Alarm Lock Price Book 2017

PRICE BOOK

October 1, 2017

ALARM LOCK SYSTEMS, LLC

345 Bayview Ave.

Amityville, NY 11701

1-800-ALA-LOCK (252-5625)

(631) 789-4871 Tel or (631) 789-3383 Fax

Price Book 2017

Important Things to Know about Doing Business with Alarm Lock

Systems, Inc.

Prices shown in this book are list prices. All customers with direct accounts receive a discount

letter along with each new price book. If you have a direct account with Alarm Lock you may

request a copy of your discount letter in writing or by contacting you local sales representative.

The price book is for pricing purposes only and does not represent stocking levels. Certain items

are manufactured to order. Please be sure to consult the factory or your Alarm Lock

representative or Regional Sales Manager for availability.

Terms: Net 30

Freight Allowance: Shipments are F.O.B. Amityville, NY. Freight allowed within the

continental U.S.A. is $7,500.00. Freight allowance not available on drop ship orders.

Drop Shipments: All orders shipping to an address other than the customer’s or one of their

branches, is subject to a $25.00 handling fee. Freight allowance not available on drop ship

orders.

Minimum Order: The minimum order requirement has been changed to $250.00 for all

customers.

Returns/Warranty: Please see last page of price book for details.

Website: Visit us at www.alarmlock.com for a complete list of sales representatives by state,

product specifications, technical data, and downloadable PDF files of all Alarm Lock’s products

as well as the most current version of our software DL-Windows.

If you need to contact us:

Alarm Lock Systems, Inc.

345 Bayview Ave

Amityville NY 11701

Toll free number –1 800 ALA-LOCK (252-5625)

Direct telephone –631 789-4871

Direct fax –631 789-3383

All prices published are suggested list prices in US Dollars. Some specifications are

preliminary and subject to change without prior notice. Not responsible for typographical

errors. Alarm Lock Systems, LLC, is a Division of Napco Security Technologies, Inc.

(NASDAQ:NSSC) © Alarm Lock Systems, LLC, 9.16

Price Book 2017

Table of Contents

Trilogy DL2700/DL2700LD 100 user Lock/LocDown.………………..……………………..6

Trilogy DL5200 100 user Double Sided Lock…………………………………………………7

Trilogy DL2700CR/DB T2 Series ………………………………………………..……….…….8-9

Trilogy ETDL27 Series ……………………………………………………………………….10-12

Trilogy DL2800 200 user Lock…………………………………………………………….…13

Trilogy DL3000 300 user Lock………………………………………………….…………….14

Trilogy DL3200 2000 user Lock…………………………...……..………………………...…15

Trilogy DL5300 2000 user Double Sided Lock………………………………………….……16

Trilogy DL4100 2000 user Privacy/Residency Lock……………………….………………..17

Trilogy PDL3000 2000 user Proximity & Keypad Lock…..…………….……………….……18

Trilogy PDL5300 2000 user Proximity Double Sided Lock..………...………………………..19

Trilogy PL3000 2000 user Proximity Only Lock……..……………….……………………. 20

Trilogy PDL4100 2000 user Proximity w/Privacy/Residency Lock………………….……….21

Trilogy Cylindrical Lock Parts……………………..…………………………………………22-23

Trilogy & Networx Remote Release Products …………………………………………….……24

Trilogy DL3500 300 user Mortise Lock …………………………………………..……….25-26

Trilogy DL4500 2000 user Mortise w/Privacy/Residency Lock……………………..………27

Trilogy PL/PDL3500 2000 user Proximity Mortise Lock ………………………………….28-29

Trilogy PDL4500 2000 user Proximity Mortise w/Privacy/Residency Lock..……………..30-31

Price Book 2017

Table of Contents (con’t)

Trilogy DL1200 100 user Narrow stile Lock……………………………………………..32

Trilogy DL1300 2000 user Narrow Stile Lock………………………………..………….33

Trilogy PDL1300 2000 user Narrow Stile Proximity Lock……………..…….…………..34

Trilogy Narrow Stile Lock Parts & Accessories…………………………….….………….….35

Trilogy DL1200ET, DL/PDL1300ET Narrow Stile Exit Trim…………………..……….36-37

Trilogy Narrow Stile Exit Trim Parts & Accessories…………………………………………38

Trilogy ETDL/ETPDL 2000 user Exit Trim Lock…………………………..……..…….39-41

Trilogy DK3000 2000 user Keypad/Wall Mounted Reader…….………………………42

Trilogy PDK3000 2000 user Proximity Keypad/Wall Mounted Reader …………….…..42

Trilogy DL6100 Networx Digital Lock, 5,000 user codes ……………………………….43

Trilogy PDL6100 Networx Proximity & Keypad 5,000 user codes ……………………...44

Trilogy Training Options ……………………………………………………………………… 45

Trilogy PL6100/PDL6200 Networx Proximity Only 5,000 user codes ………………………46

Trilogy DL6500 Networx Digital Mortise Lock 5,000 user codes …………………………47

DL 6500 Mortise Lock Accessories ...…………………………………………………………48

Trilogy PDL6500/PL6500 Networx Proximity and Prox Only 5,000 user codes ……….…..49

PDL6500/PL6500/PDL6600 Mortise Lock Accessories ……….………………..…….………50

PDL8200/PDL8600 iClass Networx Locks and Accessories….…........……..…….....…51-53

New Networx Accessories ............................................................................................................54

ETPDNSRX Networx Exit Trim ................................................................................................55

Price Book 2017

Table of Contents (con’t)

Trilogy ETDLN Networx Exit Trim 5,000 user codes …………………………..…..……..55-57

Trilogy ETPDN Networx Exit Trim 5,000 user codes …………………………..……...….55-57

Trilogy ETPLN Networx Exit Trim 5,000 user codes ………………………………..……55-57

NETDK Networx Digital wireless Keypad ……………………………………………………58

NETPDK Networx Proxmity & Digital Keypad …………………………………………...….58

NETDK/PDK Kits and Accessories …………………………………………………………….59

Trilogy Remote Release ……………………………………………………………………...….60

Networx Upgrade Kits ………………………………………………………………………......61

ArchiTechTM Series Locks and Accessories ..........................................................................62-66

Weather Resistant Alarmed Panic Devices..…………………………………………………..67

Alarmed Panic Devices……………………………………………………………………….…68

Door Alarms……………………………………………………………………………………..69

Delayed Egress Panic Device………………………………………………………….………..70

Electric Deadbolts………………………………………………………………..………..…….71

Remote Release Magnets…………………………………………………….…………………71

Power Magnets…………………………………………………………………………………..71

Alarm Lock Warranty/Return Policy …………………………………………………………73

Price Book 2017

TRILOGY ELECTRONIC DIGITAL LOCKS

DL2700 SERIES – Electronic battery operated digital lock. Holds up to 100 user codes,

1 Master, 10 Manager codes & up to 3 one time user codes.

SPECIFICATIONS:

Door Thickness: Fits 1 5/8” to 1 7/8”. Other thickness,

please consult factory

Backset: 2 3/4” (2 3/8” also available)

Strike: 1 1/8”x 2 3/4” T strike & 1 1/4” x 4 7/8

ASA strike included

Latchbolt: UL Listed, fire rated 3 hours, 1/2” throw

reversible

Handing: Non-handed

Power: 5 AA alkaline batteries (included)

Keypad: All metal, 12 button. All functions programmed

through keypad.

Door prep: Standard ANSI A115 Series prep, modified by

adding additional through-bolt holes

Compliances: BHMA Certified Grade 1 heavy duty cylindrical lockset. UL listed

UL Listed 10C Positive Pressure Specification. FCC

Certified . ADA compliant levers

Cylinder: 6 pin solid brass, SC1 keyway, furnished with all

key override locks. Schlage, Corbin-Russwin CL,

Sargent 480 series, ASSA 65-611 & Lori cylinders

can also be used with HW620 tailpiece (supplied)

Interchangeable Standard model accepts 6 & 7 pin cylinders from

Core Models: Best, Falcon, Arrow, KSP, Medeco Keymark & Kaba

Peaks. IC core models prepped for 6 & 7 pin Yale, Medeco,

Sargent, Corbin-Russwin & Schlage are also available

PLEASE CHECK WITH FACTORY FOR LEAD TIMES ON SPECIAL FINISHES AND IC PREPS

SPECIFY "WP" FOR WEATHER RISISTENT MODEL

PRODUCT

FINISH

LIST PRICE

DL2700

Standard key override

US26D

US3 & US10B

$881.00

$1,009.00

DL2775

Standard Key override

Regal (curved)

US26D

US3 & US10B

$941.00

$1,066.00

DL2700IC*

Interchangeable core

US26D

US3 & US10B

$916.00

$1,028.00

DL2775IC*

Interchangeable core

Regal (curved)

US26D

US3 & US10B

$976.00

$1,044.00

DL2700WP

Weather proof key override

US26D

US3 & US10B

$964.00

$1,025.00

DL2775WP

Weather proof key override

Regal (curved)

US26D

US3 & US10B

$978.00

$1,046.00

DL2700WPIC*

Weather proof

Interchangeable core

US26D

US3 & US10B

$978.00

$1,011.00

DL2775WIC*

New Regal (curved) lever

Interchangeable core

US26D

US3 & US10B

$998.00

$1,069.00

DL2700SK

Mounted DL2700 demo

Call Factory

DL2700LD

Standard Key override

DL2700LDIC

Interchangeable core

US26D

$927.00

$973.00

*Add “C” for Corbin, “M” for Medeco, “R” for Sargent, “Y” for Yale and “S” for Schlage to end of the part number for

specially prepped IC core models. Add $15.00 to the list price shown above. **MUST SPECIFY 7 PIN FOR CORBIN AND

YALE**

DL2700

DL2700LD

(LocDownTM)

Extended sizes:

WP standard and SFIC

cylinder preps can be

extended for thicker doors.

$165.00 add on to list for

extended lock.

Extended lock legend:

W54 - 2 1/8"

W57 - 2 1/4"

W60 - 2 3/8"

W64 - 2 1/2"

W70 - 2 3/4"

W76 - 3"

W83 - 3 1/4"

W89 - 3 1/2"

Note: Locks can be

adjusted by +/- 1/8" by

adding or removing

spacers.

Price Book 2017

TRILOGY ELECTRONIC DOUBLE SIDED DIGITAL LOCKS

DL5200 SERIES – Double sided electronic battery operated digital lock. Holds up to 100 user codes,

1 Master, 10 Manager codes & up to 3 one time user codes. Programmable keypad

on both sides of the door. Key override is only operable on the primary side. The key

on the secondary side is used only to remove the lever and access the batteries.

SPECIFICATIONS:

Door Thickness: Fits 1 5/8” to 1 7/8”. Other thickness,

please consult factory

Backset: 2 3/4” (2 3/8” also available)

Strike: 1 1/8”x 2 3/4” T strike & 1 1/4” x 4 7/8”

ASA strike included

Latchbolt: UL Listed, fire rated 3 hours, 1/2” throw

reversible

Handing: Non-handed

Power: 5 AA alkaline batteries (included)

Keypad: All metal, 12 button. All functions programmed

through keypad on both sides of the door

Door prep: Standard ANSI A115 Series prep, modified by

adding additional through-bolt holes

Compliances: BHMA Certified Grade 1 heavy duty cylindrical lockset. UL listed

UL Listed 10C Positive Pressure Specification. FCC

Certified . ADA compliant levers

Cylinder: 6 pin solid brass, SC1 keyway, furnished with all

key override locks. Schlage, Corbin-Russwin CL,

Sargent 480 series, ASSA 65-611 & Lori cylinders

can also be used with HW620 tailpiece (supplied)

Interchangeable Standard model accepts 6 & 7 pin cylinders from

Core Models: Best, Falcon, and Arrow only.

ALL DL5200 LOCKS ARE WEATHER RESISTANT

PLEASE CHECK WITH FACTORY FOR LEAD TIMES

ON SPECIAL FINISHES

PRODUCT

FINISH

LIST PRICE

DL5200

Standard key override

US26D

US3 & US10B

$1,485.00

$1,552.00

DL5275

Standard Key override

Regal (curved)

US26D

US3 & US10B

$1,513.00

$1,576.00

DL5200IC

Interchangeable core

US26D

US3 & US10B

$1,508.00

$1,576.00

DL5275IC

Interchangeable core

Regal (curved)

US26D

US3 & US10B

$1,524.00

$1,604.00

DL5200SK

Mounted DL5200 demo

Call Factory

Note: Key override operates latch on primary side only. Key override on secondary side protects the

battery pack.

Price Book 2017

NEW! ALARM LOCK TRILOGY T2 SERIES MORTISE LOCK

DL2700CR/DB series – Trilogy T2 keyless access lock for mortise door prep. Holds up to 100 use codes, 1 master, 10 manager

codes and up to 3 one time user codes.

SPECIFICATIONS:

Door Thickness: Fits 1 3/8” to 1 7/8” (4.46cm).

Backset: 2 3/4” standard

Strike: 1 1/4” x 4 7/8”strike included

Handing: Specify RH or LH when ordering, lock is reversible

In the field

Power: 4 C- cell batteries (included)

Keypad: All metal, 12 button. Basic functions programmed

through keypad.

Door prep: Standard ANSI A115 Mortise prep, modified by

adding additional through-bolt holes

Compliances: Steelcase lock body meets BHMA specifications

For Grade 1 locks. UL listed to the 10C Positive

Pressure Specification. FCC Certified. ADA

compliant levers

Functions: Classroom function feature stainless steel latchbolt

With 3/4” (1.91cm) projection and deadlocking latch

Deadbolt function feature stainless steel deadbolt with

1” (2.55cm) projection, latchbolt with 3/4” (1.91cm)

projection and deadlocking latch Deadbolt may be

projected from key cylinder from outside door or

turn-piece from inside door.

Cylinder: 1 3/8” (3.5cm) mortise cylinder supplied. Will

Accept 1 3/8” to 1 1/2” (3.5 – 3.82cm) mortise

Cylinder. Classroom function supplied with straight

Cam.

Cams: Cams for other manufacturer’s cylinders are available

See “Mortise Lock accessories” for part numbers &

Manufacturers

ALL DL2700CR/DB MORTISE LOCKS ARE WEATHER-RESISTANT

PLEASE CHECK WITH FACTORY ON LEAD TIMES FOR SPECIAL FINISHES

PRODUCT

FINISH

LIST PRICE

DL2700CRR

Straight lever classroom

Function right hand

26D $1,004.00

DL2700CRL

Straight lever classroom

Function left hand

26D $1,004.00

DL2700DBR

Straight lever deadbolt

Function right hand

26D $1,004.00

DL2700DBL

Straight lever deadbolt

Function left hand

26D $1,004.00

DL2775CRR

Regal (curved) lever classroom

Function right hand

26D $1,021.00

DL2775CRL

Regal (curved) lever classroom

Function Left Hand

26D $1,021.00

DL2775DBR

Regal (curved) lever deadbolt

Function right hand

26D $1,021.00

DL2775DBL

Regal (curved) lever deadbolt

Function left hand

26D $1,021.00

Price Book 2017

NEW! EXPANDED TRILIGY T2 SERIES (con’t)

DL2700CR/DB Parts

CLASSROOM FUNCTION CAMS DESCRIPTION LIST PRICE

HW956-L

Alarm Lock Standard Straight Cam

$5.00

HW956-M

Marks Straight Cam

$5.00

HW956-C

Corbin-Russwin Straight Cam

$5.00

HW956-S

Schlage Straight Cam

$5.00

HW956-A

Arrow Straight Cam

$5.00

HW956-R

Sargent Straight Cam

$5.00

DEADBOLT FUNCTION CAMS

HW957-L

Alarm Lock Standard Cloverleaf Cam

$5.00

HW957-M

Marks Cloverleaf Cam

$5.00

HW957-C

Corbin-Russwin Cloverleaf Cam

$5.00

HW957-S

Schalge Cloverleaf Cam

$5.00

HW957-A

Arrow Cloverleaf Cam

$5.00

HW957-R

Sargent Cloverleaf Cam

$5.00

HW1141

Schlage IC Cloverleaf Cam

$5.00

HW904DBR

Right hand deadbolt lock body

$171.00

HW903DBL

Left hand deadbolt lock body

$171.00

HW870CRL

Left Hand Classroom lock body

$171.00

HW875CRR

Right hand Classroom lock body

$171.00

S6065

Replacement Battery Pack

$38.00

Price Book 2017

NEW! ALARM LOCK TRILOGY T2 SERIES EXIT TRIM

Battery operated Trilogy T2 keyless access outside trim works with Marks M9900, Von Duprin 99, Corbin ED5000, Yale 7100,

Dorma 9300, Arrow 3800, Sargent 8800, Precision 1100, 2100 & Cal Royal 9800, series panic devices. Holds up 100 user codes,

1 master, 10 manager codes and up to 3 one time user codes.

SPECIFICATIONS:

Cylinder: Uses standard rim cylinder to operate key override

function. Will accept 6 or 7 pin interchangeable

core cylinders – see below.

Handing: Non-handed

Power: 5 AA alkaline batteries (included) mounted on inside

of door.

Keypad: Weather-resistant all metal, 12 button. All functions

Programmable through the keypad.

ALL ET SERIES LOCKS ARE WEATHER-RESISTANT

PLEASE CHECK WITH FACTORY FOR LEAD TIMES ON SPECIAL FINISHES

PRODUCT

DESCRIPTION

LIST PRICE

ETDL27 series

26D

$876.00

ETDL27 series

US3 & US10B

$943.00

ETDL27 series w/Regal lever

26D

$901.00

ETDL27 series w/Regal lever

US3 & US10B

$969.00

Specify finish on adapter kit

ET-AL Finish = 26D, US3 & US10B

Alarm Lock Standard Rim Cylinder

Adapter kit (Schlage C keyway)

$57.00

ET-AR Finish = 26D, US3 & US10B

Arrow Standard Rim Cylinder

Adapter kit

$57.00

ET-AS Finish = 26D, US3 & US10B

ASSA Standard Rim Cylinder

Adapter kit

$57.00

ET –C Finish = 26D, US3 & US10B

Corbin Standard Rim Cylinder

Adapter kit

$57.00

ET –M Finish = 26D, US3 & US10B

Medeco Standard Rim Cylinder

Adapter kit

$57.00

ET –R Finish = 26D, US3 & US10B

Sargent Standard Rim Cylinder

Adapter kit

$57.00

ET -S Finish = 26D, US3 & US10B

Schlage Standard Rim Cylinder

Adapter kit

$57.00

ET -Y Finish = 26D, US3 & US10B

Yale Standard Rim Cylinder

Adapter kit

$57.00

ET –ARIC Finish = 26, 26D, 3, 4, 5, 10B

Arrow IC 6 & 7 Pin Rim Cylinder

Adapter kit

$79.00

ET -BIC Finish = 26D, US3 & US10B

Best IC 6 & 7 Pin Rim Cylinder

Adapter kit

$79.00

ET -CIC Finish = 26D, US3 & US10B

Corbin IC Rim Cylinder

Adapter kit

$79.00

ET –MIC Finish = 26D, US3 & US10B

Medeco IC 6 & 7 Pin Rim Cylinder

Adapter kit

$79.00

Crash bar not included

Price Book 2017

NEW! ALARM LOCK TRILOGY T2 SERIES EXIT TRIM (con’t)

Product Description List Price

ET -RIC Finish = 26D, US3 & US10B

Sargent IC Rim Cylinder

Adapter kit

$79.00

ET -SIC Finish = 26D, US3 & US10B

Schlage IC Rim Cylinder

Adapter kit

$79.00

ET –YIC Finish = 26D, US3 & US10B

Yale IC 6 Pin Rim Cylinder

Adapter kit

$79.00

EXTENDED SPINDLES MUST BE PURCHASED SEPARATELY

S6146

Extended Spindle and screws

Extend exit trim to fit 2 –2 ¾” doors

$112.00

S6147

Extended Spindle and screws

Extend exit trim to fit 3 –4” doors

$112.00

S6195

Extended Spindle and screws

Extend exit trim to fit 4 ¼ -5” doors

$112.00

SC544

Extended replacement screws with

adjustable lengths (4 per unit)

$21.00

PLEASE SEE “HOW TO ORDER” CHART ON PAGE 46 TO PROPERLY ORDER YOUR TRILOGY EXIT

TRIM.

IF YOU REQUIRE THE LOCK TO BE PREPPED FOR A THICKER DOOR, YOU MUST ORDER BASED

ON THE SELECTIONS SHOWN. THE BASIC MODEL IS PREPPED FOR A

1 5/8” TO 1 7/8” DOOR.

**** PRECISION 2100 SERIES WILL WORK WITH THE VON DUPRIN 99 PREP. YOU MUST GET A

MOUNTING PLATE PART # 2141208 FROM PRECISION****

Price Book 2017

HOW TO ORDER YOUR T2 TRILOGY EXIT LOCK

Below is a “How to Order” guide for the Trilogy Exit Trim products. Please follow this

guide when placing orders to avoid any delay in processing your order.

All units are sold with a generic cylinder adapter installed. When you are using a

specific brand of rim cylinder, you must purchase a Cylinder Adapter Kit from the

chart below.

ETDL27S1G/26DV99

HANDLE

R-Regal

S-Straight

FINISH

26D = satin chrome

10B = duronodic

COMPATABLE PANIC

DEVICES

V99 – VonDuprin 99(P21)

C50 – Corbin ED5000 and

Y71 - Yale 7100

D93 – Dorma 9300

A38 – Arrow 3800

S88 – Old Style Sargent 8800

NS8 – New Style Sargent 8888

P11 -Precision 1100

CR8 – Cal Royal 9800

M99 -Marks 9900

TYPE

DL27 – T2 series Exit Trim

CYLINDER ADAPTER KITS

You must choose one of the cylinder

adapter kits below if you are using a name

brand cylinder in the lock.

