to operate in environmental conditions complying with IP66 and
relevant standards.
Lightning Protection
WARNING: The following notes are general recommendations for the system. The wireless
equipment should be installed by a qualified professional installer and must follow local and national
codes for electrical grounding and safety. Failure to meet safety requirements and/or use of non-
standard practices and procedures could result in personal injury and damage to equipment. A direct
lightning strike may cause serious damage even if these guidelines are followed.
All outdoor wireless equipment is susceptible to lightning damage from a direct hit or induced current
from a near strike. Lightning protection and grounding practices in local and national electrical codes
serve to minimize equipment damage, service outages, and serious injury. The antennas are to be
DC grounded, so surge protection is not required. Reasons for lightning damage are summarized as:
- Poorly grounded tower/antenna sites that can conduct high lightning strike energy into equipment.
- Lack of properly installed lightning protection equipment that can cause equipment failures from
lightning induced currents.
A lighting protection system provides a means by which the energy may enter earth without passing
through and damaging parts of a structure. A lightning protection system does not prevent lightning
from striking; it provides a means for controlling it and preventing damage by providing a low
resistance path for the discharge of energy to travel safely to ground. Improperly grounded
connections are also a source of noise that can cause sensitive equipment to malfunction.
A good tower grounding system disperses most of the surge energy from a tower strike away from the
building and equipment.
To limit the equipment damage due to a lightning strike, the following practices are recommended for
the wireless system:
- Provide direct grounding from the antenna mounting bracket, the radio and antenna and the
lightning/surge protectors to the same ground point at the base of the tower or a ground bus on the
building. Use the grounding screws on the antenna bracket and the radio and antenna for terminating
the ground wires.
- The AC wall outlet ground must be connected to the same grounding system as the eNodeB.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 5
DECLARATION OF CONFORMITY
European Community, Switzerland, Norway, Iceland, and Liechtenstein
Declaration of Conformity with Regard to the R&TTE Directive 1999/5/EC
English:
This equipment is in compliance with the essential requirements and other relevant provisions of
Directive 1999/5/EC.
Deutsch:
Dieses Gerät entspricht den grundlegenden Anforderungen und den weiteren entsprecheneden
Vorgaben der Richtlinie 1999/5/EU.
Dansk:
Dette udstyr er i overensstemmelse med de væsentlige krav og andre relevante bestemmelser i
Directiv 1999/5/EF.
Español:
Este equipo cumple con los requisitos esenciales asi como con otras disposiciones de la Directive
1999/5/EC.
Greek:
ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Airspan ΔΗΛΩΝΕΙ ΟΤΙ Ο ΕΞΟΠΛΙΣΜΟΣ ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ
ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ.
Français:
Cet appareil est conforme aux exigencies essentialles et aux autres dispositions pertinantes de la
Directive 1999/5/EC.
Íslenska:
Þessi búnaður samrýmist lögboðnum kröfum og öðrum ákvæðum tilskipunar 1999/5/ESB.
Italiano:
Questo apparato é conforme ai requisiti essenziali ed agli altri principi sanciti dalla Direttiva
1999/5/EC.
Nederlands:
Deze apparatuur voldoet aan de belangrijkste eisen en andere voorzieningen van richtlijn
1999/5/EC.
Norsk:
Dette utstyret er i samsvar med de grunnleggende krav og andre relevante bestemmelser i EU-
directiv 1999/5/EC.
Português:
Este equipamento satisfaz os requisitos essenciais e outras provisões da Directiva 1999/5/EC.
Suomalainen:
Tämä laite täyttää direktiivin 1999/5/EY oleelliset vaatimukset ja on siinä asetettujen muidenkin
ehtojen mukainen.
Svenska:
Denna utrustning är i överensstämmelse med de väsentliga kraven och andra relevanta
bestämmelser i Direktiv 1999/5/EC.
Român:
Acest echipament este în conformitate cu cerinţele esenţiale şi alte prevederi relevante ale Directivei
1999/5/CE.
The Declaration of Conformity related to this product can be obtained from PLM@Airspan.com.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 6
GPS Compliance
The GPS is in compliance with the essential requirements and other relevant provisions of Directive
1999/5/EC."
The GPS complies with the following EMC Common Regulatory Testing standards:
EN55022: Radiated and Conducted Emissions
CISPR 22: Class B
EN 50081-1: Generic Emissions Class B
EN 50082-1: Generic Immunity Class B
EN 61000-4-2: Electrostatic Discharge Immunity
EN 61000-4-3: Radiated RF EM Field Immunity Test
EN 61000-4-4: Electrical Fast Transient/Burst Test
EN 61000-4-6: Conducted Immunity
EN 61000-4-8: Magnetic Field Immunity
Note: A GPS is recommended for synchronizing between LTE sectors.
Note: An optional GPS Lightning/Surge protector is available from Airspan when installing the GPS
antenna in a remote location for lightning prone deployments.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 7
Maximum Output TX Power
Table 1: AirHarmony-1000 FCC Maximum Output TX Power
Frequency Band
FCC
TX EIRP
Antenna Gain
2300-2400 MHz
TBDdBm
TBDdBM
12dBi
2496-2 690 MHz
39.86dBm
57.86dBm
18dBi
Table 2: AirHarmony-1000 ETSI Maximum Output TX Power
Frequency Band
ETSI
TX EIRP
Antenna Gain
2300-2400 MHz
40dBm
52dBm
12dBi
2496-2 690 MHz
40dBm
58dBm
18dBi
Caution: Do not set maximum output TX power to higher than local regulations.
Power Consumption
AirHarmony-1000 has a Max nominal power consumption of 130W. AirHarmony-1000 power
consumption is described in the following table:
Table 3: Power Consumption
Duplex
Tx Power at RF
Port (dBm)
Nominal Power
Consumption (W)
Power Supply Requirement (W)
FDD
TBD
TBD
TBD
TDD
37
156
200
Antenna System
The following antennas are designed specifically for AirHarmony-1000 deployments. Externally
mounted antennas are available for use as well (pending), but are specified separately.
Note: For a list of compatible external antennas, please contact your nearest Airspan sales
representative.
Front Mounted Sector Antenna
The front mounted sector antenna is a cross polarized fixed antenna which mounts on the front of the
unit in place of the sun-shield.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 8
Note: When using a front mounted antenna, external antennas cannot be used.
Note: When using external antennas, the sun-shield must be used.
