Operating Instructions
Installation and Connections

AOEU Issue_A

Mobile Media Station

IVE-W530BT

• OWNER’S MANUAL

Please read before using this equipment. • ANVÄNDARHANDLEDNING

Innan du använder utrustningen bör du läsa

igenom denna användarhandledning.

• BEDIENUNGSANLEITUNG

Lesen Sie diese Bedienungsanleitung

bitte vor Gebrauch des Gerätes.

• GEBRUIKERSHANDLEIDING

Lees deze aanwijzingen aandachtig alvorens

dit toestel te gebruiken.

• MODE D’EMPLOI

Veuillez lire avant d’utiliser cet appareil. • РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ

Прочтите настоящее руководство перед

началом использования оборудования.

• MANUAL DE OPERACIÓN

Léalo antes de utilizar este equipo. • INSTRUKCJA OBSŁUGI

Prosimy zapoznać się z tą instrukcją przed

przystąpieniem do użytkowania urządzenia.

• ISTRUZIONI PER L’USO

Si prega di leggere prima di utilizzare il

attrezzatura.

• ΕΓΧΕΙΡΙΔΙΟ ΧΡΗΣΤΗ

Παρακαλούμε διαβάστε το πριν

χρησιμοποιήσετε τη συσκευή.

ALPINE ELECTRONICS MARKETING, INC.

1-7, Yukigaya-Otsukamachi, Ota-ku,

Tokyo 145-0067, JAPAN

Phone: 03-5499-4531

ALPINE ELECTRONICS OF AMERICA, INC.

19145 Gramercy Place, Torrance,

California 90501, U.S.A.

Phone 1-800-ALPINE-1 (1-800-257-4631)

ALPINE ELECTRONICS OF CANADA, INC.

777 Supertest Road, Toronto,

Ontario M3J 2M9, Canada

Phone 1-800-ALPINE-1 (1-800-257-4631)

ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.

161-165 Princes Highway, Hallam

Victoria 3803, Australia

Phone 03-8787-1200

ALPINE ELECTRONICS GmbH

Wilhelm-Wagenfeld-Str. 1-3, 80807 München, Germany

Phone 089-32 42 640

ALPINE ELECTRONICS OF U.K. LTD.

Alpine House

Fletchamstead Highway, Coventry CV4 9TW, U.K.

Phone 0870-33 33 763

ALPINE ELECTRONICS FRANCE S.A.R.L.

(RCS PONTOISE B 338 101 280)

98, Rue de la Belle Etoile, Z.I. Paris Nord Il,

B.P. 50016, 95945 Roissy Charles de Gaulle

Cedex, France

Phone 01-48638989

ALPINE ITALIA S.p.A.

Viale C. Colombo 8, 20090 Trezzano

Sul Naviglio (MI), Italy

Phone 02-484781

ALPINE ELECTRONICS DE ESPAÑA, S.A.

Portal de Gamarra 36, Pabellón, 32

01013 Vitoria (Alava)-APDO 133, Spain

Phone 945-283588

ALPINE ELECTRONICS (BENELUX) GmbH

Leuvensesteenweg 510-B6,

1930 Zaventem, Belgium

Phone 02-725-13 15

FOR CAR USE ONLY/NUR FÜR AUTOMOBIL GEBRAUCH/POUR APPLICATION AUTOMOBILE UNIQUEMENT/PARA USO EN

AUTOMÓVILES/SOLO PER L’UTILIZZO IN AUTOMOBILE/ENDAST FÖR BILBRUK/ALLEEN VOOR GEBRUIK IN DE AUTO/

ТОЛЬКО

ДЛЯ ИСПОЛЬЗОВАНИЯ В АВТОМОБИЛЯХ

DO UŻYCIA TYLKO W SAMOCHODZIE

ΓΙΑ ΧΡΗΣΗ ΜΟΝΟ ΣΕ ΑΥΤΟΚΙΝΗΤΟ

3-EN

ENGLISH

Contents

Operating Instructions

WARNING

WARNING ................................................. 6

CAUTION .................................................. 6

PRECAUTIONS ........................................ 7

Discs Playable on This Unit ................... 8

Getting Started

Accessory List ................................................ 12

Location of Controls ...................................... 12

Turning Power On or Off ............................... 13

Adjusting the Volume ..................................... 13

Lowering Volume Quickly ............................. 13

How to view the Display ................................ 13

TOUCH PANEL operation ......................... 13

Recalling the Source ................................... 13

Displaying the Numeric Keypad Input

Screen ...................................................... 14

Radio

Listening to the Radio .................................... 15

Presetting Stations Manually .......................... 15

Presetting Stations Automatically .................. 15

Tuning to Preset Stations ................................ 15

RDS Operation

Turning AF (Alternative Frequencies) On or

Off ............................................................... 16

Receiving Traffic Information ........................ 16

PTY (Programme Type) Tuning ..................... 16

Receiving Traffic Information While Playing

CD or Radio ................................................ 17

Priority News .................................................. 17

Displaying Radio Text .................................... 17

CD/MP3/WMA/AAC

Playback ......................................................... 18

Repeat Play ..................................................... 18

M.I.X. (Random Play) .................................... 19

Selecting Folders

(concerning MP3/WMA/AAC) .................. 19

About MP3/WMA/AAC .................................19

DVD

Playing a Disc ................................................21

To display the DVD mode screen ...............21

If a menu screen appears .............................22

Displaying the Top Menu Screen ...............23

Displaying the Menu Screen ......................23

Displaying the Menu Operation Mode

Screen ......................................................23

Numeric Keypad Input Operation ...................23

Select a Track/File/Chapter .........................23

Select a Folder/Title .....................................23

Stopping Playback (Pre Stop) ........................24

Stopping Playback .........................................24

Fast-forwarding/Fast-reversing ......................24

Finding the Beginnings of Chapters/Files ......24

Playing Still Frames (Pausing) .......................24

Slow Motion Playback ...................................24

Selecting Folders ............................................25

Repeat Playback .............................................25

Searching by Title/Folder Number .................25

Searching Directly by Chapter,

File Number ................................................25

Switching the Angle .......................................26

Switching the Audio Tracks ...........................26

Switching the Subtitles

(Subtitle Language) ....................................26

Switching from the disc menu .......................26

About DivX .....................................................27

Other Useful Features

Adjusting the Audio ........................................27

Search Function ..............................................29

Rear Selection Function ..................................29

Switching Display Modes ...............................30

Switching the Visual Source Only

(Simultaneous Function) .............................30

Cancelling the Simultaneous Function ........30

Blackout Mode On and Off .............................30

4-EN

Setup

DVD Setup

DVD Setup Operation ..................................... 31

Changing the language setting .................... 31

Setting of the Menu Language .................... 31

Setting of the Audio Language ................... 31

Setting of the Subtitle Language ................. 32

Setting the Downmix Mode ........................ 32

Setting the TV Screen ................................. 32

Setting the DOLBY Dynamic Range .......... 32

Displaying DivX® Disc Information ......... 32

Source Setup

Source Setup Operation .................................. 33

Radio Setup ................................................. 33

Display Setup

Display Setup Operation ................................. 34

Setting the Brightness of the

Backlighting ............................................. 34

Adjusting the Minimum Level of

Backlight .................................................. 34

Turn the Function Guide ON/OFF

(Function Guide Fade) ............................. 35

Switching the Font Background Colour ...... 35

Adjusting the Touch Panel .......................... 35

Setting the VISUAL Button ........................ 35

Visual EQ™

Visual EQ Setting Operation .......................... 35

Selecting the Visual EQ Mode

(Factory’s setting) .................................... 36

Adjusting Brightness ................................... 36

Adjusting Colour of Picture ........................ 36

Adjusting Tint of Picture ............................. 36

Adjusting Image Contrast ........................... 36

Adjusting Picture Quality ............................ 36

Storing Visual EQ ....................................... 36

General Setup

General Setup Operation ................................ 37

Displaying the Time .................................... 37

Setting the Clock Display ............................ 37

Setting the Time .......................................... 37

Setting Summer Time .................................. 37

Demonstration Function .............................. 37

Sound (Beep) Guide Function ..................... 37

Setting the Beep Level ................................ 38

Setting the Scroll ......................................... 38

Changing the Russian Font ......................... 38

Adjusting the Dimmer of Button Lighting

at Night .................................................... 38

Setting Security code .................................. 38

System Setup

System Setup Operation ................................. 39

Setting the Rear Camera Input .................... 39

Setting the Navigation Mode ...................... 40

Setting the Navigation Interruption ............ 40

Setting the AUX Mode ............................... 40

Setting the AUX Front Mode ...................... 41

Setting the Picture/Sound Output ............... 41

Setting the BLUETOOTH Connection

(BLUETOOTH IN) ................................. 41

Changing the Lighting Colour of

Buttons ..................................................... 41

BT Hands Free Calling

Setup Before Using ........................................ 42

About BLUETOOTH .................................. 42

Before Using Hands-Free Function ............ 42

How to connect to a BLUETOOTH

compatible device (Pairing) ..................... 42

BLUETOOTH Setup ...................................... 43

BLUETOOTH Setup Operation .................. 43

Hands-Free Phone Control ............................. 44

About the Hands-Free Phone ...................... 44

Answering a Call ............................................ 45

Hanging up the Telephone .............................. 45

Adjusting the volume when receiving

a Call ........................................................... 45

Redial Function .............................................. 45

Call waiting function ...................................... 45

Call Switching Operation ............................... 46

Call History .................................................... 46

Redialing a Number in Dialed Calls

History ..................................................... 46

Dialing a Number in Received Calls

History ..................................................... 46

Dialing a Number in Missed Calls

History ..................................................... 46

Dialing a Number In the Phone Book

(Phone Book) ........................................... 47

Dialing a Number Using Direct

Dial Input ................................................. 48

Voice Dial Operation ................................... 48

BLUETOOTH Audio Function ...................... 48

BLUETOOTH Audio Operation ................. 48

Rearview Camera Operation

(Optional)

Switching the Rear Camera Screen

(Optional) .................................................... 49

5-EN

Displaying the rear view video while

the car is in reverse .................................. 49

Displaying the rear view video

manually .................................................. 49

Navigation System (Optional)

Switching the Navigation Screen

(Optional) .................................................... 49

Auxiliary Device (Optional)

Operating Auxiliary Devices (Optional) ........ 50

TUE-T200DVB Operation (Optional)

Operating the TUE-T200DVB (Optional) ..... 50

USB Memory (Optional)

BANK Function ............................................. 51

Playback ......................................................... 52

Repeat Play ..................................................... 52

Random Play Shuffle (M.I.X.) ....................... 52

Searching for a desired Song .......................... 53

Searching by Playlist name ......................... 53

Selecting the desired Playlist ......................... 53

Select the desired Folder

(Folder up/down) ........................................ 53

iPod/iPhone (Optional)

Connecting an iPod/iPhone ............................ 54

Setting the iPod Control ................................. 54

Playback ......................................................... 54

Searching for a desired Song .......................... 55

Searching by artist name ............................. 55

Selecting Playlist/Artist/Album/Genre/

Composer/Episode/Category ...................... 55

Random Play Shuffle (M.I.X.) ....................... 56

Repeat Play ..................................................... 56

Information

About DVDs ................................................... 56

List of Language Codes ................................. 57

In Case of Difficulty ....................................... 58

Specifications ................................................. 62

Installation and

Connections

Warning .................................................. 63

Caution ................................................... 63

Precautions ........................................... 63

Installation ......................................................64

Mounting the Microphone ..............................65

Connections ....................................................67

System Example .............................................69

6-EN

Operating Instructions

INSTALL THE PRODUCT CORRECTLY SO THAT THE DRIVER

CANNOT WATCH TV/VIDEO UNLESS THE VEHICLE IS

STOPPED AND THE EMERGENCY BRAKE IS APPLIED.

It is dangerous for the driver to watch TV/Video while driving a

vehicle. Installing this product incorrectly enables the driver to

watch TV/Video while driving. This may cause a distraction,

preventing the driver from looking ahead, thus causing an accident.

The driver or other people could be severely injured.

DO NOT WATCH VIDEO WHILE DRIVING.

Watching the video may distract the driver from looking ahead of

the vehicle and cause an accident.

DO NOT OPERATE ANY FUNCTION THAT TAKES YOUR

ATTENTION AWAY FROM SAFELY DRIVING YOUR VEHICLE.

Any function that requires your prolonged attention should only be

performed after coming to a complete stop. Always stop the vehicle

in a safe location before performing these functions. Failure to do

so may result in an accident.

KEEP THE VOLUME AT A LEVEL WHERE YOU CAN STILL

HEAR OUTSIDE NOISES WHILE DRIVING.

Excessive volume levels that obscure sounds such as emergency

vehicle sirens or road warning signals (train crossings, etc.) can be

dangerous and may result in an accident. LISTENING AT LOUD

VOLUME LEVELS IN A CAR MAY ALSO CAUSE HEARING

DAMAGE.

MINIMIZE DISPLAY VIEWING WHILE DRIVING.

Viewing the display may distract the driver from looking ahead of

the vehicle and cause an accident.

DO NOT DISASSEMBLE OR ALTER.

Doing so may result in an accident, fire or electric shock.

USE ONLY IN CARS WITH A 12 VOLT NEGATIVE GROUND.

(Check with your dealer if you are not sure.) Failure to do so may

result in fire, etc.

KEEP SMALL OBJECTS SUCH AS BOLTS OR SCREWS OUT

OF THE REACH OF CHILDREN.

Swallowing them may result in serious injury. If swallowed,

consult a physician immediately.

USE THE CORRECT AMPERE RATING WHEN REPLACING

FUSES.

Failure to do so may result in fire or electric shock.

DO NOT BLOCK VENTS OR RADIATOR PANELS.

Doing so may cause heat to build up inside and may result in fire.

USE THIS PRODUCT FOR MOBILE 12V APPLICATIONS.

Use for other than its designed application may result in fire,

electric shock or other injury.

DO NOT PLACE HANDS, FINGERS OR FOREIGN OBJECTS IN

INSERTION SLOTS OR GAPS.

Doing so may result in personal injury or damage to the product.

HALT USE IMMEDIATELY IF A PROBLEM APPEARS.

Failure to do so may cause personal injury or damage to the

product. Return it to your authorized Alpine dealer or the nearest

Alpine Service Centre for repairing.

WARNING

This symbol means important instructions.

Failure to heed them can result in serious injury

or death.

CAUTION

This symbol means important instructions.

Failure to heed them can result in injury or

material property damage.

7-EN

PRECAUTIONS

Product Cleaning

Use a soft dry cloth for periodic cleaning of the product. For more

severe stains, please dampen the cloth with water only. Anything

else has the chance of dissolving the paint or damaging the plastic.

Temperature

Be sure the temperature inside the vehicle is between +45°C

(+113°F) and 0°C (+32°F) before turning your unit on.

Moisture Condensation

You may notice the disc playback sound wavering due to

condensation. If this happens, remove the disc from the player and

wait about an hour for the moisture to evaporate.

Damaged Disc

Do not attempt to play cracked, warped, or damaged discs. Playing

a bad disc could severely damage the playback mechanism.

Maintenance

If you have problems, do not attempt to repair the unit yourself.

Return it to your Alpine dealer or the nearest Alpine Service

Station for servicing.

Never Attempt the Following

Do not grip or pull out the disc while it is being pulled back into the

player by the automatic reloading mechanism.

Do not attempt to insert a disc into the unit when the unit power is

off.

Inserting Discs

Your player accepts only one disc at a time for playback. Do not

attempt to load more than one disc.

Make sure the label side is facing up when you insert the disc.

“Disc Error” will be displayed on your player if you insert a disc

incorrectly.

Playing a disc while driving on a very bumpy road may result in

skips, but this will not scratch the disc or damage the player.

Irregular Shaped Discs

Be sure to use round shaped discs only for this unit and never use

any special shaped discs.

Use of special shaped discs may cause damage to the mechanism.

New Discs

To prevent the CD from jamming, “Disc Error” is displayed if discs

with irregular surfaces are inserted or if discs are inserted

incorrectly. When a new disc is ejected immediately after initial

loading, use your finger to feel around the inside of the centre hole

and outside edge of the disc. If you feel any small bumps or

irregularities, this could inhibit proper loading of the disc. To

remove the bumps, rub the inside edge of the hole and outside edge

of the disc with a ballpoint pen or other such instrument, then insert

the disc again.

Installation Location

Make sure the IVE-W530BT will not be installed in a location

subjected to:

• Direct sun and heat

• High humidity and water

• Excessive dust

• Excessive vibrations

Correct Handling

Do not drop the disc while handling. Hold the disc so you will not

leave fingerprints on the surface. Do not affix tape, paper, or

gummed labels to the disc. Do not write on the disc.

Disc Cleaning

Fingerprints, dust, or soil on the surface of the disc could cause the

DVD player to skip. For routine cleaning, wipe the playing surface

with a clean, soft cloth from the centre of the disc to the outer edge.

If the surface is heavily soiled, dampen a clean, soft cloth in a

solution of mild neutral detergent before cleaning the disc.

Centre Hole

Bumps

Centre Hole

New Disc

Outside

(Bumps)

CORRECT

INCORRECT CORRECT

8-EN

Disc Accessories

There are various accessories available on the market for protecting

the disc surface and improving sound quality. However, most of

them will influence the thickness and/or diameter of the disc. Using

such accessories can cause the disc to be out of standard

specifications and may create operational problems. We

recommend not using these accessories on discs played in Alpine

DVD players.

Handling the Detachable Front Panel

• Do not expose to rain or water.

• Do not drop or subject to shock.

• After turning the system off, a slight ghost of the image will

remain temporarily. This is an effect peculiar to LCD technology

and is normal.

• In cold temperature conditions, the screen may lose contrast

temporarily. After a short warm-up period, it will return to

normal.

Operation of some of the functions of this unit is very complex.

Because of this, it was deemed necessary to place these functions

into a special screen. This will restrict operation of these functions

to times when the vehicle is parked. This ensures the focus of the

driver’s attention will be on the road and not on the IVE-W530BT.

This has been done for the safety of the driver and passengers.

The car must be parked and the parking brake must be engaged for

the procedure described in the Owner’s Manual to be valid. The

warning “Can’t operate while driving”, will be displayed if any

attempts are made to perform these operations while driving.

• The IVE-W530BT draws minimal current even when its power

switch is turned off. If the switched power (ignition) lead of the

IVE-W530BT is connected directly to the positive (+) post of the

vehicle’s battery, the battery may be discharged.

An SPST (Single-Pole, Single-Throw) switch (sold separately)

can be added to simplify this procedure. Then, you can simply

place it in the OFF position when you leave the vehicle. Turn the

SPST switch back ON before using the IVE-W530BT. For

connecting the SPST switch, refer to the “Connection Diagram

of SPST Switch (Sold Separately)” (page 66). If the power

(ignition) lead is unswitched, it must be disconnected from the

battery post should the vehicle be left unused for an extended

period of time.

Discs Playable on This Unit

Playable discs

The discs listed below can be played on this unit.

* Two-layer DVD disc compatible

The formatted discs listed below can be played on this unit.

Discs that are not finalised cannot be played back

Transparent Sheet Disc Stabilizer

Mark (logo) Recorded content Disc size

DVD Video

Audio

Video

12 cm*

Music CD Audio 12 cm

DivX®

Audio

Video

12 cm

CD-R/

CD-RW

DVD-R/

DVD-RW

DVD+R/

DVD+RW

CD Format

MP3 Format (“mp3”)

WMA Format

(“wma”)

AAC Format

(“mp4”, “m4a”)

DVD Video Format

DivX Format

(“avi”, “div”, “divx”)

9-EN

Discs that cannot be played

DVD-ROMs, DVD-RAMs, CD-ROMs (excluding MP3/WMA/

AAC files), photo CDs, etc.

DualDisc

This unit is not compatible with DualDisc.

Using a DualDisc may cause unit malfunction, and may cause disc

damage when the disc is inserted/ejected.

DVD region number (playable region number)

This DVD player will play back any disc whose region number is 2

(or All). DVDs with a region number other than those listed below,

cannot be played on this DVD player.

Using compact discs (CD/CD-R/CD-RW)

If you use unspecified compact discs, correct performance cannot

be guaranteed.

You can play CD-Rs (CD-Recordable)/CD-RWs (CD-ReWritable)

which have been recorded only on audio devices. You can also play

CD-Rs/CD-RWs containing MP3/WMA/AAC formatted audio

files.

• Some of the following discs may not play on this unit:

Flawed discs, discs with fingerprints, discs exposed to extreme

temperatures or sunlight (e.g., left in the car or this unit), discs

recorded under unstable conditions, discs on which a recording

failed or a re-recording was attempted, copy-protected CDs

which do not conform to the audio CD industry standard.

• Use discs with MP3/WMA/AAC files written in a format

compliant with this unit. For details, see pages 19 and 20.

To customers using CD-R/CD-RW

• If a CD-R/CD-RW cannot be played back, make sure the last

recording session was closed (finalised).

• Finalise the CD-R/CD-RW if necessary, and attempt playback

again.

Tips for making your own CDs

The IVE-W530BT plays DVD Video, Audio CD, DivX® and has a

built in MP3/WMA/AAC decoder.

The following information is designed to help you create your own

music CDs (either Audio CD or MP3/WMA/AAC encoded CD-R/

RW files).

What is the difference between an Audio and MP3/WMA/AAC

CD?

An Audio CD is the same format as the commercial CDs you buy

in the store (also known as CD-DA). MP3 (MPEG-1 Audio Layer

3)/WMA (Windows Media Audio)/AAC (Advanced Audio

Coding) is a data file that uses a compression scheme to reduce the

size of the music file.*

Hybrid Audio CD and Data (MP3/WMA/AAC) CD-R/RW

discs:

The IVE-W530BT can only read CD-DA sector on the disc.*

Multi-session CD-R/RW:

Once a recording has been stopped, this is considered one session.