ET - AL - Alarm Lock standard

(Schlage C keyway)

ET – BIC - Best IC 6 & 7 pin

ET – S - Schlage standard rim

ET – SIC - Schlage IC

ET – R - Sargent standard rim

ET – RIC - Sargent IC

ET – Y -Yale standard rim

ET – YIC -Yale IC 6 pin

ET - C - Corbin standard rim

ET – CIC - Corbin IC

ET - M - Medeco standard rim

ET – MIC - Medeco IC 6 & 7 pin

ET – AR - Arrow standard rim

ET – ARIC - Arrow IC 6 & 7 pin

ET – AS - ASSA standard rim

G= generic rim

Cylinder & adapter

kit included in all

locks

Please note that Precision 2100

series will match up to the Von

Duprin 99 series Trilogy. You must

get a mounting plate #2141208 from

Precision.

DOOR

THICKNESS

1=1 ¾” +

1/8”

All units

shipped with

“1” option.

For thicker

door preps,

you must

order

extended

spindle and

screw kit

separately.

Price Book 2017

TRILOGY ELECTRONIC DIGITAL LOCKS

DL2800 SERIES – Electronic battery operated digital lock. Holds up to 200 codes, Master,

Management, Supervisor & basic user. 150 event schedule, real time clock

& 1,000 event audit trail.

SPECIFICATIONS:

Door Thickness: Fits 1 5/8” to 1 7/8”. Other thickness,

please consult factory

Backset: 2 3/4 “ (2 3/8” also available)

Strike: 1 1/8”x 2 3/4” T strike & 1 1/4” x 4 7/8”

ASA strike included

Latchbolt: UL Listed, fire rated 3 hours, 1/2” throw reversible

Handing: Non-handed

Power: 5 AA alkaline batteries (included)

Keypad: All metal, 12 button. All functions programmed

through keypad.

Door prep: Standard ANSI A115 Series prep, modified by

adding additional through-bolt holes

Compliances: BHMA Certified Grade 1 heavy duty cylindrical lockset.

UL listed, 10C Positive Pressure Specification. FCC

Certified . ADA compliant levers

Cylinder: 6 pin solid brass, SC1 keyway, furnished with all

key override locks. Schlage, Corbin-Russwin CL,

Sargent 480 series, ASSA 65-611 & Lori cylinders

can also be used with HW620 tailpiece (supplied)

Interchangeable

Core Models: Standard model accepts 6 & 7 pin cylinders from

Best, Falcon, Arrow, KSP, Medeco Keymark & Kaba Peaks.

IC core models prepped for 6 & 7 pin Yale, Medeco,

Sargent, Corbin-Russwin & Schlage are also available

All DL2800 LOCKS ARE WEATHER-RESISTANT

PLEASE CHECK WITH FACTORY FOR LEAD TIMES

ON SPECIAL FINISHES AND IC PREPS

PRODUCT

FINISH

LIST PRICE

DL2800

Standard key override

US26D

US3 & US10B

$1,078.00

$1,171.00

DL2875

Standard key override

Regal (curved) lever

US26D

US3 & US10B

$1,102.00

$1,188.00

DL2800IC*

Interchangeable core

US26D

US3 & US10B

$1,102.00

$1,188.00

DL2875IC*

Interchangeable core

Regal (curved) lever

US26D

US3 & US10B

$1,124.00

$1,206.00

DL2800SK

Mounted DL2800 demo

Call Factory

AL-DTMIII

Data Transfer Module

$448.00

AL-PCI2

Computer interface cable for

Serial connection includes

DL-Windows Software

$129.00

ALPCI2-U

USB computer interface cable

includes DL-Windows software

$237.00

MX1130

USB Converter

$118.00

AL-IR1

Infrared Printer

$520.00

*Add “C” for Corbin, “M” for Medeco, “R” for Sargent, “Y” for Yale and “S” for Schlage to end of the part number for

specially prepped IC core models. Add $15.00 to the list price shown above. **MUST SPECIFY 7 PIN FOR CORBIN AND

YALE**

Extended sizes:

Standard and SFIC cylinder

preps can be extended for

thicker doors.

$165.00 add on to list for

extended lock.

Extended lock legend:

W54 - 2 1/8"

W57 - 2 1/4"

W60 - 2 3/8"

W64 - 2 1/2"

W70 - 2 3/4"

W76 - 3"

W83 - 3 1/4"

W89 - 3 1/2"

Note: Locks can be adjusted

by +/- 1/8" by adding or

removing spacers.

Price Book 2017

TRILOGY ELECTRONIC DIGITAL LOCKS

DL3000 SERIES – Electronic battery operated digital lock. Holds up to

300 codes, Master, Management, Supervisor & basic

user. 150 event schedule, real time clock & 1,600 event audit trail.

SPECIFICATIONS:

Door Thickness: Fits 1 5/8” to 1 7/8”. Other thickness,

please consult factory

Backset: 2 3/4” (2 3/8” also available)

Strike: 1 1/8”x 2 3/4” T strike & 1 1/4” x 4 7/8”

ASA strike included

Latchbolt: UL Listed, fire rated 3 hours, 1/2” throw

reversible

Handing: Non-handed

Power: 5 AA alkaline batteries (included)

Keypad: All metal, 12 button. All functions programmed

through keypad.

Door prep: Standard ANSI A115 Series prep, modified by

adding additional through-bolt holes

Compliances: BHMA Certified Grade 1 heavy duty cylindrical lockset.

UL listed 10C Positive Pressure Specification. FCC

Certified . ADA compliant levers

Cylinder: 6 pin solid brass, SC1 keyway, furnished with all

key override locks. Schlage, Corbin-Russwin CL,

Sargent 480 series, ASSA 65-611 & Lori cylinders

can also be used with HW620 tailpiece (supplied)

Interchangeable Standard model accepts 6 & 7 pin cylinders from

Core Models Best, Falcon, Arrow, KSP, Medeco Keymark & Kaba Peaks.

IC core models prepped for 6 & 7 pin Yale, Medeco,

Sargent, Corbin-Russwin & Schlage are also available.

PLEASE CHECK WITH FACTORY FOR LEAD TIMES ON SPECIAL FINISHES AND IC PREPS

SPECIFY "WP" FOR WEATHER RISISTENT MODEL

PRODUCT

FINISH

LIST PRICE

DL3000

Standard key override

US26D

US3 & US10B

$1,309.00

$1,400.00

DL3075

Standard key override

Regal (curved) lever

US26D

US3 & US10B

$1,303.00

$1,378.00

DL3000IC*

Interchangeable core

US26D

US3 & US10B

$1,303.00

$1,378.00

DL3075IC*

Interchangeable core

Regal (curved) lever

US26D

US3 & US10B

$1,328.00

$1,400.00

DL3000WP

Weather proof key override

US26D

US3 & US10B

$1,337.00

$1,405.00

DL3075WP

Weather proof key override

Regal (curved) lever

US26D

US3 & US10B

$1,360.00

$1,405.00

DL3000WPIC*

Weather proof interchangeable core

US26D

US3 & US10B

$1,360.00

$1,428.00

DL3075WPIC*

Weather proof interchangeable core

Regal (curved) lever

US26D

US3 & US10B

$1,366.00

$1,404.00

DL3000SK

Mounted DL3000 demo

Call Factory

AL-DTMIII

Data Transfer Module

$448.00

AL-PCI2

Computer interface cable for serial

connection with DL-Windows Software

$129.00

ALPCI2-U

USB computer interface cable

includes DL-Windows software

$237.00

MX1130

USB Converter

$118.00

AL-IR1

Infra red Printer

$520.00

*Add “C” for Corbin, “M” for Medeco, “R” for Sargent, “Y” for Yale and “S” for Schlage to end of the part number for

specially prepped IC core models. Add $15.00 to the list price shown above**MUST SPECIFY 7 PIN FOR CORBIN AND

YALE**

Extended sizes:

WP standard and SFIC

cylinder preps can be

extended for thicker doors.

$165.00 add on to list for

extended lock.

Extended lock legend:

W54 - 2 1/8"

W57 - 2 1/4"

W60 - 2 3/8"

W64 - 2 1/2"

W70 - 2 3/4"

W76 - 3"

W83 - 3 1/4"

W89 - 3 1/2"

Note: Locks can be

adjusted by +/- 1/8" by

adding or removing

spacers.

Price Book 2017

TRILOGY ELECTRONIC DIGITAL LOCKS

DL3200 SERIES – Electronic battery operated digital lock. Holds up to 2,000 codes,

Master, Management, Supervisor & basic user. 500 event schedule,

multiple “one-time” user codes & 40,000 event audit trail.

SPECIFICATIONS:

Door Thickness: Fits 1 5/8” to 1 7/8”. Other thickness,

please consult factory

Backset: 2 3/4” (2 3/8” also available)

Strike: 1 1/8”x 2 3/4” T strike & 1 1/4” x 4 7/8”

ASA strike included

Latchbolt: UL Listed, fire rated 3 hours, 1/2” throw reversible

Handing: Non-handed

Power: 5 AA alkaline batteries (included)

Keypad: All metal, 12 button. All functions programmed

through keypad.

Door prep: Standard ANSI A115 Series prep, modified by

adding additional through-bolt holes

Compliances: BHMA Certified Grade 1 heavy duty cylindrical

lockset.

UL listed 10C Positive Pressure Specification. FCC

Certified . ADA compliant levers

Cylinder: 6 pin solid brass, SC1 keyway, furnished with all

key override locks. Schlage, Corbin-Russwin CL,

Sargent 480 series, ASSA 65-611 & Lori cylinders

can also be used with HW620 tailpiece (supplied)

Interchangeable Standard model accepts 6 & 7 pin cylinders from

Core Models Best, Falcon, Arrow, KSP, Medeco Keymark & Kaba Peaks.

IC core models prepped for 6 & 7 pin Yale, Medeco,

Sargent, Corbin-Russwin & Schlage are also available

ALL DL3200 LOCKS ARE WEATHER RESISTANT

PLEASE CHECK WITH FACTORY FOR LEAD TIMES

ON SPECIAL FINISHES AND IC PREPS

PRODUCT

FINISH

LIST PRICE

DL3200

Standard key override

US26D

US3 & US10B

$1,342.00

$1,423.00

DL3275

Standard key override

Regal (curved) lever

US26D

US3 & US10B

$1,371.00

$1,446.00

DL3200IC*

Interchangeable core

US26D

US3 & US10B

$1,351.00

$1,446.00

DL3275IC*

Interchangeable core

Regal (curved) lever

US26D

US3 & US10B

$1,388.00

$1,457.00

DL3200SK

Mounted DL3200 demo

Call Factory

AL-DTMIII

Data Transfer Module

$448.00

AL-PCI2

Computer interface cable for serial

connection with DL-Windows Software

$129.00

ALPCI2-U

USB computer interface cable

includes DL-Windows software

$237.00

MX1130

USB Converter

$118.00

AL-IR1

Infrared Printer

$520.00

*Add “C” for Corbin, “M” for Medeco, “R” for Sargent, “Y” for Yale and “S” for Schlage to end of the part number for

specially prepped IC core models. Add $15.00 to the list price shown above **MUST SPECIFY 7 PIN FOR CORBIN AND

YALE**

Extended sizes:

Standard and SFIC cylinder

preps can be extended for

thicker doors.

$165.00 add on to list for

extended lock.

Extended lock legend:

W54 - 2 1/8"

W57 - 2 1/4"

W60 - 2 3/8"

W64 - 2 1/2"

W70 - 2 3/4"

W76 - 3"

W83 - 3 1/4"

W89 - 3 1/2"

Note: Locks can be

adjusted by +/- 1/8" by

adding or removing

spacers.

Price Book 2017

TRILOGY ELECTRONIC DOUBLE SIDED DIGITAL LOCKS

DL5300 SERIES – Double sided electronic battery operated digital lock. Holds up to 2,000 codes, Master, Management,

Supervisor & basic user. 500 event schedule, multiple “one-time” user codes & 40,000 event audit

trail. Programmable keypad on both sides of the door. Only primary keypad has data transfer

capability. Key override is only operable on the primary side. The key on the secondary side is used

only to remove the lever and access the batteries.

SPECIFICATIONS:

Door Thickness: Fits 1 5/8” to 1 7/8”. Other thickness,

please consult factory

Backset: 2 3/4” (2 3/8” also available)

Strike: 1 1/8”x 2 3/4” T strike & 1 1/4” x 4 7/8”

ASA strike included

Latchbolt: UL Listed, fire rated 3 hours, 1/2” throw

reversible

Handing: Non-handed

Power: 5 AA alkaline batteries (included)

Keypad: All metal, 12 button. All functions programmed

through keypad on both sides of

Door prep: Standard ANSI A115 Series prep, modified by

adding additional through-bolt holes

Compliances: BHMA Certified Grade 1 heavy duty cylindrical lockset.

UL listed 10C Positive Pressure Specification. FCC

Certified . ADA compliant levers

Cylinder: 6 pin solid brass, SC1 keyway, furnished with all

key override locks. Schlage, Corbin-Russwin CL,

Sargent 480 series, ASSA 65-611 & Lori cylinders

can also be used with HW620 tailpiece (supplied)

Interchangeable Standard model accepts 6 & 7 pin cylinders from

Core Models Best, Falcon, and Arrow only.

ALL DL5300 LOCKS ARE WEATHER RESISTANT

PLEASE CHECK WITH FACTORY FOR LEAD TIMES

ON SPECIAL FINISHES

PRODUCT

FINISH

LIST PRICE

DL5300

Standard key override

US26D

US3 & US10B

$1,869.00

$1,918.00

DL5375

Standard key override

Regal (curved) lever

US26D

US3 & US10B

$1,884.00

$1,952.00

DL5300IC

Interchangeable core

US26D

US3 & US10B

$1,874.00

$1,974.00

DL5375IC

Interchangeable core

Regal (curved) lever

US26D

US3 & US10B

$1,883.00

$1,986.00

DL5300SK

Mounted DL5300 demo

Call Factory

AL-DTMIII

Data Transfer Module

$448.00

AL-PCI2

Computer interface cable for serial

connection with DL-Windows Software

$129.00

ALPCI2-U

USB computer interface cable

includes DL-Windows software

$237.00

MX1130

USB Converter

$118.00

AL-IR1

Infra red Printer

$520.00

Note: Key override operates latch on primary side only. Key override on secondary side protects the

battery pack.

Price Book 2017

TRILOGY ELECTRONIC DIGITAL LOCKS

WITH PRIVACY & RESIDENCY FEATURES

DL4100 SERIES - Electronic battery operated digital lock. Holds up to 2000 codes, Master,

Management, Supervisor & basic user. Multiple “one-time” user codes. 500

event schedule, real time clock & 40,000 event audit trail. Privacy feature will

lock out all users for programmed amount of time. Residency feature-allows

exiting without having to lock the door.

SPECIFICATIONS:

Door Thickness: Fits 1 5/8” to 1 7/8”. Other thickness,

please consult factory

Backset: 2 3/4” (2 3/8” also available)

Strike: 1 1/8”x 2 3/4” T strike & 1 1/4” x 4 7/8”

ASA strike included

Latchbolt: UL Listed, fire rated 3 hours, 1/2” throw reversible

Handing: Non-handed

Power: 5 AA alkaline batteries (included)

Keypad: Weatherproof all metal, 12 button. All functions

programmed through keypad.

Door prep: Standard ANSI A115 Series prep, modified by

adding additional through-bolt holes

Compliances: BHMA Certified Grade 1 heavy duty cylindrical lockset.

UL listed 10C Positive Pressure Specification. FCC

Certified . ADA compliant levers

Cylinder: 6 pin solid brass, SC1 keyway, furnished with all

key override locks. Schlage, Corbin-Russwin CL,

Sargent 480 series, ASSA 65-611 & Lori cylinders

can also be used with HW620 tailpiece (supplied)

Interchangeable Core Models:

Standard model accepts 6 & 7 pin cylinders from

Best, Falcon, Arrow, KSP, Medeco Keymark & Kaba Peaks.

IC core models prepped for 6 and 7 pin Yale, Medeco,

Sargent, Corbin-Russwin & Schlage are also available

ALL DL4100 LOCKS ARE WEATHER RESISTANT

PLEASE CHECK WITH FACTORY FOR LEAD TIMES

ON SPECIAL FINISHES AND IC PREPS

PRODUCT

FINISH

LIST PRICE

DL4100

Standard key override

US26D

US3 & US10B

$1,026.00

$1,096.00

DL4175

Standard key override

w/Regal (curved) lever US26D

US3 & US10B

$1,050.00

$1,119.00

DL4100IC*

Interchangeable core prepped for Best

US26D

US3 & US10B

$1,050.00

$1,119.00

DL4175IC*

Interchangeable core prepped for Best

W/Regal (curved) lever US26D

US3 & US10B

$1,067.00

$1,142.00

DL4100SK

Mounted DL4100 Demo

Call Factory

AL-PCI2

Computer interface cable for serial

connection includes DL-Windows

software

$129.00

ALPCI2-U

USB computer interface cable

includes DL-Windows software

$237.00

MX1130

USB Converter

$118.00

AL-IR1

Infra-red Printer

$520.00

AL-DTMIII

Data Transfer Module

$448.00

*Add “C” for Corbin, “M” for Medeco, “R” for Sargent, “Y” for Yale and “S” for Schlage to end of the part number for

specially prepped IC core models. Add $15.00 to the list price shown above.

Extended sizes:

Standard and SFIC cylinder

preps can be extended for

thicker doors.

$165.00 add on to list for

extended lock.

Extended lock legend:

W54 - 2 1/8"

W57 - 2 1/4"

W60 - 2 3/8"

W64 - 2 1/2"

W70 - 2 3/4"

W76 - 3"

W83 - 3 1/4"

W89 - 3 1/2"

Note: Locks can be

adjusted by +/- 1/8" by

adding or removing

spacers.

Price Book 2017

TRILOGY ELECTRONIC DIGITAL PROXIMITY LOCKS

PDL3000 SERIES -Electronic battery operated digital proximity lock. Holds up to 2000 codes, Master,

Management, Supervisor & basic user. Multiple “one-time” user codes. 500 event schedule,

real time clock & 40,000 event audit trail. Will read most HID card and keyfob formats.

SPECIFICATIONS:

Door Thickness: Fits 1 5/8” to 1 7/8”. Other thickness,

please consult factory

Backset: 2 3/4” (2 3/8” also available)

Strike: 1 1/8”x 2 3/4” T strike & 1 1/4” x 4 7/8”

ASA strike included

Latchbolt: UL Listed, fire rated 3 hours, 1/2” throw reversible

Handing: Non-handed

Power: 5 AA alkaline batteries (included)

Keypad: Weatherproof all metal, 12 button. All functions

programmed through keypad. Proximity antenna housing

molded of ultra high strength, impact resistant Lexan®

Door prep: Standard ANSI A115 Series prep, modified by

adding additional through-bolt holes

Compliances: BHMA Certified Grade 1 heavy duty cylindrical lockset.

UL listed 10C Positive Pressure Specification. FCC

Certified . ADA compliant levers

Cylinder: 6 pin solid brass, SC1 keyway, furnished with all

key override locks. Schlage, Corbin-Russwin CL,

Sargent 480 series, ASSA 65-611 & Lori cylinders

can also be used with HW620 tailpiece (supplied)

Interchangeable Standard model accepts 6 & 7 pin cylinders from

Core Models Best, Falcon, Arrow, KSP, Medeco Keymark & Kaba Peaks.

IC core models prepped for 6 and 7 pin Yale, Medeco,

Sargent, Corbin-Russwin & Schlage are also available

ALL PDL3000 LOCKS ARE WEATHER RESISTANT

PLEASE CHECK WITH FACTORY FOR LEAD TIMES

ON SPECIAL FINISHES AND IC PREPS

PRODUCT

FINISH

LIST PRICE

PDL3000K

Key override audit trail

US26D

US10B

$1,861.00

$1,927.00

PDL3000

Standard key override

US26D

US3 & US10B

$1,836.00

$1,916.00

PDL3075

Standard key override

Regal (curved) lever

US26D

US3 & US10B

$1,866.00

$1,939.00

PDL3000IC*

Interchangeable core

US26D

US3 & US10B

$1,866.00

$1,939.00

PDL3075IC*

Interchangeable core

Regal (curved) lever

US26D

US3 & US10B

$1,886.00

$1,939.00

PDL3000SKLE

Mounted PDL3000 demo

Call Factory

AL-PCI2

Computer interface cable for serial

Connection includes DL-Windows

Software

$129.00

ALPCI2-U

MX1130

USB computer interface cable

includes DL-Windows software

USB Converter

$237.00

$118.00

AL-IR1

Infra-red Printer

$520.00

AL-DTMIII

Data Transfer Module

$448.00

AL-PRE

Prox Card Enroller

$590.00

ALHID1326

Proximity Access Cards 100 Per Box

$505.00

ALHID1336

Proximity, Magnetic Stripe and Photo

ID cards 100 per box

$1,030.00

ALHID1386

Proximity and Photo ID

Card 100 per box

$927.00

ALHID1391

MicroProx Tag 10 per box

$ 80.00

ALHID1346

Proximity keyfob 10 per box

$118.00

*Add “C” for Corbin, “M” for Medeco, “R” for Sargent, “Y” for Yale and “S” for Schlage to end of the part number for

specially prepped IC core models. Add $15.00 to the list price shown above. **MUST SPECIFY 7 PIN FOR CORBIN AND

YALE**

Extended sizes:

Standard and SFIC cylinder

preps can be extended for

thicker doors.

$165.00 add on to list for

extended lock.

Extended lock legend:

W54 -2 1/8"

W57 -2 1/4"

W60 -2 3/8"

W64 -2 1/2"

W70 -2 3/4"

W76 -3"

W83 -3 1/4"

W89 -3 1/2"

Note: Locks can be

adjusted by +/-1/8" by

adding or removing

spacers.

Price Book 2017

TRILOGY ELECTRONIC DOUBLE SIDED DIGITAL PROXIMITY LOCKS

PDL5300 SERIES –Double sided electronic battery operated digital proximity lock. Holds up to 2000 codes, Master,

Management, Supervisor & basic user. Multiple “one-time” user codes. 500 event schedule, 40,000 event audit trail.

Programmable keypad on both sides of the door. Only primary keypad has data transfer capability Will read most HID card

and keyfob formats. Key override is only operable on the primary side. The key on the secondary side is use only to remove

the lever and access the batteries.

