![](asset-1.png)
5020
5020A
5020D
5020E
For more information on how to use the phone, please go to www.alcatelonetouch.com and download the complete
user manual. Moreover, on the website, you can also find answers to frequently asked questions, upgrade the software
via ONE TOUCH Upgrade, and so much more.
5021E
1 2
Table of Contents
Safety and use ............................................................................4
General information ...............................................................16
1 Your mobile .......................................................................18
1.1 Keys and connectors ................................................................................18
1.2 Getting started ..........................................................................................21
1.3 Home screen ..............................................................................................25
1.4 Applications and widgets list ..................................................................35
2 Text input ...........................................................................36
2.1 Using Onscreen Keyboard ......................................................................36
2.2 Text editing .................................................................................................38
3 Phone call, Call log and Contacts ....................................39
3.1 Phone ...........................................................................................................39
3.2 Call log .........................................................................................................46
3.3 People ..........................................................................................................46
4 Messaging, Email ...............................................................54
4.1 Messaging ....................................................................................................54
4.2 Gmail/Email .................................................................................................62
4.3 Google Talk .................................................................................................67
5 Calendar & Alarm clock & Calculator ............................71
5.1 Calendar ......................................................................................................71
5.2 Clock ............................................................................................................73
5.3 Calculator ....................................................................................................75
6 Getting connected ............................................................77
6.1 Connecting to the Internet ....................................................................77
6.2 Browser .......................................................................................................80
6.3 Connecting to Bluetooth devices ........................................................87
6.4 Connecting to a computer .....................................................................89
6.5 Sharing your phone's mobile data connection ...................................89
6.6 Connecting to virtual private networks ..............................................91
6.7 Configuring Internet (SIP) calling .........................................................92
7 Google Play Store ............................................................94
7.1 Locate the item you want to download and install ..........................94
7.2 Download and install ................................................................................95
7.3 Manage your downloads ..........................................................................97
8 Multimedia applications ...................................................99
8.1 Camera ........................................................................................................99
8.2 Gallery .......................................................................................................102
8.3 YouTube .....................................................................................................105
8.4 Music ..........................................................................................................106
8.5 Video Player ..............................................................................................108
9 Google Maps ....................................................................109
9.1 Get My Location .....................................................................................109
9.2 Search for a location ..............................................................................110
9.3 Star a location ..........................................................................................110
9.4 Get driving, public transportation or walking directions...............111
9.5 Arrangement of Layers ..........................................................................113
9.6 Join Latitude to see your friends' locations and share
yours with them ......................................................................................114
10 Others ..............................................................................117
10.1 File Manager .............................................................................................117
10.2 Sound Recorder ......................................................................................117
Note:
This is a shared user manual for one touch 5020A/one touch 5020D/one touch
5020E/one touch 5020X/one touch 5021E specifying SIM information where
relevant.
![](asset-3.png)
3 4
www.sar-tick.com
This product meets applicable national SAR limits of
2.0W/kg. The specific maximum SAR values can be
found on page 8 of this user guide.
When carrying the product or using it while worn
on your body, either use an approved accessory such
as a holster or otherwise maintain a distance of 1.5
cm from the body to ensure compliance with RF
exposure requirements. Note that the product may
be transmitting even if you are not making a phone
call.
10.3 Radio ..........................................................................................................118
10.4 Setup Wizard ...........................................................................................119
10.5 Alcatel Help .............................................................................................120
10.6 Other applications .................................................................................120
11 Settings ............................................................................121
11.1 Wireless & networks .............................................................................121
11.2 Device ........................................................................................................124
11.3 Personal .....................................................................................................128
11.4 Accounts ...................................................................................................137
11.5 System ........................................................................................................137
12 Making the most of your phone ....................................144
12.1 ONE TOUCH Manager .........................................................................144
12.2 Upgrade .....................................................................................................145
13 Telephone warranty ........................................................147
14 Accessories .....................................................................149
15 Troubleshooting ..............................................................150
16 Specifications ...................................................................155
Safety and use ..............................
We recommend that you read this chapter carefully before using your phone. The
manufacturer disclaims any liability for damage, which may result as a consequence of
improper use or use contrary to the instructions contained herein.
• TRAFFIC SAFETY:
Given that studies show that using a mobile phone while driving a vehicle constitutes
a real risk, even when the hands-free kit is used (car kit, headset...), drivers are
requested to refrain from using their mobile when the vehicle is not parked.
When driving, do not use your phone and headphone to listen to music or to the
radio. Using a headphone can be dangerous and forbidden in some areas.
When switched on, your phone emits electromagnetic waves that can interfere with
the vehicle’s electronic systems such as ABS anti-lock brakes or airbags. To ensure
that there is no problem:
- do not place your phone on top of the dashboard or within an airbag deployment
area,
- check with your car dealer or the car manufacturer to make sure that the
dashboard is adequately shielded from mobile phone RF energy.
• CONDITIONS OF USE:
You are advised to switch off the telephone from time to time to optimise its
performance.
Switch the phone off before boarding an aircraft.
Switch the phone off when you are in health care facilities, except in designated
areas. As with many other types of equipment now in regular use, mobile telephones
can interfere with other electrical or electronic devices, or equipment using radio
frequency.
Switch the phone off when you are near gas or flammable liquids. Strictly obey all
signs and instructions posted in a fuel depot, petrol station, or chemical plant, or in
any potentially explosive atmosphere.
When the phone is switched on, it should be kept at least 15 cm from any medical
device such as a pacemaker, a hearing aid or insulin pump, etc. In particular when
using the phone, you should hold it against the ear on the opposite side to the
device, if any.
To avoid hearing impairment, pick up the call before holding your phone to your
ear. Also move the handset away from your ear while using the “hands-free” mode
because the amplified volume might cause hearing damage.
![](asset-4.png)
5 6
Do not let children use the phone and/or play with the telephone and accessories
without supervision.
When replacing the cover please note that your phone may contain substances that
could create an allergic reaction.
Always handle your phone with care and keep it in a clean and dust-free place.
Do not allow your phone to be exposed to adverse weather or environmental
conditions (moisture, humidity, rain, infiltration of liquids, dust, sea air, etc). The
manufacturer’s recommended operating temperature range is -10°C to +55°C.
At over 55°C the legibility of the phone’s display may be impaired, though this is
temporary and not serious.
Emergency call numbers may not be reachable on all cellular networks. You should
never rely only on your phone for emergency calls.
Do not open, dismantle or attempt to repair your mobile phone yourself.
Do not drop, throw or bend your mobile phone.
Do not use the phone if the glass made screen is damaged, cracked or broken to
avoid any injury.
Do not paint it.
Use only batteries, battery chargers, and accessories which are recommended by
TCT Mobile Limited and its affiliates and are compatible with your phone model. TCT
Mobile Limited and its affiliates disclaim any liability for damage caused by the use of
other chargers or batteries.
Remember to make back-up copies or keep a written record of all important
information stored in your phone.
Some people may suffer epileptic seizures or blackouts when exposed to flashing
lights, or when playing video games. These seizures or blackouts may occur even if
a person never had a previous seizure or blackout. If you have experienced seizures
or blackouts, or if you have a family history of such occurrences, please consult your
doctor before playing video games on your phone or enabling a flashing-lights feature
on your phone.
Parents should monitor their children’s use of video games or other features that
incorporate flashing lights on the phones. All persons should discontinue use and
consult a doctor if any of the following symptoms occur: convulsion, eye or muscle
twitching, loss of awareness, involuntary movements, or disorientation. To limit the
likelihood of such symptoms, please take the following safety precautions:
- Do not play or use a flashing-lights feature if you are tired or need sleep.
- Take a minimum of a 15-minute break hourly.
- Play in a room in which all lights are on.
- Play at the farthest distance possible from the screen.
- If your hands, wrists, or arms become tired or sore while playing, stop and rest for
several hours before playing again.
- If you continue to have sore hands, wrists, or arms during or after playing, stop the
game and see a doctor.
When you play games on your phone, you may experience occasional discomfort
in your hands, arms, shoulders, neck, or other parts of your body. Follow the
instructions to avoid problems such as tendinitis, carpal tunnel syndrome, or other
musculoskeletal disorders.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high volume levels for
long periods. Exercise caution when holding your device near your ear while
the loudspeaker is in use.
• PRIVACY:
Please note that you must respect the laws and regulations in force in your
jurisdiction or other jurisdiction(s) where you will use your mobile phone regarding
taking photographs and recording sounds with your mobile telephone. Pursuant to
such laws and regulations, it may be strictly forbidden to take photographs and/or to
record the voices of other people or any of their personal attributes, and duplicate
or distribute them, as this may be considered to be an invasion of privacy. It is the
user's sole responsibility to ensure that prior authorisation be obtained, if necessary,
in order to record private or confidential conversations or take a photograph
of another person; the manufacturer, the seller or vendor of your mobile phone
(including the operator) disclaim any liability which may result from the improper
use of the mobile phone.
• BATTERY:
Before removing the battery from your phone, please make sure that the phone is
switched off.
Observe the following precautions for battery use:
- Do not attempt to open the battery (due to the risk of toxic fumes and burns).
- Do not puncture, disassemble or cause a short-circuit in a battery.
- Do not burn or dispose of a used battery in household rubbish or store it at
temperatures above 60°C.
Batteries must be disposed of in accordance with locally applicable environmental
regulations. Only use the battery for the purpose for which it was designed. Never
use damaged batteries or those not recommended by TCT Mobile Limited and/or
its affiliates.
![](asset-5.png)
7 8
This symbol on your telephone, the battery and the accessories means that
these products must be taken to collection points at the end of their life:
- Municipal waste disposal centres with specific bins for these items of
equipment
- Collection bins at points of sale.
They will then be recycled, preventing substances being disposed of in the
environment, so that their components can be reused.
In European Union countries:
These collection points are accessible free of charge.
All products with this sign must be brought to these collection points.
In non European Union jurisdictions:
Items of equipment with this symbol are not to be thrown into ordinary bins if your
jurisdiction or your region has suitable recycling and collection facilities; instead they
are to be taken to collection points for them to be recycled.
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
• CHARGERS
Mains powered chargers will operate within the temperature range of: 0°C to 40°C.
The chargers designed for your mobile phone meet with the standard for safety of
information technology equipment and office equipment use. They are also compliant
to the ecodesign directive 2009/125/EC. Due to different applicable electrical
specifications, a charger you purchased in one jurisdiction may not work in another
jurisdiction. They should be used for this purpose only.
• RADIO WAVES:
Proof of compliance with international standards (ICNIRP) or with European
Directive 1999/5/EC (R&TTE) is required of all mobile phone models before they
can be put on the market. The protection of the health and safety for the user and
any other person is an essential requirement of these standards or this directive.
THIS DEVICE MEETS INTERNATIONAL GUIDELINES FOR EXPOSURE TO
RADIO WAVES.
Your mobile device is a radio transmitter and receiver. It is designed not to exceed
the limits for exposure to radio waves (radio frequency electromagnetic fields)
recommended by international guidelines. The guidelines were developed by an
independent scientific organization (ICNIRP) and include a substantial safety margin
designed to assure the safety of all persons, regardless of age and health.
The radio wave exposure guidelines use a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit for mobile devices is 2 W/kg.
Tests for SAR are conducted using standard operating positions with the device
transmitting at its highest certified power level in all tested frequency bands. The
highest SAR values under the ICNIRP guidelines for this device model are:
ONE TOUCH 5020X:
Maximum SAR for this model and conditions under which it was
recorded.
Head SAR GSM 900 + Wi-Fi + Bluetooth 0.773 W/kg
Body-Worn SAR GSM 900 + Wi-Fi + Bluetooth 1.050 W/kg
ONE TOUCH 5020A & 5020E:
Maximum SAR for this model and conditions under which it was
recorded.
Head SAR GSM 900 + Wi-Fi + Bluetooth 0.524 W/kg
Body-Worn SAR GSM 900 + Wi-Fi + Bluetooth 0.874 W/kg
ONE TOUCH 5020D:
Maximum SAR for this model and conditions under which it was
recorded.
Head SAR GSM 900 + Wi-Fi + Bluetooth 0.773 W/kg
Body-Worn SAR GSM 900 + Wi-Fi + Bluetooth 1.050 W/kg
ONE TOUCH 5021E:
Maximum SAR for this model and conditions under which it was
recorded.
Head SAR GSM 900 + Wi-Fi + Bluetooth 0.578 W/kg
Body-Worn SAR GSM 900 + Wi-Fi + Bluetooth 0.874 W/kg
During use, the actual SAR values for this device are usually well below the values
stated above. This is because, for purposes of system efficiency and to minimize
interference on the network, the operating power of your mobile device is
automatically decreased when full power is not needed for the call. The lower the
power output of the device, the lower its SAR value.
![](asset-6.png)
9 10
Body-worn SAR testing has been carried out at a separation distance of 1.5 cm.
To meet RF exposure guidelines during body-worn operation, the device should
be positioned at least this distance away from the body. If you are not using an
approved accessory ensure that whatever product is used is free of any metal and
that it positions the phone the indicated distance away from the body.
Organizations such as the World Health Organization and the US Food and Drug
Administration have stated that if people are concerned and want to reduce their
exposure they could use a hands-free device to keep the phone away from the head
and body during phone calls, or reduce the amount of time spent on the phone.
For more information you can go to www.alcatelonetouch.com
Additional information about electromagnetic fields and public health are available on
the following site: http://www.who.int/peh-emf.
Your telephone is equipped with a built-in antenna. For optimal operation, you should
avoid touching it or degrading it.
As mobile devices offer a range of functions, they can be used in positions other
than against your ear. In such circumstances the device will be compliant with
the guidelines when used with headset or usb data cable. If you are using another
accessory ensure that whatever product is used is free of any metal and that it
positions the phone at least 1.5 cm away from the body.
5020A:
• Regulatory information
The following approvals and notices apply in specific regions as noted.
![](asset-7.png)
11 12
5020D: 5020E:
![](asset-8.png)
13 14
5020X: 5021E:
![](asset-9.png)
15 16
• LICENCES
microSD Logo is a trademark.
The Bluetooth word mark and logos are owned by the Bluetooth
SIG, Inc. and any use of such marks by TCT Mobile Limited and its
affiliates is under license. Other trademarks and trade names are
those of their respective owners.
ONE TOUCH 5020A/ONE TOUCH
5020D/ONE TOUCH 5020E/ONE
TOUCH 5020X/ONE TOUCH 5021E
Bluetooth QD ID B020261
TouchPal™ and CooTek™ are trademarks of Shanghai HanXiang
(CooTek)Information Technology Co., Ltd. and/or its Affiliates.
The Wi-Fi Logo is a certification mark of the Wi-Fi Alliance.
Google, the Google logo, Android, the Android logo, Google Search TM,
Google MapsTM, Gmail TM, YouTube, Android Market, Google Latitude TM
and Google Talk TM are trademarks of Google Inc.
You have purchased a product which uses the open source
(http://opensource.org/) programs mtd, msdosfs, netfilter/iptables
and initrd in object code and other open source programs licensed
under the GNU General Public License and Apache License.
We will provide you with a complete copy of the corresponding
source codes upon request within a period of three years from the
distribution of the product by TCT.
You may download the source codes from http://sourceforge.net/
projects/alcatel/files/. The provision of the source code is free of
charge from internet.
General information ...................
• Internet address: www.alcatelonetouch.com
• Hot Line Number: see “TCT Mobile Services” leaflet or go to our website.
• Address: Room 1910-12A, Tower 3, China HK City, 33 Canton Road,
Tsimshatsui, Kowloon, Hong Kong
On our website, you will find our FAQ (Frequently Asked Questions) section. You
can also contact us by e-mail to ask any questions you may have.
An electronic version of this user guide is available in English and other languages
according to availability on our server: www.alcatelonetouch.com
Your telephone is a transceiver that operates on GSM in quad-band
(850/900/1800/1900MHz) or UMTS in dual band with 900/2100MHz for one touch
5020D/one touch 5020X, tri-band with 850/1900/2100 for one touch 5020A/one
touch 5020E/one touch 5021E.
