Alco Electronics AV62981HB Home Theater Receiver User Manual

Alco Electronics Ltd Home Theater Receiver

User manual

FCC INFORMATION
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to radio
or television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one
or more of the following measures:
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
Safety Precautions
For Your Safety
The AC power plug is polarized (one blade is
wider than the other) and only ts into AC power
outlets one way. If the plug won’t go into the outlet
completely, turn the plug over and try to insert it
the other way.
If it still won’t t, contact a qualied
electrician to change the outlet, or
use a dierent one. Do not attempt
to bypass this safety feature.
Caution
To prevent electric shock, match wide blade of •
plug to wide slot, fully insert.
Main plug is used as disconnect device and it •
should remain readily operable during intended
use. In order to disconnect the apparatus from
the mains completely, the mains plug should
be disconnected from the mains socket outlet
completely.
Connecting for Power
Make sure you connect all your other electronic
components and the speakers before plugging
your unit into the outlet. Plug the power cord in the
wall outlet, matching the wide blade of the plug
with the wide slot in the outlet. Be sure to insert the
plug completely.
Technical Specication
Product: Home Theater System
Brand : Blackweb
Electrical Consumption
Power Supply: 120V ~ 60Hz
THE LIGHTNING FLASH AND ARROWHEAD
WITHIN THE TRIANGLE IS A WARNING SIGN
ALERTING YOU OF “DANGEROUS VOLTAGE”
INSIDE THE PRODUCT.
THE EXCLAMATION POINT WITHIN THE
TRIANGLE IS A WARNING SIGN ALERTING
YOU OF IMPORTANT INSTRUCTIONS
ACCOMPANYING THE PRODUCT.
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment
•
and receiver.
Connect the equipment into an outlet on a
•
circuit dierent from that to which the receiver is
connected.
Consult the dealer or an experienced radio / TV
•
technician for help.
WARNING: Changes or modications to this unit
not expressly approved by the party
responsible for compliance could void the
user's authority to operate the equipment.
The Shock Hazard Marking and Associated
Graphical Symbol is provided on the bottom
panel of unit.
Refer to the identification / rating label located
on the back panel of your product for its proper
operating voltage.
IMPORTANT: The power cord can be unplugged
to turn off the main power to the unit. It should
also be easily accessible in an emergency.
Leave sufficient space around the appliance
•
to allow adequate ventilation: 10cm on either
side and at the back, as well as 7cm above it are
ideal.
• DonotconnecttotheACpowercordsuntilall
connections are completed.
• Donotuseyoursetimmediatelyaftertransferring
it from a cold place to a warm place: there is risk
of condensation.
• Donotexposeyoursettowaterandexcessively
high temperatures.
• Afterhavingdisconnectedyourset,cleanthe
case with a soft cloth, or with a slightly damp
leather chamois. Never using strong solvents.
Protect your Components from Overheating
• Donotblockventilationholesinanycomponent.
Arrange the components so that air can circulate
freely.
• Donotstackcomponentsdirectlyontopofeach
other.
• Donotplacetheunitnearothercomponents
that generate heat such as heating vents.
• Allowadequateventilationwhenplacingyour
components in a stand.
• Placeanampliernearthetopshelfofthestand
so heated air rising from it will not aect other
components. If you have a satellite receiver, you
should place it on the top shelf.
WARNING: To reduce the risk of fire or electric
shock, do not expose this apparatus to rain or
moisture.
Service Information
This product should be serviced only by those
specially trained in appropriate servicing
techniques. For instructions on how to obtain
service, refer to the warranty included in this user
manual.
IMPORTANT SAFETY INSTRUCTIONS
Please read and save for future reference.
Some of the following information may not apply
to your particular product; however, as with
any electronic product, precautions should be
observed during handling and use.
Read these instructions.
•
Keep these instructions.
•
Heed all warnings.
•
Follow all instructions.
•
Do not use this apparatus near water.
•
Clean only with a dry cloth.
•
Do not block any ventilation openings.
•
Install in accordance with the manufacturer’s
instructions.
Do not install near any heat sources such
•
as radiators, heat registers, stoves, or other
apparatus (Including amplifiers) that produce
heat.
Do not defeat the safety purpose of the
•
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade
or the third prong is provided for your safety.
If the provided plug does not t into your wall
outlet, consult an electrician for replacement of
the obsolete outlet.
Protect the power cord from being walked on
•
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
Only use attachments / accessories
•
specied by the manufacturer.
Use only with a cart, stand, tripod,
•
bracket, or table specified by the
manufacturer, or sold with the
apparatus. When a cart is used,
use caution when moving the cart / apparatus
combination to avoid injury from tip-over.
Unplug this apparatus during lightning storms
•
or when unused for long periods of time.
Refer all servicing to qualied service personnel.
•
Servicing is required when the apparatus has
been damaged in any way, such as the power
cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus,
the apparatus has been exposed to rain or
moisture, does not operate normally, or has
been dropped.
