Alarm com orporated 143450L Z-Wave adds remote control to home automation and security systems User Manual

Alarm.com Incorporated Z-Wave adds remote control to home automation and security systems

User Manual

Rhein Tech Laboratories, Inc. Client: Alarm.com
360 Herndon Parkway Model: ADC-450L
Suite 1400 Standards: FCC 15.249/IC RSS-210
Herndon, VA 20170 IDs: YL6-143450L/9111A-143450L
http://www.rheintech.com Report #: 2014100
Page 35 of 46
Appendix M: Manual
Please refer to the following pages.
Copyright © 2014 Alarm.com | www.alarm.com | v3.1
1
Simon XT/XTi Module | Installation Guide
Simon XT/XTi Module
INSTALLATION GUIDE
Introduction
This Module with firmware version 172 for Simon XT and XTi features
integrated support for Alarm.com’s emPowerTM solution with built-in Z-Wave
capabilities.
The module interfaces with the Simon XT and XTi panel boards, fits into a
special compartment inside the panel, and is powered by the control panel
and panel battery.
Contact Information
For additional information and support on Alarm.com products and services,
please visit www.alarm.com/dealer or contact Alarm.com technical support
at 1-866-834-0470.
Copyright © 2014 Alarm.com. All rights reserved.
Compatibility
The Alarm.com module with firmware version 172 is compatible with Simon
XT and XTi panels.
Power Up
Reconnect panel battery and AC power. When the Alarm.com module is
connected to a powered control panel, the LEDs at the bottom of the module
will become active (see Table 1 on page 4). It may take a few moments after
power up for the LEDs to become active. If the LEDs do not light up at all,
ensure that the module has been fully inserted into the connector beneath it
then perform a full power cycle by following these steps:
1) Disconnect the battery leads and unplug the panel power transformer
from AC power.
2) Verify that the module is inserted securely and that the antenna is
snapped-in completely.
3) Connect battery leads to the battery. On the XT, make sure to observe
polarity (red to + and black to –) and to keep the wires outside of the tab
holding them in place.
4) Plug the panel power transformer into the AC outlet.
It is important to plug the battery in before plugging in the transformer,
otherwise the panel will issue a “System Low Battery” message regardless of
the battery voltage level.
Troubleshooting LEDs
Status LEDs indicate network and module status.
LED L2 (yellow)
L2 flashes with every communication between the module and the panel.
Normal pattern calls for a series of quick flashes every two seconds in Idle
Mode or four seconds in PowerSave Mode.
It also occasionally flashes in patterns to indicate Z-Wave status. See the
table below for a description of various possibilities.
Table 4: Z-wave LED status indicators
LED 2
LED 5
Device status or error
Description
4-blink
Add Mode (lasts 120
seconds or until a device
is added)
In this mode you can add a
device to the local Z-Wave
network. Devices cannot be
added to a network if they
are already a part of a
network
2-blink
Delete Mode (lasts 120
seconds or until a device
is deleted)
In this mode you can delete a
device from a Z-Wave
network. A device can only
be in one network at a time,
and must receive a “delete”
command before it can be
learned into a new network
Solid
Successful add
node/remove
node/replication (lasts
60 seconds)
After receiving this signal
leave all devices by the
Alarm.com module for 1
minute. Locks must be left
next to the module for 4
minutes
Solid
with
one
blink
Add node attempt failed
because node already in
network (lasts 60
seconds)
Device you attempted to add
to a network is already in a
network, and must be
“deleted” before it can join a
new network
2-blink
No other nodes are in
the network (lasts until a
device is added to the
network)
No devices have been added
that can be controlled by the
Alarm.com module yet. See
above for instructions on
how to add devices
5-blink
Learn mode error (lasts
60 seconds)
The device was not
successfully added to the Z-
Wave network.
6-blink
No Home ID present
(lasts until the module
connects to Alarm.com
and is configured)
When the Alarm.com module
first connects to Alarm.com it
is configured with a
necessary unique network ID
Specifications
Compatible
Power requirements
Standby current
Peak current
Operating temperature
Storage temperature
Max. relative humidity
Dimensions
Copyright © 2014 Alarm.com | www.alarm.com | v3.1
2
Simon XT/XTi Module | Installation Guide
Regulatory Information
Changes or modifications not expressly approved by Alarm.com can void the
user’s authority to operate the equipment.
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux
conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2)
l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le fonctionnement.
FCC ID: YL6-143450L, IC: 9111A-143450L
