Alpheus Digital PIR-101 Motion sensor User Manual
Alpheus Digital Co., Limited. Motion sensor
User Manual
Motion Sensor
The PIR-101 is a intended for walls and has a detection range
of 90 degrees. The motion detector uses infrared technology
to detect moving bodies of heat. When on, the pet immunity
setting can endure animals up to 55 pounds. The sensor will
also send a signal when the contact sensor cover is tampered
or when the test button on the side is pressed.
Adding Sensor to the Panel
To add a PIR-101 to the panel, set your panel to sensor
learning mode, tamper the sensor by pressing the test button
found on the side of the sensor.
Installation
Corners are the best place to install motion sensors, but
they can also be installed on a wall. Place motion sensors 6
to 8 feet above the floor.
You can use the adhesives to mount a motion sensor in a
corner or on the wall. For all sensors, make sure the
surface is clean and dry for good adherence.
After removing the backing from the adhesive and placing
the sensor in its location, press firmly and hold it in place
for 30 seconds.
Testing
To test a PIR-101 go to test mode on your panel and ensure
the panel volume is loud enough to hear. Next, move in
front of the motion detector. Listen for the appropriate
verification sounds (see panel instructions for more details).
When you are finished, Exit test mode.
Battery Installation/Replacement
To change the motion sensor batteries, press up on the
button on the bottom of the sensor and pull the case toward
you. The motion sensor requires one CR17345. Replace the
battery and snap the case cover back on the sensor.
Specifications
Signal Range:120m Open Air
Frequency: 345.00 MHz
Supervisory Interval: 60 minutes
Operating Temperature: 0-49℃
Operating Humidity: 5-90% Non-Condensing
Battery Type: CR123A
FCC COMPLIANCE STATEMENT*
This device complies with FCC Rules and Regulations as Part
15 devices.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired operation.
FCC ID:OC7PIR-101
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and
receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician
for help.