Table 4: Front Mounted Sector Antenna Parameters
Parameter
2.x GHz
3.x GHz
Frequency
2.3–2.7
2.3–2.7
3.3–3.8
Polarization
Dual Slant ±45
Dual Slant ±45
Dual Slant ±45
Polarization discrimination
18 dB
15 dB
>15 dB
Boresight gain
12 dBi
7.5 dBi
11.5 dBi
Azimuth HPBW
65
90 ± 10
65
Elevation HPBW
22
20
22
Electrical tilt
-1
N/A
-1
Grounding
DC GND
DC GND
DC GND
SelectaBeam Multi-beam Antenna
The SelectaBeam SC-800 provides four direction beams and an omnidirectional pattern covering
360 in azimuth. Beam selection is achieved via a digital control interface.
Table 5: Omni Antenna Parameters
Parameter
2.x GHz
Frequency
2.3–2.7
Polarization
Dual Slant ±45
Polarization discrimination
16 dB
Boresight gain
2.0 dBi
Peak gain
7.5 dBi
Azimuth HPBW
Omni-Directional
Elevation HPBW
20
Electrical tilt
N/A
Grounding
DC GND
AirHarmony-1000 Antenna Usage Options
AirHarmony-1000 comes in a range of frequency variants that can be mounted with different
antenna options and formats. Initially deliveries are of the Front Mount Antenna variant.
A typical sector installation will have a cross-polar sector antenna fitted directly to the front of the
AirHarmony-1000 main unit. (This is attached instead of the sun-shield in other variants - pending).
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 9
Figure 1: AirHarmony-1000 with front mounted antenna and AirHarmony-1000 with sun-shield
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 10
About This Document
Purpose
This guide provides the workflow and step-by-step procedures for Installing the AirHarmony-1000.
These procedures include:
Verify prerequisites
Install wall / pole mount
Install the AirHarmony-1000
Install the AC/DC converter
Connect and manage cables
Intended Audience
This guide is intended for persons who are responsible for installing the AirHarmony-1000 equipment.
These persons should have a working knowledge of the equipment.
Document Conventions
This document uses the following typographic conventions.
Table 6: Typographic Conventions
Convention
Element
Blue underlined text
Cross-reference links.
Bold text
Keyboard buttons and GUI elements.
Command
Command names or phrases.
Computer output
Text displayed by the computer.
Hyperlinks
Website and e-mail addresses.
Danger
Signifies a hazardous situation—if not avoided—will
cause death or serious injury. Describes how to avoid
it.
Warning
Signifies a hazardous situation—if not avoided—can
cause death or serious personal injury. Describes
how to avoid it.
Caution
Signifies a hazardous situation—if not avoided—can
void the product warranty, and cause property
damage. Describes how to avoid it.
Important
Provides necessary information to explain a task.
Note
Provides additional information.
Tip
Provides helpful hints.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 11
Document Organization
Chapter
Contents
Introduction
Provides a comprehensive overview of AirHarmony 1000 and
its installation.
Getting Started
Provides workflows for initial install and workflow.
Verifying Prerequisites
Lists the hardware, software, and client requirements for
installation.
AirHarmony-1000 Installation
Describes how to install AirHarmony-1000.
Install the AC/DC converter
AC/DC converter installation
Connect and Manage Cables
Describes how to connect the cables.
Job Sheet
Provides information that aids users in performing the
installation.
Checklist
Provides an overview of the high–level steps involved in the
workflow.
Abbreviations
Lists the abbreviations used in this document and their
expansions.
Related Reading
The following documents contain related information:
AirHarmony-1000 Hardware Product Specification
AirHarmony-1000 Commissioning Manual
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 12
Customer Care Help Desk
Airspan’s Customer Care Help Desk offers prompt and efficient customer support services.
Note: To avail Airspan’s Customer Care Help Desk support, you must be a registered user and
must have a valid support contract. To register, click here and fill the Registration form.
To create and update issue logs, send e-mails to Customer Care Help Desk. Once you submit your
issue, the system generates a new issue and sends an issue number for your reference. The system
uses this issue number to categorize and store e-mails under the appropriate issue.
To help Customer Care Help Desk identify your issue, include the issue number and your Customer
Care Helpdesk account details in all further communications.
Main Operations
Airspan Communications Ltd.
Capital Point
33 Bath Road
Slough, Berkshire
SL1 3UF, United Kingdom
Tel: +44-1895-467-100
Worldwide Headquarters
Airspan Networks Inc.
777, Yamato Road, Suite 105
Boca Raton, FL 3341-4408, USA
Tel: +1 561 893 8670
Airspan Encourages Comments
Airspan welcomes any feedback and suggestions that help to improve the quality of the
documentation. Send your feedback to documentfeedback@airspan.com.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 13
1 Introduction
This section provides a descriptive overview of the Airspan’s AirHarmony-1000 Micro / Pico eNodeB
variant and its place in the Airspan product suite.
1.1 AirHarmony-1000
AirHarmony-1000 is part of Airspan’s carrier-class 4G Micro eNodeB family. AirHarmony-1000
supports 3GPP’s Long Term Evolution (LTE) eNodeB specifications, providing high-speed data and
mobility in order to meet the demands of the Broadband Wireless Access market.
AirHarmony-1000 is a compact, easy to install Micro / Pico-cell, allowing an operator to deploy LTE
broadband services using existing Street Furniture (e.g. street lamps, power poles, etc…)
AirHarmony-1000 employs Software Defined Radio (SDR) technology, together with two transmit and
receive paths, antennas and a GPS receiver - all in a highly integrated, physically small and light, All-
Outdoor package, targeted to blend seamlessly into the urban environment. This very compact
outdoor product minimizes physical footprint, power consumption and operator OPEX.
AirHarmony-1000 will support a wide array of frequencies and channel sizes, able to operate in both
licensed and unlicensed bands. Frequencies and channel sizes will be added regularly.
AirHarmony-1000 implements dual 37 dBm (2 x 5W) transmitters with the availability of several
optional integral antennas and external antennas connectivity.
AirHarmony-1000 fully supports the standard LTE (Uu/S1/X2) interfaces.
All Airspan eNodeB products, including AirHarmony-1000, are interoperable with a rich portfolio of 3rd
party end user devices, including many handsets, indoor UEs, outdoor UEs and USB dongles from
several ODMs, using various chipsets. For an updated of interoperability list, please contact your
nearest Airspan Sales Representative.
Note: For management please refer to the AirHarmony-1000 LTE Commissioning Manual as well
as the Netspan User Manual.
1.1.1 Deployment
A highly flexible and scalable 4G Base Station, the AirHarmony-1000 is capable of supporting LTE
profiles across multiple frequency bands.
Note: The following is for illustration only; actual layout may differ as infrastructure is installation-
specific.