Additional safety information
• Apparatusshallnotbeexposedto drippingor
splashing and no objects lled with liquids, such
as vases, shall be placed on the apparatus.
• Alwaysleavesucientspacearoundtheproduct
for ventilation. Do not place product in or on a bed,
rug, in a bookcase or cabinet that may prevent
air ow through vent openings.
• Donotplacelightedcandles,cigarettes,cigars,
etc. on the product.
• ConnectpowercordonlytoACpowersourceas
marked on the product.
• Careshouldbetakensothatobjectsdonotfall
into the product.
• Donotattempttodisassemblethecabinet.This
product does not contain customer serviceable
components.
• Attentionshouldbedrawntotheenvironmental
aspects of battery disposal.
• Theapparatusshouldonlybeusedinmoderate
climates.
If your product operates on batteries, adhere to
the following precautions:
A. Any battery may leak electrolyte if mixed with a
dierent battery type, inserted incorrectly, or if
all batteries are not replaced at the same time.
B. Any battery may leak electrolyte or explode if
disposed of in re or an attempt is made to charge
a battery not intended to be recharged.
C. Discard leaky batteries immediately. Leaking
batteries can cause skin burns or other personal
injury. When discarding batteries, be sure to
dispose of them in a proper manner, according
to your state/provincial and local regulations.
D. Battery shall not be exposed to excessive heat
such as sunshine, re or the like.
]
Portable Cart
Warning
Headset Safety
Do not play your headset at a high volume.
•
Hearing experts warn against extended high-
volume play.
If you experience a ringing in your ears, reduce
•
volume or discontinu use.
You should use extreme caution or temporarily
•
discontinue use in potentially hazardous
situations.
Even if your headset is an open-air type
•
designed to let you hear outside sounds,
don't turn up the volume so high that you are
unable to hear what is around you.
Excessive sound pressure from earphones and
•
headphone can cause hearing loss.
I m p o r t a n t b a t t e r y i n f o r m a t i o n
• Do not mix new and old batteries. Do not mix
alkaline, standard (carbon-zinc), or rechargeable
(ni-cad, ni-mh, etc) batteries.
• In order to avoid any risk of explosion, observe
the polarities indicated inside the battery
compartment. Replace only with the type of
batteries specied. Do not dispose of them in a
re or recharge them.
• If you are not using the remote control for a long
period of time, remove the batteries.
• Do not dispose of batteries in a re. Batteries may
explode or leak.
• Batteries should always be disposed of with
the environment in mind. Always dispose of
batteries in accordance with applicable laws and
regulations.
General Controls
Model: BWA18SB003
Ver.00 08/03/18
5.1-CHANNEL HOME THEATER SYSTEM
WITH WIRELESS SUBWOOFER AND AM/FM DIGITAL TUNER
You can experience superb Home Theater quality sorround-sound from any HDMI connected device such
as Blu-Ray Disc Player, Satellite Receiver and Cable Box, DVD Player, etc.
Connecting to HDMI Components
Connecting to Audio Components
HDMI IN
Three “HDMI in” jacks receive digital signal from Blu-
Ray Disc Player, Satellite Receiver and Cable Box, DVD
Player, etc.
HDMI OUT jack
The “HDMI Out (to TV)” jack on this unit serves as a Video
Repeater from any HDMI signal input from connected
devices such as Blu-Ray Disc Player, Satellite Receiver
and Cable Box, DVD Player, etc. that are connected to
any of the three “HDMI in” jacks on this unit.
Press the SOURCE button on the Home Theater System
or the HDMI button on the remove control to select
HDMI 1, HDMI 2 or HDMI 3.
Press the SOURCE button on the Home Theater System
or the OPTICAL button on the remove control to select
OPTICAL 1 or OPTICAL 2.
Press the SOURCE button on the Home Theater System
or the COAXIAL button on the remove control to select
COAXIAL.
Press the SOURCE button on the Home Theater System
or the AUX button on the remove control to select
AUX1.
Analog Audio Input - Good
If your TV has digital audio output, you can connect it
to one the unit’s digital audio inputs, instead of using
analog connection.
Digital Audio Input
The digital audio jacks can accept Dolby Digital (Surround Sound) or PCM (Stereo) signals when compatible
components are connected.
•
This unit provides two optical and one coaxial digital input jacks for the connection of your
components that have digital audio outputs.
• ToconnectDVDplayer,Satellitereceiver,Cablebox,Blu-rayPlayer,orTVthathasadigitalaudio
output, use a coaxial digital (included) or an optical digital cable (not included) to carry the audio
signal and enjoy Dolby Digital sound quality.
• Aseparateopticalorcoaxialcableisneededforeachdigitalconnection.
Coaxial Digital In (Audio) - Better
Connect to coaxial digital output of DVD, Cable box,
Satellite receiver, TV or other compatible devices using
the Coaxial Digital Cable (not included).
10cm 10cm
10cm
7cm
7cm
Install two “AAA” batteries in the
remote control prior to use.
1. ON•OFF
Turn on/o the unit.
2. SLEEP
Selects sleep time.