This equipment is in compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC. The entire copy of the Declaration of Conformity
for your telephone can be obtained through our website: www.alcatelonetouch.com.
Protection against theft (1)
Your telephone is identified by an IMEI (phone serial number) shown on the
packaging label and in the phone’s memory. We recommend that you note the
number the first time you use your telephone by entering * # 0 6 # and keep it in
a safe place. It may be requested by the police or your operator if your telephone is
stolen. This number allows your mobile telephone to be blocked preventing a third
person from using it, even with a different SIM card.
(1) Contact your network operator to check service availability.
![](asset-a.png)
17 18
1 Your mobile ..........................
1.1 Keys and connectors
Headset connector
Power key
Back key
Front camera
Home key
Recent
apps key
Touch screen
Disclaimer
There may be certain differences between the user manual description and the
phone’s operation, depending on the software release of your telephone or specific
operator services.
TCT Mobile shall not be held legally responsible for such differences, if any, nor for
their potential consequences, which responsibility shall be borne by the operator
exclusively.
This handset may contain materials, including applications and software in executable
or source code form, which is submitted by third parties for inclusion in this handset
(“Third Party Materials”). All third party materials in this handset are provided “as
is”, without warranty of any kind, whether express or implied, including the implied
warranties of merchantability, fitness for a particular purpose or use/third party
application, interoperability with other materials or applications of the purchaser
and non-infringement of copyright. The purchaser undertakes that TCT Mobile has
complied with all quality obligations incumbent upon it as a manufacturer of mobile
devices and handsets in complying with Intellectual Property rights. TCT Mobile will
at no stage be responsible for the inability or failure of the Third Party Materials to
operate on this handset or in interaction with any other devices of the purchaser.
To the maximum extent permitted by law, TCT Mobile disclaims all liability for any
claims, demands, suits or actions, and more specifically – but not limited to – tort
law actions, under any theory of liability, arising out of the use, by whatever means,
or attempts to use, such Third Party Materials. Moreover, the present Third Party
Materials, which are provided free of charge by TCT Mobile, may be subject to
paid updates and upgrades in the future; TCT Mobile waives any responsibility
regarding such additional costs, which shall be borne exclusively by the purchaser.
The availability of the applications may vary depending on the countries and the
operators where the handset is used; in no event shall the list of possible applications
and software provided with the handsets be considered as an undertaking from
TCT Mobile; it shall remain merely as information for the purchaser. Therefore,
TCT Mobile shall not be held responsible for the lack of availability of one or more
applications wished for by the purchaser, as its availability depends on the country
and the operator of the purchaser. TCT mobile reserves the right at any time to add
or remove Third Party Materials from its handsets without prior notice; in no event
shall TCT Mobile be held responsible by the purchaser for any consequences that
such removal may have on the purchaser regarding the use or attempt to use such
applications and Third Party Materials.
![](asset-b.png)
19 20
Back key
• Touch to go back to the previous screen, or to close a dialog
box, options menu, the notification panel, etc.
These keys are visible when the screen lights up.
Power key
• Press: Lock the screen/Light up the screen
• Press and hold: Show the pop-up menu to select from Power
off/Restart/Airplane mode/Quick start
Press and hold: Power on
• Press and hold Power key and Volume down key to capture
a screenshot.
• Press to mute the ringtone when there’s an incoming call.
• Press to end the current conversation during a call.
Volume Keys
• Under call mode, adjust the earpiece or headset volume.
• In Music/Video/Streaming mode, adjust the media volume.
• In general mode, adjust the ringtone volume.
• Mute the ringtone of an incoming call.
• In Camera mode, using it as the capture key allows you to
take a photo and start or stop recording a video.
• Press to light up the screen when it dims during a call.
Volume up
Volume down
Camera
Micro-USB
connector
Recent apps key
• Open a list of thumbnail images of apps you've worked with
recently. Touch it to open an app. Swipe it left or right to
remove a thumbnail from the list.
• Touch and hold: As Menu key, touch and hold it to access
Wallpaper, Manage applications and Settings.
Home key
• While on any application or screen, touch to return to the
Home screen.
![](asset-c.png)
21 22
To install, insert SIM1 into the slot on the right side with SIM chip facing
downwards, and then insert SIM2 into the slot on the left side with SIM
chip facing downwards. To remove the card, gently press it out.
For dual SIM models, both SIM1 and SIM2 can support 2G and 3G
networks.
Installing or removing the battery
Please power off your phone before removing the battery.
• Insert and click the battery into place, then close the phone cover.
• Unclip the cover, then remove the battery.
Installing or removing the microSD card
Insert the external microSD card into the slot with the gold contact facing
down. To remove the external microSD card, gently press and slide it out.
1.2 Getting started
1.2.1 Set-up
Removing or installing the back cover
Inserting or removing the SIM card
You must insert your SIM card to make phone calls. Please power off your
phone before inserting or removing the SIM card.
ONE TOUCH 5020A/ONE TOUCH 5020X
ONE TOUCH 5020D/ONE TOUCH 5020E/ONE TOUCH 5021E
![](asset-d.png)
23 24
Set up your phone for the first time
The first time you power on the phone, you should set the following
options:
• Touch Get started..., then select the phone's language.
• The device will search for service by itself. The process of activation will
take a few minutes
• Select your input keyboard, then touch Next.
• Select SIM you want to use, then touch Next.
• Set your date and timezone, you can also choose Automatic time zone,
then touch Next.
• Setup your Google account: Touch Set up now. If you have
a Google Account, touch Sign in, then enter your user name and
password. If you forget your password, you can go to http://www.
google.com/ to retrieve it. If you don’t own a Google Account, you are
prompted to create one by touching Get an account. Touch Not now
to skip to the next step.
• Touch Next ,then the Setup complete screen will display, touch Finish
to confirm.
When the phone is powered on, you can connect to a Wi-Fi network,
without a SIM card inserted (refer to section "6.1.2 Wi-Fi"), to sign into
your Google account and to use some features.
1.2.3 Power off your phone
Hold down the Power key until the pop-up menu appears, select Power
off, and touch OK to confirm.
Charging the battery
Connect the battery charger to your phone, then the charging icon will
show on the right of status bar.
• Make sure the battery is correctly inserted before connecting the
charger.
• When using your telephone for the first time, charge the battery fully
(approximately 5 hours).
You are advised to fully charge the battery ( ). Charging status is
indicated by the percentage on screen while the phone is powered off. The
percentage increases as the phone is charged.
The charging status bar will not float if your battery is extensively
consumed. To reduce power consumption and energy waste, when
battery is fully charged, disconnect your charger from the plug; switch
off Wi-Fi, GPS, Bluetooth or background-running applications when
not in use; reduce the backlight time, etc.
1.2.2 Power on your phone
Hold down the Power key until the phone powers on, unlock your phone
(Slide, PIN, password, pattern) if necessary and confirm. The Home screen
is displayed.
If you do not know your PIN code or if you have forgotten it, contact your
network operator. Do not leave your PIN code with your phone. Store
this information in a safe place when not in use.
![](asset-e.png)
25 26
Touch and Hold
Touch and hold the home screen to access the available options for setting
the wallpaper.
Drag
Place your finger on any item to drag it to another location.
Slide/Swipe
Slide the screen to scroll up and down the applications, web pages… at
your convenience.
Flick
Similar to swiping, but flicking makes it move quicker.
Pinch/Spread
Place your fingers of one hand on the screen surface and draw them apart
or together to scale an element on the screen.
Rotate
Automatically change the screen orientation from portrait to landscape by
turning the phone sideways to have a better screen view.
1.3.2 Status bar
From status bar, you can view both phone status (to the right side) and
notification information (to the left side).
1.3 Home screen
You can bring all the items (applications, shortcuts, folders and widgets)
you love or use most frequently to your Home screens for quick access.
Touch the Home key to switch to the Home screen.
Status bar
• Status/Notification indicators
• Touch and drag down to open the
notification panel.
Application tab
• Touch to open main menu.
Search bar
• Touch to enter text search screen.
• Touch to enter voice search screen.
Favorite tray applications
• Touch to enter the application.
• Touch and hold to move or
change applications.
Home screen is provided in an extended format to allow more space for
adding applications, shortcuts etc. Slide the Home screen horizontally left
and right to get a complete view of the Home screen. The white short line
at the lower part of the screen indicates which screen you are viewing.
1.3.1 Using the touchscreen
Touch
To access an application, touch it with your finger.
![](asset-f.png)
27 28
Notification icons
New text or multimedia
message Missed call
Problem with SMS or MMS
delivery Call on hold
New Google Talk message Call forwarding is on
New voicemail Uploading data
Upcoming event Downloading data
Data is synchronizing Download finished
Song is playing Select input method
Screenshot error An open Wi-Fi network is
available
USB tethering is on Phone is connected via USB
cable
Portable Wi-Fi hotspot is on Radio is on
Screenshot captured System update available
Carrier data use threshold
approaching or exceeded Connected to VPN
Call in progress Disconnected from VPN
Call in progress using
Bluetooth headset
Status icons
For dual SIM model, status icons referring to either SIM1 or SIM2 will be
identified by a colour which you have defined.
GPRS connected Roaming
GPRS in use No SIM card inserted
EDGE connected Vibrate mode
EDGE in use Ringer is silenced
3G connected Phone microphone is mute
3G in use Battery is very low
Connected to a Wi-Fi
network Battery is low
Bluetooth is on Battery is partially drained
Connected to a Bluetooth
device Battery is full
Airplane mode Battery is charging
Alarm is set Headset connected
GPS is on No signal (gray)
Receiving location data from
GPS Signal strength (blue)
![](asset-10.png)
29 30
1.3.3 Search bar
The phone provides a Search function which can be used to locate
information within applications, the phone or the web.
Search by text
• Touch Search bar from the Home screen.
• Enter the text/phrase you want to search for.
• Touch the Enter/Search key on the keyboard if you want to search
on the web.
Search by voice
• Touch from Search bar to display a dialog screen.
• Speak the word/phrase you want to search for. A list of search results
will display for you to select from.
Notification panel
Touch and drag down the Status bar to open the notification panel. Touch
and drag up to close it. From the Notification panel, you can open items
and other reminders indicated by notification icons or view wireless
service information.
Quick settings bar
• Touch to enable/disable functions
or change modes.
• Slide left and right to view more.
Touch a notification and slide it to the left to delete it.
Touch the icon to clear all event–based notifications (other ongoing
notifications will remain).
Touch the Settings icon to access Settings.
Once you inserted SIM card, you can drag down the notification panel even
from the locked screen.
![](asset-11.png)
31 32
To unlock phone screen
Press the power key once to light up the screen, draw the unlock pattern you
have created or enter PIN or password to unlock the screen.
If you have chosen slide as the screen lock, touch and drag down the icon
to unlock the screen, and drag down the icon , , respectively
to access the camera, messaging, phone.
1.3.5 Personalize your Home screen
Add
Touch the application tab , touch and hold an application or a widget
to active the Move mode, and drag the item to any Home screen as you
prefer.
While adding an application to a Home screen, drag it to the top of App
info icon to view its detail information. If the application is downloaded,
drag it to the top of Uninstall icon to unmount it directly.
1.3.4 Lock/Unlock your screen
To protect your phone and privacy, you can lock the phone screen by
choosing slide or creating a variety of patterns, PIN or password.
To create a screen unlock pattern (refer to section “Screen lock”for
detail settings)
• Drag down the notification panel and touch to enter Settings, then
touch Security\Set up screen lock\Pattern.
• Draw your own pattern.
Draw your unlock pattern
Touch to confirm by drawing pattern again
To create a screen unlock PIN/Password
• Touch Settings\Security\Set up screen lock\PIN or Password.
• Set your PIN or password.
To lock phone screen
Press the Power key once to lock the screen.
![](asset-12.png)
33 34
1.3.6 Application tab
Touch on the Home screen to enter applications and widgets list.
To return to the Home screen, touch the Home key.
Consult recently-used applications
To consult recently-used applications, you can touch the Recent apps
key. Touch a thumbnail in the window to open the related application.
Touch one thumbnail and slide it to the left or right to delete it. You can
also touch and hold the app and touch Remove from list to delete it.
1.3.7 Volume adjustment
Using volume key
Press Volume key to adjust the volume. To active the vibrate mode,
press the Volume down key until the phone vibrates. Press the Volume
down key once more to active the silent mode.
Using Settings menu
Drag down the notification panel and touch to enter Settings, then
touch Audio profiles\Volume you can set the volume of media,
ringtone, alarm, and etc to your preference.
Reposition
Touch and hold the item to be repositioned to activate the Move mode,
drag the item to the desired position and then release. You can move
items both on the Home screen and the Favorite tray. Hold the icon on
the left or right edge of the screen to drag the item to another Home
screen.
Remove
Touch and hold the item to be removed to activate the Move mode, drag
the item up to the top of Remove icon, and release after the item turns
red.
Create folders
To improve the organization of items (shortcuts or applications) on the
Home screen and the Favorite tray, you can add them to a folder by
stacking one item on top of another. To rename a folder, open it, touch
the folder’s title bar to input the new name.
Wallpaper customization
Touch and hold an empty area, a popup window named Select wallpaper
from will appear, offering a range of options. Gallery includes pictures
you have taken, cropped or downloaded. Live wallpapers includes a
scrolling list of animated wallpapers. Video wallpaper includes preset
videos in phone, videos stored in SD card and camera. Wallpapers
includes all preset wallpapers in the phone. Slide left and right to locate a
desired image, touch Set wallpaper to confirm.
![](asset-13.png)
35 36
2 Text input ..............................
2.1 Using Onscreen Keyboard
Onscreen Keyboard settings
On application list, Settings\Language & input, touch the Settings
icon on the right of Android keyboard a series of settings are
available for your selection.
Adjust the Onscreen Keyboard orientation
Turn the phone sideways or upright to adjust the Onscreen Keyboard
orientation. You can also adjust it by changing the settings (On application
list, touch Settings\Display\Orientation).
1.4 Applications and widgets list
This list contains all pre-embedded and newly installed applications and
widgets.
To access the list, touch from Home screens.
Touch the Home key or the Back key to return to a Home screen.
Slide left and right to view all applications and widgets. Touch APPS or
WIDGETS to access the category directly. Touch the icon to access
the Google play store.
![](asset-14.png)
37 38
2.2 Text editing
You can edit the text you have entered.
• Touch and hold or double-tap within the text you would like to edit.
• Drag the tabs to change the high-lighted selection.
• Options list will show as below, icons from left to right mean Select all
, Cut , Copy and Paste .
• Touch the icon .
You can also insert new text
• Touch where you want to type, or touch and hold a blank space, the
cursor will blink and the tab will show. Drag the tab to move the cursor.
• If you have selected any text, touch the tab to show PASTE &
REPLACE icon which allows you to paste any text you have previously
copied or replace with other text.
2.1.1 Android keyboard
Touch to switch
between symbol
and numeric
keyboard.
Touch & hold, then
select to enter symbols/
emoticons.
Touch to enter text or
numbers.
Touch & hold to show input
options;
When Wi-Fi or data connection is
on, touch to enter voice input.
Touch to switch
between "abc/
Abc" mode;
Touch & hold to
switch between
"abc/ABC" mode.
To show settings key , touch Settings\Language & input\Android
keyboard settings, then mark Show settings key.
![](asset-15.png)
39 40
International call
To dial an international call, touch and hold to enter “+”, then enter
the international country prefix followed by the full phone number and
finally touch .
Emergency call
If your phone has network coverage, dial emergency number and touch
to make an emergency call. This works even without a SIM card and
without typing the PIN code.
3.1.2 Answering or rejecting a call
When you receive a call
• Slide the icon rightward to answer;
• Slide the icon leftward to reject;
3 Phone call, Call log
and Contacts .........................
3.1 Phone ...........................................................
3.1.1 Placing a call
You can easily start a call using Phone.
Touch Application tab from the Home screen and select Phone.
Touch and hold to
access voicemail
Slide to access Call
log and Contacts.