Note: AirHarmony-1000 must be properly grounded according with NEC and other local safety
code requirements.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 14
Figure 2: AirHarmony-1000 assembled with Front Mount antenna and GPS
Note: The illustration above displays the GPS connected directly to the top of the unit; there is also
a remote GPS antenna option.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 15
2 Getting Started
2.1 Workflow of Installation
The Workflow to install the AirHarmony-1000 is shown in the following diagram:
Figure 3: Workflow
Caution: Antennas must be connected and attached before AirHarmony-1000 is powered on.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 17
3 Verifying Prerequisites
Prior to installing the AirHarmony-1000, verify the required safety, power, tools, parts and
components. This chapter includes the hardware, software, and client requirements for installation.
Important: Set up requirements for the installation is detailed in the Job Sheet, see Appendix A.
3.1 Verifying Site Requirements
To set up the AirHarmony-1000, an IP connection to a Netspan server is required.
3.2 Verify Installation Requirements
3.2.1 Verify the Tools
Note: AirHarmony-1000 variants with front mounted, Sunshield (pending) and Switched Beam
(pending) antennas come pre-assembled from the production line.
Table 7. Minimum Hardware Requirements
Tool
Use
Large flat bladed screwdriver
securing the pole straps
10mm or 13/32 inch wrench
for securing flange nuts
Large pliers
Tightening cable glands - To fit 15mm
3.2.2 Verify the Parts and Kits
Note: Verify order and requirements to ensure the correct unit type is being installed.
Table 8. Parts & Kits
Installation Kit / Part
Part No.
Consisting of:
Note:
AirHarmony 1000 2.5 GHz
(B38, B41), Conn
HAR10-CN-U41-
B01D
AirHarmony 1000 2.496 - 2.69
GHz (B38, B41),
Connectorized, Fiber BH
DC output - 16AWG x
4 connected to
AirHarmony 1000 DC
connector
AirHarmony 1000, 2.3 GHz
(B40), Front
HAR10-FM-U40-
B01D
AirHarmony 1000 Front Mount,
2.3 GHz (B40), Fiber
Backhaul, DC
DC output - 16AWG x
4 connected to
AirHarmony 1000 DC
connector
AirHarmony 1000, 2.3 GHz
(B40), Conn
HAR10-CN-U40-
B01D
AirHarmony 1000
Connectroized, 2.3 GHz (B40),
Fiber Backhaul, DC
DC output - 16AWG x
4 connected to
AirHarmony 1000 DC
connector
AirHarmony 1000 universal
wall & pole mounting kit
HAR10-U-PMK-1
Wall / pole mounting bracket
for the AirHarmony + 4 bands
GPS Antenna
GPS-ANT-3
GPS Antenna
GPS Kit
GPS-HAR-KIT-1
GPS antenna, bracket, 16m
cable and surge protection kit
For remote GPS
antenna installation
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 18
Installation Kit / Part
Part No.
Consisting of:
Note:
Lightning/Surge protector
(part of GPS Kit)
N/A – part of GPS
Kit
Lightning protection 0-4 GHz
90V TNC(M/F)- L-COM
Current: 5KA
Voltage: 1000V +/- 20%
Power / Resistance: 50ohm
Operating Temp: -55 - 85
AC/DC Outdoor Power
Converter Kit
HAR10-ACDC-KIT-
ODUL-1
Wall & Pole mounting for
AC/DC Converter
Mounting bracket for
AC/DC converter.
Serratub Maxi Clamp,
band 12mm wide + quick
adjust lock, 50-215mm
pole dia.
Sems Pan Hd M4x10 DIN
7985 with Plain&Spring
Washers, St St, A2
AC/DC Converter 48V,
240W, 90-305Vac, IP67, -
30/+70C, EN60950-1
SYN-PSU-ODUL-AC-2
DC side cable is pre-
connected to the
AirHarmony-1000 DC
plug. Cable length is
300/1000mm
AC side cable 3 wires
(brown, blue & green).
Cable length 300mm.
should be connected to
the AC cable by using the
weather-proof cable joiner.
AC cable weather-proof
cable joiner - SYN-PWR-
JOIN-1
AC/DC converter
supplied pre-
connected to the DC
plug. DC cable length
is 300mm or 1000mm.
AC joiner and
mounting kit are to be
assembled during field
installation.
AC Cable
CBL-AC-3x18AWG-
1
AC Cable, 3x 18AWG per
meter, (white, black & green)
Grounding Cable
CBL-GND-1M-1
Grounding cable per meter
(green)
Grounding Lug
CON-LUG-GND-1
Ring Terminal for 6AWG
grounding cable. (M6 x 8mm
screw)
DC Power cable v1, 10m
PWR-10-MF-1
DC Power cable
Alternative to the
AC/DC converter kit.
Additional lengths will
be defined as required.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 19
Installation Kit / Part
Part No.
Consisting of:
Note:
Outer Fiber Cables
(various lengths)
FIB-FA-10-LC-
SM-1
10M
FIB-FA-15-LC-
SM-1
15M
FIB-FA-30-LC-
SM-1
30M
FIB-FA-50-LC-
SM-1 50M
FIB-FA-75-LC-
SM-1
75M
FIB-FA-100-LC-
SM-1
100M
FIB-FA-150-LC-
SM-1
150M
FIB-FA-200-LC-SM-
1
200M
Outdoor fiber cable is available
in 8 different lengths
PVC Insulation tape
PVC-INS-TAPE-1
20m, Black 19mm width
Self-amalgamating
waterproof tape
S-AMAL-WP-TAPE-
1
10m, Black 25mm width
Airspan Recommends:
Finisar SFP Transceiver
FTLF1318P3BTL 1000BASE-LX
Tested and approved by Airspan.
Available from Airspan if required.
Table 9: AirHarmony-1000 additional items
Additional Common Accessories
(not provided by Airspan)
Cable ties
3.2.3 Power Supply
AirHarmony-1000 supports direct connection to DC power source (-48V DC):
Operational Voltage Range: -40.5 to -57 VDC
Transient Voltage: +150V (ETR283)
AC power feed is also available, using an AC/DC power converter offered by Airspan.
3.2.4 Verify Components
The following figures display various AirHarmony-1000 components and accessory kits.
