Alco Electronics RCT6773W22 7 Inch Tablet User Manual
Alco Electronics Ltd 7 Inch Tablet
User Manual
7” Tablet Computer
User Manual
It's important to read these instructions prior to using your
new product for the first time.
CT9773W22
EN - 1
Safety Precautions
Equipment tested for
compliance as a
complete unit
FCC Information
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to Part 15 of FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will
not occur in a particular installation. If this equipment
does cause harmful interference to radio or television
reception, which can be determined by tur ning the
equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
CT9773W22
EN - 2
CAN ICES-3(B) / NMB-3(B)
This device complies with Industry Canada license-
exempt RSS-210. Operation is subject to the following two
conditions: (1) this device may not cause interference,
and (2) this device must accept any interference, including
interference that may cause undesired operation of the
device.
Le présent apparei l est conforme aux CNR d'Industrie
Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions
suivantes: (1) l'appareil ne doit pas produire de brouillage,
et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible
d'en compromettre le fonctionnement.
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Warning: Changes or modifications not expressly
approved by the party responsible for compliance (MLB
International Inc., P.O. Box 1535, Buffalo, NY 14226, Tel:
516-236-4556) could void the user’s authority to operate
the equipment.
Warning: the AC adapter is used as disconnect device
and it should remain readily operable during intended use.
In order to disconnect the mains plug from mains
completely, the AC adapter should be disconnected from
the mains socket outlet completely.
Service Information
This product should be serviced only by those specially
trained in appropriate servicing techniques. For instructions
on how to obtain service, refer to the warranty included in
this guide.
Caution: Use of controls or adjustments or performance
of procedures other than those specified may result in
hazardous radiation exposure.
EN - 3
Some of the following information may not apply to your
particular product; however, as with any electronic product,
precautions should be observed during handling and use.
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with dry cloth.
• Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
• Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
• Only use attachments / accessories specified by the
manufacturer.
• Unplug this apparatus during lightning storms or when
unused for long periods of time.
IMPORTANT SAFETY INSTRUCTIONS
PLEASE READ AND
SAVE THIS FOR FUTURE REFERENCE
EN - 4
• Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
ADDITIONAL SAFETY INFORMATION
• The AC adapter and apparatus shall not be exposed to
dripping or splashing and no objects filled with liquids,
such as vases, shall be placed on the apparatus.
• Always leave sufficient space around the product for
ventilation. Do not place product in or on a bed, rug,
in a bookcase or cabinet that may prevent air flow
through vent openings.
• Do not place lighted candles, cigarettes, cigars, etc. on
the product.
• Care should be taken so that objects do not fall into
the product.
• Do not attempt to disassemble the cabinet. This
product does not contain customer serviceable
components.
• To prevent the risk of fire or electric shock, do not
expose this apparatus to rain or moisture.
• Do not play your headset at high volume. Hearing
experts warn against extended high-volume play.
EN - 5
EN - 6
Safety Precautions .....................................................1
Important Safety Instructions ................................... 4
Startup ..................................................................... 7
Overview of Controls ........................................................ 7
Buttons .......................................................................... 8
Accessories ................................................................... 8
Navigating the Home Screen ............................................ 9
Connections ............................................................. 13
Battery Management and Charging ............................... 13
Micro-USB .....................................................................14
Headphone ..................................................................... 15
Micro SD .......................................................................15
Wi-Fi ...............................................................................16
Basic Operation ....................................................... 17
First Time Operation ........................................................... 17
Basic Operation ...................................................................18
Google NowTM ........................................................................19
Voice Search & Voice Actions ................................................19
Google PlayTM ........................................................................20
Settings ............................................................................... 21
GoogleTM ................................................................................23
Preinstalled Apps ..................................................... 23
Additional Information ............................................ 24
Trouble Shooting .................................................................. 24
Copyright and Trademark Notices ........................................ 25
Specifications .......................................................................25
Limited Warranty ..................................................... 26
Contents
EN - 7
Item Description
Power Button Press to enter standby/wake up mode,
press and hold to switch On/Off the unit.
Headphone jack Headphone connection for personal
listening.
Front Camera
Reset
Overview of Controls
Speaker
Startup
Power Button
Headphone jack
Microphone
Micro-USB Port
Vol+/- Button
Micro SD Card Slot
Micro-USB Port Connect to a PC or USB storage device;
Or use to charge the battery.
Vol+/- Button Press to increase/decrease the volume.
Microphone For voice input.
Micro SD Card Slot
Accepts micro SD card (up to 32G).
Reset Reset the tablet.
Accessory
The following accessory is included.
AC Adapter ......................................................................... x1
Buttons
Power Button
Power the Tablet On
Press and hold the Power button until the logo appears.
Power the Tablet Off
Press and hold the Power button until a message box
appears and tap "Power off", then tap "OK" and the tablet
will be powered off.