SPECIFICATIONS:

Door Thickness: Fits 1 5/8” to 1 7/8”. Other thickness,

please consult factory

Backset: 2 3/4” (2 3/8” also available)

Strike: 1 1/8”x 2 3/4” T strike & 1 1/4” x 4 7/8”

ASA strike included

Latchbolt: UL Listed, fire rated 3 hours, 1/2” throw

reversible

Handing: Non-handed

Power: 5 AA alkaline batteries (included)

Keypad: Weatherproof all metal, 12 button. All functions

programmed through keypad. Proximity antenna housing

molded of ultra high strength, impact resistant Lexan®

Door prep: Standard ANSI A115 Series prep, modified by

adding additional through-bolt holes

Compliances: BHMA Certified Grade 1 heavy duty cylindrical lockset.

UL listed 10C Positive Pressure Specification. FCC

Certified . ADA compliant levers

Cylinder: 6 pin solid brass, SC1 keyway, furnished with all

key override locks. Schlage, Corbin-Russwin CL,

Sargent 480 series, ASSA 65-611 & Lori cylinders

can also be used with HW620 tailpiece (supplied)

Interchangeable Standard model accepts 6 & 7 pin cylinders from

Core Models Best, Falcon, and Arrow.

ALL PDL5300 LOCKS ARE WEATHER RESISTANT

PLEASE CHECK WITH FACTORY FOR LEAD TIMES

ON SPECIAL FINISHES

PRODUCT

FINISH

LIST PRICE

PDL5300

Standard key override

US26D

US3 & US10B

$2,228.00

$2,295.00

PDL5375

Standard key override

Regal (curved) lever

US26D

US3 & US10B

$2,251.00

$2,324.00

PDL5300IC

Interchangeable core

US26D

US3 & US10B

$2,245.00

$2,287.00

PDL5375IC

Interchangeable core

Regal (curved) lever

US26D

US3 & US10B

$2,273.00

$2,314.00

PDL5300SK

Mounted PDL3000 demo

Call Factory

AL-PCI2

Computer interface cable for serial

Connection includes DL-Windows

$129.00

ALPCI2-U

MX1130

USB computer interface cable

includes DL-Windows software

USB Converter

$237.00

$118.00

AL-IR1

Infra-red Printer

$520.00

AL-DTMIII

Data Transfer Module

$448.00

AL-PRE

Prox Card Enroller

$590.00

ALHID1326

Proximity Access Cards 100 Per Box

$505.00

ALHID1336

Proximity, Magnetic Stripe and Photo

ID cards 100 per box

$1,030.00

ALHID1386

Proximity and Photo ID

Card 100 per box

$927.00

ALHID1391

MicroProx Tag 10 per box

$82.00

ALHID1346

Proximity keyfob 10 per box

$118.00

Note: Key override operates latch on primary side only. Key override on secondary side protects the

battery pack.

Price Book 2017

TRILOGY ELECTRONIC DIGITAL PROXIMITY LOCKS

PL3000 SERIES -Electronic battery operated proximity only lock. Holds up to 2000 codes,

Master, Management, Supervisor & basic user. Multiple “one-time” user codes. 500 event

schedule, real time clock & 40,000 event audit trail. Will read most HID card and keyfob

formats.

SPECIFICATIONS:

Door Thickness: Fits 1 5/8” to 1 7/8”. Other thickness,

please consult factory

Backset: 2 3/4” (2 3/8” also available)

Strike: 1 1/8”x 2 3/4” T strike & 1 1/4” x 4 7/8”

ASA strike included

Latchbolt: UL Listed, fire rated 3 hours, 1/2” throw

reversible

Handing: Non-handed

Power: 5 AA alkaline batteries (included)

Programming: 9 prox programming cards included

Door prep: Standard ANSI A115 Series prep, modified by

adding additional through-bolt holes

Compliances: BHMA certified Grade 1 heavy duty cylindrical lockset.

UL listed to the 10C Positive Pressure Specification.

FCC Certified. ADA compliant levers

Cylinder: 6 pin solid brass, SC1 keyway, furnished with all

key override locks. Schlage, Corbin-Russwin CL,

Sargent 480 series, ASSA 65-611 & Lori cylinders

can also be used with HW620 tailpiece (supplied)

Interchangeable Standard model accepts 6 & 7 pin cylinders from

Core Models Best, Falcon, Arrow, KSP, Medeco Keymark & Kaba Peaks.

IC core models prepped for 6 and 7 pin Yale, Medeco,

Sargent, Corbin-Russwin & Schlage are also available

ALL PL3000 PROXIMITY LOCKS ARE WEATHER-RESISTANT

PLEASE CHECK WITH FACTORY FOR LEAD TIMES

ON SPECIAL FINISHES AND IC PREPS

PRODUCT

FINISH

LIST PRICE

PL3000

Standard key override

US26D

US3 & US10B

$1,836.00

$1,916.00

PL3075

Standard key override

Regal (curved) lever

US26D

US3 & US10B

$1,866.00

$1,939.00

PL3000IC*

Interchangeable core

US26D

US3 & US10B

$1,866.00

$1,939.00

PL3075IC*

Interchangeable core

Regal (curved) lever

US26D

US3 & US10B

$1,886.00

$1,939.00

PL3000SK

Mounted PL3000 Demo

Call Factory

AL-PCI2

Computer interface cable for serial

connection includes DL-Windows

software

$129.00

ALPCI2-U

MX1130

USB computer interface cable

includes DL-Windows software

USB Converter

$237.00

$118.00

AL-IR1

Infra-red Printer

$520.00

AL-DTMIII

Data Transfer Module

$448.00

AL-PRE

Prox Card Enroller

$590.00

ALHID1326

Proximity Access Cards 100 Per Box

$505.00

ALHID1336

Proximity, Magnetic Stripe and Photo

ID cards 100 per box

$1,030.00

ALHID1386

Proximity and Photo ID

Card 100 per box

$927.00

ALHID1391

MicroProx Tag 10 per box

$82.00

ALHID1346

Proximity keyfob 10 per box

$118.00

*Add “C” for Corbin, “M” for Medeco, “R” for Sargent, “Y” for Yale and “S” for Schlage to end of the part number for

specially prepped IC core models. Add $15.00 to the list price shown above. **MUST SPECIFY 7 PIN FOR CORBIN AND

YALE**

Extended sizes:

Standard and SFIC cylinder

preps can be extended for

thicker doors.

$165.00 add on to list for

extended lock.

Extended lock legend:

W54 -2 1/8"

W57 -2 1/4"

W60 -2 3/8"

W64 -2 1/2"

W70 -2 3/4"

W76 -3"

W83 -3 1/4"

W89 -3 1/2"

Note: Locks can be

adjusted by +/-1/8" by

adding or removing

spacers.

Price Book 2017

TRILOGY ELECTRONIC DIGITAL PROXIMITY LOCKS

WITH PRIVACY & RESIDENCY FEATURES

PDL4100 SERIES - Electronic battery operated digital proximity lock. Holds up to 2000 codes, Master, Management,

Supervisor & basic user. Multiple “one-time” user codes. 500 event schedule, real time clock & 40,000 event audit trail. Will

read most HID card and keyfob formats. Privacy feature will lock out all users for a programmed amount of time. Residency

feature-allows exiting without having to lock the door.

SPECIFICATIONS:

Door Thickness: Fits 1 5/8” to 1 7/8”. Other thickness,

please consult factory

Backset: 2 3/4” (2 3/8” also available)

Strike: 1 1/8”x 2 3/4” T strike & 1 1/4” x 4 7/8”

ASA strike included

Latchbolt: UL Listed, fire rated 3 hours, 1/2” throw

reversible

Handing: Non-handed

Power: 5 AA alkaline batteries (included)

Keypad: Weatherproof all metal, 12 button. All functions

programmed through keypad. Proximity antenna housing

molded of ultra high strength, impact resistant Lexan®

Door prep: Standard ANSI A115 Series prep, modified by

adding additional through-bolt holes

Compliances: BHMA certified Grade 1 heavy duty cylindrical lockset.

UL listed to the 10C Positive Pressure Specification.

FCC certified . ADA compliant levers

Cylinder: 6 pin solid brass, SC1 keyway, furnished with all

key override locks. Schlage, Corbin-Russwin CL,

Sargent 480 series, ASSA 65-611 & Lori cylinders

can also be used with HW620 tailpiece (supplied)

Interchangeable Standard model accepts 6 & 7 pin cylinders from

Core Models: Best, Falcon, Arrow, KSP, Medeco Keymark & Kaba

Peaks.

IC core models prepped for 6 pin and 7 pin Yale, Medeco,

Sargent, Corbin-Russwin & Schlage are also available

ALL PDL4100 LOCKS ARE WEATHER-RESISTANT

PLEASE CHECK WITH FACTORY FOR LEAD TIMES

ON SPECIAL FINISHES AND IC PREPS

PRODUCT

FINISH

LIST PRICE

PDL4100

US26D

US3 & US10B

$1,492.00

$1,578.00

PDL4175

US26D

US3 & US10B

$1,508.00

$1,612.00

PDL4100IC*

US26D

US3 & US10B

$1,508.00

$1,612.00

PDL4175IC*

US26D

US3 & US10B

$1,543.00

$1,612.00

PDL4100SK

Mounted PDL4100 demo

Call Factory

AL-PCI2

Computer interface cable for serial

connection Includes DL-Windows

$129.00

ALPCI2-U

MX1130

USB computer interface cable

includes DL-Windows software

USB Converter

$237.00

$118.00

AL-IR1

Infra-red Printer

$520.00

AL-DTMIII

Data Transfer Module

$448.00

AL-PRE

Prox Card Enroller

$590.00

ALHID1326

Proximity Access Cards 100 Per Box

$505.00

ALHID1336

Proximity, Magnetic Stripe and Photo

ID cards 100 per box

$1,030.00

ALHID1386

Proximity and Photo ID

Card 100 per box

$927.00

ALHID1391

MicroProx Tag 10 per box

$82.00

ALHID1346

Proximity keyfob 10 per box

$118.00

*Add “C” for Corbin, “M” for Medeco, “R” for Sargent, “Y” for Yale and “S” for Schlage to end of the part number for

specially prepped IC core models. Add $15.00 to the list price shown above. **MUST SPECIFY 7 PIN FOR CORBIN AND

YALE**

Extended sizes:

Standard and SFIC cylinder

preps can be extended for

thicker doors.

$165.00 add on to list for

extended lock.

Extended lock legend:

W54 - 2 1/8"

W57 - 2 1/4"

W60 - 2 3/8"

W64 - 2 1/2"

W70 - 2 3/4"

W76 - 3"

W83 - 3 1/4"

W89 - 3 1/2"

Note: Locks can be

adjusted by +/- 1/8" by

adding or removing

spacers.

Price Book 2017

TRILOGY CYLINDRICAL LOCK PARTS

Part Number

Description

List Price

S6054 Complete

o

utside housing for

DL2700WP available finishes 26D, 3, &

10B

$358.00

S6126

Complete outside housing for DL2800WP

available finishes 26D, 3, & 10B

$457.00

S6047

Complete outside housing for DL3000WP

available finishes 26D, 3, & 10B

$696.00

S6122

Complete outside housing for PDL3000

available finishes 26D, 3, & 10B

$1,087.00

S6163

Complete outside housing for DL4100

available finishes 26D, 3, & 10B $524.00

S6164

Complete outside housing for PDL4100

available finishes 26D, 3, & 10B $893.00

S6045

Standard key override lock body

complete

$326.00

S6046

Best prep interchangeable core lock body

complete

$326.00

S6045-C/R

Corbin/Sargent prep interchangeable core

lock body complete

$358.00

S6045-Y/M

Yale/Medeco prep interchangeable core

lock body complete

$358.00

S6045-S

Schlage prep interchangeable core lock

body complete

$358.00

HW614C

Outside lever standard prep available

finishes 26D, 3, & 10B

$37.00

HW616C

Outside lever Best IC prep available

finishes 26D, 3, & 10B

$37.00

HW615D

Inside lever for all cylindrical locks

available finishes 26D, 3, & 10B

$37.00

HW592G

Battery Cover available finishes 26D, 3,

& 10B

$21.00

P5849

Latch bolt 2 ¾” available finishes 26D, 3,

& 10B

$26.00

S5980-1

Latch bolt 2 3/8” 26D finish

$26.00

S5980-2

Latch bolt 2 3/8” US5 finish

$26.00

HW470

4 7/8” strike available 26D, 3, & 10B

$15.00

HW577

2 ¾” strike available finishes 26D, 3, &

10B

$16.00

HW596F

Standard cylinder w/2 keys available

finishes 26D, 3, & 10B

$26.00

S6148

Lever return spring

$5.00

S6061

Replacement battery pack cylindrical

$47.00

S6172

Replacement battery pack Double sided

$30.00

HW580

Schlage® key override tailpiece for

Cylindrical locks

$11.00

HW620D

Lori® key override tailpiece for

Cylindrical locks

$11.00

HW597E

Alarm Lock cylindrical key override

tailpiece

$11.00

HW598D

Cylindrical Interchangeable core

Tailpiece Best prep

$11.00

S6070

IC tailpiece bag assembly w/washer

Specify for the following:

S – Schalge, B –Best, R –Sargent,

M – Medeco, Y –Yale, C –Corbin

$16.00

MX942

Replacement DTM cable

$20.00

Price Book 2017

TRILOGY CYLINDRICAL LOCK PARTS (con’t)

Part Number

Description

List Price

WA160C

Washer used on HW620, HW597C &

HW598D

$3.00

S6072

Set of spacers for doors 1 3/8” or less

$70.00

CW-27AB

Wrap around plate in US5

$65.00

CW-27PB

Wrap around plate in US3

$70.00

CW-27S

Wrap around plate US32D

$70.00

DL2700DJ

Drilling Jig for cylindrical locks

$405.00

TRILOGY LOCK ACCESSORIES

AL-PCI2

Computer interface cable for serial

Connection includes DL-Windows

Software

$129.00

ALPCI2-U

MX1130

USB computer interface cable

includes DL-Windows software

USB Converter

$237.00

$118.00

AL-IR1

Infra-red Printer

$520.00

AL-DTMIII

Data Transfer Module

$448.00

AL-PRE

Prox Card Enroller

$590.00

ALHID1326

Proximity Access Cards 100 Per Box

$505.00

ALHID1336

Proximity, Magnetic Stripe and Photo

ID cards 100 per box

$1,030.00

ALHID1386

Proximity and Photo ID

Card 100 per box

$927.00

ALHID1391

MicroProx Tag 10 per box

$82.00

ALHID1346

Proximity keyfob 10 per box

$118.00

ALTRAINDVD

Trilogy DL-Windows and Networx

Connectivity software training videos

divided into 4 easy to follow sections

conducted into a classroom style

environment. Training videos cover

basics, getting started, schedules and

times zones, programming Trilogy locks

via a laptop and the DTM along with how

to connect and bring Networx on line.

$0.00 + $15.95 shipping and handling

charge. Please contact customer service at

1-800-ALA-LOCK to place your order via

credit card, or email

sales@alarmlock.com

Price Book 2017

TRILOGY & NETWORX REMOTE RELEASE PRODUCTS

PRODUCT

DESCRIPTION

LIST PRICE

RR-TRILOGYKIT

Remote release kit for all Trilogy

Cylindrical models includes the RR-

1BUTTON for desk mount applications

and RR-RECEIVER which is designed to

be installed inside the battery

compartment next to the battery pack of

any cylindrical Trilogy lock. The RR-

RECEIVER connects to the 2 white

remote release wires inside the battery

compartment and to the black and red

battery pack wires to power the receiver.

These kits will retro fit to any existing

cylindrical Trilogy manufactured since

1994.

$221.00

RR-RECEIVER

RR-RECEIVER is designed to be

installed next to the battery pack of any

cylindrical Trilogy lock. The RR-

RECEIVER connects to the 2 white

remote release wires and to the black and

red battery pack wires and will retro fit to

any existing cylindrical Trilogy

manufactured since 1994. You will need

to purchase separately either an RR-

1BUTTON OR 4BKEYFOB to activate

the receiver

$128.00

RR-1BUTTON

Remote release desk mounted button

designed to be used with any existing

Networx lock enrolled with a simple

keypad program. Must update the

firmware of your existing Networx Lock.

Also can be used with an RR-RECEIVER

to any existing Trilogy Cylindrical Lock,

RR-RECEIVER sold separately.

$92.00

RR-4BKEYFOB

Remote release 4 button key fob designed

to be used with any existing Networx lock

enrolled with a simple keypad program.

Must update the firmware of your existing

Networx Lock. Also can be used with an

RR-RECEIVER to any existing Trilogy

Cylindrical Lock, RR-RECEIVER sold

separately.

$103.00

RR-MORTISEKIT

RR-EXITTRIMKIT

Remote release kit for Mortise Locks

Remote release kit for Exit Trim Locks

*Both include RR-1BUTTON and

RECEIVER mounted on a Lexan battery

cover.*

$242.00

Note: The Remote Release Products follow the Networx Discount Structure. Will not work with Narrow Stile series locksets.

Price Book 2017

TRILOGY ELECTRONIC DIGITAL MORTISE LOCKS

DL3500 SERIES - Electronic battery operated digital mortise lock. Holds

up to 300 codes, Master, Management, Supervisor & basic

user. 500 event schedule, real time clock & 40,000 event audit trail.

SPECIFICATIONS:

Door Thickness: Fits 1 3/8” to 1 7/8” (4.46cm).

Backset: 2 3/4” standard

Strike: 1 1/4” x 4 7/8”strike included

Handing: Specify RH or LH when ordering, lock is reversible

In the field

Power: 5 AA alkaline batteries (included)

Keypad: All metal, 12 button. All functions programmed

through keypad.

Door prep: Standard ANSI A115 Mortise prep, modified by

adding additional through-bolt holes

Compliances: Steelcase lock body meets BHMA specifications

For Grade 1 locks. UL listed to the 10C Positive

Pressure Specification. FCC Certified. ADA

compliant levers

Functions: Classroom function feature stainless steel latchbolt

With 3/4” (1.91cm) projection and deadlocking latch

Deadbolt function feature stainless steel deadbolt with

1” (2.55cm) projection, latchbolt with 3/4” (1.91cm)

projection and deadlocking latch Deadbolt may be

projected from key cylinder from outside door or

turn-piece from inside door

Cylinder: 1 3/8” (3.5cm) mortise cylinder supplied. Will

Accept 1 3/8” to 1 1/2” (3.5 – 3.82cm) mortise

Cylinder. Classroom function supplied with straight

Cam and deadbolt function supplied with cloverleaf

Cam

Cams: Cams for other manufacturer’s cylinders are available

See “Mortise Lock accessories” for part numbers &

Manufacturers

ALL DL3500 MORTISE LOCKS ARE WEATHER-RESISTANT

PLEASE CHECK WITH FACTORY ON LEAD TIMES FOR SPECIAL FINISHES

PRODUCT

FINISH

LIST PRICE

DL3500CRR

Straight lever classroom function

Right hand

US26D

US3 & US10B

$1,516.00

$1,590.00

DL3500CRL

Straight lever classroom function

Left Hand

US26D

US3 & US10B

$1,516.00

$1,590.00

DL3500DBR

Straight lever deadbolt function

Right hand

US26D

US3 & US10B

$1,516.00

$1,590.00

DL3500DBL

Straight lever deadbolt function

Left Hand

US26D

US3 & US10B

$1,516.00

$1,590.00

DL3575CRR

Regal (curved) lever classroom

Function right hand

US26D

US3 & US10B

$1,532.00

$1,606.00

DL3575CRL

Regal (curved) lever classroom

Function left hand

US26D

US3 & US10B

$1,532.00

$1,606.00

DL3575DBR

Regal (curved) lever deadbolt

Function right hand

US26D

US3 & US10B

$1,532.00

$1,606.00

DL3575DBL

Regal (curved) lever deadbolt

Function left hand

US26D

US3 & US10B

$1,532.00

$1,606.00

Price Book 2017

TRILOGY ELECTRONIC DIGITAL MORTISE LOCKS (con’t)

PRODUCT

DESCRIPTION

LIST PRICE

DL3500SK

Mounted sales kit, straight lever.

Available in classroom or deadbolt

function.

Call Factory

AL-DTMIII

Data Transfer Module

$448.00

AL-PCI2

Computer interface cable for serial

connection includes DL-Windows

software

$129.00

ALPCI2-U

USB computer interface cable

includes DL-Windows software

$237.00

MX1130

USB Converter

$118.00

AL-IR1

Infra red Printer

$520.00

ALTRAINDVD

Trilogy DL-Windows and Networx

Connectivity software training videos

divided into 4 easy to follow sections

conducted into a classroom style

environment. Training videos cover

basics, getting started, schedules and

times zones, programming Trilogy locks

via a laptop and the DTM along with how

to connect and bring Networx on line.

$0.00 + $15.95 shipping and handling

charge. Please contact customer service at

1-800-ALA-LOCK to place your order via

credit card, or email

sales@alarmlock.com

MORTISE LOCK PARTS

CLASSROOM FUNCTION CAMS

DESCRIPTION

LIST PRICE

HW956-L

Alarm Lock Standard Straight Cam

$5.00

HW956-M

Marks Straight Cam

$5.00

HW956-C

Corbin-Russwin Straight Cam

$5.00

HW956-S

Schlage Straight Cam

$5.00

HW956-A

Arrow Straight Cam

$5.00

HW956-R

Sargent Straight Cam

$5.00

DEADBOLT FUNCTION CAMS

HW957-L

Alarm Lock Standard Cloverleaf Cam

$5.00

HW957-M

Marks Cloverleaf Cam

$5.00

HW957-C

Corbin-Russwin Cloverleaf Cam

$5.00

HW957-S

Schalge Cloverleaf Cam

$5.00

HW957-A

Arrow Cloverleaf Cam

$5.00

HW957-R

Sargent Cloverleaf Cam

$5.00

HW1141

Schlage IC Cloverleaf Cam

$5.00

S6123

DL3500 complete outside housing

available in 26D, US3 & US10B

$1,008.00

S6175

Replacement lever support spring

$3.00

S6192

Lever and spring upgrade kit

Standard lever –26D, 10B, US3

$54.00

S6193

Lever and spring upgrade kit

Regal lever –26D, 10B, US3

$80.00

HW904DBR

Right hand deadbolt lock body

$171.00

HW903DBL

Left hand deadbolt lock body

$171.00

HW870CRL

Left Hand Classroom lock body

$171.00

HW875CRR

Right hand Classroom lock body

$171.00

S6065

Replacement Battery Pack

$38.00

Price Book 2017

TRILOGY ELECTRONIC DIGITAL MORTISE LOCKS

WITH PRIVACY & RESIDENCY FEATURES

DL4500 SERIES -Electronic battery operated digital proximity lock. Holds up to 2000 codes, Master,

Management, Supervisor & basic user. 500 event schedule, real time clock & 40,000 event audit trail. Privacy

feature will lock out all users for programmed amount of time. Residency feature-allows exiting without having

to lock the door.