Touch to find
contacts
Enter the desired number from the keyboard directly or select a contact
from Contacts or Call log by sliding or touching tabs, then touch to
place the call.
The number you entered can be saved to Contacts by touching the Menu
icon and touching Add to Contacts.
If you make a mistake, you can delete the incorrect digits by touching .
To hang up a call, touch or the Power key.
![](asset-16.png)
41 42
Touch to hold the current call. Touch this icon again to
retrieve the call.
Touch to display Dialpad.
Touch to end the current call.
Touch Menu icon to Add a call or Start recording.
Touch to mute the current call. Touch this icon again to
unmute the call.
Touch to activate the speaker during the current call. Touch
this icon again to deactivate the speaker.
To avoid misoperation on touchscreen during a call, screen will be
locked automatically when you put the cellphone close to your ear;
and it will be unlocked when the cellphone is taken away from your
ear.
3.1.5 Call settings
Touch Menu icon and settings from Dial screen, the following options
are available:
Voice call
• Voicemail
Voicemail service Opens a dialog box where you can select your
carrier’s voicemail service or another service.
Voicemail settings If you are using your carrier’s voicemail service,
this opens a dialog box where you can enter the
phone number to use for listening to and managing
your voicemail. You can enter a comma (,) to
insert a pause into the number — for example, to
add a password after the phone number.
• Slide the icon upward to reject the call by sending a preset message.
To mute the incoming calls, press the Volume up/down key or turn the
phone face down if Turn over to mute is activated. To activate, touch
Settings\Gestures\Turn over to mute or touch Phone\Settings\
Other settings\Turn over to mute.
3.1.3 Calling your voicemail
Your voicemail is provided by your network to avoid missing calls. It works
like an answering machine that you can consult at any time.
To access your voicemail, touch and hold on Phone tab.
To set your voicemail number, touch Menu icon and touch Settings\
Call settings\Voice call\Voicemail.
If you receive a voicemail, a voicemail icon appears on the Status bar.
Open the Notification panel, touch New voicemail.
3.1.4 During a call
To adjust the volume during a call, press the Volume up/down key.
43 44
• Outgoing video
call
Touch to display local video when you place a
call.
• Incoming video
call
Touch to display local video when receiving an
incoming call.
• Call forwarding Touch to configure how your calls are forwarded
when you are busy, unanswered or unreachable.
• Video call barring Enter to cancel types of video calls and change
barring password.
• Phone number and call waiting settings
• Caller ID Open a dialog box where you can set whether your
phone number is displayed when making calls.
• Call waiting Mark the check box to notify you of a new
incoming call.
• Call waiting status Touch to view call waiting status if available.
Internet call
For more information of Internet call, please refer to section 6.7
Configuring Internet (SIP) calling.
• IP prefix number
Touch to set prefix number, touch OK to confirm, touch Cancel to cancel.
• Call forwarding
Touch to configure how your calls are forwarded when you are busy,
unanswered or unreachable.
• Additional settings
Caller ID Open a dialog box where you can set whether
your phone number is displayed when making
calls.
Call waiting Mark the check box to notify you of a new
incoming call.
Call waiting status Touch to view call waiting status if available.
Video call (1)
• Local video
replacement
You can pick a picture from your collection to
display when Camera is unreachable.
• Display peer video Mark the checkbox to display picture for replacing
peer video when it is unavailable.
• Peer video
replacement
Set a picture to display when peer video is
unavailable.
• Enable back
camera
Mark the checkbox to turn on back camera during
a video call.
• Bigger peer video Touch to enable a bigger view of peer.
• Auto drop back Mark the checkbox to enable dropping back to
voice call automatically.
(1) Depending on your model.
![](asset-18.png)
45 46
3.2 Call log
You can access your call memory by touching from the Dial screen.
Touch on the right side of contact/number to place a call directly.
There are three kinds of calls in Call log:
Missed calls
Outgoing calls
Incoming calls
Touch icons on top of call logs to change among different kinds.
Touch a contact or number to view information or further operations.
You can view detailed information of a call, launch a new call or send
messages to a contact or number, or add numbers to People (only
available for unsaved phone numbers), etc.
Touch the photo to open the Quick Contact panel.
To clear the entire call memory, touch Menu icon and Delete, select
the call log entries you want to delete and then touch the trash bin.
3.3 People ...........................................................
People app enables quick and easy access to the people you want to
reach.
You can view and create contacts on your phone and synchronize these
with your Gmail contacts or other applications on the web or on your
phone.
3.3.1 Consult your contacts
To access People app, touch Application tab on the Home screen, then
select People.
Other settings
• Fixed Dialing Numbers
Fixed Dialing Number (FDN) is a service mode of SIM, where outgoing
calls are restricted to a set of phone numbers. These numbers are added
to the FDN list. The most common practical application of FDN is for
parents to restrict the phone numbers which their children can dial.
For security reasons, you’ll be prompted to enable FDN by entering SIM
PIN2 which is usually acquired from your service provider or SIM maker.
Minute reminder
Mark the check box to enable minute reminder at 50s of every minute
during a call.
Vibrate reminder
Mark the checkbox to enable vibration when the call is connected.
Dual mic noise reduction
Mark the checkbox to turn on dual mic for noise reduction.
Turn on smart calling
Mark the checkbox to turn on smart calling.
Power button ends call
Mark the checkbox to end a call while pressing the power button.
Quick responses
Touch to edit quick responses which will be used when you reject a call
with messages.
![](asset-19.png)
47 48
3.3.2 Managing contact groups
The contact group helps you to improve the organization of your contacts.
You can add, remove and view groups in the Contact group screen.
Touch the icon to view local groups. To create a new group, touch
the icon , enter the new name and touch Done to confirm.
3.3.3 Adding a contact
Touch the icon in the contact list to create a new contact.
You are required to enter the contact's name and other contact
information. By scrolling up and down the screen, you can move from one
field to another easily.
Touch to select a picture for the contact.
Touch to unfold the other
predefined labels of this category.
Touch to save.
Touch to add a new label.
If you want to add more information, touch Add another field to add
a new category.
When finished, touch Done to save.
To exit without saving, you can touch Menu icon and then touch Discard.
Touch to view the
contact’s detailed
information.
Touch icon to open
Quick Contact panel.
Touch to view your
favourite contacts.
Touch to view your
contact groups
Touch to search
in Contacts
Touch to add a
new contact.
Touch Menu icon to display contacts list option menu.
Following actions are enabled:
• Delete contact Select and delete unwanted contacts.
• Contacts to display Choose contacts to display.
• Import/Export Import or export contacts between phone, SIM
card, and microSD card, or share contacts.
• Accounts Manage the synchronization settings for different
accounts.
• Settings
Sort list by Touch to display contact information as given
name or family name.
View contact
names as
Touch to view contact names as given name first
or family name first.
• Share visible
contacts
Share contacts with others by sending the
contact's vCard to them via Bluetooth, Email,
SMS,etc.
![](asset-1a.png)
49 50
3.3.5 Communicating with your contacts
From the contacts list, you can communicate with your contacts by making
a call or exchanging messages.
To launch a call to a contact, touch the contact to enter the detail screen,
then touch the number.
To send a message to a contact, touch the contact to enter the detail
screen, then touch the icon on the right side of the number.
Use Quick contact for Android
Touch a contact’s picture to open Quick Contact for Android, then you
can touch the number or the icon for the way you want to connect.
The icons available on Quick Contact panel depend on the information
you have for the contact and the applications and accounts on your phone.
Add to/remove from Favourites
To add a contact to favourites, you can touch a contact to view details
then touch to add the contact to favourites (the star will turn yellow
in color).
To remove a contact from favourites, touch the white star on contact
details screen.
3.3.4 Editing your contacts
To edit contact information, touch the Menu icon in the contact details
screen, then touch Edit. When finished, touch Done.
Change a contact’s default phone number
The default phone number (the number which has priority when making a
call or sending a message) will always be displayed under the contact name.
Set ringtone for a contact
On the contact's detail screen, touch
Menu icon
to display contacts list
options menu, touch Set ringtone.
Delete a contact
To delete a contact, touch Menu icon and Delete contact from
contact (details) screen. Pick the contact you want to remove and touch
to confirm. Touch to delete all contacts, touch to cancel the
selected one.
The contact you have deleted will also be removed from other
applications on the phone or web the next time you synchronize
your phone.
![](asset-1b.png)
51 52
3.3.8 Joining/Separating contacts
To avoid duplication, you can add any new contact information to existing
contacts in a single action.
Touch the contact which you want to add information to, touch Menu icon
and touch Edit contact, then touch Menu icon again and touch Join.
At this time, you are required to select the contact whose information
you want to join with the first contact. The information from the second
contact is added to the first one, and the second contact will no longer be
displayed in the Contacts list.
To separate contact information, touch the contact whose information
you want to separate, touch Menu icon and touch Edit contact, then
touch Menu icon again and touch Separate, touch OK to confirm.
3.3.9 Accounts
Contacts, data or other information can be synchronized from multiple
accounts, depending on the applications installed on your phone.
To add an account, drag down the notification panel and touch to enter
Settings, then touch Add account.
You are required to select the kind of account you are adding, like Google,
Corporate, etc.
As with other account set-ups, you need to enter detailed information, like
username, password, etc.
You can remove an account to delete it and all associated information
from the phone.Open the Settings screen, touch the account you want
to delete, touch the Menu icon and Remove account, then confirm.
3.3.6 Contacts importing, exporting and sharing
This phone enables you to import contacts from SIM card/microSD card
and export contacts to a microSD card which can then be used to back
up your information.
From Contacts screen, touch Menu icon to open options menu, touch
Import/Export, then select Phone, Phone storage, SD Card, SIM/USIM
card, and other accounts (eg: gmail account).
To import/export a single contact from/to SIM card, choose an account
and target SIM card(s), select the contact you want to import/export, and
touch the icon √ to confirm.
To import/export all contacts from/to SIM card, choose an account and
target SIM card(s), select and touch the icon √ to confirm.
You can share a single contact or contacts with others by sending the
contact's vCard to them via Bluetooth, Gmail, etc.
Touch a contact you want to share, touch Menu icon and Share from
contact details screen, then select the application to perform this action.
3.3.7 Displaying contacts
You can configure which group of contacts, for each account, you want to
display in the Contacts list. Touch Menu icon and touch Contacts to
display from contacts list screen, then you can choose contacts to display.
Touch Menu icon and Settings, you can sort list by the given name or
family name, as well as view contact names as given name first or family
name first.
![](asset-1c.png)
53 54
4 Messaging, Email ..................
4.1 Messaging....................................................
You can create, edit and receive SMS and MMS with this mobile phone.
To access this feature, touch Application tab from the Home screen, then
select Messaging.
All messages you receive or send out can be saved in phone
memory or SIM card. To consult messages stored in SIM card,
touch Menu icon from Messaging screen, then touch Settings\
Manage SIM messages.
4.1.1 Write message
On message list screen, touch the new message icon to write text/
multimedia messages.
Touch to create a new message
Touch to search in all messages
• Touch to view the whole message
thread.
• Touch & hold to active the delete
mode. Touch message threads to choose
deleted ones, and touch the trash bin to
confirm.
Turn on/off the sync & Auto-sync
Touch an account to enter the account screen, mark/unmark the
checkbox(s) to turn on/off the account’s auto-sync. When activated,
all changes to information on the phone or online will be automatically
synchronized to each other.
Sync manually
You can also synchronize an account manually on Account screen, touch
an account in the list, then touch Menu icon and Sync now.
![](asset-1d.png)
55 56
Attach options:
• Pictures Access Gallery application or File manager to
select a picture as attachment.
• Capture picture Access Camera to capture a new picture for
attaching.
• Videos Access Gallery application or File manager to
select a video as attachment.
• Capture video Access Camcorder to record a new video for
attaching.
• Audio Access to select an audio file as attachment.
• Record audio Enter voice message recorder to record a voice
message for attaching.
• Slideshow Enter Edit slide show screen, touch Add slide to
create a new slide, and touch currently existing
slide to edit it (see following picture). Touch
Menu icon to get more actions, like setting the
slide duration, add music, etc.
• Contact Access People application to select one or
more contact(s) to attach.
• Calendar Enter Calendar to select events to attaching.
For saved contacts, touch the photo to open the Quick Contact
panel to communicate with the contact. For unsaved contacts,
touch the photo to add the number to your Contacts.
Sending a text message
Enter the mobile phone number of the recipient on To bar or touch
to add recipients, touch Type to compose bar to enter the text of the
message. When finished, touch to send the text message.
An SMS message of more than 160 characters will be charged as
several SMS. When the total number of characters you have entered is
approaching the 160-character limit, a counter will appear on the lower
right corner below Send option of the text box to remind you how many
characters are allowed to be entered in one message.
Specific letters (accent) will increase the size of the SMS, which
may cause multiple SMS to be sent to your recipient.
Sending a multimedia message
MMS enables you to send video clips, images, photos, animations, slides
and sounds to other compatible mobiles and e-mail addresses.
An SMS will be converted to MMS automatically when media files (image,
video, audio, slides, etc.) are attached or subject or email addresses are
added.
To send a multimedia message, enter the recipient's phone number in the
To bar, touch Type to compose bar to enter the text of the message.
touch Menu icon to open the option menu, touch Add subject to
insert a subject, and touch to attach picture, video, audio and so on.
When finished, touch to send the multimedia message.
![](asset-1e.png)
57 58
Touch and hold a SMS in message details screen. The following message
options are available for selection:
• Copy message
text
This option displays when the message is an SMS.
Copy the current message content. You can paste
it to the enter bar of the new message you are
going to compose.
• Forward Touch to forward the message to another recipient.
• Lock/Unlock
message
Touch to lock/unlock the message so it can't/
can be deleted if you reach maximum number of
stored messages.
• Save message to
SIM card
This option displays when the message is an SMS.
Touch to save the message to SIM card.
• View message
details
Touch to view details of the message.
• Delete message Delete the current message.
• Select text Select the current message.
Touch to go to previous or next slide.
Touch to preview the current slide.
Touch to edit the title of this slide.
4.1.2 Manage messages
When receiving a message, an icon will appear on status bar as
notification. Drag down the status bar to open the Notification panel,
touch the new message to open and read it. You can also access the
Messaging application and touch the message to open.
Messages are displayed in conversational order.
To reply to a message, touch the current message to enter message-
composing screen, enter the text, then touch .
![](asset-1f.png)
59 60
Multimedia (MMS) Messages
• Delivery reports Select to request a delivery report for each
multimedia message you send.
• Read reports Select to request a report on whether each
recipient has read a multimedia message sent by
you.
• Send read report Select to request a report on whether the
multimedia message is sent out.
• Auto-retrieve Select to download the full MMS message
(including message body and attachment)
automatically to your phone. Otherwise,
download only the MMS message header.
• Roaming auto-
retrieve
Select to download the full MMS message
(including message body and attachment)
automatically when roaming. Otherwise,
download only the MMS message header to
avoid extra charges.
• Creation mode Select creation mode as restricted, warning or
free.
• Maximum
message size
Select to edit the message size, but it should not
be more than 300KB.
• Priority Select message priority as high, normal or low.
4.1.3 Adjust message settings
You can adjust a set of message settings. From Messaging application
screen, touch Menu icon and touch Settings.
Storage
• Delete old
messages
Select to delete old messages when the maximum
number of stored messages is reached.
• Text message
limit
Touch to set the number of text messages to be
saved per conversation.
• Multimedia
message limit
Touch to set the number of multimedia messages
to be saved per conversation.
Text (SMS) Messages
• Delivery reports Select to request a delivery report for each text
message you send.
• Manage SIM
messages
Touch to manage the messages stored on SIM
card.
• Edit quick text Touch to add or edit message templates.
• SMS service
centre
Touch to view or edit SMS service centre
number.
• Validity period Select message validity period such as Maximum,
1 hour, 6 hours etc.
• SMS storage
location
Touch to select phone or SIM card to store
messages.
![](asset-20.png)
61 62
4.2 Gmail/Email
The first time you set up your phone, you can select to use an existing
Gmail or to create a new Email account.
