Wireless & standalone access control door solutions trusted by more

schools & universities, ofces, retail chains & healthcare providers

TRILOGY T2/ DL2700 STANDALONE DIGITAL PIN CODE LOCKS, CYLINDRICAL, DUAL-SIDED, MORTISE & EXIT DOORS .....2

TRILOGY CLASSROOM LOCKDOWN DL2700LD ................................................................2

TRILOGY AUDIT TRAIL/PC-PROGRAMMABLE PUSHBUTTON LOCKS ................................................3

TRILOGY PROX LOCKS WITH HID PROX ID CARD READERS .......................................................4

TRILOGY DOUBLE-SIDED PIN CODE AND PIN/PROX STANDALONE LOCKS ..........................................5

TRILOGY STANDALONE LOCKS FOR PRIVACY AND SPECIAL APPLICATIONS .........................................6

TRILOGY HIGH SECURITY STANDALONE MORTISE LOCKS ........................................................7

TRILOGY EXIT ADDS AUDIT TRAIL AND AUTO LOCK/UNLOCK TO PANIC EXITS ......................................8

TRILOGY NARROW STILE TRIM FOR ALL GLASS/ALUMINUM DOORS AND PANIC EXIT DOORS ......................9-10

MATCHING TRILOGY DIGITAL PIN & PROX ACCESS 12/24V KEYPADS WITH AUDIT TRAIL .............................10

TRILOGY AUDIT TRAIL AND PROGRAMMING ACCESSORIES, FINISHES AND ORDERING INFORMATION .................11

WIRELESS NETWORX KEYPADS & NETPANEL ..............................................................12-13

TRILOGY NETWORX WIRELESS 802.11/ETHERNET LOCK ACCESS SYSTEMS .....................................14-17

ILOCK APP ..............................................................................................17

ARCHITECH DESIGNER WIRELESS ACCESS CONTROL LOCKING PLATFORM .....................................18-21

SIRENLOCK EXIT ALARMS: WATERPROOF, INTERIOR, AND DELAYED EGRESS .......................................22

REMOTE RELEASE MAG LOCKS, POWERMAGS AND RTES ......................................................23

ADVANCED DOOR ALARMS ................................................................................24

ESSENTIAL ADD-ONS AND EXTRAS .........................................................................25

TRILOGY FAMILY OF ACCESS PRODUCTS CHART ............................................................26-27

K-12 AND CAMPUS LOCDOWN SOLUTIONS ..................................................................28

ABOUT US, RETAIL LOCKSMITHS PROFIT CENTER PROGRAM AND TRAINING .......................................29

table of contents

Trilogy: The leading

electronic access locks

Product Club 12:55 PM 79%

Trilogy®

:ofﬁce

pharmacy

hospital retail airport schools

Keyless access locks trusted by more leading

retailers, ﬁrms, hospitals, schools & airports

Restrooms/Classrooms

DL/PDL4100, DL/PDL4500 DL2700LD

Trilogy Privacy/Lock Down Pushbutton –

for restrooms, on-call rooms, ﬁle rooms,

ﬁtting rooms, classrooms

page 6

High Security PIN/Prox ID

DL2700CR/DB, P/DL3500 Trilogy high

security mortise locks and keyless gate

locks with and without prox

page 7

Glass/Aluminum Doors

DL1200, DL1300, PDL1300 Trilogy

Narrow Stile Pushbutton aluminum

door trim latch locks for PIN or Prox

ID card access

page 9

Access Keypads

DK3000 & PDK3000 Trilogy

Matching Weatherproof PIN/

Prox. ID Access Keypads with

audit trail

page 10

Exit Doors

ETDL2700, ETDL, ETPDL TrilogyExit retroﬁts

existing exit bars and saves manpower on

guard tours

page 8

Glass & Standard Pushbar Doors

DL1200, DL/PDL1300ET TrilogyExit keyfree

convenience and greater security for panic exit

devices on standard & narrow stile

aluminum frame glass doors

page 9 & 10

Retroﬁt Any Knobset

DL2700/LD Trilogy® T2 Grade 1

standalone digital cylindrical keyless

door lock, ﬁngertip programmable

- page 2

Audit Trail

DL2800/DL3000, DL3200

Trilogy audit trail cylindrical

security locks with PC

Programming & Schedules

page 3

Vandalism Protection

PL3000 Prox-only vandal

proof lock

page 4

Airport Jetway Use

and more

DL/PDL5300, DL5200 Dual

sided PIN/prox lock with

audit trail

page 5

Communicate Wirelessly

Trilogy Networx® communicate wirelessly via

Ethernet or 802.11 now including Networx

Keypads & Controller plus Exit Trim

DL/PDL6100, DL/PDL6500, NET-DKPAK, NET-

PDKPAK, NETWORXPANEL, ETDLN/ETPDN

page 12-17

ID Card Access

PDL3000 Trilogy HID®

Reader/Enroller Prox

Lock with audit trail

page 4

+ New iClass/One-Card

Model PDL8200

page 16

ArchiTech Series Locks

Designer Wireless Access Control Systems

page 18-21

Product Club 12:55 PM 79%

Trilogy T2: Electronic cylindrical digital locks

More Trilogy T2 Models: Field-proven electronic standalone pushbutton locks available in

cylindrical, mortise, dual sided and exit trim models to retroﬁt with panic exit bars or narrow

stile aluminum/glass doors’ latch locks

Trilogys feature:

• In an hour, add dependable wireless access control, one door at a time—easily retrot standard knobsets

• Support 100 to 2000 PIN codes (3-6 digits); some with built-in HID prox readers for use with access ID cards/fobs

• Multi-level user codes & one-time service codes. Free passage, group- or total lock-out modes, too

• All are ngertip programmable at vandalproof all-metal keypad

• PC programmable models also feature printable audit trail, auto-lock/unlock scheduling saving guard/manpower costs

• Longer-life battery operation – 200,000 cycles typical (cylindrical models use 5AA off-the-shelf batteries); low battery alert

• Key override, standard core (supplied) or interchangeable core prep

• Durable BHMA Grade 1 cylindrical Lockset; Non-handed. Curved Regal handle option.

• Programmable relay functions

• Weatherproof models -31˚ to +151˚F (-35˚ to +66˚C)

Trilogy® T2 standalone digital

cylindrical lock : #1 in its class

DL2700 Series

More powerful & More T2 models

• More codes: up to 100 3-6 digit codes: 1 master, 10

managers, 90 basic users, 3 one time service codes

• Uses 5AA batteries; 5 years battery life or 200,000 cycles, typ.

• For outdoors, specify WP weatherproof models -31˚ to

+151˚F (-35˚ to +66˚C)

• DL5200 Dual-sided option, see pg 5

Trilogy® T2 Lockdown: Ideal for School

& Campus Security

DL2700LD Series

Classroom Lockdown Indicator & Keyfob-Activation

• Lockdown up to four locks with one compact remote keyfob,

supplied (up to 50 RR-4KEYFOB keyfobs supported per lock)

• Bright visual lockdown indicator bar on inner door; Outside

small indicator light ashes and/or beeps when in lockdown

• Up to 100 different user codes (3-6 digits)

• Uses 5AA batteries; 3 to 4 years battery life or

100,000 cycles, typ.

• Grade 1 Durability; Weather-Resistant, Standard 2” Remote Keyfob controls up to 4 locks and

works up to 75’ away (RR-4KEYFOB)

DL2700CR/DB Mortise T2 Trilogy

standalone digital lock for high security

locking. Choice of classroom or deadbolt

functions, see also pg 7

ETDL2700 T2 Trilogy Exit trim for

use with exit device, see also pg 8

DL1200 Narrow stile T2 Trilogy

for glass or exit doors, see also

pg 9, 10

Curved regal

handle option

ADA-compliant

levers

Lever sets feature clutch

mechanism ensuring

longer life and complies

with ADA specs providing

barrier-free access to the

disabled.

Trilogy T3: Choice of audit trail pushbutton locks

Trilogy economical audit trail lock

DL2800

Cylindrical Lock

• 1000 event audit trail log, time-stamped by day, date, time and user

• 150 scheduled automatic lock/unlock events, etc.

• 200 user codes: Master, manager, supervisor and basic users. Also one-

time service code (3-6 digits)

• Weatherproof -31˚ to +151˚F (-35˚ to +66˚C)

• 5AA Battery operated; 80,000 cycles, typical

T3 advanced digital lock with audit trail

DL3200 Series

High Capacity Audit Trail Lock

Enhanced version of the original DL3000

• 2000 user codes (3-6 digits)

• Multilevel security - Master; manager; supervisor; basic users

• Program at keypad or with PC-and/or data-transfer module

• 40,000 event audit trail logs with time-/date-stamp of access

by user; create PC reports or at hand-held wireless printer

• 500 scheduled lock/unlock events

• Quick passage mode (without being in program mode)

• Weatherproof -31˚ to +151˚F (-35˚ to +66˚C)

• 5AA Battery operated; 80,000 cycles, typical

DL3000

Original Audit Trail Trilogy, similar to above

• 300 multilevel user codes; 1600 event log

• 150 scheduled lock/unlock events

• For outdoors, specify WP weatherproof models -31˚ to

+151˚F (-35˚ to +66˚C)

Remote

Release

Add Remote-Release

convenience to any

cylindrical Trilogy

installation with keyfobs

or desk-mounted button

• Easy & Cost Effective

• Retrots Cylindrical Trilogy

Locks dating all the way back

to 2000 (with a serviceable

battery pack) :RR-TrilogyKit

• For Networx Locks, too! Just

purchase either the keyfob

(shown above left) or desk-

mount release button (pg 8)

Ideal for receptionists.

Trilogy cylindrical locks retroﬁt

standard knobsets simply, in about

an hour

Turn Standalone Trilogy Locks into Wireless Networked Networx Locks with Field Upgrade Kits for Standalone PIN or PIN/Prox

Cylindrical or Mortise Models. P/DL6100 and P/DL6500 upgrade kits available. iClass available – PDL8200 upgrade kit.

Prox ID card support: With Trilogy durability

Trilogy prox lock with audit trail

PDL3000

PIN/Prox Cylindrical

• Use the same ID cards as hardwired access systems & install in an

hour

• Save all the downtime and 1/2 the cost of hardwired systems

• Provide access for up to 2000 users, with prox ID-cards or 3 to 6 digit

codes including: Master, manager, supervisor and basic user. Users

are individually programmed to use a card only, code only, or, for the

highest security, both card and code.

• Built-in HID Prox reader for entry with HID125KZ prox ID cards and

keyfob credentials

• Grade 1 BHMA Certied durability and rugged clutch mechanism

ensure long dependable life

• Weatherproof performance for indoor and outdoor applications,

wide operating temperature range of -31°F to +151°F (-35°C to

+66°C)

• Electronic master key system with access customized to each

user’s hours - Give each user access to common areas and/or their

individual area(s) and do so dened by the actual times they are

permitted entry there.

• Tap and Add batch ID card enrollment mode at lock or download

from a PC

• 40,000 event audit trail; 500 scheduled events

• PC programming/reporting

• Quick passage mode

• 5AA battery operation; 60,000 cycles, typical

For iClass Prox Locks with 13.56 MHz support for one-card

solutions - also see PDL8200 pg 16

PDL8200 – Model also logs mechanical key override use

Trilogy prox only defeats vandals

PL3000

Prox Only Cylindrical

• Keypad-less version of above for ultimate vandal-proofness in

harshest environments

• Accepts HID prox cards and keyfobs for access

• Easy Tap & Add batch ID card enrollment mode allows many cards

to be quickly added without PC –also- downloadable from PC or

enroller tool

• 40,000 event audit trail log, 500 scheduled events

• PC programming/reporting

OUTSIDE OUTSIDE

2 1/4

in.

2 9/16 in.

2 3/8 in.

1 11/16 in.

3 1/4 in.

2 1/8 in.

3 1/4 in.

INSIDE INSIDE

1 3/4 in.

4 3/4 in.

8 in. 8 1/4

in.

OUTSIDE OUTSIDE

2 1/4

in.

2 9/16 in.

2 3/8 in.

1 11/16 in.

3 1/4 in.

2 1/8 in.

3 1/4 in.

INSIDE INSIDE

1 3/4 in.

4 3/4 in.

8 in. 8 1/4

in.

Double Sided: Access on both sides of the door

DL5200

• Incorporates all of the important features of DL2700 (T2) into a double-sided lock

• Easy to add, delete, change users at the keypad

• Programming user codes on one side of the door works both sides, cutting your

time & labor in half

• Ideal for community pool gates, courtyard gates, airport jetway doors,

interrogation rooms, psych wards

• Comes with LED & audible entry indicators

• 100 user codes (3-6 digit codes)

• Standard prep & IC models available

• Weatherproof -31˚ to 151˚F (-35˚ to +66˚C)

• 5AA batteries operated, 80,000 cycles, typical

DL5300/PDL5300

• 2000 user codes (3-6 digits) and/or accepts HID prox cards and keyfobs (prox

model PDL5300)

• Direction-specic access assignable per user programmable access for each user

for one or both sides of the door

• Up to 40,000 event audit trail log, time-stamped by day, date, time and user (PC

or data module reportable)

• 500 scheduled events, including 4 quick schedules

• Data port for programming lock and querying audit trail is on primary side of

door, along with functioning mechanical key override

• 4 programming levels, 4 user groups

• 5AA battery operated; 60,000 cycles, typical

PDL5300 model

features 2 built-

in HID prox card

ID readers on

both sides.

Note: Key

override

operates latch

only from

primary side.

A favorite solution for airport jetways!

Trilogy 4100/4500: Privacy or lock down features

Standard

Cylindrical Model

with privacy button (center,

top) featured

Standalone Trilogy® locks with privacy/lock

down pushbutton on inner door (mortise &

cylindrical pin or pin/prox models)

DL4100 and Prox PDL4100

Similar to the DL3200 features plus:

• Interior LED on the inside housing indicates when the privacy session

is active

• Rest assured knowing that you are safe within the room, while locking

out unauthorized users.

