Simon XT/XTi Module | Installation Guide
Simon XT/XTi Z-Wave Module
INSTALLATION GUIDE
Introduction
The module with firmware version 172 for Simon XT and XTi features
integrated support for Alarm.com’s emPower
TM
solution with built-in Z-Wave
capabilities.
The module interfaces with the Simon XT and XTi panel boards, fits into a
special compartment inside the panel, and is powered by the control panel
and panel battery.
Contact Information
For additional information and support on Alarm.com products and services,
please visit www.alarm.com/dealer or contact Alarm.com technical support
at 1-866-834-0470.
Copyright © 2012 Alarm.com. All rights reserved.
Compatibility
The Alarm.com module with firmware version 172 is compatible with Simon
XT and XTi panels.
Power Up
Reconnect panel battery and AC power. When the Alarm.com module is
connected to a powered control panel, the LEDs at the bottom of the module
will become active (see Table 1 on page 4). It may take a few moments after
power up for the LEDs to become active. If the LEDs do not light up at all,
ensure that the module has been fully inserted into the connector beneath it
then perform a full power cycle by following these steps:
1) Disconnect the battery leads and unplug the panel power transformer
from AC power.
2) Verify that the module is inserted securely and that the antenna is
snapped-in completely.
3) Connect battery leads to the battery. On the XT, make sure to observe
polarity (red to + and black to –) and to keep the wires outside of the tab
holding them in place.
4) Plug the panel power transformer into the AC outlet.
It is important to plug the battery in before plugging in the transformer,
otherwise the panel will issue a “System Low Battery” message regardless of
the battery voltage level.
Troubleshooting LEDs
Status LEDs indicate z-wave network information
LED L2 (yellow)
L2 flashes with every communication between the module and the panel.
Normal pattern calls for a series of quick flashes every two seconds in Idle
Mode or four seconds in PowerSave Mode.
It also occasionally flashes in patterns to indicate Z-Wave status. See the
table for a description of various possibilities.
Table 4: Z-wave LED status indicators
LED 2 LED 5 Device status or error Description
4-blink Add mode (lasts 120
seconds or until a device
is added)
In this mode you can add a
device to the local Z-Wave
network. Devices cannot be
added to a network if they
are already a part of a
network
2-blink Delete mode (lasts 120
seconds or until a device
is deleted)
In this mode you can delete a
device from a Z-Wave
network. A device can only
be in one network at a time,
and must receive a “delete”
command before it can be
learned into a new network
Solid Successful add
node/remove
node/replication (lasts
60 seconds)
After receiving this signal
leave all devices by the HSPA
module for 1 minute. Locks
must be left next to the
module for 4 minutes
Solid
with
one
blink
Add node attempt failed
because node already in
network (lasts 60
seconds)
Device you attempted to add
to a network is already in a
network, and must be
“deleted” before it can join a
new network
2-blink No other nodes are in
the network (lasts until a
device is added to the
network)
No devices have been added
that can be controlled by the
HSPA module yet. See above
for instructions on how to
add devices
5-blink Learn mode error (lasts
60 seconds)
The device was not
successfully added to the Z-
Wave network.
6-blink No Home ID present
(lasts until the module
connects to Alarm.com
and is configured)
When the HSPA module first
connects to Alarm.com it is
configured with a necessary
unique network ID
LED L5 (yellow)
L5 indicates Z
Specifications
Compatible
Simon XT panels with software versions 0.0.H and
later and Simon XTi.
Power requirements 6V nominal
Standby current 30mA (10mA in power save mode)
Peak current 1.7 A
Operating temperature 32 to 120°F (0 to 49°C)
Storage temperature -30 to 140°F (-34 to 60°C)
Max. relative humidity 90% non-condensing
Dimensions (H x W) 4 1/16 x 1 7/8 in.
Copyright © 2012 Alarm.com | www.alarm.com | v1.3
2
Simon XT/XTi Module | Installation Guide
Regulatory Information
Changes or modifications not expressly approved by Alarm.com can void the
user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different form that
which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help.
Operation is subject to the following two conditions:
(1) This device may not cause interference
(2) This device must accept any interference, including interference that may
cause undesired operation of the device
This equipment complies with the FCC RF radiation exposure limits set forth
for an uncontrolled environment. This equipment should be installed and
operated with a minimum distance of 20 centimeters between the radiator
and your body.
FCC ID: YL6-143200H5V4, IC: 9111A-143200H5V4