Sleep Mode
Briefly press the Power button to put the tablet in sleep mode.
If you don’t operate for some time, the tablet will enter sleep
mode automatically.
Tip: You can go to Settings -> DEVICE -> Display ->
Sleep to set the screen timeout.
Wake the Tablet from Sleep Mode
Press the Power button to wake the tablet from sleep mode.
Vol +/- Button
Press the Vol +/- button to increase or decrease the volume.
Tip: You can go to Settings -> DEVICE -> Sound ->
Volumes to adjust volume settings for Music, Video, Games
& other media, Notifications and Alarms.
EN - 8
EN - 9
Navigating the Home Screen
App Icons
Status Bar
Google
SearchTM
App Icons
Speakers
Notification Bar
Recent AppsHomeBack All Apps
Notification & Status Bar
Some indicators that inform you about the status of your
tablet are shown at the top of the screen.
Notification Shade
Notifications may come from the system, a game, an
application such as E-mail, or the music player.
When Notifications are available, related icons will appear
in the top left corner of the screen. To open the Notification
Shade, touch the Notification icon and swipe your finger
down. Some notifications allow you to take specific actions
by tapping icons within the notification.After you are finished
with a notification, just slide it away to the left or right. If you
want to dismiss all notifications, tap the Dismiss icon at
the top of the notification.
Status Bar & Quick Settings
The Status Bar in the top right corner shows various
indicators, including Wi-Fi connection and battery status. To
access "Quick Settings", touch the status bar and swipe
down. You can then adjust various settings on the tablet by
touching the corresponding square.
EN - 10
Notification & Status Icons
The below table lists some of the frequently used icons in
the Notification & Status bar:
Item Description
Message Received new message.
Music The Google Play Music app is running.
Screenshots Screenshot captured.
Home Screen Icons
All Apps
Tap the All Apps icon to enter the All Apps screen.
In All Apps screen, you can:
• Move between screens: Slide left or right.
• Open an App: Tap its icon.
• Copy an App icon to the Home screen: Press and hold
the icon or widget icon and slowly to drag it to the Home
screen.
• View widgets: Tap the widgets tab at the top of a All
Apps screen. Widgets are app information displays that
can be placed on your Home screen.
• Get more apps: Tap the Google Play Store icon .
• View info about an App: Press and hold it, and drag it
to the top of the screen, then drop the app over the App
Info icon i.
Tip: Most apps include a Menu icon near the top or
bottom of the screen that lets you control the app’s
settings.
USB tethering Has connected to a PC and the
USB tethering is turned on.
Wi-Fi Has a Wi-Fi Internet connection.
Play Store An update for an app is available.
EN - 11
Back
Tap Back icon to return to the previous screen.
• The Back icon remains on the bottom of the screen at
all times, allowing you to navigate back to the previous
screen.
• Once you go back to the Home screen, you can’t go
back any further in your history.
Home
Tap Home icon from anywhere on your tablet to return
to the Home screen.
Recent Apps
Tap Recent Apps icon to view recently used apps. Tap
an app to use it again.
You can slide down to see more apps. You can also slide it
away to the left or right.
Speakers &
Tap Speaker icon to increase volume.
Tap Speaker icon to decrease volume.
EN - 12
Battery Management and Charging
The tablet has a built-in rechargeable battery.
Battery Icon
The battery icon in the upper-right corner shows the battery
level or charging status.
Charging the Battery
Connect the AC Adapter to the Micro-USB port for charging
the battery.
Note: In order to keep the battery working in best
condition, please pay attention to the following:
• The included AC adapter is for use with this unit only.
Do not use it with other equipment.
• Please do not charge the battery in high temperatures.
Full battery Low battery Need to be
charged
Charging
AC Adapter
(included) To Wall Outlet
To Mico-USB port
Connections
EN - 13
• Do not wait for the battery to be fully depleted before
charging again. Keep the battery charged as needed.
• If tablet has not been used for a long period of time, the
battery might be in over discharge protection mode and
may take longer to charge.
Prolong the Battery Life
Here are some tips for how to prolong the life of the battery:
• If you aren’t using Wi-Fi, go to Settings -> WIRELESS
& NETWORKS -> Wi-Fi, turn it off.
• Don’t leave the Maps or Navigation apps open on the
screen when you’re not using them.
• Turn down screen brightness and set a shorter screen
timeout: Settings -> DEVICE -> Display.
• If you don’t need it, turn off automatic syncing for all
apps: Settings -> ACCOUNTS ->[Google account-
name]. This means you need to sync manually to collect
messages, email, and other recent information, and won’t
receive notifications when updates occur.
EN - 14
Connect your tablet to a PC or a USB storage device with
the USB cable (not included), to transfer music, pictures and
other files in both directions.