Note: AirHarmony-1000 variants with front mounted, Sunshield (pending) and Switched Beam
(pending) antenna come factory pre-assembled. Verify order and requirements to ensure the
correct unit type is being installed.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 20
Table 10: AirHarmony-1000 Components
Parts
Images
AirHarmony-1000 Unit (with front
mounted antenna) in typical packing
box
HAR10-FM-U40-B01D
AirHarmony-1000 Unit (with
Sunshield) in typical packing box
(Pending)
HAR10-CN-U40-B01D
Universal mounting plate
HAR10-U-PMK-1
Pole Clamps X 2
(included in above)
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 21
Parts
Images
AC/DC Outdoor Power
Converter Kit - HAR10-ACDC-
KIT-OD-1
Kit includes:
PSU (shown)
Mounting bracket +
hardware
Circular connectors (male
& female)
Serratub Maxi Clamp (2)
GPS antenna - GPS-ANT-2
AC cable (3x18AWG)
Outer Fiber Cables (ASX Optical
cables in 8 available lengths)
Ground cable with grounding lug
(Note that the cable is ordered per
meter and the lug is ordered
separately. Crimping is done by the
user)
PVC Insulation tape
Self-Amalgamating Tape
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 22
AirHarmony-1000 is shown below from the Ethernet termination and RF port end views respectively.
Copper Ethernet connection is currently unsupported.
Figure 4: AirHarmony-1000 Unit, bottom termination
Figure 5: AirHarmony-1000 Unit, Top, RF ports
3.2.5 Physical Dimensions
AirHarmony-1000 is in an all outdoor enclosure.
Table 11. AirHarmony-1000 Physical Dimensions
Variant
Dimensions (H x W x D)
Comment
Initial Deliveries - Front Mount (only)
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 23
Variant
Dimensions (H x W x D)
Comment
Front Mount Antenna
549 x 142 x 228 mm / 21.6 x 5.6 x
9.0 in.
The physical dimensions exclude
connectors
Future Deliveries
Connectorized
(with sunshield) (pending)
549 x 142 x 203 mm / 21.6 x 5.6 x
8.0 in.
The physical dimensions exclude
connectors
SBA (with sunshield) (pending)
770 x 142 x 203 mm / 30.3 x 5.6 x
8.0 in.
Weight
Main unit (Connectorized)
11 kg (24.25 lb)
Universal mounting bracket
(Including pole straps)
925 g (2.04 lb)
Sun-shield
575 g (1.27 lb)
Front mount antenna & plate
1.35 kg (2.98 lb)
SBA Antenna
1 Kg (2.20 lb) (pending)
3.2.6 Environmental
Note: AirHarmony-1000 is not meant to be used in a Marine environment.
AirHarmony 1000 meets the following environmental requirements:
ETSI EN 300-019-1-4 Operational (non-weather protected equipment)
ETSI EN 300-019-1-1 Storage (weather protected, not temperature controlled locations)
ETSI EN 300-019-1-2 Transportation
Table 12. AirHarmony 1000 Environment Compliance
Type
Details
Standard Compliance
Operating temperature
-40°C to 55°C
ETSI 300 019 1-4
Operating humidity
5% - 100% non-condensing
ETSI 300 019 1-4
Storage temperature
-40°C to 70°C
N/A
Storage humidity
5% - 100% non-condensing
ETSI 300 019 1-4
Rain and dust ingress
protection
IP66
N/A
Operational altitude
70-106 kPa as well as:
From -60m to 1800m @ 40C
From 1800m to 4000m @ 30C
ETSI 300 019 1-4
Solar radiation
1120 W/m2
ETSI 300 019 1-4
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 24
4 Before Installation of AirHarmony-1000
Prior to installation of the AirHarmony either on a pole or a wall the GPS antenna should be
connected and the all antenna connections should be weather-proofed.
4.1 Connection of GPS Antenna
The following defines the connection of the GPS antenna which is installed directly to the top of the
unit.
1. Remove the protective dust cap from the GPS antenna jack prior to mounting on the
AirHarmony-1000.
2. Align the GPS jack with the plug attached to the top panel on the AirHarmony-1000.
3. Attach the GPS antenna to the TNC connector on the unit.
Figure 6: Attaching GPS antenna to unit
Caution: Take care not to over tighten so as not to damage the threads.
Note: It is good practice to weather-proof the antenna connections both the GPS connection and
the RF connections.
4.2 Weather-proofing of the Antenna Connections
Weather-proofing of all the connections is required. This is done with a layer of self-amalgamating
tape followed by an over layer of PVC tape. The weather-proofing is best done at this stage to give
easier access to the connections.
Note: It is good practice to weather-proof the antenna connections both the GPS connection and
the RF connections.
The RF connectors on the Front Mount Antenna variant arrive pre-connected. Weather-proofing is
best done at this stage to give easier access to the connections.
1. Verify a secure connection of the RF cable between the antenna and the appropriate RF
connection on the top of the unit.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 25
Figure 7: Verify connection of RF cable
Caution: Do not over-tighten the RF connector. RF failures can result when the RF connector is
over-tightened.
Figure 8: Weather-proof the connection
2. Weather-proofing of the connections is mandatory. This is done with a layer of self-
amalgamating tape followed by an over layer of PVC tape. Both the self-amalgamating tape
and the PVC tape are available from Airspan.
3. Verify the RF connector is completely weather-proof.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 26
5 Installing AirHarmony-1000
Install the AirHarmony-1000 eNodeB by pole mount or wall mount. AirHarmony-1000 is mounted on
a pole or wall with its pre-installed antenna (front mount or SBA variants (pending)) or in close
proximity to its external antenna (connectorized variant). Take care to install the mounting plate the
correct way up. This is with the slot openings in the bracket at the top edges as shown below.
Caution: Proper local rigging and hoisting practices should be followed when installing the
AirHarmony-1000.
5.1 Pole Mount Assembly
The following images show the pole mount assembly.
1. Prepare the mounting plate by assembling the pole clamps in the provided threaded holes
with the provided M8X20 Hex Cap screws.
Figure 9: Pole mounting assembly preparation
2. Insert the clamp straps through the slots in the mounting plate passing them through the pole
clamps.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 27
Figure 10: Mounting plate on pole
3. Position mounting plate on the pole with slots facing up.
4. Feed clamp bands through the quick release locking mechanisms and wrap around pole.
Figure 11: Assemble clamp bands (4 required)
5. Wrap the band to properly fit on the pole. Press down locking mechanism with band excess
fed through the mechanism.
Figure 12: Press down locking mechanism
6. Align and position each of the 4 pole clamps. Tighten the clamp bands with large flat
screwdriver in place.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 28
Figure 13: Tighten clamp bands
7. Mounting plate is installed and ready for AirHarmony-1000 mounting.
Figure 14: Pole mounting – exploded view
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 29
Figure 15: Mounted on pole
5.1.1 Installing AirHarmony-1000 Back-to-Back
In the event you want to deploy two (2) AirHarmony-1000(s) on the same pole – back-to-back, then
the installation must be performed so that the clamp bands used to secure the units to the pole do not
interfere with the clamp bands of the other unit. Each unit is installed separately as explained above in
Installing AirHarmony-1000. The clamp bands are installed with a small deviation to each other as
displayed below:
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 30
Figure 16: Back-2-Back Assembly
The difference in height between the installed units after installation will be 40mm.