If the disc is not closed (finalised), additional data may be added.

Once this additional data has been recorded, this becomes a “multi-

session” CD. The IVE-W530BT can only read multi-session DATA

Formatted discs (MP3/WMA/AAC files - Not Audio CD files).

Properly formatted MP3/WMA/AAC Discs:

Use ISO9660 formatting to insure proper playback. You may use

standard ISO naming Level 1 (8.3 DOS standard), Level 2 (32

characters) or Joliet (Windows or Macintosh long filenames) file

naming conventions*.

* Please consult the Owner’s manual for additional information.

ALL

On handling compact discs (CD/CD-R/CD-RW)

• Do not touch the surface.

• Do not expose the disc to direct sunlight.

• Do not affix stickers or labels.

• Clean the disc when it is dusty.

• Make sure that the disc is smooth and flat.

• Do not use commercially available disc accessories.

Do not leave the disc in the car or the unit for a long time.

Never expose the disc to direct sunlight.

Heat and humidity may damage the disc and you may not be

able to play it again.

10-EN

Using DVD-Rs/DVD-RWs/DVD+Rs/DVD+RWs

• This unit is compatible with discs recorded in the standard DVD-

Video (DVD-R/DVD-RW only) formats.

• Note that discs not finalised (processed to enable to play on

playback-only DVD players) cannot be played on this DVD

player.

• Some discs may not play back, depending on the recording

device and disc format.

• Discs or files utilizing copy protection, may not be playable.

Some recording systems may not properly format copied files to

enable proper playback.

• In the following cases, the disc may not play on this unit:

discs recorded by certain DVD recorders, certain irregular discs,

flawed discs, dirty discs, when the pickup lens of this DVD

player is dirty, or when moisture condensation has occurred

inside the unit.

• Be sure to follow all cautions included with your DVD-Rs/

DVD-RWs/DVD+Rs/DVD+RWs discs.

• Do not put stickers, seals, or tape on the label side of DVD-Rs/

DVD-RWs/DVD+Rs/DVD+RWs.

• Compared to the regular discs, DVD-Rs/DVD-RWs/DVD+Rs/

DVD+RWs are more affected by heat, moisture, and direct

sunlight. If left in a car, etc., damage may occur and it might not

play on this unit.

• The operable temperature range for disc playback is as follows:

DVD-R/DVD-RW: -25 ~ +70°C

DVD+R/DVD+RW: +5 ~ +55°C

Disc terminology

Title

If titles are programmed for the DVD, these are the largest units of

division of the information recorded on the disc.

Chapter

Each Title may also be divided into smaller divisions, called

chapters. These can be specific scenes or musical selections.

Protecting the USB connector

• Only an iPod/iPhone or USB memory can be connected to the

USB connector on this unit. Correct performance using other

USB products cannot be guaranteed.

• If the USB connector is used, be sure to use only the supplied

connector cable with the unit. A USB hub is not supported.

• Depending on the connected USB memory device, the unit may

not function or some functions may not be performed.

• The audio file format that can be played back on the unit is

MP3/WMA/AAC.

• Artist/song name, etc., can be displayed, however characters

may not be correctly displayed.

On Handling USB Memory

• This unit can control a memory storage device that supports the

USB Mass Storage Class (MSC) protocol. Playable audio file

formats are MP3, WMA and AAC.

• USB memory function is not guaranteed. Use USB memory

according to the terms of agreement. Read the USB memory

Owner’s Manual thoroughly.

• Fix the USB memory in a location where driver operation will

not be hindered.

• USB memory may not function correctly at high or low

temperature.

• Use only certified USB memory. Note that even certified USB

memory, may not function correctly depending on its type or

state.

• Depending on the settings of the USB memory type, memory

state or encoding software, the unit may not play back or display

properly.

• Files protected by DRM (Digital Rights Management), cannot be

played back on this unit. These include AAC formatted files

purchased from the iTunes Store and WMA or other files with

some form of copyright protection.

• USB memory may take time to start playback. If there is a

particular file other than audio in the USB memory, it may take

considerable time before the file is played back or searched.

• The unit can play back “mp3”, “wma”, “m4a” or “divx” file

extensions.

• Do not add the above extensions to a file other than audio data.

This non-audio data will not be recognised. The resulting

playback may contain noise that can damage speakers and/or

amplifiers.

• It is recommended to back up important data on a personal

computer.

• Do not remove the USB device while playback is in progress.

Change SOURCE to something other than USB, then remove the

USB device to prevent possible damage to its memory.

CAUTION

Alpine accepts no responsibility for lost data, etc., even if data, etc.,

is lost while using this product.

11-EN

•This item incorporates copy protection technology that is

protected by U.S. patents and other intellectual property rights

of Rovi Corporation. Reverse engineering and disassembly are

prohibited.

•Manufactured under license from Dolby Laboratories.

Dolby and the double-D symbol are trademarks of Dolby

Laboratories.

•Windows Media and the Windows logo are trademarks, or

registered trademarks of Microsoft Corporation in the United

States and/or other countries.

•iPhone, iPod, iPod classic, iPod nano, and iPod touch are

trademarks of Apple Inc., registered in the U.S. and other

countries.

•“Made for iPod,” and “Made for iPhone,” mean that an

electronic accessory has been designed to connect specifically to

iPod, or iPhone, respectively, and has been certified by the

developer to meet Apple performance standards. Apple is not

responsible for the operation of this device or its compliance

with safety and regulatory standards. Please note that the use of

this accessory with iPod, or iPhone may affect wireless

performance.

•The BLUETOOTH® word mark and logos are registered

trademarks owned by the Bluetooth SIG, Inc. and any use of

such marks by Alpine Electronics, Inc. is under license.

•“MPEG Layer-3 audio coding technology licensed from

Fraunhofer IIS and Thomson”

•“Supply of this product only conveys a license for private, non-

commercial use and does not convey a license nor imply any

right to use this product in any commercial (i.e. revenue-

generation) real time broadcasting (terrestrial, satellite, cable

and/or any other media), broadcasting/streaming via internet,

intranets and/or other networks or in other electronic content

distribution systems, such as pay-audio or audio-on-demand

applications. An independent license for such use is required.

For details, please visit http://www.mp3licensing.com”

•DivX®, DivX Certified® and associated logos are trademarks of

Rovi Corporation or its subsidiaries and are used under license.

12-EN

Accessory List

•Head unit .............................................................................1

•Power Cable ........................................................................1

•Mounting Sleeve ..................................................................1

•Bracket key..........................................................................2

•Flush Head Screw (M5 × 8).................................................6

•Screw (M5 × 8) ...................................................................8

•Rubber Cap .........................................................................1

•Hex Bolt ...............................................................................1

•Front Frame .........................................................................1

•USB extension cable ..........................................................1

•Microphone .........................................................................1

•Owner’s Manual .............................................................1 set

Location of Controls

DISC Slot

button

Ejects a disc.

(Phone) button

•Press to display the Telephone Menu screen.

•Press and hold for at least 2 seconds to activate Voice

Dial mode.

(When BLUETOOTH IN is set to HFP or HFP+AUDIO

(page 41).)

Track tune button

Press to select the desired Radio preset station/track/file/

chapter.

SOURCE/ button

•Turns the power on.

•Press and hold for at least 3 seconds to turn the power

off.

•Recalls the SOURCE selection screen.

Rotary encoder/MUTE/TA

•Adjust the volume by turning to the left or right.

•Press to activate/deactivate mute mode.

•Press and hold for at least 2 seconds to activate/

deactivate the Traffic Information mode.

Remote Sensor/Dimmer Sensor

•Point the optional remote control transmitter towards the

remote sensor within a range of 2 meters.

•Senses the brightness of the car interior.

Front AUX Input Terminal

Connects a portable music player, etc., to the system. For

details, see “Operating Auxiliary Devices (Optional)”

(page 50).

Getting Started

Connectable to Remote Control Interface Box

You can operate this unit from the vehicle’s control unit when

an Alpine Remote Control Interface Box (optional) is

connected. For details, contact your Alpine dealer.

•The buttons on the face of this unit are shown in bold

(e.g. SOURCE/). The onscreen buttons that appear in the

display are shown in bold enclosed by [ ] (e.g.[BAND]).

13-EN

Turning Power On or Off

Some of this unit’s functions cannot be performed while the vehicle is in

motion. Be sure to stop your vehicle in a safe location and apply the

parking brake, before attempting these operations.

Press SOURCE/ to turn on the unit.

•The unit can be turned on by pressing any button on the unit except

(Eject).

•When the security code is set, you have to input the password when

the system is connected to a battery and turned on for the first time.

For details, refer to “Setting Security code” on page 38.

Press and hold SOURCE/ for at least 3 seconds to

turn off the unit.

Adjusting the Volume

Adjust the volume by turning the Rotary encoder.

Volume: 0 - 35

Lowering Volume Quickly

Activating this function will instantly lower the volume level by 20 dB.

Press Rotary encoder (MUTE).

The audio level decreases by about 20 dB.

Pressing Rotary encoder (MUTE) again brings the audio back to

its previous level.

How to view the Display

•To protect the display, touch the onscreen button with the tip of your

finger.

•If you touch a button and there is no reaction, remove your finger

from the display once, and try again.

•If you touch two buttons at the same time, a malfunction may occur.

Here is an example explanation for the Radio mode display on how to

recall a source.

Press SOURCE/ .

The SOURCE selection screen is displayed.

Display example for SOURCE selection screen

Changes the item of source selection list. (Depending

on the source quantity, this button may not be

displayed.)

Displays the source modes that can be selected.

[ ] button: Changes to Navigation screen.

(Available only when ON is set in “Setting the Navigation

Mode” (page 40) and “Navi” is set in “Setting the

VISUAL Button” on page 35).

[V.Sel] button: Changes to VISUAL selection screen.

(When V.Sel is set in “Setting the VISUAL Button” on

page 35.)

Changes to SETUP main screen.

Changes to Navigation main screen. (When “ON” is set

in “Setting the Navigation Mode” (page 40).)

Changes to the Telephone Menu screen.

(When “BLUETOOTH IN” is set to other than OFF

(page 41).)

Displays the rear view video.

(When an optional rearview camera is connected and

Camera IN is set to ON (page 39).)

Turns off the Source Select screen, and returns to

previous source screen.

Changes to the Rear selection screen when “Setting the

Picture/Sound Output” (page 41) is set to ON.

Returns to the previous screen.

•The kind of source modes that are displayed varies depending on

connection and setting

Touch [Radio].

The radio mode is activated and the display changes to the

Radio Mode screen.

TOUCH PANEL operation

Onscreen buttons are expressed as follows in this Owner’s

Manual.

•Onscreen buttons are shown in bold, enclosed in [ ] (e.g.

[BAND]).

Recalling the Source

14-EN

Display example for FM Radio main screen

Displays the source name, such as radio band, etc.,

that is selected.

Displays the time, BLUETOOTH indicator, etc.

Function Guide:

The function guide display varies depending on each

source.

The contents of the function guide change by touching

[P1/2]* or [P1/3]* on the function guide, and many other

operations can be performed.

Displays the image of current source.

* Display may vary depending on the connected devices.

Press SOURCE/ to change to another source

screen, and select the desired source from the

SOURCE selection screen.

•The screen can be changed to the SETUP selection screen by

touching [].

The numeric keypad input screen is displayed when the DVD or CD

mode, etc. is selected for searching a title, chapter or track, etc.

Touch [10KEY] on the main source screen.

Touch the desired numeric key.

Display example for numeric keypad (DVD mode)

Change select mode (File/Chapter, etc.) or quit numeric

keypad input screen.

Input screen area.

Numeric keypad.

Input number is confirmed.

The numeric keypad input screen closes if the area is

touched while being displayed.

Close numeric keypad input screen.

All input numbers will be deleted.

Touch [Enter] to confirm your entry.

Displaying the Numeric Keypad Input

Screen

15-EN

Display example for FM Radio main screen

Displays the preset number/frequency

[DX SEEK]*1 button: Displays the tuning mode selection

list.

[PTY SEARCH]*2 button: Search for a station by PTY

(Programme Type) Tuning, refer to “PTY (Programme

Type) Tuning” (page 16).

*1 The button displays the current tuning mode.

*2 The button displays only when the tuning mode of PTY is selected.

Listening to the Radio

Press SOURCE/ .

The SOURCE selection screen is displayed.

Touch [Radio].

The radio mode is activated and the display changes to the

Radio Mode screen.

Touch [BAND] to select the desired radio band.

Each press changes the bands as follows:

Touch [DX SEEK] to choose the tuning mode.

•There are two modes you can select for auto tuning, DX and Local:

-DX (Distance) mode;

Both strong and weak stations will be tuned in.

-Local mode;

Only strong stations will be tuned in.

The initial setting is DX.

Touch [ ], [ ] or [ ], [ ] to change the

radio frequency up or down respectively.

When touched and held in the manual mode, the frequency

changes continuously.

Presetting Stations Manually

Tune in a desired radio station you wish to store in

the preset memory by manual or automatic seek

tuning.

Touch [P1/2] to change the function guide.

Touch and hold any one of the preset buttons

[P.SET 1] through [P.SET 6] for at least 2 seconds.

The selected station is stored.

Repeat the procedure to store up to 5 other stations

onto the same band.

To use this procedure for other bands, simply select the

band desired and repeat the procedure.

A total of 30 stations can be stored in the preset memory (6

stations for each band; FM1, FM2, FM3, MW and LW).

•If a preset memory has already been set in the same preset number, it

will be cleared and the new station will be memorized.

Presetting Stations Automatically

The tuner can automatically seek and store 6 strong stations in the

selected band in order of signal strength.

After selecting the desired band, touch and hold

[A.MEMO] for at least 2 seconds.

The tuner automatically seeks and stores 6 strong stations into

[P.SET 1] to [P.SET 6] in order of signal strength.

When the automatic storing has been completed, the tuner goes

to the station stored in [P.SET 1].

•If no stations are stored, the tuner will return to the original station

you were listening to before the automatic storing procedure began.

Tuning to Preset Stations

You can tune in the preset stations in memory on each band using the

preset number.

After selecting the desired band, touch [P1/2] to

change the function guide.

Touch any one of the preset buttons [P.SET 1]

through [P.SET 6] that has a station stored to it.

The preset station is received.

Radio

FM-1 FM-2 FM-3 MW LW FM-1

DX SEEK Local SEEK MANUAL PTY

16-EN

Turning AF (Alternative Frequencies) On

or Off

The RDS (Radio Data System) is a radio information system using the

57 kHz subcarrier of regular FM broadcast. The RDS allows you to

receive a variety of information such as traffic information, station

names, and to automatically re-tune to a stronger transmitter that is

broadcasting the same programme.

Touch [ ] on the main screen.

The SETUP selection screen is displayed.

Touch the title bar of Source Setup.

The Source Setup screen appears.

Touch the title bar of RDS Setup.

The RDS Setup screen appears.

Touch [AF] to select the AF (Alternative Frequency)

ON or OFF mode.

•RDS SETUP mode will not be displayed when the band of radio is set

to MW or LW.

•When the AF ON mode is selected, the unit automatically tunes to a

strong signal station in the AF list.

•Use the AF OFF mode when automatic re-tuning is not required.

Touch [ ] to return to the previous screen.

•Touching [Exit] will turn off the Setup screen, and return to previous

main screen.

Tips

•If the unit receives the PTY31 (Emergency Broadcast) signal, the unit

will show “Alarm” in the display only when PTY31 is set to on. For

operation, refer to “Setting PTY31 (Emergency Broadcast)

Reception” (page 33).

•The RDS digital data includes the following:

•Refer to page 33 about “PI Seek Setting”, “Receiving RDS Regional

(Local) Stations”, “Switching the Display Language of PTY

(Programme Type)” and “Setting PTY31 (Emergency Broadcast)

Reception”.

Receiving Traffic Information

Press and hold Rotary encoder (TA) for at least 2

seconds to turn on the Traffic Information mode.

When the traffic information station is tuned in, the TA indicator

lights up.

Traffic information is heard only when it is being broadcast. If

traffic information is not being broadcast, the unit is set in the

standby mode.

When a traffic information broadcast begins, the unit

automatically receives it and the display shows “T. Info”.

When traffic information broadcast is over, the unit will

automatically set in the standby mode.

•If the traffic information broadcast signal falls below a certain level,

the unit remains in the receiving mode for 1 minute. If the signal

remains below a certain level for over 70 seconds, “TA” blinks in the

display.

•If you do not want to listen to the traffic information being received,

lightly press SOURCE/ or touch []/[PTY]/[NEWS]/[ ]/

[]/[V.Sel] to skip that traffic information message. The T. INFO

mode will remain in the ON position to receive the next traffic

information message.

•If the volume level is changed while receiving traffic information, the

changed volume level will be memorized. When traffic information is

received next time, the volume level will be automatically adjusted to

the level memorized.

PTY (Programme Type) Tuning

RDS SETUP mode

Touch [PTY] on the screen.

FM Radio mode

Touch [DX SEEK]* to choose the PTY tuning mode.

The PTY mode is activated.

The Programme Type of the station being currently received

will be displayed.

Touch [ ] or [ ] after activating the PTY mode to

choose the desired programme type while “PTY”

(programme type) is displayed.

Each press scrolls the programme type by one.

RDS Operation

PI Programme Identification

PS Programme Service Name

AF List of Alternative Frequencies

TP Traffic Programme

TA Traffic Announcement

PTY Programme Type

EON Enhanced Other Networks

17-EN

RDS SETUP mode

Touch [PTY] after selecting the programme type to

start searching for a station of the selected

programme type.

FM Radio mode

Touch [PTY SEARCH] after selecting the

programme type to start searching for a station of

the selected programme type.

If no station is found, “NO PTY” will be displayed.

* The button displays the current tuning mode.

Receiving Traffic Information While

Playing CD or Radio

The example explained here is how to receive the traffic information

broadcast during CD playback.

In the CD mode, press and hold Rotary encoder

(TA) for at least 2 seconds to turn on the Traffic

information mode.

The unit automatically starts to search the receivable traffic

broadcasts.

When the traffic information broadcast is searched out, the

CD mode is switched to the Radio mode and the unit

receives the traffic information broadcast.

•When the traffic information broadcast starts, the unit

automatically mutes the CD.

•When the traffic information broadcast finishes, the unit

automatically returns to the original source you were

playing before the traffic information broadcast began.

•The receiver is equipped with the EON (Enhanced Other Networks)

function so if the station being received does not broadcast the traffic

information, the receiver automatically tunes in the related station

that broadcasts the traffic information.

When the traffic information broadcast has finished,

the unit returns to the CD mode.

Priority News

This function allows you to preset to give priority to the News

programme. You will never miss the News programme as the unit

automatically gives priority to the News programme whenever it begins

broadcasting, and interrupts the programme you are currently listening.

This feature is functional when your unit is set to a mode other than the

LW and MW modes.

Touch [NEWS] to activate the PRIORITY NEWS

mode.

The “NEWS” indicator appears in the display. Touch

[NEWS] again to deactivate the Priority News mode and

return to the programme you were previously listening.

Touch [ ] to return to the previous screen.

Displaying Radio Text

Text messages from a radio station can be displayed.

Tune in a radio station that transmits text messages.

Touch [INFO.] in the FM radio mode to activate the

Radio Text mode.

The display shows “WAIT” for a few seconds.

To change the Radio Text display, touch [INFO.].

•If there is no receivable text message or the unit cannot receive a text

message properly, the display shows “NO TEXT”.

18-EN

Display example for MP3/WMA/AAC main screen

[ ] button: Refer to page 29

CD:

Displays the Track text*/Disc text*.

•If there is neither Track nor Disc name information, “NO TEXT” will

be displayed.

MP3/WMA/AAC:

After displaying the file name in the upper line, the track

name is displayed if there is ID3 tag information.

After displaying the folder name in the lower line, the album

name/artist name are displayed if there is ID3 tag

information.

CD:

Displays play state/track number/progress bar/elapsed

time/remain time.

MP3/WMA/AAC:

Displays play state/folder number/track number/progress

bar/elapsed playback time/remain time.

* Displayed when a CD text disc is inserted.

Playback

Press SOURCE/ .

The SOURCE selection screen is displayed.

Touch [Disc].

The display shows the Disc screen.

When a CD/MP3/WMA/AAC is inserted into the DISC SLOT

of the IVE-W530BT, with the label side facing up, the unit

starts to play the CD/MP3/WMA/AAC.

Touch [ ] or [ ] to select the desired track

(file).

Returning to the beginning of the current track (file):

Touch [ ].

Fast reverse:

Touch and hold [ ].

Advancing to the beginning of the next track (file):

Touch [ ].

Fast forward:

Touch and hold [ ].

To pause playback

Touch [ / ].

Touching [ / ] again will resume playback.

To eject the disc

Press .

•If the disc does not eject, press and hold for at least 3 seconds.

•The IVE-W530BT model include a built-in MP3/WMA/AAC unit. You

can play CD-ROMs, CD-Rs, and CD-RWs containing MP3/WMA/

AAC files on this unit. Use the format compliant with this unit.

For further information about playing or storing MP3/WMA/AAC

files, refer to pages 19 and 20 before using the unit.

•Any file protected by DRM (Digital Rights Management) copy

protection, cannot be played back on this unit.

•The unit can play discs containing both audio data and MP3/WMA/

AAC data.

•The track display for CD audio data playback is the track numbers

recorded on the disc.

•Three-inch (8cm) CD’s cannot be used.

•If an MP3/WMA/AAC disc with many files and folders is played, it

takes a little longer than normal to start playback.

•Touch [ ] to activate the search mode. For operations, refer to

“Search Function” on page 29.