Note: To change your tablet’s USB connection options, you
should go to Settings -> DEVICE -> Storage, and tap Menu
icon at the upper right corner. Then tap USB computer
connection to enter to setup.
The tablet can be connected to a keyboard, a mouse or other
input devices via USB cable and use it just as you would with
a PC.
Micro-USB
EN - 15
Headphone
Headphone can be connected to the tablet’s Headphone
jack.
Headphone
(not included)
To headphone jack
Micro SD
Insert the micro SD card into the tablet’s Micro SD slot
until it clicks.
To check the storage of the micro SD card, go to Settings
-> DEVICE -> Storage.
Remove the micro SD card by pushing in on the card's
edge. The card will pop out and can be removed.
Notes:
• You can use micro SDTMcard and micro SDHCTMcard (up
to 32GB, SD card not included).
• Never remove or insert micro SD card in On mode.
Micro SD Card
(not included)
To Micro SD Card Slot
Wi-Fi
Connect to a Wi-Fi Network
1. Go to Settings -> WIRELESS & NETWORKS -> Wi-Fi,
and slide Wi-Fi to the I (ON) position.
2. The device will scan Wi-Fi networks automatically and
display the available names.
• If the device finds a network that you connected to
previously, it will connect to it automatically.
3. Tap a network name to connect to it, and enter a
password if necessary.
4. Alternatively, if your Wi-Fi router supports Wi-Fi
Protected Setup, tap the WPS icon at the top of the
screen, and then press the WPS button on your router.
5. If your network does not broadcast its SSID, tap the
Plus icon + at the top of the screen, and enter the
EN - 16
Turning Your Tablet On for the First Time
When using the tablet for the first time, you will be required
to setup the following:
1. Select the language, then tap .
2. Set the Wi-Fi.
3. If you have a Google Account, select "Yes". Then tap a
network name to see more details or connect to it, and
enter a password if necessary.
When prompted, sign in using the email address and
password for your Google Account. If you don’t have one
yet, go ahead and create one.
4. Follow the onscreen instructions to setup the tablet.
First Time Operation
Network SSID (name) of the network. If necessary,
enter security or other network configuration details.
Note: you can tap Menu icon at the upper right
corner in the Settings screen for advanced settings.
VPN (Virtual Private Network)
You can create virtual private network (VPN) and connect to
your private network securely through a public network, such
as the internet. You must set a lock screen PIN or password
before you can use credential storage.
Add VPN network and follow the instructions on the screen.
Basic Operation
EN - 17
Drag or Swipe
While holding an item such as an icon, it
can sometimes be moved by dragging it to
another area or screen. You may also be able
to swipe your finger across a screen or item to
navigate or move it.
Zoom
By placing two fingers on the screen, you can
slide them apart to "Zoom In", or pinch them
together to "Zoom Out".
Basic Operation
Using the Touchscreen
Here are some basic procedures for interacting with the
touchscreen.
Tap
To select an item on the touchscreen, lightly
tap it.
Press & Hold
In some instances, touching the item and
holding your finger on it will present other
options or menus.
EN - 18
Customizing the Home Screen
• From All Apps screen to Home screen: Tap All Apps
icon to open All Apps screen, press & hold an icon
or widget and slowly to drag it to the location of your
choice. This makes it much easier to change your Home
screen layout.
• Move apps or widgets: Press & hold an icon or widget,
slowly to drag it to the screen edge, the screen will
switch.
• Delete apps or widgets: Press & hold an icon or widget,
when the "X" icon appears at the left of the screen,
drag the icon or widget into it.
• Press & hold the wallpaper on your Home screen, and
choose your wallpaper from Gallery, Live Wallpapers,
Photos or Wallpapers.
To create a truly personalized experience, using your
location and personal Google account information, use
Google Now. Touch and Hold the Home icon, and slide
up to the Google Now icon. Follow the instructions to
setup your Google Now experience.
Turn Voice Search or Voice Action On
You can initiate a Voice Search or Voice Action by tapping
the Microphone icon in the top left corner of the Home
screen.
Google Now
Voice Search & Voice Actions
EN - 19
When you’re viewing the Google Now screen, you don’t
have to touch anything. Just say “Google.”
Note: To detect when you say "Google" to launch Voice
Search or Voice Actions, your tablet analyzes sound
picked up by your tablet's microphone in intervals of a few
seconds or less.
Using Voice Search
After tapping the microphone icon, just say whatever it is
you want Google to search for.
Using Voice Actions
There are many actions that the tablet can perform using
"Voice Actions". For example, you can send emails, set
alarms, play a song, or navigate to a website. Just tap
the Microphone icon, and say what you want the tablet
to do. As you speak, Voice Search analyzes your speech
and initiates the action.
If Voice Search doesn’t understand you, it lists a set of
possible meanings. Just tap the one you want.