4.2.1 Gmail ...................................................................
As Google's web-based email service, Gmail is configured when you first
set up your phone. Gmail on your phone can be automatically synchronized
with your Gmail account on the web. Unlike other kinds of email account,
each message and its replies in Gmail are grouped in your inbox as a single
conversation; all emails are organized by labels instead of folders.
To access Gmail
From the Home screen, touch the Application tab to enter the applications
list, then touch Gmail.
Gmail displays messages and conversations from one single Gmail account
at a time, if you own more than one account, you can add a new one by
touching Menu icon and Settings from Inbox screen, then touch ADD
ACCOUNT. When finished, you can switch accounts by touching the
account name from Inbox screen, and touch the account you want to view.
To create and send emails
• Touch the icon from Inbox screen.
• Enter recipient(s)’s email address in To field, and if necessary, touch
Menu icon and touch Add Cc/Bcc to add a copy or a blind copy to
the message.
• Enter the subject and the content of the message.
• Touch Menu icon and select to add an attachment.
• Finally, touch the icon to send.
Notifications
• Notifications Select to display message notifications in status
bar.
• Select ringtone Touch to select a ringtone as a new message
notification tone.
Cell Broadcast
• Enable CB
ringtone
Select to enable CB ringtone.
• Select CB
ringtone
Touch to select a ringtone as a CB notification
tone.
• Cell Broadcast Touch to choose a SIM card and configure cell
broadcast messages.
Service message setting
• Enable service
message
Select the checkbox to enable to receive service
message.
Touch and hold operation guide
• Show animation Touch to show animation of messaging operation
guide.
![](asset-21.png)
63 64
Managing Gmails by Labels
To conveniently manage conversations and messages, you can organize
them using a Label.
To label a conversation when reading a conversation’s messages, touch the
icon and select the label to assign to the conversation.
To view conversations by labels when viewing your inbox or another
conversation list, touch the icon , then touch a label to view a list of
conversations with that label.
To manage labels, touch MANAGE LABELS from Labels screen.
Mark the checkbox to select email to activate batch mode, and
produce the following options:
• Touch to archive the email message.
• Touch to delete the email message.
•
Touch to add or change the label of the email
message or conversation.
• /Touch to mark an email message as read or unread.
• To assign a star or remove the star from the
conversation.
• Mark as (not)
important
To Mark the email as important or not important.
• Mute To mute the entire conversation. When muted,
new mails related to this conversation will not be
displayed in Inbox, but archived.
• Report spam To report the email message/conversation as spam.
• If you do not want to send the mail out right away, you can touch Menu
icon and Save draft or touch Back key to save a copy. To view the
draft, touch the icon , then select Drafts.
If you do not want to send or save the mail, you can touch Menu icon
and then touch Discard.
To add a signature to emails, touch Menu icon and Settings from inbox
screen, choose an account, then touch Signature.
To receive and read your emails
When a new email arrives, you will be notified by a ringtone or vibration,
and an icon will appear on Status bar.
Touch and drag down the Status bar to display the Notification panel,
touch the new email to view it. Or you can also access the Gmail Inbox
label and touch the new mail to read it.
You can search for an email by sender, subject, label, etc.
• Touch the icon from Inbox screen.
• Enter the keyword you want to search for in the searching box and
touch the Enter key in the software keyboard.
To reply or forward emails
When viewing an email, you will see three icons offering further options
at the centre of the conversation.
• Reply/Reply all Touch to enter text-inputting mode, enter the
message you want to reply, then touch icon
to send this message to one single recipient or all
people in a mail loop.
• Forward Touch to forward the message to another person.
You are required to enter the new recipient’s email
address and then touch .
![](asset-22.png)
65 66
Touch an account, the following settings will show:
• Priority Inbox To set this inbox as the default one.
• Notifications Select to activate notification when a new email
arrives.
• Sound & vibrate Touch to set Ringtone, Vibrate and Notify once.
• Signature To add a signature text to the end of each mail
you send.
• Gmail sync is ON Touch to turn on/off Gmail sync.
• Days of mail to
sync
Touch to set the duration of days for mail sync.
• Manage labels Touch to open the Label screen, where you can
manage synchronization and notifications.
• Download
attachments
Mark the checkbox to auto download attachments
to recent messages via Wi-Fi.
4.2.2 Email ..................................................................
Besides your Exchange account, you can also set-up external POP3 or
IMAP email accounts in your phone.
To access this function, touch Application tab from the Home screen, then
select Email.
An email wizard will guide you through the steps to set-up an email
account.
• Enter the email address and password of the account you want to set-up.
Gmail settings
To manage Gmail settings, touch Menu icon and Settings in Inbox screen.
General settings
• Confirm before
deleting
Mark the checkbox to confirm before
deleting emails.
• Confirm before
archiving
Mark the checkbox to confirm before
archiving emails.
• Confirm before
sending
Mark the checkbox to confirm before
sending emails.
• Reply all Touch to mark the checkbox to make the
default responding to messages.
• Auto-fit messages Mark the checkbox to shrink messages to fit
the screen and allow zooming.
• Auto-advance Touch to select which screen to show
after you delete or archive a conversation.
• Hide checkboxes Mark the checkbox to hide checkboxes
while selecting emails in the batch mode.
• Message Actions Touch to show/hide message actions.
• Clear search history Touch to remove the search history.
• Hide pictures in
messages
Touch to hide pictures for all senders.
![](asset-23.png)
67 68
To sign out, touch Menu icon from Friends list to display options, then
touch Sign out. Or you can also select Sign out from online status.
4.3.1 Chatting with your friends
To start a chat, touch the name of a friend in your Friends list, then enter
your message and finally touch .
You can invite other friends to join in a group chat by touching Menu icon
and Add to chat and then selecting the friend you want to add.
4.3.2 To add a new friend
From Friends list, touch Menu icon and select Add friend to add a new
friend. Enter the Google Talk ID or Gmail address of the friend you want
to add, and then touch Done.
A notification with this invitation will be received by the friend. By
touching the invitation, the friend can select Block, Decline or Accept
in response.
4.3.3 To close a chat
When you want to end a chat, touch Menu icon from Chatting screen
directly, and then touch End chat.
If you want to end all chats, touch Menu icon and End all chats from
Friends list screen.
• Touch Next. If the account you entered is not provided by your service
provider in the phone, you will be prompted to go to the email account
settings screen to enter settings manually. Or you can touch Manual
setup to directly enter the incoming and outgoing settings for the email
account you are setting up.
• Enter the account name and display name in outgoing emails.
• To add another email account, you can touch Menu icon and Settings.
Touch Add account on the right of the title to create.
To create and send emails
• Touch the icon from Inbox screen.
• Enter recipient(s) email address(es) in To field.
• If necessary, touch Menu icon and touch Add Cc/Bcc to add a copy
or a blind copy to the message.
• Enter the subject and the content of the message.
• Touch Menu icon , touch Attach file to add an attachment.
• Finally, touch to send.
• If you do not want to send the mail right away, you can touch Menu icon
and Save draft or touch Back key to save a copy.
4.3 Google Talk ................................................
Google's instant messaging service, Google Talk, lets you communicate
with your friends whenever they are connected to this service.
To access this feature and sign in, touch Application tab from the Home
screen, then touch Talk. All friends added by using Google Talk from the
web or phone will be displayed in your friends list.
Touch your account to set your online status.
Touch the text box below your online status to enter your status message.
![](asset-24.png)
69 70
4.3.5 Settings
A series of settings are available for your selection by touching Menu icon
and Settings from Friends list screen, and choose an account.
• Mobile indicator Select to display an indicator icon along with
your name in other people’s Friends list.
• Away when screen
off
Select to set status as Away when the screen is
turned off.
• Invitation
notifications
Select to activate the notification function on
status bar when a new message arrives.
• IM/Video chat
notifications
Touch to set the notification way for text or
Video chat.
• Notification/Video
chat ringtone
Touch to choose a ringtone for notification or
Video chat.
• Vibrate Touch to set the vibrate way for text or Video
chat.
• Blocked friends Touch to show/unblock blocked friends.
• Clear search
history
Touch to clear previous chat search history from
showing up in the Search box.
• Manage account Touch to add, remove or sync your accounts.
• Terms & privacy Touch to show more information about Talk.
4.3.4 To manage your friends
Besides adding new friends to your friends list, the following actions are
available for your choice:
• To view all friends/
most popular
friends
By default, only friends that you frequently
communicate with are displayed in Friends
list. To view all friends, touch Menu icon
and Display options, then touch Name. To
return to displaying most popular friends screen,
touch Availability or Recency from Display
options.
• To block/Remove
a friend
To block a friend from exchanging messages or
remove them from your friends list, touch Menu
icon and Friend info from Chatting screen,
then touch Block or Remove. All blocked friends
can be viewed by touching Menu icon and
Settings, touch an account then choose Blocked
friends.To unblock a friend, touch the name of this
friend and touch OK when prompted.
![](asset-25.png)
71 72
5.1.2 To create new events
You can add new events from any Calendar view.
• In portrait mode, touch Menu icon and New event from Calendar
screen; or in landscape mode, touch the icon to access new event
edit screen.
• Fill in all required information for this new event. If it is a whole-day
event, you can select All day.
• Invite guests to the event. Enter the email addresses of the guests you
want to invite with commas to separate. The guests will receive an
invitation from Calendar and Email.
• When finished, touch DONE from the top of the screen.
To quickly create an event from Day, Week view screen, touch and hold
an empty spot or an event to open Option menu, then touch New event
to enter the event details screen of the time you have previously selected.
Or you can also touch the empty spot to select the target area which will
turn blue, and tap again to create the new event.
5.1.3 To delete or edit an event
To share, delete or edit an event, touch the event to enter details screen,
touch the icon to share the event to other people by Bluetooth, Email
and messaging, etc., touch the icon to edit the event, and touch the
icon to delete.
5.1.4 Event reminder
If a reminder is set for an event, the upcoming event icon will appear
on Status bar as a notification when the reminder time arrives.
5 Calendar & Alarm clock &
Calculator ..............................
5.1 Calendar ......................................................
Use Calendar to keep track of important meetings, appointments, etc.
To access this function, touch Application tab from the Home screen, then
touch Calendar.
5.1.1 Multimode view
You can display the Calendar in daily, weekly, monthly, or agenda view.
Touch the date to change your Calendar view, and a drop-down menu will
show for you to choose. Touch the icon to return to Today's view.
In Agenda, Day or Week
view touch an event to
view its details. Touch a day in
Month view to open
that day's events.
Agenda view
Day view
Week view
Month view
![](asset-26.png)
73 74
5.2.1 To set an alarm
From Clock screen, touch to enter Alarms screen, touch to add
a new alarm. Following options will show:
• Enable alarm Touch to enable the alarm.
• Time Touch to set time.
• Repeat Touch to select days you want alarm to work
• Ringtone Touch to select a ringtone for the alarm
• Vibrate Select to activate vibration
• Label Touch to set a name for the alarm
• Crazy alarm Touch to set an alarm without snooze mode,
the alarm will keep work until you press dismiss
button.
When finished, touch DONE to confirm.
To delete an alarm, touch it from Alarms screen to enter the alarm
editing screen, touch to delete. Touch OK to confirm, touch Cancel
to cancel.
Touch and drag down the status bar to open the notification panel, touch
event name to view Calendar notification list.
Touch Snooze all to turn off all event reminders for 5 minutes.
Touch Dismiss all to delete all reminders from the list.
Touch Back key to keep the reminders pending in the status bar and the
notification panel.
Important options by touching Menu icon from Calendar main screen:
• New event To add a new event
• Refresh To refresh the calendar
• Search To search in the calendar
• Calendars to display To show or hide, remove or add calendars
• Clear events To clear events in the calendar.
• Settings To set a series of Calendar settings
5.2 Clock ............................................................
Your mobile phone has a built-in clock.
To access this function, touch the Application tab from the Home screen,
then touch Clock.
Touch anywhere of the screen to dim/light the screen.Touch Set
alarm to add or set an alarm.
![](asset-27.png)
75 76
To switch between panels, select one of the following two ways:
• Touch and drag the basic screen to the left to open the Advanced panel.
• Or touch and hold the Menu key from basic panel to open option menu
and touch Advanced panel.
Enter a number and the arithmetic operation to be performed, enter the
second number, then touch “=” to display the result. Touch to delete
digits one by one, touch and hold to delete all at one time.
When some numbers or operations have been entered, touch and hold
the entering bar to open a menu offering these further operations:(1)
• Cut To cut selected text
• Copy To copy selected text
• Paste (1) To paste what you have previously copied to the
entering bar
(1) Option will not appear unless copy or cut operation has been made.
5.2.2 To adjust alarm settings
Touch Menu icon from Alarms screen, then touch Settings. The
following options can now be adjusted:
• Alarm in silent
mode
Select to play alarm with sound or vibration
even when the phone is in Silent mode
• Alarm volume Touch to set the volume of alarms
• Snooze duration Touch to set temporary turn off time of an
alarm
• Volume buttons Touch to set side Volume up/down key
behaviors when alarm sounds: None, Snooze
or Dismiss
• Set default ringtone Touch to set default ringtone for alarms
• Turn over to
activate
Select to turn on/off snooze mode.
• View Whether and
Events
Mark the checkbox to display weather
forecast and today’s event.
5.3 Calculator .....................................................
With Calculator, you can solve many mathematical problems.
To access this function, touch Application tab from the Home screen, then
touch Calculator.
There are two panels available: Basic panel and Advanced panel.
![](asset-28.png)
77 78
To activate/deactivate Data roaming
When roaming, you can decide to connect/disconnect to a data service.
• Drag down notification panel and touch to access Settings.
• SIM management\Roaming.
• Mark/Unmark the Data roaming checkbox to activate or deactivate
data roaming.
• When Data roaming is deactivated, you can still perform data exchange
with a Wi-Fi connection (refer to “6.1.2 Wi-Fi”).
6.1.2 Wi-Fi
Using Wi-Fi, you can connect to the Internet when your phone is within
range of a wireless network. Wi-Fi can be used on your phone even
without a SIM card inserted.
To turn Wi-Fi on and connect to a wireless network
• Drag down notification panel and touch to access Settings.
• Touch the switch beside Wi-Fi to turn on/off Wi-Fi.
• Touch Wi-Fi, the detailed information of detected Wi-Fi networks is
displayed in the Wi-Fi networks section.
• Touch a Wi-Fi network to connect. If the network you selected is
secured, you are required to enter a password or other credentials (you
may contact your network operator for details). When finished, touch
Connect.
6 Getting connected ................
To connect to the internet with this phone, you can use GPRS/EDGE/3G
networks or Wi-Fi, whichever is most convenient.
6.1 Connecting to the Internet
6.1.1 GPRS/EDGE/3G
The first time you turn on your phone with SIM card inserted, it will
automatically configure network service: GPRS, EDGE or 3G. If the network
is not connected, you can press and hold on notification panel.
To check the network connection you are using, drag down notification
panel and touch to access Settings, then touch More...\Mobile
networks\Mobile network settings\Access Point Names or
Network operators.
To create a new access point
A new GPRS/EDGE/3G network connection can be added to your phone
with the following steps:
• Drag down notification panel and touch to access Settings.
• Touch More...\Mobile networks\Mobile network settings\Access
Point Names
• Then touch Menu icon again and touch New APN.
• Enter the required APN information.
• When finished, touch Menu icon and touch Save.
![](asset-29.png)
79 80
6.2 Browser.........................................................
Using Browser, you can enjoy surfing the Web.
To access this function, touch Application tab from the Home screen, then
touch Browser.
To go to a web page
On Browser screen, touch the URL bar at the top, enter the address of
the web page.
Touch to delete all contents
Touch to search and go to this address
Touch to input the suggested address
Touch to go the suggested web site
The URL bar will hide after a few seconds. To show the URL bar, you
can touch and slide down the screen.
To set homepage
• Touch Menu icon from Browser screen to display option menu, touch
Settings\General\Set home page.
• Choose a page or most visited website as your homepage.
• If you choose Other, enter the URL of the website you want to set as
your homepage, touch OK to confirm.