•Touch [10KEY] to activate direct search mode. For operations, refer

to “Numeric Keypad Input Operation” on page 23.

•The playback time may not be correctly displayed when a VBR

(Variable Bit Rate) recorded file is played back.

•If the disc is left in the unit after pressing , the disc is

automatically pulled back into the unit and paused. In this case, start

playback by touching [/ ] or eject again and remove the disc

within 15 seconds.

Repeat Play

Touch [ ] to play back repeatedly the track currently

being played.

The track (file) will be played repeatedly.

Touch [ ] again and select OFF to deactivate Repeat play.

1 Touch [P1/2]*1 to change the function guide.

2 Touch [ ] and select the desired Repeat play.

*1Display may vary depending on the connected devices.

*2Only files in a folder are repeatedly played back.

CD/MP3/WMA/AAC

CD: (off)

(Repeat one)

MP3/WMA/AAC:

*2 (off)

(Repeat one)

(Repeat folder)

19-EN

M.I.X. (Random Play)

Touch [ ] during playback.

The tracks (files) on the disc will be played back in a random

sequence.

To cancel M.I.X. play, touch [ ].

1 Touch [P1/2]*1 to change the function guide.

2 Touch [ ] and select the desired M.I.X. play.

*1Display may vary depending on the connected devices.

*2Only files in a folder are played back in random sequence in the

M.I.X. Folder mode.

*3All files in a disc are played back in random sequence.

•If the search mode (page 29) is activated, the M.I.X. Play mode will

be cancelled.

Selecting Folders (concerning MP3/

WMA/AAC)

Touch [ ] or [ ] to select the folder.

About MP3/WMA/AAC

What is MP3?

MP3, whose official name is “MPEG Audio Layer 3,” is a

compression standard prescribed by the ISO, the International

Standardization Organization and MPEG which is a joint activity

institution of the IEC.

MP3 files contain compressed audio data. MP3 encoding is

capable of compressing audio data at extremely high ratios,

reducing the size of music files to as much as one-tenth

their original size. This is achieved while still maintaining

near CD quality. The MP3 format realises such high

compression ratios by eliminating the sounds that are either

inaudible to the human ear or masked by other sounds.

What is WMA?

WMA, or “Windows Media™ Audio,” is compressed audio data.

WMA is similar to MP3 audio data.

What is AAC?

AAC is the abbreviation for “Advanced Audio Coding,” and is a

basic format of audio compression used by MPEG2 or MPEG4.

Method for creating MP3/WMA/AAC files

Audio data is compressed using software with MP3/WMA/AAC

codecs. For details on creating MP3/WMA/AAC files, refer to the

user’s manual for that software.

MP3/WMA/AAC files that can be played back by this device

have the following file extensions:

MP3: “mp3”

WMA: “wma” (ver. 2, 8, 9 are supported)

AAC: “m4a”, “mp4”

WMA is not supported for the following files, Windows Media

Audio Professional or Windows Media Audio 9 Pro Lossless.

There are many different versions of the AAC format. Confirm

that the software being used conforms to the acceptable

formats listed above. It’s possible that the format may be

unplayable even though the extension is valid. Playback of AAC

files encoded by iTunes is supported.

Supported playback sampling rates and bit rates

MP3

WMA

AAC

This device may not play back correctly depending on sampling

rates.

ID3 tags/WMA tags

This device supports ID3 tag v1 and v2, and WMA tag.

If tag data is in an MP3/WMA/AAC file, this device can display

the title (track title), artist name, and album name ID3 tag/WMA

tag data (maximum 64 characters).

This device can only display single-byte alphanumeric

characters and the underscore. For non-supported characters,

“No Support” is displayed.

The number of characters may be limited, or not correctly

displayed, depending on the tag information.

CD: (off)

MP3/WMA/AAC:

*2 *3 (off) *2

CAUTION

Except for private use, duplicating audio data (including MP3/

WMA/AAC data) or distributing, transferring, or copying it,

whether for free or for a fee, without permission of the copyright

holder is strictly prohibited by the Copyright Act and by

international treaty.

Sampling rates: 48 kHz, 44.1 kHz, 32 kHz, 24 kHz, 22.05 kHz,

16 kHz, 12 kHz, 11.025 kHz, 8 kHz

Bit rates: 32 - 320 kbps

Sampling rates: 48 kHz, 44.1 kHz, 32 kHz

Bit rates: 48 - 320 kbps

Sampling rates: 48 kHz, 44.1 kHz, 32 kHz

Bit rates: 32 - 192 kbps

20-EN

Producing MP3/WMA/AAC discs

MP3/WMA/AAC files are prepared, then written to a CD-R or

CD-RW (DVD-R/DVD-RW) using CD-R writing software. A disc

can hold up to 1,000 files/255 folders (including Root Folders),

and the maximum number of folders is 255.

Playback may not be performed if a disc exceeds the limitations

described above.

Media supported

The media that this device can play back are CD-ROMs, CD-Rs,

CD-RWs, DVD-Rs and DVD-RWs.

Corresponding File Systems

This device supports discs formatted with ISO9660 Level 1 or

Level 2.

Under the ISO9660 standard, there are some restrictions to

remember.

The maximum nested folder depth is 8 (including the root

directory). The number of characters for a folder/file name is

limited.

Valid characters for folder/file names are letters A-Z (all caps),

numbers 0-9, and ‘_’ (underscore).

This device also can play back discs in Joliet, etc., and other

standards that conform to ISO9660. However, sometimes the file

names, folder names, etc., are not displayed correctly.

Formats supported

This device can read CD-DA sector from Mixed Mode CD or

Enhanced CD (CD-Extra).

This device cannot correctly play back discs recorded with

Track At Once or packet writing.

Order of files

Files are played back in the order that the writing software writes

them to the disc. Therefore, the playback order may not be

what’s expected. Verify the writing order in the software’s

documentation. The playback order of the folders and files is as

follows. (The following numbers may differ from actually

displayed numbers.)

Terminology

Bit rate

This is the “sound” compression rate specified for encoding. The

higher the bit rate, the higher the sound quality, but also the larger

the files.

Sampling rate

This value shows how many times per second the data is sampled

(recorded). For example, music CDs use a sampling rate of 44.1 kHz,

so the sound is sampled (recorded) 44,100 times per second. The

higher the sampling rate, the higher the sound quality, but also the

larger the volume of data.

Encoding

Converting music CDs, WAVE (AIFF) files, and other sound files into

the specified audio compression format.

Tag

Song information such as track titles, artist names, album names,

etc., written into MP3/WMA/AAC files.

Root folder

The root folder (or root directory) is found at the top of the file

system. The root folder contains all folders and files. It is created

automatically for all burned discs.

Root

Folder

Folder MP3/WMA/AAC File

21-EN

Display example for DVD Video main screen

[ ] button: Changes to Navigation screen.

[ ] button: Displays the SETUP selection screen.

[ ] button: Changes to full screen.

Displays the disc (DVD VIDEO) being played back.

Displays tag information for DivX®.

•If [ ] on the DivX® mode screen is touched, the search list screen

is displayed. Refer to “Search Function” (page 29).

•Some operations cannot be carried out depending on the disc or

playback screen.

•Displays of the function guide [P1/2], etc., may vary depending on

the connected device(s).

Disc types that can be used for each heading are

represented by the following marks.

Playing a Disc

IVE-W530BT has a built-in DVD player. When an optional Alpine

DVD/CD player is connected to the IVE-W530BT, you can control it

from the IVE-W530BT (except some operations).

•If you try to activate the auxiliary device while driving, the display

will show the warning-Picture off for your safety.

DVD

DVD Commercial Video discs (used for the

distribution of movies, etc.) or a DVD-R/DVD-

RW, DVD+R/DVD+RW recorded in a video

mode can be used.

CD-R/CD-RW/DVD-R/DVD-RW/DVD+R/

DVD+RW discs and USB memory that are

recorded in the DivX® mode can be used.

WARNING

It is dangerous for the driver to watch the TV/DVD/

Video while driving the vehicle. The driver may be

distracted from looking ahead and an accident could

occur.

Install the IVE-W530BT correctly so that the driver

cannot watch TV/DVD/Video unless the vehicle is

stopped and the emergency brake is applied.

If the IVE-W530BT is not installed correctly, the driver

will be able to watch the TV/DVD/Video while driving

the vehicle and may be distracted from looking ahead

causing an accident. The driver or other people could

be severely injured.

To display the DVD mode screen

Caution

• Not all functions will operate for every DVD. See the

individual DVD’s instructions for details on the

features supported.

• Fingerprints on a disc may adversely affect

playback. If a problem occurs, remove the disc and

check for fingerprints on the playback side. Clean

the disc if necessary.

• If you switch the power or Ignition Key OFF or

change sources during playback, playback will

continue where you left off when you resume

playback.

• If you try to perform an invalid operation (based on

the type of disc being played), the following mark is

displayed on the monitor screen:

• Play Position Memory Function

Even if you turn power off or switch the Ignition Key

to OFF during playback or change the source,

playback will continue from the point where

playback stopped when the power is turned ON

again.

22-EN

Press SOURCE/ .

The SOURCE selection screen is displayed.

Touch [Disc]*.

The display shows the Disc screen.

Insert a disc with the label side facing up. The unit starts to

play the disc.

When an optical Alpine DVD player is connected, insert a

disc into the DVD/CD player, and the player starts playing.

* When you want to play a DivX file from a USB device, touch [USB].

•The operation screen changes to the visual screen in the DVD mode

for 5 seconds after an operation has been performed. Touch the

display panel to display the operation screen again.

•The display mode can be changed by touching [WIDE].

For operation, see “Switching Display Modes” on page 30.

To eject the disc

Press .

•The reverse side of a double-sided DVD will not be played

automatically.

Remove the disc, turn it over, and reinsert it.

•If the disc does not eject, press and hold for at least 3 seconds.

•Do not insert discs containing maps for the navigation system. Doing

so could result in damage.

•Be sure that the remote input lead is connected to the remote output

lead of this unit when a DVD player is connected. If not correctly

connected, touching operation cannot be performed.

•Refer also to “DVD Setup” (pages 31 to 32).

•If the disc is left in the unit after pressing , the disc is

automatically pulled back into the unit and stopped. In this case,

start playback by touching [/ ] or eject again and remove the

disc within 15 seconds.

•While “Index reading” is displayed by DivX®, the fast-forwarding/

fast-reversing and repeat functions, etc. cannot be used.

On DVDs, menu screens may appear automatically. If this happens,

perform the operation described below to start playback.

Direct Menu Operations

1 Touch the DVD menu directly.

Menu Operations

1 Touch screen to display the operation keys.

2 Touch [Key].

The menu operation mode will be displayed.

3 Select a desired menu item by touching [ ], [ ], [ ] or [ ].

4 Touch [Enter] to confirm the selected item.

Numeric Keypad Input Operations

1 Touch screen to display the operation keys.

2 Touch [Key].

The menu operation mode appears.

3 Touch [Key] again.

The numeric keypad input mode screen appears.

4 Touch a desired number.

5 Touch [Enter] on the numeric keypad mode screen to confirm

your selection.

If a menu screen appears

•Some operations cannot be performed depending on the disc.

Touch [] to return to the previous display.

(Operation may not be possible, depending on the disc.)

The numeric keypad input screen closes when

the area is touched while being displayed.

Touch [] to close the

numeric keypad input screen.

23-EN

When a DVD contains two or more titles, the top menu screen appears.

Touch [TOP MENU] on the DVD mode main screen.

The top menu screen appears.

•To perform necessary operations, see “If a menu screen appears” on

page 22.

With a DVD having two or more menus, a menu screen will appear for

the programmes available, in addition to the main programmes.

Touch [MENU] on the DVD mode main screen.

The menu screen appears.

•To perform necessary operations, see “If a menu screen appears” on

page 22.

Touch [P1/2]* on the DVD mode main screen.

The function guide changes.

* The display differs, depending on the disc (mode).

Touch [MENU CONT].

The menu operation mode screen appears.

•For further operation, see “If a menu screen appears” on page 22.

Numeric Keypad Input Operation

You can quickly find the desired track/file or folder by inputting its’

track/file or folder Number in this mode.

Touch [P1/2]* in the CD/MP3/WMA/AAC/DVD (except

stop) mode to change to the function guide.

* The display differs, depending on the source (mode).

Touch [10KEY].

The numeric keypad input mode screen appears.

Touch and input a desired number.

Touch [Enter] to confirm.

The selected Track/File/Chapter is selected.

•For CD, during Track select mode, touch [ ], etc. to quit.

•For MP3/WMA/AAC/DVD, during File/Chapter select mode, touch

[] again to change to Folder/Title select mode.

Touch [P1/2]* in the MP3/WMA/AAC/DVD stop mode

to change to the function guide.

* The display differs, depending on the source (mode).

Touch [10KEY].

The numeric keypad input mode screen appears.

Touch and input a desired number.

Touch [Enter] to confirm.

The first file/chapter in the selected Folder/Title begins to

play back.

•During File/Chapter select mode, touch [ ] again to change to

Folder/Title select mode.

•During Folder/Title select mode, touch [ ], etc. to quit.

Displaying the Top Menu Screen

Displaying the Menu Screen

Displaying the Menu Operation Mode

Screen

Select a Track/File/Chapter

Select a Folder/Title

24-EN

Stopping Playback (Pre Stop)

Press the stop button during playback to stop playback. That position is

stored in the memory.

Touch [ ] once during playback.

“Pre Stop” is displayed.

Touch [ / ] in the Pre Stop mode.

Playback starts from the position at which it was stopped.

•For some discs, the position at which playback was stopped may not

be accurate.

Stopping Playback

Touch [ ] twice during playback.

“Stop” is displayed, and playback stops.

•Playback starts from the beginning when [/] is touched while

playback is stopped.

Fast-forwarding/Fast-reversing

DVD-Video, DivX®:

During playback, touch and hold [ ] (Fast-

reverse) or [ ] (fast-forward).

When touched and held for more than 0.5 second, the disc

is forwarded/reversed at double speed. When held for 5

more seconds or longer, the disc is forwarded/reversed at

10 times the normal speed. When held for 10 seconds or

longer, the disc is forwarded/reversed at 20 times the

normal speed.

Stop touching [ ] or [ ] to return to normal

playback.

•No sound is played during fast-forwarding/fast-reversing.

•For DVDs, the menu screen may reappear during fast-forwarding/

fast-reversing.

•Operation may not be possible, depending on the disc.

Finding the Beginnings of Chapters/Files

During playback, touch [ ] or [ ].

The chapter/track/file switches each time the button is touched,

and playback of the selected chapter/track/file starts.

•Some DVDs do not have chapters.

Playing Still Frames (Pausing)

During playback, touch [ / ].

Touch [ / ] to resume playback.

•No sound is played during the still frame mode.

•The image or sound may stop temporarily when playback starts from

the pause mode. This is not a malfunction.

Slow Motion Playback

When [ ] is touched and held while in the pause

mode, the 1/3th speed slow motion playback mode is

set.

Stop touching [ ] to pause, and touch [ / ] to

play back.

•No sound is played during slow motion playback.

•1/3 is approximate speeds. The actual speed differs from disc to disc.

:Touch this to start playback from the beginning of the

following chapter, track or file.

:Touch this to start playback from the beginning of the

current chapter, track or file.

Supplementary explanation

“Chapters” are divisions of movies or musical selections on

DVDs.

“Tracks” are divisions of musical selections on music CDs.

25-EN

Selecting Folders

Touch [ ] or [ ] to select the folder.

Repeat Playback

Use this function to play the disc’s chapters, tracks etc., repeatedly.

DVD Video

Touch [ ].

The repeat mode switches every time the button is touched.

•Display may vary depending on the connected devices.

DivX®

Touch [] after touching [P1/2]*.

The repeat mode switches every time the button is touched.

* Touch [P1/3] while playing a DivX from USB Flash Memory.

•The REPEAT mode is always turned off when [ ] is touched and

held for at least 2 seconds.

Searching by Title/Folder Number

Use this function to easily find positions on the DVD using the DVD’s

titles.

Touch [P1/2]*1/*2 while playback is stopped.

The function guide appears.

*1The display differs, depending on the disc (mode).

*2Touch [P1/3] while playing a DivX from USB Flash Memory.

Touch [10KEY].

The numeric keypad input mode screen appears.

Enter a desired title by touching its title number.

See page 22 for operation of the numeric keypad.

Confirm your selection by touching [Enter].

Playback will start from the title number selected.

•This function cannot be used on discs on which no title numbers are

recorded.

•Playback starts from the beginning of the chapter/track number in the

state of Pre Stop.

•Some disc may not accept any operation.

Searching Directly by Chapter, File

Number

Use this function to easily move to the beginnings of the chapters or

files on the disc.

Touch [P1/2]*1/*2 in any mode other than stop mode.

The function guide will appear.

*1The display differs, depending on the disc (mode).

*2Touch [P1/3] while playing a DivX from USB Flash Memory.

Touch [10KEY].

The numeric keypad input mode screen appears.

Touch and enter the chapter or track number you

want to play.

See page 22 for operation of the numeric keypad.

Touch [Enter] to confirm your selection.

Playback will start from the selected chapter or track.

•This function is not available for a disc on which chapters or tracks

are not stored.

The chapter is played repeatedly.

The playback returns to normal mode.

The file is played repeatedly.

The disc is played repeatedly.

The folder is played repeatedly.

26-EN

Switching the Angle

On DVDs in which scenes have been filmed from multiple angles, the

angle can be switched during playback.

During playback, touch [P1/2]*.

The function guide changes.

* The display differs, depending on the disc (mode).

Touch [ANGLE].

The angle switches between the angles recorded on the

disc every time the button is touched.

•Some time may be required for the angle to change.

•Depending on the disc, the angle may switch in one of two ways.

-Seamless: The angle switches smoothly.

-Non-seamless: When the angle is switched, a still picture is displayed

first, after which the angle switches.

Switching the Audio Tracks

DVDs with multiplex audio or audio languages allow switching the

sound during playback.

During playback, touch [P1/2]*1/*2.

*1The display differs, depending on the disc (mode).

*2Touch [P2/3] while playing a DivX from USB Flash Memory.

Touch [AUDIO].

The sound switches between the alternate audio tracks

recorded on the disc every time the button is touched.

•The alternate track selected becomes the default setting every time

the power is turned on or the disc is replaced. If the disc does not

include that track, the disc’s default language is selected instead.

•Not all discs will allow changing the alternate audio tracks during

playback. In these cases, select audio tracks from the DVDs menu.

•There may be a delay before the selected alternate track begins to

play.

Switching the Subtitles (Subtitle

Language)

With DVDs on which multiple subtitle languages are recorded, the

subtitle language can be switched during playback; moreover, subtitles

can be hidden.

During playback, touch [P1/2]*1/*2.

The function guide changes.

*1The display differs, depending on the disc (mode).

*2Touch [P2/3] while playing a DivX from USB Flash Memory.

Touch [SUBT.].

Touching this button repeatedly selects sequentially the

subtitle languages recorded on the disc, and then turns the

subtitles OFF.

•There may be a delay before the selected subtitle appears.

•Not all discs will allow changing the subtitles during playback. In

these cases, select subtitles from the DVDs menu.

•The subtitle language selected becomes the default setting every time

the power is turned on or the disc is replaced. If the disc does not

include that language, the disc’s default language is selected instead.

However, the subtitle language may differ depending on the disc.

•For some discs, the subtitles will be displayed even when this is set to

OFF. However, the subtitle language may differ depending on the

disc.

Switching from the disc menu

For some discs, the audio language, angle and subtitles can be switched

from the disc menu.

Touch [MENU] or [TOP MENU] to display the

menu.

Select an item to confirm it.

See “If a menu screen appears” on page 22.

27-EN

About DivX

DivX® is a codec (software) programme to compress moving images

while maintaining image quality using a highly advanced encoding.

• Official DivX® Certified product

• Plays all versions of DivX® video (including DivX® 5) with

standard playback of DivX® media files

• DivX®, DivX Certified® and associated logos are trademarks of

Rovi Corporation or its subsidiaries and are used under license.

DivX Certified® to play DivX® video, including premium

content.

The unit can play back CD-R/CD-RW/DVD-R/DVD-RW/DVD+R/

DVD+RW discs and USB Flash Memory that are recorded in the

DivX® mode with extension “avi”, “divx” or “div”.

The optimum size for DivX® disc playback is as follows:

With an aspect ratio other than 16:9, black bars may be

displayed on the left and right sides, or at the top and bottom of

the screen.

The following audio recording systems are supported:

ABOUT DIVX VIDEO:

DivX® is a digital video format created by DivX, LLC, a

subsidiary of Rovi Corporation. This is an official DivX Certified®

device that plays DivX video. Visit divx.com for more information

and software tools to convert your files into DivX videos.

ABOUT DIVX VIDEO-ON-DEMAND:

This DivX Certified® device must be registered in order to play

purchased DivX Video-on-Demand (VOD) movies. To obtain

your registration code, locate the DivX VOD section in your

device setup menu. Go to vod.divx.com for more information on

how to complete your registration.

Adjusting the Audio

Touch [] on the main screen.

The SETUP selection screen is displayed.

Touch the title bar of Audio Setup.

The Audio Setup screen appears.

Display Example for Audio Adjustment Screen

•Touching [] will return to the previous display.

•Scroll the list one line at a time by touching [] or [] .

•Scroll the list one page at a time by touching [] or [].

Setting the Bass Control

You can change the Bass Frequency emphasis to create your

own tonal preference. Touch the title bar of Bass to display the

Bass adjusting screen.

•Adjustment cannot be performed when Defeat is set to ON.

Setting the Bass level

You can emphasise or weaken the bass frequency.

Touch [ ] or [ ] of Level to select the desired bass level.