SPECIFICATIONS:

Door Thickness: Fits 1 3/8” to 1 7/8” (4.46cm).

Backset: 2 3/4” standard

Strike: 1 1/4” x 4 7/8”strike included

Handing: Specify RH or LH when ordering, lock is reversible

In the field

Power: 5 AA alkaline batteries (included)

Keypad: All metal, 12 button. All functions programmed

through keypad.

Door prep: Standard ANSI A115 Mortise prep, modified by

adding additional through-bolt holes

Compliances: Steelcase lockbody meets BHMA specifications

For Grade 1 locks. UL listed to the 10C Positive

Pressure Specification. FCC Certified. ADA

compliant levers

Functions: Deadbolt function feature stainless steel deadbolt with

1” (2.55cm) projection, latchbolt with 3/4” (1.91cm)

projection and deadlocking latch Deadbolt may be

projected from key cylinder from outside door or

turn-piece from inside door

Cylinder: 1 3/8” (3.5cm) mortise cylinder supplied. Will

Accept 1 3/8” to 1 1/2” (3.5 –3.82cm) mortise

Cylinder. Deadbolt function supplied with cloverleaf

Cam

Cams: Cams for other manufacturer’s cylinders are available

See “Mortise Lock accessories” for part numbers &

Manufacturers

ALL DL4500 LOCKS ARE WEATHER-RESISTANT

PLEASE CHECK WITH FACTORY FOR LEAD TIMES ON SPECIAL FINISHES

PRODUCT

FINISH

LIST PRICE

DL4500DBR

Straight lever deadbolt function

Right hand

US26D

US3 & US10B

$1,142.00

$1,216.00

DL4500DBL

Straight lever deadbolt function

Left Hand

US26D

US3 & US10B

$1,142.00

$1,216.00

DL4575DBR

Regal (curved) lever deadbolt

Function right hand

US26D

US3 & US10B

$1,164.00

$1,233.00

DL4575DBL

Regal (curved) lever deadbolt

Function left hand

US26D

US3 & US10B

$1,164.00

$1,233.00

AL-PCI2

Computer interface cable for serial

connection includes DL-Windows

software

$129.00

ALPCI2-U

Computer interface cable for serial and

USB computer interface cable includes

DL-Windows software

$237.00

MX1130

USB Converter

$118.00

AL-IR1

Infra-red Printer

$520.00

AL-DTMIII

Data Transfer Module

$448.00

DL4500SK

Mounted DL4500 Demo

Call Factory

Price Book 2017

TRILOGY ELECTRONIC PROXIMITY MORTISE LOCKS

PDL3500/PL3500 -Electronic battery operated digital mortise lock. Holds up to 2000

user codes, Master, Management, Supervisor & basic user. 500 scheduled

events, real time clock & 40,000 event audit trail. Will read most HID card

and keyfob formats.

SPECIFICATIONS:

Door Thickness: Fits 1 3/8” to 1 7/8” (4.46cm).

Backset: 2 3/4” standard

Strike: 1 1/4” x 4 7/8”strike included

Handing: Specify RH or LH when ordering, lock is reversible

In the field

Power: 5 AA alkaline batteries (included)

Keypad: Weatherproof all metal, 12 button. All functions

programmed through keypad. Proximity antenna housing

molded of ultra high strength, impact resistant Lexan®

Door prep: Standard ANSI A115 Mortise prep, modified by

adding additional through-bolt holes

Compliances: Steelcase lockbody meets BHMA specifications

For Grade 1 locks. UL listed to the 10C Positive

Pressure Specification. FCC Certified. ADA

compliant levers

Functions: Classroom function feature stainless steel latchbolt

With 3/4” (1.91cm) projection and deadlocking latch

Deadbolt function feature stainless steel deadbolt with

1” (2.55cm) projection, latchbolt with 3/4” (1.91cm)

projection and deadlocking latch Deadbolt may be

projected from key cylinder from outside door or

turn-piece from inside door

Cylinder: 1 3/8” (3.5cm) mortise cylinder supplied. Will

Accept 1 1/4” to 1 1/2” (3.5 –3.82cm) mortise

Cylinder. Classroom function supplied with straight

Cam and deadbolt function supplied with cloverleaf

Cam

Cams: Cams for other manufacturer’s cylinders are available

See “Mortise Lock accessories” for part numbers &

Manufacturers

ALL PDL3500 LOCKS ARE WEATHER-RESISTANT

PLEASE CHECK WITH FACTORY FOR LEAD TIMES ON SPECIAL FINISHES

PRODUCT

FINISH

LIST PRICE

PDL3500CRR

Straight lever classroom function

Right hand

US26D

US3 & US10B

$1,940.00

$2,020.00

PDL3500CRL

Straight lever classroom function

Left Hand

US26D

US3 & US10B

$1,940.00

$2,020.00

PDL3500DBR

Straight lever deadbolt function

Right hand

US26D

US3 & US10B

$1,940.00

$2,020.00

PDL3500DBL

Straight lever deadbolt function

Left Hand

US26D

US3 & US10B

$1,940.00

$2,020.00

PDL3575CRR

Regal (curved) lever classroom

Function right hand

US26D

US3 & US10B

$1,956.00

$2,037.00

PDL3575CRL

Regal (curved) lever classroom

Function left hand

US26D

US3 & US10B

$1,956.00

$2,037.00

Price Book 2017

TRILOGY ELECTRONIC PROXIMITY MORTISE LOCKS (con’t)

PLEASE CHECK WITH FACTORY FOR LEAD TIMES ON SPECIAL FINISHES

PRODUCT

DESCRIPTION

LIST PRICE

PDL3575DBR

Regal (curved) lever deadbolt

Function right hand

US26D

US3 & US10B

$1,956.00

$2,037.00

PDL3575DBL

Regal (curved) lever deadbolt

Function left hand

US26D

US3 & US10B

$1,956.00

$2,037.00

PDL3500SK/26D

Mounted sales kit, straight lever.

Available in classroom or deadbolt

function.

Call Factory

PL3500CRR

Straight lever classroom function

Right hand

US26D

US3 & US10B

$1,940.00

$2,020.00

PL3500CRL

Straight lever classroom function

Left Hand

US26D

US3 & US10B

$1,940.00

$2,020.00

PL3500DBR

Straight lever deadbolt function

Right hand

US26D

US3 & US10B

$1,940.00

$2,020.00

PL3500DBL

Straight lever deadbolt function

Left Hand

US26D

US3 & US10B

$1,940.00

$2,020.00

PL3575CRR

Regal (curved) lever classroom

Function right hand

US26D

US3 & US10B

$1,956.00

$2,037.00

PL3575CRL

Regal (curved) lever classroom

Function left hand

US26D

US3 & US10B

$1,956.00

$2,037.00

PL3575DBR

Regal (curved) lever deadbolt

Function right hand

US26D

US3 & US10B

$1,956.00

$2,037.00

PL3575DBL

Regal (curved) lever deadbolt

Function left hand

US26D

US3 & US10B

$1,956.00

$2,037.00

AL-PCI2

Computer interface cable for serial

connection includes DL-Windows

software

$129.00

ALPCI2-U

USB computer interface cable includes

DL-Windows software

$237.00

MX1130

USB Converter

$118.00

AL-IR1

Infra-red Printer

$520.00

AL-DTMIII

Data Transfer Module

$448.00

AL-PRE

Prox Card Enroller

$590.00

ALHID1326

Proximity Access Cards 100 Per Box

$505.00

ALHID1336

Proximity, Magnetic Stripe and Photo

ID cards 100 per box

$1,030.00

ALHID1386

Proximity and Photo ID

Card 100 per box

$927.00

ALHID1391

MicroProx Tag 10 per box

$82.00

ALHID1346

Proximity keyfob 10 per box

$118.00

ALTRAINDVD

Trilogy DL-Windows and Networx

Connectivity software training videos

divided into 4 easy to follow sections

conducted into a classroom style

environment. Training videos cover

basics, getting started, schedules and

times zones, programming Trilogy locks

via a laptop and the DTM along with how

to connect and bring Networx on line.

$0.00 + $15.95 shipping and handling

charge. Please contact customer service at

1-800-ALA-LOCK to place your order via

credit card, or email

sales@alarmlock.com

S6190

Exit Trim/Mortise Lock Parts Kit

$151.00

Price Book 2017

TRILOGY ELECTRONIC DIGITAL PROXIMITY MORTISE LOCKS

WITH PRIVACY & RESIDENCY FEATURES

PDL4500 -Electronic battery operated digital proximity lock. Holds up to 2000 codes, Master, Management,

Supervisor & basic user. 500 event schedule, real time clock & 40,000 event audit trail. Will read most HID card

and keyfob formats. Privacy feature will lock out all users for a programmed amount of time. Residency

feature-allows exiting without having to lock the door.

SPECIFICATIONS:

Door Thickness: Fits 1 3/8” to 1 7/8” (4.46cm).

Backset: 2 3/4” standard

Strike: 1 1/4” x 4 7/8”strike included

Handing: Specify RH or LH when ordering, lock is reversible

In the field

Power: 5 AA alkaline batteries (included)

Keypad: Weatherproof all metal, 12 button. All functions

programmed through keypad. Proximity antenna housing

molded of ultra high strength, impact resistant Lexan®

Door prep: Standard ANSI A115 Mortise prep, modified by

adding additional through-bolt holes

Compliances: Steelcase lockbody meets BHMA specifications

For Grade 1 locks. UL listed to the 10C Positive

Pressure Specification. FCC Certified. ADA

compliant levers

Functions: Deadbolt function feature stainless steel deadbolt with

1” (2.55cm) projection, latchbolt with 3/4” (1.91cm)

projection and deadlocking latch Deadbolt may be

projected from key cylinder from outside door or

turn-piece from inside door

Cylinder: 1 3/8” (3.5cm) mortise cylinder supplied. Will

Accept 1 1/4” to 1 1/2” (3.5 –3.82cm) mortise

Cylinder. Deadbolt function supplied with cloverleaf cam

Cams: Cams for other manufacturer’s cylinders are available

See “Mortise Lock accessories” for part numbers &

Manufacturers

ALL PDL4500 LOCKS ARE WEATHER-RESISTANT

PLEASE CHECK WITH FACTORY FOR LEAD TIMES ON SPECIAL FINISHES

PRODUCT

FINISH

LIST PRICE

PDL4500DBR

Straight lever deadbolt function

Right hand

US26D

US3 & US10B

$1,664.00

$1,744.00

PDL4500DBL

Straight lever deadbolt function

Left Hand

US26D

US3 & US10B

$1,664.00

$1,744.00

PDL4575DBR

Regal (curved) lever deadbolt

Function right hand

US26D

US3 & US10B

$1,682.00

$1,757.00

PDL4575DBL

Regal (curved) lever deadbolt

Function right hand

US26D

US3 & US10B

$1,682.00

$1,757.00

PDL4500SK/26D

Mounted Sales Demo

Call Factory

AL-PCI2

Computer interface cable for serial

connection includes DL-Windows

software

$129.00

ALPCI2-U

MX1130

USB computer interface cable

includes DL-Windows software

USB Converter

$237.00

$118.00

AL-IR1

Infra-red Printer

$520.00

AL-DTMIII

Data Transfer Module

$448.00

AL-PRE

Prox Card Enroller

$590.00

Price Book 2017

MORTISE LOCK ACCESSORIES

ALHID1326

Proximity Access Cards 100 Per Box

$505.00

ALHID1336

Proximity, Magnetic Stripe and Photo

ID cards 100 per box

$1,030.00

ALHID1386

Proximity and Photo ID

Card 100 per box

$927.00

ALHID1391

MicroProx Tag 10 per box

$82.00

ALHID1346

Proximity keyfob 10 per box

$118.00

ALTRAINDVD

Trilogy DL-Windows and Networx

Connectivity software training videos

divided into 4 easy to follow sections

conducted into a classroom style

environment. Training videos cover

basics, getting started, schedules and

times zones, programming Trilogy locks

via a laptop and the DTM along with how

to connect and bring Networx on line.

$0.00 + $15.95 shipping and handling

charge. Please contact customer service at

1-800-ALA-LOCK to place your order via

credit card, or email

sales@alarmlock.com

MORTISE LOCK PARTS

CLASSROOM FUNCTION CAMS

HW956-L

Alarm Lock Standard Straight Cam

$5.00

HW956-M

Marks Straight Cam

$5.00

HW956-C

Corbin-Russwin Straight Cam

$5.00

HW956-S

Schlage Straight Cam

$5.00

HW956-A

Arrow Straight Cam

$5.00

HW956-R

Sargent Straight Cam

$5.00

DEADBOLT FUNCTION CAMS

HW957-L

Alarm Lock Standard Cloverleaf Cam

$5.00

HW957-M

Marks Cloverleaf Cam

$5.00

HW957-C

Corbin-Russwin Cloverleaf Cam

$5.00

HW957-S

Schalge Cloverleaf Cam

$5.00

HW957-A

Arrow Cloverleaf Cam

$5.00

HW957-S

Sargent Cloverleaf Cam

$5.00

HW1141

Schlage IC Cloverleaf Cam

$5.00

S6165

PDL3500 complete outside housing

available in 26D, US3 & US10B

$1,087.00

S6175

Replacement lever support spring

$3.00

S6192

Lever and spring upgrade kit

Standard lever –26D, 10B, US3

$54.00

S6193

Lever and spring upgrade kit

Regal lever –26D, 10B, US3

$80.00

HW904DBR

Right hand deadbolt lock body

$171.00

HW903DBL

Left hand deadbolt lock body

$171.00

HW870CRL

Left Hand Classroom lock body

$171.00

HW875CRR

Right hand Classroom lock body

$171.00

S6065

Replacement Battery Pack

$38.00

Price Book 2017

TRILOGY NARROW STYLE LOCK PRODUCTS

DL1200 SERIES –Aluminum door retrofit outside trim. Works with Adams Rite®

4500, 4700 & 4900 series deadlatch. 4070, MS18505 & MS19505

series deadbolts. 100 user codes, master,

Manager, basic user and 3 “one-time” user codes.

ALL DL1200 SERIES LOCKS ARE WEATHER-RESISTANT

PRODUCT

DESCRIPTION

LIST PRICE

DL1200/26D1

Lever set works with Adams Rite®

4500, 4700, & 4900 series deadlatch

26D finish

$672.00

DL1200/10B1

Lever set works with Adams Rite®

4500, 4700 & 4900 series deadlatch

10B finish

$672.00

DL1225/26D2

Thumb turn works with Adams Rite®

4070, MS18505, MS1950 series

deadbolt

26D finish

$672.00

DL1225/10B2

Thumb turn works with Adams Rite®

4070, MS18505, MS1950 series

deadbolt

10B finish

$672.00

DL1250/26D2

Knob works with Adams Rite®

4070, MS18505, MS1950 series

deadbolt

26D finish

$672.00

DL1250/10B2

Knob works with Adams Rite®

4070, MS18505, MS1950 series

deadbolt

10B finish

$672.00

SPECIFICATIONS:

Door thickness: supports style 1 ¾” only

Backset: supports 31/32”, 1 1/8”, & 1 ½”

Latch: works with Adams Rite® 1850, 1950, 4710, 4070, 4730, 4900

Series spring latch and MS1850S & MS1950S series deadbolts

Handing: non-handed

Power: uses 2 DL123A lithium batteries

Keypad: all metal, vandal resistant 12 button keypad supports 3-5 digit

PIN codes

Cylinder: supplied with 6 pin mortise standard mortise cylinder SC1

Keyway. Use 1 3/8” or 1 ½” cylinders

Cams: cam supplied works with generic Alarm Lock cylinder. Other

Standard cams available for Corbin-Russwin, Marks, Arrow,

Sargent & Schlage. IC type cams for Best, Corbin-Russwin,

Medeco, Schlage & Yale are also available

Price Book 2017

TRILOGY NARROW STYLE LOCK PRODUCTS

DL1300 SERIES –Aluminum door retrofit outside trim. Works with Adams Rite® 1850, 1950, 4710,

4070, 4730, 4900 series spring latch and MS18505 & MS19505 series deadbolts. 2,000 user

codes, master, Manager, basic user and multiple “one-time” user codes. 500 event schedule,

real time clock & 40,000 event audit trail.

ALL DL1300 SERIES LOCKS ARE WEATHER RESISTANT

PRODUCT

DESCRIPTION

LIST PRICE

DL1300/26D1

Lever set works with Adams Rite®

4500, 4700, & 4900 series deadlatch

26D finish

$843.00

DL1300/10B1

Lever set works with Adams Rite®

4500, 4700, & 4900 series deadlatch

10B finish

$843.00

DL1325/26D2

Thumb turn works with Adams Rite®

4070, MS18505, MS1950 series

deadbolt

26D finish

$843.00

DL1325/10B2

Thumb turn works with Adams Rite®

4070, MS18505, MS1950 series

deadbolt

10B finish

$843.00

DL1350/26D2

Knob works with Adams Rite®

4070, MS18505, MS1950 series

deadbolt

26D finish

$843.00

DL1350/10B2

Knob works with Adams Rite®

4070, MS18505, MS1950 series

deadbolt

10B finish

$843.00

AL-PCI2

Computer interface cable for serial

connection includes DL-Windows

software

$129.00

ALPCI2-U

USB computer interface cable includes

DL-Windows software

$237.00

AL-IR1

Infra-red Printer

$520.00

AL-DTMIII

Data Transfer Module

$448.00

SPECIFICATIONS:

Door thickness: supports style 1 ¾” only

Backset: supports 31/32”, 1 1/8”, & 1 ½”

Latch: works with Adams Rite® 1850, 1950, 4710, 4070, 4730, 4900

Series spring latch and MS1850S & MS1950S series deadbolts

Handing: non-handed

Power: uses 2 DL123A lithium batteries

Keypad: all metal, vandal resistant 12 button keypad supports 3-5 digit

PIN codes

Cylinder: supplied with 6 pin mortise standard mortise cylinder SC1

Keyway. Use 1 3/8” or 1 ½” cylinders

Cams: cam supplied works with generic Alarm Lock cylinder. Other

Standard cams available for Corbin-Russwin, Marks, Arrow,

Sargent & Schlage. IC type cams for Best, Corbin-Russwin,

Medeco, Schlage & Yale are also available

Price Book 2017

TRILOGY NARROW STILE LOCK PRODUCTS

PDL1300 SERIES –Aluminum door retrofit outside trim. Works with Adams Rite®

1850, 1950, 4710, 4070, 4730, 4900 series spring latch and MS18505 & MS19505 series deadbolts.

2,000 user codes, master, Manager, basic user and multiple “one-time” user codes. Proximity

capabilities. 500 event schedule, real time clock & 40,000 event audit trail.

ALL NARROW STILE LOCKS ARE WEATHER RESISTANT

PRODUCT

DESCRIPTION

LIST PRICE

PDL1300/26D1

Lever set works with Adams Rite®

4500, 4700, & 4900 series deadlatch

26D finish

$1,222.00

PDL1300/10B1

Lever set works with Adams Rite®

4500, 4700, & 4900 series deadlatch

10B finish

$1,222.00

PDL1325/26D2

Thumb turn works with Adams Rite®

4070, MS18505, MS1950 series

deadbolt

26D finish

$1,222.00

PDL1325/10B2

Thumb turn works with Adams Rite®

4070, MS18505, MS1950 series

deadbolt

10B finish

$1,222.00

PDL1350/26D2

Knob works with Adams Rite®

4070, MS18505, MS1950 series

deadbolt

26D finish

$1,222.00

PDL1350/10B2

Knob works with Adams Rite®

4070, MS18505, MS1950 series

deadbolt

10BD finish

$1,222.00

AL-PCI2

Computer interface cable for serial

connection includes DL-Windows

software

$129.00

SPECIFICATIONS:

Door thickness: supports style 1 ¾” only

Backset: supports 31/32”, 1 1/8”, & 1 ½”

Latch: works with Adams Rite® 1850, 1950, 4710, 4070, 4730, 4900

Series spring latch and MS1850S & MS1950S series deadbolts

Handing: non-handed

Power: uses 2 DL123A lithium batteries

Keypad: all metal, vandal resistant 12 button keypad supports 3-5 digit

PIN codes and HID proximity cards and fobs. Proximity

antenna housing molded of ultra high strength, impact

resistant Lexan®

Cylinder: supplied with 6 pin mortise standard mortise cylinder SC1

Keyway. Use 1 3/8” or 1 ½” cylinders

Cams: cam supplied works with generic Alarm Lock cylinder. Other

Standard cams available for Corbin-Russwin, Marks, Arrow,

Sargent & Schlage. IC type cams for Best, Corbin-Russwin,

Medeco, Schlage & Yale are also available

Price Book 2017

TRILOGY NARROW STYLE LOCK PRODUCTS

(con’t)

ALPCI2-U

USB computer interface cable includes

DL-Windows software

$237.00

MX1130 USB Converter $118.00

AL-IR1

Infra-red Printer

$520.00

AL-DTMIII

Data Transfer Module

$448.00

AL-PRE

Prox Card Enroller

$590.00

ALHID1326

Proximity Access Cards 100 Per Box

$520.00

ALHID1336

Proximity, Magnetic Stripe and Photo

ID cards 100 per box

$1,030.00

ALHID1386

Proximity and Photo ID

Card 100 per box

$927.00

ALHID1391

MicroProx Tag 10 per box

$82.00

ALHID1346

Proximity keyfob 10 per box

$118.00

PARTS

STANDARD MORTISE CAMS

DESCRIPTION

LIST PRICE

HW1344

Corbin-Russwin standard cam

$5.00

HW1346

Marks standard cam

$5.00

HW1348

Arrow & Sargent standard cams

$5.00

HW1349

Schlage standard cam

$5.00

IC MORTISE CAMS

HW1345

Corbin-Russwin IC cam

$11.00

HW1347

Medeco IC cam

$11.00

HW1350

Schlage IC cam

$11.00

HW1343

Best IC cam

$11.00

S6169

Best IC housing with cam attached

26D, 10B

$42.00

Replacement Battery

S6161

Inside Battery Kit

$61.00

S6170

Replacement Battery

$38.00

HOW TO ORDER THE TRILOGY NARROW STILE LOCKS

Last two digits of the part number are Used with Adams Rite Product

00 Straight Lever 4500, 4700 & 4900 Series Only

25 Thumb turn MS1850, MS1950 & 4070 Series

50 Knob MS1850, MS1950 & 4070 Series

Price Book 2017

TRILOGY NARROW STYLE/EXIT LOCK PRODUCTS

DL1200ET, DL1300ET & PDL1300ET SERIES -Aluminum door retrofit outside trim. Works with Arrow,

DCI, Von Duprin, Corbin, Dor-o-matic, Dorma & Jackson. DL1200ET has 100 user codes, master, Manager,

basic user and 3 “one-time” user codes. DL1300ET & PDL1300ET have 2,000 user codes, multiple “one-time”

user codes. 500 event schedule, real time clock & 40,000 event audit trail. PDL1300ET also has proximity

capabilities.

