User Manual Rev01
Equipped with an Android 4.2 operating system, a 1.3Ghz quad-core processor and
dedicated readers for data capturing (1D/2D barcodes, RFID), OBM-A8 is a
reliable and powerful 3G Mobile Data Terminal. It can be used in a variety of
specific contexts such as inventory management, warehousing, medical supplies
control, retail stores supervision, logistic operation, parking lot fare collection,
FMCG distribution, fixed assets management, procurement fair ordering,
admission ticket verification, and etc.
Safety Cautions
Please read the following concise rules. Violation of these rules may cause danger or
infringement of the law.
Boot in safety: Don’t switch on the handheld when wireless device is forbidden or
is to cause interference and danger.
Interference: all wireless devices may be subject to radio interference which may
affect their performance.
Fare use: the handheld can be only used in the purpose described in this manual.
Maintenance: only technically qualified person can disassemble the handheld.
Accessories and battery: use only approved accessories and battery. Don’t connect
to inconsistent products.
Water-proof: the handheld is not water-proof, please keep it dry.
Data backup: please make a backup for the data saved in the handheld.
Connection: If in need of connecting to other devices, please obtain necessary
safety instructions from their manual or manufacturer. Never connect to an inconsistent
device.
Battery Charging
Connect the usb power adaptor with the micro-usb cable then plug one end into the
power outlet and the other end into the Handheld charging port. A charging icon will be
shown on the screen status bar. When it is fully charged, a full battery icon will be
shown instead.
CAUTIONS：
1. The Handheld accepts only authorized battery and charger;
2. For first time charging, please make sure the charging time is over 12 successive
hours;
3. Battery may self-discharge. Please charge up the battery before use if the battery
stands idle for a long period;
4. If a fully charged battery's life goes short greatly, please replace the battery with
a new one;
5. Do not impact，shock or throw the battery violently, or it may cause leakage,
damage or even explosion.
battery
unscrew the battery cover securing
bolt to load or replace a new battery.
usb power adaptor
use together with the micro-usb cable to
charge the handheld battery.
micro-usb cable
connect the handheld to the computer
for data synchronization or use with
the power adaptor to charge the
handheld battery.
lanyard
place through the lanyard holder and
hang on the wrist preventing drop of the
handheld.
Accessories
SIM /TF card installation
To connect the Handheld to a CDMA/GSM network, a SIM card must be inserted in
the card slot before power-on.
The Handheld also come with a TF card slot which supports storage up to 32G.
Unscrew the battery cover securing bolt and remove the cover and the battery.
Data Collecting
The Handheld comes with a standard laser scan engine for quick, easy and professional
capture of a bar code.
A 2D scan engine for reading QR code is also available under request.
Another option is the RFID reader. It is used to decode an electronic tag. It can come
with the laser scan engine or the 2D scan engine or install alone.
However, only one scan engine can be installed.
Press Scan A on the left side or Scan B on the right side of the Handheld to invoke the
scan engine. When the red beam (laser scan engine) or the square light (2D scan
engine) is emitted from the scan window, aim it at the bar code/QR code and the
information contained in the code will be captured.
The use of the RFID reader is even more convenient. Just put the electronic tag beneath
the RFID inductive zone and the decode program will automatically capture the
information in the tag.
CAUTIONS：
1. Dust on the scan window may impair the scan performance. Use a soft cloth not
the finger to wipe it regularly.
2. the scan angle and distance may affect the scan performance. Try to adjust the
angle and distance when the scan result is not desirable.
3. Request for a DLL tool if an APP is to launch the scan engine or the RFID reader.
CAUTIONS：
1. The touch of the metal plate of the SIM card may cause data loss and damage;
2. Put the SIM card far away from magnetism and electricity.
3. As a professional data collecting equipment, the Handheld transfers data instead
of voice via the CDMA/GSM network. It provides no voice input parts such as
microphone.
Technical Parameters
Hardware test: this icon provides not a phone call dial but a test service
entry. By dialing a specific code, testers can enter the test mode to check if
the hardware works well. Test items include screen display, keypads,
speaker, wireless connections and some other performance. It is usually
used in maintenance service to identify problems quickly. The specific code
is generally open to professional maintenance persons and testers only.
Warning Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesired operation.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device
can be used in portable exposure condition without restriction.