• 2000 PIN or PIN/Prox user codes; 500 scheduled events; 40,000 audit

trail

• Privacy Pushbutton – Push button on inside door to temporarily lock-

out keypad codes (programmable option)

• Occupied and multi-status LED indicator, ashes when privacy session

is active

• Self-stick instructional signage, supplied (bilingual)

• Keypad or PC programming/reporting

• Right- or left-hand, classroom or deadbolt function models, only with

4500 Series

• 1-3/8” mortise cylinder & ASA strike, matching function supplied, only

with 4500 Series

• 5AA battery-pak operated; 60,000 cycles, typical

• 3 Architectural nishes (US3 polished brass, 26D satin chrome,

10B duronodic)

• Weatherproof -31˚ to +151˚F (-35˚ to +66˚C)

Mortise DL4500, Prox Mortise PDL4500 and Prox Networx

PDLN4100/4500 also available

Flashing LED

inside and outside

indicates the room

is occupied or

locked

Also available in

mortise model

School Lock-Down Applications:

remain safely inside until the coast is clear

– no need to open the door

At the first sign of trouble

outside, with just one but-

ton and virtually no special

training or knowledge

required, faculty and/or

students of all ages can

simply press Trilogy’s inside

‘privacy’ button to lock

out unauthorized access,

instantly locking-down a

classroom or area, all while

remaining safely within

the room. There is no need to open the door, nor use a special key,

since the fingertip-activated button is located on the inside door, i.e.,

the same side as classroom occupants. Trilogy’s lockdown function

automatically disables free passage through the door and even locks

out general PIN user codes, since routine Trilogy keypad access

is temporarily suspended whenever the privacy button is activated

(even when the lock is time-scheduled for free-access mode). Instant

lock-down override code, will reactivate the pushbutton keypad and

enable authorized teachers/staff, outside the classroom.

For Keyfob Lockdown Trilogy, see DL2700LD pg. 2

For Global Lockdown from Server or any lock, see Trilogy Networx

pg 12-17

Trilogy Mortise: High security digital locks

DL2700CR/DB T2 Series Mortise Locks

• Trilogy T2 Keyless Access Lock for mortise door prep

• High security mortise locking

• Fingertip access and programming exibility

• Weatherproof for use inside or out

• 1-3/8” mortise cylinder included

• Choice of classroom or deadbolt functions & nishes

• Long battery life

DL3500 Series Mortise Locks

• 300 User codes: Master, manager, supervisor & basic users

• Fingertip or Windows PC-programmable

• Real time clock enables up to 150 scheduled events and holiday

schedules

• 40,000 Event audit trail provides a printed time/date- stamped log

of all electronic activity

• Long-life battery pak for 80,000 cycles, typical and low-battery alert

• Choose either classroom or deadbolt versions and left or right hand-

ing (If reverse hand is required, lock is eld reversible.)

• 1 3/8” (3.5 cm) mortise cylinder supplied card enrollment mode al-

lows many cards to be quickly added without PC –also– download-

able from PC or prox enroller tool

• 40,000 event audit trail log

• 150 scheduled events, e.g., lock or unlock

• PC programming/reporting

• Quick passage mode (without being in program mode)

• Program data transferred to lock via AL-PCI2 or AL-DTMIII

• 5AA battery-pak operated; 75,000 cycles, typical

• 3 Architectural nishes (US3 polished brass, 26D satin chrome,

10B duronodic)

• Weatherproof -31˚ to +151˚F (-35˚ to +66˚C)

PDL3500 Series

PDL3500 Series mortise lock with built in HID prox reader, similar

to DL3500 Series, but with:

• 2000 user codes (3-6 digits) and/or HID prox cards/fobs

• 500 scheduled events, e.g., lock or unlock

• Multilevel security - Master; manager; supervisor; basic users

• Easy Tap & Add batch prox ID card enrollment mode allows many

cards to be quickly added without PC –also– downloadable from PC

or prox enroller tool

• PC programming/reporting

• Quick passage mode (without being in program mode)

• Program data transferred to lock via AL-PCI2 or AL-DTMIII

• 5AA battery-pak operated; 75,000 cycles, typical

• 3 Architectural nishes (US3 polished brass, 26D satin chrome,

10B duronodic)

• Weatherproof -31˚ to +151˚F (-35˚ to +66˚C)

Trilogy® high security mortise locks with and without prox ID readers

Turn Standalone Trilogy Locks into Wireless Networked

Networx Locks with Field Upgrade Kits for Standalone PIN

or PIN/Prox Cylindrical or Mortise Models. P/DL6100 and P/

DL6500 upgrade kits available. iClass available – PDL8200

upgrade kit.

Trilogy Exit: Add audit trail to panic exits

Add Trilogy convenience, programming, flexibility and audit trail to exit

devices from most major manufacturers

Add Trilogy convenience, programming, ﬂexibility and audit trail to exit devices from

most major manufacturers

Trilogy Exit – ETDL, ETPDL

• Clutch Mechanism insures long life and durability

• Fingertip and/or Windows Programmable

• 2000 User Codes: Master, manager, supervisor and users

• Real Time Clock for up to 40,000 Event Time/Date-Stamped Audit Trail

• Up to 500 Lock/Unlock Schedules (with Time Zone Support)

• Rugged 12-Button Metal Keypad

• Non-Handed; Fully Field Reversible

• Adaptable to most major manufacturers of standard RIM and IC RIM Cylinders

• Supports most push in style panic exit devices including: Von Duprin 99, Marks USA M9900, Corbin ED5000 & Yale, Dorma 9300, Arrow

3800, Hager 4500, Old Style Sargent, New Style Sargent, Precision 1100, Cal Royal 9800, etc. (Consult factory for full list)

• Battery operated; uses 5 AA batteries

Also available in prox model for added convenience and security. Includes all of the features above plus:

• Accepts most HID Proximity cards and keyfobs

• Users are individually programmed to use a card only, code only, or for highest security – both card and code

• Prox card data can be added to software by uploading from lock, by using AL-PRE or entering directly from computer using DL-WINDOWS

software.

Also available in prox only model (ETPL)

ETDL2700 T2 Exit Trim

• As above but with T2 Trilogy features

OUTSIDE:

Rugged, ﬁeld-proven Trilogy

digital lock.

INSIDE:

Existing exit device –

Most major brands

supported

Trilogy Narrow Stile: Glass door retrot

Pushbutton aluminum door trim retroﬁt

glass doors with latch locks

DL1200, DL1300

• Add keyless convenience to mechanical latch locks from Trilogy’s all-

metal, vandal-resistant 12-button keypad and/or automatic timed-

scheduled locking/unlocking and audit trail with 1300 Series

• Aluminum door retrot outside trim for Adams Rite® 1850, 1950,

4710, 4070*, 4730, 4900 Series and MS1850S* and MS1950S* Series

latch locks

• DL1200 supports 100 3-5 digit PIN user codes, ngertip

programmable

• DL1300 (and Prox PDL1300, right) support 2000 users, PC

programming/reporting and features 40,000 event audit trail by user

and 500 event schedule/real time clock (e.g. lock/unlock by time)

• Weatherproof -31˚ to +151˚F (-35˚ to +66˚C)

• Long-life, battery-operated for 100,000 and 80,000 cycles

respectively, typical on 2 lithium 3V batteries, supplied; low battery

alert

• Compact styling 14-3/8”H x 1-5/8”D x 1-3/4”W

• Key override mortise cylinder, 1-1/4” supplied. (Supports 1-1/8”,

1-1/4” and 1-3/8”). Also interchangeable cores supported (Corbin/

Russwin, Yale, Schlage, Medeco.)

• Backsets 31/32”,1-1/8” and 1-1/2”; Stile thickness 1-3/4”

• Non-handed; fully eld-reversible

• Two nishes US26D satin & 10B Durondic

Narrow stile prox ID card

PC-programmable model with audit trail

PDL1300

Includes all of the 1300 Series features, at left:

• Built-in HID prox reader, supports up to 2000 users with HID Prox ID

cards or/fobs or 3-6 digit PIN codes

• Easy Tap & Add batch prox ID card enrollment mode allows many

cards to be quickly added without PC –also– downloadable from PC

or prox enroller tool

• 40,000 event time-/date-

stamped audit trail by user

• 500 event schedule/real time

clock (e.g. lock/unlock by time)

• Long-life, battery-operated

for 65,000 cycles, typical on 2

lithium 3V batteries, supplied;

low battery alert

Now get convenient

keyless PIN code or

Prox access anywhere

there’s a glass door.

Trilogy Narrow Stile lever models

(left and right) designed to work

with Adams Rite® latch series;

Thumbturn models (shown at

center) support swing & hook bolt

products .

Plus, PC-programmable 1300 Series

models provide audit trail log of

door users.

Ideal for universities, hospitals,

laboratories, airports, ofce buildings & retailers

*The 4070, MS1850S, and MS1950S only work with knob (50) or thumb turn (25) models.

Narrow Stile Exit: For aluminum door retrots

Trilogy® Weatherproof Keypads:

12/24VAC/DC digital access keypads with

PC programming & audit trail

Trilogy DK3000 (shown,left)

• 2000 PIN user codes, multilevel security

• Ideal for use with 12V or 24V (AC or DC) electric door strikes, mag

locks or Alarm Lock Remote Release Mag Lock Kit (adjacent page)

• Wall mount or single gang box

• 2 High-Current Rated 8A Relays for entry, alarm zone shunting or

lock release by real-time schedule

• Vandal-resistant, all metal 12-button keypad

• Keypad or PC programmable

• 40,000 Event audit trail report/print to PC or hand held printer or

DTMIII Data Module

• Timed Egress Input – Selectable door open times 3, 10 or 15

seconds

• 500 Scheduled events & real time clock

• Tamper supervised (reportable to alarm system)

• Remote release feature; request-to-exit input

• Weatherproof -31˚ to 151˚F (-35˚ to +66˚C)

Digital access keypad with prox reader

Trilogy PDK3000 (shown, right)

Same features as DK3000 above, plus

• Built-in HID proximity reader

• Accepts up to 2000 PIN codes and/or HID cards and keyfobs

For Wireless Keypad Solution, Ideal for use with Mags,

Strikes and Electried Exit Devices - Please also see

Networx Keypad & NetPanel pgs 12-13

Alarm Lock’s Trilogy narrow stile exit device

trim locks

DL1200ET Trilogy T2-platform

• Adds vandal-resistant keyless access to panic exit doors

• Protects storefronts and managed properties 24/7

• 100 users supported (3-5 digit codes)

• Designed with all-metal, vandal-resistant 12-button keypads

• Supports 3-6 digit PIN codes and multilevel user hierarchy

• Easily installs on most aluminum glass doors

• Works with Marks USA M8800, Jackson, Dor-O-Matic, Von Duprin

(Von 33 LH (RHR) only), Dorma, Arrow, DCI & Corbin panic devices

(Dor-O-Matic, Jackson and Dorma devices require thumb-turn or

knob Note: Must purchase separate TP assembly – See price book).

DL/PDL1300ET

As above but also equipped with ID card prox reader (PDL version),

PC programming and automatic lock/unlock scheduling and time

zone support

• 2000 Users (PIN code or prox ID on PDL model)

• Two nishes 2 Architectural nishes (26D satin chrome,10B

duronodic)

Exit Devices TP Kits (Must order TP Kit Separately)

• Marks USA M8800

• Jackson 1095

• Dor-O-Matic - 2090

• Von Duprin 22

• Von Duprin 33 LH (RHR) only

• Dorma - 5300

• Arrow - 51200/51250

• DCI - 1200/1300

• Corbin - ED8200

Note - Certain manufactures’ exit devices such as Jackson, Dor-O-Matic, DCI and

others require a greater degree of rotation so a knob (50) or Thumb Turn (25) is required

to retract and project the latch. In this function, the latch will remain retracted until

a PIN or Prox Card is represented to project the latch creating a hold back feature.

please contact your local Alarm Lock representative for additional information.

Ideal for elevators and gate applications

Trilogy Ordering Information

Cylindrical Trilogys

Model/Series:

DL27 = DL2700 Series

DL28 = DL2800 Series

DL30 = DL3000 Series

DL32 = DL3200 Series

DL52 = DL5300 Series

PDL30 = PDL3000 Series

PDL53 = PDL5300 Series

Networx Wireless:

DL6100 PIN Series;

PDL6100, 8200 PIN/Prox

Trim:

00 = Lever

75 = Regal Curved Lever

Exterior/Interior Use:

For Exterior use of DL2700 & DL3000

only, order WP for weatherproof use.

All other models are weatherproof as

standard.

Cylinder:

IC = Standard Interchangeable

Core Prep for Best, Falcon, Arrow,

KSP

(Note: No “IC” indicates standard K.O.

cylinder.)

Finish:

/3 = US3 Polished Brass

/26D = US26D Satin Chrome

/10B = Duronodic (Special Order)

Special Order IC Prep:

-Y = Yale

-M = Medeco

-R = Sargent

-C = Corbin/Russwin

-S = Schlage

DL 27 00 WP IC /26D -Y

Model Type

PDL – Prox/PIN

DL – Digital PIN

Trilogy Series

12 – 2700 Series

13 – 3000 Series

Trim

00 = Lever

25 = Turnpiece

50 = Knob

75 = Regal lever

Finish

/26D Satin Chrome

/10B Duronodic

/MS Metallic Silver

/MB Metallic Bronze

Mechanical Dead Latch

1 – Supports Adams Rite:

4710, 4730, 4900 Series

2 – Supports Adams Rite:

4070, MS1850S,

MS1850S-050, MS1950,

MS1950-050

Trilogy Narrow Stile

DL1200/26D1

Type:

PDL = Digital with Prox

PL = Prox Only

DL = No Prox

N = (suffix) Networx Wireless

Door Thickness:

1 = 1

3/4” + 1/8”

2 = 2” to 2 3/4”

3 = 3” to 4”

Handle:

R = Regal

S = Straight

Finish:

/3 = US3 Polished Brass

/26D = US26D Satin Chrome

/10B = Duronodic (Special Order)

OEM Trim

M99 = Marks USA M9900

V99 = Von Duprin 99

C50 = Corbin ED5000 & Yale

D93 = Dorma 9300

A38 = Arrow 3800

S88 = Old Style Sargent

N58 = New Style Sargent

P11 = Precision 1100

CR8 = Cal Royal 9800

Trilogy Exit

ETPDL- 1 R/ 26D V99

Mortise Trilogys

Finish:

/3 = US3 Polished Brass

/26D = US26D Satin Chrome

/10B = Duronodic (Special Order)

European Model Suffix

Not Used For U.S. Models

*Note: Standard Lever for U.S.

Models is Straight Lever.

Standard Lever for European

Models is Curved Tubular Lever

DL 35 00 DB R /26D EX

Model & Series:

DL35 = Trilogy T3 Mortise Series

Networx Wireless:

DL6500 PIN; PDL6500 PIN/Prox

Trim:

00 = Standard Lever

75 = Regal Curved Lever

(U.S. Option Only)

Lock Body:

DB = Dead Bolt

CR = Class Room (U.S. Only)

Handing:

Your Door- Order -

Left Handed L

Right Handed R

Left Hand Reverse Bevel R

Right Hand Reverse Bevel L (Note: Trim is non-handed. Lock body is field reversible.)

DL-WINDOWS Trilogy Software

Free Alarm Lock Trilogy Microsoft Windows-based software

application, for programming, entering users, receiving

audit trail from lock or used with ALDTMs to transfer data.