3. NIGHT
Selects among night mode options
(MODE RATE / QUIET / OFF) which
compresses the volume dierence
between normal voices and sounds
such as explosions. (Available only
during Dolby digital signal playback).
4. TEST TONE
Speaker test tone setting. Refer to
“Advanced Sound Control” for details.
5. SURROUND
Selects among digital surround sound
eects.
6. DISTANCE
Adjusts the speakers’ listening distance.
7.
/
/
/
• Press
/
to select among setting items in Setup
mode.
• Press
/
to adjust the values when the display
shows the setup you want to change.
• PressOK to conrm your selection.
8. LEVEL
Speaker level setting. Refer to “Advanced Sound
Control” for details.
Remote Control
9. SUBWOOFER
Selects among subwoofer sound levels.
10. MEM + / MEM -
Selects programmed stations in AM/FM mode.
11. TUNER +
Press to increase the radio frequency in AM/FM mode.
Press and hold to search next available station in
descending frequencies.
12. EQ buttons
Selects among preset equalizer mode. Press the
corresponding button to select the desired sound
mode. This function is only available in Stereo mode.
13. Number buttons
Directly accesses a preset station in AM/FM mode.
14. MEMORY
Stores stations as preset stations in AM/FM mode.
15. MONO/ST
Selects between Stereo and Mono sound in FM mode.
16. SETUP
Enters Setup mode. Use
/
to select among setup
options.
17. MUTE
Mutes all sound.
18. VOL + / VOL -
Adjusts the volume.
19. EXIT
Exits the current setting.
20. TUNER -
Press to decrease the radio frequency in AM/FM
mode.
Press and hold to search next available station in
descending frequencies.
21. Source buttons
Selects audio sources.
Main Unit
Subwoofer
1. ON/STANDBY
Turns on / o the unit. When the unit is turned
on, the unit will go to the mode it was in before
powered o.
2. / (SURROUND buttons)
Selects among digital surround sound eects
depending on input signal.
3. / (TUNING buttons)
Tunes in to desired stations in AM/FM mode.
4. / (PRESET buttons)
Selects preset stations in AM/FM mode.
1. Power switch
2. WIRELESS LINK button/
WIRELESS LINK PAIRING indicator
3. Rear speaker terminals
4. Power cord to Wall outlet
2
13 4 5 6 7 8 9
5. AUX 2 jacks
Connect game consoles or other AV products
that have AUX audio outputs.
6. LINE-IN jack
Connect portable audio devices or other AV
products that have a LINE-OUT jack.
7. PHONES jack
8. MASTER VOLUME -/+
Adjusts the volume.
9. SOURCE
Selects sound source.
ON
OFF 2
13
4
General Controls
Connections and Setup
Positioning speakers
Connecting the speakers to the Home Theater System and Subwoofer
Speaker wires are color-coded to match the terminals. Connect the speaker wire from the back of each
speaker to the corresponding color terminal at the back of the unit. Press down the tab to open the
terminal and insert the wire. Release the tab to lock wire in the terminal.
When connecting the speakers, make sure the polarities (“+“ speaker wire to “+“ on the unit. For example, red
wire to red terminal on the unit) of speaker wires and terminals match.
If the cords are reversed, the sound will be distorted. Do not let the speaker wires touch each other, it will
damage the Home Theater’s amplier.
Magnetic Shielding
Speakers placed less than two feet from the TV set must be magnetically shielded in order to prevent
picture distortion. Center speaker provided with this unit is magnetically shielded to protect your TV
set.
Optical Digital In (Audio)- Best
Connect to optical digital output of Cable box, Satellite
receiver, DVD, Blu-ray player, TV or other compatible
devices using the Optical Fiber Cable (not included).
Optical Fiber cable
(not included)
HDMI cable
(not included)
TV/GAME/BD/
DVD/SAT-CABLE
Coaxial Digital cable
(not included)
TV/GAME/BD/
DVD/SAT-CABLE
Connecting the Antennas
Connect the AM and FM antennas to the AM and FM terminals on the system’s back panel.
AM Loop Antenna and FM Indoor Antenna
1. Uncoil the antenna wire and locate the base end of the AM antenna.
2. Press down on the antennas tab to open the terminal.
3. Insert the antenna wires into the terminal and release the tabs to secure the wires in place.
4.
Make sure the white wire on the AM loop antenna is inserted into the AM loop terminal and the other
wire is inserted into the ground loop terminal.
They must be hooked up in order to receive clear reception. For FM reception, extend antenna to its full
length. For AM reception, rotate the antenna horizontally to get better reception.
Audio cable (included)
VCR/TV
Front
R i g h t S p e a k e r
Red
and
Black
White
and
Black
Front
Left Speaker
Green
and
Black
Center Speaker
Rear
Right Speaker
Grey
and
Black
Rear
Left Speaker
Blue
and
Black
Insert
Press Release
Center speakerFront Left speaker Front Right speaker
Rear Left speaker Rear Right speaker
Subwoofer
Front speakers
Front speakers carry primarily music and sound eects.