Setting range: -7 to +7

Screen Size: 32 to 720 pixel (horizontal) × 32 to 576 pixel

(vertical)

Image bit rate: “Peak 8 Mbps” Home Theatre Profile

supported

MPEG1 Layer III 32 to 320 kbps

MPEG2 Layer III 8 to 160 kbps

MPEG2.5 Layer III 8 to 160 kbps

Other Useful

Features

28-EN

Setting the Bass Centre Frequency

The displayed bass frequency is emphasised.

Touch [ ] or [ ] of Freq. to select the desired bass centre

frequency.

Setting range: 60 Hz, 80 Hz, 100 Hz, 200 Hz

Setting the Bass Bandwidth

Changes the boosted bass bandwidth to wide or narrow.

A wider setting will boost a wide range of frequencies above and

below the centre frequency. A narrower setting will boost only

frequencies near the centre frequency.

Touch [ ] or [ ] of Q to select the desired bass band width.

Setting range: 1, 1.25, 1.5, 2

•The bass level settings will be individually memorised for each

source (FM, MW, LW, CD, etc.) until the setting is changed. The bass

frequency and bass band width settings adjusted for one source are

effective for all other sources (FM, MW, LW, CD, etc.).

•The function is inoperable when Defeat is set to ON.

Setting the Treble Control

You can change the Treble Frequency emphasis to create your

own tonal preference.

Touch the title bar of Treble to display the Treble adjusting

screen.

•Adjustment cannot be performed when Defeat is set to ON.

Setting the Treble level

You can emphasise the treble frequency.

Touch [ ] or [ ] of Level to select the desired treble level.

Setting range: -7 to +7

Setting the Treble Centre Frequency

The displayed treble frequency is emphasised.

Touch [ ] or [ ] of Freq. to select the desired treble centre

frequency.

Setting range:10 kHz, 12.5 kHz, 15 kHz, 17.5 kHz

•The treble level settings will be individually memorised for each

source (FM, MW, LW, CD, etc.) until the setting is changed. The

Treble frequency settings adjusted for one source are effective for all

other sources (FM, MW, LW, CD, etc.).

•The function is inoperable when Defeat is set to ON.

Adjusting Balance/Fader

Touch the title bar of Balance/Fader.

The display changes to the Balance/Fader adjusting screen.

Display Example for Balance/Fader Screen

Adjusting the Fader

Touch [F] or [R] to adjust the volume of the front and

rear speakers.

Setting range: F15 to R15

Adjusting the Balance

Touch [L] or [R] to adjust the sound volume of the left

and right speakers.

Setting range: L15 to R15

Adjusting the Balance/Fader Directly

Touch and move [ ] to a desired setting.

Or touch a desired setting range, and [ ] will move to that

location.

Touch [L] or [R] of Balance and [F] or [R] of Fader for fine-tuning.

Subwoofer On and Off

Touch [ ] or [ ] of Subwoofer to set to ON or OFF.

OFF: Subwoofer output is off.

ON: Subwoofer output is on.

29-EN

Adjusting the Subwoofer Level

When ON is set in “Subwoofer On and Off ”, the item can be

adjusted.

1 Touch the title bar of Subwoofer.

The display changes to the Subwoofer Adjusting screen.

2 Touch [ ] or [ ] of Level to adjust the subwoofer output.

Setting range: 0 to 15

Setting the Subwoofer System

When ON is set in “Subwoofer On and Off”, the item can be

adjusted.

1 Touch the title bar of Subwoofer.

The display changes to the Subwoofer Adjusting screen.

2 Touch [ ] or [ ] of System to select to System 1 or System 2.

System 1: Subwoofer level changes according to the main

volume setting.

System 2: Subwoofer level change is different from the main

volume setting. For example, even at low volume

settings, the subwoofer is still audible.

Adjusting Nav. Mix Level

Touch [ ] or [ ] of Nav. Mix Level to adjust the volume of

navigation interruption.

Setting range: 0 to 15

•This adjustment becomes available when Nav. Mix is turned ON in

“Setting the Navigation Interruption” (page 40).

•Adjustment cannot be performed when Defeat is set to ON.

Adjusting Highpass Filter

When Defeat is set to OFF, touch the title bar of H.P.F. to adjust

screen.

Touch [ ] or [ ] of Front H.P.F. to adjust the front speaker.

Setting range: OFF, 60 Hz, 80 Hz, 100 Hz

Touch [ ] or [ ] of Rear H.P.F. to adjust the rear speaker.

Setting range: OFF, 60 Hz, 80 Hz, 100 Hz

•Select OFF when no adjustment is required.

Turning Defeat ON or OFF

Touch [ ] or [ ] of Defeat to set to ON or OFF.

Search Function

Touch [ ] on the function guide while in the CD or

MP3/WMA/AAC or DivX® mode.

The search list screen is displayed.

Select a desired track or folder

Touch [ ] for direct playback.

When a hierarchical list is prepared, will be displayed.

Touch the title bar to display the respective hierarchy list

screens.

Display Example for Search Screen

Select directly by touching [ ], and its track (or

folder/file) is played back.

is displayed if there is a hierarchical list.

Scroll the list one line at a time by touching [ ] or [ ].

Scroll the list one page at a time by touching [ ] or [ ].

Touch [ ] to return to the previous list screen.

Touching [Exit] will turn off the search screen, and return

to previous main screen.

Internal CD player mode

1 The track list* screen appears.

2 Touch [ ] of a desired track text*.

The selected track will be played back.

* If the CD is text compatible only.

Internal MP3/WMA/AAC/DivX® Player mode

1 The folder list screen appears.

Select a desired folder and then touch the title bar.

( appears only when a file is present in the selected

folder.)

The file list screen is displayed.

2 Touch [ ] of a desired file name.

The selected file will be played back.

Rear Selection Function

The rear entertainment function independently routes different sources

to the front and the rear inside a car. For example, while listening to the

radio or other audio source in the front, DVD can be enjoyed in the rear

with the optional rear monitor and headphones.

Press SOURCE/ .

The SOURCE selection screen is displayed.

•“TRACK” is displayed in the track text list if there is no text on the

disc.

•Touch [ ] to play back the folder directly.

30-EN

Touch [Rear].

The Rear selection screen appears.

•This function cannot be used when “Setting the Picture/Sound

Output” (page 41) is set to OFF in the System Setup.

•If [Main] on the Rear Select screen is touched, the screen changes to

the main source screen.

Touch the desired source such as visual (auxiliary

input, built-in DVD, etc.) to select.

•Tou ch [Off] to cancel the rear entertainment function.

•When the AUX1 IN is set to OFF and AUX2 IN is set to iPod Video,

the AUX source is not displayed. Refer to “Setting the AUX Mode”

(page 40).

•Some sources such as DVB-T (TUE-T250DV), etc., can be displayed

on the rear monitor only when they are the same as the main source.

Switching Display Modes

While your vehicle is parked, touch [WIDE] on the visual

source screen.

Each touch changes the display modes as follows:

In Mode 1 (Wide), the monitor displays a normal picture wider to

fit in a wide-screen monitor by evenly stretching out the picture

horizontally.

In Mode 2 (Cinema), the monitor displays a normal picture by

stretching out the picture horizontally and vertically. This mode is

good for displaying a cinema type picture at the 16:9 ratio.

In Mode 3 (Normal), the monitor displays a normal picture at the

centre of the screen with a vertical black band at each side.

Switching the Visual Source Only

(Simultaneous Function)

You can watch the video portion of another source while listening to the

current source.

Touch [V.Sel].

The VISUAL selection screen is displayed.

Touch desired visual source.

The visual source is switched to the selected one.

Touch [V.Sel].

Touch [Normal].

The simultaneous function is cancelled.

•To apply the setting, set to V.Sel in “Setting the VISUAL Button”

(page 35).

•The simultaneous function cannot be used when the Audio source is

in the navigation mode.

When Navi is set in “Setting the VISUAL Button” (page 35), only the

navigation screen can be recalled.

•When the AUX1 IN is set to OFF and AUX2 IN is set to iPod Video,

the AUX source is not displayed. Refer to “Setting the AUX Mode”

(page 40).

Blackout Mode On and Off

When Blackout mode is turned on, the monitor display will turn off to

reduce power consumption.

This additional power enhances the sound quality.

Touch [V.Sel].

The VISUAL selection screen is displayed.

Touch [Off].

The backlit-display portion goes out.

Touch [Off] again to cancel the display backlight.

•To apply the setting, set to V.Sel in “Setting the VISUAL Button”

(page 35).

•If any button on the unit is pressed or main screen is touched during

Blackout mode, the function will be displayed for 5 seconds. This

confirms the operation as well as allowing for additional functions

before returning to Blackout mode.

Mode 1 Mode 2 Mode 3 Mode 1

(WIDE) (CINEMA) (NORMAL) (WIDE)

Cancelling the Simultaneous Function

31-EN

DVD Setup Operation

Touch [ ] on the main screen.

The SETUP selection screen is displayed.

Touch the title bar of Source Setup.

The Source Setup screen appears.

Touch the title bar of DVD Setup.

The DVD Setup screen appears.

Touch [ ] or [ ], etc., of the desired item to change

its setting.

Setting items:

Menu Language / Audio Language / SUBT. Language /

Downmix Mode / TV Screen / DOLBY / DivX Info.

Display example for DVD setup screen

Touch [Code] to display the numeric keypad input

screen.

Touch [ ] or [ ] to set a desired language/item.

Touch [ ] or [ ] to scroll a setting item list by one Line.

Touch

[ ]

to scroll a setting item list by one page.

Touch [ ] to return to the previous screen.

•Touching [Exit] will turn off the DVD Setup screen, and return to

previous main screen.

•Immediately after changing the settings of DVD mode (while the

system is writing data automatically) do not turn the ignition key

(engine key) to OFF.

Otherwise, the settings may not be changed.

•Depending on the DVD, the setting is effective after the disc has been

ejected and reinserted.

The audio language, subtitle language and menu language can be set

according to your preferences.

Once set, this becomes the default language. This function is convenient

when you always want to listen in English. (The language setting is not

effective on some discs. If not, the default language is set from the

factory.)

•When the settings are changed, the old settings are overwritten.

Make a note of the current settings before making changes. The

settings are cleared when the vehicle’s battery is disconnected.

•To temporarily change the language of the current disc, either do so

from the DVD menu or by using the operation described in the

section “Switching the Audio Tracks” (page 26).

•If the disc does not include the selected language, the disc’s default

language is set.

Set the language used for the menus (title menu, etc.).

Setting item: Menu Language

Setting contents: Auto / EN / JP / DE / ES / FR / IT / SE / RU / CN

•When “Auto” is selected, the primary menu language among the

recorded ones is played.

Set the audio language produced from the speakers.

Setting item: Audio Language

Setting contents: Auto / EN / JP / DE / ES / FR / IT / SE / RU / CN

•When “Auto” is selected, the primary audio language among the

recorded ones is played.

Setup

DVD Setup

The Parking Brake must be engaged to access the DVD

mode screen. Attempting to access this screen while driving

will display the warning-Can’t operate while driving.

The following steps 1 to 5 are common operations to each

“Setting item” of DVD Setup. Refer to each section for details.

Changing the language setting

Setting of the Menu Language

Setting of the Audio Language

32-EN

Set the language of the subtitles displayed on the screen.

Setting item: SUBT. Language

Setting contents: Auto / EN / JP / DE / ES / FR / IT / SE / RU / CN

•When “Auto” is selected, the primary subtitle language among the

recorded ones is played.

To play in a language other than those displayed

1 Touch [Code].

The numeric keypad screen is displayed.

2 Touch the 4-digit numeral of the language number.

As for the language number, refer to “List of Language

Codes” (page 57).

3 Touch [Enter] to memorize the number.

This function applies to Dolby Digital sound.

Setting item: Downmix Mode

Setting contents: Surround / Stereo

Use the procedure described below to modify the output screen

according to the type of TV monitor (rear monitor) being used.

This setting can also be applied for the IVE-W530BT.

If the rear monitor is not connected, the screen setting is 16:9.

Setting item: TV Screen

Setting contents: 4:3 LB / 4:3 PS / 16:9

•For some discs, the picture may not be set to the selected screen size.

(For details, refer to the explanation on the disc’s jacket.)

4:3 LETTER BOX:

Select this when connected to a conventional 4:3 size (normal

TV aspect ratio) monitor. There may be black stripes visible at

the top and bottom of the screen (when playing a 16:9 size

movie). The width of these stripes will depend upon the original

aspect ratio of the theatrical release of the movie.

4:3 PAN-SCAN:

Select this when connected to a conventional 4:3 size monitor.

The picture will fill the entire TV screen. However, due to the

mismatch in aspect ratio, parts of the movie at the extreme left

and right sides will not be visible (when playing a 16:9 size

movie).

16:9 WIDE:

Select this when connected to a wide screen TV. This is the

factory setting.

The DOLBY Dynamic Range can be chosen.

Setting item: DOLBY

Setting contents: RF / Line / OFF

Setting item: DivX Info.

If the title bar of DivX Info. is touched, a DivX® file registered

code or deactivate code is displayed.

•During DISC/USB/iPod playing mode, the above information will not

be displayed.

Setting of the Subtitle Language

Setting the Downmix Mode

Surround: Surround compatible Downmix

Stereo: Stereo Downmix

Setting the TV Screen

Setting the DOLBY Dynamic Range

Displaying DivX® Disc Information

33-EN

Source Setup Operation

Touch [ ] on the main screen.

The SETUP selection screen is displayed.

Touch the title bar of Source Setup.

The Source Setup screen appears.

Touch the title bar of your desired Setup mode.

DVD Setup

/ Radio Setup / BLUETOOTH Setup

/ RDS

Setup

*1Refer to “DVD Setup” on page 31.

*2Displayed when “BLUETOOTH IN” is set to other than “OFF”

(page 41).

*3Refer to “RDS Operation” on page 16.

Touch [ ], [ ] or the title bar, etc. of the desired

item to change its setting.

Radio Setup:

RDS Clock DISP / FM Level / PI Seek / RDS Regional /

PTY Language / PTY31

BLUETOOTH Setup:

Paired Devices / Device Search / Clear Device / Service Provider /

Visible Mode / Auto Answer / Speaker Select / MIC Input /

Firmware Version / Firmware Update / BT Menu Language /

Shortcut Memory

•For BLUETOOTH Setup details, refer to “BLUETOOTH Setup”

(page 43).

Touch [ ] to return to the previous screen.

“Radio Setup” is selected on the source setup main menu in step 3.

RDS Time Display

When ON is selected, the clock is adjusted automatically based

on the time data sent from the RDS broadcast.

Setting item: RDS Clock DISP

Setting contents: OFF / ON

Adjusting Source Signal Levels

If the difference in volume level between the CD and FM radio is

too great, adjust the FM signal level as follows.

Setting item: FM Level

Setting contents: Low / High

PI Seek Setting

Setting item: PI Seek

Setting contents: OFF / Auto

Receiving RDS Regional (Local) Stations

When OFF is selected, the unit automatically keeps receiving the

related local RDS station.

Setting item: RDS Regional

Setting contents: OFF / ON

Switching the Display Language of PTY (Programme Type)

You can select one of the patterns of the display languages.

Setting item: PTY Language

Setting contents: GB / NL / F / D / I / E

Setting PTY31 (Emergency Broadcast) Reception

PTY31 (Emergency Broadcast) reception can be set to ON/OFF.

Setting item: PTY31

Setting contents: OFF / ON

•The unit automatically gives priority to an Emergency Broadcast

whenever it begins, and interrupts the programme you are currently

listening to when PTY31 is set to ON.

•The unit will show “Alarm” in the display during PTY31 reception.

Source Setup

The Parking Brake must be engaged to access the Source

mode screen. Attempting to access this screen while driving

will display the warning-Can’t operate while driving.

The following steps 1 to 5 are common operations to each

“Setting item” of Source Setup. Refer to each section for details.

Radio Setup

OFF: To adjust it manually.

ON: Adjust the clock automatically based on the time data. In

this case, the clock cannot be adjusted manually.

To adjust it manually, select OFF.

34-EN

Display Setup Operation

Touch [ ] on the main screen.

The SETUP selection screen is displayed.

Touch the title bar of Display Setup.

The Display Setup screen appears.

Touch [ ] or [ ] etc., of the desired item to change

its setting.

Setting items:

Visual EQ

/ Dimmer / Screen Dimmer Level

/ Function Guide

Fade / Base Color / Screen Alignment / Visual Key

*1For details, refer to “Visual EQ Setting Operation” on page 35.

*2Not displayed when “Dimmer” is set to “OFF”.

Touch [ ] to return to the previous screen.

•Touching [Exit] will turn off the Display Setup screen, and return to

previous main screen.

•Immediately after changing the settings of Display Mode (While the

system is writing data automatically) do not turn the ignition key

(engine key) to OFF.

Otherwise, the settings may not be changed.

Backlighting is provided by a fluorescent light built into the liquid

crystal panel. The illumination control adjusts the brightness of the

backlighting based on the car ambient lighting for easier viewing.

Setting item: Dimmer

Setting contents: Auto / ON / OFF

•When ON or Auto is set, the setting is also applied for the button

lighting in “Adjusting the Dimmer of Button Lighting at Night”

(page 38).

You can adjust the brightness of the backlight (LOW). This function

could be used, for instance, to change the screen brightness while

travelling at night.

Setting item: Screen Dimmer Level

Setting content: –15 to +15

You can adjust the level between MIN (-15) and MAX (+15).

When it reaches the minimum or maximum point, the display

shows “MIN” or “MAX” respectively.

Display Setup

The Parking Brake must be engaged to access the Display mode

screen. Attempting to access this screen while driving will display

the warning-Can’t operate while driving.

The following steps 1 to 4 are common operations to each

“Setting item” of Display Setup. Refer to each section for

details.

Setting the Brightness of the Backlighting

Auto: Adjust the brightness of the background illumination of

the monitor automatically to the brightness of the car

interior.

ON: Keep the background illumination of the monitor dark.

OFF: Deactivate Auto Dimmer mode to keep the background

illumination of the monitor bright.

Adjusting the Minimum Level of Backlight

35-EN

By setting to ON, the function guide will be hidden if no operation is

performed for 5 seconds in Radio source, USB source, etc. To display

the function guide, touch the screen slightly.

Setting item: Function Guide Fade

Setting contents: OFF / ON

•In DVD play mode, the function guide will be hidden if there is no

operation for 5 seconds even if you set OFF.

You can choose from 4 different colours for the font background.

Setting item: Base Color

Setting contents: Blue / Red / Green / Amber

Adjustment becomes necessary when the display position on the LCD

and the touch position on the touch panel do not match.

Setting item: Screen Alignment

Setting contents: / Reset

1 Touch the title bar of Screen Alignment.

The adjustment screen appears.

2 Accurately touch the mark provided in the lower left

corner of the screen.

The screen changes to the adjustment screen.

3 Accurately touch the mark provided in the upper right

corner of the screen.

This completes adjustment, and returns to the Display

Setup mode screen.

•If you have touched a location other than the mark, touch [Reset]

to restore the adjustment screen to the initial setting.

•If you touch [ ] on the adjustment screen, no adjustment is done

and the Display Setup screen is restored.

Setting item: Visual Key

Setting contents: Navi / V.Sel

Visual EQ Setting Operation

After steps 1 and 2 in “Display Setup Operation”

(page 34) have been performed, touch the title bar of

Visual EQ.

The Visual EQ screen appears.

Select a desired setting item by touching [ ] or [ ].

Setting items:

Visual EQ* Bright Color* Tint* Contrast

Sharp* User Memory*

* The setting is available in the visual source mode. (except navigation

screen)

Change the setting on the selected item by touching

its [] or [ ].

Touch [ ] to return to the previous screen.

•Touching [Exit] will turn off the Display Setup screen, and return to

previous main screen.

•Only one setting item can be displayed on each page, you can select

the desired brightness, picture tint, etc. through the screen shown.

Turn the Function Guide ON/OFF

(Function Guide Fade)

Switching the Font Background Colour

Adjusting the Touch Panel

Setting the VISUAL Button

Navi: When Navi is set, [ ] will appear on the upper

right screen. Touch [ ] to switch to the navigation

screen directly. (Only when an Alpine optional RGB

Navigation is connected.)

V. S e l : When V.Sel is set, [V.Sel] will appear on the upper right

screen. Recalls the VISUAL selection screen by

touching [V.Sel] on the main source screen.

Visual EQ™

The following steps 1 to 4 are common operations to each

“Setting item” of Visual EQ setting. Refer to each section for

details

36-EN

You can select a mode suitable for the subject image.

•To return to the initial setting, after selecting any one of the setting

contents (Night M. to Contrast) and adjusting a desired brightness,

picture tint, etc., set this function to OFF.

•If your desired brightness, picture tint, etc., are adjusted after

selecting any one of the setting contents (Night M. to Contrast),

“Custom” is displayed.

Setting item: Bright

Setting content: –15 ~ +15

You can adjust the brightness between MIN (–15) and MAX

(+15). When it reaches the minimum or maximum point, the

display shows “MIN” or “MAX” respectively.

•When any Visual EQ Preset is selected, the brightness is

automatically adjusted according to the car’s interior lighting as

long as Auto is set in “Setting the Brightness of the Backlighting”

(page 34).

Setting item: Color

Setting content: -15 ~ +15

You can adjust the colour between MIN (–15) and MAX (+15).

When it reaches the minimum or maximum point, the display

shows “MIN” or “MAX” respectively.

•Colour adjustment can be made only in the iPod video, DVD, USB

Video, AUX modes.

•Colour adjustment cannot be made if a Navigation system with the

RGB feature is connected.

Setting item: Tint

Setting content: G15 ~ R15

Adjust the colour from G15 to R15. “G MAX” or “R MAX” is

displayed at the maximum of each colour.