Note: The Universal Mounting plate for each AirHarmony-1000 must be mounted on the pole prior
to assembling the AirHarmony-1000 units.
Assemble each unit’s AC/DC Converter as explained in AC/DC Converter Pole Mount Assembly with
the same deviation of the clamp bands.
5.2 Wall Mount Assembly
The following images show the wall mount assembly.
1. Position mounting plate against the wall with slots facing up. Be sure to position the wall
mounting plate straight with level mounting to ensure the unit sits evenly.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 31
Figure 17: Positioning wall mounting plate
2. Mark the wall through the holes on the wall mount at the required height.
3. Attach the mounting plate to the wall using wall plugs (x4) rated for at least 8-10 Kg per
fastener.
Figure 18: Wall mounting plate fastened on wall
Note: Wall plugs (x4) and necessary hardware are not supplied by Airspan and are the
responsibility of the installer. Recommended minimum 8mm dia. with appropriate wall
plugs according to field conditions.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 32
5.3 Securing AirHarmony-1000 to the Mounting Plate
Note: The following procedure shown with the Front-Mount antenna variant as shown
below.
To mount AirHarmony-1000 to the mounting plate, perform the following:
1. Loosely fit the flange nuts on the studs protruding from the sides of the unit.
Figure 19: Lift unit to top of mounting plate
2. Hook the studs into the top slots of the mounting plate.
Figure 20: unit engages into slots on the top of mounting plate
3. With the studs engaged in the top slots raise the unit slightly until the bottom studs also drop
into their respective slots.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 33
Figure 21: AirHarmony-1000 unit engaged into the bottom slots
4. Tighten the flange nuts (4 places) to the required degree of down-tilt.
5. Check and tighten all flange nuts.
5.4 Front Mount Antenna Tilt Adjustment
On the Front Mount Antenna variant it is possible, after assembly to adjust the front mounted antenna
tilt-down. There are adjustment slots located on the sides of unit body and on the sides of the front
mounted antenna mounting plate.
Note: Combined tilt adjustment of both the unit body and the antenna yield a maximum
down-tilt of 7.5°. The antenna has an electrical fixed down-tilt of 1°.
1. Slightly loosen the upper flange nuts (2) where the unit is fixed to the wall/pole mounting
bracket.
Figure 22: Tilt adjustment body
2. Slightly loosen the upper screws (2) where the front mount antenna is fixed to the unit.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 34
Figure 23: Tilt adjustment antenna
3. After adjusting to the required tilt amount tighten both flange nuts and both screws. The
antenna has an electrical fixed down-tilt of 1°.
5.5 LED Display
A single tri-color LED (Green/Red/Orange) appears at the bottom of the unit, providing unit status
indication. When powering up refer to the following table for indication of current status:
Table 13: LED display
Name
Color
Status
Description
Powering Up
Orange
On Continuously
Till the SW starts loading
Software loading
Green
Blinking (3Hz)
While SW is loading
Normal Operation
Green
On Continuously
Normal operation (no alarm)
Major Alarm
Red
Blinking (3Hz)
Service not affected
Critical Alarm
or
Sector OOS
Red
On Continuously
5.6 Connecting the Ground Cable
Connect the ground cable after attaching the grounding lug (optionally supplied by Airspan – CBL-
GND-1M-1 and CON-LUG-GND-1) to the M6 threaded connection on the bottom of the main body
casting.
Note: Cutting the Ground cable to the required length and crimping the grounding lug is
performed by the Installer.
Note: The ground cable is available per meter. The lug can also be used for securing the
ground cable to the other side.
Note: The ground surface is bare metal and needs no preparation.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 35
Note: Prior to insertion apply No-Ox or other approved anti-oxidation agent.
This ground cable should be connected to a protection ground bar or clamped directly to a steel
structure. A direct earth ground connection is required for the surge protection devices inside the
AirHarmony-1000 to be effective.
1. Remove grounding screw and slip the ring terminal end of the ground cable onto the screw
prior to re-setting into the threaded hole.
Figure 24: Attaching ground cable to AirHarmony-1000
2. Connect the ground cable to the protection ground bar using suitable crimp lugs.
Alternatively use a clamp to bond the ground cable to the mounting pole or to the tower
structure.
Figure 25: attach ground cable to pole (example)
Note: Above drawing is for illustration only – use locally approved method for grounding.
Note: For wood pole installations, a 5/8" x 8' ground rod should be installed immediately
adjacent to the wood pole and the #6 AWG stranded conductor extended down to the
ground rod and connected using and approved method (Exothermic or split bolt).
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 36
Note: When installing a protection ground take care to use suitable metal combinations
to avoid or minimize galvanic corrosion.
5.7 Installing AC/DC Converter
The AC/DC power converter kit can be optionally supplied by Airspan.
The kit includes the following:
AC/DC power converter with cables on both AC and DC side. The DC side comes pre-
connected to the AirHarmony-1000 DC plug and the AC side arrives with 3 bare wires.
Waterproof cable joiner to connect the AC side with the AC cable
Mounting bracket for pole mounting of AC/DC converter
The AC/DC Converter can be mounted on a pole (with the supplied mounting bracket) or on a wall.
The AC/DC Converter should be mounted in close proximity to the AirHarmony-1000 so as to
facilitate the proper connection.
5.7.1 AC/DC Converter Pole Mount Assembly
The following images show the pole mount assembly.
1. Insert the clamp straps through the slots in the mounting bracket.
2. Position mounting bracket on the pole with notched edges towards the pole.
3. Feed clamp bands through the quick release locking mechanisms and wrap around pole.
Figure 26: Assemble clamp bands (2 required)
4. Wrap the band to properly fit on the pole. Press down locking mechanism with band excess
fed through the mechanism.
Figure 27: Press down locking mechanism
5. Align and position each of the 2 clamps. Tighten the clamp bands with large flat screwdriver in
place.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 37
Figure 28: Tighten clamp bands
6. Mounting bracket is installed and ready for AC/DC Converter mounting.
7. Align the 4 mounting slots located on the flange of the AC/DC Converter with the 4
threaded holes on the mounting bracket.
8. Insert the 4 pan head screws (supplied) and tighten.
Figure 29: Pole mounting – exploded view
5.7.2 AC/DC Converter Wall Mount Assembly
The following images show the wall mount assembly. The converter can be fastened directly to a wall
utilizing the holes on the unit body (4 places).