• Place the left and right speakers to form a 45-degree angle with your favorite viewing position to
duplicate the soundtrack mixer’s perspective.
• Placethespeakersothattheirtweeterswillbeatthesameheightasyourear.
• Alignthefrontspeakerswiththecentrespeakerorplacethemslightlyinfrontofthecenterspeakers.
Center speaker
In surround mode, the center speaker carries most of the dialog as well as music and eects.
• Itshouldbesetbetweentheleftandrightspeakers.
• Itisbesttoinstallitatthesameheightasthefrontspeakers.
Rear Speakers (Surround Speakers)
The surround speakers’ overall sound balance should be as close as possible to the front speakers. Proper
placement is vital to establish an evenly distributed sound eld.
• Ifpossible,placesurroundspeakerstoeithersideofthelisteningarea,notbehindit.
• Ifspacepermits,installsurroundspeakers2-3feetaboveviewers.Thishelpstominimizelocalization
eects.
Subwoofer
A subwoofer is designed to reproduce powerful low bass eects (explosions, the rumble of spaceships,
etc.).
* For optimal wireless reception, the Wireless Subwoofer should be placed within 20 feet
from the AV Receiver.
Playback via Bluetooth® enabled devices
The unit can be paired and connected to the
Bluetooth® enabled devices such as a smart
phone.
INITIAL DEVICE PAIRING AND CONNECTION
In order to pair and connect your Bluetooth®
device for the rst time:
1. Press button to turn on the unit.
2. Press SOURCE button or button on the
remote control to select the BT mode. Turn
on the Bluetooth® device you wish to pair and
connect.
3. On your Bluetooth® enabled device, search for
the “BW HTiB” in the list of discovered devices
and select it.
It may take the unit and Bluetooth® enabled
device a few seconds to pair.
4. If it is successful, the front display of the main
unit will show “CONNECTED”.
5. You can now enjoy audio from the unit.
Notes
• IfyourBluetoothdevice(e.g.Smartphoneetc.)
need the PIN code while pairing, please enter
4-digit number: 0000.
• The unit can only be connected to one
Bluetooth® device at a time.
Selecting Source
When one of the SOURCE buttons on the front
panel or on the remote control is pressed, the
corresponding input will be activated.
The unit acts as a switching device between all the
sources that are plugged into it.
Example 1:
If you have connected a DVD player to the HDMI
IN 3 jack on the unit, press SOURCE on the front
panel or on the remote control to receive the
sounds transmitted by the DVD.
Example 2:
If a LINE IN is connected to the LINE IN jack of the
unit, press SOURCE on the front panel or on the
remote control, the sound from the LINE IN will
be selected.
You can connect up to 9 audio sources to this
amplier.
Example: Connecting a Blu-ray Player
1. Connect the optical digital audio out jack of Blu-
ray player to OPTICAL 1 jack on the rear panel
of the unit.
2. Press ON/STANDBY on the front panel of the
unit or press ON•OFFon the remote control to
switch on the unit.
3. Press SOURCE on the main unit to select BD
source.
4.
Switch ON the Blu-ray player and start playback.
5. Set the SURROUND mode if needed (see
“Advanced Sound Control” for details).
Example: Connecting a TV
1. If TV has an analog audio output, connect it to
the ANALOG AUDIO IN jack on the rear panel
of the unit.
2. Press ON/STANDBY on the front panel of the
unit or press ON•OFFon the remote control to
switch on the unit.
3. Press SOURCE button to select AUX 1.
4. Switch on the TV.
5. Set the SURROUND mode if needed (see
“Advanced Sound Control” for details).
The source name you selected will be shown on
the display.
The Bluetooth® word mark and logos are registered
trademarks owned by the Bluetooth SIG Inc. Other
trademarks and trade names are those of their
respective owners.
Notes
• Your unit has a built-in tuner. Just connect the
appropriate antenna to the back of the unit and
you will be able to listen to radio stations (For
details, please refer to Radio section).
• Connectionsatthebackpanelcanbeinterchanged
depending on whether sources have the same
audio input.
Operating Your Unit
RECONNECTING A BLUETOOTH® ENABLED
DEVICE
Bluetooth® enabled devices must be reconnected
when the device has been turned o or the unit has
been turned o.
1. Press button to turn on the unit.
2. Press SOURCE button or button on the remote
control to select the BT mode. Turn on the
Bluetooth® device that has already been paired
with the unit.
3. Depending on your Bluetooth device, your
device may automatically connect to the unit.
If the device does not automatically connect to
the unit, then search for the “BW HTiB” in its list
of your Bluetooth® devices and select it.
4. If it is successful, the front display of the main
unit will show “CONNECTED”.
5. You can now enjoy audio from the unit.
PAIR AND CONNECT WITH ANOTHER NEW
DEVICE
In order to pair the unit to a new device, you must
rst disconnect the currently paired and connected
Bluetooth® device from the unit.
1. On the currently paired and connected
Bluetooth® device, select the “BW HTiB” from
the list of currently paired and connected
devices, and disconnect it. Please refer to your
Bluetooth® enabled device User’s Guide for
direction on how to disconnect a device. Or turn
o the Bluetooth® device.