•Tint adjustment can be made only in the iPod video, DVD, USB

Video, AUX modes.

•When the picture from the external input is set to PAL, you cannot

adjust the Tint.

•Tint adjustment cannot be made if a Navigation system with the RGB

feature is connected.

Setting item: Contrast

Setting content: -15 to +15

Adjustment of contrast is done in the range of -15 to +15. “HIGH”

and “LOW” appear as the maximum and minimum values

specified.

Setting item: Sharp

Setting content: -5 to +5

Picture quality adjustment range is -5 to +5. “SOFT” and “HARD”

appear as the minimum and maximum values specified.

•Picture quality adjustment can be made only in the iPod video, DVD,

USB Video, AUX modes.

•Picture quality adjustment cannot be made if a Navigation system

with the RGB feature is connected.

You can store the settings made for “Adjusting Image Brightness, Tint,

Depth, Picture Quality and Contrast.”

Setting item: User Memory

Setting contents: P-1 / P-2

1 After completing “Adjusting Brightness, Tint, Colour,

Sharpness, and Contrast” (page 36), touch [ ] or [ ] of

User Memory and then select preset number “P-1” or “P-

2” to which the settings are to be stored.

2 After selecting a preset No., touch [L-Memory].

The adjusted Visual EQ mode is stored by the above

operations.

•You can recall the Visual EQ mode stored here from P-1 or P-2 of

“Selecting the Visual EQ Mode (Factory’s setting)” (page 36).

Selecting the Visual EQ Mode (Factory’s

setting)

Setting item: Visual EQ

Setting contents: OFF (FLAT) / Night M. / Soft / Sharp / Contrast /

P-1 / P-2

OFF (FLAT): Initial Setting

Night M.: Suitable for movies in which dark scenes

frequently appear.

Soft: Suitable for CGs and animated films.

Sharp: Suitable for old movies where images are not

clearly shown.

Contrast: Suitable for recent movies.

P-1: Recalls the Visual EQ mode being stored on

preset No.P-1 from “Storing Visual EQ” (page 36).

P-2: Recalls the Visual EQ mode being saved on

preset No.P-2 from “Storing Visual EQ” (page 36).

Adjusting Brightness

Adjusting Colour of Picture

Adjusting Tint of Picture

Adjusting Image Contrast

Adjusting Picture Quality

Storing Visual EQ

37-EN

General Setup Operation

Touch [ ] on the main screen.

The SETUP selection screen is displayed.

Touch the title bar of General Setup.

The General Setup screen appears.

Touch [ ], [ ] or the title bar of setting item, etc., of

the desired item to change its setting.

Setting items:

Clock / Clock Mode*1 / Clock Adjust*1 / Summer Time*1 /

Demonstration / Beep / Beep Level*2 / Auto Scroll / Language

Sel. / Dimmer Level*3 / Security Code

*1Displayed only when “Clock” is set to “ON”.

*2When Beep is ON, the item is displayed.

*3Not displayed when “OFF” is set in “Setting the Brightness of the

Backlighting” (page 34).

Touch [ ] to return to the previous screen.

•Touching [Exit] will turn off the General Setup screen, and return to

previous main screen.

•Immediately after changing the settings of General Mode (While the

system is writing data automatically) do not turn the ignition key

(engine key) to OFF.

Otherwise, the settings may not be changed.

The clock indication on the monitor display is turned on or off

respectively.

Setting item: Clock

Setting contents: OFF / ON

You can select the clock display type, 12-hour or 24-hour, depending on

your preference.

Setting item: Clock Mode

Setting contents: 24h / 12h

Setting item: Clock Adjust

Further setting items: Hour / Minute / Time Adjust

Setting contents: 0-23 / 0-59 / Reset

•The clock-adjusting mode is cancelled when the power is turned off,

when [] or [Exit] is touched.

•Clock adjustment can be made when “RDS Time Display” (page 33)

is set to OFF.

Setting item: Summer Time

Setting contents: OFF / ON

This unit is equipped with a demonstration function capable of showing

basic operations of respective sources on the monitor display.

Setting item: Demonstration

Setting contents: OFF / ON

•The demonstration operation is automatically repeated until the

function is turned off.

Setting item: Beep

Setting contents: OFF / ON

General Setup

The Parking Brake must be engaged to access the General mode

screen. Attempting to access this screen while driving will display

the warning-Can’t operate while driving.

The following steps 1 to 4 are common operations to each

“Setting item” of General Setup. Refer to each section for

details.

Displaying the Time

Setting the Clock Display

Setting the Time

Hour: Adjust the hour.

Minute: Adjust the minute.

Reset: If the clock shows less than 30 minutes past, the

minute will be “0”; more than 30, the hour advances.

Setting Summer Time

ON: Place the Summer Time mode ON. The time advances by

one hour.

OFF: Return to the ordinary time.

Demonstration Function

ON: Turns on the demonstration mode to show the basic

operations.

OFF: Turns off the demonstration mode.

Sound (Beep) Guide Function

ON: Activate the Sound Guide mode.

OFF: Deactivate the Sound Guide mode. The sound guide

beep will not be produced when a button is pressed/

touched.

38-EN

After set to ON in “Setting the Beep”, this setting can be performmed.

Setting item: Beep Level

Setting content: 0 to +15

Scroll display is available if CD text, folder name, file name or tag

information is entered.

Setting item: Auto Scroll

Setting contents: OFF / ON

•The display scrolls on the unit when the screen is filled up.

•Song, artist and album name, etc. scrolls when an iPod/iPhone is

connected.

Three types of font can be selected.

Setting item: Language Sel.

Setting contents: Mode1 / Mode2 / Mode3

You can adjust the brightness of the button lighting at night with the

dimmer.

Setting item: Dimmer Level

Setting content: -2 to +2

You can set the system to be unusable without entering a password.

When you set this setting to ON and set a password, the password input

is required when the system is connected to a battery and turned on for

the first time.

Setting item: Security Code

Setting contents: ON / OFF

Setting the password

Touch [ON].

After the confirmation message appears, touch

[Yes].

The password setting screen is displayed.

Enter a password, then touch [OK].

• Enter the 6-digit number.

• Input numbers are displayed as “*”.

Enter the same password again, then touch [OK].

The password is set and the system returns to the General

Setup screen.

•If you forget a registered password, you can not use this unit. In this

case, service will be required.

Clearing the password

Touch [OFF].

The password setting screen is displayed.

Enter the password you have set, then touch [OK].

The password is cleared and the system returns to the

General Setup screen.

• Input numbers are displayed as “*”.

Setting the Beep Level

Setting the Scroll

OFF: Turns off the AUTO scroll mode. Scroll display is done

once as a track is changed.

ON: Turns on the AUTO scroll mode. Scroll display is

repeated as long as the mode is turned on.

Changing the Russian Font

Mode1: Normal Font Display (ISO8859-1).

Mode2: Russian Font Display (WINDOWS-1251).

You cannot use this font for display in RDS, Tuner

mode.

Mode3: European Font Display (WINDOWS-1252).

Adjusting the Dimmer of Button Lighting at

Night

Setting Security code

39-EN

System Setup Operation

Touch [ ] on the main screen.

The SETUP selection screen is displayed.

Touch the title bar of System Setup.

The System Setup screen appears.

Touch [ ] or [ ] of the desired item to change its

setting.

Setting items:

Camera IN / Nav. IN / Nav. Mix* / AUX1 IN / AUX2 IN /

AUX Front / AUX Out / BLUETOOTH IN / Illumi Color

* When ON is set in “Setting the Navigation Mode” (page 40), the item

is displayed.

Touch [ ] to return to the previous screen.

•Touching [Exit] will turn off the System Setup screen, and return to

previous main screen.

•Immediately after changing the settings of System Mode (While the

system is writing data automatically) do not turn the ignition key

(engine key) to OFF.

Otherwise, the settings may not be changed.

With an optional rear camera connected, rear view video is output to the

monitor.

Setting item: Camera IN

Setting contents: OFF / ON

•By shifting to reverse (R), the rear pictures are output.

This function is effective when the reverse wire is properly connected.

After setting this item to ON, touch the title bar of Camera IN, the

following further setting items can be adjusted.

Setting the Rear Camera Signal Input

The video input signal type can be chosen.

Further Setting item: Camera Signal

Setting contents: NTSC/PAL / Auto

•When set to Auto, unstable display may occur while playing back

certain black and white video signal. In this case, select NTSC or

PAL mode manually.

Rear camera guide line display setting

You can set whether the rear camera guide line is displayed or

not.

Further Setting item: Guide Line

Setting contents: OFF / ON

System Setup

The Parking Brake must be engaged to access the System mode

screen. Attempting to access this screen while driving will display

the warning-Can’t operate while driving.

The following steps 1 to 4 are common operations to each

“Setting item” of System Setup. Refer to each section for details.

Setting the Rear Camera Input

OFF: The Camera mode is not displayed in the mode

switching screen.

ON: Use when the optional rearview camera is

connected to the CAMERA Input Connector.

NTSC/PAL: Choose the video input signal type manually.

Auto: The suitable video input signal type will be

automatically chosen between NTSC and PAL.

40-EN

Adjusting the Rear Camera Guide line

You can adjust the rear camera guide line position.

Further Setting item: Guide Line Adjustment

Touch the title bar of Guide Line Adjustment.

The Guide Line Adjustment screen is displayed.

When you touch the guide pylon to be adjusted, a

border appears around the pylon.

Drag and drop the selected pylon or centre guide to

adjust its position.

After the adjustment is completed, touch [ ].

You can touch [Reset] during adjustment to return to the

default adjustment.

Camera mute setting

You can set whether to mute the source volume when the

camera video is displayed.

Further Setting item: Camera Mute

Setting Contents: OFF / ON

When you connect an optional navigation equipment, set it to ON.

Setting item: Nav. IN

Setting contents: OFF / ON

With an Alpine navigation system connected to the IVE-W530BT, the

voice guidance of the navigation system will be mixed with the radio or

CD play.

Setting item: Nav. Mix

Setting contents: OFF / ON

See “Adjusting Nav. Mix Level” under “Adjusting the Audio” on

page 29 to set the navigation interruption volume level.

•The volume level for voice prompts during navigation guidance is set

by adjusting its volume while the prompts are announced. When the

announcement finishes, the normal audio volume and the previous

audio screen are restored. The voice prompt volume is always at or

below the current listening volume. If a navigation announcement

cuts in while adjusting the audio level, it always resets to the current

level regardless of the audio level setting.

•This setting is effective when Nav.IN of SYSTEM list screen is ON.

Setting item: AUX1 IN

Setting contents: OFF / ON

•When OFF is selected, the settings related to AUX-1 cannot be

changed from this unit.

After setting this item to ON, touch the title bar of AUX1 IN, the

following further setting items can be adjusted.

Adjusting the AUX1 name Mode

Further Setting items: Primary / Secondary

Setting contents: OFF

/ AUX

/ DVD / GAME / TV / DVB-T

/ NAV.

*1When TUE-T200DVB (sold separately) is connected, you can use it

to connect one more External Input device. Setting the Secondary

name can change the source name display of this device.

*2The setting is only available for Secondary.

*3The setting is only available for Primary.

•You can set Secondary name only when Primary name is set to

DVB-T. And you cannot set the same name as in Primary name.

•When OFF is selected, the settings related to AUX cannot be changed

from this unit.

•The selected name is displayed on the Visual and Rear selection

screen.

•Only when an Alpine TV tuner is connected, you can operate the

displayed function guide from this unit.

•The selected source name is displayed instead of AUX source name.

Select SOURCE to switch to the guide function of each mode.

Setting item: AUX2 IN

Setting contents: iPod Video / AUX

•When the current source is iPod video or AUX-2, this setting cannot

be adjusted.

Setting the Navigation Mode

ON: Navigation source is displayed.

OFF: Navigation source is not displayed. The settings related

to the navigation can not be changed from this unit.

Setting the Navigation Interruption

OFF: The navigation interruption mode is turned off.

ON: The navigation interruption mode is on.

Setting the AUX Mode

OFF: AUX-1 source is not displayed.

ON: AUX-1 source is displayed.

iPod Video: Set when an iPhone or a video compatible iPod is

connected to the iPod (V)/AUX Input Connector.

AUX: Set when an optional AV/RCA interface cable

(4-pole mini AV plug to 3-RCA) is connected. A DVD

player etc., with RCA audio/video output can be

connected to this unit. In this case, the iPod video

will not be displayed.

41-EN

After setting this item to AUX, touch the title bar of AUX2 IN, the

following further setting items can be adjusted.

Adjusting the AUX2 name Mode

Further Setting items: Primary

Setting contents: AUX / DVD / GAME / TV / DVB-T / NAV.

•The selected name is displayed on the Visual and Rear selection

screen.

•Only when an Alpine TV tuner is connected, you can operate the

displayed function guide from this unit.

•The selected source name is displayed instead of AUX source name.

Select SOURCE to switch to the guide function of each mode.

Touch the title bar of AUX1 IN or AUX2 IN, the following further

setting items can be adjusted.

Adjusting the External Input Audio Level

Further Setting item: Level

Setting contents: Low / High

•For AUX1, this setting item is adjustable only when AUX1 IN is set to

ON.

•For AUX2, this setting item is adjustable only when AUX2 IN is set to

AUX.

Switching the Visual Input Signal System

Further Setting item: Signal

Setting contents: NTSC/PAL / Auto

•The video input type can be changed.

•When set to Auto, unstable display may occur while playing back

certain black and white video signal. In this case, select NTSC or

PAL mode manually.

•For AUX1, this setting item is adjustable only when AUX1 IN is set to

ON.

•For AUX2, this setting item is adjustable only when AUX2 IN is set to

AUX.

You can input the audio of an external device (such as a Portable audio

player) to the Front AUX Input Terminal of this unit.

Setting item: AUX Front

Setting contents: ON / OFF

•When OFF is selected, the setting related to AUX Front source

cannot be changed from this unit.

After setting this item to ON, touch the title bar of AUX Front, the

following further setting item can be adjusted.

Adjusting the Front AUX Input Audio Level

Further Setting item: Level

Setting contents: Low / High

•This setting item is adjustable only when AUX Front is set to ON.

Outputs the picture/Sound of the source selected on the IVE-W530BT

connected to the rear monitor.

Setting item: AUX Out

Setting contents: OFF / ON

Setting item: BLUETOOTH IN

Setting contents: OFF / HFP / HFP+Audio

•For details on BLUETOOTH operation, refer to “BT Hands Free

Calling” on page 42.

Setting item: Illumi Color

Setting contents: Blue / Red / Green / Amber

Low: Decreases the external input audio level.

High: Increases the external input audio level.

Setting the AUX Front Mode

ON: AUX Front source is displayed.

OFF: AUX Front source is not displayed.

Low: Decreases the front aux input audio level.

High: Increases the front aux input audio level.

Setting the Picture/Sound Output

ON: The “Rear” item is displayed on the Source Selection

screen.

Touch [Rear] to change to the REAR select screen, and

then touch the desired source. The selected source

picture is output on the rear monitor.

OFF: The “Rear” item is not displayed on the SOURCE select

screen.

Setting the BLUETOOTH Connection

(BLUETOOTH IN)

OFF: Select to ignore any external interrupts.

HFP: Select when you want to pair your BLUETOOTH

compatible phone with this unit.

HFP+Audio: Select when you want to use BLUETOOTH Audio

function.

Changing the Lighting Colour of Buttons

Blue: Lighting colour is blue.

Red: Lighting colour is red.

Green: Lighting colour is green.

Amber: Lighting colour is amber.

42-EN

Setup Before Using

BLUETOOTH is a wireless technology allowing communication

between a mobile device or personal computer over short distances.

This enables a hands-free call or data transmission between

BLUETOOTH compatible devices. BLUETOOTH transmission is

available in the unlicensed 2.4 GHz spectrum if the distance between

devices is within 10 meters. For details, refer to the BLUETOOTH

Home page (http://www.BLUETOOTH.com/).

•Depending on the BLUETOOTH version, a BLUETOOTH

compatible device may not be able to communicate with this unit.

•Proper function of this unit with all BLUETOOTH compatible

devices is not guaranteed. For handling of the BT compatible device,

consult your ALPINE dealer or ALPINE website.

•Depending on the surroundings, BLUETOOTH wireless connection

may be unstable.

•When you place a call, or perform setup operations, be sure to stop

your car in a safe place.

•Depending on the connected BLUETOOTH compatible device(s), the

function may differ. Also refer to the Owner’s Manual of the

connected device(s).

Before using the hands-free phone/audio function, the following

settings need to be made.

Set “BLUETOOTH IN” to HFP or HFP+Audio (page 41).

•Before using a hands-free phone, it must be paired with this unit.

Refer to “BLUETOOTH Setup” (pages 43-44).

For details on the control from a BLUETOOTH compatible device,

refer to the Owner’s Manual of the BLUETOOTH compatible device.

Set a BLUETOOTH connection from a BLUETOOTH

compatible device.

The PIN code (“0000”) is displayed on the screen.

Input the PIN code (“0000”) in a BLUETOOTH

compatible device.

If this unit is successfully connected to a

BLUETOOTH compatible device, “Connected/

(Device name)” is displayed, and then the unit

returns to normal mode.

•When pairing a BLUETOOTH compatible device with SSP (Secure

Simple Pairing), a message “Connect/(Security Code)/Yes/No” will

be displayed, touch [Yes] to connect.

•Set “Setting the Search Mode” (page 44) to Visible Mode ON to

enable this unit to recognise a mobile phone. For mobile phone

passkey (passcode) input operation, refer to the mobile’s Owner’s

Manual. Additionally, the mobile phone can be searched directly

from this unit. Refer to “Registering the BLUETOOTH Device”

(page 43).

•If a BLUETOOTH compatible device is successfully paired, the next

time when the ignition key of the car is turned to on, the unit will

automatically connect to the previously connected device. However,

the connection may fail. If the auto connection fails, try the

connection manually.

BT Hands Free

Calling

About BLUETOOTH

Before Using Hands-Free Function

How to connect to a BLUETOOTH

compatible device (Pairing)

43-EN

BLUETOOTH Setup

The following steps 1 to 5 are common to the various BLUETOOTH

functions. For details, refer to each individual function.

•While calling, or in the BLUETOOTH Audio source, BLUETOOTH

Setup operation cannot be performed.

•When BLUETOOTH IN is set to other than OFF, the following

operation can be performed.

Touch [ ] on the main screen.

The SETUP selection screen is displayed.

Touch the title bar of Source Setup.

The Source Setup screen appears.

Touch the title bar of BLUETOOTH Setup.

The BLUETOOTH Setup screen appears.

Touch [ ], [ ] or the title bar of the desired item to

change its setting.

Setting items:

Paired Devices / Device Search / Clear Device /

Service Provider / Visible Mode / Auto Answer / Speaker Select /

MIC Input / Firmware Version / Firmware Update / BT Menu

Language / Shortcut Memory

Touch [ ] to return to the previous screen.

Touch [Exit] to return to the main source screen that was

displayed before the setup operation was started.

Setting the BLUETOOTH Device

Select one of 3 connected BLUETOOTH compatible devices that

you previously registered.

Setting item: Paired Devices

Touch a BLUETOOTH compatible device to use (change

connection)

from the Paired Device list.

•If the connection is successfully changed, “Connected/(Device

name)” is displayed for 2 seconds, and then the display returns to the

Setup screen.

•If you input the wrong passcode or communications fail, “Failed” is

displayed.

•If you want to connect another BLUETOOTH compatible device,

after disconnecting the current BLUETOOTH compatible device,

connect the BLUETOOTH compatible device you want to change to.

•Up to 3 BLUETOOTH compatible devices can be registered to this

unit. If all 3 positions have been registered, you cannot register a 4th

device. To register another device, you need to delete one of the

devices from position 1 to 3 first.

Registering the BLUETOOTH Device

The BLUETOOTH device is used when a connectable

BLUETOOTH compatible device is searched and connected

from this unit, or a new BLUETOOTH compatible device is

registered.

Setting item: Device Search

When Device Search is selected, “Now Searching” is

displayed, and searching starts.

Touch the device name to be connected from the

Device Search list.

If this unit is successfully connected to a

BLUETOOTH compatible device, “Connected/

(Device name)” is displayed, and then the unit

returns to normal mode.

•If a mobile phone is registered for the first time:

Input a passcode when the numeric keypad screen is displayed, then

input the same passcode in the BLUETOOTH compatible device to

make the pairing. Or a confirmation prompt (Connect (6-digit code

number)) will appear on this unit, then touch [Yes]. After the pairing

is completed, the unit will automatically connect to the

BLUETOOTH compatible device.

•If you input the wrong passcode or communications fail, “Failed” is

displayed.

•A passcode input on the unit is maximum 4-digit. If a passcode on the

BLUETOOTH compatible device exceeds 4 digits, reset the passcode

and make this setting again.

Deleting a BLUETOOTH Device from the list

You can delete the history of a previously connected

BLUETOOTH compatible device.

Setting item: Clear Device

Touch the BLUETOOTH compatible device you want

to delete from the Clear Device list.

A message is displayed.

Touch [Yes] if you want to delete.

•Touching [No] will cancel the setting.

BLUETOOTH Setup Operation

44-EN

Displaying the phone service provider name

Setting item: Service Provider

The service provider name of the connected BLUETOOTH

compatible device will be displayed. If a BLUETOOTH

compatible device is not connected, “ID UNSENT” will be

displayed.

•Depending on the character type some phone service provider name

cannot be displayed.

Setting the Search Mode

You can set whether this unit can be recognised or not from a

BLUETOOTH compatible device. Normally set this to Visible

Mode ON.