To activate notification when a new network is detected
When Wi-Fi is on and the network notification is activated, the Wi-Fi icon
will appear on the status bar whenever the phone detects an available
wireless network within range. The following steps activate the notification
function when Wi-Fi is on:
• Drag down notification panel and touch to access Settings.
• Touch Wi-Fi. Then touch Menu icon and Advanced from Wi-Fi
screen.
• Mark/Unmark the Network notification checkbox to activate/
deactivate this function.
To add a Wi-Fi network
When Wi-Fi is on, you may add new Wi-Fi networks according to your
preference.
• Drag down notification panel and touch to access Settings.
• Touch Wi-Fi, and then touch to add network.
• Enter the name of the network and any required network information.
• Touch Save.
When successfully connected, your phone will be connected automatically
the next time you are within range of this network.
To forget a Wi-Fi network
The following steps prevent automatic connections to networks which you
no longer wish to use.
• Turn on Wi-Fi, if it’s not already on.
• In the Wi-Fi screen, touch & hold the name of the saved network.
• Touch Forget network in the dialog that opens.
![](asset-2a.png)
81 82
To open a new window/switch between windows
Multiple windows can be opened at the same time for your convenience.
• Touch to open all windows' thumbnails.
• Slide up and down to view all windows, touch one to view it.
• Touch to open a new window.
• Touch Menu icon and New incognito tab to open a window without
any trace.
• To close a window, touch on the window you want to close or slide
it sideways.
Other options:
• Refresh To refresh the current page.
• Forward To forward the pages you have opened.
• Share page To share the current page with your friends via
various ways, like Message, Email, Bluetooth, etc.
• Request
desktop site
To enable/disable computer version websites.
• Save for
offline reading
To save the web page for offline reading. You can find
it via Menu icon then touch Bookmarks\History.
• Close To close all tabs and exit.
• Home screen To get back to the homepage you set.
• Save to
bookmarks
To add the current website page as bookmark.
• Find on page To input contents you want to find on the current
page.
• Stop To stop opening the current page.
• Bookmarks/
History
To see the bookmarks and browsing history.
• Version To see the version of browser.
6.2.1 Viewing web pages
When opening a website, you can navigate on web pages by sliding your
finger on the screen in any direction to locate the information you want
to view.
To zoom in/out of a web page
Pinch/Spread your finger on the screen to zoom out/in of the web page.
To quickly zoom into a section of a web page, double-tap on the section
you want to view. To return to normal zoom level, double-tap again.
To find text on a web page
• Touch Menu icon from web page screen, then touch Find on page.
• Enter the text or phrase you want to find.
• The first word with matching characters will be highlighted on the
screen, and subsequent matches will be boxed.
• Touch the up or down arrow to switch to the previous or next matching
items.
• When finished, you can touch or the Back key to close the search
bar.
Further operations for the text on a web page
You can copy, share or search the text from a web page:
• Touch and hold the text to highlight the text.
• Move the two tabs to select the text.
• Touch SELECT ALL to select all words in this web screen.
• Touch to show further actions, including copy, share and search on
the page or the web.
• When finished, touch or the Back key to deactivate the mode.
![](asset-2b.png)
83 84
Manage bookmarks
To bookmark a web page
• Open the web page you want to bookmark.
• Touch Menu icon and Save to bookmarks, or from the History
screen, touch the star beside the URL.
• Enter the name and the location if needed and touch OK to confirm.
To open a bookmark
• Touch Menu icon and Bookmarks/History, or touch the icon
and touch to enter the Bookmarks screen.
• Touch the bookmark you want to open.
• You can also touch and hold to display the options screen, then touch
Open or Open in new window.
To edit a bookmark
• Touch Menu icon and Bookmarks, or touch the icon and touch
to enter the Bookmarks screen.
• Touch and hold the bookmark you want to edit.
• Touch Edit bookmark, and enter your changes.
• When finished, touch OK to confirm.
Touch and hold a bookmark in the bookmark list to view these
additional options:
• Add shortcut to
Home
To add a bookmark shortcut to the Home
screen.
• Share link To share the bookmark.
• Copy link URL To copy the bookmark link.
• Delete bookmark To delete a bookmark.
• Set as homepage To set this page as the homepage.
Touch on the left of the URL, you can view more information
about the current page.
6.2.2 Manage links, history, downloads
To manage a link, phone number or address displayed on a web
page
• Link Touch the link to open the web page.
Touch and hold the link to open options for further
operation, like open in new window, save link, share
link, copy link, etc.
• Phone number Touch to call the phone number.
• Address Touch to open Google Maps and locate the address
To view Browser history
• Touch Menu icon from Browser screen
• Touch Bookmarks\History
• Touch HISTORY tab to view browser history.
• Touch SAVED PAGES to view the pages you saved.
To download a web application/view your downloads
To download a item, touch the item or the link you want to download.
To cancel a download, touch the downloaded item from the Notification
panel, select the item to be cancelled, and touch to confirm.
To view items you have downloaded, touch the Application tab, then
touch the application Downloads.
![](asset-2c.png)
85 86
• Remember
passwords
Mark to save usernames and passwords for
websites.
• Clear passwords Touch to clear all saved passwords.
Accessibility
• Force enable
zoom
Mark to control a website's zoom as you prefer.
• Text scaling Slide to change the size of the text display.
• Zoom on double-
tap
Slide to change the magnification level when
double-tapping the page.
• Minimum font size Slide to change the minimum font size.
• Inverted rendering Mark to display pages in invert color.
• Contrast Slide to change pages contrast. It is grey, unless
you mark Inverted rendering.
Advanced
• Set search engine Touch to select a search engine.
• Open in
background
Mark to open new windows behind the current
one.
• Enable JavaScript Mark to enable JavaScript.
• Enable plug-ins Mark to enable plug-ins.
• Website settings Touch to view advanced settings for individual
websites.
• Default zoom Touch to select the magnification level by default.
• Open pages
in overview
Mark the checkbox to open web pages zoomed
out, in an overview.
• Auto-fit pages Mark to format web pages to fit the screen.
6.2.3 Settings
A series of settings are available for your adjustment. To access Browser
settings, touch Menu icon from Browser screen, and touch Settings.
General
• Set homepage Touch to set homepage.
• Form auto-fill Mark the checkbox to fill out web forms with a
single touch.
• Auto-fill text Touch to set up text to auto-fill in web forms.
Privacy & security
• Clear cache Touch to clear locally cached content and
databases.
• Clear history Touch to clear the browser history.
• Show security
warnings
Mark to show warning if there is a problem with
a site’s security.
• Accept cookies Mark to allow sites to save and read cookie data.
• Clear all cookie
data
Touch to clear all browser cookies.
• Remember form
data
Mark to remember data in forms for later use.
• Clear form data Touch to clear all the saved form data.
• Enable location Mark to allow sites to request access to your
location.
• Clear location
access
Touch to clear location access for all websites.
![](asset-2d.png)
87 88
• Touch to activate/deactivate this function.
To make your phone more recognizable, you can change your phone name
which is visible to others.
• Drag down notification panel and touch to access Settings.
• Touch Bluetooth.
• Touch Menu icon and Rename phone.
• Enter a name, and touch Rename to confirm.
To make device visible
• Drag down notification panel and touch to access Settings.
• Touch Bluetooth
• Touch your device to make it visible or invisible.
• Touch Menu icon and Visibility timeout to select the visible time.
To pair/connect your phone with a Bluetooth device
To exchange data with another device, you need to turn Bluetooth on
and pair your phone with the Bluetooth device with which you want to
exchange data.
• Drag down notification panel and touch to access Settings.
• Touch Bluetooth
• Touch SEARCH FOR DEVICES
• Touch a Bluetooth device you want to be paired with in the list.
• A dialog will popup, touch Pair to confirm.
• If the pairing is successful, your phone connects to the device.
To disconnect/unpair from a Bluetooth device
• Touch the Settings icon beside the device you want to unpair.
• Touch Unpair to confirm.
• Block pop-up
windows
Mark the checkbox to prevent pop-up windows.
• Text encoding Touch to select the character-encoding standard.
• Reset to default Touch to clear all browser data and to reset all
settings to default.
Bandwidth management
• Search result
preloading
Touch to enable/disable browser to preload
search results in the background.
• Web page
preloading
Touch to enable/disable browser to preload the
linked web pages in the background.
• Load images Mark to display images on web pages.
Labs
• Quick controls Mark to enable quick controls.
• Fullscreen Mark to use the fullscreen mode.
6.3 Connecting to Bluetooth devices (1)
Bluetooth is a short-range wireless communication technology that you
can use to exchange data, or connect to other Bluetooth devices for
various uses.
To access this function, drag down notification panel and touch to
access Settings. Then touch Bluetooth, your device and other available
ones will show on the screen.
To turn on Bluetooth
• Drag down notification panel and touch to access Settings.
(1) You are recommended to use ALCATEL ONE TOUCH Bluetooth headsets,
which have been tested and proved compatible with phone. You can go
to www.alcatelonetouch.com for more information about ALCATEL ONE
TOUCH Bluetooth headset.
![](asset-2e.png)
89 90
To share your phone's data connection via USB
Use the USB cable that along with your phone to connect the phone to a
USB port on your computer.
• Drag down notification panel and touch to access Settings.
• Touch More...\Tethering & portable hotspot.
• Mark\unmark the checkbox of USB tethering to activate/deactivate
this function.
To share your phone's data connection as a portable Wi-Fi hotspot
• Drag down notification panel and touch to access Settings.
• Touch More...\Tethering & portable hotspot.
• Mark\unmark the checkbox of Portable Wi-Fi hotspot to activate/
deactivate this function.
To rename or secure your portable hotspot
When Portable Wi-Fi hotspot is activated, you could change the name of
your phone's Wi-Fi network (SSID) and secure its Wi-Fi network.
• Drag down notification panel and touch to access Settings.
• Touch More...\Tethering & portable hotspot.
• Touch Set up Wi-Fi hotspot to change the network SSID or set your
network security.
• Touch Save.
6.4 Connecting to a computer
With the USB cable, you can transfer media files and other files between
your microSD card/phone's internal storage and the computer. Before
using this MTP, you should firstly unmark USB debugging via Settings\
About phone\Advanced settings\USB debugging.
To connect your phone to the computer:
• Use the USB cable that came with your phone to connect the phone to
a USB port on your computer. You will receive a notification that the
USB is connected.
• Your phone will automatically be connected as a media device to transfer
files.
Before using MTP, make sure that the driver (Windows Media
Player 11 or above version) has been installed.
To format a microSD card
• Drag down notification panel and touch to access Settings.
• Touch Storage.
• Touch Format SD card. On the screen a popup warns you that
formatting the microSD card will erase its contents, touch .
6.5 Sharing your phone's mobile data connection
You can share your phone's mobile data connection with a single
computer via a USB cable(USB tethering) or with up to eight devices at
once by turning your phone into a portable Wi-Fi hotspot.
The functions below may incur additional network charges from
your network operator. Extra fees may also be charged in roaming
areas.
![](asset-2f.png)
91 92
To edit/delete a VPN
To edit a VPN:
• Drag down notification panel and touch to access Settings.
• Touch More...\VPN settings
• VPNs you have added are listed; touch & hold the VPN you want to edit.
• Touch Edit profile.
• After finished, touch Save.
To delete:
• Touch and hold the VPN you want to delete, in the dialog that opens,
touch Delete profile.
• Touch OK to confirm.
6.7 Configuring Internet (SIP) calling
You can place/receive voice calls via the Internet when connected to a
Wi-Fi network, rather than via your mobile network. You should configure
a valid internet account before using this feature. Refer to section 3.1.1
Placing a call to learn more about placing an internet call.
To add an internet calling account
• Touch the Application tab from the Home screen and then select Phone.
• Touch Settings\Call settings\Internet call\Use Internet call.
• Mark the checkbox to enable Internet calling.
• Touch Accounts, then touch ADD ACCOUNT tab.
• In the screen that opens, follow the instructions from your internet
calling service provider to configure the settings for your account.
• When finished, touch SAVE to confirm or touch DISCARD to cancel.
6.6 Connecting to virtual private networks
Virtual private networks (VPNs) allow you to connect to the resources
inside a secured local network from outside network. VPNs are commonly
deployed by corporations, schools, and other institutions so that their
users can access local network resources when not inside that network,
or when connected to a wireless network.
To add a VPN
• Drag down notification panel and touch to access Settings.
• Touch More...\VPN settings\Add VPN profile
• In the screen that opens, follow the instructions from your network
administrator to configure each component of the VPN settings.
• Touch Save.
The VPN is added to the list on the VPN settings screen.
Before adding a VPN, you should set a PIN code or password for
your phone.
To connect/disconnect to a VPN
To connect to a VPN:
• Drag down notification panel and touch to access Settings.
• Touch More...\VPN settings
• VPNs you have added are listed; touch the VPN you want to connect with.
• In the dialog that opens, enter any requested credentials and touch
Connect.
To disconnect:
• Open the Notification panel and touch the resulting notification for the
VPN disconnection.
![](asset-30.png)
93 94
7 Google Play Store (1) .......
Google Play Shop is an online software store, where you can download
and install applications and games to your Android Powered Phone.
To open Google Play Shop:
• Touch Application tab from the Home screen, then touch Play Store.
• For the first time you access Google Play Shop, a screen with terms of
service pops up for your attention, touch Accept to continue.
Touch Menu icon , then touch Help to enter Google Play Shop help page
for more information on this function.
7.1 Locate the item you want to download
and install
Google Play Shop home page provides several ways to find applications. It
showcases applications and games in categorized listings.
Touch Menu icon and My Apps to see all your downloads.
Touch to search in Play Store.
Slide left and right to see all categories.
(1) Depending on your country and operator.
To edit/remove an internet calling account
To edit:
• Touch the Application tab from the Home screen and then select Phone.
• Touch Settings\Call settings\Internet call\Accounts.
• Accounts you have added are listed; touch the account you want to edit.
• Edit your chosen settings. When finished, touch SAVE.
To remove:
• Touch the account you want to remove.
• Touch and Remove account.
To configure your phone to receive Internet calls
Receiving Internet incoming calls is off by default to reduce power
consumption.
• Touch the Application tab from the Home screen and then select Phone.
• Touch Settings\Call settings\Internet call\Accounts\Receive
incoming calls.
• Mark/Unmark the checkbox to activate/deactivate this function.
![](asset-31.png)
95 96
Be especially cautious with applications that have access to many
functions or to a significant amount of your data. Once you accept,
you are responsible for results of using this item on your phone.
To open the application you have downloaded:
• On Google Play Shop screen, touch Menu icon and My apps.
• Touch the installed application in the list, then touch Open.
To buy an application(1)
On Google Play Shop, some applications are labeled as free, while some
of them are to be paid for before downloading and installing.
• Touch the application you want to buy.
• Touch the price on the up-right of the screen to preview the functions
and data the application can access on your phone if you install it.
• Touch Continue to confirm.
• When making your first purchase, you are required to input your credit
card information and to log in to Google payment and billing service.
• If your account has multiple credit card accounts, select one to proceed.
• Select the Terms of service link and read the document. When finished,
touch Back key.
• Mark the checkbox if you agree with the terms of service.
• Touch Buy now at the bottom of the screen.
When finished, Android downloads the application.
(1) Google Paid applications may not be available to users in some countries.
Touch a category on Google Play Shop screen to browse its contents.
You can also select a subcategory if there is any. Within each category you
can select to view items sorted by Top paid, Top free, Top grossing, etc
Touch the Google Play Shop icon on the top left of the screen or
touch Back key to return to the previous screen.
7.2 Download and install
To download & install:
• Navigate to the item you want to download, and select to enter the
details screen from which you can read its description, overall rating or
comments, view developer’s information, etc.
• Touch Install to preview the functions and data the application can
access on your phone if you install it.
• Touch Accept & download.
• The progress of the download will show on the details screen, touch
to stop downloading the item. You can also access this screen through
Notificaiton panel.
• After download and installation have finished, you will see a notification
icon on the status bar.