2. Follow the Initial device pairing and connection
instructions above.
About HDMI
High-Denition Multimedia Interface (HDMI) is
a high-speed digital interface that can transmit
uncompressed high denition video and digital
multichannel audio. It delivers high quality
picture and sound quality. HDMI is fully backward
compatible with DVI. As required by the HDMI
standard, connecting to HDMI or DVI products
without HDCP (High bandwidth Digital Content
Protection) will result in no Video or Audio output.
Tips
•
When you tune at a weak FM station
manually,
press MONO/ST on remote
control to switch
from Stereo to Mono mode.
This will reduce the
background noise.
• Ifthereisanyinterference,changethe
antenna’s
position until ideal sound
reception is obtained.
TV and other electronic
devices could be the cause
of interference, so try to position the antenna away
from them.
Manual Tuning
Press TUNER+ or TUNER- button on the remote
control or or button on the front panel of the
unit repeatedly to tune a desired frequency.
Automatic Preset Programming
The unit can preset 30 FM stations and 30 AM
stations. Before tuning, make sure to turn down
the volume to minimum.
1. Press TUNER button to select AM/FM mode.
2. Press and hold TUNER button for two seconds
to start automatic preset programming.
3. Radio frequencies will be browsed and radio
stations stored automatically. When all the
available radio stations are stored or all 60 preset
stations (30 for AM and 30 for FM) memory
locations are full, the auto preset programming
function will stop.
Manual Preset
1. Press TUNER button on the remote control to
select AM/FM mode.
2.
Press and hold TUNER+/TUNER- button on the
remote control or / button on the front panel
of the unit until the system tunes in a station.
Advanced Sound Control
Fine Setting of the Speakers
All the basic settings have already been pre-set
for the speakers included in the box.
Also, to make the surround sound more eective
and suit the acoustic conditions in your listening
room, you may need to delay the signal coming
from some of the speakers. Channel delay
compensates for center or surround speakers that
are closer to the listening position than the front
speakers.
Analog Inputs
The Home Theater has three analog audio inputs:
AUX 1 (VCR/ TV), AUX 2 and LINE-IN.
Notes
• To play Dolby Pro Logic II Movie sound, press
the SURROUND buttons until “Dolby PL II
MOVIE” appears on the Display.
• To play Dolby Digital sound, the source must be
connected to the unit via the optical or coaxial
terminal.
Testing and Adjusting Speaker Loudness
The TEST TONE button on the remote control
allows
you to adjust each speaker volume level
individually
to suit your particular listening
environment.
1. Press the TEST TONE button.
2. Press
/
button on the remote control to
select FL, CT, FR, SR, SW or SL.
3. A tone will be heard at each speaker, one
speaker at a time.
4. Press TEST TONE button again to exit this
mode.
You have the capability to change audio inputs
for the SAT-CABLE, BD, TV or GAME sources.
Adjusting Speaker Loudness Without Using Test
Tones
1. To adjust individual speaker volume level, press
LEVEL on the remote control.
2. Continue to press LEVEL on the remote control
to select the speaker to be adjusted, then press
the
/
buttons to adjust the level.
3. Press EXIT button to exit this mode.
Notes
• CTR stands for Center Speaker selection while
SURR stands for Surround Speaker selection.
•
By default, the Center and Surround Speakers
are set to YES. If you decide not to use them, set
the ones you do not intend to use to NO so that
the sound performance is not aected.
Speaker Congurations
You can also change the setup of the speakers. Use
a subwoofer to enjoy optimum sound.
For optimum surround experience measure the
distance between the speaker and your favorite
listening position. Press DISTANCE to adjust the
speakers’ distance.
1.
Press the DISTANCE button to show setup
options.
2. Press the DISTANCE until the speaker you want
to change is displayed.
3. Press
/
to change the speaker settings. Your
selection will be stored automatically.
4. Repeat step 2 and 3 to set up the next speaker.
You may adjust the distance within the following
ranges:
• FrontSpeakerdistance(FRNT):0-30ft
• CenterSpeakerdistance(CNTR):0-30ft
• RearSpeakerdistance(SURR):0-30ft
5. When set up is done, wait for ve seconds to
automatically save your settings or press any
buttons to save your selection and set up mode.
Factory Default Speaker Distance Settings
• FrontSpeakers(FRNT):15ft
• CenterSpeaker(CNTR):10t
• RearSpeakers(SURR):10ft
Center / Surround Speaker Setup
1. Press the SETUP button on the remote control
to show setup options.
2. Press
/
until CTR YES or SUR YES is displayed.
3. Press
/
to select between YES and No.
SUBWOOFER Mode Selection
Press the SUBWOOFER button to select among
“BALANCE”, “STRONG”, “POWERFUL” and “SOFT “.
Home Theater’s Display Dimmer Control
1. Press the SETUP button on the remote control
to show setup options.
2. Press
/
until DIMMER 0 is displayed.