ALL NARROW STILE/EXIT LOCKS ARE WEATHER RESISTANT

PRODUCT

DESCRIPTION

LIST PRICE

DL1200ET/26D

STRAIGHT LEVER

100 user codes

Narrow Stile Lock for Arrow

S1200/S1250, DCI 1200/1300, Von

Duprin 22, Corbin ED8200 & Von Duprin

33 panic LH (RHR) devices only

$672.00

DL1200ET//10B

STRAIGHT LEVER

100 user codes

Narrow Stile Lock for Arrow

S1200/S1250, DCI 1200/1300, Von

Duprin 22, Corbin ED8200 & Von Duprin

33 panic LH (RHR) devices only

$672.00

DL1225ET/26D

TURNPIECE

100 user codes

Narrow Stile lock for Dor-o-Matic 2090,

Jackson 1095 & Dorma 5300 panic

devices

$672.00

DL1225ET/10B

TURNPIECE

100 user codes

Narrow Stile lock for Dor-o-Matic 2090,

Jackson 1095 & Dorma 5300 panic

devices

$672.00

DL1250ET/26D

KNOB

100 user codes

Narrow Stile lock for Dor-o-Matic 2090,

Jackson 1095 & Dorma 5300 panic

devices

$672.00

SPECIFICATIONS:

Door thickness: supports style 1 ¾” only

Handing: non-handed

Power: uses 2 DL123A lithium batteries

Keypad: all metal, vandal resistant 12 button keypad supports 3-5

digit

PIN codes

Cylinder: supplied with 6 pin mortise standard mortise cylinder SC1

Keyway. Use 1 3/8” or 1 ½” cylinders

Cams: cam supplied works with generic Alarm Lock cylinder. Other

Standard cams available for Corbin-Russwin, Marks, Arrow,

Sargent & Schlage. IC type cams for Best, Corbin-Russwin,

Medeco, Schlage & Yale are also available

Must order separate tailpiece for specific ET being installed

(See page 31)

Note: ET Trim works w/V33 LH (RHR) only

Price Book 2017

TRILOGY NARROW STYLE/EXIT LOCK PRODUCTS (CON’T)

DL1250ET/10B

KNOB

100 user codes

Narrow Stile lock for Dor-o-Matic 2090,

Jackson 1095 & Dorma 5300 panic

devices

$672.00

DL1300ET/26D

STRAIGHT LEVER

2,000 user codes

Narrow Stile Lock for Arrow

S1200/S1250, DCI 1200/1300, Von

Duprin 22, Corbin ED8200 & Von Duprin

33 LH (RHR) devices only

$878.00

DL1300ET/10B

STRIGHT LEVER

2,000 user codes

Narrow Stile Lock for Arrow

S1200/S1250, DCI 1200/1300, Von

Duprin 22, Corbin ED8200 & Von Duprin

33 LH (RHR) devices only

$878.00

DL1325ET/26D

TURNPIECE

2,000 user codes

Narrow Stile lock for Dor-o-Matic 2090,

Jackson 1095 & Dorma 5300 panic

devices

$878.00

DL1325ET/210B

TURNPIECE

2,000 user codes

Narrow Stile lock for Dor-o-Matic 2090,

Jackson 1095 & Dorma 5300 panic

devices

$878.00

DL1350ET/26D

KNOB

2,000 user codes

Narrow Stile lock for Dor-o-Matic 2090,

Jackson 1095 & Dorma 5300 panic

devices

$878.00

DL1350ET/10B

KNOB

2,000 user codes

Narrow Stile lock for Dor-o-Matic 2090,

Jackson 1095 & Dorma 5300 panic

devices

$878.00

PDL1300ET/26D

STRAIGHT LEVER

2,000 user codes

Narrow Stile Lock for Arrow

S1200/S1250, DCI 1200/1300, Von

Duprin 22, Corbin ED8200 & Von Duprin

33 LH (RHR) devices only

$1,222.00

PDL1300ET/10B

STRAIGHT LEVER

2,000 user codes

Narrow Stile Lock for Arrow

S1200/S1250, DCI 1200/1300, Von

Duprin 22, Corbin ED8200 & Von Duprin

33 LH (RHR) devices only

$1,222.00

PDL1325ET/26D

TURNPIECE

2,000 user codes

Narrow Stile lock for Dor-o-Matic 2090,

Jackson 1095 & Dorma 5300 panic

devices

$1,222.00

PDL1325ET/10B

TURNPIECE

2,000 user codes

Narrow Stile lock for Dor-o-Matic 2090,

Jackson 1095 & Dorma 5300 panic

devices

$1,222.00

PDL1350ET/26D

KNOB

2,000 user codes

Narrow Stile lock for Dor-o-Matic 2090,

Jackson 1095 & Dorma 5300 panic

devices

$1,222.00

PDL1350ET/10B

KNOB

2,000 user codes

Narrow Stile lock for Dor-o-Matic 2090,

Jackson 1095 & Dorma 5300 panic

devices

$1,222.00

Price Book 2017

TRILOGY NARROW STYLE/EXIT LOCK PRODUCTS (CON’T)

Tailpieces must be used with the Panic Devices as shown below

TAILPIECE PART NUMBER

PANIC DEVICE

LIST PRICE

TP-1691

Used with Arrow S1200/1250, DCI

1200/1300, Von Duprin 22 & Dorma

5300 Panic Devices

$57.00

TP-1692 Used with Dor-o-Matic 2090 Panic

Device

$57.00

TP-1693

Used with Corbin ED8200 Panic Device

$57.00

TP-1694

Used with Von Duprin 33 LH (RHR)

devices only

$57.00

TP-1698

Used with Jackson 1095 Panic Device

$57.00

TRILOGY NARROW STYLE/EXIT LOCK PRODUCTS

PARTS AND ACCESSORIES

ACCESSORIES

DESCRIPTION

LIST PRICE

AL-PCI2

Computer interface cable for serial

connection includes DL-Windows

software

$129.00

ALPCI2-U

USB computer interface cable

includes DL-Windows software

$237.00

MX1130

USB Converter

$120.00

AL-IR1

Infra-red Printer

$520.00

AL-DTMIII

Data Transfer Module

$448.00

AL-PRE

Prox Card Enroller

$590.00

ALHID1326

Proximity Access Cards 100 Per Box

$505.00

ALHID1336

Proximity, Magnetic Stripe and Photo

ID cards 100 per box

$1,030.00

ALHID1386

Proximity and Photo ID

Card 100 per box

$927.00

ALHID1391

MicroProx Tag 10 per box

$82.00

ALHID1346

Proximity keyfob 10 per box

$118.00

STANDARD MORTISE CAMS

DESCRIPTION

LIST PRICE

HW1344

Corbin-Russwin standard cam

$5.00

HW1346

Marks standard cam

$5.00

HW1348

Arrow & Sargent standard cams

$5.00

HW1349

Schlage standard cam

$5.00

IC MORTISE CAMS

HW1345

Corbin-Russwin IC cam

$11.00

HW1347

Medeco IC cam

$11.00

HW1350

Schlage IC cam

$11.00

HW1343

Best IC cam

$11.00

S6169

Best IC housing w/cam attached 26D, 10B

$42.00

Replacement Battery

S6161

Inside Battery Kit

$61.00

S6170

Replacement Battery

$38.00

Price Book 2017

TRILOGY EXIT TRIM PRODUCTS

Battery operated Trilogy outside trim works with Marks M9900, Von Duprin 99, Corbin ED5000,

Yale 7100, Dorma 9300, Arrow 3800, Sargent 8800, Precision 1100, 2100 & Cal Royal 9800, series

panic devices. Available in DL series (keypad) or PDL (prox/keypad) formats. Features include

2,000 user codes, 500 scheduled events and 40,000 event audit trail.

SPECIFICATIONS:

Cylinder: Uses standard rim cylinder to operate key override

function. Will accept 6 or 7 pin interchangeable

core cylinders – see below.

Handing: Non-handed

Power: 5 AA alkaline batteries (included) mounted on inside

of door.

Keypad: Weather-resistant all metal, 12 button. All functions

Programmable through the keypad.

PDL version proximity antenna housing molded of

ultra high strength, impact resistant Lexan®

ALL ET SERIES LOCKS ARE WEATHER-RESISTANT

PLEASE CHECK WITH FACTORY FOR LEAD TIMES ON SPECIAL FINISHES

PRODUCT

DESCRIPTION

LIST PRICE

ETDL series

26D

$1,320.00

ETDL series

US3 & US10B

$1,388.00

ETDL series w/Regal lever

26D

$1,343.00

ETDL series w/Regal lever

US3 & US10B

$1,400.00

ETPDL series

26D

$1,722.00

ETPDL series

US3 & US10B

$1,792.00

ETPDL series w/Regal lever

26D

$1,744.00

ETPDL series w/Regal lever

US3 & US10B

$1,812.00

ETPL series

26D

US3 & US10B

$1,722.00

$1,792.00

ETPL series w/Regal lever

26D

US3 & US10B

$1,744.00

$1,812.00

Specify finish on adapter kit

ET- AL Finish = 26D, US3 & US10B

Alarm Lock Standard Rim Cylinder

Adapter kit (Schlage C keyway)

$57.00

ET-AR Finish = 26D, US3 & US10B

Arrow Standard Rim Cylinder

Adapter kit

$57.00

ET-AS Finish = 26D, US3 & US10B

ASSA Standard Rim Cylinder

Adapter kit

$57.00

ET –C Finish = 26D, US3 & US10B

Corbin Standard Rim Cylinder

Adapter kit

$57.00

ET –M Finish = 26D, US3 & US10B

Medeco Standard Rim Cylinder

Adapter kit

$57.00

ET –R Finish = 26D, US3 & US10B

Sargent Standard Rim Cylinder

Adapter kit

$57.00

ET -S Finish = 26D, US3 & US10B

Schlage Standard Rim Cylinder

Adapter kit

$57.00

ET -Y Finish = 26D, US3 & US10B

Yale Standard Rim Cylinder

Adapter kit

$57.00

ET –ARIC Finish = 26, 26D, 3, 4, 5, 10B

Arrow IC 6 & 7 Pin Rim Cylinder

Adapter kit

$79.00

ET -BIC Finish = 26D, US3 & US10B

Best IC 6 & 7 Pin Rim Cylinder

Adapter kit

$79.00

ET -CIC Finish = 26D, US3 & US10B

Corbin IC Rim Cylinder

Adapter kit

$79.00

ET –MIC Finish = 26D, US3 & US10B

Medeco IC 6 & 7 Pin Rim Cylinder

Adapter kit

$79.00

crash bar not included except with M99 kit.

Price Book 2017

TRILOGY EXIT TRIM PRODUCTS (CONT’D)

Product

Description

LIST PRICE

ET -RIC Finish = 26D, US3 & US10B

Sargent IC Rim Cylinder

Adapter kit

$79.00

ET -SIC Finish = 26D, US3 & US10B

Schlage IC Rim Cylinder

Adapter kit

$79.00

ET –YIC Finish = 26D, US3 & US10B

Yale IC 6 Pin Rim Cylinder

Adapter kit

$79.00

ETDLSKZ/26D

V99, C50, A38, D93, Y71, S88, CR8, P11

Mounted sales kit

For demo purposes

Call Factory

ETPDLSKZ/26D

V99, C50, A38, D93, Y71, S88, CR8, P11

Mounted sales kit

For demo purposes

Call Factory

AL-PCI2

Computer interface cable for serial

connection Includes DL-Windows

software

$129.00

ALPCI2-U

USB computer interface cable

includes DL-Windows software

$ 230.00

AL-IR1

Infra-red Printer

$520.00

AL-DTMIII

Data Transfer Module

$448.00

Al-PRE

Prox Card Enroller

$590.00

ALHID1326

Proximity Access Cards

100 per box

$470.00

ALHID1336

Proximity, Magnetic Stripe and Photo

ID cards 100 per box

$1,030.00

ALHID1386

Proximity and Photo ID

Card 100 per box

$927.00

ALHID1346

Proximity keyfob packed 10 per box

$118.00

ALHID1391

MicroProx Tag 10 per box

$82.00

EXIT TRIM KITS W/MARKS M9900 PANIC BAR

PRODUCT

DESCRIPTION

LIST PRICE

ETDL-M99K

26D Finish

$1,729.00

ETPDL-M99K

26D Finish

$2,118.00

EXTENDED SPINDLES CAN BE PURCHASED SEPARATELY

S6146

Extended Spindle and screws

Extend exit trim to fit 2 –2 ¾” doors

$112.00

S6147

Extended Spindle and screws

Extend exit trim to fit 3 –4” doors

$112.00

S6195

Extended Spindle and screws

Extend exit trim to fit 4 ¼ -5” doors

$112.00

SC544

Extended replacement screws with

adjustable lengths (4 per unit)

$21.00

9ETBATCASE

Replacement Battery

$48.00

S6175

Lever return spring for ET

$3.00

S6190

Exit Trim/Mortise Lock Parts Kit

$151.00

S6191

Lever and spring upgrade kit

Standard lever –26D, 10B

$61.00

S6193

Lever and spring upgrade kit

Regal lever –26D, 10B

$78.00

PLEASE SEE “HOW TO ORDER” CHART ON PAGE 18 TO PROPERLY ORDER YOUR TRILOGY EXIT TRIM.

IF YOU REQUIRE THE LOCK TO BE PREPPED FOR A THICKER DOOR, YOU MUST ORDER EXTENDED

SPINDLE/SCREW KIT. THE BASIC MODEL IS PREPPED FOR A

1 5/8” TO 1 7/8” DOOR.

**** PRECISION 2100 SERIES WILL WORK WITH THE VON DUPRIN 99 PREP. YOU MUST GET A MOUNTING

PLATE PART # 2141208 FROM PRECISION****

Price Book 2017

HOW TO ORDER YOUR TRILOGY EXIT LOCK

Below is a “How to Order” guide for the Trilogy Exit Trim products. Please follow this

guide when placing orders to avoid any delay in processing your order.

All units are sold with a generic cylinder adapter installed. When you are using a specific

Brand of rim cylinder, you must purchase a Cylinder Adapter Kit from the chart below.

ETPDLS1G/26DV99

HANDLE

R-Regal

S-Straight

FINISH

26D = satin chrome

10B = duronodic

COMPATABLE PANIC DEVICES

M99 – Marks M9900

V99 – VonDuprin 99(P21)

C50 – Corbin ED5000 and

Y71 -Yale 7100

D93 – Dorma 9300

A38 – Arrow 3800

S88 – Old Style Sargent 8800

NS8 – New Style Sargent 8888

P11 -Precision 1100

CR8 – Cal Royal 9800

DOOR

THICKNESS

1=1 ¾” + 1/8”

All units

shipped with

“1” option.

For thicker

door preps, you

must order

extended

spindle and

screw kit

separately.

TYPE

PDL Digital w/Prox

PL Prox only

DL Keypad only

CYLINDER ADAPTER KITS

You must choose one of the cylinder adapter kits

below if you are using a name brand cylinder in

the lock.

ET - AL - Alarm Lock standard

(Schlage C keyway)

ET – BIC - Best IC 6 & 7 pin

ET – S - Schlage standard rim

ET – SIC - Schlage IC

ET – R - Sargent standard rim

ET – RIC - Sargent IC

ET – Y -Yale standard rim

ET – YIC -Yale IC 6 pin

ET - C - Corbin standard rim

ET – CIC - Corbin IC

ET - M - Medeco standard rim

ET – MIC - Medeco IC 6 & 7 pin

ET – AR - Arrow standard rim

ET – ARIC - Arrow IC 6 & 7 pin

ET –AS -ASSA standard rim

G= generic rim

cylinder & adapter

kit included in all

locks

Please note that Precision 2100

series will match up to the Von

Duprin 99 series Trilogy. You must

get a mounting plate #2141208 from

Precision.

Price Book 2017

TRILOGY ELECTRONIC DIGITAL KEYPAD

DK3000/PDK3000 Series - Electronic digital keypad. Available in keypad only

and keypad plus prox. Holds up to 2,000 user codes,

Master, Management, Supervisor & basic user. 500

event schedule, real time clock & 40,000 event audit

trail. Prox unit will read most HID cards and keyfobs.

Specifications:

Wall mount : Single gang box mounting .

Wiring : Unit provides flying leads for power, relays, tamper and remote

Release.

I/O Specs: 2 form C relays 5AMP minimum contact rating. Red & green LED

Indicators. 1 remote release input. Sounder and tamper.

Power: Operating voltage 12-24VAC/DC field selectable.

ALL DK3000/PDK3000 ARE WEATHER-RESISTANT

PRODUCT

FINISH

LIST PRICE

DK3000 Metallic silver (MS) Metallic bronze (MB)

26D, US3 & US10B

$642.00

$838.00

PDK3000 Metallic silver (MS) Metallic bronze (MB)

26D, US3 & US10B

$1,067.00

$1,211.00

AL-PCI2

Computer interface cable for serial

connection includes DL-Windows

software

$129.00

ALPCI2-U

USB computer interface cable

includes DL-Windows software

$237.00

MX1130

USB Converter

$118.00

AL-IR1

Infra-red Printer

$520.00

AL-DTMIII

Data Transfer Module

$448.00

AL-PRE

Prox Card Enroller

$590.00

ALHID1326

Proximity Access Cards

100 per box

$505.00

ALHID1336

Proximity, Magnetic Stripe and Photo

ID cards 100 per box

$1,030.00

ALHID1386

Proximity and Photo ID

Card 100 per box

$927.00

ALHID1346

Proximity keyfob packed 10 per box

$118.00

ALHID1391

MicroProx Tag 10 per box

$82.00

ALTRAINDVD

Trilogy DL-Windows and Networx

Connectivity software training videos

divided into 4 easy to follow sections

conducted into a classroom style

environment. Training videos cover

basics, getting started, schedules and

times zones, programming Trilogy locks

via a laptop and the DTM along with how

to connect and bring Networx on line.

$0.00 + $15.95 shipping and handling

charge. Please contact customer service at

1-800-ALA-LOCK to place your order via

credit card, or email

sales@alarmlock.com

Price Book 2017

TRILOGY NETWORX DIGITAL LOCKS

DL6100 SERIES – Digital cylindrical lock supporting 5,000 pin user codes (3-6 digits), 500

scheduled events and 35,000 event audit log.

SPECIFICATIONS:

Door Thickness: Fits 1 5/8” to 1 7/8”. Other thickness,

please consult factory

Backset: 2 3/4” (2 3/8” also available)

Strike: 1 1/8”x 2 3/4” T strike & 1 1/4” x 4 7/8”

ASA strike included

Latchbolt: UL Listed, fire rated 3 hours, 1/2” throw

reversible

Handing: Non-handed

Power: 4 C-cell batteries (included)

Keypad: All metal, 12 button. Basic functions programmed

through the keypad.

Door prep: Standard ANSI A115 Series prep, modified by

adding additional through-bolt holes

Compliances: BHMA Certified Grade 1 heavy duty cylindrical lockset. UL listed

UL Listed 10C Positive Pressure Specification. FCC

Certified. ADA compliant levers

Cylinder: 6 pin solid brass, SC1 keyway, furnished with all

key override locks. Schlage, Corbin-Russwin CL,

Sargent 480 series, ASSA 65-611 & Lori cylinders

can also be used with HW620 tailpiece (supplied)

Interchangeable Standard model accepts 6 & 7 pin cylinders from

Core Models: Best, Falcon, Arrow, KSP, Medeco Keymark & Kaba

Peaks. IC core models prepped for 6 & 7 pin Yale, Medeco,

Sargent, Corbin-Russwin & Schlage are also available

ALL NETWORX LOCKS ARE WEATHER RESISTANT

PLEASE CHECK WITH FACTORY FOR LEAD TIMES ON SPECIAL FINISHES AND IC PREPS

PRODUCT

FINISH

LIST PRICE

DL6100

Standard key override

26D

10B

$1,452.00

$1,534.00

DL6175

Standard Key override

Regal (curved)

26D

10B

$1,472.00

$1,586.00

DL6100IC*

Interchangeable core

26D

10B

$1,472.00

$1,550.00

DL6175IC*

Interchangeable core

Regal (curved)

26D

10B

$1,503.00

$1,565.00

AL-IME

Ethernet connected gateway w/AC

adapter to plug into standard wall outlet $510.00

AL-IM80211

Wi-Fi gateway to connect to 802.11

network w/AC adapter to plug into

standard wall outlet.

$710.00

AL-IMEPOEP

Power Over Ethernet, plus hardwire

gateway interface capability. No AC

Power required.

$610.00

S6196

Networx Replacement Battery Pack

$45.00

*Add “C” for Corbin, “M” for Medeco, “R” for Sargent, “Y” for Yale and “S” for Schlage to end of the part number for

specially prepped IC core models. Add $15.00 to the list price shown above.