Version.4.177 or higher, supports Trilogy Networx, Wireless

Keypads, Locks and ArchiTech series, and Trilogy standalone

locks, with single database. Downloadable free at www.alarmlock.com. For

enterprise network software options, and real-time performance, see pg.15

Trilogy audit trail and programming

AL-IR1 Infrared Printer

Prints the event log and user code with hand-held

convenience.

AL-DTMIII Data Transfer Module

Module used to transfer program data from the PC

to the lock and receive Audit Trail from the lock. Can

transfer program data for up to 200 locks.

AL-PRE2 Dual Function Reader/Enroller for Smart Cards or

Prox IDs

Just tap the Smart Card or Prox ID device to the unit’s faceplate to

automatically enroll in DL-WINDOWS software database. (USB)

AL-PCI2U Lock / PC Interface (shown)

Interface cable interconnects lock and PC for data

transfer with USB interface cable. (AL-PCI also includes

DL-WINDOWS CD). Also available AL-PCI2 w/o USB.

Remote Release Kit

RR-TRILOGYKIT

Remote release kit for all Trilogy Cylindrical models includes

the RR-1BUTTON for desk mount applications and

RR-RECEIVER for installation inside the battery compartment

of any cylindrical Trilogy lock (Simply connects to the 2 white

remote release wires inside. Retrots any existing cylindrical Trilogy

manufactured since 2000.

Also available for Mortise and Exit Trim models, RR-MORTISEKIT

and RR-EXITTRIMKIT, respectively. (Note: individual kit components,

in blue, are also separately available.) Retrots units with serviceable

battery pack (2000 and up year built)

Choice of three standard Trilogy ﬁnishes

US3

Polished Brass

US10B

Duronodic

US26D

Satin Chrome

75 Regal Curved Lever 25 Turnpiece

50 Knob available on

DL1250/1350

U.S. Handing options

00 Straight Lever

Wireless Networx Keypad Solution: Trilogy

Trilogy Networx Wireless Keypads

and NetPanel combine to provide

the ideal wireless keypad solution

for use with mag locks, strikes

and electriﬁed exit devices in a

smart access system with advanced

features & functions, like automatic

schedules, event logs and support

for 2000 doors and 5000 existing

Prox. ID Cards/Badges. The

Networx Panel communicates via a

Networx Gateway networked to any

Windows-based PC. Networx keypads

seamlessly share one common

database hosted on free Alarm Lock

free software (along with Networx

locks and standalone Trilogys too.).

This cost effective system is very

scalable, and up to 63 NetPanels,

controlling up to 126 Networx

Keypads (or Wiegand devices), can

communicate to as little as one

Alarm Lock Gateway. Two starter

kits are available, NET-DKPAK &

NET-PDKPAK, each with a controller

and keypad (Digital PIN or Prox,

respectively). Additional keypads

and NetPanels may also be

purchased individually.

Advantages

• Wireless Keypad solution - networked

versions of popular Trilogy DK/PDK3000

Keypads

• Ideal for use with strikes, mags,

electried exit devices

• 5000 users with 3-6 digit PINs or HID® ID

cards

• Save manpower - Bidirectional 128 AES

encrypted network communications

updates, users, time-schedules and audit

trail queries — without ever going to the

keypads

Versatile for indoors and outside; ideal

for education, healthcare, government,

airports, courts, municipalities, & retail

• Familiar Trilogy operation,

programming, software and ruggedness

• NetPanel Controller supports 2

Networx keypads and/or 2 Wiegand

output readers /devices

• Key features: Global lockdown and

passage from keypad or PC, schedules,

35K event log, door position status

indicator, request-to-exit, door ajar/kick-in,

remote release options.

Features

• Networx NetPanel supports up to

2 Networx wireless keypads and/

or Wiegand-output readers and

communicates wirelessly via Ethernet or

802.11B/G for a comprehensive wireless

networked door access control system,

eliminating door-to-door programming

and audit trail retrieval and providing all

standalone Trilogy lock functionality plus

new network-wide global emergency

lockdown/unlock commands

• Networx Keypads support up to 5000

users with 3-6 digit numeric PIN codes and

NETPDK-Series also support prox ID card

users (virtually all HID format proximity

technology ID cards, fobs, credentials.)

• System-wide free-passage enable or

disable, can be activated from the keypad

or the Networx PC

• On demand, in seconds, wirelessly change

keypad users, schedules, features or retrieve

35,000 events from any networked PC.

• Ideal for use with mag locks, strikes and

electried exit /panic devices (EL-devices/

electried latch retraction devices.)

• Free Alarm Lock DL-WINDOWS software

doesn’t require a dedicated computer

or a special computer network or costly

server software licenses, it simply runs

as a secure Microsoft Windows-based

application, on any computer system (as

basic as a desktop or laptop PC), a wired

or wireless router, and a gateway module

or on a an internal LAN with static IP

address (recommended).

• Up to 2000 NetPanels can be used

per account to further expand system

capabilities.

NET-DKPAK & NET-PDKPAK

EASY NETWORX WIRELESS KEYPAD SYSTEM

Router

Existing

Corporate

Ethernet

Network

NETPDK GATEWAY

Wire up to

2 Wiegand

Devices

NETDK and/or NETPDK keypads (and/or Wiegand devices) wired to a dedicated NETWORXPANEL control panel

NETDK

EGND AC IN WOA WO W1 PWR GND RED

LED

WIEGAND INPUT

GRN

LED

SNDR

DRIVE

(+) (–) TX

(YEL)

(GRN)

N/O N/C COM

AUX RELAY KYPD PWR

LOCK

PWR

(+)

COM N/C N/O

MAIN RELAY

LOCK

PWR

(–)

DOOR

POSITION

CONTACT

REMOTE

RELEASE

INPUT

T1 T2 T3 T4 T5 T6 T7 T8 T9 T10 T11 T12 T13 T14 T15 T16 T17 T18 T19 T20 T21 T22 T23 T24 T25 T26 T27

N/O

Momentary

Switch

MAG LOCK

(OR

FAIL-SAFE

ELECTRIC

DOOR

STRIKE)

N/C

Emergency Exit

Switch (or Fire

Panel Relay)

Jumper

Wire

Door

Position

Contact

ELECTRIC DOOR

STRIKE

(FAIL-SECURE)

NOT FOR FIRE EXITS

Red (+ DC)

White (Data 1)

Green (Data 0)

Black (- Ground)

Green (Data 0)

Brown (Red LED)

Orange (Green LED)

Yellow (Beeper)

Red

Black

Yellow

Green

TSD*

Wired (RJ-45)

or Wireless 802.11

Wired (RJ-45)

or Wireless 802.11

NETWORX NETPANEL

SECONDARY

NETPDK

PRIMARY

NETDK

PRIMARY

WIEGAND**

SECONDARY

WIEGAND**

The system is capable of controlling two doors using up to two of any combination of NETDK or NETPDK keypads, PLUS up to two Wiegand devices. Two auxiliary

Form-C relays are available for up to two of any combination of magnetic locks and/or electric door strikes.

Networx Keypads & NetPanel

NETPANEL

dedicated

access panel

Includes

• Circuit board with onboard ash

memory;12V power supply, with

transformer and rechargeable backup

battery

• Inputs supporting two of any combination

of NETDK or NETPDK keypads, PLUS up

to two Wiegand devices

• Special “Two Door Mode” allows two

keypads and/or two Wiegand devices to

separately control two doors

• Two Form-C relays

• Inputs for door position contact to

indicate the status of the door, open or

closed;

• Inputs for a remote release button or

sensor

• Onboard bi-directional Networx radio

• Wiegand interface, red LED, green LED,

and sounder.

Wiegand Device Support

• The NetPanel’s Wiegand inputs

currently support all Wiegand output

devices, that support the Data 0/Data

1 communications protocol and are

compatible with HID Prox credentials

(including Wiegand keypads and

combination units.)

Examples of Wiegand Devices

Supported:

• HID Classic Swipe Wiegand Reader Model

310 (36-bit card format compatible).

• HID ProxPro with Keypad Model 5355

• HES model RF5910 Hybrid Electric Strike

with HID125k reader

*** Other formats may be accommodated for special orders.

Ask you Alarm Lock Representative.

Ordering Info.

NETPDKPAK26D Complete 2-Door Net-

Panel System with 1 PDK wireless keypad

with built in HID Prox Reader, 26D nish.

**** Includes 12 volt power supply, onboard

bidirectional radio, 4Ah/12V rechargeable

backup battery and plug in AC transformer.

(System requires use of one of the AL-IM

Series Gateway Modules, separately pur-

chased.)

NETDKPAK26D Complete 2-Door Net-

Panel System with 1 DK wireless keypad,

26D nish. **** Includes 12 volt power supply,

onboard bidirectional radio, 4Ah/12V

rechargeable backup battery and plug in

AC transformer. (System requires use of

one of the AL-IM Series Gateway Modules,

separately purchased.)

NETPDK26D PDK Wireless Keypad with

built in HID Prox Reader only, 26D nish. ****

NETDK26D DK Wireless keypad only, 26D

nish.

****Note: Special keypad nishes may also be available – ask

your Alarm Lock Rep.

NETHIDNSPAK Networx Narrowstile Prox

point reader, control panel w/door position

switch with RX, remote release and battery

backup plus plug-in transformer.

NETWORXPANEL Access Control Panel

to be used with other approved Wiegand

output readers. Includes 12 volt power sup-

ply, onboard bidirectional radio, 4Ah/12V

rechargeable backup battery and plug in AC

transformer.

Networx Series Accessories

AL-NSG Gateway Simulator

A portable battery powered

Networx Gateway simulation

device that generates

continuous Gateway radio

signals to a Networx Signal

Meter.

AL-NSM Site Survey Tool for Networx

Gateways

Performs a site survey test of

the premises to nd optimum

location of Networx gateways

and locks. Also helps to

determine the number of

gateways required to cover

the signal area of the Networx

locks you plan to install.

Router

Existing

Corporate

Ethernet

Network

NETPDK GATEWAY

Wire up to

2 Wiegand

Devices

NETDK and/or NETPDK keypads (and/or Wiegand devices) wired to a dedicated NETWORXPANEL control panel

NETDK

EGND AC IN WOA WO W1 PWR GND RED

LED

WIEGAND INPUT

GRN

LED

SNDR

DRIVE

(+) (–) TX

(YEL)

(GRN)

N/O N/C COM

AUX RELAY KYPD PWR

LOCK

PWR

(+)

COM N/C N/O

MAIN RELAY

LOCK

PWR

(–)

DOOR

POSITION

CONTACT

REMOTE

RELEASE

INPUT

T1 T2 T3 T4 T5 T6 T7 T8 T9 T10 T11 T12 T13 T14 T15 T16 T17 T18 T19 T20 T21 T22 T23 T24 T25 T26 T27

N/O

Momentary

Switch

MAG LOCK

(OR

FAIL-SAFE

ELECTRIC

DOOR

STRIKE)

N/C

Emergency Exit

Switch (or Fire

Panel Relay)

Jumper

Wire

Door

Position

Contact

ELECTRIC DOOR

STRIKE

(FAIL-SECURE)

NOT FOR FIRE EXITS

Red (+ DC)

White (Data 1)

Green (Data 0)

Black (- Ground)

Green (Data 0)

Brown (Red LED)

Orange (Green LED)

Yellow (Beeper)

Red

Black

Yellow

Green

TSD*

Wired (RJ-45)

or Wireless 802.11

Wired (RJ-45)

or Wireless 802.11

NETWORX NETPANEL

SECONDARY

NETPDK

PRIMARY

NETDK

PRIMARY

WIEGAND**

SECONDARY

WIEGAND**

The system is capable of controlling two doors using up to two of any combination of NETDK or NETPDK keypads, PLUS up to two Wiegand devices. Two auxiliary

Form-C relays are available for up to two of any combination of magnetic locks and/or electric door strikes.

NETWORX KEYPADS use with Mag Lock, Electric Strike or

Wiegand Devices – Control up to 2 Doors

Wireless Networx Locks: Easily-networked access locks

Networked Wireless Access Control that’s ½ the cost of

a hardwired system, now for every door & application

Based on Trilogy®, the #1 electronic standalone access locks, Networx™

Locking Products are networked to save staff labor, eliminating door-to-

door programming and audit trail retrieval, by communicating wirelessly

via Ethernet or 802.11B/G, all while providing the ultra dependability,

functionality & long battery life, original Trilogys are known for. The

expanded Networx line, for every type of door, combines to provide a

quick, easy, economical access system for up to 2000 doors and 5000

users, with advanced features & functions, e.g., automatic schedules, event

logs. But, with no wires to run, and no access panels or power supplies

to buy or install, it can be a great time and budget saver for buildings,

campuses or office suites. At its simplest, it’s one Grade 1 wireless lock per

door, installed in about an hour, all communicating to a single Gateway

(your choice of gateways controls up to 63 locks), networked to any non-

dedicated Windows-based PC. In addition to Wireless Trilogy Networx’

unsurpassed battery-life, exceeding 5 years, they feature new network-

wide capabilities, executed from any lock or the network’s PC, including

emergency priority global lockdown deployed in seconds, and you can

activate (non-priority) system-wide free-passage or locking modes from the

PC. For existing Trilogy installations, original standalone and new Trilogy

Networx locks can seamlessly share one common database hosted on free

Alarm Lock DL-WINDOWS software. For real-time access applications,

Networx Locks offer enterprise network integration with several leading

platforms.

• Trilogy Networx Locks communicate wirelessly via Ethernet or

802.11B/G for a comprehensive wireless networked door access

control system, eliminating door-to-door programming and audit trail

retrieval and providing all standalone Trilogy lock functionality plus

new network-wide and emergency lockdown features

• Unsurpassed 5-year+ battery life, typical, (Automatic battery status

reports at the PC; visual and audible low-battery status indicators at

lock(s).

• Trilogy Networx and gateway modules have an integral transceiver

for highly-efcient 900MHz bidirectional communications, for

longer range and less interference than with more common 2.4GHz

spread spectrum devices. Alarm Lock devices require NO wiring; NO

splitters or repeaters; NO hardwiring to the host/server; NO extra

power supplies; and NO access controller/panels.

• In 10 seconds, activate emergency global lockdown from the

Networx PC, any Networx lock or Keyfob (RR-4BKEYFOB). (This

priority emergency command is lightning-fast system-wide and

supercedes all scheduled programs or updates, etc. However, if

desired, locks may be selectively programmed to be excluded

from emergency global lockdown function, i.e., they will ignore the

command. )

• System-wide free-passage enable or disable, can likewise be

activated from the Networx PC

• Locks easily retrot standard or any Networx locks and support

up to 5000 users with 3-6 digit numeric PIN codes and PDL-Series

also support prox ID card users (virtually all HID™ format proximity

technology ID cards, fobs, credentials.)