![](asset-32.png)
97 98
Update notification
On Google Play Shop screen, touch Menu icon and My apps. Touch
Menu icon and Settings\Notifications to enable update notification.
Auto update
To auto update all installed applications, touch Menu icon and My apps
from Google Play Shop screen. Touch Menu icon and Settings\Auto-
update apps to enable this function.
Rate and review
Open the details screen for an application, touch the stars
under RATE & REVIEW to award and input comments, touch OK to
confirm.
Flag
You can report an inappropriate application to Google Play Shop by
flagging it. Open the details screen for the application, scroll to the bottom
and touch Flag as inappropriate, enter the reason and finally touch
Submit.
To request a refund
If you are not satisfied with the application, you can ask for a refund within
15 minutes of the purchase. Your credit card will not be charged and the
application will be removed. If you change your mind, you can install the
application again, but you will not be able to request a refund.
• Touch Menu icon and My apps from Google Play Shop screen.
• Touch the application that you want to uninstall and refund.
• Touch Refund to uninstall the application and refund. If the button
becomes Uninstall, your trial period has expired.
• In the survey form, select the answer that best matches your reason,
and touch OK.
7.3 Manage your downloads
After you downloaded and installed an application, the following further
operations are available for your selection.
View
On Google Play Shop screen, touch Menu icon and My apps.
Uninstall
On Google Play Shop screen, touch Menu icon and My apps. Touch
the application you want to uninstall to enter the details screen, touch
Uninstall, and finally touch OK to confirm.
Refund
On Google Play Shop screen, touch Menu icon and My apps. Touch the
application you want to uninstall for a refund, touch Refund, and finally
touch OK to confirm.
![](asset-33.png)
99 100
To take a picture
The screen acts as the viewfinder. First position the object or landscape in
the viewfinder, touch the screen to focus if necessary, touch icon to
take the picture which will be automatically saved.
To shoot a video
Switch Camera mode to Video mode. First position the object or
landscape in the viewfinder, and touch icon to start recording. Touch
icon to stop recording. The video will be automatically saved.
Further operations when viewing a picture/video you have taken
• Touch the icon of gmail, Bluetooth, MMS, etc to share the photo or
video you have taken.
• Touch the photo to access Gallery.
• Touch the Back key to return to camera or Camcorder.
8 Multimedia applications
8.1 Camera .......................................................
Your mobile phone is fitted with a Camera for taking photos and shooting
videos.
Before using the Camera, please ensure that a microSD card where all
pictures and videos are stored is correctly installed. Also, be sure to open
the protective lens cover before use to avoid it affecting your picture
quality.
To access this function, touch Application tab from the Home screen and
then touch Camera.
Touch to view
pictures or videos
you have taken.
Drag up and
down to switch
between Camera
and Video mode. Touch to take a picture or
record a video. Touch &
hold to enable burst shoot.
Touch to
show settings.
Drag left and right
to zoom in/out.
Touch the screen
to set a focus.
Touch to switch
between front/back
camera
![](asset-34.png)
101 102
8.2 Gallery ..........................................................
Gallery acts as a media player for you to view photos and playback videos.
In addition, a set of further operations to pictures and videos are available
for your choice.
To access this function, touch Application tab from the Home screen, then
touch Gallery.
Touch to open camera.
Touch the album to
spread it apart.
Slide left or right to
view more albums.
Touch to select
categories:
Albums, Locations,
Times, People and
Tags.
8.1.1 Settings in framing mode
Before taking a photo/shooting a video, touch the icon and to adjust
a number of settings in framing mode.
Camera settings
• Scene Mode Touch to adjust the scene: Auto, Night, Sunset,
Party, etc.
• Exposure Touch to adjust the value of exposure.
• White balance Touch to adjust color in different lights: Auto,
Incandescent, Daylight, Fluorescent, Cloudy,
etc.
• Capture mode Touch to adjust the capture mode: Normal,
HDR, Auto scene detect, Smile shot, etc.
• Grid Touch to turn on/off grid.
Touch the icon to to set Store location, Shutter sound, Picture size,
ISO, etc.
Camcorder settings:
• Scene Mode Touch to adjust the scene: Auto, Night.
• Exposure Touch to adjust the value of exposure.
• White balance Touch to adjust color in different lights:
Auto, Incandescent, Daylight, Fluorescent or
Cloudy.
• Time lapse interval Touch to set time lapse interval.
Touch the icon to set Store location, Shutter sound, Microphone,
Duration, Video quality, etc.
![](asset-35.png)
103 104
Touch menu icon and choose Edit to edit a picture.
Touch to adjust whitebalance: Fill Lights, Highlights, Shadows, Auto-fix.
Touch to adjust effects: Cross-Process, Posterize, Lomo, etc.
Touch to adjust the color: Warmth, Saturation, B&W. Sepia, etc.
Touch to see more edit options: Crop, Red Eye, Rotate, Flip, etc.
Touch to undo last edit operation.
Touch to retrieve last undo.
Touch to save the picture when the edit is done.
Touch to exit edit mode.
After activating the crop mode, the cropping square appears in the
middle of the picture. Select the portion to crop, touch Crop to
Save, touch Back key to exit without saving.
Batch operation
Gallery provides a multi-select function, so that you can work with
pictures/videos in batches.
Open the main Gallery window or an album, touch menu icon and
Select album or Select item to activate batch operation mode (you can
also touch and hold one album/picture), then touch albums/pictures you
want to work on. Touch icon to perform further actions, like delete and
rotate. Touch to share selected ones.
To view a picture/play a video
Pictures and videos are displayed by albums in Gallery.
Touch to play the
slideshow.
Slide left or right to
view more pictures.
Touch to return to
gallery's main screen
• Touch an album and all pictures or videos will spread the screen.
• Touch the picture/video directly to view or play it.
• Slide left/right to view previous or next pictures/videos.
Working with pictures
You can work with pictures by rotating or cropping them, sharing them
with friends, setting them as contact photo or wallpaper, etc.
Locate the picture you want to work on, touch the picture from full-
screen picture view. Slide the picture bar below left and right to select one,
touch icon to share the picture, touch icon (only show in landscape
mode)and delete to delete the picture.
Touch menu icon from full-screen picture view, more options will show
for you to choose.
![](asset-36.png)
105 106
8.3.1 Watch videos
Touch a video to play it. In the Playing screen, you can view information
and video comments, and also browse links to related videos.You can also
rate, share, label as favorite, create a new playlist, etc from this screen.
To exit video playing screen, touch Back key to return to the video list.
8.4 Music ............................................................
Using this menu, you can play music files stored on the microSD card in
your phone. Music files can be downloaded from computer to microSD
card using a USB cable.
To access this function, touch Application tab from the Home screen, then
touch Music.
You will find four categories in which all songs are classified: Artists,
Albums, Songs and Playlists. Slide left and right to view all. Touch Menu
icon and Shuffle all to shuffle all songs,
8.3 YouTube ......................................................
YouTube is an online video-sharing service where the user can download,
share and view videos. It supports a streaming function that allows you
to start watching videos almost as soon as they begin downloading from
the Internet.
To access this function, touch Application tab from the Home screen, then
touch YouTube.
As an online video service, your phone must have a network
connection to access YouTube.
All videos in YouTube are grouped into several categories, like Most
Popular, Most Discussed, Featured Videos, etc.
Touch to play the video and
to show more information
Touch to search for a video.
Touch to shoot a video.
Touch to show videos'
categories.
By touching Menu icon from YouTube screen, you can set General
settings and Search settings for YouTube.For details about these features,
please visit the YouTube website: www.YouTube.com
![](asset-37.png)
107 108
8.4.2 Working with playlists
Playlists allow you to conveniently organize all songs stored in the SD card.
You can create a new playlist, add a song to the list, and delete or rename
a playlist.
To create a playlist
Touch Recently added from Playlists screen, touch and then Save as
playlist, enter the name and finally touch Save.
To delete a playlist
Touch and hold a playlist to show the menu, then touch Delete.
To rename a playlist
Touch and hold a playlist to show the menu, then touch Rename. When
finished, touch Save to confirm.
8.5 Video Player ................................................
To access this function, touch Application tab from the Home screen, then
touch Video player.
Video player is a small built-in video player that lists all your videos.
Touch an item from the list to play. While playing, use Pause, Forward and
Back functional icons as required, touch a point on the timeline to jump
to and play from.
8.4.1 Playing music
Touch a song or touch Play from drop-down menu to play the song.
Touch to play the current playlist in shuffle mode (tracks are played in
random order).
Touch to select repeat mode: Repeating all songs, Repeating current
song, or Repeat is off.
Touch to skip to the previous track in the album, playlist, or shuffle.
Touch to skip to the next track in the album, playlist, or shuffle.
Touch to pause/resume playback.
Touch to show the displaying song.
While playing songs with Play Music, the operation of pause, play
or skip is still available even if the screen is locked.
Adjust sound effects
Touch Menu icon and Sound effects from Now playing screen to
enable and adjust sound effects.
![](asset-38.png)
109 110
To move the map, drag the map with your finger.
To zoom in and out of a map, pinch or spread your fingers, or you can also
zoom in by double-tapping a location on screen.
To clear the map history, touch Menu icon and Clear Map.
9.2 Search for a location
While viewing a map, touch the search icon to activate search
function.
In the search box, enter an address, a city or a local business.
Touch the icon to search, and in a while your search results will appear
on the map as red dots. You can touch one to show a label.
Touch to show all
search results list
Touch to show
more information
9.3 Star a location
Just like bookmarking a web address on the Internet, you can star any
position on the map for later use.
9.3.1 How to star (or unstar) a location
Touch & hold a location on a map
Touch the address rectangle that opens
9 Google Maps ...................
9.1 Get My Location
9.1.1 Choose a data source to decide My Location
Drag down notification panel and touch to access Settings, touch
Location services.
Mark the checkbox of Google's location service to set Wi-Fi and/or
mobile networks as My Location data source.
Or mark the checkbox of GPS satellites to set GPS as My Location
data source.
9.1.2 Open Google Maps and view My Location
Touch Application tab from the Home screen, then touch Maps.
Touch icon on the map to view My Location.
The map will then center on a blue dot with a blue circle around. Your
actual position is within the blue circle.
![](asset-39.png)
111 112
• Touch enter bar or the triangle to edit your start point by one of the
following methods: entering an address, using My Location, selecting a
start point on a map, selecting a starred item, selecting an address from
your contacts or using search history.
• Do likewise for your end point.
• To reverse directions, touch Menu icon and touch Reverse Start
& End.
• Then select a transport mode: driving by car, using public transportation,
or walking directions.
• Finally touch GET DIRECTIONS.
• A couple of suggested routes will appear in a list. Touch any routes to
view their respective detailed directions.
To get reverse directions for a route you’ve already made, simply open
that route’s directions window and touch Menu icon and Reverse. No
need to enter your start point and end point again.
9.4.2 Preview suggested routes and decide on a route
more preferable or feasible to you
You can preview each turn in your route in Navigation, Satellite, and
other views.
• Touch a left or right arrow to preview the next or previous leg of your
route.
• You can view turn-by-turn directions, estimated distance and possible
arrival time in a list by touching DIRECTIONS LIST, touch Back key
or MAP VIEW to return to previous view.
When selecting a more preferable or feasible route, distance and time
will be the two most important factors for your evaluation. Distance and
estimated time will be displayed at the top of the directions screen.
Touch the gray star at the top of the screen to star the location. (Or touch
a gold star to unstar that location.)
9.3.2 View a list of starred items
Touch Maps at the upper-left corner, and touch My Places.
The list of your starred items and their addresses opens.
Touch a location in the list to view it.
9.4 Get driving, public transportation or walking
directions
9.4.1 Get suggested routes for your trip
Touch icon from Maps screen.
![](asset-3a.png)
113 114
9.6 Join Latitude to see your friends' locations
and share yours with them
With Google Latitude, you can:
• see your friends' locations on a map or in a list.
• quickly contact your friends with a text message, instant message, or
phone call.
• you can share, set, hide your location, or sign out of Google Latitude.
• control who sees your location, and at what level of detail.
• add Latitude widget to Home screen to see nearby friends at a glance.
9.6.1 To join Latitude
Touch Maps at the upper-left corner, and select Join Latitude.
To open Latitude, touch icon from Maps screen, then select Latitude.
9.6.2 How to invite friends to share their locations
• Touch icon from list view.
• Touch Select from Contacts or Add via email address.
• After selecting your chosen contacts touch Add friends at the bottom
of the screen.
When finished, an invitation will be sent to the friends you have invited.
To respond to an invitation, you can select one of the followings:
• Accept and share
back
You and your friend can share locations with
each other.
• Accept, but hide
my location
You can view your friend's location, but they can
not view yours.
• Don’t accept No locations can be shared between you and
your friend.
9.4.3 Search for locations along your route
Please refer to “9.2 Search for a location” for detailed information.
9.5 Arrangement of Layers
Layers allow you to view locations and additional information overlaid on
the map. You can add multiple layers or remove only certain layers so you
control exactly what information you want visible on the map at one time.
9.5.1 To view multiple layers
Touch icon from Maps screen. All available layers are listed (like Traffic,
Satellite, Terrain, etc), select one to view.
9.5.2 To open Street View for a location
• Touch and hold a location to display a balloon with the address and a
Street View thumbnail.
• Touch the balloon and touch Street view.
9.5.3 To clear the map
After you get directions or search on a map, you can clear the markers/
layers that have been drawn: touch Menu icon on maps screen and
touch Clear Map, or you can also touch Clear Map on Layers screen.
![](asset-3b.png)
115 116
9.6.5 To control what you share
You can control the information you want to share with your friends.
Touch icon from Maps screen, then select Latitude, touch your own
name and then touch Location settings.
The following options are available to choose from:
• Location reporting Touch to detect/set your location, or stop
updating your location.
• Enable location
history
Mark to hide your location history.
• Reporting from this
device
Mark the checkbox to automatically update
your location from this device.
• Enable location
sharing
Mark the checkbox to share your location with
the people you choose.
• Manage your
friends.
Add or remove friends who can see your
location.
9.6.3 To view your friends' location
You can view your friends' locations on a map or in a list.
• MAP VIEW When Google Maps is opened, your friends'
locations will display with their photo icons for
identification.
• FRIENDS LIST Your friends are displayed in a list.
9.6.4 To connect with your friends
Select a contact, you can communicate with your friend and set privacy
options.
• Map Locate the friend's position on the map.
• Directions Get directions to this friend's location.
• Street view Touch to show panoramic views from positions
along many streets in the world.
• Ping for check-in Send friends a notification and ask them to
check in.
• Manage sharing Touch to set sharing options: Share best
available location; Share city-level location only;
Hide from this friend
• Remove this friend Remove this friend from your list and stop
sharing information with him or her.
![](asset-3c.png)
117 118
10.3 Radio ............................................................
Your phone is equipped with a radio (1) with RDS (2) functionality. You
can use the application as a traditional radio with saved channels or with
parallel visual information related to the radio program on the display if
you turn to stations that offer Visual Radio service.
To access this function, touch Application tab from the Home screen, then
touch Radio.
To use it, you must plug in your headset, which works as an
antenna connected with your phone.
Touch to go to previous
saved channel
Touch to add the
current station to
favorites
Touch to open
and view the saved
channels list
Touch to play/stop
Touch to go to next
saved channel
Touch to decrease 0.1MHz
Touch and hold to search
and go to the nearest lower
frequency channel
Touch to increase 0.1MHz
Touch and hold to search
and go to the nearest
higher frequency channel
(1) The quality of the radio depends on the coverage of the radio station in that
particular area.
(2) Depending on your network operator and market.
10 Others .................................
10.1 File Manager .................................................
To access this function, touch Application tab from the Home screen, then
touch File Manager.
File Manager works with both external SD card and internal SD card. To
use it, you have to install your SD card first. See “Installing or removing
the microSD card”.
File Manager displays all data stored on both microSD cards, including
applications, media files; videos, pictures or audios you have captured;
other data transferred via Bluetooth, USB cable, etc.
When you download an application from PC to microSD card, you can
locate the application on File Manager, then touch it to install it in your
phone.
