Altai Technologies Limited A8n Super WiFi Base Station Lightning Protection

User manual

Altai A8n
Super WiFi Base Station
802.11n Long Range Outdoor WiFi
The Altai A8n Super WiFi Base Station is the world’s
leading 802.11n WiFi outdoor access point
optimized for maximum coverage and highest
throughput from a minimum number of installation
sites. The Altai A8n has been designed to provide
industry best coverage and capacity without
complicated networking protocols or the need for a
high density of transmitters.
The A8n is a multi-radio base station utilizing 2x2
MIMO smart antenna technologies and a patented
signal processing algorithm to provide the industry’s
best coverage per base station, especially in non-
line-of sight (NLOS) environments. The multiple
antennas of the A8n can be configured to provide
coverage that is optimized for area, pattern and
elevation. Using up to 80% fewer access points than
other WiFi systems to cover the same area enables
less complex network design and provides lower
latency for improvement in handling real-time
applications such as VoIP and video streaming.
Whether deployed for a single location, a campus
area or city-wide network coverage, the Altai A8n is
designed to minimize the total cost of ownership with
significant savings in network equipment, broadband
access, planning, site acquisition and installation.
The Altai A8n can serve as last mile infrastructure for
a wide range of wireless broadband access
applications. It provides low deployment cost and
fast provisioning of WiFi systems with the greatest
coverage and bandwidth per installed base
station.
The A8n Super WiFi Base Station can be deployed in
conjunction with existing 3G networks to provide low
cost high bandwidth mobile data offloading solution.
The A8n can be co-located with existing 3G cell sites
allowing immediate WiFi provisioning at much lower
acquisition and operating costs.
As an integral part of our Super WiFi network infrastructure, key benefits of the Altai A8n include:
Link integrity, backhaul link self healing and access link
safe mode
Adaptive interference control mitigates the influence from
surrounding interfering sources
Standard 802.11b/g/n access and 802.11a/n backhaul
Giga Ethernet or integrated 802.11a/n wireless backhaul
Flexible antenna deployment for various site conditions
Remote configuration through the Altai Wireless
Management System (AWMS)
Extended coverage in a Non-Line-of-Sight (NLOS)
environment which matches the foot print of most 3G
deployments in dense urban environments
High 11n throughout capacity up to 300 Mbps data rate
4-sector x dual-diversity advanced Smart Antenna
Technology provides flexible 90 to 360-degree and large
vertical beamwidth coverage with minimal holes in dense
urban environments
Multi-radio 2x2:2 MIMO platform maximizing both
uplink/downlink performance and access redundancy
© 2012 Altai Technologies Limited. All rights reserved.
Wireless Interface
802.11b/g/n (2x2:2)
Operating Mode Access Point
Standard IEEE 802.11b/g/n
Operating Frequency 2.412 – 2.462 GHz (Ch 1-11)
Max. EiRP 36 dBm
Receiver Sensitivity (Typical)
802.11b 11 Mbps -89 dBm
1 Mbps -95 dBm
802.11g 54 Mbps -79 dBm
6 Mbps -93 dBm
802.11n HT20 -92 dBm
HT40 -89 dBm
Interference Mitigation
Bandwidth Control – Airtime/ Throughput/ VAP/Client
Altai AirFi™ Bandwidth Control
Transmit and Receive Diversity
Automatic Channel Selection
Site Survey/ Channel Scan (2.4 and 5 GHz)
802.11a/n (2x2:2)
Operating Mode Access Point/Bridge
Standard IEEE 802.11a/n
Operating Frequency 5.745 – 5.825 GHz
EiRP 36 dBm
Receiver Sensitivity (Typical)
802.11a 54 Mbps -77 dBm; 6 Mbps -94 dBm
802.11n HT20 -93 dBm; HT40 -90 dBm
Dimension 360 x 234 x 80 mm (Chassis)
Weight 4 kg (Unit Weight) /
6.5 kg (Gross Weight)
Mounting Pole or Wall-mounted
Web-based Administration Tool
CLI-based Administration Tool (Telnet and Console)
SNMP v1/ v2c, Altai MIB
SNMP Manager Access Control List
Remote Firmware Upgrade (HTTP, FTP)
Performance Monitoring
WiFi Client Association Status/ Bad Client Disassociation
Customized Configuration File
Syslog Support
Packet Capture Diagnosis
Throughput Test Utility
TR-069 Support*
802.11b/g/n
Authentication – Open system, Shared key, WPA/ WPA-
PSK, WPA2/ WPA2-PSK, 802.1x (PEAP, TLS, TTLS)
Encryption – WEP, TKIP, AES
WAPI
Rogue AP Detection
MAC based Access Control
SSID Suppression
Inter/ Intra-VAP Client Communication Control
802.11a/n
Encryption – WEP, AES
2.4 GHz Antenna
External Antenna 14 dBi (Max.) Sector
Frequency 2.4 – 2.5 GHz
Polarization Dual Slant ±45°
3-dB Horizontal
Beamwidth
70° ±3°
3-dB Vertical Beamwidth 12° ±2°
VSWR 2 (Max.)
Impedance 50 Ω
Front-to-back Ratio 25 dB (Max.)
Isolation Between Ports 20 dB (Min.)
Antenna Connector 8 x Dual N-female
5 GHz Antenna (separate orderable item)
External Antenna 20 dBi Panel
Antenna Connector 2 x N-female
16 Multiple SSID/ Virtual AP
User Limit Per SSID
VLAN / Configurable Management VLAN
DHCP Client/ Server/ Relay
Dynamic NAT
PPPoE Client, PPPoE Pass-through
VPN Pass-through
Switch and Gateway Mode
VLAN trunking/ WDS
10/100/1000 Mbps Ethernet Port
Radius Server Per VAP/ Backup Radius Server Support
Multicast Rate Filter/ IGMP Snooping
Link Integrity/ Backhaul Link Self-Healing/ Safe Mode
WMM/ Port-based Prioritization
Power Source PoE Injector, -48V DC*
Power Consumption 25 W (Typical) / 60 W (Max.)
Operating Temperature -40 °C to +60 °C (Ambient)
0 °C to +40 °C (PoE Injector)
Storage Temperature -40 °C to +85 °C
Humidity 5 to100% (Condensing)
Lightning Protection EN 61000-4-5
Wind Loading 100 mph (Operational)
135 mph (Survival)
Weatherproof IP67 Compliant
FCC*/ CE*/ Others*
Altai Technologies Limited
www.altaitechnologies.com
A8n-PB-120606
Antenna
Networking
Although Altai has attempted to provide accurate information in these materials, Altai assumes no legal liability for the acc uracy and completeness of the information.
All specifications are subject to change without notice.
Security
Physical Specification (BTS Unit)
Power Supply
Environmental Specification
Certification
Management
Standard Package
A8n Super WiFi Base Station (PoE Power) (Model No.:
WA8011N)
Smart Antennas
RF Cables
PoE Injector and Mounting Accessories
Other Package
A8n (bgn) Package Removed 11a/n Radio
Product Ordering Information
* Feature will be available in future release