• On demand, in seconds, wirelessly change users, schedules, lock

features or retrieve audit trails of up to 40,000 events/lock from

any networked PC. (Note: Transaction processing time is dependent

upon system capacity, the more locks/gateways and the more data to

be up/downloaded, the longer the time.)

Wireless Networx Locks: Easily-networked access locks

• Unattended programming updates or

event log retrievals can be scheduled to

run automatically, saving manpower and

productive time.

• Seamless upgrade path for original

Trilogy users: Intermix with existing Trilogy

standalone lock installations and share

one database and familiar Trilogy lock

and software functions: Trilogy Wireless

Networx Locks seamlessly integrate in an

existing Alarm Lock Trilogy standalone door

access system and share the same single

DL-WINDOWS database (requires v4.1.x

or higher). Existing Trilogy users can easily

add one wireless Networx Lock, or as many

as two thousand, to an existing system

seamlessly with no downtime.

• Secure 128bit AES PC encryption and

proprietary RF-link lock communication

encryption protects the system from

interference or tampering (WEP or WPA

compatible with wireless modem).

• Remote System Management:

VPN-connection /remote capability

for accessing the Networx System and

controlling up to all 2000 locks, with all

the security and peace-of-mind of your IT

network. (No special modems required.)

• Wireless locks are fully keypad

programmable and can be up and

functioning even before their wireless

network is congured, so IT departments

don’t have to coordinate with physical

security departments or locksmiths

• Free Alarm Lock DL-WINDOWS software

doesn’t require a dedicated computer or

a special computer network or costly server

software licenses, it simply runs as a secure

Microsoft Windows-based application, on

any computer system (as basic as a desktop

or laptop PC), a wired or wireless router, and

a gateway module or on an internal LAN with

static IP address (recommended).

(v4.1.x or higher).

• Minimizing hardware & installation costs,

a single gateway module can interface

between the PC network and up to 63

Networx locks , with a clear eld range

of up to 500 feet and 150 feet in buildings.

At its maximum, a Trilogy Networx system

can comprise up to 50 gateways for the

networking of up to 2000 locks or access

controlled doors. New Gen 2 Gateways &

Expanders for easiest networking

(see pg 17 )

• Wall- or ceiling-mountable, compact

gateway modules are available in

wireless/hardwired and wired-only

versions (with Power Over Ethernet (POE)

option). The hybrid model connects using

either 802.11, Ethernet cable or 100Base-

TX (using RJ45 Jack); the wired versions

use an RJ-45 Ethernet cable. Networx

communications support both wired

Ethernet 10BaseT and wireless 802.11.

• For the fastest most reliable networked

system, in discovery setup mode, the system

will locate and DL-WINDOWS will display

each lock’s signal strength at each installed

gateway, so you can select it and optimize

reliable communications and eliminate

guesswork.

• Lock programming, user- and usage-data

are stored locally at the battery-powered

lock for uninterrupted door access usage in

a power outage or server ofine situation.

Enterprise Networks, Real-Time

Performance

• Networx locks can be used as wireless, single-

door controllers in real time too

• Use with Continental Access®, CA4K®, Lenel

OnGuard® Integrated Access Control & Video

Security or Software House Connect Partner®

Program Platforms ‡‡

Trilogy Networx Lock Specications:

• Weatherproof locks for indoor/outdoor use

with wide operating temperature range (-31 to

151˚ degrees F).

• Cylindrical models boast industrial strength

BHMA Grade 1 durability and all models

feature vandal-resistant all-metal keypad for

PIN codes.

• PDL versions, HID Prox. Reader.

• ADA-compliant leversets.

• Easy-to-install modied ANSI A115 Series

door prep; easily and neatly retrot standard

cylindrical knobsets and mechanical standalone

locks, in under an hour. Non-handed

• 3 hour UL re-rated deadlatch.

• Supports 1-5/8 to 1-7/8” door thickness; 2-3/4”

backset (2-3/8” available.)

• Manual key override standard; most IC cores

also supported on interchangeable core

models.

• Wide choice of 3 Architectural nishes (US3

polished brass, 26D satin chrome,10B

duronodic) and IC core preps (6-7pin).

Network Interface

INTERFACE: Ethernet 10Base-T or 100Base-TX (using

RJ45 Jack)

PROTOCOLS: TCP/IP, UDP/IP, DHCP 802.11 Wireless

Specications

WIRELESS STANDARDS: º 802.11b; 802.11g

FREQUENCY RANGE: 2.412 - 2.484 GHz

OUTPUT POWER: 14 dBm + 1.5 dBm/-1.0 dBm

MAXIMUM RECEIVE LEVEL: -10dBm (with PER < 8%)

DATA RATES WITH AUTOMATIC FALLBACK: 54Mbps

- 1Mbps

RANGE: Up to 328 feet indoors

MODULATION TECHNIQUES: OFDM, DSSS, CCK,

DQPSK, DBPSK, 64 QAM, 16 QAM

INTERFACE: Wireless 802.11b, 802.11g and 10/100

Ethernet

PROTOCOLS: TCP/IP, UDP/IP, DHCP

SECURITY

• IEEE 802.11 - PSK with AES Encryption 128-bit

Encryption

• 128-bit AES Rijndael encryption

AL Radio Link

• 900 MHz GFSK, 50 channels, 10mW power output

VOLTAGE: 5 - 6 volts AC/DC

OPERATING TEMPERATURE: -20˚ to 60˚C (-4˚ to 140˚F)

STORAGE: -40˚ to 85˚C (-40˚ to 185˚F)

AVERAGE POWER CONSUMPTION:

• 1300 mW (WLAN mode; maximum data rate)

• 300 mW (WLAN mode; idle)

• 750 mW (Ethernet Mode)

PEAK SUPPLY CURRENT: 650 mA

INPUT VOLTAGE: 5 - 6 volts AC/DC

OPERATING TEMPERATURE: -31 to 151˚ degrees F

STORAGE TEMPERATURE: -40˚ to 85˚C (-40˚ to 185˚F)

‡‡ Important: For enterprise integration consult

technical documentation to match proper AL hardware

(Gateways, Expanders,etc.) with enterprise software

Versions supported.

Up to 2000 locks and a PC

communicate wirelessly through

bidirectional Gateways – eliminating

the need for door-to-door

programming and audit trail

retrieval.

In seconds, global lockdown can be

implemented from any Trilogy lock

or the DL-WINDOWS computer.

Trilogy Networx: Wireless networked access for every application

Add Networx Trilogy convenience, programming, exibility,

audit trail and wireless connectivity to panic exit devices

from most major manufacturers

More Networx Models & Options:

PDL6100 Cylindrical Trilogy Networx PIN/Prox. wireless access

control lock with built in HID proximity ID card reader

PDLN4100 As above, with privacy button on inner door

DL6100 As above PDL6100, with full-metal digital keypad only

PDL6200 Cylindrical Trilogy Networx PIN/Prox. wireless access

control lock with built in HID proximity ID card reader and Door

Position Switch/Request to Exit feature

PDL8200 As above, with HID iClass support

PDL6500 Mortise Trilogy Networx PIN/Prox. wireless access

control lock with built in HID proximity ID card reader

PDLN4500 As above but with privacy function via thumb turn on

inner door (deadbolt only)

DL6500 As above PDL6500, with full-metal digital keypad only

PDL6600 Mortise Trilogy Networx PIN/Prox. wireless access

control lock with built in HID proximity ID card reader and Door

Position Switch/Request to Exit feature

PDL8600 As above, with HID iClass support

PDL6300 Cylindrical Trilogy Networx double-sided PIN/Prox.

wireless access control lock with built in HID proximity ID

card reader

PDL1300NW Networx narrow stile wireless access prox lock trim

with built in HID proximity ID card reader

DL1300NW As above, with full-metal digital keypad only

PDL1300NWET Networx narrow stile exit trim with built in HID

proximity ID card reader

DL1300NWET As above, with full-metal digital keypad only

ETPDN Trilogy Networx wireless access lock trim with built-in HID

proximity ID card reader

ETDLN As above, with full-metal digital keypad only

ETPDN-RX Trilogy Networx wireless access lock trim with built-in

HID proximity ID card reader with Request to Exit feature

ETPDNI-RX As above, with HID iClass support

NETWXSTARTER Trilogy Networx Wireless Access Control

Starter Kit, contains 1 each PDL610026D, ALIME-2 Gateway,

DL-WINDOWS and 30 HID cards

For a list of compatible exit trims, see page 8; for compatible wireless keypads see page 10

Trilogy Networx: Gen.2 Gateways & Expanders‡‡

AL-IME2 Gen. 2 Gateway

The Trilogy Networx AL Generation

Gateway, interfaces Networx locks

with a PC network via a hardwire

Ethernet connection. It is very similar

in function to the original hardwired

Networx Gateway Modules, but is enhanced with additional

extended potential range, supporting up to seven (7) Expanders

(model AL-IME2-EXP Expanders). Each Expander can extend the

AL-IME2 Gateway’s coverage area by approximately 100 feet.

Also both Gen. 2 Gateways and matching Expanders have a new

modern styling, and three LED indicators, blending into any décor.

AL-IM2-80211

Gen. 2 802.11 Gateway

Similar to model above, but this

802.11 Gateway Module includes a

bi-directional radio, and interfaces

Networx locks with a PC network

with hardwire Ethernet and wireless

802.11. It is very similar in function to

the original 802.11 Networx Gateway

Modules, but is enhanced with

additional extended potential range,

supporting up to seven (7) Expanders

(model AL-IME2-EXP Expanders).

Each Expander can extend the AL-IM2-80211 Gateway’s coverage

area by approximately 100 feet.

AL-IME2-POE Gen. 2 Gateway

The Trilogy Networx AL-IME2-POE

(Power Over Ethernet) Hardwired

Gateway interfaces Networx locks

with a PC network with hardwire

Power-Over-Ethernet. It is very similar

in function to the original hardwired

Networx Gateway Modules, but

is enhanced with alternative power, and additional extended

potential range, supporting up to seven (7) Expanders (model AL-

IME2-EXP Expanders).

AL-IME2-EXP Expander

Trilogy® Networx™ Expander

extends the coverage area of a Gen

2 Series Gateways to Trilogy Networx

Locks within a PC network, allowing

greater distances for the placement

of up to a maximum rated capacity

of 63 Networx locks per Version 2

Gateway.

AL-IME2-PIE Plug-in Expander

The Trilogy® Networx™ Plug-In Expander

extends the coverage area of a Generation 2

Series AL-IME2 Gateway to Trilogy Networx

Locks within a PC network, allowing greater

900mHz distances for the placement of up

to a maximum rated capacity of 63 networx

locks per Version 2 Gateway.

Verizon 12:55 PM 79%

Introducing iLock®, the easy

smartphone mobile solution for

unlocking your ArchiTech™ Series

Designer Access Control Locks from

any smart device without the need

to carry cumbersome ID cards or

keys. Password protected access is

secure through the use of Bluetooth

LE™ and proprietary encryption.

Additionally, an optional feature can

be utilized, requiring a password for

each unlock request.

The Key is Your Smartphone &

More Secure Technology

Any Smart Device can be the

Access Key: Much more than

an ID card displayed on your

smartphone, for your security,

ArchiTech & its iLock App are

wirelessly linked together, each

supplying its portion of stored

encrypted data to provide secure

access without a key, fuss or worry,

ensuring user identities. A unique

combination of convenience

and cloneproof peace of mind,

the ArchiTech platform uses

universally-compatible Bluetooth

LE technology, so they can use any

smart device to unlock ArchiTech on

your door(s); and do so from afar, at

a comfortable, customizable range

of up to 30 feet away. For even

greater security users can add an

optional passcode, entered on their

phone App. Coming soon: emailable

digital eKeys for guests or service

temporary access, too.

iLock App is available from both iTunes and the Google Play Store

iLock® App: Unlocks ArchiTech™ Bluetooth® Series Door Locks in seconds!

Networx ArchiTech: Designer Wireless Access Control Platform

MORTISED

NETWORX

CONTROL UNIT

SURFACE-MOUNTED

NETWORX

CONTROL UNIT

DOOR

CONTACT

SENSOR

SURFACE-MOUNTED

NETWORX

CONTROL UNIT

DOOR

CONTACT

SENSOR

SURFACE-MOUNTED

NETWORX

CONTROL UNIT

DOOR

CONTACT

SENSOR

(rea r)

(front)

(outside)

(inside)

PROXIMITY

READER

(OVAL AND

RECTANGULAR)

PROXIMITY

READER

(OVAL AND

RECTANGULAR)

PROXIMITY

READER

(OVAL AND

RECTANGULAR)

PROXIMITY

READER

(OVAL AND

RECTANGULAR)

DOOR CONTACT

MAGNET

(TWO TYPES)

DOOR CONTACT

MAGNET

(TWO TYPES)

DOOR CONTACT

MAGNET

(TWO TYPES)

DOOR CONTACT

MAGNET

(TWO TYPES)

• All Applications and Doors - Cylindrical and

Mortise models for wood and metal doors, for new

and existing applications, with wireless surface

mount or mortised-in electronics and

batteries.

• Customize To Match Any Aesthetic Look, For

Every Décor - Over 300 locks, levers, roses and

ﬁnishes to choose from, durable ANSI/BHMA Grade

1 hardware over 300 locks, levers, roses and ﬁnishes

• Future-Proof Multi-Technology Access ID

Credentials Replace Cumbersome Keys – HID®

Prox, Mag Stripe, Smart Cards, PIV, keyfobs and

remote buttons

• Emergency Lock-Down option via lock, button,

keyfob or server (where networked). (Global Unlock

via server too.)

• Proven, Low Maintenance, Wireless Installation

And Unsurpassed Battery-Life with Advanced

Power-Saver circuit, with years of use in even high-

trafﬁc areas, using off-the-shelf AA batteries.

• Flexible System Programming Locally using a

USB Gateway or remotely across a wireless network

(using free Alarm Lock DL-WINDOWS Windows-

based software) or integrated on an enterprise class

IT environment, in realtime, using LENEL

• Networking Choices – Choose 802.11 or Ethernet

network, with wireless encrypted bi-directional

gateways, in which many locks communicate to a

single gateway, expander, or use a wireless RF USB

Gateway equivalent. For entry door applications and

the like, used in conjunction with strikes and mags,

use with Networx NetPanels. Or, use as a single-

door control, in real time, as part of the IT-Network

environment, with Continental Access CA4K®, Lenel

OnGuard® Integrated Access Control & Video

Security or Software House Connected Partner

Program® Platforms.‡

Performance Overview

ArchiTech Series Networx Locks are an ideal access control solution; elegantly blending

advanced wireless access control convenience within any décor, in an attractive, inﬁ-

nitely customizable designer locking form factor, in choice of trims and ﬁnishes. Ideal for

educational, commercial ofﬁce or multi-dwelling residential settings, these stylish, durable locks,

leveraging proven Networx access control technology, offer a choice of ID credential technology,

and can be used to control access a door at a time; across a wireless network; or as an integral part of a new or existing enterprise

security system—spanning a few, or thousands of doors, in one building, a campus or multiple sites around the world.

