ALPCI2-U

DL-Windows Communication Interface Cable

INSTALLATION INSTRUCTIONS

GENERAL DESCRIPTION

The ALPCI2-U is an interface cable that allows high

speed communication between a PC running DL-

Windows software and a compatible Trilogy Digital Lock

or an AL-DTM Data Transfer Module. Using the ALP-

CI2-U cable, the PC can upload or download program-

ming to / from the lock, and upload event history. Com-

patible with all Trilogy Digital Locking devices equipped

with data ports.

SPECIFICATIONS

Input Power: Supplied by the PC

Dimensions: 3⅛"L x ½"H x ⅞"W with 52" cord

Also supplied with a USB extension cable (for computers

with USB sockets positioned in very close proximity).

SYSTEM REQUIREMENTS

For optimal performance, the following minimum require-

ments are recommended:

• Supported operating systems: Windows XP Service

Pack 3, Windows 7, 32-Bit and 64-Bit Systems

• Processor: 1 GHz or faster minimum (2GHz or faster

is recommended)

• RAM: 1GB or more is recommended

• Hard Disk Space: 1GB or more is recommended

• DL-Windows software

• One unused USB Communications Port (see

DRIVER INSTALLATION).

DRIVER INSTALLATION

1. Insert the "ALPCI2-U Drivers" CD into the CD drive

of your PC.

2. The CD should AutoRun; if not, explore the files on

the CD. Open the folder named

"CP210x_VCP_Windows".

For 32-bit operating systems, run the file

"CP210xVCPInstaller_x86.exe" by double-clicking

it.

For 64-bit operating systems, run the file

"CP210xVCPInstaller_x64.exe".

3. In the window that appears, click Next, click the radio

button to accept the License Agreement and click

Next again. The appropriate drivers for your operat-

ing system will install.

4. When the message indicates that the drivers are suc-

cessfully installed on your PC, click Finish to exit

WI2069A 01/14

345 Bayview Avenue

Amityville, New York 11701

For Sales and Repairs 1-800-ALA-LOCK

For Technical Service 1-800-645-9440

or visit us at http://tech.napcosecurity.com/

(Note: Technical Service is for security professionals only)

Publicly traded on NASDAQ Symbol: NSSC

© ALARM LOCK 2014

NOTE: Observe

Tab direction when

inserting plug

(+ Red) (– Black).

Windows-Compatible

Laptop or PC

ALPCI2-U

LA3125A

ALARM LOC K

ALPCI2-U

(+)

(–)

To USB

Windows-Compatible

Laptop or PC

NOTE: Observe

Tab direction when

inserting plug

(+ Red) (– Black).

ALPCI2-U

LA3125A

ALARM LOC K

ALPCI2-U

(+)

(–)

To USB

AL-DTM3

Trilogy® is a registered trademark of Alarm Lock Windows is a trademark of Microsoft