3. Press
/
to select between 0 and 1.
NIGHT Mode Selection
“Night Mode” will limit the volume on loud
passages of movies (such as action sequences)
while still allowing you to hear quiet passages
(such as dialog).
1.
Press the NIGHT button to show setup options.
2. Continue to press the NIGHT button to select
among dierent options “MODE RATE /QUIET/
OFF” .
3. It is available only during Dolby Digital signal
playback.
Care and Maintenance
Disconnect the audio system from the power
source before performing any maintenance.
Cleaning the exterior
Disconnect the system from AC power before
cleaning the exterior of the system with a soft dust
cloth, or with a slightly damp leather chamois.
Never use strong solvents.
Important Battery Information
• Removethebatteriestoavoidleakageifyoudo
not use your remote control for more than one
month.
• Discard leaky batteries immediately as leaking
batteries may cause skin burns or other personal
injuries.
• Dispose of batteries in the proper manner,
according to provincial and local regulations.
• Anybatterymayleakelectrolyteifmixedwitha
dierent battery type, if inserted incorrectly, if
all batteries are not replaced at the same time,
if disposed of in re, or if an attempt is made to
charge a battery not intended to be recharged.
R/S
L/S
Rch
Cch
Lch
Front
Left
Rear
Right
Rear
Left
Front
Right
Center
AM / FM Operation
ST indicator is o.
• Adjust the antenna.
• Press MONO / ST button to insure you are not
outputting in mono.
The signal is Mono. Severe hum or noise.
• The signal is too weak. Connect an external
antenna.
• Adjustantenna.
• Repositionantennaawayfromanyelectronics.
There is interference to FM reception.
• Turn off other electrical devices (e.g. DVD, CD
player) near the unit.
Remote Control Operation
The remote control does not operate the unit.
• No batteries installed (included with your
system). Install the batteries before attempting
to operate the remote. Be sure to match the
+ and - ends of each battery to the symbols
shown in the remote battery compartment.
• The batteries are weak. Replace all batteries.
• The remote is not pointed at the remote control
sensor on the main unit or there is an obstacle
between the remote and the main unit.
• The remote control is too far from the main unit,
move closer.
General
No audio.
• Make sure the speakers are connected.
• Check the input connections.
• Check the power cord connections.
• Make sure MUTE is off.
• Make sure the digital setting (optical, coaxial or
analog) is correct.
• Check that the headphone is not inserted.
No audio from one channel.
• Check the speaker level setting.
• Check the speaker wire or external source cable
connections.
Noise occurs when the TV is turned on.
• The TV is too close to the audio system.
VENTURER ELECTRONICS (“VENTURER”) makes the following limited warranty. This limited warranty
extend to the original consumer purchaser and is limited to non-commercial use of the product.
Ninety (90) Day Parts & Labor Warranty
Venturer products purchased in the United States are warranted to be free from defects in materials
or workmanship for a period of ninety (90) days from the date of their original retail purchase. If the
unit fails to conform to this warranty, we will service the product using new or refurbished parts
and products, at VENTURER’s sole discretion.During a period of ninety (90) days from the effective
warranty date, VENTURER will provide, when needed, service labor to repair a manufacturing defect
at its designated Service Center. To obtain warranty service in the United States, you must rst contact
our Customer Support Center at www. venturer.com. The determination of service will be made by
VENTURER Customer Support. PLEASE DO NOT RETURN YOUR UNIT TO VENTURER WITHOUT PRIOR
AUTHORIZATION. New or remanufactured replacements for defective parts or products will be used for
repairs by VENTURER at its designated Service Center for ninety (90) days from the eective warranty
date. Such replacement parts or products are warranted for an additional ninety (90) days from the date
of repair or replacement.
The Customer will be required to ship the unit to the Service Center indicated at the time Customer
Support is contacted to make the necessary repairs. The customer is responsible for all transportation
charges to the service facility.
Packaging and Shipping Instruction
When you send the product to the VENTURER service facility you must use the original carton box and
packing material or an equivalent as designated by VENTURER.
Your Responsibility
(1) You must retain your bill of sale to provide proof of purchase.
(2) These warranties are eective only if the product is purchased and operated in the U.S.A. or Canada.
(3) Warranties extend only to defects in material or workmanship, and do not extend to any product or
parts which have been lost or discarded, or damage to product or parts caused by misuse, accident,
improper operation or maintenance, or use in violation of instructions provided with the product, or
to product which has been altered or modied without authorization of VENTURER, or to products
or parts thereof which have had the serial number removed or changed.
Out of Warranty
In the event your product requires repair after the limited warranty period has expired, please contact
our Customer Support Center at www.venturer.com
Important: You are responsible for any transportation, shipping or insurance relative to the return of
product to our Product Returns Center.
All warranties implied by state law, including the implied warranties of merchantability and fitness
for a particular purpose, are expressly limited to the duration of the limited warranties set forth
above. With the exception of any warranties implied by state law as hereby limited, the foregoing
warranty is exclusive and in lieu of all other warranties, guarantees, agreements and similar obligations
of manufacturer or seller with respect to the repair or replacement of any parts. In no event shall
VENTURER be liable for consequential or incidental damages.