Standard Conﬁgurations

Features:

• 5000 Users, 500 Scheduled Events & 40,000

Event Audit Trail

• Surface-Mount or Mortised-in Electronics and

Battery Pack

• Lock available in Mortise and Cylindrical

versions

• Real Time Clock

• Uses 4 AA Batteries – 3 year battery life, typ.

using advanced Power-Saver circuit

• Operated via access card, keyfob or bluetooth

enabled iLock® App.

• DL-Windows Software for programming Or

in enterprise networx, in real time, use with

Continental Access® CA4K®, Lenel OnGuard®

Integrated Access Control & Video Security or

Software House Connected Partner Program®

Platforms

• USB Radio Gateway Method or Via Networx

Gateways (Ethernet, 802.11 or POE)

• Manual Card Enrollment Option for Quick

Installation

• Wireless programming range: up to 100 ft.

• ANSI / BHMA Grade 1 Certiﬁed, UL Listed 3

Hours

• Auto-Deadbolt option for automatic keyless

locking of deadbolt upon exiting, ideal for

residential applications

• Includes standard lever rose hardware design

• Mortise version compatible with all 300+

optional architectural trim / lever or knob

designs

• Stainless steel latch, 2-3/4” backset

• Auto-Reverse lock body tested to 6 million

cycles

• Lock Body - Self cleaning long life motor

• Door closure monitor / electronic deadbolt

monitor

• Key override standard or high-security

• Optional integrated door position indicator

switch

ArchiTech: Standalone or Networked Access

Mortise; Surface

Mounted Electronics

Cylindrical; Surface

Mounted Electronics

(back box not shown)

Mortised-in electronics

and batteries

Mag Reader KeypadConcealed

electronics

• Designer Wireless Access Control Networked Locks include

multi-technology ID reader access control convenience for any door and

decor, with choice of handles, nishes and reader shape

• Easily, securely networked via 802.11 or ethernet, spanning a few or

thousands of doors, in one building, a campus or multiple sites in an

enterprise (also available in standalone model)

• Emergency LocDown Keyfobs & Flashing Strobe Indicator - In

emergency, lockdown one or multiple locks globally with remote pocket

sized keyfob. Lockdown indicator vividly ashes on the inside door,

conrming lock activation and providing peace of mind to occupants

• Programmable Lockdown/Unlock Privileges - For added security,

programmable user privileges can be varied by group, i.e., all users can

be given global lockdown privileges, while only select users can have both

lockdown & unlock privileges, etc.

• Cylindrical ArchiTech Locks neatly, quickly retrot any standard door

lock, with easy surface mount electronics, for use in all applications -

Including wood and metal doors, for new and existing applications

• Customizable oval or square Access ID Reader, in black or silver and three

levers to choose from - American 195, Crescent 295 & Titan 495 - See lever

photos on back

• Future-Proof Multi-Technology Access ID Credentials Replace

Cumbersome Keys – HID® Prox, Mag Stripe, Smart Cards, PIV, keyfobs and

remote buttons

• Proven, Low Maintenance, Wireless Installation and Unsurpassed

Battery-Life with Advanced Power-Saver circuit, for years of use in even

high-trafc areas, powered by 4 off-the-shelf AA Batteries. 3 to 4 years, typ.

• Flexible System Monitoring, Control & Programming – Program locally

using a USB Gateway or remotely across a wireless network (using free

Alarm Lock DL-WINDOWS Windows- based software). Or, in Real-Time

Enterprise platforms, using either Continental Access CA4K®, Lenel®

OnGuard® or support via Software House® Connected Partner Program®

• Minimizing hardware & installation costs, a single gateway module can

be placed anywhere in any size network and interface between the

PC and up to 63 Networx locks. At its maximum, a, ArchiTech Networx

system can comprise of up to 50 Gateways for the networking of up to

2000 locks or access controlled doors

• Compact LocDown Keyfob - Program up to 10 keyfobs per lock. For added

security, program different users for global lockdown & unlock privileges

• Up to 5000 users/ credential holders, 500 Scheduled Events &

36,000 Event Audit Trail

• Non-handed for easy installation and versatility

LocDown Keyfobs -

Staffers lock down

one, or all networked

doors in seconds

Lockdown

Strobe Indicator

ashes to

conrm lock

is in secure,

lockdown mode

Choice of

access ID

credentials

replace

cumbersome

keys

ArchiTech N90L: Ideal for school & campus safety

ArchiTech Lock Designs

ArchiTech Ordering: Innite Grade 1 Trim Options

ArchiTech: Hundreds of Options for ArchiTech to be Customized. Select

Standard Mortise & Tubular Lock Trim & Rose Options:

Standard Model Ordering. Inﬁnite Custom Models Also Available, Call for Ordering Assistance

Networx Finish

9 Marks Funcon

5 = Morse

Handing

I = Electronic Insert Knob/ Lever design

J = Electronic Insert Bluetooth

S = Surface Mount Electronics

T = Surface Mount Electronics esoR/etalPhtooteulB

L = Lockdown

Design

Technology

1 = Prox Oval

2 = Prox Square

Mag Stripe4 =

5 = Keypad

7 = Keypad

A = Smart Oval Prox (iClass® Technology)

B = Smart Square Prox (iClass®Technology)

C = Concealed Prox (only with insert version)

BASE DISTRIBUTION MORTISE MODEL P/N SCHEME

5 I 1 R

Style

86 FD 26D

Model

Series

N 9

Networx

Finish

0 = Cylindrical

Marks Funcon

Lever /Rose design

S = Surface Mount Electronics

T = Surface

L = Lockdown

Mount Electronics Bluetooth

Technology

1 = Prox Oval

2 = Prox Square

Mag Stripe4 =

7 = Keypad

A = Smart Oval Prox (iClass

Technology)

B = Smart Square Prox (iClass Technology)

Style

195 F 26D

Model

Series

N 9 0 I 1

BASE DISTRIBUTION CYLINDRICAL MODEL P/N SCHEME

2-1/2"

7/16"

2-9/16"

2-1/2"

2-1/4"

7/16"

2-9/16"

4-1/2"

7/16"

2-9/16"

2-7/8"

4-1/4"

7/16"

2-9/16"

2-5/8"

4-1/4"

7/16"

2-9/16"

7/16"

2-9/16" 2-3/16"

1/2"

7/16"

2-9/16"

4-1/2"

7/16"

2-9/16"

2-3/4"

2-1/2"

7/16"

2-9/16"

2-3/4"

1/2"

4-1/2"

7/16"

2-9/16"

3-1/8"

2-1/2"

7/16"

2-1/4"

4-1/2"

7/16"

2-9/16"

2-3/4"

2-9/16"

7/16"

2-9/16"

7/16"

2-9/16"

7/16"

2-1/4"

7/16"

2-1/4"

ROUND 10

ROSE RR ROSE RW ROSE RS ROSE RQ ROSE RX

BALL 20/30

ECLIPSE 60

MAXWELL 77

STANHOPE 5644

MONACO 57

TOWNE 72

AMERICAN 92

PLAZA 82

DAYTON 83

CRESCENT 86

OMNI 78

TITAN 96

Some Designer Custom Options for ArchiTech

2-5/16"

5348

SF031 2-1/2"

5-1/16"

SF095 2-11/16"

2-7/8"

SF117

5-1/8"

SF037A

2-13/16"

5-5/16"

5671

3-15/16"

4-3/16"

www.designalock.com Create custom locks

Create and share a custom lock vision for any space or building with www.designalock.com

interactive site for trying out various lock looks for locks inside and out. Ideal for Architects,

Designers and Building Operating Management who want their access control and locking

“look” to be as welcome as the security they provide.

Select Standard Mortise & Tubular Lock Trim Options:

2-1/2"

7/16"

2-9/16"

2-1/2"

2-1/4"

7/16"

2-9/16"

4-1/2"

7/16"

2-9/16"

2-7/8"

4-1/4"

7/16"

2-9/16"

2-5/8"

4-1/4"

7/16"

2-9/16"

7/16"

2-9/16" 2-3/16"

1/2"

7/16"

2-9/16"

4-1/2"

7/16"

2-9/16"

2-3/4"

2-1/2"

7/16"

2-9/16"

2-3/4"

1/2"

4-1/2"

7/16"

2-9/16"

3-1/8"

2-1/2"

7/16"

2-1/4"

4-1/2"

7/16"

2-9/16"

2-3/4"

2-9/16"

7/16"

2-9/16"

7/16"

2-9/16"

7/16"

2-1/4"

7/16"

2-1/4"

ROUND 10

ROSE RR ROSE RW ROSE RS ROSE RQ ROSE RX

BALL 20/30

ECLIPSE 60

MAXWELL 77

STANHOPE 5644

MONACO 57

TOWNE 72

AMERICAN 92

PLAZA 82

DAYTON 83

CRESCENT 86

OMNI 78

TITAN 96

Sirenlock: Panic exit alarms

Delayed egress exit alarm

SIRENLOCK™ MODEL 715

• Offers stylish, cost-effective control of unauthorized use of exit

doors

• 15 second delayed egress with instant 95db Dual Piezo alarm

(meets UL specications)

• Instant alarmed exit in case of actual emergency or re (meets

NFPA 1012 Life Safety Code)

• Easy-to-install, surface mount unit in a standard panic bar

deadbolt/deadlatch design

• Monitoring output for simultaneous use of CCTV camera,

secondary siren, remote monitoring console, etc.

• Smoke detector input can be used to power existing system or

standalone smoke detector(s) (Includes armored door cord and

cables for wiring)

• 9V battery back-up powers in event of power failure

• Requires standard RIM cylinder (not included)

MODEL 11A (Not Shown)

(Dead bolt only; Not for ADA applications)

• Model 11A is an exit lock designed to control unauthorized use

of emergency doors. It provides trouble free service and deters

theft from within and outside. Unauthorized use sounds alarm

which can only be reset or bypassed with key. Standard features

include 1 inch throw deadbolt, warning alarm, outside cylinder

capability, tamper switch and long life battery pack. Available

for use with double doors or for use with existing panic bars.

Optional AC power supply. Requires standard RIM cylinder (not

included).

Sirenlock™ Models 250, 260, 700, and

710 are UL Listed panic alarm deadbolt

devices which restrict unauthorized

use of exit doors by sounding an

alarm, while providing instant egress in

emergencies

Clapper plate & full door exit style alarms

A – SIRENLOCK™ MODEL 250/260

B – SIRENLOCK™ MODEL 700/710

• Deadbolt and deadlatch meet relatching requirements

• Blaring 95db dual tone siren

• Selectable 2-minute alarm or

constant alarm

• 9V battery powered and

audible low battery warning

• Meets or exceeds UL,

CFM, ADA, NYC housing

requirements

• 250/700 Models have

changeable 2 minute alarm

cutoff or manual reset.

• 260/710 Models have changeable 2 minute auto reset or manual

reset

• Models 700 and 710 are available in 33” and 48” versions

• Model 700 is also available in red nish (700XRD) and 312 (Duronotic)

• Non-handed surface installations on single or double doors

• Requires standard RIM cylinder (not included)

Waterproof electronic alarmed panic locks

700/710x28WP and 250/260x28WP (models same as above)

• Suitable for outdoor use

• Weather-resistant for exposure to rain and precipitation, even in

harsh conditions

• Wide operating temperature of -20˚F to +140˚F (-29˚ to+60˚C)

• Powered with long-life sealed 9VDC alkaline battery pack (BP9)

• Loud 99db alarm

Sirenlock™ Models 250, 260, 700, and

710 are UL Listed panic alarm deadbolt

devices which restrict unauthorized use

of exit doors by sounding an alarm, while

providing instant egress in emergencies

Mags: Remote release mags, powermags & RTEs

Easy buzz-in convenience from a mag lock. Ideal for

reception areas!

Electromagnetic locks

PowerMag™ 12/24V

• Strong holding force of 600 and 1200 lb. models

• Perfect for both single and double doors and even sliding doors

• 5-year limited warranty

• Low voltage (12 or 24VDC); including eld-selectable models

• Double door models with 1200 lb. locking per side (PM1200SLB1

and 40)

PowerExit™ Request-to-Exit Push Buttons

• Come in ve models, with or without

illuminated buttons

• All models have solid aluminum

anodized nish US28

• Sizes: 3’ x 4 3/4” x 1/4” and 1 5/8” x 4

3/4” x 1/4”

• Back Depth: 1 1/4” and 1 7/8”

• Switch Rating: 250V AC 5A

• Momentary Action

Electric door locks

Models 103 & 104RA

• Models 103 & 104RA are compact electric locks simple to install

on all types of doors. The door is locked or unlocked by remote

switch, key switch, time programmer or other electrical contact

which interrupts the power. Model 103 is our standard fail-

safe unit which projects the bolt only while power is

on. When the power is off the bolt retracts.

Model 104RA (reverse action) unlike

our standard unit is “fail-secure” and

will project the bolt only when the

power is “off.” When the power is

on the bolt retracts. 24AC/DC and

12VAC/DC models available

Innovative remote release mag-kit

KIT RR-PM1200PAK

• Advanced 1200 lb. Electromagnetic Lock with Infrared

Remote Release

• The power of a mag with the convenience of pocket-size

remote controls for reception or staffers

• Complete turnkey system includes: Advanced 1200 lb.

Mag, one remote control, and plug-in AC transformer

• Plug-in 12VAC transformer eliminates the requirement

for pulling wires or the services of an electrician (optional

use)

• Supports up to 100 individual remote controls (AL-

REMOTE)

• Releases mag from either side of door

• AL-REMOTE Keyfob features single button operation

with positive “click” response

• Automatically-enrolled by system in easy programming

mode and is audibly and visually conrmed

• UL-listed; CE-listed

Multifunction Door Alarms with Enhanced Features

PG21MS Series surface-mount narrow stile door alarms

Ideal in schools, nursing homes, restaurants & theatres

PG21MS/PG21MB

• Improve security at any door and stops security vulnerability from doors propped

open, for innocent and even felonious reasons in schools, nursing homes,

restaurants, stores and theaters

• Two selectable arming modes –

1. Always armed mode – when key is turned counter clockwise to the disarm

position, the key cannot be removed. To remove key, turn back to arm mode,

thus keeping unit armed always.

2. Standard arming mode – when key is inserted turning counter clockwise

will disarm and key can be removed. Turning key clockwise will arm and key

can be removed.

• Status Indicator – The LED will indicate RED when armed

• Long-life 9V battery (supplied), low battery alert

• Entry Delay Time Options: Includes 15 seconds; 1 min. 15 sec. & 3 mins 15 sec.