Setting item: Visible Mode

Setting the Received Calls automatically (Auto Answer)

When a call is received, you can set whether to receive it

automatically or not.

Setting item: Auto Answer

•If the received call setting on the mobile phone is on, the call will be

answered automatically even though this setting is set to OFF.

Selecting the output speaker

You can select the connected speaker in car to output the sound

signal of telephone.

Setting item: Speaker Select

•The setting cannot be adjusted during a phone call. Adjust the setting

before placing a call.

Adjusting the volume for the microphone input

You can emphasise or weaken the microphone input volume

level.

Setting item: MIC Input

Touch

[ ] or [ ]

to select the desired volume level (0 ~15).

•The setting cannot be adjusted during a phone call. Adjust the setting

before placing a call.

•The setting can be adjusted only when the BLUETOOTH compatible

device is connected.

Displaying the firmware version

Setting item: Firmware Version

The current firmware version will be displayed.

Updating the firmware

Setting item: Firmware Update

For information to update your BLUETOOTH firmware, please

visit your local Alpine web site or choose your country from

Alpine Europe top page (http://www.alpine-europe.com).

Setting the BLUETOOTH Menu language

The BLUETOOTH Menu can be switched within 8 languages

(EN/DE/ES/FR/IT/NL/RU/TH).

Setting item: BT Menu Language

For example, if you want the BLUETOOTH Menu to be displayed

as German, select DE with above procedure.

Deleting a preset number from the Shortcut Memory

Setting item: Shortcut Memory

Touch [Delete] of the preset number to delete preset shortcut

dial number.

•About how to store the telephone number as shortcut dial, refer to

“Preset a number in the Phone Book (Shortcut Dial)” on page 47.

Hands-Free Phone Control

Hands-free calls are possible when using a HSP (Head Set Profile) and

HFP (Hands-Free Profile) compatible mobile phone with this unit.

•Avoid performing a hands-free call in heavy traffic or on narrow or

winding streets.

•Close the windows while calling to reduce background noise.

•If both calling parties are using hands-free devices, or the call is

made in a noisy location, difficulty hearing the other person’s voice

is normal.

•Depending on telephone line conditions or certain mobile devices

used, voices may sound unnatural.

•When using a microphone, speak as directly as you can into the

microphone to pick up the best sound quality.

•Certain mobile phone features are dependent on the capabilities and

settings of your service provider’s network. Additionally, certain

features may not be activated by your service provider, and/or the

provider’s network settings may limit the feature’s functionality.

Always contact your service provider about feature availability and

functionality.

All features, functionality, and other product specifications, as well

as the information contained in the Owner’s Manual are based upon

the latest available information and are believed to be accurate at

the time of printing.

Alpine reserves the right to change or modify any information or

specifications without notice or obligation.

ON: Enables recognition of this unit from the

BLUETOOTH compatible device.

OFF: Disables recognition of this unit from the

BLUETOOTH compatible device.

ON: When a call is received, it will be taken

automatically after about 5 seconds.

OFF: When a call is received, it will not be

received automatically. If a message is

displayed and [ ] is touched when a call is

received, you can receive the call.

All: The sound outputs from all of speakers in car.

F-L: The sound only outputs from the front left speaker.

F-R: The sound only outputs from the front right

speaker.

F-LR: The sound outputs from the front left and front right

speaker.

About the Hands-Free Phone

45-EN

Answering a Call

Incoming calls are announced by the received call ring tone and a

displayed message (Caller name/PHONE No.).

Touch [ ].

The call starts.

•Indicator (Signal Strength):

While calling, the indicator will display the current signal strength of

your mobile phone. While in a mode other than Calling, the unit

cannot read the signal strength of the mobile phone exactly. In this

case, the indicator displays the signal strength of the last call.

•When “Setting the Received Calls automatically (Auto Answer)”

(page 44) is set to ON, you can receive a call automatically.

•While calling, the source sound on the unit is muted.

After calling, playback will resume.

Hanging up the Telephone

Touch [ ].

The call finishes.

Adjusting the volume when receiving a

Call

While calling, you can adjust the volume. The adjusted volume level is

stored.

Turn the Rotary encoder to adjust the volume.

•You may need to increase volume from your regular audio listening

source level. However, increasing the volume excessively may result

in feedback. If feedback is noticed as feedback is directly related to

the volume, turn down the volume as low as acceptable to eliminate

it. Positioning the microphone in a direction away from the main car

speakers (e.g. clipped on sun visor) may also reduce feedback at high

volume.

Redial Function

You can redial the person you have previously called.

After finishing a call, touch [ ] on the screen within

5 seconds.

The telephone is redialed.

Call waiting function

If a second call is received during a current call, you can have the first

caller wait momentarily while you take the second call. When you are

finished with one call, you can switch to the other one.

If a second call is received during the current call

(caller1), the number of second caller (caller2) is

displayed instead of the current caller’s information.

Touch [ ], the call waiting mode is activated.

In this case, caller1 is on hold, while you take caller2.

Display example for the 2nd incoming call screen

Second call message

Hang up the first call and the second incoming call is

answered.

Hang up the second incoming call.

Display example for the 2nd incoming call screen

Feedback of the connected second call

By touching [ ] on the call waiting screen,

you can switch between the calling person and the

person on hold.

46-EN

Call Switching Operation

While making a call, this function allows you to initiate the transfer of

the audio between the mobile phone and the speakers in the car.

While calling, touch [ ] to switch the call sound

between the unit and mobile phone.

•Depending on the mobile phone, this operation may not be

performed.

Call History

Call History is recorded for the last dialed/received/missed calls. There

are various ways of making calls based on the “Call History”. The

following steps 1 to 2 are common to the various ways of making these

calls. For details, refer to each individual category for making calls.

Check that “HFP” or “HFP+Audio” is selected in

“Setting the BLUETOOTH Connection (BLUETOOTH

IN)” (page 41).

Press .

The Telephone Menu screen is displayed.

Display example for Telephone Menu screen

•During SOURCE selection screen, you can also switch to Telephone

Menu screen by touching [Phone] icon.

Touch the title bar of the desired item to place the

call.

Setting items:

When “BT Menu Language” is set to “EN”, the Telephone Menu is

displayed as:

Dialled Numbers / Received Calls / Missed Calls / Phone Book /

Dial Input / Voice Dial

When “BT Menu Language” is set to “DE”, the Telephone Menu is

displayed as:

Gewählte Nummern / Angenommene Anrufe / Verpasste

Anrufe / Telefonbuch / Nummer wählen / Sprachwahl

When “BT Menu Language” is set to “ES”, the Telephone Menu is

displayed as:

Llamadas Realizadas / Llamadas Recibidas / Llamadas

Perdidas / Agenda / Marcación Directa / Marcación por Voz

When “BT Menu Language” is set to “FR”, the Telephone Menu is

displayed as:

Numéros composés / Appels reçus / Appels manqués /

Répertoire / Clavier / Composition vocale

When “BT Menu Language” is set to “IT”, the Telephone Menu is

displayed as:

Chiamate Effettuate / Chiamate Ricevute / Chiamate Perse /

Rubrica / Tastiera / Chiamata Vocale

When “BT Menu Language” is set to “NL”, the Telephone Menu is

displayed as:

Gekozen nummers / Ontvangen oproepen / Gemiste oproepen /

Telefoonboek / Manuele ingave / Voice Dial

When “BT Menu Language” is set to “RU”, the Telephone Menu is

displayed as:

Набранные номера / Принятые вызовы / Пропущенные

вызовы / Телефонная книга / Набор номера / Голосовой

набор

When “BT Menu Language” is set to “TH”, the Telephone Menu is

displayed as:

/ / / /

•For details, refer to “Setting the BLUETOOTH Menu language” on

page 44.

•It may take some time for the list to be displayed, and also directly

after connection, the list may not be brought up to date.

Touch [ ] to return to the previous screen.

Touch [Exit] to return to the main source screen that was

displayed before the setup operation was started.

•If you place a call directly from the paired mobile phone, the phone

number is not displayed, you cannot redial from the unit in this case.

Previously dialed telephone numbers are stored in dialed calls history.

You can redial a number by searching from dialed calls history.

Setting item: Dialled Numbers

Touch [Call] of the person name or the telephone

number you want to call from the Dialed Calls list.

The call is placed.

Telephone numbers from received calls are stored in the received calls

history. You can redial these numbers by searching here.

Setting item: Received Calls

Touch [Call] of the person name or the telephone

number you want to call from the Received Calls list.

The call is placed.

Telephone numbers for received calls that are missed, are stored in the

missed calls history. You can redial these numbers by searching here.

Setting item: Missed Calls

Touch [Call] of the person name or the telephone

number you want to call from the Missed Calls list.

The call is placed.

Redialing a Number in Dialed Calls History

Dialing a Number in Received Calls History

Dialing a Number in Missed Calls History

47-EN

Up to 1,000 telephone numbers are downloadable to the BLUETOOTH

compatible unit from a mobile phone. Dial a call by selecting a person

from the phone book list.

Setting item: Phone Book

Scroll the list one line at a time by touching [ ] or [ ].

Scroll the list one page at a time by touching [ ] or [ ].

Activate alphabet search function. For details, refer to

“Alphabet Search Function” on page 47.

Touch [Call] of the person name or the telephone

number you want to call from the Phone Book list.

The call is placed.

•If one name has several numbers registered in the telephone book,

choose and touch [Call] of the desired number after touching the

name, the telephone will be called. Touch [Call] of the name directly,

the default number of the name will be called. Depending on the

connected mobile phone, this function may not be performed.

•If a name cannot be obtained via the phone book, only the telephone

number (default number) is displayed. If both name and number

cannot be obtained, “ID UNSENT” will be displayed.

•If the call history or phonebook of the mobile phone is added or

deleted while it is connected to the unit, the list displayed on the unit

may not be brought up to date. If it is not updated, you cannot

correctly place a call.

Alphabet Search Function

You can search for a desired name in phone book list by its’

initial letter.

During Phone Book mode, touch [ALPHABET].

The Alphabet search screen is displayed.

Display example for Alphabet Search screen

When Mode2 is set in “Changing the Russian Font”

(page 38), [Cyrillic] button will appear. Touch [Cyrillic] to

change to Russian font keypad screen. Touch [ABC] to

return to normal alphanumeric keypad screen.

Touch the desired number or letter.

The numbers/names stored in phone book which begin with

the selected number/letter are searched.

•This function is also applicable for iPod/USB search mode.

Preset a number in the Phone Book (Shortcut Dial)

Assign numbers that you dial frequently to presets for quick

recall.

Touch a name or number you want to preset from the

Phone Book list.

Touch [Preset].

A “Save as Preset (No)” pop-up screen is displayed.

The phone number you selected is stored in presets.

•You can delete the preset shortcut dial number. For details, refer to

“Deleting a preset number from the Shortcut Memory” on page 44.

•A total of 5 phone numbers can be stored in the preset memory for

each mobile phone in the paired device list. If a mobile phone is

deleted from the paired device list, the stored preset numbers of this

mobile phone are deleted, even when it is paired again.

Dialing the preset number

During Telephone Menu screen, touch any one of preset

buttons (1 through 5) that has had a preset number

stored in the Phone Book mode.

The stored preset number is dialed directly.

Dialing a Number In the Phone Book

(Phone Book)

Display example for Phone book screen

48-EN

You can place a call by inputting the telephone number directly by the

numeric keypad screen on the unit.

Setting item: Dial Input

Display example for the Dial Input screen

The numeric keypad screen is displayed. Touch (input)

the telephone number, and then touch [Call].

The call is placed.

•About the numeric keypad

[]: closes the numeric keypad input screen.

[Delete All]: deletes all input numbers.

[]: deletes a previous number.

You can call the telephone by performing voice operation.

Setting item: Voice Dial

Touch [ ] to display the item of Voice Dial.

Touch the title bar of Voice Dial.

A message is displayed.

•You can also activate Voice Dial mode directly by pressing and

holding for at least 2 seconds.

Touch [Yes] to activate the voice dial mode.

The voice dial mode is activated.

•Touch [No] will return to the Telephone Menu screen.

Say the telephone number*, name* you want to call

into the microphone.

* The number and name depend on the voice dial information stored in

the mobile phone.

•If the voice dial fails, the unit will return to normal mode in 30

seconds.

•You can perform this operation only when a voice dial compatible

mobile phone is connected. If the mobile phone is not compatible

with the voice dial, “No Support” is displayed for 2 seconds.

•The Voice Dial function performance depends on the recognition

range of the mobile phone and mounting location of the microphone.

Note when the microphone is mounted.

•Voice dial operation depends on the function of the mobile phone.

For details, refer to the Owner’s Manual of the mobile phone.

BLUETOOTH Audio Function

Audio information of a BLUETOOTH compatible mobile phone, a

portable player, etc., is controllable/playable wirelessly* from this unit.

* To play back audio, a mobile phone or a portable player conforming

to A2DP (Advanced Audio Distribution Profile) or AVRCP (Audio/

Video Remote Control Profile) is required.

Not all functions work with all devices.

•During a call, sound on the BLUETOOTH audio source is muted.

•There are times when it cannot be operated with the device which you

use.

Recalling the BLUETOOTH audio source

Press SOURCE/ .

The SOURCE selection screen is displayed.

Touch the [BT Audio] icon.

The BT Audio source is activated and the display changes

to the BT Audio main screen.

Selecting the desired Song

Touch [ ].

Returns the beginning of the song being played back.

Touch [ ].

Forwards the next song.

Touching and holding [ ] or [ ] will fast backward/fast

forward track continuously.

Pausing

Touch [/].

A playback stops. Touching again will resume a playback.

Dialing a Number Using Direct Dial Input

Voice Dial Operation

BLUETOOTH Audio Operation

49-EN

When an optional rearview camera is connected, rear view video can be

output to the monitor.

•Be sure to set “Camera IN” to “ON” before using the Rearview

Camera, refer to “Setting the Rear Camera Input” on page 39.

Switching the Rear Camera Screen

(Optional)

The rear view video will be displayed for the two situations as below.

Shift the gear lever to the reverse (R) position.

The rear view image is displayed while the car remains in

reverse.

If you shift the gear lever to a position other than

reverse (R), the monitor returns to the previous

screen.

•Be sure to also check behind the car visually. Use the camera image

to assist in showing conditions behind the car.

•This function is effective when the reverse wire is properly connected.

•No sound output during Camera view display when ON is set in

“Camera mute setting” (page 40).

Press SOURCE/ .

The SOURCE selection screen is displayed.

Touch [Camera].

The Camera mode is activated and the rear view video is

displayed.

Touch [Guide ON] or [Guide OFF] to set whether

the rear camera guide line is displayed.

Touch [ ] to access to Visual selection screen, and

then touch [Normal] to return to previous main

screen.

Switching the Navigation Screen

(Optional)

If an optional Alpine Navigation System is connected to the

IVE-W530BT, the Navigation screen can be displayed on this unit.

Press SOURCE/ .

The SOURCE selection screen is displayed.

Touch [Nav.].

The Navigation screen is displayed.

The operation is possible with the supplied navigation

remote control.

For navigation operation, refer to the Owner’s Manual of the

navigator.

•You can touch [V.Sel] to activate the Visual Sel. screen, and then

touch [Nav.]. The navigation mode is activated from the Visual Sel.

mode without interrupting normal audio. For details, refer to

“Switching the Visual Source Only (Simultaneous Function)” on

page 30.

•You can also directly access to Navigation screen by pressing

[] on main source screen. For details, refer to “Recalling the

Source” on page 13.

•If the Navigation mode menu is not displayed on the main menu

screen, select ON in “Setting the Navigation Mode” (page 40).

•When the Navigation System is on and in guidance mode, the voice

prompts and navigation map interrupts the current audio source.

Rearview Camera

Operation (Optional)

Displaying the rear view video while the

car is in reverse

Displaying the rear view video manually

Navigation System

(Optional)

50-EN

Operating Auxiliary Devices (Optional)

To operate your devices connected to the AUX1, AUX2 or Front AUX

terminals, follow the procedure described below.

•If you try to activate the auxiliary device while driving, the display

will show the warning-Picture off for your safety.

Press SOURCE/ .

The SOURCE selection screen is displayed.

Touch [Aux-1]*, [Aux-2] or [Front AUX].

The external input screen is displayed.

Touch [NTSC/PAL] to change the video input.

This step is not applicable to Front AUX mode.

* The name which is given as the source name in “Setting the AUX

Mode” on page 40 is displayed.

•If the AUX mode is not displayed on the main menu, set AUX1 IN to

ON or AUX2 IN to AUX by following “Setting the AUX Mode”

(page 40). Or set AUX Front to ON by following “Setting the AUX

Front Mode” on page 41.

•The setting of switching NTSC/PAL, which you have set in this

section, can be used in same way in “Setting the AUX Mode” on

page 40.

•The display mode changes by touching [WIDE].

For operation, refer to “Switching Display Modes” on page 30.

Operating the TUE-T200DVB (Optional)

Operable when optional TUE-T200DVB is connected.

When DVB-T is selected in “Setting the AUX Mode” (page 40), the

source is displayed in SOURCE selection screen.

While your vehicle is parked, press SOURCE/ .

The SOURCE selection screen is displayed.

Touch [DVB-T].

The DVB-T screen is displayed.

Perform the desired operation.

Channel Number UP/Down or Favourite Channel Number

Up/Down

Touch [CH.]* to select changing the Channel or the Favourite

Channel.

Touch CH. [ ] or [ ] to move the Channel number Up/Down.

Touch FAV [ ] or [ ] to move the Favourite Channel number

Up/Down.

* The button displays the current changing mode ([CH.] or [FAV]).

Calling up Main Menu Screen

Touch [MENU] to call up the main menu screen.

Calling up Menu Operation Mode

Touch [MENU CONT] to call up the menu operation mode.

Switching the Source

Touch [A/V].

The source switches with each touch.

Calling up Electronic Programme Guide (EPG)

Touch [EPG] to call up the Electronic Programme Guide.

Auxiliary Device

(Optional)

WARNING

It is dangerous for the driver to watch the TV/Video

while driving the vehicle. The driver may be distracted

from looking ahead and an accident could occur.

Install the IVE-W530BT correctly so that the driver

cannot watch TV/Video unless the vehicle is stopped

and the emergency brake is applied.

If the IVE-W530BT is not installed correctly, the driver

will be able to watch the TV/Video while driving the

vehicle and may be distracted from looking ahead and

cause an accident. The driver or other people could

be severely injured.

TUE-T200DVB

Operation (Optional)

51-EN

Scanning Mode

Touch [P1/3].

The function guide appears.

Touch [SCAN] to start the auto scan procedure.

•For detail, refer to the Owner’s Manual of the TUE-T200DVB (sold

separately).

Video Menu Operation of TUE-T200DVB

Touch [P1/3] twice.

The direct touch mode screen is displayed.

•When the optional TUE-T200DVB is connected, you can control it by

the touch key (except the [Control] key) on the display screen of the

unit.

Touch [Control].

Return to DVB-T main screen.

•If no operation is performed for 5 seconds, the screen will

automatically switch to the full screen mode.

A USB memory can be connected to this unit through the USB

Connector of this unit.

If a USB memory device is connected to the unit, MP3/WMA/AAC/

DivX files of USB memory can be played back.

BANK Function

What is a Bank?

A bank is a unit of up to 1,000 songs, which is stored in memory.

“Banking” refers to the grouping of songs available in USB

Memory, in banks of 1,000 songs each.

About Banking

While a bank is being built up, “Banking” is displayed. Banking

occurs whenever a USB Memory device is connected or after

power to the head unit turns on.

It can take anywhere from a few seconds to up to several

minutes for banking to complete. This depends on the number

of files and folders in USB Memory.

This unit has the BANK function that automatically divides every 1,000

songs stored in USB memory into individual banks to make searching

and playing back a song easier. A maximum of 1,000 songs for one

bank can be stored according to the order stored in USB memory. A

maximum of 20 banks (20,000 songs) can be recognised. BANK1

(songs 1 to 1,000) is set as the default. If you want to search beyond

1,000 songs, perform the following operation to select a different bank.

Touch [P1/2] to change the function guide.

Touch BANK [ ] or [ ] to select the desired

BANK.

Each operation can be performed in the selected bank.

•Even if the files are contained in the same folder, they may be saved

as different BANK.

USB Memory

(Optional)

BANK No. Song number

BANK1 1~1,000

BANK2 1,001~2,000

...

BANK20 19,001~20,000

52-EN

Playback

Press SOURCE/ .

The SOURCE selection screen is displayed.

Touch [USB], the USB mode is activated and the

display changes to the USB screen.

Touch [ ] or [ ] to select the desired track

(file) within current Bank.

Returning to the beginning of the current track (file):

Touch [ ].

Fast backward:

Touch and hold [ ].

Advancing to the beginning of the next track (file):

Touch [ ].

Fast forward:

Touch and hold [ ].

•If the next/previous file is a video file or during repeat play mode,

fast-forward/fast-backward only applies to current file.

•If the Playlist search mode was used to select a song, fast-forward/

fast-backward only applies to current file.

•Fast-forward/fast-backward is valid in current folder.

To pause playback, touch [ /].

Touching [/] again will resume playback.

•Any file protected by DRM (Digital Rights Management) copy

protection, cannot be played back on this unit.

•The playback time may not be correctly displayed when a VBR

(Variable Bit Rate) recorded file is played back.

•If there is tag information, artist name/album name/track name is

displayed.

•Touch [10KEY] to activate direct search mode. For operations, refer

to “Numeric Keypad Input Operation” on page 23.

•ID3 tag/WMA tag

If an MP3/WMA/AAC file contains ID3 tag/WMA tag information,

the ID3 tag/WMA tag information is displayed (e.g., song name,

artist name, and album name). All other tag data is ignored.

•Nothing will be displayed when text information is not compatible

with this unit.