No person, agent, distributor, dealer or company is authorized to change, modify or extend the terms of
these warranties in any manner whatsoever. The time within action must be commenced to enforce any
obligation of VENTURER arising under the warranty or under any statute, or law of the United States or
LIMITED WARRANTYTroubleshooting Tips
SOURCE
button on
front panel
SOURCE
buttons on
remote control
Corresponding
connector at the rear
panel and front panel
HDMI 1
HDMI 2
HDMI 3
OPTICAL 1
OPTICAL 2
COAXIAL
AUX 1
AUX 2
LINE-IN
HDMI
HDMI
HDMI
OPTICAL
OPTICAL
COAXIAL
AUX
AUX
LINE-IN
HDMI IN 1
HDMI IN 2
HDMI IN 3
OPTICAL 1
OPTICAL 2
COAXIAL
AUX 1
AUX 2
LINE-IN
Source Default input
BD
SAT-CABLE
DVD
TV
AM/FM
VCR
GAME
LINE-IN
HDMI 1 (BD: HD 1)
HDMI 2 (SAT: HD 2)
HDMI 3 (DVD: HD 3)
Rear Analog (TV: ANLG)
Built in tuner
Rear Analog (VCR)
Front Analog (AUX 2: FRNT)
Front Analog (LINE-IN)
Sound Enhancement Systems
This receiver is equipped with several built-in
sound enhancement systems.
Manufactured under license from Dolby
Laboratories. Dolby, Pro Logic, and the double-D
symbol are trademarks of Dolby Laboratories.
Dolby Digital
The Dolby Digital mode lets you enjoy full digital
surround from software processed in the Dolby
Digital format. Dolby Digital provides better
sound quality and a more powerful presence
than conventional Dolby Surround. This unit is
equipped with Dolby Digital 5.1-channel so that
you can enjoy enhanced full digital surround
sound. Dierent from Dolby Pro Logic in that only
four channels (Front Left, Front Right, Centre and
Rear) are used, the new system provides stereo
separation of the rear speakers (Rear-Right, Rear-
Left). Adding the subwoofer channel to the 5
channels for bass sounds (counted as 0.1 channel)
results in 5.1 channels (or 6 Channels) input Dolby
Digital for that bring you the most sophisticated
sound enjoyment.
Dolby Pro Logic II
The Pro Logic II mode uses the built-in circuit to
steer the Left, Center, Right and Surround left
and right channel audio signals and uses all ve
speakers to play both stereo and Dolby Pro Logic
program source, such as TV and VCR.
Dolby Pro Logic II includes Dolby Pro Logic II
Movie, Dolby Pro Logic II Music and Dolby Pro
Logic Emulation.
You can use this mode with any stereo program
source (such as VCR/TV) to enjoy multi-channel
sound experience.
DSP (Digital Sound Processor)
These digital sound eects resemble sounds in a
real environment such as (HALL, CHURCH, DOLBY
5 CH, DOLBY PL EMULATION, DOLBY PL II MUSIC,
DOLBY PL II MOVIE). DSP automatically converts
analog audio signals to digital ones which enables
you to adjust the sound without degrading
the sound quality. Dierent modes will give
you dierent feels of size and types of listening
environment.
Press SUBWOOFER button to select the subwoofer
eects level according to you needs. Four settings
are available: BALANCE, STRONG, POWERFUL and
SOFT.
Fine Setting of the Components
You can select the surround mode by pressing
SURROUND repeatedly to select among dierent
options.
(DOLBY PL II MUSIC / DOLBY PL II MOVIE /
DOLBY PL EMULATION / HALL / CHURCH /CONCERT
/ LIVING ROOM / CAVE/ARENA/DOLBY 5 CH)
.
The default surround modes for dierent
components are listed in the table below. The unit
will keep the last selection in memory.
HDMI and Digital Inputs
The Home Theater has three digital audio inputs
and three HDMI AV inputs for BD, SAT-CABLE, DVD,
TV, or GAME sources.
The default input is HDMI IN 1 for BD, HDMI IN 2 for
SAT-CABLE, and HDMI IN 3 for DVD. However, if you
need to assign a source to a dierent input:
Press SOURCE button to select among HDMI 1 /
HDMI 2 / HDMI 3 / OPTICAL1 / OPTICAL 2 / COAXIAL
/ AUX 1 / AUX 2 / LINE IN (dierent source will have
dierent available inputs for selection) to match
your connection. Your selection will be stored for
future use automatically.
Source
Input
If digital input
(HDMI, optical or
coaxial) is selected
If analog input is
selected
DVD
SAT-CABLE
BD
TV
AM/FM
VCR
GAME
LINE-IN
Dolby Digital
Dolby Digital
Dolby Digital
Dolby Digital
N/A
N/A
Dolby Digital
N/A
Pro Logic II Movie
Pro Logic II Movie
Pro Logic II Movie
Pro Logic II Movie
DOLBY 5 CH
Pro Logic II Movie
Pro Logic II Movie
Pro Logic II Movie
Setting the sleep timer
You can set the system to turn o at a preset time,
so you can fall asleep listening to music. You can
preset the time in 30-minutes increments.