• For use on standard size and narrow stile doors, sleek model design key-activated

door alarm

• Sweeping Siren over 95db alarm &/or strobe

• Unauthorized use of door causes alarm to sound and activates LED indicator

&/or optional strobe

• Options include continuous alarm, minute shutdown with auto reset and

exit/entry delay

• Uses standard mortise cylinder (not included)

• Self contained and dual-tamper supervised

• Continuous Power with the addition of external power supply

• Multiple Door Monitoring permitted with external reed switches

• Metallic silver or duronodic nish

• Easy installation

• For exterior key control, optional RIM cylinder may be used

• PG21MSS/PG21MBS Optional strobe unit (shown left) – include a highly

visible amber strobe that ashes when unit goes into alarm

All-in-One: Exit Alarm • Door-Prop Alarm • Door Management Alarm • Door Annunciator • Timed-Bypass Alarm

Model PG30KPD:

Keypad-controlled narrow stile door alarm, similar to PG21, plus:

• Digital codes for master, management and

passage (used for auto-arming)

• 3 security levels for: a) high security b)

unattended applications c) exible control for

delivery doors, etc.

• Audible low battery warning

• 3 Programmable 95db siren styles: sweep,

pulsed, and steady

• Logo key is dual function test button

PG30KPD Accessory:

• For optional use with the PG30, this low-prole, brushed aluminum

nished accessory provides all functions of the PG30 from the

outside of the door. (Available in metallic silver only.)

Model PG10

• The Pilfergard Model PG10 is an exit door alarm designed to

deter the use of the secured door by sounding a twin action

alarm when opened by unauthorized personnel. The alarm

can be bypassed from inside or outside by

the use of a key. (Requires standard mortise

cylinder not supplied.) This durable surface mount

unit is easily installed and is tamper-supervised with

two separate tamper switches. Its test button veries

battery. Optional AC power supply available.

Model LL1

• All of the features of the PG10 unit with

addition of a ashing strobe for easy alarm

identication.

• Choice of system controllers

Multiple door monitoring with built-in

external reed switches, too.

PG21MSS PG21MB

Alarm Lock: Essential add-ons and extras

Strikes for model 11A

Model 210K

• Strike for single or double

inswinging door(s) (not included

with 11A)

Model K24A

• Strike for single outswinging

door (included with 11A)

Rim cylinder

Model CER

• Required for interior arming/

disarming of models 11A, 80, 250,

260, 700, 710 & 715. Includes two

keys (KA or KD)

Mortise cylinder

Model CEM

• Used with the Pilfergard models

PG10 and PG21/E to arm and

disarm the alarm circuit. Includes

two keys (KA or KD)

Cylinder ﬁnger pull

Model 711

• An inexpensive door pull for

use when outside key only

access is required.

Outside access

door pull

Model 707

• For access from building

exteriors. Installed on the

outside of the door and

linked to the lock. After

deadbolt is retracted by

outside key, a slight pull will

release the deadlatch and

open the door. 8” x 1 1/2”.

(For use with all models

except Model 11A).

Battery eliminator

Model PP100

• For use with all

PG10, PG21/E,

PG30, 250, 700,

80, 260, 710 and

715 models. The

PP100 conserves

the battery which

automatically

takes over as the

power source to

sound the alarm in

the event of a power failure or intentional

cut-off. A built-in circuit breaker with push-

button reset eliminates troublesome fuse

replacements. Includes a cam lock cylinder

and 6’ of armored cable adequate to

provide a door loop at the hinged-side of

the door. Can be used with all 6V and 9V

models.

Double door holder

Model 44

• The Double

Door Holder

secures the

inactive door to

the frame while

the active door is

closed. Releasing

the active door automatically allows both

doors to swing freely. Reversible, right or

left hand doors. Cast aluminum 8 1/2” long,

3” wide and 2 1/2” high.

Armored door loop

Model 271

• For use with

electried locks.

An easy means

for bringing

electric current

from the

hinge side of

a door frame

to the door. 18” exible armored cable.

End brackets are deep drawn anodized

aluminum to conceal wire connections.

Single door strike

Models 730 & 725

• Model 730 supplied with

models 250, 700 and 80

• Model 730M supplied with

models 260 and 710 and 80

• Model 725 supplied with

model 715

Double door strike

Models 732 & 735

• Model 732 for use with models

250, 700 and 80.

• Model 732M for use with models

260 and 710.

• Model 735 for use with model

715. (Not Shown)

Cable energy switch

Model 261

• Transfers current to other side of the door.

• For use with models 250, 100 and 11A

Severe Weather Keypad

Guard

Model HW2037

• Protects keypad from

harsh outdoor weather

conditions.

Trilogy, Networx & ArchiTech: Standalone &

Model &

Feature DL2700 DL2700LD

DL2700

CR/DB DL2800 DL3000 PDL3000 DL3200 DL3500 PDL3500 DL4100 PDL4100 P/DL4500 DL5200 P/DL5300 P/DL6100 PDL6300 P/DL6500 PDL8200 DL1200 P/DL1300 ETDL2700 ETDL ETPDL

ETDLN,

ETPDN DL1200ET P/DL1300ET P/DL1300NW DK3000 PDK3000

NETDK/

NETPDK N90S/ST N90L N95S/T N95I/J

Lock Type Cylindrical Cylindrical Mortise,

CR-Classroom,

DB Beadbolt

Cylindrical Cylindrical Cylindrical

Prox Cylindrical Mortise

CR-Classroom,

DB Beadbolt

Mortise Prox

CR-Classroom,

DB Beadbolt

Cylindrical Cylindrical

Prox Mortise Cylindrical Cylindrical Cylindrical

Ethernet Mortise Prox

Ethernet,

Double

-sided

Mortise Prox

Ethernet Cylindrical

Prox

Ethernet

Narrow Stile Narrow Stile For use w/exit

device For use w/exit

device ,Prox For use w/

panic

device

Ethernet

Narrow Stile

For use w/

panic

device

Narrow Stile

For use w/

panic

device

Narrow Stile

PDL1300NWET

for use with

exit device

Standalone

Keypad Standalone

Keypad, Prox Keypad

Ethernet Cylindrical Surface

Mount, Ethernet Cylindrical Surface

Mount, Ethernet Mortise Surface

Mount, Ethernet Mortise Insert

Electronics,

Ethernet

Users 100 100 100 200 300 2000 2000 300 2000 2000 2000 2000 100 2000 5000 5000 5000 5000 100 2000 100 2000 2000 2000 100 2000 5000 2000 2000 5000 5000 5000 5000 5000

Code Length 3-6 digits 3-6 digits 3-6 digits 3-6 digits 3-6 digits 3-6 digits 3-6 digits 3-6 digits 3-6 digits 3-6 digits 3-6 digits 3-6 digits 3-6 digits 3-6 digits 3-6 digits 3-6 digits 3-6 digits 3-6 digits 3-6 digits 3-6 digits 3-6 digits 3-6 digits 3-6 digits 3-6 digits 3-5 digits 3-6 digits 3-6 digits 3-6 digits 3-6 digits 3-6 digits

Programming Keypad only Keypad only Keypad only Keypad /PC Keypad /PC Keypad /PC Keypad /PC Keypad /PC Keypad /PC Keypad /PC Keypad /PC Keypad /PC Keypad only Keypad /PC Keypad /PC Keypad /PC Keypad /PC Keypad /PC Keypad Keypad /PC Keypad only Keypad /PC Keypad /PC Keypad /PC Keypad Keypad /PC Keypad /PC Keypad /PC Keypad /PC Keypad /PC Card Reader/PC Card Reader/PC Card Reader/PC Card Reader/PC

Vandal-Proof

Keypad All metal,

12 button All metal,

12 button Dual sides, All

metal,

12 button

Dual sides, All

metal,

12 button

All metal,

12 button All metal,

12 button

Trim

w/Rugged

Clutch

Straight or

curved lever Straight or

curved lever,

thumbturn or

knob

Straight or

curved lever,

thumbturn or

knob

Straight or

curved lever Straight or

curved lever,

thumbturn or

knob

Straight or

curved lever,

thumbturn or

knob

Straight or

curved lever, Straight or

curved lever Std Lever Rose

Hardware Design;

Choice of 4 lever

designs

Choice of 3 levers Std Lever Rose

Hardware Design,

Custom choice

of 300 Grade 1

Trim lever/knob

designs

Std Lever Rose

Hardware Design,

Custom choice

of 300 Grade 1

Trim lever/knob

designs

Audit Trail

Events 1000 1600 40000 40000 40000 40000 40000 40000 40000 40000 35000 40000 35,000 35,000 40000 40000 40000 40000 40000 40000 40000 40000 35000 40000 36000 40000 40000

Scheduled

Events 150 150 500 500 500 500 500 500 500 500 500 500 500 500 500 500 500 500 500 500 500 500 500 500 500 500 500

Reader/

Credential-

Support

Prox

HID Prox

HID PDL4500 for

HID Prox PDL5300 for

HID Prox PDL6100 for

HID Prox HID Prox PDL6500 for

HID Prox iClass

HID Prox

13.56MHz

PDL1300 for

Prox HID Prox

HID ETPDLN for

Prox HID;

ETPDNI for

iClass support

PDL1300ET

for Prox PDL1300NW

for HID Prox Prox

HID NETPDK for

HID Prox Choice of Oval

or Square

Multitechnology

Reader, HID,

iClass; Also

available Mag

Swipe Reader

Choice of Oval

or Square

Multitechnology

Reader in black or

silver, HID, iClass;

Also available

Mag Swipe

Reader

Choice of Oval

or Square

Multitechnology

Reader, HID,

iClass; Also

available Mag

Swipe Reader

Choice of Oval

or Square

Multitechnology

Reader, HID,iClass

iLock® App

Mobile

Solution

T Model has

Bluetooth LE App

- No keys, no ID +

Audit trail

T Model has

Bluetooth LE App

- No keys, no ID +

Audit trail

J Model has

Bluetooth LE App

- No keys, no ID +

Audit trail

Lockdown or

Privacy Lockdown

w/ Keyfob

incldd

Privacy/

Lock-out Privacy/

Lock-out Global

lockdown Global

Lockdown Global

lockdown Global lockdown Global lockdown Global lockdown Global lockdown

Function Lockdown

Indicator light

bar (inner door)

CR Classroom

or DB

Deadbolt

CR Classroom

or DB

Deadbolt

DB Deadbolt FD Flashing lockdown

strobe Indicator

(inner door)

CR Classroom or

DB Deadbolt; FD CR Classroom or

DB Deadbolt; FD

Door Position

Switch PDL6200;

PDL8200

with iClass

support

PDL6600;

PDL8600

with iClass

support

Request to

Exit PDL6200;

PDL8200

with iClass

support

PDL6600;

PDL8600

with iClass

support

ETPDN-RX;

ETPDNI-RX

with iClass

support

Weather-Proof

-31 To 151˚ F WP version Standard Standard Standard WP version Standard Standard Standard Standard Standard Standard Standard Standard Standard Standard Standard Standard Standard Standard Standard Standard Standard Standard Standard Standard Standard Standard Standard Standard Standard

Handing Nonhanded Nonhanded Handed; Field

Reversible Nonhanded Nonhanded Nonhanded Nonhanded Handed; Field

Reversible Handed; Field

Reversible Nonhanded Nonhanded Handed; Nonhanded Nonhanded Nonhanded Handed; Field

Reversible Handed; Field

Reversible Nonhanded Nonhanded Nonhanded Nonhanded Nonhanded. Nonhanded. Nonhanded. Nonhanded Nonhanded Nonhanded Nonhanded Nonhanded Nonhanded Handed; Field

Reversible Handed; Field

Reversible

Door

Thickness 1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8” 1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8” 1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8”

others upon

request

1-5/8 to

1-7/8” 1-5/8 to

1-7/8”

others upon

request

1-3/4” 1-3/4” 1-5/8 to

1-7/8” \ 1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8” (others

on request.)

1-3/4” 1-3/4” 1-3/4” 1-5/8 to

1-7/8”

others upon

request

1-5/8" to 1-7/8"

others upon

request

1-5/8” to 1-7/8”

others upon

request

1-5/8" to 1-7/8"

others upon

request

1-5/8" to 1-7/8"

others upon

request

Backset 2-3/4”

(included);

2-3/8”option.

2-3/4”

(included);

2-3/8”option.

2-3/4”

(included) 2-3/4”

(included);

2-3/8”option.

2-3/4”

(included);

2-3/8”option.

2-3/4”

(included);

2-3/8”option.

2-3/4”

(included);

2-3/8”option.

2-3/4”

(included) 2-3/4”

(included);

2-3/8”option.

2-3/4”

(included);

2-3/8” option.

2-3/4”

(included) 2-3/4”

(included);

2-3/8”option.

2-3/4”

(included);

2-3/8”option

2-3/4”

(included)

2-3/8” opt.

2-3/4”

(included) 2-3/4”

(included)

2-3/8” opt.

31/32”,

1-1/8”,

1-1/2”

31/32”,

1-1/8”,

1-1/2”

31/32”, 1-1/8”,

1-1/2” 31/32”, 1-1/8”,

1-1/2” 2-3/4”

(included)

2-3/8” opt.

2-3/4" (included) 2-3/4” (included) 2-3/4" (included) 2-3/4" (included)

Cylinder Large key-in-

knob, incld

-or- IC Prep for

Best/Falcon/

Arrow (w/o

cyld.)

Large key-in-

knob, incld

-or- IC Prep for

Best/Falcon/

Arrow (w/o

cyld.)

Generic

mortise

cylinder,

supplied.

Large key-in-

knob, incld

-or- IC Prep for

Best/Falcon/

Arrow (w/o

cyld.)

Large key-in-

knob, incld

-or- IC Prep for

Best/Falcon/

Arrow (w/o

cyld.)

Large key-in-

knob, incld

-or- IC Prep for

Best/Falcon/

Arrow (w/o

cyld.)

Large key-in-

knob, incld

-or- IC Prep for

Best/Falcon/

Arrow (w/o

cyld.)

Generic

mortise

cylinder,

supplied.

Generic

mortise

cylinder,

supplied.

Large key-in-

knob, incld

-or- IC Prep for

Best/Falcon/

Arrow (w/o

cyld.)

Large key-in-

knob, incld

-or- IC Prep for

Best/Falcon/

Arrow (w/o

cyld.)

Generic

mortise

cylinder,

supplied.

Other cams

available for

cylinders

Large key-in-

knob, incld

-or- IC Prep for

Best/Falcon/

Arrow (w/o

cyld). One

cyld. needed

for each side

of door

Large key-in-

knob, incld

-or- IC Prep for

Best/Falcon/

Arrow (w/o

cyld.). One

cyld. needed

for each side

of door

Large key-in-

knob, incld

-or- IC Prep for

Best/Falcon/

Arrow (w/o

cyld.)