•This unit plays back DivX files in the USB Memory with the same

controls and modes as playback of DVD containing DivX. For

details, refer to “DVD” on page 21.

Repeat Play

The Repeat function of the USB Memory is displayed as on the

IVE-W530BT.

Repeat One : A single song is repeatedly played back.

Repeat Folder : Only files in a folder are repeatedly played

back.

Touch [P1/2].

The function guide is displayed.

Touch [ ].

The file will be played repeatedly.

To cancel repeat play, touch [ ].

Random Play Shuffle (M.I.X.)

The Shuffle function of the USB memory is displayed as on the

IVE-W530BT.

Shuffle Folder :

Only files in a folder are played back in random sequence in the

M.I.X. Folder mode.

Shuffle ALL :

Song shuffle randomly plays back within the selected Bank.

Touch [ ] after touching [P1/2].

The songs will be played back in random sequence.

(off)

(Shuffle Folder) (Shuffle ALL)

To cancel M.I.X. play, touch [ ].

(off)

(Repeat One) (Repeat Folder)

53-EN

Searching for a desired Song

A USB memory can contain hundreds of songs. By keeping these songs

organised in playlists, this unit can use these to ease song searches.

Using the search mode’s individual hierarchy, you can narrow down

your search as shown in the table below.

* Only files with an “m3u” extension pertain to Playlist search.

For example: Searching by Playlist name

The following example explains how a Playlist search is performed.

Another search mode can be used for the same operation, although the

hierarchy differs.

Touch [ ].

The search mode is activated, and the search list screen

appears.

Touch the title bar of Playlists.

The Playlist search screen is displayed.

Select the desired playlist.

To play back the playlist directly

1 Touch [ ] next to the playlist’s name.

All files of the selected playlist are played back.

To search for the file of a playlist

1 Touch the title bar of the selected playlist.

The Files search screen of the selected playlist is displayed.

2 Touch [ ] next to the desired file’s name.

The selected file is played back.

•In the search mode, you can scroll the list one page at a time by

touching [] or [ ].

•In the search mode, a search can be made quickly by Alphabet search

function to find the desired playlist or file, etc. For details, refer to

“Alphabet Search Function” on page 47.

Selecting the desired Playlist

Touch [ ] or [ ] to select the desired Playlist.

Select the desired Folder (Folder up/

down)

If you listen to a file from a selected folder, the folder can be changed.

Touch [ ] or [ ] to select the folder.

Hierarchy 1 Hierarchy 2

Playlists*Files

Folders Files

Files —

Searching by Playlist name

54-EN

Connecting an iPod/iPhone

An iPod/iPhone can be connected to this unit, by using the USB

connection cable. When this unit is connected by using the cable, the

controls on the iPod are not functional.

•Other applications (Internet function, etc.) of the iPhone or

iPod touch are not controllable from the unit; however, these

functions can be controlled from the iPhone or iPod touch

itself.

•An iPhone connected to this unit operates as an iPod. The

iPhone can be used as a hands-free device using the

integrated Bluetooth module.

•Video is only viewable from a video capable iPhone/iPod. The

AUX2 IN must be set to “iPod Video” (see “Setting the AUX

Mode” on page 40), and the Parking Brake must be

engaged.

•For automatic transmission vehicles, place the transmission lever in

the Park position.

iPod/iPhone models usable with this unit

•Confirmed devices regarding Made for iPod. Correct function

of earlier versions cannot be guaranteed.

iPod touch (4th generation): Ver. 5.1

iPod nano (6th generation): Ver. 1.2

iPod touch (3rd generation): Ver. 4.2.1

iPod nano (5th generation): Ver. 1.0.2

iPod classic (160 GB) (Late 2009): Ver. 2.0.4

iPod touch (2nd generation): Ver. 4.2.1

iPod nano (4th generation): Ver. 1.0.4

iPod classic (120 GB): Ver. 2.0.1

iPod touch (1st generation): Ver. 3.1.3

iPod nano (3rd generation): Ver. 1.1.3

iPod classic (80 GB, 160 GB): Ver. 1.1.2

iPod nano (2nd generation): Ver. 1.1.3

iPod with video: Ver. 1.3

iPod nano (1st generation): Ver. 1.3.1

•Confirmed devices regarding Works with iPhone. Correct

function of earlier versions cannot be guaranteed.

iPhone4S: Ver. 5.1

iPhone4: Ver. 5.1

iPhone 3GS: Ver. 5.1

iPhone 3G: Ver. 4.2.1

iPhone: Ver. 3.1.3

•For clarity in identifying your model of iPod, please see

Apple’s own document “Identifying iPod models” at

http://support.apple.com/kb/HT1353.

Setting the iPod Control

When an iPod/iPhone is connected, operate it from its own controls or

from the head unit.

Touch [ App] after touching [P1/2] on the iPod

mode screen.

“App Mode” appears on the upper left corner of the screen.

In the App Mode screen, touching [ App] again

will switch to the HU mode.

“ iPod” appears on the upper left corner of the screen.

•When using the App Mode, make sure the USB 30P cable is

connected to the iPod(V)/AUX Input Connector correctly by using the

AV extension cable.

For “ iPod”: Operate the iPod/iPhone via this unit.

For “App Mode”: Operate the iPod/iPhone using its own

controls. When App Mode is selected, all function guide except

[ App] and [WIDE] (video mode only) will disappear.

•Depending upon the iPod used, App Mode may not be selectable. Or,

if iPod is selected, operation must still be from the head unit.

Playback

Press SOURCE/ .

The SOURCE selection screen is displayed.

Touch [iPod].

The display shows the iPod mode screen.

Touch [ ] or [ ] to select the desired song.

Return to the beginning of the current song:

Touch [ ].

Fast backward the current song:

Touch and hold [ ].

Advance to the beginning of the next song:

Touch [ ].

Fast forward the current song:

Touch and hold [ ].

To pause playback, touch [ / ].

Touching [ / ] again will resume playback.

iPod/iPhone

(Optional)

55-EN

•If a song is playing on the iPod/iPhone when it is connected to this

unit, it will continue playing after the connection.

•If the artist, album, genres, composers, titles, created in iTunes, has

too many characters, songs may not be played back when connected

to this unit. Therefore, a maximum of 64 characters is recommended.

The maximum number of characters for the head unit is 66 (64 byte).

•Some characters may not be correctly displayed.

•If an iPhone or a video-compatible iPod is connected, touching

[WIDE] on the function guide will change the display mode. For

operation, refer to “Switching Display Modes” (page 30).

•If you listen to an episode from a selected podcast or audiobook, the

episode can be changed by pressing [] (Episodes) [ ] or [ ].

•An episode may have several chapters. The chapter can be changed

by pressing [] or [ ].

Searching for a desired Song

An iPod/iPhone can contain hundreds of songs. By keeping these songs

organized in playlists, this unit can use these to ease song searches.

Using the search mode’s individual hierarchy, you can narrow down

your search as shown in the table below.

•Video search mode depends on the iPod/iPhone. If the specification

of the iPod/iPhone is changed, the search mode on this unit will also

be changed.

For example: Searching by Artist name

The following example explains how an Artist search is performed.

Another search mode can be used for the same operation, although the

hierarchy differs.

Touch [ ].

The search mode is activated, and the search list screen

appears.

Touch the title bar of Music.

The Music search screen is displayed.

•If Video mode is selected, the Video playlists/Movies/Music Videos/

TV Shows/Video Podcasts search mode may be used depending on

the connected iPod/iPhone (Only for iPhone or iPod compatible

Video).

•If you want to select Video search mode, set AUX2 IN to iPod Video in

advance. Refer to “Setting the AUX Mode” on page 40.

Touch the title bar of Artists.

The Artist search screen is displayed.

Select the desired artist.

To play back the artist directly

1 Touch [ ] next to the artist’s name.

All songs of the selected artist are played back.

To search for the album of an artist

1 Touch the title bar of the selected artist.

The Album search screen of the selected artist is displayed.

2 Touch [ ] next to the desired album’s name.

All songs of the selected album are played back.

To search for a song in the album of an artist

1 Touch the title bar of the desired album in “To search for the

album of an artist” in step 2.

The Song search screen of the selected album is displayed.

2 Touch [ ] next to the desired song’s name.

The selected song is played back.

•Touching [ ] of ALL will play back all songs in the list when you

are in a hierarchy with an asterisk* (see table on the left column).

•Touching the title bar of ALL will display the search list in the next

hierarchy.

•If Alphabet search Function is activated in the search mode, a search

can be made quickly by Alphabet search function to find the desired

artist or song, etc. For details, refer to “Alphabet Search Function”

on page 47.

•When search is made during M.I.X. play, the M.I.X. play mode will be

cancelled.

•In search mode, touch [ ] to return to the previous menu.

•In search mode, touch [Exit] to return to iPod main screen.

Selecting Playlist/Artist/Album/Genre/

Composer/Episode/Category

Playlist/Artist/Album/Genre/Composer/Episode/Category* can be

easily changed.

For example, if you listen to a song from a selected album, the album

can be changed.

Press [ ] or [ ] to select the desired

(Playlist) / (Artist) / (Album) /

(Genre) / (Composer) / (Episode) /

Category*.

* Category can be changed only when playback the video files of

iPod/iPhone.

•If search selection mode is not activated, a Song search is not

possible.

•During shuffle (M.I.X.) playback, this operation is not possible.

•If Playlist/Artist/Album/Genre/Composer/Episode are not searched,

this operation is not possible.

Hierarchy 1 Hierarchy 2 Hierarchy 3 Hierarchy 4

Playlists Songs — —

Artists*Albums*Songs —

Albums*Songs — —

Songs ———

Podcasts Episodes — —

Genres*Artists*Albums*Songs

Composers*Albums*Songs —

Audiobooks ———

Searching by artist name

56-EN

Random Play Shuffle (M.I.X.)

The Shuffle function of the iPod is displayed as on the

IVE-W530BT.

Shuffle Albums :

Album shuffle playback plays back all songs in order, then

randomly selects the next album. All songs of that album are

played back in order, and so on. Any one album is played just

once.

Shuffle Songs :

Song shuffle randomly plays back certain selected songs. Any

one song plays back just once until all songs have been played

back.

Touch [ ] after touching [P1/2].

To cancel M.I.X. play, touch [ ].

•If a song is selected in the album search mode before selecting

Shuffle (M.I.X.), the songs will not play back randomly even when

Shuffle album is selected.

Repeat Play

Only Repeat One is available for the iPod.

Repeat One: A single song is repeatedly played back.

Touch [P1/2].

The function guide is displayed.

Touch [ ].

The file will be played repeatedly.

To cancel repeat play, touch [ ].

•Depending on the connected iPod, track up/down may be not

available during Repeat play.

About DVDs

Music CDs and DVDs have grooves (tracks) in which the digital

data is recorded. The data is represented as microscopic pits

recorded into the track – these pits are read by a laser beam to

play the disc. On DVDs, the density of the tracks and pits is

twice that of CDs, so DVDs can contain more data in less space.

A 12 cm disc can contain one movie or about four hours of

music.

In addition, DVDs provide sharp picture quality with vivid colours

thanks to a horizontal resolution of over 500 lines (compared to less

than 300 for VHS tape).

In addition, DVDs offer a variety of functions.

Multiple audio* (page 26)

Movies can be recorded in up to eight languages. The desired

language can be selected from the unit.

Subtitles function* (page 26)

Movies can include subtitles in up to 32 languages. The desired

subtitle language can be selected from the unit.

Multi angle function* (page 26)

When the DVD contains a movie shot from multiple angles, the

desired angle can be selected from the unit.

Multi story function*

With this function, a single movie includes various story lines.

You can select different story lines to view various versions of the

same movie.

Operation differs from disc to disc. Story line selection screens

including instructions appear during the movie. Just follow the

instructions.

* The functions audio languages, subtitle languages, angles, etc., differ

from disc to disc. For details, refer to the disc’s instructions.

(Shuffle Albums)

(Shuffle Songs)

(off)

(Repeat One) (Repeat the list

being played back)

Information

CDs

Minimum pit

length -

0.9 µm 1.2 mm Track pitch -

1.6 µm

DVDs

Minimum pit

length -

0.9 µm

0.6 mm Track pitch -

0.74 µm

0.6 mm

57-EN

List of Language Codes

(For details, see page 32.)

Language

Romanian

Russian

Sanskrit

Sindhi

Serbo-Croatian

Singhalese

Slovak

Slovenian

Samoan

Shona

Somali

Albanian

Serbian

Sundanese

Swedish

Swahili

Tamil

Te l ugu

Tajik

Thai

Tigrinya

Turkmen

Tagalog

To n g a

Turkish

Tatar

Tw i

Ukrainian

Urdu

Uzbek

Vietnamese

Volapuk

Wolof

Xhosa

Yo r uba

Chinese

Zulu

Abbreviation

Language

Afar

Abkhazian

Afrikaans

Amharic

Arabic

Assamese

Aymara

Azerbaijani

Bashkir

Byelorussian

Bulgarian

Bihari

Bislama

Bengali, Bangla

Tibetan

Breton

Catalan

Corsican

Czech

Welsh

Danish

German

Bhutani

Greek

English

Esperanto

Spanish

Estonian

Basque

Persian

Finnish

Fiji

Faroese

French

Frisian

Irish

Scots Gaelic

Galician

Guarani

Gujarati

Hausa

Hindi

Croatian

Hungarian

Armenian

Interlingua

Code

6565

6566

6570

6577

6582

6583

6589

6590

6665

6669

6671

6672

6673

6678

6679

6682

6765

6779

6783

6789

6865

6869

6890

6976

6978

6979

6983

6984

6985

7065

7073

7074

7079

7082

7089

7165

7168

7176

7178

7185

7265

7273

7282

7285

7289

7365

Abbreviation

Code

7375

7378

7383

7384

7465

7473

7487

7565

7575

7576

7577

7578

7579

7583

7585

7589

7665

7678

7679

7684

7686

7771

7773

7775

7776

7778

7779

7782

7783

7784

7789

7865

7869

7876

7879

7982

8065

8076

8083

8084

8185

8277

Language

Inupiak

Indonesian

Icelandic

Italian

Japanese

Yiddish

Javanese

Georgian

Kazakh

Greenlandic

Cambodian

Kannada

Korean

Kashmiri

Kurdish

Kirghiz

Latin

Lingala

Laothian

Lithuanian

Latvian, Lettish

Malagasy

Maori

Macedonian

Malayalam

Mongolian

Moldavian

Marathi

Malay

Maltese

Burmese

Nauru

Nepali

Dutch

Norwegian

Oriya

Punjabi

Polish

Pashto, Pushto

Portuguese

Quechua

Rhaeto-Romance

Abbreviation

Code

8279

8285

8365

8368

8372

8373

8375

8376

8377

8378

8379

8381

8382

8385

8386

8387

8465

8469

8471

8472

8473

8475

8476

8479

8482

8484

8487

8575

8582

8590

8673

8679

8779

8872

8979

9072

9085

58-EN

In Case of Difficulty

Basic

No function or display.

• Vehicle’s ignition is off.

- If connected according to the instructions, the unit will not

operate with the vehicle’s ignition off.

• Improper power lead connections.

- Check power lead connections.

•Blown fuse.

- Check the fuse on the battery lead of the unit; replace with the

proper value if necessary.

• Blackout mode is activated.

- Cancel Blackout mode.

No sound or unnatural sound.

• Incorrect setting of volume/balance/fader controls.

- Readjust the controls.

• Connections are not properly or securely made.

- Check the connections and firmly connect.

Screen not displayed.

• Brightness control is set at the minimum position.

- Adjust the Brightness control.

• Temperature in the vehicle is too low.

- Increase the vehicle’s interior temperature to operation

temperature range.

• Connections to the DVD, CD player, and navigation system are

not securely made.

- Check the connections and firmly connect.

Movement of displayed picture is abnormal.

• Temperature in the vehicle is too high.

- Allow the vehicle’s interior temperature to cool.

Unclear or noisy display.

• Fluorescent plate is worn out.

- Replace the fluorescent plate.

Navigation system inoperative.

• Connections to the navigation system are incorrect.

- Check the connections with the navigation system and connect

the cables correctly and firmly.

Unclear picture display.

• Fluorescent tube is exhausted.

- Replace the fluorescent tube*.

* The fluorescent tube replacement is not free of charge even within the

warranty period, for the tube is an article of consumption.

Radio

Unable to receive stations.

• No antenna, or open connection in the antenna cable.

- Make sure the antenna is properly connected; replace the

antenna or cable if necessary.

Unable to tune stations in the seek mode.

• You are in a weak signal area.

- Make sure the tuner is in DX mode.

• If the area you are in is a primary signal area, the antenna may

not be grounded and connected properly.

- Check your antenna connections; make sure the antenna is

properly grounded at its mounting location.

• The antenna may not be the proper length.

- Make sure the antenna is fully extended; if broken, replace the

antenna with a new one.

Broadcast is noisy.

• The antenna is not the proper length.

- Extend the antenna fully; replace it if it is broken.

• The antenna is poorly grounded.

- Make sure the antenna is grounded properly at its mounting

location.

• The station signal is weak and noisy.

- If above solution does not work, tune in another station.

CD/MP3/WMA/AAC/DVD

Disc playback sound is wavering.

• Moisture condensation in the disc Module.

- Allow enough time for the condensation to evaporate (about 1

hour).

Disc insertion not possible.

• A disc is already in the DVD player.

- Eject the disc and remove it.

• The disc is being improperly inserted.

- Make sure the disc is being inserted following the instructions

in the CD/MP3/WMA/AAC, DVD Player Operation section.

Unable to fast forward or reverse the disc.

• The disc has been damaged.

- Eject the disc and discard it; using a damaged disc in your unit

can cause damage to the mechanism.

Disc playback sound skips due to vibration.

• Improper mounting of the unit.

- Securely re-mount the unit.

• Disc is very dirty.

- Clean the disc.

• Disc has scratches.

- Change the disc.

• The pick-up lens is dirty.

- Do not use a commercial available lens cleaner disc. Consult

your nearest ALPINE dealer.

Disc playback sound skips without vibration.

• Dirty or scratched disc.

- Clean the disc; damaged disc should be replaced.

CD-R/CD-RW playback not possible.

• Close session (finalisation) has not been performed.

- Perform finalisation and attempt playback again.

Error displays

• Mechanical error

- Press . After the error indication disappears, insert the disc

again. If the above-mentioned solution does not solve the

problem, consult your nearest ALPINE dealer.

If you encounter a problem, please turn the power off, then on again.

If the unit is still not functioning normally, please review the items

in the following checklist. This guide will help you isolate the

problem if the unit is at fault. Otherwise, make sure the rest of your

system is properly connected, or then consult your authorized

Alpine dealer.

59-EN

MP3/WMA/AAC is not played back.

• Writing error occurred. The CD format is not compatible.

- Make sure the CD has been written in a supported format.

Refer to “About MP3/WMA/AAC” (pages 19 and 20), then

rewrite in the format supported by this device.

Unit does not operate.

• Monitor’s power is not turned on.

- Turn on the monitor’s power.

• Condensation.

- Wait a while (about 1 hour) for the condensation to dry.

No picture is produced.

• Monitor’s mode is not switched to the mode you want to see.

- Switch to the mode you want to see.

• Monitor’s parking brake lead is not connected.

- Connect the monitor’s parking brake wire and set the parking

brake.

(For details, refer to the monitor’s instructions.)

Playback does not start.

• Disc is loaded upside-down.

- Check the disc and load it with the labelled side facing upward.

•Disc is dirty.

- Clean the disc.

• A disc not able to play back with this unit is loaded.

- Check if the disc is able to be played back.

• Parental lock is set.

- Cancel the parental lock or change the rating level.

Picture is unclear or noisy.

• Disc is being fast-forwarded or fast-reversed.

- The picture may be slightly disturbed, but this is normal.

• Vehicle’s battery power is weak.

- Check the battery power and wiring.

(The unit may malfunction if the battery power is under 11

volts with a load applied.)

• Monitor’s fluorescent tube is worn.

- Replace the monitor’s fluorescent tube.

Image stops sometimes.

• Disc is scratched.

- Replaced with a non-scratched disc.

Playing back a DRM protected DivX® File

Some operations cannot be performed while displaying the

following message.

“Authorization Error This player is not authorized to play

this video.”

• If an unauthorized DRM protected DivX® file is played back,

the following message is displayed for 2 seconds:

“Authorization Error This player is not authorized to play this

video”. This means the file’s registration code does not match

the player’s and cannot be played back. After the message has

been displayed, the beginning of the next file will automatically

begin playing.

“Rental expired”

• A DivX® rental is set for a fixed number of viewings. If viewing

time has counted down to 0, “Rental expired” is displayed for 2

seconds. This indicates that the file can no longer be played.

After the message has been displayed, the beginning of the next

file will automatically begin playing.

“Rental Countdown OK?”

• While playing back a rental file, if B.SKIP or ENTER is selected

in the file selection menu, “Rental Countdown OK?” is

displayed. The rental file playback is interrupted (viewing time

is reduced by 1). To confirm stopping playback, touch [Yes], or

touch [No] to continue playing the file.

“View DivX® VOD Rental

This rental has (remaining times) views left.

Do you want to use one of your (remaining times) views

now?”

• If audio/visual times still remain, the remaining number of

playback times is displayed. To play back, touch [Yes]. If the

next file is to be played back, touch [No].

Indication for CD/MP3/WMA/AAC

• No disc is inserted.

- Insert a disc.

• Although a disc is inserted, “No Disc” is displayed and the unit

does not start to play or eject the disc.

- Remove the disc by following these steps:

Press for at least 3 seconds.

• Mechanism error.

1) Press and eject the disc.

If not ejecting, consult your Alpine dealer.

2) When the error indication remains after ejecting, press

again.