File Manager allows you to perform and be really efficient with the
following common operations: create (sub) folder, open folder/file, view,
rename, move, copy, delete, play, share, etc.
10.2 Sound Recorder ...........................................
To access this function, touch Application tab from the Home screen, then
touch Sound Recorder.
Sound Recorder allows you to record voice/sound for seconds/hours.
![](asset-3d.png)
119 120
10.5 Alcatel Help ...............................................
To access this function, touch the Application tab from the Home screen,
then touch Alcatel Help.
Alcatel Help provides help when you have questions or need assistance
when using the phone.
10.6 Other applications (1) .........................................
The previous applications in this section are preinstalled on your phone.
To read a brief introduction of the preinstalled 3rd party applications,
please refer to the leaflet provided with the phone. You can also download
thousands of 3rd party applications by going to Google Play Store on your
phone.
(1) Application availability depends on country and operator.
Available options:
• Save channel Save the current tuned station to the channels
list.
• Audio mode Listen to the radio using loudspeaker or headset.
• Exit Turn off the radio.
• Enter frequency Enter the frequency manually.
• Delete Delete the channel
• RDS settings Select radio data system as channel information
or alternative frequency.
• Record FM Record video voice of the current channel.
• Search Search for all available stations automatically.
10.4 Setup Wizard ............................................
To access this function, touch the Application tab from the Home screen,
then touch Setup Wizard.
Setup Wizard helps set up your phone in multiple ways: language, input
method, mobile data connection, account setup and synchronization,
system update, etc. This will also be performed the first time you power
on your phone.
![](asset-3e.png)
121 122
11.1.2 Wi-Fi
Using Wi-Fi you can now surf the Internet without using your SIM card
whenever you are in range of a wireless network. The only thing you
have to do is to enter the Wi-Fi screen and configure an access point to
connect your phone to the wireless network.
For detailed instructions on using Wi-Fi, please refer to “6.1.2 Wi-Fi”.
11.1.3 Bluetooth
Bluetooth allows your phone to exchange data (videos, images, music,
etc.) in a small range with another Bluetooth supported device (phone,
computer, printer, headset, car kit, etc.).
For more information on Bluetooth, please refer to “6.3 Connecting to
Bluetooth devices”.
11.1.4 Data usage
To enable/disable mobile data by touching the switch .
Mark the checkbox of Set mobile data limit, then you can drag the
limit line and the warning line according to your limitation. Your mobile
data connection will be disabled when the specified limit is reached. You
can also choose a data usage cycle to view the statistics and related
applications of used data by your phone.
Touch the Menu icon , and you can view more settings related to your
data usage.
Data usage is measured by your phone, and your carrier may count
differently. Please consider using a conservative limit.
11 Settings .........................
Drag down notification panel and touch to access Settings.
11.1 Wireless & networks
11.1.1 SIM management
SIM management option only exists under Dual SIM status.
• SIM information
Touch to edit SIM name, enter phone number, set background color and
display numbers.
• Default SIM
Touch to select SIM for voice call, video call, messaging and data
connection.
• General settings
Roaming
Touch to turn on/off data roaming and show roaming reminder.
Contacts & SIM
Select to associate contacts with a specific SIM.
123 124
11.1.8 Mobile networks
• Data connection
Touch to turn on/off data connection.
• 3G service
Touch to turn on/off 3G service and select network mode.
• Access Point Names
You can select your preferred network with this menu.
• Network operators
You can select a network operator.
• Mobile data priority mode
Mark the checkbox to allow mobile data transmission at full speed.
11.2 Device
11.2.1 Gestures
• Turn over to mute
Mark the checkbox to mute incoming calls by turning the phone over.
• Turn over to activate
Select to snooze or dismiss the alarm.
• Shake to switch music
Mark the checkbox to shake to switch to the next song when your phone
is unlocked.
11.1.5 Airplane mode
Mark the checkbox of Airplane mode to simultaneously disable all
wireless connections including Wi-Fi, Bluetooth and more.
11.1.6 VPN settings
A mobile virtual private network (mobile VPN or mVPN) provides mobile
devices with access to network resources and software applications on
their home network, when they connect via other wireless or wired
networks. Mobile VPNs are used in environments where workers need to
keep application sessions open at all times, throughout the working day,
as the user connects via various wireless networks, encounters gaps in
coverage, or suspend-and-resumes their devices to preserve battery life. A
conventional VPN cannot survive such events because the network tunnel
is disrupted, causing applications to disconnect, time out, fail, or even the
computing device itself to crash.
For more information on VPN, please refer to “6.6 Connecting to
virtual private networks”.
11.1.7 Tethering & portable hotspot
This function allows you to share your phone's mobile data connection via
USB or as a portable Wi-Fi access point (Please refer to “6.5 Sharing your
phone's mobile data connection”).
125 126
Silent
This profile will silence all sounds except media & alarms.
Meeting
When this is selected the phone will not ring or beep by default unless an
alarm has been set. A new event will cause it to vibrate.
Outdoor
This profile is designed for outdoor users who require louder ringtones.
11.2.3 Display
• Brightness Touch to adjust the brightness of the screen.
• Wallpaper Touch to set the wallpaper.
• Orientation Touch to select whether rotate screen automatically
or not.
• Sleep Touch to set screen timeout.
• Font size Touch to set the fond size.
11.2.4 Storage
Use these settings to monitor the total and available space on your
phone and on your microSD card; to manage your microSD card; and if
necessary, to reset the phone, erasing all of your personal information.
Default write disk
Touch to select your storage device as SD card or Phone storage.
11.2.2 Audio profiles
Use the Audio profiles settings to configure ringtones for different events
and environments.
General
To modify the sound settings within any profile, touch General to view the
following functions by scrolling up/down. When finished, mark the check
box on the right of the profile's name to activate the action.
• Phone vibrate Mark the check box to vibrate phone for
incoming calls.
• Volume Touch to set volume for incoming calls, alarm
and notifications.
• Voice call ringtone Touch to set your default voice incoming call
ringtone.
• Video call
ringtone
Touch to set your default video incoming call
ringtone.
• Default
notification
Touch to set your default notification ringtone.
• Dial pad touch
tones
Mark the check box to enable playing tones when
using dial pad.
• Audible selection Mark the check box to enable playing sound
when making screen selection.
• Screen lock sound Mark the check box to enable sounds to play
when locking and unlocking the screen.
• Haptic feedback Mark the check box to activate vibration when
pressing soft keys and on certain UI interactions.
• Power on ringtone Set your default power on ringtone.
• Shut down
ringtone
Set your default power off ringtone.
![](asset-41.png)
127 128
11.2.5 Battery
In battery screen you can view the battery usage data since you last
connected the phone to a power source. The screen also shows your
battery status and how long it has been used since last charging. Touch one
category, then you can learn its specific power consumption.
You can adjust power use via the screen brightness or screen timeout in
Display screen.
11.2.6 Applications
You use the Applications settings to view details about the applications
installed on your phone, to manage their data and force them to stop, and
to set whether you want to permit installation of applications that you
obtain from web sites and emails.
11.3 Personal
11.3.1 Location services
Google's location service
Mark the checkbox to let apps determine your approximate location.
GPS satellites
Mark the checkbox to let apps pinpoint your location.
Check to use your phone’s global positioning system (GPS) satellite
receiver to pinpoint your location within an accuracy as close as several
meters (“street level”). The process of accessing the GPS satellite and
setting your phone's precise location for the first time will require up to
5 minutes. You will need to stand in a place with a clear view of the sky
and avoid moving. After this, GPS will only need 20-40 seconds to identify
your precise location.
Phone storage
This menu displays the amount of internal phone storage in different
colours. The available space will be shown in grey, which shows the amount
of internal phone storage used by the operating system, its components,
applications (including those you downloaded), permanent and temporary
data.
If a warning message comes up saying that phone memory is
limited, you are required to free up space by deleting some
unwanted applications, downloaded files, etc.
SD card
Lists the amount of space on any microSD card installed in your phone
and the amount you can use to store applications, videos, music, and other
files. you can touch one category to access the function and learn more
in details
Mount/Unmount SD card
You must mount the microSD card before using applications and files in it,
or formatting the microSD card. Unmount the microSD card from your
phone so that you can safely remove it when the phone is on.
Format SD card
Permanently format everything on a microSD card and prepares it for use
with your phone.
129 130
Make passwords visible
Mark the checkbox to show passwords as you type.
Device administrators
Touch to view or deactivate device administrators.
Unknown sources
Mark the checkbox to permit installation of applications that you obtain
from web sites, emails, or other locations other than Play Store.
To protect your phone and personal data, download applications only
from trusted sources, such as Play Store.
Trusted credentials
Touch to display trusted CA certificates.
Install from SD card
Touch to install encrypted certificates from the microSD card.
Clear storage
Touch to remove all certificates.
11.3.3 Language & input
Use the Language & input settings to select the language for the text on
your phone and for configuring the onscreen keyboard. You can also
configure voice input settings and the pointer speed.
Language
Touch to select the language and the region you want.
Location & Google search
Mark the checkbox to let Google use your location to improve search
results and other services.
11.3.2 Security
Screen lock
• None Touch to disable screen unlock security.
• Slide Touch to enable slide unlock mode.
• Pattern Touch to draw pattern to unlock screen.
• PIN Touch to enter a numeric PIN to unlock screen.
• Password Touch to enter a password to unlock screen.
Owner info
Touch to input owner information which will display on the lock screen.
Encrypt phone
You can encrypt your accounts, settings,download apps and their data,
media and other files by touching Encrypt phone.
Set up SIM card lock
Choose a SIM card you want to configure.
Mark the checkbox of Lock SIM card to lock the SIM card with PIN
code.
Touch Change SIM PIN to change the PIN code.
![](asset-43.png)
131 132
• Popup on key press
Mark the checkbox to popup the key that you touched.
• Voice input key
Touch to activate/inactivate voice input key.
• Add-on dictionaries
Touch to add other dictionaries.
• Auto-correction
Touch to turn on/off auto correction, or you can also adjust the sensitivity
of correction.
• Show correction suggestions
Touch to show or not the correction suggestions while typing.
• Advanced settings
Touch to view more advanced settings for android keyboard, such as Key
pop-up dismiss delay, Suggest Contact name, and etc.
Google voice typing
• Choose input languages
Mark the checkbox to set Google voice typing automatically.
• Block offensive words
Mark the checkbox to hide recognized offensive text.
Spell checker
Mark the checkbox to enable the system to show suggested words.
Personal dictionary
Touch to open a list of the words you’ve added to the dictionary. Touch a
word to edit or delete it. Touch the add button (+) to add a word.
Default
Touch to select a default input method. Touch Configure input
methods to show all input methods. Touch the settings icon to
configure a certain input method.
Android keyboard
The Android keyboard settings apply to the onscreen keyboard that is
included with your phone. The correction and capitalization features affect
only the English version of the keyboard. Available options are as follows:
• Input languages
Touch to set input language.
• Auto-capitalisation
Mark the checkbox to have the onscreen keyboard automatically capitalize
the first letter of the first word after a period, the first word in a text field,
and each word in name fields.
• Vibrate on key press
Mark the checkbox to have the phone vibrate briefly each time you touch
a key on the onscreen keyboard.
• Sound on key press
Mark the checkbox to play a brief sound each time you touch a key on
the onscreen keyboard.
133 134
Quick “.”
Mark the checkbox to enable double tapping the spacebar to inserts a
period.
AutoCaps
Mark the checkbox to automatically capitalize words.
Audio & haptic feedback
Touch to customize sounds and haptic on keypress.
Voice recognition
Touch to enable voice recognition key.
Long-press duration
Set the time needed while long press a key.
Portrait key height
Set the key height on the portrait keyboard.
Landscape key height
Set the key height on the landscape keyboard.
Bluetooth keyboard layout
Select keyboard layout as English (US), Italian, Spanish, etc.
Remove old Swiftkey
Remove an old Swiftkey version.
• Swiftkey 3 stats
Touch to see your usage statistics such as typing efficiency, saved
keystrokes, corrected typos on Swiftkey 3.
SwiftKey3
• Languages & layouts
Touch to select language installation.
• Personalization
Select to restore writing style and new words you have used, or clear
them.
• Theme
Theme
Touch to select the theme as light, cobalt, berry, etc.
Show foreign characters
Mark the checkbox to enable all long-press foreign characters.
Arrow keys
Mark the checkbox to hide arrow keys.
Split layout
Mark the checkbox to enable split keyboard layout in landscape.
• Advanced
Typing style
Select typing style as precise or rapid.
Spacebar will…
Select the function of spacebar.
![](asset-45.png)
135 136
Pointer speed
Touch to open a dialog where you can change the pointer speed, touch
OK to confirm.
11.3.4 Backup and reset
Back up my data
Mark the checkbox to back up your phone’s settings and other application
data to Google Servers, with your Google Account. If you replace your
phone, the settings and data you’ve backed up are restored onto the new
phone for the first time you sign in with your Google Account. If you mark
this option, a wide variety of settings and data are backed up, including
your Wi-Fi passwords, bookmarks, a list of the applications you’ve
installed, the words you’ve added to the dictionary used by the onscreen
keyboard, and most of the settings that you configure with the Settings
application. If you unmark this option, you stop backing up your settings,
and any existing backups are deleted from Google Servers.
Back up account
Touch to back up your account.
DRM reset
Touch to deletes all DRM licenses.
Automatic restore
Mark the checkbox to restore back up settings or other data.
• How-to videos
Touch to enter a web page on how to use Swiftkey 3.
• About Swiftkey 3
Touch to learn more information about Swiftkey 3, such as terms of
service and privacy.
Voice search
• Language
Set voice search language.
• Speech output
Select speech output as always, informative only or hands-free only.
• Block offensive words
Mark the checkbox to hide recognized offensive voice results.
• Bluetooth headset
Mark the checkbox to record audio through Bluetooth headset if available.
Text-to-speech settings
• Prefered engine
Touch to choose a preferred text-to-speech engine, touch the settings
icon to show more choices for each engine.
• Speech rate
Touch to open a dialog where you can select how quickly you want the
synthesizer to speak.
• Listen to an example
Touch to play a brief sample of the speech synthesizer, using your current
settings.
137 138
Set date
Touch to open a dialog where you can manually set the phone’s date.
Set time
Touch to open a dialog where you can manually set the phone’s time.
Select time zone
Touch to open a dialog where you can set the phone’s time zone.
Use 24-hour format
Mark the checkbox to display the time using 24-hour clock format.
Select date format
Touch to open a dialog where you can select the format for displaying
dates.
NTP server
Select the type of NTP servers.
11.5.2 Schedule power on/off
Touch to set automatic power on/off time.
11.5.3 Accessibility
You use the Accessibility settings to configure any accessibility plug-ins you
have installed on your phone.
Talkback
Touch to turn/off the function which provides spoken feedback to help
blind and low-vision users.
Factory data reset
Erase all of your personal data from internal phone storage, including
information about your Google Account, any other accounts, your system
and application settings, and any downloaded applications. Resetting the
phone does not erase any system software updates you’ve downloaded
or any files on your microSD card, such as music or photos. If you reset
the phone in this way, you’re prompted to re-enter the same kind of
information as when you first started Android.
When you are unable to power on your phone, there is another way to
perform a factory data reset by using hardware keys. Press the Volume
up key and the power key at same time until the screen lights up.
11.4 Accounts
Add account
Select to add an account of Facebook, Google, LinkedIn, etc.
11.5 System
11.5.1 Date & time
Use Date & Time settings to customize your preferences for how date
and time are displayed.
Automatic date & time
Mark the checkbox to use network provided time or use GPS provided
time.
Automatic time zone
Mark the checkbox to use network-provided time zone. Or unmark to
set all values manually.
139 140
11.5.5 Qiuck Start
Mark the checkbox to shorten boot time.
11.5.6 About phone
This contains information about things ranging from Legal information,
Model number, Firmware version, Baseband version, Kernel version, Build
number etc.
Advanced settings
Touch to turn on/off more settings options as below:
• Desktop backup password
Touch to set/change/remove desktop full backup password.