Note: For the wall mount assembly the mounting bracket is not required.
Note: The AC/DC converter can be mounted horizontally if required.
1. Position AC/DC Converter against the wall in close proximity to the AirHarmony-1000 so as to
facilitate the proper connection.
2. Mark the wall through the holes on the AC/DC Converter at the required height.
3. Attach the AC/DC Converter to the wall using screws and wall plugs (x4) rated for at least 8-
10 Kg per fastener.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 38
Figure 30: Wall mount – exploded view
Figure 31: Wall mount
Note: Wall plugs (x4) and necessary hardware are not supplied by Airspan and are the
responsibility of the installer. Recommended minimum 8mm dia. with appropriate wall
plugs according to field conditions.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 39
6 Cable Connections
Hazardous voltage! Before working, ensure that the power is removed from the power
connection cables. When the system is powered on, do not touch the power
terminals.
6.1 Connecting the AC/DC Power Converter to
AirHarmony-1000
The DC Connector comes pre-assembled on the AC/DC Converter, as shown below:
Figure 32: AC/DC Converter with DC power connector
6.1.1 Power Cable Preparation
The Power cable is connected to the AirHarmony-1000 using a Gland connector assembled on the
bottom panel of the unit.
1. Remove the connector by unscrewing the body from the AirHarmony-1000, using the Gland
wrench.
2. Pass the pre-assembled connector through the tail nut, gland seal, body and rubber seal of
the connector casing as shown below. Do not tighten the tail nut.
Figure 33: DC Power connector pre-assembled on converter
Note The connector is attached inside the weather protected area of the enclosure and
is not subjected to water/moisture therefore the use of die-electric gels is not required.
3. Connect the DC power cable connector to the female connector outlet inside the unit.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 40
Figure 34: Power connection - on bottom panel of AirHarmony-1000
4. Screw the gland connector plug securely into the body cavity of the unit using the provided
Gland wrench.
5. Tighten the tail nut on to the body forcing the seal to compress around the power cable using
the (provided) Gland wrench.
Figure 35: Power cable assembly
Caution: Do not over tighten the gland connector or the tail nut. The gland nut should be
tightened to a torque of no more than 3.3 Nm (2.43 lb-ft) max.
Note: When securing the cable verify there is no tension on the connector so that it is
easy to disconnect and re-connect for future maintenance actions.
Caution: The internal plastic parts of the mating connector are keyed. Take care to align
these by visual inspection or by gently rotating the connector body until the key way
sections align and the pins go in before tightening.
Figure 36: Power cable attached to AirHarmony-1000
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 41
6.2 Wiring AC Power Cable on the AC/DC Converter
Advice: It is good practice to label both ends of the cable to identify which AirHarmony-
1000 unit it is connected to.
Advice: It is good practice to leave a spare loop of cable (approximately 0.5m). This will
allow for easier wiring and will allow the cable to be re-terminated if necessary in the
future.
Note: This is a waterproof connection therefore the use of die-electric gels is not
required.
The power cable is available in various lengths as required.
Figure 37: Waterproof connector exploded view
1. Route and bring the unterminated end of the AC power cable to the location of the AC/DC
converter.
2. Strip back and remove the outer sheath to expose the inner brown, blue and green insulated
wires to a length of 3cm (1.18 in). Then strip back 6mm (0.24 in) of the inner core insulation.
Figure 38: AC power cable preparation
Figure 39: Waterproof connector separated
3. Thread the prepared cable end through the gland, washer, sealing ring and body of the
connector.
Figure 40: Connector on cable
4. Secure the prepared ends of the cable into the head part of the connector.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 42
5. Secure the prepared ends of the power cable into the head part of the connector
(male part with visible pins).
Figure 41: Secure cable to connector
6. Insert and secure the brown wire into position 1 and the blue wire into position 2 and green
wire into position (earth ground).
Figure 42: Power cable wires assembled
Note: Individual connection numbers are marked on each part of the connector.
Note: Set screw maximum recommended tightening torque of 0,3 Nm.
Figure 43: Numbered connector contacts
7. Assemble the parts of the connector and tighten the gland to provide a waterproof seal.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 43
Figure 44: Assemble and tighten
6.3 Wiring AC Power Input Cable
1. Cut the AC power cable to the required length.
2. Prepare the ends of the AC/DC converter cable and thread the connector parts over the
cable.
3. Secure the prepared ends of the drop cable into the head part of the connector (female part).
Figure 45: AC/DC converter cable connector assembly
4. Insert and secure the white wire into position 1 and the black wire into position 2 and green
wire into position (earth ground).
Figure 46: AC/DC converter wires assembled
5. Assemble the parts of the connector and tighten the gland to provide a waterproof seal.
Figure 47: Assemble and tighten
6. Fasten the 2 parts of the connector together and tighten to make a waterproof seal.
7. Position the pins correctly; the connector is secured to the unit with a locking ring that is
screwed into place. Use firm hand pressure only, the connector has a built in sealing ring.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 44
Figure 48: Connector assembled and tightened
6.4 Fiber Ethernet (SFP) Cable Installation
The Fiber Ethernet Small form-factor pluggable transceiver (SFP) must be connected to the
AirHarmony -1000 using an outdoor fiber cable. The optical connection enables a one-hand
installation of the connector. This enables the users to easily remove and replace the SFP transceiver
module which eliminates the need to open the unit and expose its contents to hazardous weather
conditions.
Note: Airspan recommends using the Finisar - FTLF1318P3BTL 1000BASE-LX which
has been tested and approved by Airspan. Available from Airspan if required.
The Outdoor fiber cable is available in 8 different lengths from 10m to 200m.
Note: Airspan recommends to test the fibers prior to installation (using FOA’s standard
testing industry standards).
Note: Airspan recommends to clean the fibers according to standard procedure (using
FOA’s cleaning guidance).
6.4.1 SFP Cable Connection
Figure 49: LC duplex cable assembly
1. Remove the protective dust cap from the connector housing assembled on the unit.
2. Line up the SFP transceiver module with the port and slide it into the port.
3. Connect the cable connector onto the board connector.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 45
Figure 50: Cable connector hook up to the board connector
4. Verify that the locking latch on the cable connector is engaged on the board connector.
5. Slide the inner housing and ground shield (if present) over the cable and over the molding.
Figure 51: Slide on inner housing
Note: Check that there no space between the inner housing and mounting flange. Check
and remove any debris that might interfere with the connection.