Google Play
In addition to the apps that come preinstalled on your tablet,
you can download Android apps and games, music, movies,
TV shows and magazines using the Google Play Store app.
1. On the App menu, touch the Google Play Store icon.
2. To search for an item from the Google Play Store app,
touch the search icon in the upper right corner, and then
type a keyword to search.
3. Touch an available item to go to its details page. From
there you can install or download the item.
EN - 20
Settings
Settings lets you configure the tablet, set app options,
add accounts, and change other preferences.
WIRELESS & NETWORKS
Wi-Fi — Enable or disable Wi-Fi, and connect to a wireless
network so that you can check email, search the Web, or
access social media websites.
More... —Enable or disable Airplane mode or VPN; Enable
or disable USB Internet.
DEVICE
Sound — Set Volumes, Default notification sound, and
enable or disable Touch sounds and Screen lock sound.
Display — Set Brightness, Sleep, Daydream, Font size,
Cast screen, enable or disable Full screen mode.
ScreenshotSetting — Set Select delay time to capture the
screen, Set the location of screenshot storage and enable
or disable Show the screenshot button in the statusbar.
Storage — View available space in INTERNAL STORAGE,
SD CARD and EXTERNAL USB STORAGE /set the related
items.
Battery — View battery status.
Apps — View downloaded apps and running apps. To view
information or uninstall an app, tap the relevant app.
PERSONAL
Location — Enable or disable Access to my location,
EN - 21
RECENT LOCATION REQUESTS and LOCATION
SERVICES.
Security — Set preferences for SCREEN SECURITY,
PASSWORDS, DEVICE ADMINISTRATION, and
CREDENTIAL STORAGE.
Language & input — Set preferences for Language,
KEYBOARD & INPUT METHODS, SPEECH and MOUSE/
TRACKPAD.
Backup & reset — Set preferences for BACKUP &
RESTORE, and PERSONAL DATA.
ACCOUNTS
You can add an email account or another type of account.
SYSTEM
Date & time — Enable or disable Automatic date & time,
and select preferences for date, time, time zone, time format,
and date format.
Accessibility — Select preferences for SERVICES and
SYSTEM.
Printing — Enable or disable PRINT SERVICES.
About tablet
Check System updates, Status, Legal information etc.
EN - 22
A Google Account lets you organize and access your
personal information from any computer or mobile device.
Add an Account
You can use multiple Google Accounts and Microsoft
Exchange ActiveSync accounts on your tablet.
You may also be able to add other kinds of accounts,
depending on your apps. To add some accounts, you may
need to obtain details from your system administrator about
the service to which the account connects. For example, you
may need to know the account’s domain or server address.
1. Go to Settings -> ACCOUNTS -> Add account.
2. Tap the kind of account to add. And then follow the on-
screen instructions.
Remove an Account
To remove a Google account, go to Settings ->
ACCOUNTS -> Google -> [account-name] Menu icon
-> Remove account.
Google
Preinstalled Apps
Your tablet comes with many apps preinstalled to allow you
to browse the web, send and receive email, and access
entertainment. Spend some time exploring these apps to
learn how your tablet can be most useful for you.
EN - 23
Tablet displays network or service error message
• When you are located in places with poor signals, your
tablet may lose its Wi-Fi connection. Try moving closer to
the Wi-Fi router.
Touch screen response is slow or incorrect
If the tablet’s touch screen response is incorrect, please try
the following:
• Remove any protective film of the touch screen. The
protective film may prevent the device recognition input.
• Make sure that your fingers dry and clean before you tap
the touch screen.
• Restart the tablet to clear any temporary software bugs.
Tablet is frozen or a serious error appears
•
If the tablet is frozen or suspended, you may need to close the
app program or reset the tablet.
• If the tablet is frozen or slow to respond, press and hold the
power button for 8 seconds to reset the tablet.
• If that doesn't work, insert a paper clip into the RESET hole
on the back of the tablet.
Tablet gets warm
• When using for a long time, the tablet may be warm. This is
normal and will not affect the life or performance of the unit.
Trouble Shooting
Additional Information
EN - 24
Power: DC IN 5V (operate with AC adapter)
Front Camera: 0.3 Megapixel
Specifications
Copyright and Trademark Notices
Google, Google Play and other marks are trademarks of Google
Inc.
The Wi-Fi CERTIFIED Logo is a certification mark of the Wi-Fi
Alliance.
The Wi-Fi Protected Setup Mark is a mark of the Wi-Fi
Alliance.
Specifications and external appearance are subject to
change without notice.
Tablet can not show video of opposite side during skype
call
• The Wi-Fi signal is poor. Please move close to your
wireless router, or disconnect other devices from your
wireless router, or increase bandwidth of internet
connection.
• Please check the Wi-Fi setting. It's recommended to use
an IEEE 802.11 b/g/n. certified Wi-Fi network.
EN - 25