If the error indication still does not turn off after pressing

for a few times, consult your Alpine dealer.

• Scratched disc, contaminated disc/poor recording/disc

incompatible with this unit.

- Press .

- Change the disc.

• A copy-protected WMA file was played back.

- You can only play back non-copy-protected files.

60-EN

Indication for DVD

• No disc is inserted.

- Insert a disc.

• Although a disc is inserted, “No Disc” is displayed and the unit

does not start to play or eject the disc.

- Remove the disc by following these steps:

Press for at least 3 seconds.

• Button operation on the unit or remote control (optional) is not

possible.

- For some discs or playing modes, certain operations are not

possible. This is not a malfunction.

• Mechanism error.

1) Press and eject the disc.

If not ejecting, consult your Alpine dealer.

2) When the error indication remains after ejecting, press

again.

If the error indication still does not turn off after pressing

for a few times, consult your Alpine dealer.

• Scratched disc, contaminated disc/poor recording/disc

incompatible with this unit.

- Press .

- Change the disc.

• Disc does not match regional code number.

- Load a disc that matches the regional code number.

Indication for USB Memory

• Database error or decoder error.

- You can solve the problem by switching the source.

• Communication error or boot error, etc.

- You can solve the problem by reconnecting the USB memory

or changing source.

• Abnormal current is run to the USB connector device.

- You can solve the problem by switching the source.

• A USB device that is not supported by the unit is connected.

- Connect a USB device that is supported by the unit.

• A USB Memory is not connected.

- Make sure the USB Memory device is correctly connected and

the cable is not excessively bent.

• No song (file) is stored in the USB Memory.

- Connect the USB Memory device after storing songs (files).

• A sampling rate/bit rate not supported by the unit is used.

- Use a sampling rate/bit rate that is supported by the unit.

• A copy-protected WMA file was played back.

- You can only play back non-copy-protected files.

61-EN

Indication for iPod Mode

• The iPod/iPhone is not connected.

- Make sure the iPod/iPhone is correctly connected (refer to

“Connections”).

Make sure the cable is not bent excessively.

• There are no songs in the iPod/iPhone.

- Download songs to the iPod/iPhone and connect to the

IVE-W530BT.

• Database error or decoder error.

- You can solve the problem by switching the source.

• Communication error or boot error, etc.

- You can solve the problem by reconnecting the iPod/iPhone or

changing source.

• The iPod/iPhone is not verified.

- You can solve the problem by reconnecting the iPod/iPhone.

• Abnormal current is run to the USB connector device.

- You can solve the problem by switching the source.

62-EN

Specifications

MONITOR SECTION

FM TUNER SECTION

MW TUNER SECTION

LW TUNER SECTION

USB SECTION

* Frequency response may differ depending on the encoder software/

bit rate.

CD/DVD SECTION

PICKUP

BLUETOOTH SECTION

GENERAL

CHASSIS SIZE

•Due to continuous product improvement, specifications and design

are subject to change without notice.

•The LCD panel is manufactured using an extremely high precision

manufacturing technology. Its effective pixel ratio is over 99.99%.

This means that there is a possibility that 0.01% of the pixels could

be either always ON or OFF.

CAUTION

Screen Size 6.1"

LCD Type Transparent type TN LCD

Operation System TFT active matrix

Number of Picture Elements 1,152,000 pcs. (800 × 3 × 480)

Effective Number of Picture Elements

99.99% or more

Illumination System LED

Tuning Range 87.5 – 108.0 MHz

Mono Usable Sensitivity 8.1 dBf (0.7 µV/75 ohms)

50 dB Quieting Sensitivity 12 dBf (1.1 µV/75 ohms)

Alternate Channel Selectivity 80 dB

Signal-to-Noise Ratio 65 dB

Stereo Separation 35 dB

Capture Ratio 2.0 dB

Tuning Range 531 – 1,602 kHz

Sensitivity (IEC Standard) 25.1 µV/28 dBf

Tuning Range 153 – 281 kHz

Sensitivity (IEC Standard) 31.6 µV/30 dBf

USB requirements USB 1.1/2.0

Max. Power Consumption 1A

USB Class USB (Mass Storage Class)

File System FAT12/16/32

MP3 Decoding MPEG-1/2 AUDIO Layer-3

WMA Decoding Windows Media™ Audio

AAC Decoding AAC-LC format “.m4a” file

Number of Channels 2-Channel (Stereo)

Frequency Response* 20 – 20,000 Hz (±1 dB)

Total Harmonic Distortion 0.008% (at 1 kHz)

Dynamic Range 95 dB (at 1 kHz)

Signal-to-Noise Ratio 105 dB

Channel Separation 85 dB (at 1 kHz)

Frequency Response 20 – 20,000 Hz

Wow & Flutter (% WRMS) Below measurable limits

Total Harmonic Distortion 0.008% (at 1 kHz)

Dynamic Range 95 dB (at 1 kHz)

Channel Separation 85 dB (at 1 kHz)

Signal system NTSC/PAL

Horizontal resolution 500 lines or greater

Video output level 1Vp-p (75 ohms)

Video S/N ratio DVD: 60 dB

Audio S/N ratio 105 dB

Wave length DVD: 666 nm

CD: 785 nm

Laser power CLASS II

BLUETOOTH Specification BLUETOOTH V 3.0

Output Power +4 dBm Max. (Power class 2)

Profile HFP (Hands-Free Profile)

HSP (Head Set Profile)

A2DP (Advanced Audio

Distribution Profile)

AVRCP (Audio/Video Remote

Control Profile)

Power Requirement 14.4 V DC

(11–16 V allowable)

Operating temperature +32°F to +113°F

(0°C to + 45°C)

Maximum Power Output 50 W × 4

Output Voltage 2,000 mV/10k ohms

Weight 2.1 kg (4 lbs. 10 oz)

Audio output level

Preout (Front, Rear): 2V/10k ohms (max.)

Preout (Subwoofer): 2V/10k ohms (max.)

AUX OUT: 1.2V/10k ohms

Width 178 mm (7")

Height 100 mm (3-15/16")

Depth 150 mm (5-7/8")

CLASS 1

LASER PRODUCT

(Bottom side of player)

CAUTION-Laser radiation when open, DO NOT STARE INTO BEAM

(Bottom side of player)

63-EN

Installation and Connections

Before installing or connecting the unit, please read the

following and pages 6 to 10 of this manual thoroughly for

proper use.

Warning

MAKE THE CORRECT CONNECTIONS.

Failure to make the proper connections may result in fire or product

damage.

USE ONLY IN CARS WITH A 12 VOLT NEGATIVE GROUND.

(Check with your dealer if you are not sure.) Failure to do so may

result in fire, etc.

BEFORE WIRING, DISCONNECT THE CABLE FROM THE

NEGATIVE BATTERY TERMINAL.

Failure to do so may result in electric shock or injury due to

electrical shorts.

DO NOT ALLOW CABLES TO BECOME ENTANGLED IN

SURROUNDING OBJECTS.

Arrange wiring and cables in compliance with the manual to

prevent obstructions when driving. Cables or wiring that obstruct or

hang up on places such as the steering wheel, shift lever, brake

pedals, etc. can be extremely hazardous.

DO NOT SPLICE INTO ELECTRICAL CABLES.

Never cut away cable insulation to supply power to other

equipment. Doing so will exceed the current carrying capacity of

the wire and result in fire or electric shock.

DO NOT DAMAGE PIPE OR WIRING WHEN DRILLING

HOLES.

When drilling holes in the chassis for installation, take precautions

so as not to contact, damage or obstruct pipes, fuel lines, tanks or

electrical wiring. Failure to take such precautions may result in fire.

DO NOT USE BOLTS OR NUTS IN THE BRAKE OR STEERING

SYSTEMS TO MAKE GROUND CONNECTIONS.

Bolts or nuts used for the brake or steering systems (or any other

safety-related system), or tanks should NEVER be used for

installations or ground connections. Using such parts could disable

control of the vehicle and cause fire etc.

KEEP SMALL OBJECTS SUCH AS BOLTS OR SCREWS OUT

OF THE REACH OF CHILDREN.

Swallowing them may result in serious injury. If swallowed,

consult a physician immediately.

DO NOT INSTALL IN LOCATIONS WHICH MIGHT HINDER

VEHICLE OPERATION, SUCH AS THE STEERING WHEEL OR

SHIFT LEVER.

Doing so may obstruct forward vision or hamper movement etc.

and results in serious accident.

Caution

HAVE THE WIRING AND INSTALLATION DONE BY EXPERTS.

The wiring and installation of this unit requires special technical

skill and experience. To ensure safety, always contact the dealer

where you purchased this product to have the work done.

USE SPECIFIED ACCESSORY PARTS AND INSTALL THEM

SECURELY.

Be sure to use only the specified accessory parts. Use of other than

designated parts may damage this unit internally or may not

securely install the unit in place. This may cause parts to become

loose resulting in hazards or product failure.

ARRANGE THE WIRING SO IT IS NOT CRIMPED OR

PINCHED BY A SHARP METAL EDGE.

Route the cables and wiring away from moving parts (like the seat

rails) or sharp or pointed edges. This will prevent crimping and

damage to the wiring. If wiring passes through a hole in metal, use

a rubber grommet to prevent the wire’s insulation from being cut by

the metal edge of the hole.

DO NOT INSTALL IN LOCATIONS WITH HIGH MOISTURE OR

DUST.

Avoid installing the unit in locations with high incidence of

moisture or dust. Moisture or dust that penetrates into this unit may

result in product failure.

Precautions

• Be sure to disconnect the cable from the (–) battery post before

installing your IVE-W530BT. This will reduce any chance of

damage to the unit in case of a short-circuit.

• Be sure to connect the colour coded leads according to the

diagram. Incorrect connections may cause the unit to

malfunction or damage to the vehicle’s electrical system.

• When making connections to the vehicle’s electrical system, be

aware of the factory installed components (e.g. on-board

computer). Do not tap into these leads to provide power for this

unit. When connecting the IVE-W530BT to the fuse box, make

sure the fuse for the intended circuit of the IVE-W530BT has the

appropriate amperage. Failure to do so may result in damage to

the unit and/or the vehicle. When in doubt, consult your

ALPINE dealer.

• The IVE-W530BT uses female RCA-type jacks for connection

to other units (e.g. amplifier) having RCA connectors. You may

need an adapter to connect other units. If so, please contact your

authorized ALPINE dealer for assistance.

• Be sure to connect the speaker (–) leads to the speaker (–)

terminal. Never connect left and right channel speaker cables to

each other or to the vehicle body.

• The Display must be completely retracted in the casing when

installing. If it is not, problems may occur.

• When installing in automobiles, make sure the Display can open/

close without coming in contact with the shift lever.

IMPORTANT

Please record the serial number of your unit in the space provided

below and keep it as a permanent record. The serial number plate is

located on the bottom of the unit.

SERIAL NUMBER:

INSTALLATION DATE:

INSTALLATION TECHNICIAN:

PLACE OF PURCHASE:

64-EN

Installation

The main unit must be mounted within 30 degrees of the

horizontal plane, back to front.

Remove the mounting sleeve from the main unit

(Refer to “Removal” on page 64). Slide the mounting

sleeve into the dashboard and fix it with the metal

shackles.

When your vehicle has the Bracket, mount the long

hex bolt onto the rear panel of the IVE-W530BT and

put the Rubber Cap on the hex bolt. If your vehicle

does not have the Mounting Support, reinforce the

head unit with the metal mounting strap (not

supplied). Secure the ground lead of the unit to a

clean metal spot using a screw (*1) already attached

to the vehicle’s chassis. Connect all the leads of the

IVE-W530BT according to details described in the

CONNECTIONS section.

Slide the IVE-W530BT into the dashboard until it

clicks. This ensures that the unit is properly locked

and will not accidentally come out from the

dashboard.

Removal

1. Insert the bracket keys into the unit, along the guides

on either side. The unit can now be removed from the

mounting sleeve.

2. Pull the unit out, keeping it unlocked as you do so.

Heat Sink

Caution

Do not block the unit’s fan or heat sink, thus preventing

air circulation. If blocked, heat will accumulate inside

the unit and may cause a fire.

Rear of the Unit

Rear of the unit

Less than 30°

Mounting Sleeve (Included)

Dashboard

This unit

Rubber Cap (Included)

Bracket key

Hex Bolt

(Included)

Face Plate (Included)

•For the screw marked “*2”, use an appropriate screw for the chosen

mounting location.

This unit

Chassis

Ground Lead

Metal

Mounting

Strap

Hex Nut (M5)

Screw

Bolt Stud

This unit

Bracket keys

(Included)

65-EN

Take the face plate off, and secure the ground lead of the unit to

a clean metal spot using a screw (*) already attached to the

car’s chassis.

Attach the Original Mounting Bracket to each side of the

IVE-W530BT, using the screws supplied with IVE-W530BT.

Mounting the Microphone

For the sake of safety, mount the microphone in the following location.

• In a stable and secure location.

• In a location that does not inhibit safely driving the vehicle.

• Mount the microphone in a location where the driver’s voice can

easily be picked up.

Requiring the driver to move towards the microphone for audibility

causes a distraction that could be dangerous.

Ground Lead

Chassis

Screws (M5 × 8) (Included)

Face Plate (Included)

Mounting

Bracket

66-EN

To prevent external noise from entering the audio system.

•Locate the unit and route the leads at least 10 cm away from the car harness.

•Keep the battery power leads as far away from other leads as possible.

•Connect the ground lead securely to a bare metal spot (remove any paint, dirt or grease if necessary) of the car chassis.

•If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries various

noise suppressors, contact them for further information.

•Your Alpine dealer knows best about noise prevention measures so consult your dealer for further information.

IVE-W530BT

(Red)

(Yellow)

SPST SW (Optional)

FUSE (5A)

(Optional)

FUSE (20A)

(Optional)

Battery

ACC

BATTERY

Connection Diagram of SPST Switch (Sold Separately)

(If the ACC power supply is not available)

•If your vehicle has no ACC power supply, add an SPST (Single-Pole, Single-Throw) switch (sold separately) and fuse (sold separately).

•The diagram and the fuse amperage shown above are in the case when IVE-W530BT is used individually.

•If the switched power (ignition) lead of the IVE-W530BT is connected directly to the positive (+) post of the vehicle’s battery, the IVE-W530BT

draws some current (several hundred milliamperes) even when its switch is placed in the OFF position and the battery may be discharged.

67-EN

Connections

* ISO Power Supply Connector and ISO Connector (Speaker Output) are integrated.

(Red)

Amplifier

Front Right

Front Left

Rear Right

Rear Left

Subwoofers

To Audio output

terminal (R, L)

To Audio input

terminal (R, L)

To Video output

terminal

To Video input

terminal

(White)

(Yellow)

(Red)

(White)

(Yellow)

Antenna

ISO Antenna Plug

To power antenna

To amplifier or equalizer

Battery

Ignition key

Front Left

Rear Left

Rear Right

Front Right

Speakers

(Blue/White)

(Yellow)

(Black)

(Red)

(Green)

(Green/Black)

(White/Black)

(Grey)

(Violet/Black)

(Violet)

ACC

GND

BATTERY 15A

(Grey/Black)

(White)

PARKING BRAKE (Yellow/Blue) To the parking brake signal lead

To plus side of the back lamp

signal lead of the car

To remote input lead

REVERSE (Orange)

Microphone

REMOTE OUT (White/Brown)

(Blue/White)

68-EN

Antenna Receptacle

ISO/JASO Antenna Adapter (sold separately)

ISO/JASO Antenna Adaptor may be required, depending on

the vehicle.

Video Input Connector (AUX IN) (Yellow)

Input the AUX video.

•To use this function, turn on “AUX1 IN” in the “SETUP” menu (see

“Setting the AUX Mode” on page 40).

Audio Input Connector (AUX IN)

RED is down and WHITE is up input the audio.

Video Output Connector (AUX OUT) (Yellow)

Output the video.

Audio Output Connectors (AUX OUT)

RED is down and WHITE is up output the audio.

Front Output RCA Connectors

RED is left and WHITE is right.

Rear Output RCA Connectors

RED is left and WHITE is right.

Subwoofer Output RCA Connectors

RED is left and WHITE is right.

Fuse Holder (15A)

Power Supply Connector

Switched Power Lead (Ignition) (Red)

Connect this lead to an open terminal on the vehicle’s fuse

box or another unused power source which provides (+)

12V only when the ignition is turned on or in the accessory

position.

Ground Lead (Black)

Connect this lead to a good chassis ground on the vehicle.

Make sure the connection is made to bare metal and is

securely fastened using the sheet metal screw provided.

Power Antenna Lead/Remote Turn On Lead (Blue/

White)

Connect this lead to the +B terminal of your power antenna,

if applicable.

Also connect this lead to the remote turn-on lead of your

amplifier or signal processor.

Battery Lead (Yellow)

Connect this lead to the positive (+) post of the vehicle’s

battery.

ISO Power Supply Connector

ISO Connector (Speaker Output)

Left Rear (+) Speaker Output Lead (Green)

Left Rear (–) Speaker Output Lead (Green/Black)

Left Front (+) Speaker Output Lead (White)

Left Front (–) Speaker Output Lead (White/Black)

Right Front (–) Speaker Output Lead (Grey/Black)

Right Front (+) Speaker Output Lead (Grey)

Right Rear (–) Speaker Output Lead (Violet/Black)

Right Rear (+) Speaker Output Lead (Violet)

Parking Brake Lead (Yellow/Blue)

Connect this lead to the power supply side of the parking

brake switch to transmit the parking brake status signals to

the IVE-W530BT.

Reverse Lead (Orange)

Use only when a back-up camera is connected. Connect to

the plus side of the car’s reverse lamp. This lamp illuminates

when the transmission is shifted into reverse (R).

With this lead properly wired, the video picture

automatically switches to the back-up camera whenever the

car is put into reverse (R).

Remote Control Output Lead (White/Brown)

Connect this lead to the remote control input lead. This lead

outputs the controlling signals from the remote control.

RGB Input Connector

Connect this to the RGB output terminal of the Navigation

System.

USB Connector

Connect this to a USB Memory device or to an iPod/iPhone.

To use an iPod/iPhone, an iPod interface cable is required.

•Use the supplied USB cable. If a USB cable other than the supplied is

used, correct performance cannot be guaranteed.

•Route the USB cable away from other cables.

MIC Input Connector

To Microphone

Steering Remote Control Interface Connector

To steering remote control interface box.

For details about connections, consult your nearest Alpine

dealer.

iPod (V)/AUX Input Connector

Input the iPhone/video compatible iPod audio/video signal

or AUX video/audio signal.

•Set “AUX2 IN” to “iPod Video” in “Setting the AUX Mode”

(page 40) when an iPhone or a video compatible iPod is connected.

•Set “AUX2 IN” to “AUX” in “Setting the AUX Mode” (page 40)

when normal AUX video/audio is input.

CAMERA Input Connector

Use when the optional rearview camera with RCA

Connector is connected.

•Set “ON” in “Setting the Rear Camera Input” (page 39) when

connecting a rearview camera with RCA output connector.

RCA Extension Cable (sold separately)

Microphone (Supplied)

69-EN

System Example

Connecting iPhone/Video compatible iPod and Back-up Camera

CAMERA Input Connector

Use when the optional rearview camera with RCA connector

is connected.

•Set “ON” in “Setting the Rear Camera Input” (page 39) when

connecting a rearview camera with RCA Output connector.

RCA Extension Cable (Sold Separately)

USB Connector

USB extension cable (Included)

*USB 30P cable (Sold Separately)

*AV extension cable (Sold Separately)

* The optional accessory KCU-461iV contains and , you cannot

individually purchase or .

iPhone/Video compatible

iPod (Sold Separately)

Rear camera

(Sold Separately)

To Video Output terminal

70-EN

When Connecting External Equipment

Video Input Connector (AUX IN) (Yellow)

Input AUX video.

•To use this function, turn on “AUX1 IN” in the “SETUP” menu (see

“Setting the AUX Mode” on page 40).

Audio Input Connectors (AUX IN)

RED is right and WHITE is left input the audio.

Video Output Connector (AUX OUT) (Yellow)

Output the video.

Audio Output Connectors (AUX OUT)

RED is right and WHITE is left output the audio.

RCA Extension Cable (Sold separately)

Power Supply Connector

Remote Control Output Lead (White/Brown)

Reverse Lead (Orange)

Use only when a back-up camera is connected. Connect to

the plus side of the car’s reverse lamp. This lamp illuminates

when the transmission is shifted into reverse (R).

With this lead properly wired, the video picture

automatically switches to the back-up camera whenever the

car is put into reverse (R).

iPod (V)/AUX Input Connector

Input the iPhone/video compatible iPod audio/video signal

or AUX video/audio signal.

•Set “AUX2 IN” to “AUX” in “Setting the AUX Mode” (page 40)

when normal AUX video/audio is input.

•When you use this connector as normal video/audio input connector

(AUX 2 Input), an optional AV/RCA interface cable should be used.

For details, refer to .

To Video Output terminal

To Audio Output terminal

To Audio Input terminal

To Video Output terminal

TV Tuner or VCR

(Sold Separately)

External DVD, etc.

(Sold Separately)

Use only when back-up camera is connected.

Rear monitor

(Sold Separately)

To Video Input terminal

To Audio Output terminal

71-EN

AV/RCA interface cable (4-pole mini AV plug to

3-RCA) (Sold Separately)

Usable 4-pole mini AV plug

Wiring convention of this system is as follows:

•This configuration is not standardized for commercially available AV

plugs. Please confirm compatibility before purchasing.

Video/Audio Input Connectors

YELLOW is for input video, RED is right and WHITE is left

input the audio.

Audio L (White)

Audio R (Red)

Ground

Video (Yellow)