Large text
Mark the checkbox to enlarge the screen text.
Power button ends call
Mark the checkbox to end a call by pressing Power key during the call.
Orientation
Mark the checkbox to rotate screen automatically.
Speak passwords
Mark the checkbox to speak passwords while typing.
Touch & hold delay
Touch to adjust the duration of touch and hold delay. This function enables
your phone to differ touch and touch & hold, which may avoid incorrect
operations.
Install web scripts
Touch to open a dialog which asks you to install scripts from Google which
make their web content more accessible. Touch Allow to confirm.
11.5.4 Regulatory & Safety
Touch to view information of product model, manufacture name, IMEI
number and some certification logo or text.
141 142
• Show GPU view updates.
Mark the checkbox to flash the views in the window when drawn with
the GPU.
• Show screen updates
Mark the checkbox to flash relative screen areas when they update.
• Window animation scale
Touch to adjust the animation scale for your window.
• Transition animation scale
Touch to adjust the animation scale while performing transition.
• Animator duration scale
Touch to adjust the animation scale for animator.
• Disable HW overlays
Mark the checkbox to use GPU for screen compositing.
• Force GPU rendering
Mark the checkbox to use 2D hardware acceleration in applications.
• Strict mode enabled
Mark the checkbox to enable strict mode. After enabled, the screen will
flash when applications do long operations on the main thread.
• Show CPU usage
Mark the checkbox to show current CPU usage.
• Profile GPU rendering
Mark the checkbox to measure the rendering time in adb shell dumpsys
gfxinfo.
• Don't keep activities
Mark the checkbox to destroy all activities as soon as you leave.
• Stay awake
Mark the checkbox to prevent the screen from dimming and locking when
the phone is connected to a charger or to a USB device that provides
power. Don’t use this setting with a static image on the phone for long
periods of time, or the screen may be marked with that image.
• Protect SD card
Mark the checkbox to request permission before reading SD card.
• USB debugging
Mark the checkbox to permit debugging tools on a computer to
communicate with your phone via a USB connection.
• Allow mock locations
Mark the checkbox to permit a development tool on a computer to
control where the phone believes it is located, rather than using the
phone’s own internal tools for this purpose.
• Select debug app
Touch to select debug applications if available.
• Wait for debugger
Mark the checkbox to allow debugged application wait for debugger to
attach before executing.
• Show touches
Mark the checkbox to show visual feedback for touches.
• Pointer location
Mark the checkbox to show current touch data.
• Show layout bounds
Mark the checkbox to show bounds, margins, etc.
143 144
12 Making the most of your
phone ..................................
12.1 ONE TOUCH Manager
You can download software upgrade for free from the website (www.
alcatelonetouch.com). ONE TOUCH Manager includes:
• Contacts
It allows you to back up contact entries so that you don't have to worry
about losing, breaking, switching phones or changing service providers.
• Messages
It frees you from painstakingly inputting text on the keypads. All of your
messages are easily accessible and well-organized.
• Photos
It allows you to easily import photos from PC or the handset and organize
them in different albums for better management.
• Videos
It allows you to insert video files from PC for playback and then upload
to handset folder.
• Music
It allows you to quickly search your favourites in PC, manage the ultimate
Library, and enjoy the easiest digital jukebox in your own mobile way.
• Enable traces
Touch to select enabled traces if available.
• Background process limit
Touch to change the limit for background processes.
• Show all ANRs
Mark the checkbox to show "Application Not Responding" dialog for
background applications.
System updates
Touch to check for system updates.
Status
This contains the status of the Battery status, Battery level, My phone
number, Network, Signal strength, etc.
Legal information
Touch to view legal information.
You can learn more information about the phone such as model number,
firmware version, baseband version, kernel version, build number, custom
build version and Bluetooth QD ID.
![](asset-4a.png)
145 146
• Application
It allows you to import downloaded mobile applications and have them
installed into your handset upon synchronization.
• File
It allows you to organize handset files with just a few clicks and then the
files on the handset can be arranged where you want them.
• Sync
It allows you to synchronize the Contacts and Calendar in Outlook/
Outlook Express and handset.
Supported Operating Systems
Windows XP/Vista/Windows 7.
12.2 Upgrade
12.2.1 ONE TOUCH Upgrade
Using ONE TOUCH Upgrade tool you can update your phone’s software
from your computer.
Download ONE TOUCH Upgrade from ALCATEL ONE TOUCH website
(www.alcatelonetouch.com) and install it on your computer. Launch the
tool and update your phone by following the step by step instructions
(refer to the User Guide provided together with the tool).
Your phone’s software will now have the latest software.
All personal information will be permanently lost following the
update process. We recommend you backup your personal data
using ONE TOUCH Manager before upgrading.
12.2.2 System updates
Using FOTA Upgrade tool you can update your phone's software.
To access System Updates, please open notification panel and touch
, then press About phone\System updates. Or you can directly touch
System Updates on application list directly. Touch Check for updates,
and the phone will search for the latest software. If you want to update
the system, please touch the button Download, after it done please touch
Install to complete the upgrade. Now your phone's software will have
the latest version.
You should turn on data connection before searching for updates. Settings
for auto-check intervals and reminders about upgrades are also available
once you restart the phone.
If you have chosen auto-check, when the system discovers the new
version, the icon will appear in the status bar. Touch the notification
to access the System Updates directly.
During FOTA downloading or updating, to avoid errors in locating
the correct update packages, do not change your default storage
location.
147 148
13 Telephone warranty ..........
Your phone is warranted against any defect or malfunctioning which may
occur in conditions of normal use during the warranty period of twelve
(12) months (1) from the date of purchase as shown on your original
invoice.
Batteries (2) and accessories sold with your phone are also warranted
against any defect which may occur during the first six (6) months (1) from
the date of purchase as shown on your original invoice.
In case of any defect of your phone which prevents you from normal
use thereof, you must immediately inform your vendor and present your
phone with your proof of purchase.
If the defect is confirmed, your phone or part thereof will be either
replaced or repaired, as appropriate. Repaired phone and accessories
are entitled to a one (1) month warranty for the same defect. Repair or
replacement may be carried out using reconditioned components offering
equivalent functionality.
This warranty covers the cost of parts and labor but excludes any other
costs.
(1) The warranty period may vary depending on your country.
(2) The life of a rechargeable mobile phone battery in terms of conversation time
standby time, and total service life, will depend on the conditions of use and
network configuration. Batteries being considered expendable supplies, the
specifications state that you should obtain optimal performance for your phone
during the first six months after purchase and for approximately 200 more
recharges.
This warranty shall not apply to defects to your phone and/or accessory
due to (without any limitation):
1) Non-compliance with the instructions for use or installation, or with
technical and safety standards applicable in the geographical area where
your phone is used,
2) Connection to any equipment not supplied or not recommended by
TCT Mobile Limited,
3) Modification or repair performed by individuals not authorised by TCT
Mobile Limited or its affiliates or your vendor,
4) Modification, adjustment or alteration of software or hardware
performed by individuals not authorized by TCT Mobile Limited,
5) Inclement weather, lightning, fire, humidity, infiltration of liquids
or foods, chemical products, download of files, crash, high voltage,
corrosion, oxidation…
Your phone will not be repaired in case labels or serial numbers (IMEI)
have been removed or altered.
There are no express warranties, whether written, oral or implied, other
than this printed limited warranty or the mandatory warranty provided by
your country or jurisdiction.
In no event shall TCT Mobile Limited or any of its affiliates be liable for
indirect, incidental or consequential damages of any nature whatsoever,
including but not limited commercial or financial loss or damage, loss of
data or loss of image to the full extent those damages can be disclaimed
by law.
Some countries/states do not allow the exclusion or limitation of indirect,
incidental or consequential damages, or limitation of the duration of
implied warranties, so the preceding limitations or exclusions may not
apply to you.
![](asset-4c.png)
149 150
14 Accessories .......................
The latest generation of ALCATEL ONE TOUCH mobile phones offers
a built-in handsfree feature that allows you to use the telephone from a
distance, placed on a table for example. For those who prefer to keep
their conversations confidential, an earpiece is also available known as
the headset.
1. Charger
2. Battery
3. USB cable
4. Stereo headset
Only use your telephone with the ALCATEL ONE TOUCH
batteries, chargers and accessories in your box.
15 Troubleshooting ................
Before contacting the service centre, you are advised to follow the
instructions below:
• You are advised to fully charge ( ) the battery for optimal operation.
• Avoid storing large amounts of data in your phone as this may affect its
performance.
• Use Factory date reset and the upgrade tool to perform phone
formatting or software upgrading (to reset factory data, hold down
the power key and the Volume up key at the same time). ALL
User phone data: contacts, photos, messages and files, downloaded
applications will be lost permanently. It is strongly advised to fully
backup the phone data and profile via Android Manager before doing
formatting and upgrading.
and carry out the following checks:
My phone is frozen or cannot be switched on
• Check the battery power level, charge for at least 20 minutes.
• If it still does not work, please reset the phone using the Power key
and the Volume up key.
My phone has not responded for several minutes
• Restart your phone by pressing and holding the Power key.
My phone turns off by itself
• Check that your screen is locked when you are not using your phone,
and make sure the Power key is not mis-contacted due to unlocked
screen.
• Check the battery charge level.
My phone cannot charge properly
• Make sure that your battery is not completely discharged; if the battery
power is empty for a long time, it may take around 20 minutes to
display the battery charger indicator on the screen.
• Make sure charging is carried out under normal conditions (0°C to
+40°C).
![](asset-4d.png)
151 152
• When abroad, check that the voltage input is compatible.
My phone cannot connect to a network or “No service” is
displayed
• Try connecting in another location.
• Verify the network coverage with your operator.
• Check with your operator that your SIM card is valid.
• Try selecting the available network(s) manually (see “11.1.8 Mobile
networks”)
• Try connecting at a later time if the network is overloaded.
My phone cannot connect to the Internet
• Check that the IMEI number (press *#06#) is the same as the one
printed on your warranty card or box.
• Make sure that the internet access service of your SIM card is available.
• Check your phone's Internet connecting settings.
• Make sure you are in a place with network coverage.
• Try connecting at a later time or another location.
Invalid SIM card
• Make sure the SIM card has been correctly inserted (see “Inserting or
removing the SIM card”).
• Make sure the chip on your SIM card is not damaged or scratched.
• Make sure the service of your SIM card is available.
Unable to make outgoing calls
• Make sure you have dialed a valid number and have touched .
• For international calls, check the country and area codes.
• Make sure your phone is connected to a network, and the network is
not overloaded or unavailable.
• Check your subscription status with your operator (credit, SIM card
valid, etc.).
• Make sure you have not barred outgoing calls.
• Make sure that your phone is not in airplane mode.
Unable to receive incoming calls
• Make sure your phone is switched on and connected to a network
(check for overloaded or unavailable network).
• Check your subscription status with your operator (credit, SIM card
valid, etc.).
• Make sure you have not forwarded incoming calls.
• Make sure that you have not barred certain calls.
• Make sure that your phone is not in airplane mode.
The caller’s name/number does not appear when a call is
received
• Check that you have subscribed to this service with your operator.
• Your caller has concealed his/her name or number.
I cannot find my contacts
• Make sure your SIM card is not broken.
• Make sure your SIM card is inserted properly.
• Import all contacts stored in SIM card to phone.
The sound quality of the calls is poor
• You can adjust the volume during a call by pressing the Volume Up/
Down key.
• Check the network strength .
• Make sure that the receiver, connector or speaker on your phone is
clean.
I am unable to use the features described in the manual
• Check with your operator to make sure that your subscription includes
this service.
• Make sure this feature does not require an ALCATEL ONE TOUCH
accessory.
When I select a number from my contacts, the number cannot
be dialed
• Make sure that you have correctly recorded the number in your file.
• Make sure that you have selected the country prefix when calling a foreign
country.
I am unable to add a contact in my contacts
• Make sure that your SIM card contacts are not full; delete some files or
save the files in the phone contacts (i.e. your professional or personal
directories).
153 154
My callers are unable to leave messages on my voicemail
• Contact your network operator to check service availability.
I cannot access my voicemail
• Make sure your operator’s voicemail number is correctly entered in
"Voicemail number".
• Try later if the network is busy.
I am unable to send and receive MMS
• Check your phone memory availability as it might be full.
• Contact your network operator to check service availability and check
MMS parameters (see “4.1.3 Adjust message settings”).
• Verify the server centre number or your MMS profile with your
operator.
• The server centre may be swamped, try again later.
SIM card PIN locked
• Contact your network operator to obtain the PUK code (Personal
Unblocking Key).
I am unable to connect my phone to my computer
• Install ALCATEL ONE TOUCH Android Manager.
• Check that your USB driver is installed properly.
• Open the Notification panel to check if the Android Manager Agent
has been activated.
• Check that you have marked the checkbox of USB debugging in
Settings\About phone\Advanced settings\USB debugging
• Check that your computer meets the requirements for ALCATEL ONE
TOUCH Android Manager Installation.
• Make sure that you’re using the right cable from the box.
I am unable to download new files
• Make sure there is sufficient phone memory for your download.
• Check your subscription status with your operator.
The phone cannot be detected by others via Bluetooth
• Make sure that Bluetooth is turned on and your phone is visible to
other users (see “6.3 Connecting to Bluetooth devices”).
• Make sure that the two phones are within Bluetooth’s detection range.
How to make your battery last longer
• Make sure you follow the complete charge time (minimum 2.5 hours).
• After a partial charge, the battery level indicator may not be exact.
Wait for at least 20 minutes after removing the charger to obtain an
exact indication.
• Switch on the backlight upon request.
• Extend the email auto-check interval for as long as possible.
• Update news and weather information on manual demand, or increase
their auto-check interval.
• Exit background-running applications if they are not being used for a
long time.
• Deactivate Bluetooth, Wi-Fi, or GPS when not in use.
The phone will become warm following prolonged calls, game
playing, internet surfing or running other complex applications.
• This heating is a normal consequence of the CPU handling excessive
data. Ending above actions will make your phone return to normal
temperatures.
![](asset-4f.png)
155 156
16 Specifications
Processor MTK6575 (ONE TOUCH 5020A/ONE
TOUCH 5020D/ONE TOUCH 5020E/ONE
TOUCH 5020X)
MTK6577 (ONE TOUCH 5021E)
Platform Android™ 4.1
Memory ROM: 4 GB
RAM: 512 MB
Dimensions
(LxWxT)
121.5 x 64 x 11.8 mm
Weight 136.5g with Battery
Display 4.0", TFT, WVGA
Network UMTS:
900/2100 MHz (ONE TOUCH 5020D/ONE
TOUCH 5020X)
850/1900/2100 MHz (ONE TOUCH 5020A/
ONE TOUCH 5020E/ONE TOUCH 5021E)
GSM/GPRS/EDGE:
Quad-band 850/900/1800/1900 MHz
(Band frequency and data speed are operator
dependent.)
GPS Assisted GPS/Internal GPS antenna
Connectivity • Bluetooth V4.0/A2DP
• Wi-Fi IEEE 802.11 b/g/n
• 3.5 mm audio jack
• Micro-USB
Camera 5.0 megapixel back camera
0.3 megapixel front camera
Audio supported
formats
AAC, AAC+, MP3, Midi, eAAC
Video supported
formats
MPEG-4, H.263, H.264
Battery (1) 1400 mAh, Lithium-Ion battery
Special Features • G-sensor
• Light Sensor
• Proximity Sensor
Note: Specifications are subject to change without prior notice. (1)
(1) The original battery has undergone rigorous safety inspections to meet
qualification standards, the use of non-original batteries may be dangerous.
![](asset-50.png)
157
ALCATEL is a trademark of Alcatel-Lucent
and is used under license by
TCT Mobile Limited.
© Copyright 2013 TCT Mobile Limited
All rights reserved
TCT Mobile Limited reserves
the right to alter material
or technical specification
without prior notice.
English - CJA1742ALAAA
All “Signature” ringtones embedded in this phone have
been composed, arranged and mixed by NU TROPIC
(Amar Kabouche).