Large key-in-

knob, incld

-or- IC Prep for

Best only

Generic

mortise

cylinder,

supplied.

Large

key-in-knob,

incld -or- IC

Prep for Best/

Falcon/Arrow

(w/o cyld.)

Generic

1-1/4”

mortise

cylinder,

supplied.

1-1/8”,

1-1/4”

1-3/8”

supported

Generic

1-1/4”

mortise

cylinder,

supplied.

1-1/8”,

1-1/4”

1-3/8”

supported

Generic Rim

Cylinder,

supplied.

Other mfrs.

Cylinder

Adapters must

be ordered

separately.

Generic Rim

Cylinder,

supplied.

Other mfrs.

Cylinder

Adapters must

be ordered

separately.

Generic Rim

Cylinder,

supplied.

Other mfrs.

Cylinder

Adapters must

be ordered

separately.

Generic Rim

Cylinder,

supplied.

Other mfrs.

Cylinder

Adapters must

be ordered

separately.

Generic 1-1/4”

mortise

cylinder,

supplied.

1-1/8”, 1-1/4”

1-3/8”

supported

Generic 1-1/4”

mortise

cylinder,

supplied.

1-1/8”, 1-1/4”

1-3/8”

supported

1-1/4”

mortise

cylinder,

supplied;.

for Best,

Falcon, Arrow

prep cam

and housing

available

Large key-in-

knob, incld

-or- IC Prep for

Best/Falcon/

Arrow (w/o

cyld.)

Large key-in knob,

incld or IC prep for

Best/Falcon/Arrow

Generic mortise

cylinder supplied Generic mortise

cylinder supplied

Special Order

Cylinders Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent, Corbin/

Russwin, Schlage

Best/Falcon/

Arrow, Schlage

(Note: must order

appropiate IC

Housing)

Best/Falcon/

Arrow, Schlage

(Note: must order

appropiate IC

Housing)

Relay

Options yes yes yes yes yes yes yes yes yes yes yes no no yes no yes yes yes yes yes yes no yes yes yes

Battery/

Cycles Typical 5AA; 200000

or up to 5

years

5AA; 100000

or up to 3 - 4

years

5AA; 60000 5AA; 100000 5AA; 100000 5AA; 60000 5AA; 100000 5AA; 100000 5AA; 60000 5AA; 100000 5AA; 60000 5AA; 60000 5AA; 80,000 5AA; 100000 4 C cells

5 years

500,000

4 AA

3-4 years

600,000

4 C cells

5 years

500,000

4 C cells

5 years

500,000

2-3V Lithium,

100,000 2-3V Lithium,

80,000 5AA; 60000 5AA; 60000 5AA; 60000 4 C cells, 5

years/500,000 2-3V Lithium,

100,000 2-3V Lithium,

80,000 4 AA; 100,000

3-4 years 4 C cells

5 years

500,000

4 AA, 3 years

/ 100,000 (w/

Power Saver

Circuit)

4 AA, 3 years

/ 100,000 (w/

Power Saver

Circuit)

4 AA, 3 years

/ 100,000 (w/

Power Saver

Circuit)

4 AA, 3 years

/ 100,000 (w/

Power Saver

Circuit)

Ratings BHMA Grade

1 Lockset; 3hr.

Fire Rated UL

BHMA Grade

1 Lockset; 3hr.

Fire Rated UL

3hr. Fire

Rated UL BHMA Grade

1 Lockset; 3hr.

Fire Rated UL

BHMA Grade

1 Lockset; 3hr.

Fire Rated UL

BHMA Grade

1 Lockset; 3hr.

Fire Rated UL

BHMA Grade

1 Lockset; 3hr.

Fire Rated UL

3 Hr Fire

Rated UL 3 Hr Fire

Rated UL BHMA Grade

1 Lockset; 3hr.

Fire Rated UL

BHMA Grade

1 Lockset; 3hr.

Fire Rated UL

3 Hr Fire

Rated UL BHMA Grade

1 Lockset; 3hr.

Fire Rated UL

BHMA Grade

1 Lockset; 3hr.

Fire Rated UL

BHMA

Grade 1

Lockset; 3hr.

Fire Rated UL

3 Hr Fire

Rated UL 3 Hr Fire

Rated UL BHMA

Grade 1

Lockset; 3hr.

Fire Rated UL

3 Hr Fire Rated UL UL Pending BHMA Grade 1

Lockset; 3hr. Fire

Rated UL

BHMA Grade 1

Lockset; 3hr. Fire

Rated UL

BHMA Grade 1

Lockset; 3hr. Fire

Rated UL

BHMA Grade 1

Lockset; 3hr. Fire

Rated UL

Architectural

Finishes US26D, US3,

10B US26D, US3,

10B US26D, 10B US26D, 10B US26D, 10B US26D, 10B US10B,

US26D, MS,

US10B,

US26D, MS,

US26D, US3,

10B US26D, US3,

10B US26D, 10B US10B,

US26D, MS,

US10B, US26D,

MS, MB US26D, 10B US10B, US26D,

MS, MB US10B, US26D,

MS, MB US26D, 10B Customizable;

Std US26D, 10B Customizable;

Std US26D, 10B

Privacy - Class Lockdown - Narrow Stile - Networx Wireless - Double-Sided - Keypads - ArchiTech -

LEGEND:

(Note: Also see

ordering information

charts pg. 11 and 20)

Wireless Access Control Locks & Special Models

Model &

Feature DL2700 DL2700LD

DL2700

CR/DB DL2800 DL3000 PDL3000 DL3200 DL3500 PDL3500 DL4100 PDL4100 P/DL4500 DL5200 P/DL5300 P/DL6100 PDL6300 P/DL6500 PDL8200 DL1200 P/DL1300 ETDL2700 ETDL ETPDL

ETDLN,

ETPDN DL1200ET P/DL1300ET P/DL1300NW DK3000 PDK3000

NETDK/

NETPDK N90S/ST N90L N95S/T N95I/J

Lock Type Cylindrical Cylindrical Mortise,

CR-Classroom,

DB Beadbolt

Cylindrical Cylindrical Cylindrical

Prox Cylindrical Mortise

CR-Classroom,

DB Beadbolt

Mortise Prox

CR-Classroom,

DB Beadbolt

Cylindrical Cylindrical

Prox Mortise Cylindrical Cylindrical Cylindrical

Ethernet Mortise Prox

Ethernet,

Double

-sided

Mortise Prox

Ethernet Cylindrical

Prox

Ethernet

Narrow Stile Narrow Stile For use w/exit

device For use w/exit

device ,Prox For use w/

panic

device

Ethernet

Narrow Stile

For use w/

panic

device

Narrow Stile

For use w/

panic

device

Narrow Stile

PDL1300NWET

for use with

exit device

Standalone

Keypad Standalone

Keypad, Prox Keypad

Ethernet Cylindrical Surface

Mount, Ethernet Cylindrical Surface

Mount, Ethernet Mortise Surface

Mount, Ethernet Mortise Insert

Electronics,

Ethernet

Users 100 100 100 200 300 2000 2000 300 2000 2000 2000 2000 100 2000 5000 5000 5000 5000 100 2000 100 2000 2000 2000 100 2000 5000 2000 2000 5000 5000 5000 5000 5000

Vandal-Proof

Keypad All metal,

12 button All metal,

12 button Dual sides, All

metal,

12 button

Dual sides, All

metal,

12 button

All metal,

12 button All metal,

12 button

Trim

w/Rugged

Clutch

Straight or

curved lever Straight or

curved lever,

thumbturn or

knob

Straight or

curved lever,

thumbturn or

knob

Straight or

curved lever Straight or

curved lever,

thumbturn or

knob

Straight or

curved lever,

thumbturn or

knob

Straight or

curved lever, Straight or

curved lever Std Lever Rose

Hardware Design;

Choice of 4 lever

designs

Choice of 3 levers Std Lever Rose

Hardware Design,

Custom choice

of 300 Grade 1

Trim lever/knob

designs

Std Lever Rose

Hardware Design,

Custom choice

of 300 Grade 1

Trim lever/knob

designs

Audit Trail

Events 1000 1600 40000 40000 40000 40000 40000 40000 40000 40000 35000 40000 35,000 35,000 40000 40000 40000 40000 40000 40000 40000 40000 35000 40000 36000 40000 40000

Scheduled

Events 150 150 500 500 500 500 500 500 500 500 500 500 500 500 500 500 500 500 500 500 500 500 500 500 500 500 500

Reader/

Credential-

Support

Prox

HID Prox

HID PDL4500 for

HID Prox PDL5300 for

HID Prox PDL6100 for

HID Prox HID Prox PDL6500 for

HID Prox iClass

HID Prox

13.56MHz

PDL1300 for

Prox HID Prox

HID ETPDLN for

Prox HID;

ETPDNI for

iClass support

PDL1300ET

for Prox PDL1300NW

for HID Prox Prox

HID NETPDK for

HID Prox Choice of Oval

or Square

Multitechnology

Reader, HID,

iClass; Also

available Mag

Swipe Reader

Choice of Oval

or Square

Multitechnology

Reader in black or

silver, HID, iClass;

Also available

Mag Swipe

Reader

Choice of Oval

or Square

Multitechnology

Reader, HID,

iClass; Also

available Mag

Swipe Reader

Choice of Oval

or Square

Multitechnology

Reader, HID,iClass

iLock® App

Mobile

Solution

T Model has

Bluetooth LE App

- No keys, no ID +

Audit trail

T Model has

Bluetooth LE App

- No keys, no ID +

Audit trail

J Model has

Bluetooth LE App

- No keys, no ID +

Audit trail

Lockdown or

Privacy Lockdown

w/ Keyfob

incldd

Privacy/

Lock-out Privacy/

Lock-out Global

lockdown Global

Lockdown Global

lockdown Global lockdown Global lockdown Global lockdown Global lockdown

Function Lockdown

Indicator light

bar (inner door)

CR Classroom

or DB

Deadbolt

CR Classroom

or DB

Deadbolt

DB Deadbolt FD Flashing lockdown

strobe Indicator

(inner door)

CR Classroom or

DB Deadbolt; FD CR Classroom or

DB Deadbolt; FD

Door Position

Switch PDL6200;

PDL8200

with iClass

support

PDL6600;

PDL8600

with iClass

support

Request to

Exit PDL6200;

PDL8200

with iClass

support

PDL6600;

PDL8600

with iClass

support

ETPDN-RX;

ETPDNI-RX

with iClass

support

Weather-Proof

Handing Nonhanded Nonhanded Handed; Field

Reversible Nonhanded Nonhanded Nonhanded Nonhanded Handed; Field

Reversible Handed; Field

Reversible Nonhanded Nonhanded Handed; Nonhanded Nonhanded Nonhanded Handed; Field

Reversible Handed; Field

Reversible Nonhanded Nonhanded Nonhanded Nonhanded Nonhanded. Nonhanded. Nonhanded. Nonhanded Nonhanded Nonhanded Nonhanded Nonhanded Nonhanded Handed; Field

Reversible Handed; Field

Reversible

Door

Thickness 1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8” 1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8” 1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8”

others upon

request

1-5/8 to

1-7/8” 1-5/8 to

1-7/8”

others upon

request

1-3/4” 1-3/4” 1-5/8 to

1-7/8” \ 1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8” (others

on request.)

1-5/8 to

1-7/8” (others

on request.)

1-3/4” 1-3/4” 1-3/4” 1-5/8 to

1-7/8”

others upon

request

1-5/8" to 1-7/8"

others upon

request

1-5/8” to 1-7/8”

others upon

request

1-5/8" to 1-7/8"

others upon

request

1-5/8" to 1-7/8"

others upon

request

Backset 2-3/4”

(included);

2-3/8”option.

2-3/4”

(included);

2-3/8”option.

2-3/4”

(included) 2-3/4”

(included);

2-3/8”option.

2-3/4”

(included);

2-3/8”option.

2-3/4”

(included);

2-3/8”option.

2-3/4”

(included);

2-3/8”option.

2-3/4”

(included) 2-3/4”

(included);

2-3/8”option.

2-3/4”

(included);

2-3/8” option.

2-3/4”

(included) 2-3/4”

(included);

2-3/8”option.

2-3/4”

(included);

2-3/8”option

2-3/4”

(included)

2-3/8” opt.

2-3/4”

(included) 2-3/4”

(included)

2-3/8” opt.

31/32”,

1-1/8”,

1-1/2”

31/32”,

1-1/8”,

1-1/2”

31/32”, 1-1/8”,

1-1/2” 31/32”, 1-1/8”,

1-1/2” 2-3/4”

(included)

2-3/8” opt.

2-3/4" (included) 2-3/4” (included) 2-3/4" (included) 2-3/4" (included)

Cylinder Large key-in-

knob, incld

-or- IC Prep for

Best/Falcon/

Arrow (w/o

cyld.)

Large key-in-

knob, incld

-or- IC Prep for

Best/Falcon/

Arrow (w/o

cyld.)

Generic

mortise

cylinder,

supplied.

Large key-in-

knob, incld

-or- IC Prep for

Best/Falcon/

Arrow (w/o

cyld.)

Large key-in-

knob, incld

-or- IC Prep for

Best/Falcon/

Arrow (w/o

cyld.)

Large key-in-

knob, incld

-or- IC Prep for

Best/Falcon/

Arrow (w/o

cyld.)

Large key-in-

knob, incld

-or- IC Prep for

Best/Falcon/

Arrow (w/o

cyld.)

Generic

mortise

cylinder,

supplied.

Generic

mortise

cylinder,

supplied.

Large key-in-

knob, incld

-or- IC Prep for

Best/Falcon/

Arrow (w/o

cyld.)

Large key-in-

knob, incld

-or- IC Prep for

Best/Falcon/

Arrow (w/o

cyld.)

Generic

mortise

cylinder,

supplied.

Other cams

available for

cylinders

Large key-in-

knob, incld

-or- IC Prep for

Best/Falcon/

Arrow (w/o

cyld). One

cyld. needed

for each side

of door

Large key-in-

knob, incld

-or- IC Prep for

Best/Falcon/

Arrow (w/o

cyld.). One

cyld. needed

for each side

of door

Large key-in-

knob, incld

-or- IC Prep for

Best/Falcon/

Arrow (w/o

cyld.)

Large key-in-

knob, incld

-or- IC Prep for

Best only

Generic

mortise

cylinder,

supplied.

Large

key-in-knob,

incld -or- IC

Prep for Best/

Falcon/Arrow

(w/o cyld.)

Generic

1-1/4”

mortise

cylinder,

supplied.

1-1/8”,

1-1/4”

1-3/8”

supported

Generic

1-1/4”

mortise

cylinder,

supplied.

1-1/8”,

1-1/4”

1-3/8”

supported

Generic Rim

Cylinder,

supplied.

Other mfrs.

Cylinder

Adapters must

be ordered

separately.

Generic Rim

Cylinder,

supplied.