Networx training options available. See page 45 for details.

Extended sizes:

Standard and SFIC cylinder

preps can be extended for

thicker doors.

$165.00 add on to list for

extended lock.

Extended lock legend:

W54 - 2 1/8"

W57 - 2 1/4"

W60 - 2 3/8"

W64 - 2 1/2"

W70 - 2 3/4"

W76 - 3"

W83 - 3 1/4"

W89 - 3 1/2"

Note: Locks can be adjusted

by +/- 1/8" by adding or

removing spacers.

Price Book 2017

TRILOGY NETWORX PROXMITY DIGITAL LOCKS

PDL6100/PDL6200–Prox and digital cylindrical lock supporting 5,000 PIN user codes (3-6 digits), and/or HID

Proximity cards. 500 scheduled events and 35,000 event audit log.

SPECIFICATIONS:

Door Thickness: Fits 1 5/8” to 1 7/8”. Other thickness,

please consult factory

Backset: 2 3/4” (2 3/8” also available)

Strike: 1 1/8”x 2 3/4” T strike & 1 1/4” x 4 7/8”

ASA strike included

Latchbolt: UL Listed, fire rated 3 hours, 1/2” throw

reversible

Handing: Non-handed

Power: 4 C-cell batteries (included)

Keypad: All metal, 12 button. Basic functions programmed

through the keypad.

Door prep: Standard ANSI A115 Series prep, modified by

adding additional through-bolt holes

Compliances: BHMA Certified Grade 1 heavy duty cylindrical lockset. UL listed

UL Listed 10C Positive Pressure Specification. FCC

Certified. ADA compliant levers

Cylinder: 6 pin solid brass, SC1 keyway, furnished with all

key override locks. Schlage, Corbin-Russwin CL,

Sargent 480 series, ASSA 65-611 & Lori cylinders

can also be used with HW620 tailpiece (supplied)

Interchangeable Standard model accepts 6 & 7 pin cylinders from

Core Models: Best, Falcon, Arrow, KSP, Medeco Keymark & Kaba

Peaks. IC core models prepped for 6 & 7 pin Yale, Medeco,

Sargent, Corbin-Russwin & Schlage are also available

ALL NETWORX LOCKS ARE WEATHER RESISTANT

PLEASE CHECK WITH FACTORY FOR LEAD TIMES ON SPECIAL FINISHES AND IC PREPS

PRODUCT

FINISH

LIST PRICE

PDL6100

Standard key override

26D

10B

$1,864.00

$1,936.00

PDL6200

Standard Key override

w/door position switch

26D

10B

$1,915.00

$1,987.00

PDL6175

Standard Key override

Regal (curved)

26D

10B

$1,890.00

$1,951.00

PDL6100IC*

Interchangeable core

26D

10B

$1,879.00

$1,946.00

PDL6175IC*

Interchangeable core

Regal (curved)

26D

10B

$1,962.00

$2,060.00

PDL6100SK

Mounted PDL6100 demo w/ mounted

sales/demo kit including IME gateway

and router mounted on plexi-glass for

plug and play demonstrations with Alarm

Lock carrying bag.

$2,0000

AL-IME

Ethernet connected gateway w/AC

adapter to plug into standard wall outlet $510.00

AL-IM80211

Wi-Fi gateway to connect to 802.11

network w/AC adapter to plug into

standard wall outlet.

$710.00

Extended sizes:

Standard and SFIC cylinder

preps can be extended for

thicker doors.

$165.00 add on to list for

extended lock.

Extended lock legend:

W54 - 2 1/8"

W57 - 2 1/4"

W60 - 2 3/8"

W64 - 2 1/2"

W70 - 2 3/4"

W76 - 3"

W83 - 3 1/4"

W89 - 3 1/2"

Note: Locks can be adjusted

by +/- 1/8" by adding or

removing spacers.

AL-IMEPOEP

Power Over Ethernet, plus hardwire

gateway interface capability. No AC

Power required.

$610.00

AL-PRE

Prox Card Enroller

$590.00

ALHID1326

Proximity Access Cards 100 Per Box

$505.00

ALHID1336

Proximity, Magnetic Stripe and Photo

ID cards 100 per box

$1,030.00

ALHID1386

Proximity and Photo ID

Card 100 per box

$927.00

ALHID1391

MicroProx Tag 10 per box

$82.00

ALHID1346

Proximity keyfob 10 per box

$118.00

S6196

Networx Replacement Battery Pack

$45.00

AL-IME-USB

USB Gateway

$300.00

AL-NSM

Networx Signal Meter

$296.00

AL-NSG

Networx Signal Generator

$240.00

*Add “C” for Corbin, “M” for Medeco, “R” for Sargent, “Y” for Yale and “S” for Schlage to end of the part number for

specially prepped IC core models. Add $15.00 to the list price shown above. **MUST SPECIFY 7 PIN FOR CORBIN AND

YALE**

AL Training DVD

ALTRAINDVD

Trilogy DL-Windows and Networx

Connectivity software training videos

divided into 4 easy to follow sections

conducted into a classroom style

environment. Training videos cover

basics, getting started, schedules and

times zones, programming Trilogy locks

via a laptop and the DTM along with how

to connect and bring Networx on line.

$0.00 + $15.95 shipping and handling

charge. Please contact customer service at

1-800-ALA-LOCK to place your order via

credit card, or email

sales@alarmlock.com

Networx training options available. See below for details.

Note:

Training and education options available for Networx products:

1. FREE On-Line certification Software and Networx connectivity video

training available at: http://alarmlock.com/trainingvideos-list.asp

2. On site training may be available thru our in field rep agencies on a

quote-by-quote basis. The minimum charge is $500. For a listing of the

reps in your area, please go to our website at:

http://alarmlock.com/contactn.html

Price Book 2017

TRILOGY NETWORX PROXMITY DIGITAL LOCKS

PL6100 SERIES – Prox only cylindrical lock supporting 5,000 PIN user codes (3-6 digits), and/or HID

Proximity cards. 500 scheduled events and 35,000 event audit log.

SPECIFICATIONS:

Door Thickness: Fits 1 5/8” to 1 7/8”. Other thickness,

please consult factory

Backset: 2 3/4” (2 3/8” also available)

Strike: 1 1/8”x 2 3/4” T strike & 1 1/4” x 4 7/8”

ASA strike included

Latchbolt: UL Listed, fire rated 3 hours, 1/2” throw

reversible

Handing: Non-handed

Power: 4 C-cell batteries (included)

Door prep: Standard ANSI A115 Series prep, modified by

adding additional through-bolt holes

Compliances: BHMA Certified Grade 1 heavy duty cylindrical lockset. UL listed

UL Listed 10C Positive Pressure Specification. FCC

Certified . ADA compliant levers

Cylinder: 6 pin solid brass, SC1 keyway, furnished with all

key override locks. Schlage, Corbin-Russwin CL,

Sargent 480 series, ASSA 65-611 & Lori cylinders

can also be used with HW620 tailpiece (supplied)

Interchangable Standard model accepts 6 & 7 pin cylinders from

Core Models: Best, Falcon, Arrow, KSP, Medeco Keymark & Kaba

Peaks. IC core models prepped for 6 & 7 pin Yale, Medeco,

Sargent, Corbin-Russwin & Schlage are also available

ALL NETWORX LOCKS ARE WEATHER RESISTANT

PLEASE CHECK WITH FACTORY FOR LEAD TIMES ON SPECIAL FINISHES AND IC PREPS

PRODUCT

FINISH

LIST PRICE

PL6100

Standard key override

26D

10B

$1,864.00

$1,936.00

PL6175

Standard Key override

Regal (curved)

26D

10B

$1,890.00

$1,951.00

PL6100IC*

Interchangeable core

26D

10B

$1,879.00

$1,946.00

PL6175IC*

Interchangeable core

Regal (curved)

26D

10B

$1,962.00

$2,060.00

AL-IME

Ethernet connected gateway w/AC

adapter to plug into standard wall outlet $510.00

AL-IM80211

Wi-Fi gateway to connect to 802.11

network w/AC adapter to plug into

standard wall outlet.

$710.00

AL-IMEPOEP

Power Over Ethernet, plus hardwire

gateway interface capability. No AC

Power required.

$610.00

AL-PRE

Prox Card Enroller

$590.00

ALHID1326

Proximity Access Cards 100 Per Box

$505.00

ALHID1336

Proximity, Magnetic Stripe and Photo

ID cards 100 per box

$1,030.00

ALHID1386

Proximity and Photo ID

Card 100 per box

$927.00

ALHID1391

MicroProx Tag 10 per box

$82.00

ALHID1346

Proximity keyfob 10 per box

$118.00

S6196

Networx Replacement Battery Pack

$45.00

*Add “C” for Corbin, “M” for Medeco, “R” for Sargent, “Y” for Yale and “S” for Schlage to end of the part number for

specially prepped IC core models. Add $15.00 to the list price shown above. **MUST SPECIFY 7 PIN FOR CORBIN AND

YALE**

Networx training options available. See page 45 for details.

Extended sizes:

Standard and SFIC cylinder

preps can be extended for

thicker doors.

$165.00 add on to list for

extended lock.

Extended lock legend:

W54 - 2 1/8"

W57 - 2 1/4"

W60 - 2 3/8"

W64 - 2 1/2"

W70 - 2 3/4"

W76 - 3"

W83 - 3 1/4"

W89 - 3 1/2"

Note: Locks can be adjusted

by +/- 1/8" by adding or

removing spacers.

Price Book 2017

TRILOGY NETWORX ELECTRONIC DIGITAL MORTISE LOCKS

DL6500 SERIES – Digital mortise lock supporting 5,000 PIN user codes (3-6 digits), 500 scheduled events and 35,000

event audit log.

SPECIFICATIONS:

Door Thickness: Fits 1 3/8” to 1 7/8” (4.46cm).

Backset: 2 3/4” standard

Strike: 1 1/4” x 4 7/8”strike included

Handing: Specify RH or LH when ordering, lock is reversible

In the field

Power: 4 C- cell batteries (included)

Keypad: All metal, 12 button. Basic functions programmed

through keypad.

Door prep: Standard ANSI A115 Mortise prep, modified by

adding additional through-bolt holes

Compliances: Steelcase lock body meets BHMA specifications

For Grade 1 locks. UL listed to the 10C Positive

Pressure Specification. FCC Certified. ADA

compliant levers

Functions: Classroom function feature stainless steel latchbolt

With 3/4” (1.91cm) projection and deadlocking latch.

Cylinder: 1 3/8” (3.5cm) mortise cylinder supplied. Will

Accept 1 3/8” to 1 1/2” (3.5 – 3.82cm) mortise

Cylinder. Classroom function supplied with straight

Cam.

Cams: Cams for other manufacturer’s cylinders are available

See “Mortise Lock accessories” for part numbers &

Manufacturers

ALL DL6500 MORTISE LOCKS ARE WEATHER-RESISTANT

PLEASE CHECK WITH FACTORY ON LEAD TIMES FOR SPECIAL FINISHES

PRODUCT

FINISH

LIST PRICE

DL6500CRR

Straight lever classroom function

Right hand

26D

10B

$1,586.00

$1,658.00

DL6500CRL

Straight lever classroom function

Left Hand

26D

10B

$1,586.00

$1,658.00

DL6575CRR

Regal (curved) lever classroom

Function right hand

26D

10B

$1,601.00

$1,673.00

DL6575CRL

Regal (curved) lever classroom

Function left hand

26D

10B

$1,601.00

$1,673.00

Networx training options available. See page 45 for details.

Price Book 2017

TRILOGY NETWORX ELECTRONIC DIGITAL MORTISE LOCKS (con’t)

AL-IME

Ethernet connected gateway w/AC

adapter to plug into standard wall outlet $510.00

AL-IM80211

Wi-Fi gateway to connect to 802.11

network w/AC adapter to plug into

standard wall outlet.

$710.00

AL-IMEPOEP

Power Over Ethernet, plus hardwire

gateway interface capability. No AC

Power required.

$610.00

AL-IME-USB

USB Gateway

$300.00

AL-NSG

Networx Signal Generator

$240.00

AL-NSM

Networx Signal Meter

$296.00

MORTISE LOCK PARTS

CLASSROOM FUNCTION CAMS

DESCRIPTION

LIST PRICE

HW956-L

Alarm Lock Standard Straight Cam

$5.00

HW956-M

Marks Straight Cam

$5.00

HW956-C

Corbin-Russwin Straight Cam

$5.00

HW956-S

Schlage Straight Cam

$5.00

HW956-A

Arrow Straight Cam

$5.00

HW956-R

Sargent Straight Cam

$5.00

S6175

Replacement lever support spring

$5.00

S6192

Lever and spring upgrade kit

Standard lever –26D, 10B

$54.00

S6193

Lever and spring upgrade kit

Regal lever –26D, 10B

$80.00

HW870CRL

Left Hand Classroom lock body

$171.00

HW875CRR

Right hand Classroom lock body

$171.00

S6196

Networx Replacement Battery Pack

$45.00

ALTRAINDVD

Trilogy DL-Windows and Networx

Connectivity software training videos

divided into 4 easy to follow sections

conducted into a classroom style

environment. Training videos cover

basics, getting started, schedules and

times zones, programming Trilogy locks

via a laptop and the DTM along with how

to connect and bring Networx on line.

$0.00 + $15.95 shipping and handling

charge. Please contact customer service at

1-800-ALA-LOCK to place your order via

credit card, or email

sales@alarmlock.com

Networx training options available. See page 45 for details.

Price Book 2017

TRILOGY NETWORX ELECTRONIC PROXMITY DIGITAL MORTISE LOCKS

PDL6500/PL6500/PDL6600 – Prox and Digital mortise lock supporting 5,000 PIN user codes (3-6 digits) and HID

Proximity cards. 500 scheduled events and 35,000 event audit log.

SPECIFICATIONS:

Door Thickness: Fits 1 3/8” to 1 7/8” (4.46cm).

Backset: 2 3/4” standard

Strike: 1 1/4” x 4 7/8”strike included

Handing: Specify RH or LH when ordering, lock is reversible

In the field

Power: 4 C- cell batteries (included)

Keypad: All metal, 12 button. Basic functions programmed

through keypad.

Door prep: Standard ANSI A115 Mortise prep, modified by

adding additional through-bolt holes

Compliances: Steelcase lock body meets BHMA specifications

For Grade 1 locks. UL listed to the 10C Positive

Pressure Specification. FCC Certified. ADA

compliant levers

Functions: Classroom function feature stainless steel latchbolt

With 3/4” (1.91cm) projection and deadlocking latch.

Cylinder: 1 3/8” (3.5cm) mortise cylinder supplied. Will

Accept 1 3/8” to 1 1/2” (3.5 – 3.82cm) mortise

Cylinder. Classroom function supplied with straight

Cam.

Cams: Cams for other manufacturer’s cylinders are available

See “Mortise Lock accessories” for part numbers &

Manufacturers

ALL PDL6500 MORTISE LOCKS ARE WEATHER-RESISTANT

PLEASE CHECK WITH FACTORY ON LEAD TIMES FOR SPECIAL FINISHES

PRODUCT

FINISH

LIST PRICE

PDL6500CR (L) or (R)

Straight lever classroom function

Specify left or Right Handing

26D

10B

$1,951.00

$2,018.00

PDL6600CR (L) or (R)

Straight lever classroom function

Specify left or Right Handing

w/door position switch

26D

10B

$2,003.00

$2,070.00

PDL6575CRR

Regal (curved) lever classroom

Function right hand

26D

10B

$1,967.00

$2,034.00

PDL6575CRL

Regal (curved) lever classroom

Function left hand

26D

10B

$1,967.00

$2,034.00

PL6500CRR (prox only)

Straight lever classroom function

Right hand

26D

10B

$1,951.00

$2,018.00

PL6500CRL (prox ony)

Straight lever classroom function

Left Hand

26D

10B

$1,951.00

$2,018.00

PL6575CRR (prox only)

Regal (curved) lever classroom

Function right hand

26D

10B

$1,967.00

$2,034.00

PL6575CRL (prox only)

Regal (curved) lever classroom

Function left hand

26D

10B

$1,967.00

$2,034.00

*Note:

PDL6600-

Request to exit

(REX); real time

when integrated

with CIC, Lenel,

Stanley B.A.S.I.S.

When used on

Networx; sound

at door, will

record on audit

trail. Must pull

audit log to view.

Price Book 2017

TRILOGY NETWORX ELECTRONIC DIGITAL MORTISE LOCKS (con’t)

AL-IME

Ethernet connected gateway w/AC

adapter to plug into standard wall outlet $510.00

AL-IM80211

Wi-Fi gateway to connect to 802.11

network w/AC adapter to plug into

standard wall outlet.

$710.00

AL-IMEPOEP

Power Over Ethernet, plus hardwire

gateway interface capability. No AC

Power required.

$610.00

AL-PRE

Prox Card Enroller

$590.00

ALHID1326

Proximity Access Cards 100 Per Box

$505.00

ALHID1336

Proximity, Magnetic Stripe and Photo

ID cards 100 per box

$1,030.00

ALHID1386

Proximity and Photo ID

Card 100 per box

$927.00

ALHID1391

MicroProx Tag 10 per box

$82.00

ALHID1346

Proximity keyfob 10 per box

$118.00

AL-IME-USB

USB Gateway

$300.00

AL-NSG

Networx Signal Generator

$240.00

AL-NSM

Networx Signal Meter

$296.00

MORTISE LOCK PARTS

CLASSROOM FUNCTION CAMS

DESCRIPTION

LIST PRICE

HW956-L

Alarm Lock Standard Straight Cam

$5.00

HW956-M

Marks Straight Cam

$5.00

HW956-C

Corbin-Russwin Straight Cam

$5.00

HW956-S

Schlage Straight Cam

$5.00

HW956-A

Arrow Straight Cam

$5.00

HW956-R

Sargent Straight Cam

$5.00

S6175

Replacement lever support spring

$5.00

S6192

Lever and spring upgrade kit

Standard lever –26D, 10B

$54.00

S6193

Lever and spring upgrade kit

Regal lever –26D, 10B

$80.00

HW870CRL

Left Hand Classroom lock body

$171.00

HW875CRR

Right hand Classroom lock body

$171.00

S6196

Networx Replacement Battery Pack

$45.00

ALTRAINDVD

Trilogy DL-Windows and Networx

Connectivity software training videos

divided into 4 easy to follow sections

conducted into a classroom style

environment. Training videos cover

basics, getting started, schedules and

times zones, programming Trilogy locks

via a laptop and the DTM along with how

to connect and bring Networx on line.

$0.00 + $15.95 shipping and handling

charge. Please contact customer service at

1-800-ALA-LOCK to place your order via

credit card, or email

sales@alarmlock.com

Networx training options available. See page 45 for details.

Price Book 2017

TRILOGY NETWORX iCLASS w/REX & DPS PROXMITY DIGITAL LOCKS

PDL8200 SERIES – Prox and digital cylindrical lock supporting 5,000 PIN user codes (3-6 digits), and a 13.56 MHz

iClass smart card proximity reader. 500 scheduled events and 35,000 event audit log.

SPECIFICATIONS:

Door Thickness: Fits 1 5/8” to 1 7/8”. Other thickness,

please consult factory

Backset: 2 3/4” (2 3/8” also available)

Strike: 1 1/8”x 2 3/4” T strike & 1 1/4” x 4 7/8”

ASA strike included

Latchbolt: UL Listed, fire rated 3 hours, 1/2” throw

reversible

Handing: Non-handed

Power: 4 C-cell batteries (included)

Keypad: All metal, 12 button. Basic functions programmed

through the keypad.

Door prep: Standard ANSI A115 Series prep, modified by

adding additional through-bolt holes

Compliances: BHMA Certified Grade 1 heavy duty cylindrical lockset. UL listed

UL Listed 10C Positive Pressure Specification. FCC

Certified . ADA compliant levers

Cylinder: 6 pin solid brass, SC1 keyway, furnished with all

key override locks. Schlage, Corbin-Russwin CL,

Sargent 480 series, ASSA 65-611 & Lori cylinders

can also be used with HW620 tailpiece (supplied)

Interchangable Standard model accepts 6 & 7 pin cylinders from

Core Models: Best, Falcon, Arrow, KSP, Medeco Keymark & Kaba

Peaks. IC core models prepped for 6 & 7 pin Yale, Medeco,

Sargent, Corbin-Russwin & Schlage are also available

ALL NETWORX LOCKS ARE WEATHER RESISTANT

PLEASE CHECK WITH FACTORY FOR LEAD TIMES ON SPECIAL FINISHES AND IC PREPS

PRODUCT

FINISH

LIST PRICE

PDL8200

Standard key override

26D

10B

$2,018.00

$2,090.00

PDL8275

Standard Key override

Regal (curved)

26D

10B

$2,044.00

$2,106.00

PDL8200IC*

Interchangeable core

26D

10B

$2,034.00

$2,101.00

PDL8275IC*

Interchangeable core Regal (curved)

26D

10B

$2,054.00

$2,116.00

AL-IME

Ethernet connected gateway w/AC

adapter to plug into standard wall outlet

$510.00

AL-IM80211

Wi-Fi gateway to connect to 802.11

network w/AC adapter

$710.00

AL-IMEPOEP

Power Over Ethernet, plus hardwire

gateway interface capability. No AC

Power required.

$610.00

AL-PRE

Prox Card Enroller

$590.00

ALHID1326

Proximity Access Cards 100 Per Box

$505.00

ALHID1336

Proximity, Magnetic Stripe and Photo

ID cards 100 per box

$1,030.00

ALHID1386

Proximity and Photo ID

Card 100 per box

$927.00

ALHID1391

MicroProx Tag 10 per box

$82.00

ALHID1346

Proximity keyfob 10 per box

$118.00

S6196

Networx Replacement Battery Pack

$45.00

AL-IME-USB

USB Gateway

$300.00

AL-NSG

Networx Signal Generator

$240.00

AL-NSM

Networx Signal Meter

$296.00

*Add “C” for Corbin, “M” for Medeco, “R” for Sargent, “Y” for Yale and “S” for Schlage to end of the part number for

specially prepped IC core models. Add $15.00 to the list price shown above. Note**MUST SPECIFY 7 PIN FOR CORBIN

AND YALE**

Request to exit

(REX); real time

when integrated

with CIC, Lenel,

Stanley B.A.S.I.S.