1. Press SLEEP button on the remote control.
2. Each time you press SLEEP, the minutes display
(the remaining time) changes by 30 minutes.
3. When you set the sleep timer, "SLEEP" icon will
be shown on the front panel display.
• To change the remaining time, press SLEEP
repeatedly to select the desired time.
• Toclearthepresetsleeptime,presstheSLEEP
button until SLP OFF appears.
Connections and Setup
any state thereof, is hereby limited to ninety (90) days from the date of purchase. This limitation does
not apply to implied warranties arising under state law.
This warranty gives you specic legal rights and you may also have other rights, which may vary from
state to state.Some states do not allow limitations on how long an implied warranty lasts, when an
action may be brought, or the exclusion or limitation of incidental or consequential damages, so the
above provisions may not apply to you.
For more information on other products and services, please contact our website at www.venturer.com
or email address support@1800customersupport.com
Important: Also keep your “Bill of Sale” as proof of purchase.
Model no .............................................................................. Product name ..............................................................................
Type of set ........................................................................... Serial no .........................................................................................
Invoice no ............................................................................ Date purchased ...........................................................................
Dealer name .....................................................................................................................................................................................
FOR SERVICE AND REPAIR, PLEASE VISIT Website : www.venturer.com or Email address :
support@1800customersupport.com
Advanced Sound Control
Trademark Notice
HDMI, the HDMI logo and High-Definition
Multimedia Interface are trademarks, registered
trademarks, or service marks of HDMI Licensing,
LLC in the United States and/or other countries.
As concerns grow about the environmental impact of outdated
electronic products, Venturer Electronics is committed to being a part
of the solution. Free of charge, Venturer Electronics customers can
return qualifying units to us for recycling. For more details, please visit
our website at www.venturer.com/recycle.
“Blu-ray Disc” is a trademark of Blu-ray Disc
Association.
Printed in China
811-298191W010
AUX 2
1. Connects audio out jacks of the
Playstations to the AUX 2 jacks on the front panel
of the unit.
2. Press the SOURCE button on the front panel repeatedly to select AUX 2 mode.
LINEIN
1. Connects one end of the 3.5mm stereo cable (not included) to the LINEIN connector on the front
panel of the unit and the other to the line out or headphone jack on an external source.
2. Press SOURCE on the front panel to select LINE-IN mode.
3. Press MEMORY. While the Program Preset
number is still ashing, input your desired
preset number using the numeric buttons, then
press MEMORY to store it.
Select Preset Stations
1. Press TUNER button on the remote control to
select AM/FM mode.
2. Press / on the main unit repeatedly or
directly press MEM + / MEM - button on the
remote control to search for the preset stations.
Each time you press the button, the system
tunes in one preset station.
Note: If you still cannot connect the wireless link, please turn o the Home System and the Subwoofer and
turn them on again. Follow the manually connection instructions above.
1. Press and hold the WIRELESS LINK button on the back of Subwoofer and the OK button on the Remote
at the same time until the “WIRELESS“ indicator blinks on the Home Theater System display.
B. MANUALLY
The Home Theater System and Subwoofer will pair up automatically after power on. If the pairing fails
accidentally, please follow below steps to reconnect.
Pairing the Subwoofer with Home Theater System
In order to use the wireless Subwoofer, you must pair it with the Home Theater System.
1. Connect the power cord to a wall outlet.
2. Turn on the Home Theater System.
3. Press the POWER switch on the back of the subwoofer to ON “ I ” position.
4. The Home Theater System and the subwoofer will automatically pair up. The WIRELESS LINK PAIRING
indicator will turn blue when the wireless link is activated.
A. AUTOMATICALLY
2. The “WIRELESS CONNECTED” indicator appears on Home Theater System display, the pairing between
Home Theater System and Subwoofer is complete and successful.
RADIO
The unit has a built-in tuner that allows for AM/FM
radio function.
Connect the FM antenna and the AM loop
antenna at the back of the unit. Rotate the AM
loop for better reception.
Automatic Tuning
1. Press TUNER button on the remote control to
select AM/FM mode.
2. Press and hold TUNER+ or TUNER- button on
the remote control or / button on the
front panel of the unit until the auto searching
starts. Searching stops when the system tunes in
a station. (Once the FM station that broadcasts
Stereo sound is found, STEREO is displayed.)
3. Repeat step 2 to tune to another radio station.
4. To prematurely stop the searching function,
press TUNER+ or TUNER- button on the remote
control.
5.
Adjusting the volume by pressing VOL +/VOL -.
No sound from the wireless subwoofer
• Turn off and turnon the HomeTheaterSystem
and Subwoofer again.
• Set up the wireless subwoofer connection
manually (Refer to the Pairing the Subwoofer
with the Home Theater System).

Navigation menu