6. Slide the outer shell over the inner housing and turn the outer bayonet shell 1/4 turn
clockwise, until it clicks into place.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 46
Figure 52: Slide over and click
Note: The shell should be hand tightened only. Do NOT use tools to tighten the shell.
7. Once the connector is properly installed, the cable should be positioned and secured to
minimize stress on the cable and connector.
6.5 Copper Ethernet Cable Installation
Note: The following images are for illustration purposes only. The actual tools or
hardware may differ according to manufacturer.
The following demonstrates the recommended assembly instructions, hardware and tool requirements
for the proper Ethernet cable assembly of the Ethernet Category 5e (enhanced) (CAT5e) cable used
by Airspan products.
The Ethernet cable is connected using a standard RJ45 connector protected by a harsh environment
protective casing.
6.5.1 Hardware Requirements
The following are the cable and connectors available from Airspan.
Table 14: Hardware
Airspan Part Number
Description
CAT5e-STP-305M-R
CAT5e Ethernet Cable, 305M (1000ft), STP, Reel
RJ45-ETH-SHLD-CONN
RJ45 Ethernet Connector, Shielded
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 47
6.5.2 Tool Requirements
Table 15: Tools
Tool
Recommended (or equivalent)
Image (examples)
Wire Cutters/snips
Standard
CAT5e Jacket
Strippers
Fluke Networks UTP/STP Adjustable Cable Stripper
and Cutter – Model # - 11230002
RJ45 Crimping
Tool
Fluke Networks Modular Crimper RJ45 - Model # -
11212530
Ethernet Cable
Tester
Standard
6.5.3 Assembly Instructions
In order to properly assemble the Ethernet cable follow the steps listed below:
1. Unroll the required length of Ethernet cable (CAT5e) and add a little extra wire, just in case.
2. Cut the required length of the cable.
3. Prior to stripping, pass the cable thru the tail nut, seal, body, front connector, and front seal
(self-stick) of the connector casing.
Figure 53: Ethernet cable thru connector
4. Peal and stick the front seal on the collar of the connector body.
5. Carefully strip the outer sheath insulation back 1- 2 inches using the Jacket strippers. Roll
back the foil shield insulation and the drain wire. Do not remove any insulation from the
conductors.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 48
Figure 54: Ethernet cable stripped
6. Untwist the pairs to within 1/8" of the jacket. Arrange the wires according to TIA/EIA 568B
standards. Flatten and align the wires.
Figure 55: RJ45 wire positioning
7. Make one straight cut across all the wires, with the wire snips.
Figure 56: cable trimmed
8. Hold the connector in front of you with the locking tab down. Orient the wires so connector Pin
1 aligns with cable Pin 1, etc.
9. Grip the wires and sheath between thumb and forefinger to hold them together.
10. Gently slide the wires into the RJ45 plug until they begin to “track” into the inner channels of
the plug.
Figure 57: RJ45 plug assembly
11. Push the wires all the way into the RJ45 connector until the front of the wires butt against the
front of the connector (inside). Visually inspect to verify that the wires are fully inserted.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 49
12. Insert cable/connector assembly into the crimping tool and crimp until all pins are set and the
ratchet lever is released.
Figure 58: RJ45 crimping
Note: All pins should be fully compressed and of equal height after crimping.
13. Place the drain wire of the cable thru the metal shell of the shielded plug.
14. Crimp the drain wire to the metal shell of the shielded plug with the crimping tool.
Figure 59: Crimped cable
15. Seat the RJ45 connector plug securely into the body cavity.
16. With an Ethernet cable tester, test to verify the proper connectivity of the cable.
17. Tighten the tail nut on to the body forcing the seal to compress around the cable.
Figure 60: RJ45 assembled
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 50
7 Additional Installations (Non-Standard)
7.1 Front Antenna Assembly
Note: The following section is included for spare-parts or replacement assembly
instructions as front mounted antenna variants come factory pre-assembled.
The AirHarmony-1000 unit can be used either with a sector antenna mounted directly on the front or
with a remotely attached antenna. The following describes the installation procedure for the front
mounted antenna.
For installation of a remotely mounted antenna follow the antenna manufacturer’s instructions and
connect the antenna to the AirHarmony-1000 using the appropriate cables. (Weather-proofed N-type
Heliax RF cables (ordered separately).
Note: When a front mounted antenna is not attached to the unit (remote antenna) a
Sunshield should be attached. Variants utilizing remotely attached antennas come
factory pre-assembled with a sunshield.
To
mount
the
front
antenna,
perform
the
following:
1. Fit the antenna to the (antenna) mounting plate. The four (4) studs on the back of the antenna
pass through the front face of the mounting plate and are secured with the 4 sets of M4 nuts
and washers (flat and split) included in the kit. Carefully position the lead RF cables and
secure them in place to the eyelets on the back of the mounting plate with the provided cable
ties. The cables are formed with a cross-over at the bottom.
Note: It is recommended to place some packing material under the unit while assembling
to protect it from scratches.
2. Attach the assembled front mounted antenna with the bracket to the AirHarmony-1000 unit
using the M5 SEMs (2 on each side) and connect the RF cables to the N type RF ports on the
top of the AirHarmony-1000.
Note: The plate is mounted with the side slots towards the top so that the required tilt-
down can be set.
Figure 61: Attaching front mount antenna assembly to AirHarmony-1000
7.2 Connecting RF Jumper Cables to External Antenna
Note: Variants utilizing remotely attached antennas are factory pre-assembled with a
sunshield.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 51
For installation of a remotely mounted antenna follow the antenna manufacturer’s instructions and
connect the antenna to the AirHarmony-1000 using the appropriate cables. (Weather-proofed N-type
Heliax RF cables (ordered separately).
1. Attach, connect and secure the RF cable between the external antenna and the appropriate
RF connection on the top of the unit.
Figure 62: Connecting RF cable
Caution: Do not over-tighten the RF connector. RF failures can result when the RF
connector is over-tightened.
Figure 63: Weather-proof the connection
2. Weather-proofing of the RF N type connections is recommended. This is done with a layer of
self-amalgamating tape followed by an over layer of PVC tape.
Verify the RF connector is completely weather-sealed.
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 52
A Job Sheet
This job sheet enables the users to keep track of their installation. It covers all the prerequisites
required for accomplishing the AirHarmony-1000 installation.