When used on

Networx; sound

at door, will

record on audit

trail. Must pull

audit log to view.

Extended sizes:

Standard and SFIC cylinder

preps can be extended for

thicker doors.

$165.00 add on to list for

extended lock.

Extended lock legend:

W54 - 2 1/8"

W57 - 2 1/4"

W60 - 2 3/8"

W64 - 2 1/2"

W70 - 2 3/4"

W76 - 3"

W83 - 3 1/4"

W89 - 3 1/2"

Note: Locks can be

adjusted by +/- 1/8" by

adding or removing

spacers.

Price Book 2017

TRILOGY NETWORX ELECTRONIC iCLASS PROXMITY DIGITAL MORTISE LOCKS

w/REX & DPS

PDL8600 – iClass Prox and Digital mortise lock supporting 5,000 PIN user codes (3-6 digits) with a 13.56 MHz

iClass smart card proximity reader. 500 scheduled events and 35,000 event audit log.

SPECIFICATIONS:

Door Thickness: Fits 1 3/8” to 1 7/8” (4.46cm).

Backset: 2 3/4” standard

Strike: 1 1/4” x 4 7/8”strike included

Handing: Specify RH or LH when ordering, lock is reversible

In the field

Power: 4 C- cell batteries (included)

Keypad: All metal, 12 button. Basic functions programmed

through keypad.

Door prep: Standard ANSI A115 Mortise prep, modified by

adding additional through-bolt holes

Compliances: Steelcase lock body meets BHMA specifications

For Grade 1 locks. UL listed to the 10C Positive

Pressure Specification. FCC Certified. ADA

compliant levers

Functions: Classroom function feature stainless steel latchbolt

With 3/4” (1.91cm) projection and deadlocking latch.

Cylinder: 1 3/8” (3.5cm) mortise cylinder supplied. Will

Accept 1 3/8” to 1 1/2” (3.5 – 3.82cm) mortise

Cylinder. Classroom function supplied with straight

Cam.

Cams: Cams for other manufacturer’s cylinders are available

See “Mortise Lock accessories” for part numbers &

Manufacturers

ALL PDL8600 MORTISE LOCKS ARE WEATHER-RESISTANT

PLEASE CHECK WITH FACTORY ON LEAD TIMES FOR SPECIAL FINISHES

PRODUCT

FINISH

LIST PRICE

PDL8600CRR

Straight lever classroom function

Right Hand

26D

10B

$2,106.00

$2,173.00

PDL8600CRL

Straight lever classroom function

Left Hand

26D

10B

$2,106.00

$2,173.00

PDL8675CRR

Regal (curved) lever classroom

Function right hand

26D

10B

$2,121.00

$2,188.00

PDL8675CRL

Regal (curved) lever classroom

Function left hand

26D

10B

$2,121.00

$2,188.00

PL8600CRR (prox only)

Straight lever classroom function

Right hand

26D

10B

$2,106.00

$2,173.00

PL8600CRL (prox ony)

Straight lever classroom function

Left Hand

26D

10B

$2,106.00

$2,173.00

PL8675CRR (prox only)

Regal (curved) lever classroom

Function right hand

26D

10B

$2,121.00

$2,188.00

PL8675CRL (prox only)

Regal (curved) lever classroom

Function left hand

26D

10B

$2,121.00

$2,188.00

*Note:

Request to exit

(REX); real time

when integrated

with CIC, Lenel,

Stanley B.A.S.I.S.

When used on

Networx; sound

at door, will

record on audit

trail. Must pull

audit log to view.

Price Book 2017

TRILOGY NETWORX ELECTRONIC DIGITAL MORTISE LOCKS (con’t)

AL-IME

Ethernet connected gateway w/AC

adapter to plug into standard wall outlet $510.00

AL-IM80211

Wi-Fi gateway to connect to 802.11

network w/AC adapter to plug into

standard wall outlet.

$710.00

AL-IMEPOEP

Power Over Ethernet, plus hardwire

gateway interface capability. No AC

Power required.

$610.00

AL-PRE

Prox Card Enroller

$590.00

ALHID1326

Proximity Access Cards 100 Per Box

$505.00

ALHID1336

Proximity, Magnetic Stripe and Photo

ID cards 100 per box

$1,030.00

ALHID1386

Proximity and Photo ID

Card 100 per box

$927.00

ALHID1391

MicroProx Tag 10 per box

$82.00

ALHID1346

Proximity keyfob 10 per box

$118.00

AL-IME-USB

USB Gateway

$300.00

AL-NSG

Networx Signal Generator

$240.00

AL-NSM

Networx Signal Meter

$296.00

MORTISE LOCK PARTS

CLASSROOM FUNCTION CAMS

DESCRIPTION

LIST PRICE

HW956-L

Alarm Lock Standard Straight Cam

$5.00

HW956-M

Marks Straight Cam

$5.00

HW956-C

Corbin-Russwin Straight Cam

$5.00

HW956-S

Schlage Straight Cam

$5.00

HW956-A

Arrow Straight Cam

$5.00

HW956-R

Sargent Straight Cam

$5.00

S6175

Replacement lever support spring

$5.00

S6192

Lever and spring upgrade kit

Standard lever –26D, 10B

$54.00

S6193

Lever and spring upgrade kit

Regal lever –26D, 10B

$80.00

HW870CRL

Left Hand Classroom lock body

$171.00

HW875CRR

Right hand Classroom lock body

$171.00

S6196

Networx Replacement Battery Pack

$45.00

ALTRAINDVD

Trilogy DL-Windows and Networx

Connectivity software training videos

divided into 4 easy to follow sections

conducted into a classroom style

environment. Training videos cover

basics, getting started, schedules and

times zones, programming Trilogy locks

via a laptop and the DTM along with how

to connect and bring Networx on line.

$0.00 + $15.95 shipping and handling

charge. Please contact customer service at

1-800-ALA-LOCK to place your order via

credit card, or email

sales@alarmlock.com

Networx training options available. See page 45 for details.

Price Book 2017

NEW TRILOGY NETWORX ACCESSORIES

AL-IME2

Ethernet connected gateway w/AC

adapter to plug into standard wall outlet.

Version 2 - allow use of expander

$475.00

AL-IM2-80211

Wi-Fi gateway to connect to 802.11

network w/AC adapter to plug into

standard wall outlet. Version 2 - allow

use of expander

$675.00

AL-IME2-POEP

Power Over Ethernet, plus hardwire

gateway interface capability. No AC

Power required. Version 2 - allow use of

expander

$575.00

AL-IME2-EXP

Wireless expander designed to expand

the coverage area of version 2 gateways.

AC power required. Up to 7 expanders

per version 2 gateway

$250.00

AL-IME2-PIE

Plug-in wireless expander designed to

expand the coverage area of version 2

gateways. Plugs into a standard AC

outlet. Up to 7 expanders per version 2

gateway

$250.00

Note: AL-IME2-EXP and AL-IME2-EXP will only work with v2 gateways

Networx training options available. See page 45 for details.

Price Book 2017

TRILOGY NETWORX EXIT TRIM PRODUCTS

Battery operated Trilogy outside trim works with Marks M9900, Von Duprin 99, Corbin ED5000,

Yale 7100, Dorma 9300, Arrow 3800, Sargent 8888, Precision 1100, 2100 & Cal Royal

9800 series panic devices. Available in DL series (keypad) or PDL (prox/keypad)

formats. Features include 5,000 user codes, 500 scheduled events and 35,000 event audit log.

SPECIFICATIONS:

Cylinder: Uses standard rim cylinder to operate key override

function. Will accept 6 or 7 pin interchangeable

core cylinders – see below.

Handing: Non-handed

Power: 4 C-cell batteries (included) mounted on inside

of door.

Keypad: Weather-resistant all metal, 12 button. Basic functions

Programmable through the keypad.

PDL version proximity antenna housing molded of

ultra high strength, impact resistant Lexan®

ALL ET SERIES LOCKS ARE WEATHER-RESISTANT

PLEASE CHECK WITH FACTORY FOR LEAD TIMES ON SPECIAL FINISHES

PRODUCT

DESCRIPTION

LIST PRICE

ETDLN series

26D Finish

$1,426.00

ETDLN series

10B Finish

$1,493.00

ETDLN series w/Regal lever

26D Finish

$1,447.00

ETDLN series w/Regal lever

10B Finish

$1,503.00

ETPDN series

26D Finish

$1,766.00

ETPDN series

10B Finish

$1,828.00

ETPDN series w/Regal lever

26D Finish

$1,781.00

ETPDN series w/Regal lever

10B Finish

$1,843.00

ETPDNSRX w/REX and DPS

ETPDNISRX iClass w/REX and DPS

26D Finish

$1,817.00

$1917.00

ETPLN series

26D Finish

10B Finish

$1,766.00

$1,828.00

ETPLN series w/Regal lever

26D Finish

10B Finish

$1,781.00

$1,843.00

Specify finish on adapter kit

ET- AL Finish = 26D & US10B

Alarm Lock Standard Rim Cylinder

Adapter kit (Schlage C keyway)

$57.00

ET-AR Finish = 26D & US10B

Arrow Standard Rim Cylinder

Adapter kit

$57.00

ET-AS Finish = 26D & US10B

ASSA Standard Rim Cylinder

Adapter kit

$57.00

ET –C Finish = 26D & US10B

Corbin Standard Rim Cylinder

Adapter kit

$57.00

ET –M Finish = 26D & US10B

Medeco Standard Rim Cylinder

Adapter kit

$57.00

ET –R Finish = 26D & US10B

Sargent Standard Rim Cylinder

Adapter kit

$57.00

ET -S Finish = 26D & US10B

Schlage Standard Rim Cylinder

Adapter kit

$57.00

ET -Y Finish = 26D & US10B

Yale Standard Rim Cylinder

Adapter kit

$57.00

ET –ARIC Finish = 26D & 10B

Arrow IC 6 & 7 Pin Rim Cylinder

Adapter kit

$79.00

ET -BIC Finish = 26D & US10B

Best IC 6 & 7 Pin Rim Cylinder

Adapter kit

$79.00

ET -CIC Finish = 26D & US10B

Corbin IC Rim Cylinder

Adapter kit

$79.00

ET –MIC Finish = 26D & US10B

Medeco IC 6 & 7 Pin Rim Cylinder

Adapter kit

$79.00

Price Book 2017

TRILOGY NETWOX EXIT TRIM PRODUCTS (CONT’D)

Product

Description

LIST PRICE

ET -RIC Finish = 26D, 10B

Sargent IC Rim Cylinder

Adapter kit

$79.00

ET -SIC Finish = 26D, 10B

Schlage IC Rim Cylinder

Adapter kit

$79.00

ET –YIC Finish = 26D, 10B

Yale IC 6 Pin Rim Cylinder

Adapter kit

$79.00

AL-IME

Ethernet connected gateway w/AC

adapter to plug into standard wall outlet $510.00

AL-IM80211

Wi-Fi gateway to connect to 802.11

network w/AC adapter to plug into

standard wall outlet.

$710.00

AL-IMEPOEP

Power Over Ethernet, plus hardwire

gateway interface capability.

No AC Power required.

$610.00

AL-PRE

Prox Card Enroller

$590.00

ALHID1326

Proximity Access Cards 100 Per Box

$505.00

ALHID1336

Proximity, Magnetic Stripe and Photo

ID cards 100 per box

$1,030.00

ALHID1386

Proximity and Photo ID

Card 100 per box

$927.00

ALHID1391

MicroProx Tag 10 per box

$82.00

ALHID1346

Proximity keyfob 10 per box

$118.00

S6196

Networx Replacement Battery Pack

$45.00

S6190

Exit Trim Service Kit

$151.00

S6191

Lever and spring upgrade kit

Standard lever –26D, 10B

$61.00

S6193

Lever and spring upgrade kit

Regal lever –26D, 10B

$78.00

NETWORX EXIT TRIM KITS W/MARKS M9900 PANIC BAR

PRODUCT

DESCRIPTION

LIST PRICE

ETDLN-M99K

26D Finish

$1,850.00

ETPDN-M99K

26D Finish

$2,190.00

TRILOGY EXIT TRIM PRODUCTS PARTS

EXTENDED SPINDLES MUST BE PURCHASED SEPARATELY

S6146

Extended Spindle and screws

Extend exit trim to fit 2 –2 ¾” doors

$112.00

S6147

Extended Spindle and screws

Extend exit trim to fit 3 –4” doors

$112.00

S6195

Extended Spindle and screws

Extend exit trim to fit 4 ¼ -5” doors

$112.00

SC544

Extended replacement screws with

adjustable lengths (4 per unit)

$21.00

PLEASE SEE “HOW TO ORDER” CHART ON PAGE 46 TO PROPERLY ORDER YOUR TRILOGY EXIT

TRIM.

IF YOU REQUIRE THE LOCK TO BE PREPPED FOR A THICKER DOOR, YOU MUST ORDER BASED

ON THE SELECTIONS SHOWN. THE BASIC MODEL IS PREPPED FOR A

1 5/8” TO 1 7/8” DOOR.

**** PRECISION 2100 SERIES WILL WORK WITH THE VON DUPRIN 99 PREP. YOU MUST GET A

MOUNTING PLATE PART # 2141208 FROM PRECISION****

Price Book 2017

HOW TO ORDER YOUR TRILOGY NETWORX EXIT LOCK

Below is a “How to Order” guide for the Trilogy Exit Trim products. Please follow this

guide when placing orders to avoid any delay in processing your order.

All units are sold with a generic cylinder adapter installed. When you are using a

specific brand of rim cylinder, you must purchase a Cylinder Adapter Kit from the

chart below.

ETPDNS1G/26DV99

HANDLE

R-Regal

S-Straight

FINISH

26D = satin chrome

10B = duronodic

COMPATABLE PANIC

DEVICES

V99 – VonDuprin 99(P21)

C50 – Corbin ED5000 and

Y71 - Yale 7100

D93 – Dorma 9300

A38 – Arrow 3800

S88 – Old Style Sargent 8800

NS8 – New Style Sargent 8888

P11 -Precision 1100

CR8 – Cal Royal 9800

M99 - Marks 9900

TYPE

PDN Digital w/Prox

PLN Prox only

DLN Keypad only

CYLINDER ADAPTER KITS

You must choose one of the cylinder

adapter kits below if you are using a name

brand cylinder in the lock.

ET - AL - Alarm Lock standard

(Schlage C keyway)

ET – BIC - Best IC 6 & 7 pin

ET – S - Schlage standard rim

ET – SIC - Schlage IC

ET – R - Sargent standard rim

ET – RIC - Sargent IC

ET – Y -Yale standard rim

ET – YIC -Yale IC 6 pin

ET - C - Corbin standard rim

ET – CIC - Corbin IC

ET - M - Medeco standard rim

ET – MIC - Medeco IC 6 & 7 pin

ET – AR - Arrow standard rim

ET – ARIC - Arrow IC 6 & 7 pin

ET – AS - ASSA standard rim

G= generic rim

Cylinder & adapter

kit included in all

locks

Please note that Precision 2100

series will match up to the Von

Duprin 99 series Trilogy. You must

get a mounting plate #2141208 from

Precision.

DOOR

THICKNESS

1=1 ¾” +

1/8”

All units

shipped with

“1” option.

For thicker

door preps,

you must

order

extended

spindle and

screw kit

separately.

Price Book 2017

TRILOGY NETWORX WIRELESS KEYPADS AND NETPANEL

Trilogy Networx Wireless Keypads and Netpanel combine to provide the ideal wireless keypad solution for

use with mag locks, strikes and electrified exit devices in a smart access system with advanced features and

functions, like automatic schedules, event logs and supports for 2000 doors and 5000 existing Prox ID

Cards/Badges.

SPECIFICATIONS:

Networx Keypads NETDK / NETPDK

• Power Requirements: 12VDC supplied by NETWORXPANEL

• Idle Current: 10mA

• Maximum Wire Length: 200 feet (61m)

• Proximity Card Formats Supported: Alarm Lock

• standard 36 bit format or HID standard 26 bit format

(for use with the model NETPDK only)

Networx Panel NETWORXPANEL

• Input Power: 16.5VAC via Class 2 Plug-In 50VATransformer

(supplied model TRF-14)

• Maximum Lock Power Output Current: 1.5A

@12VDC

• Maximum Wiegand Power Output Current:

250mA @ 12VDC

• Maximum Wiegand Red and Green LED Current:

20mA each output

• Maximum Sounder Current: 100mA

• Maximum Keypad Power Output Current:

200mA@ 12VDC

• Primary and Secondary Relays: SPDT Form C,

N/O, N/C 8A @ 30VAC or VDC

• Supplied Backup Battery: Sealed Lead Acid 4AH

• Battery Backup Time: Approximately 2 hours at

full load

ALL NETDK/PDK KEYPADS ARE WEATHER RESISTANT

PRODUCT

FINISH

LIST PRICE

NETDK

Digital wireless keypad only

26D, 10B $309.00

NETPDK

Digital & Prox wireless keypad only

26D, 10B $633.00

NETDKPAK

Digital wireless wall mounted keypad kit,

includes wall mounted reader, control

panel w/door position switch with RX,

remote release, battery backup and plug in

transformer.

26D, 10B $1,050.00

NETPDKPAK

Digital & HID wireless wall mounted

keypad kit, includes wall mounted reader,

control panel w/door position switch with

RX, remote release, battery backup and

plug in transformer.

26D, 10B $1,375.00

Note: In order for NETDK OR

NETPDK to operate you MUST

include a NETWORXPANEL

Price Book 2017

TRILOGY NETWORX WIRELESS KEYPADS AND NETPANEL (con’t)

NETWORXPANEL

NETWORX wireless control panel only,

used with Networx NETDK and

NETPDK readers and approved wiegand

input readers.

$741.00

NETHIDNSPAK

Networx Narrow Stile Pak

HID Narrow Stile Prox point reader,

control panel w/door position switch with

RX, remote release, and battery backup

and plug in transformer.

$957.00

NETHIDNS

Networx Narrow Stile Reader

HID Narrow Stile Prox Point Reader Only $157.00

AL-IME

Ethernet connected gateway w/AC

adapter to plug into standard wall outlet $510.00

AL-IM80211

Wi-Fi gateway to connect to 802.11

network w/AC adapter to plug into

standard wall outlet.

$710.00

AL-IMEPOEP

Power Over Ethernet, plus hardwire

gateway interface capability.

No AC Power required.

$610.00

AL-PRE

Prox Card Enroller

$590.00

ALHID1326

Proximity Access Cards 100 Per Box

$505.00

ALHID1336

Proximity, Magnetic Stripe and Photo

ID cards 100 per box

$1,030.00

ALHID1386

Proximity and Photo ID

Card 100 per box

$927.00

ALHID1391

MicroProx Tag 10 per box

$82.00

ALHID1346

Proximity keyfob 10 per box

$118.00

BT102

Networx Panel Replacement Battery

$55.00

S6187

Replacement ET Networx Radio

$185.00

S6185 (specify finish)

Replacement Inside Housing for

DL/PDL6100 (includes radio)

$288.00

AL-NSG

Networx Signal Generator

$240.00

AL-IME-USB

USB Gateway

$300.00

AL-NSM

Networx Signal Meter

$296.00

ALTRAINDVD

Trilogy DL-Windows and Networx

Connectivity software training videos

divided into 4 easy to follow sections

conducted into a classroom style

environment. Training videos cover

basics, getting started, schedules and

times zones, programming Trilogy locks

via a laptop and the DTM along with how

to connect and bring Networx on line.

$0.00 + $15.95 shipping and handling

charge. Please contact customer service at

1-800-ALA-LOCK to place your order via

credit card, or email

sales@alarmlock.com

Networx training options available. See page 45 for details.

Price Book 2017

TRILOGY & NETWORX REMOTE RELEASE PRODUCTS

PRODUCT

DESCRIPTION

LIST PRICE

RR-TRILOGYKIT

Remote release kit for all Trilogy

Cylindrical models includes the RR-

1BUTTON for desk mount applications

and RR-RECEIVER which is designed to

be installed inside the battery

compartment next to the battery pack of

any cylindrical Trilogy lock. The RR-

RECEIVER connects to the 2 white

remote release wires inside the battery

compartment and to the black and red

battery pack wires to power the receiver.

These kits will retro fit to any existing

cylindrical Trilogy manufactured since

1994.

$221.00

RR-RECEIVER

RR-RECEIVER is designed to be

installed next to the battery pack of any

cylindrical Trilogy lock. The RR-

RECEIVER connects to the 2 white

remote release wires and to the black and

red battery pack wires and will retro fit to

any existing cylindrical Trilogy

manufactured since 1994. You will need

to purchase separately either an RR-

1BUTTON OR 4BKEYFOB to activate

the receiver

$128.00

RR-1BUTTON

Remote release desk mounted button

designed to be used with any existing

Networx lock enrolled with a simple

keypad program. Must update the

firmware of your existing Networx Lock.

Also can be used with an RR-RECEIVER

to any existing Trilogy Cylindrical Lock,

RR-RECEIVER sold separately.

$92.00

RR-4BKEYFOB

Remote release 4 button key fob designed

to be used with any existing Networx lock

enrolled with a simple keypad program.

Must update the firmware of your existing

Networx Lock. Also can be used with an

RR-RECEIVER to any existing Trilogy

Cylindrical Lock, RR-RECEIVER sold

separately.

$103.00

RR-MORTISEKIT

RR-EXITTRIMKIT

Remote release kit for Mortise Locks

Remote release kit for Exit Trim Locks

*Both include RR-1BUTTON and

RECEIVER mounted on a Lexan battery

cover.*

$242.00

Note: The Remote Release Products follow the Networx Discount Structure. Will not work with Narrow Stile series locksets.

Price Book 2017

TRILOGY NETWORX UPGRADE KITS

PRODUCT

DESCRIPTION

LIST PRICE

DL610026DUPGRD

Component kit to upgrade a standard

Trilogy cylindrical model to a DL6100

Networx model. Kit includes a Networx

outside digital keypad housing, inside

housing with radio and a battery pack.