Other mfrs.

Cylinder

Adapters must

be ordered

separately.

Generic Rim

Cylinder,

supplied.

Other mfrs.

Cylinder

Adapters must

be ordered

separately.

Generic Rim

Cylinder,

supplied.

Other mfrs.

Cylinder

Adapters must

be ordered

separately.

Generic 1-1/4”

mortise

cylinder,

supplied.

1-1/8”, 1-1/4”

1-3/8”

supported

Generic 1-1/4”

mortise

cylinder,

supplied.

1-1/8”, 1-1/4”

1-3/8”

supported

1-1/4”

mortise

cylinder,

supplied;.

for Best,

Falcon, Arrow

prep cam

and housing

available

Large key-in-

knob, incld

-or- IC Prep for

Best/Falcon/

Arrow (w/o

cyld.)

Large key-in knob,

incld or IC prep for

Best/Falcon/Arrow

Generic mortise

cylinder supplied Generic mortise

cylinder supplied

Special Order

Cylinders Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent,

Corbin/

Russwin,

Schlage

Yale, Medeco,

Sargent, Corbin/

Russwin, Schlage

Best/Falcon/

Arrow, Schlage

(Note: must order

appropiate IC

Housing)

Best/Falcon/

Arrow, Schlage

(Note: must order

appropiate IC

Housing)

Relay

Options yes yes yes yes yes yes yes yes yes yes yes no no yes no yes yes yes yes yes yes no yes yes yes

Battery/

Cycles Typical 5AA; 200000

or up to 5

years

5AA; 100000

or up to 3 - 4

years

5AA; 60000 5AA; 100000 5AA; 100000 5AA; 60000 5AA; 100000 5AA; 100000 5AA; 60000 5AA; 100000 5AA; 60000 5AA; 60000 5AA; 80,000 5AA; 100000 4 C cells

5 years

500,000

4 AA

3-4 years

600,000

4 C cells

5 years

500,000

4 C cells

5 years

500,000

2-3V Lithium,

100,000 2-3V Lithium,

80,000 5AA; 60000 5AA; 60000 5AA; 60000 4 C cells, 5

years/500,000 2-3V Lithium,

100,000 2-3V Lithium,

80,000 4 AA; 100,000

3-4 years 4 C cells

5 years

500,000

4 AA, 3 years

/ 100,000 (w/

Power Saver

Circuit)

4 AA, 3 years

/ 100,000 (w/

Power Saver

Circuit)

4 AA, 3 years

/ 100,000 (w/

Power Saver

Circuit)

4 AA, 3 years

/ 100,000 (w/

Power Saver

Circuit)

Ratings BHMA Grade

1 Lockset; 3hr.

Fire Rated UL

BHMA Grade

1 Lockset; 3hr.

Fire Rated UL

3hr. Fire

Rated UL BHMA Grade

1 Lockset; 3hr.

Fire Rated UL

BHMA Grade

1 Lockset; 3hr.

Fire Rated UL

BHMA Grade

1 Lockset; 3hr.

Fire Rated UL

BHMA Grade

1 Lockset; 3hr.

Fire Rated UL

3 Hr Fire

Rated UL 3 Hr Fire

Rated UL BHMA Grade

1 Lockset; 3hr.

Fire Rated UL

BHMA Grade

1 Lockset; 3hr.

Fire Rated UL

3 Hr Fire

Rated UL BHMA Grade

1 Lockset; 3hr.

Fire Rated UL

BHMA Grade

1 Lockset; 3hr.

Fire Rated UL

BHMA

Grade 1

Lockset; 3hr.

Fire Rated UL

3 Hr Fire

Rated UL 3 Hr Fire

Rated UL BHMA

Grade 1

Lockset; 3hr.

Fire Rated UL

3 Hr Fire Rated UL UL Pending BHMA Grade 1

Lockset; 3hr. Fire

Rated UL

BHMA Grade 1

Lockset; 3hr. Fire

Rated UL

BHMA Grade 1

Lockset; 3hr. Fire

Rated UL

BHMA Grade 1

Lockset; 3hr. Fire

Rated UL

Architectural

Finishes US26D, US3,

10B US26D, US3,

10B US26D, 10B US26D, 10B US26D, 10B US26D, 10B US10B,

US26D, MS,

US10B,

US26D, MS,

US26D, US3,

10B US26D, US3,

10B US26D, 10B US10B,

US26D, MS,

US10B, US26D,

MS, MB US26D, 10B US10B, US26D,

MS, MB US10B, US26D,

MS, MB US26D, 10B Customizable;

Std US26D, 10B Customizable;

Std US26D, 10B

Everyone involved in schools, from parents,

students and teachers to administrators and

facility managers, are actively looking for expert

solutions and actionable steps to secure their

K-12 or college/university. And, you can be that

expert provider. Better access control is one of the

best steps you can offer and they can truly use

today – right now. Here are some of our tiered

solutions for any application & budget:

Electronic Standalone Locking Solution

with Local Lock Down

Alarm Lock Trilogy P/DL 4100/4500 Series

• Simple push button locks door from inside, or use keyfob

• Activates small light indicators on front & back sides of door

• Includes bilingual signage on use and lock down

• Override option by authorized administrators

• No keys, key hassles; access controlled with ID card or

digital code (overridden in lockdown emergency)

• 1 Hours installation. Can be ﬁeld converted into Wireless

Networx Locks later with kit (as below)

• Grade 1 Durable, Vandal-Resistant All Metal Locks, for

inside & outdoors

Electronic Standalone Locking Solutions

with Keyfob & /or Panic Button Lock

Down

Trilogy Locks with Keyfob &/or Panic Option

Lock down classrooms, ofﬁces, common areas, labs

from safely inside, with the press of a button

• Rugged, easy to use and install electronic Trilogy locks

add access convenience & quickly retroﬁt any lockset on

virtually any door, inside or out.

• Easily add keyfob or panic button option to most new &

existing Trilogys (3000 Series & above) and program to

control “Lock Down” or “Remote Release” with one button.

• New DL2700LD model locks down with keyfobs from up to

75’ away, one supplied, and includes large indicator light

on inner door to conﬁrm lock-down is activated. (Weather

Resistant for outside applications, standard.)

Wireless Network Locking Solutions with

Global Lock Down

Trilogy Networx 6000, 8000 Series

Global Lockdown activated from the server or any

individual access lock, in under 10 seconds

• Deploy wireless networked access locks in under an hour

• ID Card and/or Digital Code Access (PIN)

• Real-time global lockdown or unlock in under 10 seconds

• Scalable by door, area, building or across a campus of

buildings, new & legacy

• Manage on-premises or remotely via web client or smart

device– Control access, privileges, locks and doors, by time

schedule, exception, etc.

• Grade 1 Durable, Unparalleled battery life, 5 years+

Small Wireless PIN/ID Card Keypad

Access System with Global Lock Down

Networx NetPanel & Wireless Keypad

Solution

Affordable Access System with Global Lock Down

• Supports up to 5000 PIN-code or ID card users

• Controls electric strike, Mag Lock or exit device with electric

latch retraction (ex. narrow stile glass doors).

• Operates 1 or 2 Networx Keypads, PIN-code or PIN & Prox

ID or supports standard Wiegand output Prox Readers.

• Inputs for Door-Position Switch and/or Remote Release

• Includes, rechargeable battery backup, 1.5amp power

supply, & plug in AC transformer.

• Top features: Global lockdown and passage from keypad

or PC; schedules; 35K event log, request-to-exit, door ajar/

kick-in, etc.

• Kits with Networx keypads or NetPanel only

Designer Access Control Networked

Locks with Strobe Indicator

ArchiTech N90L

Wireless Networked Access Locks with LocDown®

Keyfob-Activation & Emergency Strobe

• Standalone locks or locks networked campus-wide via

802.11 or Ethernet - Enterprise security integration, too

• Keyfob-Activated Lockdown & bright ﬂashing strobe

indicator on inside door gives security control & peace of

mind to occupants

• Lock down One Door or a Global Lock Group in seconds

from any keyfob on the system (each with programmable

access, lock- and unlock-privileges)

• Customizable, sleek minimalist look, choice of levers,

multi-technology access ID readers, in various colors,

shapes & architectural ﬁnishes

• Keyless access for up to 5000 users, w/ 500 Scheduled

Events & 36,000 Event Log.

PG21 Series

Easily stop any door from being

propped open, for innocent

and/or felonious reasons, i.e.,

for later reentry, etc.

pg 24

K-12 and Campus Security LocDown™ Solutions:

SAVI™ , the Security Access-Control Vulnerability Index™

is what we created for security professionals to use

as an objective, brand-agnostic audit tool to evaluate

any school’s access control vulnerability. You simply

survey what kinds of security they have in place, and SAVI

automatically calculates a score for them now. Then you

use that to create a plan of actionable next-steps you can

suggest and deploy, to improve their security and SAVI

score, ranging from adding ballistic glass or better gates, to

classroom intruder- or standalone digital access -locks with

lockdown function or keyfobs. Or, from adding networked

wireless locks with near-instantaneous global lockdown, to

implementing an access control systems for a few doors to

many, in real time.

Become a certiﬁed SAVI professional. We’ll show you

how. You’ll learn how to market, approach and make a posi-

tive impact in the educational market that so desperately

needs objective answers and your expertise. Call us

1-800-ALA-LOCK for training today or email

SAVI@alarmlock.com.

10-Second

Lockdown

Campuswide

FOR ALL OUR SCHOOL SOLUTIONS & REFERENCES go to www.savischool.com

Alarm Lock Training Classes are available locally in the eld

nationwide and online

• Get training for you and your staff on using the latest new technology,

installation & programming techniques, growth in new markets and

even earn factory-certication on Alarm Lock products from Trilogy

Standalone Locks, to Wireless Networked Networx Locks, Gateways and

our NetPanel. All Alarm Lock Classes are hands-on classes taught with

real-world applications and locking expertise.

• Online Webinar classes can be taken right from your computer: No gas

or travel required, and optionally, continuing ed. credits, without ever

leaving your ofce. They are presented live, and each is followed by a

Question & Answer Session.

• Previously-Recorded Webinars are available when you are, ideal as a refresher too, 24/7.

• Class schedule & to register visit www.alarmlock.com/seminars

• Training Videos on YouTube visit www.youtube.com/c/alarmlock

About Us

Alarm Lock Systems, LLC is a respected leader in the design and manufacture of commercial door technology solutions for over

four decades, specializing in access and egress solutions for education, healthcare, government, airports, corporations and mixed-use

environments Its popular Trilogy® line enables professionals securing buildings of all kinds to more cost-effectively and quickly add

dependable coded or ID-carded wireless access control a door at a time, with a dependable ﬁeld-proven access solution and a consistent

model for every door type in a facility (cylindrical, mortise, narrow stile/glass, privacy or double-sided).

Number One in their class for many years running, Trilogy® electronic access control locks, include original standalone digital and Prox

models, with built-in HID® or iClass™ Prox reader, new classroom lock-down keyfob-controlled locks, as well as wireless networking

Trilogy Networx™ access locks, featuring global lockdown in seconds , from a lock, server or keyfob and the elimination of door-to-door

programming and audit trail event queries by communicating wirelessly via ethernet or 802.11 , and Networx Gen.2 Gateways & Expanders

for greater range. Alarm Lock’s iLock® Smartphone App puts key-free, badge-free convenience on any smartphone/device using secure

BlueTooth LE™ communications with any Apple® or Android smart phone or tablet, too.. Blending with even the most demanding decor,

ArchiTech™ Networx Series are customizable with hundreds of trims, ﬁnishes, and reader designs for the ideal architecturally-elegant

access solution. All Trilogys feature the same rugged dependability, tool-free keypad programming and unsurpassed long battery life, with

cylindrical models boasting Grade 1 BHMA certiﬁcation. Alarm Lock Networx™ Prox ID and PIN Code Keypads and NetPanel 2-Door Access

Controller provide a wireless keypad solution for use with magnetic locks, strikes and electriﬁed exit devices. All programmable Alarm Lock

models share the same database, programming, scheduling and functionality and use Alarm Lock’s Free Windows-based software. Many

Networx & ArchiTech models can also be integrated within an enterprise security system platform,in real-time, as a single-door controllers

with Continental Access® CA4K, Lenel® OnGuard® Open Access Integration, and as a Software House® Connected Program Partner.

Grow with Alarm Lock’s Prot Center Program

Today’s electronic pushbutton locks offer considerable security, key-free consumer convenience and ease of retrotting standard door locks. Add to that more

stringent security needs, virtually everywhere, and the result has been that installations of standalone access control locks, with and without door-usage logging,

are increasingly in demand, with no end or slow down in sight. For those eager to enter this lucrative, booming market and expand and complement their

traditional offerings, Alarm Lock, the leader in electronic pushbutton access locks, has specially designed a program for retail locksmiths to tap this potential and

grow their business.

The Alarm Lock Prot Center Program offers retail locksmiths and their technicians FREE simple, step-by-step, eld-proven methods. Trained professionals teach

and guide locksmith/dealers exactly how to install, sell and compete effectively in this marketplace. Your technicians will become expert on the product, its

application and its marketing, through our comprehensive system of training seminars, joint sales calls and presentations to your customers! In simplest terms,

we’ve designed a program that will help you secure and grow your bottom line with us. To enroll in our Free “Prot Center Program” just contact your Alarm Lock

Sales Representative at 1-800-ALA-LOCK.

Standalone • Wireless • Enterprise Solutions

Alarm Lock Systems is a leader

in access and egress solutions

for education, healthcare,

multi-use commercial, retail,

transportation & industry. Field-

proven standalone Trilogy®

electronic keyless access locks,

provide access control with

PIN-code or built-in HID® Prox,

multi-technology or swipe

reader for ID badges. Wireless

Trilogy Networx™ access locks,

are easily networked using

Gateways and Expanders,

eliminating door-to-door

operations and featuring

global lockdown or unlock in

seconds, activated from any

lock or the computer network’s

server. ArchiTech™ Networx

Series take it a step farther

with hundreds of customizable

trims, finishes, and readers for

the ideal architecturally-elegant

access solution and offer iLock®

App mobile solution. Both lines

feature keyfob and remote

button support; plus free

Windows-based or enterprise

software options; and models

for every application & budget.

345 Bayview Avenue Amityville, NY 11701 USA • 1-800-ALA-LOCK • 631-789-4871 • Fax: 631-789-3383

Alarm Lock Systems, LLC is a Division of NAPCO Security Technologies, Inc.

Trilogy, Sirenlock, Networx, ArchiTech, SAVI / School Access-Control Vulnerability Index, iLock and CA4K are trademarks of Alarm Lock/Napco. All others are trademarks of their respective companies.

Alarm Lock Product Catalog ALA112U 2019

Navigation menu

Versions of this User Manual:

Views

Navigation