Site Requirements
o Pole or wall for installation identified
o Position on pole or wall identified
o Pole access restrictions (highway regulations, other services on pole,
power pole)
o Method of reaching pole positions (ladders, Elevated work platform)
o AC main fuse block available for AC/DC converter (where needed)
o Configuration programming details known
o Point of connection for Ethernet (if applicable)
o All equipment items available at the installation site
o Main AirHarmony-1000 unit
o Mounting bracket and pole clamps
o AC/DC converter
o GPS Antenna
o Self-amalgamating tape
o Black PVC tape
o Weather-proofing of the connections with a layer of self-
amalgamating tape followed by an over layer of PVC tape.
o SFP cable assembly
Tool Requirements
(For further information, see Verify the Tools.)
o Large flat screw driver for pole clamps
o Small flat blade screw driver (insulated shaft recommended)
o Medium Philips head screw driver
o 13mm wrench or small pipe wrench
o 10mm wrench for unit mounting flange nuts
o Knife
o pliers
o Small side cutters
o Tweezers (or fine blade long nose pliers)
o Wire strippers
o Tilt-meter
Required Ancillary Equipment
o Laptop PC for initial configuration
o cable for temporary connection of the lap top
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 53
B Checklist
During installation, review and perform all the steps on this checklist (in the given order). This
checklist is meant for the person who performs the AirHarmony-1000 installation. It includes the high–
level steps involved in the installation process.
Tip: To make sure you complete all the tasks, detach or print this checklist and use it as a job aid.
After performing, check off each task.
Procedure
Action
Check If Performed
Verify the prerequisites
Verify the site requirements.
☐
Verify the installation requirements.
☐
Verify the tool requirements.
☐
Verify the parts & kits required.
☐
AirHarmony-1000
installation
Install the mounting bracket.
☐
Install AC/DC converter on mounting bracket (if
required)
☐
Install AirHarmony-1000 on the mounting
bracket.
☐
Connect & manage
Cables
Connect to copper Ethernet (if applicable)
☐
Connect the fiber Ethernet (if applicable)
☐
Connect power system
Connect power
☐
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 54
C Abbreviations
Term
Expansion
3GPP
3rd Generation Partnership Project, responsible for LTE
ABS
Almost Blank Subframe
ACS
Adjacent Channel Selectivity is a measurement of a receiver's ability
to process a desired signal while rejecting a strong signal in an
adjacent frequency channel. ACS is defined as the ratio of the receiver
filter attenuation on the assigned channel frequency to the receiver
filter attenuation on the adjacent channel frequency
AWGN
Additive White Gaussian Noise is a channel model in which the only
impairment to communication is a linear addition of white noise with a
constant spectral density and a Gaussian distribution of amplitude.
BER
Bit Error Rate
CN
Core Network
CP
Cyclic Prefix
CTC
Convolution Turbo Code is a high-performance forward error
correction (FEC) code
dB
Decibel. A logarithmic unit used to describe a ratio (such as power
ratio in radio telecommunications)
dBm
An abbreviation for the power ratio in decibels (dB) of the measured
power referenced to one milliwatt (mW). It is used as a convenient
measure of absolute power because of its capability to express both
very large and very small values in a short form
eNodeB
Evolved Node B, is the element in E-UTRAN of LTE
ESP
Encapsulating Security Payloads (ESP) provide confidentiality, data-
origin authentication, connectionless integrity, an anti-replay service (a
form of partial sequence integrity), and limited traffic-flow
confidentiality
E-UTRAN
Evolved UMTS Terrestrial Radio Access Network, is the air interface
of 3GPP's Long Term Evolution
EVM/RCE
The Error Vector Magnitude or EVM (sometimes also called Receive
Constellation Error or RCE) is a measure used to quantify the
performance of a digital radio transmitter or receiver. It is measured in
dB or percentage (%) – the lower the better
FDD
Frequency-Division Duplexing. A transceiver mode where the
transmitter and receiver operate at different carrier frequencies
GNSS
Global Navigation Satellite System is a term used to describe a
satellite navigation system with global coverage. There are currently
two fully operational GNSSs – the US GPS and the Russian
GLONASS.
GTP-U
GPRS Tunneling Protocol for User data is a relatively simple IP based
tunneling protocol which permits many tunnels between each set of
end points
HPBW
Half Power BandWidth is the angular separation in an antenna, in
which the magnitude of the radiation pattern decreases by 50% (or -3
dB) from the peak of the main beam
ICS
In-channel selectivity is a measure of the receiver’s ability to receive a
wanted signal at its assigned Resource Block locations in the
presence of an interfering signal
IPSec
Internet Protocol Security is a protocol suite for securing Internet
Protocol (IP) communications by authenticating and encrypting each
IP packet of a communication session
AirHarmony-1000 Installation Guide
UGD-D01006 Airspan Commercial and Internal Use 55
LED
Light Emitting Diode
LTE
Long Term Evolution
MAC
Medium Access Controller – responsible for several functions such
Error Correction, Packet (De)Multiplexing, etc…
MBSFN
Multicast-Broadcast Single Frequency Network is an LTE feature
designed to deliver services such as Mobile TV using the LTE
infrastructure, and is expected to be a competitor to DVB-H-based TV
broadcast
MCS
Modulation and Coding Scheme
MME
Mobility Management Entity is the key control-node for the LTE
access-network. It is responsible, among other things for idle mode
UE tracking and paging procedure including retransmissions
MTBF
Mean Time Between Failures
OFDMA
Orthogonal Frequency-Division Multiple Access (OFDMA) is a multi-
user version of OFDM digital modulation scheme, used for eNodeB
transmissions to UEs
PDCP
Packet Data Convergence Protocol. A Sub-Layer in LTE responsible
for IP Header (De)Compression, etc…
PDU
Protocol Data Unit
PTP
Precision Time Protocol is used to synchronize clocks throughout a
network. In this document, PTP is referring to IEEE1588-2008 protocol
RB
Resource Block
RLC
Radio Link Control. A Sub-Layer in LTE responsible for Ack/Nack,
error correction, packet reordering, etc…
ROHS
Restriction Of Hazardous Substances
RRM
Radio Resource Management is used to cover all functions that are
related to the assignment and sharing of radio resources among UEs
S-GW
Serving Gateway. A Core entity in the LTE EPC architecture
responsible for routing and forwarding user data packets, while also
acting as the mobility anchor for the user plane during inter-eNodeB
handovers and as the anchor for mobility between LTE and other
3GPP technologies
SBA
Switched Beam Antenna
SC-FDMA
Single-Carrier FDMA is a frequency-division multiple access scheme,
dealing with the assignment of multiple users to a shared
communication resource. Used in LTE for UE transmissions to the
eNodeB
SCTP
Stream Control Transmission Protocol is a reliable transport layer
protocol, ensuring in-sequence transport of messages with congestion
control like TCP
SDR
Software Defined Radio
WEEE
Waste Electrical and Electronic Equipment