Upgrade kit is designed to replace the

existing and install in place same

components, reusing the existing levers,

cylinder, lock body & strike plate. Used

with a Networx gateway purchased

separately.

$875.00

PDL610026DUPGRD

Component kit to upgrade a standard

Trilogy cylindrical model to a PDL6100

Networx model. Kit includes a Networx

outside HID Prox & digital keypad

housing, inside housing with radio and a

battery pack. Upgrade kit is designed to

replace the existing and install in place

same components, reusing the existing

levers, cylinder, lock body & strike plate.

Used with a Networx gateway purchased

separately.

$1,287.00

DL650026DUPGRD

Component kit to upgrade a standard

Trilogy mortise lock model to a

DL6500CR Networx model. Kit includes

a Networx outside digital keypad housing,

inside housing with radio, inside/outside

levers and a battery pack. Upgrade kit is

designed to replace the existing and install

in place same components, reusing the

existing cylinder, lock body & strike

plate. Used with a Networx gateway

purchased separately.

$1,158.00

PDL650026DUPGRD

Component kit to upgrade a standard

Trilogy mortise lock model to a

PDL6500CR Networx model. Kit

includes a Networx HID Prox & outside

digital keypad housing, inside housing

with radio, inside/outside levers and a

battery pack. Upgrade kit is designed to

replace the existing and install in place

same components, reusing the existing,

cylinder, lock body & strike plate. Used

with a Networx gateway purchased

separately.

$1,493.00

PDL8200/26DUPGD

Component kit to upgrade a standard

Trilogy cylindrical model to a PDL8200

iClass Networx model. Kit includes a

Networx outside iClass Prox & digital

keypad housing, inside housing with radio

and a battery pack. Upgrade kit is

designed to replace the existing and install

in place same components, reusing the

existing levers, cylinder, lock body &

strike plate. Used with a Networx

gateway purchased separately.

$1,437.00

Price Book 2017

ArchiTechTM Series Networx Locks

Ideal access control solution; elegantly blending advanced wireless access control convenience within

any decor, in attractive, infinitely customizable designer locking form, in choice of trims and finishes.

Features:

5000 Users, 500 Scheduled Events & 40,000 Event Audit Trail

Surface-Mount or Mortised - in Electronics and Battery Pack

Lock available in Mortise and Cylindrical versions

Real Time Clock - Uses 4 AA Batteries – 3 to 4-year battery life

Operated via access card, fob, key fob etc

DL-Windows Software for programming

USB Radio Key Programming Method or Via Networx Gateways

Manual Card Enrollment Option for Quick Installation

Wireless programming range: up to 20 ft. from lock

Specifications:

ANSI / BHMA Grade 1 Certified, UL Listed 3 Hours

Includes standard lever rose hardware design

Compatible with all 300+ optional architectural trim / lever or knob designs

Stainless steel latch, 2-3/4” backset

Auto-Reverse lock body tested to 6 million cycles

Lock Body - Self cleaning long life motor

Door closure monitor / electronic deadbolt monitor

Key override standard or high-Security

Optional integrated door position indicator switch

Cylindrical

Standard model ordering. Consult factory for ordering assistance.

PRODUCT

LIST PRICE

N90S2195F26D

$880.00

N90S1195F26D

$880.00

ArchiTech Cylindrical Lever and Lever Prep Options

Options

195

295

395

495

Finish

Add-on

Cylinder Prep Code

Yale Conventional

Yes

No

26D, 10B

$30.00

F7

Sargent Conventional

Yes

No

26D, 10B

$30.00

F8

Corbin Conventional

Yes

No

26D, 10B

$30.00

F9

Corbin 6 Pin IC

Yes

No

26D, 10B

$30.00

F12

Corbin 7 Pin IC

Yes

No

26D, 10B

$30.00

F13

Yale 6 Pin IC

Yes

No

26D, 10B

$30.00

F14

Yale 7 Pin IC

Yes

No

26D, 10B

$30.00

F15

Schlage 6 Pin IC

Yes

No

26D, 10B

$30.00

F19

Sargent IC

Yes

No

26D, 10B

$30.00

F20

Medeco IC (large format)

Yes

No

26D, 10B

$30.00

F21

Note: Please consult factory for availability of other finishes. Round rose place only available with cylindrical

version (3.5” diameter). IC core models: tail piece included, core not included.

Price Book 2017

AtchiTech Cylindrical (con’t)

195: American Lever

295: Crescent Lever

395: Monaco Lever

495: Titan Lever

The standard list price of a standard ArchiTech cylindrical lock is $880.00 (American Lever, SC1 keyway)

add $100 onto list for iClass

add $100 onto list for Bluetooth

add $50 onto list for keying

How To Order for ArchiTech Cylindrical

Price Book 2017

Functions for ArchiTech Mortise Locks

FD (Apartment) - Latch by knob/lever either side except when outside locked by stop-button or projected deadbolt.

Latch deadlocked by auxiliary latch or deadbolt. Deadbolt and latch by key outside. Deadbolt by turn piece inside.

Inside knob/lever retracts latch & deadbolt simultaneously, leaving outside locked.

EW (Storeroom) - Latch by knob/lever inside, key outside. Outside knob/lever always rigid. Auxiliary latch deadlocks

latch. Inside always open.

AD (Automatic deadbolt) - Latch deadlocked by deadbolt automatically when door closes. Deadbolt and latch by key

or credential outside. Inside knob/lever retracts latch & deadbolt simultaneously, leaving outside locked.

ArchiTech Mortise

Standard model ordering. Infinite custom models available for mortise version. Consult factory for ordering assistance.

PRODUCT

LIST PRICE

N95S2RX92FD26D

$1,100.00

N95S1RW86FD26D

$1,100.00

How To Order for ArchiTech Mortise

Price Book 2017

ArchiTech Series –Mortise Lockset Options

1. Insert (N951) or Surface mount (N95S) electronics

2. Oval, square, or mag reader

3. Features: Bluetooth or iClass

4. Function: storeroom (EW), Apartment (FD), or automatic deadbolt (AD)

5. Lever style (knob is also available)

6. Rose plate style

7. If escutcheon plate will be needed (consult factory)

8. Keying needed

9. Finish -currently 26D/32D and 10B is offered. Consult factory for other finishes.

The standard list price of a standard ArchiTech mortise lock is $1,100.00 (American Lever, round rose)

add $100 onto list for iClass

add $100 onto list for Bluetooth

add $50 onto list for keying

add $50 onto list for any other lever design other than American (92)

Lever, knob and rose options. The code would be the number/letter underlined.

Additional notes:

N95S (surface mount electronics, oval, square, and swipe (mag) reader available)

N95I (insert electronics, oval and square reader available)

N95J (insert electronics, Bluetooth, oval and square reader available)

N95T (surface mount electronics, Bluetooth, oval, square and swipe (mag) reader available)

Price Book 2017

ArchiTechTM Series Networx Locks Parts and Accessories

Product

DESCRIPTION

LIST PRICE

AL-IME

Ethernet connected gateway w/AC

adapter to plug into standard wall outlet $510.00

AL-IM80211

Wi-Fi gateway to connect to 802.11

network w/AC adapter to plug into

standard wall outlet.

$710.00

AL-IMEPOEP

Power Over Ethernet, plus hardwire

gateway interface capability. No AC

Power required.

$610.00

AL-IME-USB

USB Gateway

$300.00

AL-NSM

Networx Signal Meter

$296.00

ALHID1326

Proximity Access Cards 100 Per Box

$505.00

ALHID1336

Proximity, Magnetic Stripe and Photo

ID cards 100 per box

$1,030.00

ALHID1386

Proximity and Photo ID

Card 100 per box

$927.00

ALHID1391

MicroProx Tag 10 per box

$82.00

ALHID1346

Proximity keyfob 10 per box

$118.00

ArchiTechTM Series Networx Locks Mounted Samples

Cylindrical

PRODUCT

LIST PRICE

N90S1295SK26D

consult factory

S90S1195SK26D

consult factory

N90S1195SK26D

consult factory

Mortise

PRODUCT

LIST PRICE

N95S1RW86SK26D

consult factory

New! iLock App

Price Book 2017

WEATHER-RESISTANT

ALARMED PANIC LOCKS

Models 250, 260, 700, 710 Battery operated alarmed panic locks. All models

(except 11A) feature deadbolt & deadlatch for extra security.

Selectable 2-minute or constant alarm.

260/710. All models (except 11A) feature a 2-minute auto

re-set on the alarm.

SPECIFICATIONS:

Cover: Die-cast metal

Push Bar: Extruded Aluminum channel and push bar

Handed: All models non-handed except 11A

Installation: Surface mounted for single or double doors

Cylinder: Accepts most standard size rim cylinders for inside

And outside key control (not included)

Power: Uses 1 9v battery (included). Normal battery life 1

Year. Can be powered by AC power by using either

PP100 or AC9.

Lock bolt: 1” throw heavy die cast with reinforced

Steel inserts.

Alarm: Dual piezo siren measured at 95db

PRODUCT

FINISH

LIST PRICE

250WP (PADDLE)

US28

$538.00

700WP (36” BAR)

US28, US312 & Red

$654.00

700X48WP (48” BAR)

US28 & US312

$654.00

710WP (36”BAR)

US28

$677.00

CER-KD CER-12345

Rim Cylinder for Outside & Inside

Key Control Solid Brass Body

Satin Chrome Face

$32.00

730

Single Door Strike for 250,260,700 & 710

US28 & US312

$47.00

732

Double Door Strike for 250,260,700 &710

US28 & US312

$47.00

44

Double Door Holder

Aluminum

$131.00

707

Exterior Door Pull use on 250,260

700 & 710 only

Metallic Silver (MS)

Metallic Bronze (MB) $133.00

711

Exterior Finger Pull

US28 & US312

Use on 250,260,700 & 710 only $32.00

767

Mounting Plate for Aluminum

Glass Door

US28 & US312

Use on 250,260,700 & 710 only

$22.00

PP100

Optional AC Power Supply

Aluminum

$272.00

AC9

Optional AC Power Supply

Aluminum

$77.00

S6173

Replacement WP battery

$37.00

Price Book 2017

ALARMED PANIC DEVICES

Models 250, 260, 700, 710 &11A– Battery operated alarmed panic locks. All models

(except 11A) feature deadbolt & deadlatch for extra security.

Selectable 2-minute or constant alarm.

260/710. All models (except 11A) feature a 2-minute auto

re-set on the alarm.

SPECIFICATIONS:

Cover: Die-cast metal

Push Bar: Extruded Aluminum channel and push bar

Handed: All models non-handed except 11A

Installation: Surface mounted for single or double doors

Cylinder: Accepts most standard size rim cylinders for inside

And outside key control (not included)

Power: Uses 1 9v battery (included). Normal battery life 1

Year. Can be powered by AC power by using either

PP100 or AC9.

Lock bolt: 1” throw heavy die cast with reinforced

Steel inserts.

Alarm: Dual piezo siren measured at 95db

PRODUCT

FINISH

LIST PRICE

250 (PADDLE)

US28

$474.00

260 (PADDLE)

US28

$517.00

700 (36” BAR)

US28, US312 & Red

$573.00

700X48 (48” BAR)

US28 & US312

$613.00

710 (36”BAR)

US28

$613.00

710X48 (48”BAR)

US28

$628.00

11A

Deadbolt only exit lock. Handed order

11A or 11ALH. Use BP6 Battery.

$598.00

ACCESSORIES

CER-KD CER-12345

Rim Cylinder for Outside & Inside

Key Control Solid Brass Body

Satin Chrome Face

$32.00

730

Single Door Strike for 250,260,700 & 710

US28 & US312

$47.00

732

Double Door Strike for 250,260,700 &710

US28 & US312

$47.00

K24A

K28

11A Single door strike

11A Double door strike

$37.00

$42.00

K210A

11A Strike for in-swing doors

$55.00

44

Double Door Holder

Aluminum

$131.00

22

Emergency Exit Pull (250/260/11A)

Aluminum

$92.00

707

Exterior Door Pull use on 250,260

700 & 710 only

Metallic Silver (MS)

Metallic Bronze (MB) $133.00

711

Exterior Finger Pull

US28 & US312

Use on 250,260,700 & 710 only $32.00

767

Mounting Plate for Aluminum

Glass Door

US28 & US312

Use on 250,260,700 & 710 only

$22.00

PP100

Optional AC Power Supply

Aluminum

$272.00

AC9

Optional AC Power Supply

Aluminum

$77.00

9936

9948

Used to mount 11A on 36” glass door

Used to mount 11A on 48” glass door

$94.00

$99.00

261

Current Transfer

$72.00

BP6

Replacement battery for 11A

$37.00

Price Book 2017

DOOR ALARMS

PG10, PG21 & PG30 SERIES – Battery operated surface mounted door alarms. Alarms

magnetically activated. Easy to install. Convenient plug-in

“No cut” jumpers.

SPECIFICATIONS:

Power: PG21, PG30 use 9v battery (supplied). PG10 & LL1use BP6

(supplied). BP6 must be purchased from Alarm Lock.

AC power supply can also be used as a battery back up (see below).

Alarm: Dual piezo siren measured at 95db.

Cylinder: Accepts most 1¼” mortise cylinder used for interior activation

(not supplied) and standard size rim cylinder used for exterior

activation (not supplied).

Installation: Surface mounted for single or double doors.

Cover: Die cast metal.

PRODUCT

DESCRIPTION

LIST PRICE

PG10

Available in aluminum finish uses BP6

Battery replaced only through Alarm Lock

$298.00

LL1

Same as PG10 with strobe light on top.

$309.00

PG21MS PG21MB

Available in metallic silver and metallic

bronze. Uses 9v battery.

$298.00

PG21MSS/PG21MBS

Available in metallic silver and metallic

bronze. Uses 9v battery with yellow

strobe on top for noisy areas

$366.00

PG30MS PG30MB

Available in metallic silver and metallic

bronze. No cylinders required. All exit,

entry and security levels programmed

through keypad. 3 security levels, master,

management and passage. Use 9v battery.

$355.00

PG30KPD

Exterior keypad used with PG30 only.

$205.00

CEM-KD CEM-12345

Standard mortise cylinder for interior

activation. Solid brass body, satin chrome

face

$32.00

CER-KD CER-12345

Standard rim cylinder for exterior

activation. Solid brass body, satin chrome

face.

$32.00

PP100

AC battery back-up complete with

armored cable and housing.

$272.00

AC9

AC battery back-up housing only

$77.00

BP6

Replacement battery for PG10 & LL1

$37.00

Price Book 2017

DELAYED EGRESS PANIC LOCKS

715 Series - Stand alone delayed egress panic lock. 15 second delayed latch,

instant alarm. Instant egress in case of emergency or fire.

Meets NFPA 101 Life Safety Code. Includes monitoring output

for secondary siren , CCTV or remote monitoring. Smoke detector

input.

SPECIFICATIONS:

Cover: Die cast metal

Push bar: Extruded aluminum push bar and channel

Handed: Non-handed

Installation: Surface mounted for single or double doors

Cylinder: Accepts most standard size rim cylinder used for

Inside and outside key control

Power: AC powered with 9v battery back-up for siren. Transformer

And armored cable included

Lock bolt: 1” throw heavy die cast with reinforced steel inserts

Alarm: Dual piezo siren measured at 95db

PRODUCT

DESCRIPTION

LIST PRICE

715X28X88

15 second delayed egress lock. Aluminum

finish with monitoring output. 33” bar.

$1,078.00

715x28x88x48

15 second delayed egress lock. Aluminum

finish with monitoring output. 48” bar

$1,091.00

CER-KD CER-12345

Standard rim cylinder

$32.00

725x28

Single door strike (included with unit)

$55.00

735x28

Double door strike (not included with

unit)

$55.00

SWK-715

Surface wiring kit for wood or glass doors

$94.00

767x28

Metal mounting plate for glass doors

$22.00

277-12

277v transformer to wire 715 from Exit

Sign

$65.00

271

Armored cable

$56.00

ELECTRIC DEADBOLTS

Models 103 & 104 Fail-safe or fail-secure electric deadbolts. Available

In 12v or 24v AC or DC. Perfect for use on narrow stile

Doors. Complete with angle, mortise or flush mount strikes.

Use with standard key or push button switch.

SPECIFICATIONS:

Cover: Molded aluminum

Power : Requires 400 mA for 24v, 800mA for 12v unit

Deadbolt: Powered by a continuous duty solenoid. 5/8” diameter

And 5/8” projection.

PRODUCT

DESCRIPTION

LIST PRICE

103

24v AC or DC. Includes three strikes and

magnets. Fail-safe

$360.00

103x12

12v AC or DC. Includes three strikes and

magnets. Fail-safe $424.00

104RA

24v AC or DC. Includes three strikes and

magnets. Fail-secure

$429.00

104x12

12v AC or DC. Includes three strikes and

magnets. Fail-secure

$474.00

221 / 241

24v Plug-in style transformers

$55.00

222

24v Wire-in style transformer

$55.00

Price Book 2017

REMOTE RELEASE MAGNET

RR-PM1200 SERIES – Stand alone remote operated infra-red mag lock. Allows remote

Lock control by a transmitting keyfob. Infra-red signal is detectable

From interior and exterior sides of the door. Keyfob will operate

From 10 feet on exterior side and 35 feet from interior side.

SPECIFICATIONS:

Magnet: 1200lb 12v DC magnet

Power: Includes 12v AC plug in transformer. A 12v DC power supply

Can be utilized (not included)

Keyfob: Single button, dual LED infra-red transmitting. Up to 100 keyfobs

Can be programmed into a single magnet.

Programming: Each keyfob must be presented to the magnet to enroll keyfob ID into

Software.

PRODUCT

DESCRIPTION

LIST PRICE

RR-PM1200PAK

Includes 1 1200lb remote magnet, one

AL-REMOTE keyfob and one 12v AC

transformer

$642.00

RR-PM1200

1200lb remote magnet

$568.00

AL-REMOTE

Remote keyfob

$66.00

POWER MAGNETS AND REQUEST TO EXIT BUTTONS

PRODUCT

DESCRIPTION

LIST PRICE

PM600BI

600lb magnetic lock field selectable

12/24v DC 9 7/8” x 1 11/16” x 1”

Aluminum finish

$332.00

PM600L

600lb magnetic lock field selectable

12/24v DC 9 7/8” x 1 11/16” x 1”

Aluminum finish L.E.D. indicator

& door bond sensor for remote monitoring

$390.00

PM1200

1200lb magnetic lock field selectable

12/24v DC 9 7/8” x 1 11/16” x 1”

Aluminum finish

$350.00

PM1200SL

1200lb magnetic lock field selectable

12/24v DC 9 7/8” x 1 11/16” x 1”

Aluminum finish L.E.D. indicator

& door bond sensor for remote monitoring

$406.00

PM1200SLBI

1200lb magnetic lock field selectable

12/24v DC 21” x 1 11/16” x 1”

Aluminum finish L.E.D. indicator

& door bond sensor for remote monitoring

for use on double doors

$734.00

PM120040

1200lb magnetic lock field selectable

12/24v DC 9 7/8” x 1 11/16” x 1”

dark bronze finish

$396.00

PM1200SLBI40

1200lb magnetic lock field selectable

12/24v DC 21” x 1 11/16” x 1”

dark bronze finish L.E.D. indicator

& door bond sensor for remote monitoring

for use on double doors

$734.00

PE1

Round red exit button non-illuminate

Standard switch plate

$133.00

PE2

Square green illuminated exit button

Standard switch plate

$133.00

PE2S

Square green illuminated exit button

Narrow switch plate

$131.00

PMA-ANGL1

Angle bracket 1 ½ x 10 ½

$48.00

PMA-ANGL2

Angle bracket adjustable 1 ½ x2 3/8x 10½

$92.00

PMA-ANGL3

Angle bracket adjustable 1 3/8x2 3/8x10½

$92.00

PMA-FILL1

Filler plate 10 ½ x ¾ x 5/8

$38.00

Note: Remote release and Power mag and accessories follow the Trilogy discounts.

PM1200SL40 (dark bronze)

Price Book 2017

POWER MAGNETS AND REQUEST TO EXIT BUTTONS (cont’d)

PRODUCT

DESCRIPTION

LIST PRICE

PMA-FILL2

Filler plate 10 ½ x ¾ x ½

$38.00

PMA-Z1

Z bracket adjustable use with PM600BI

Series

$177.00

PMA-Z2

Z bracket adjustable use with PM1200

series

$289.00

PMA-ARMH1

Armature plate 7 ¼” x 1 ½” x 19/32”

$172.00

PMA-ARMH2

Armature plate 7 ½” x 2 7/16” x 19/32”

$188.00

ALARM LOCK SYSTEMS, INC.

WARRANTY/RETURN POLICY

Alarm Lock Systems Inc. warrants its products to be free from manufacturing

defects in material and workmanship. The length of said warranty is 24 months

on all products from the date of manufacture.

Any customer may get an over-the-counter exchange with the original seller

(distributor) for any Alarm Lock product failing to operate properly.

For those customers who have direct accounts with Alarm Lock, please follow

this procedure to return product for warranty replacement:

1. Email your request to: returns@alarmlock.com

2. In order to receive a return authorization number, you must provide the date

code of the product.

3. The 4-digit date code sticker is the actual expiration date of the warranty.

4. Any out of warranty product returned to the factory will be scrapped and is

not returnable.

5. If said product is found not to be operating properly because of a factory

defect and is within the warranty period, Alarm Lock will issue a product

replacement.

If you experience a problem with any Alarm Lock product, you may contact

Alarm Lock’s Technical Support directly at 1 800 252-5625.

All prices published are suggested list prices in US Dollars. Some specifications are

preliminary and subject to change without prior notice. Not responsible for typographical

errors. Alarm Lock Systems, LLC, is a Division of Napco Security Technologies, Inc.

Notes

Alarm Lock Systems, Inc.

345 Bayview Ave

Amityville, NY 11701

1 800 252-5625

1 631 789-3383

www.alarmlock.com

ALA132A.1

10/17

Alarm Lock Price Book 2017

Alarm Lock Price Book 2017_Alarm_Lock_Price_Book_1 Price Book

Navigation menu

Versions of this User Manual:

Views

Navigation
