User Manual
To temporarily turn off auto squelch:
Press the Light/Max Range button for
less than ve seconds.
To turn maximum range extender on:
– Press and hold the Light/Max Range button
for at least ve seconds until you hear
two beeps which indicates the maximum
range extender is on.
To turn maximum range extender off:
– Press and release the Light/Max Range
button or change channels.
Lock Function
The Lock function locks the Channel Up, Channel
Down and Mode/Power buttons to prevent
accidental operation.
To turn the lock on or off:
– Press and hold the Lock button for
two seconds.
A double beep sound is used to conrm your lock on
or off request. When in Lock mode,
the Lock icon will be displayed.
microTALK® Range
Your range will vary depending on terrain and conditions.
In at, open country your radio will
operate at maximum range.
Buildings and foliage in the path of the
signal can reduce the range of the radio.
Dense foliage and hilly terrain will further
reduce the range of the radio.
On FRS Channels 8 through 14, your radio
automatically switches to low power, which
will limit the range the radio can communicate.
Turning on Your microTALK® Radio
Press and hold the Mode/Power button until you hear
a series of audible tones indicating the radio is on.
Your microTALK® radio is now in Standby mode,
ready to receive transmissions. The radio is always in
Standby mode except when the Talk, Call or
Mode/Power buttons are pressed.
Battery Status Indicator
The battery charge status is shown on the display.
Four bars indicates fully charged.
Insert Batteries
Radio Charger Jack
Staying in touch with your family and friends is
convenient and easy when using your microTALK® radio.
Some of the many uses you will discover include:
Communicating with others while hiking, biking, and working; keeping
track of family and friends at a crowded public event; checking with
travel companions in another car; talking with neighbors; arranging
meeting spots with others while shopping at the mall.
Secure your microTALK® radio while on
the go.
Carrying your microTALK® radio with you is easy
when using the belt clip or optional wrist strap.
The belt clip easily attaches to your belt, purse, or
backpack.
Owner’s Manual
Introduction
Making Life Easier and Safer
Introduction
Product Features
Operation
Using Your Radio
Customer Assistance
Product Service & Support
Belt Clip
Backlit LCD Display
Features
• 22 Channels
• 10 Channel NOAA All
Hazards Radio
• Weather Alert
• 121 Privacy Codes
(38 CTCSS codes/
83 DCS codes)
• Hands-Free Operation
(VOX)
• Scan
Channels, privacy codes
• Backlit LCD Display
• Call Alert
Five selectable tones
• Button Lock
• Speaker/
Microphone/
Charge Jack
• Roger Beep
Selectable On/Off
• Battery/Power Saver
• Keystroke Tones
• Battery Level
Indicator
• Auto Squelch
• Maximum
Range Extender
• Belt Clip
Printed in China
KEM-ML39900-21
English
TWO-WAY RADIO MODEL
CXT235 A
Nothing Comes Close to a Cobra®A-1 A-2 A-3 1
Remove Belt Clip
Pull Up Lock Latch
Caring for Your microTALK® Radio
Your microTALK® radio will give you years of trouble-free service
if cared for properly. Handle the radio gently. Keep the radio away from
dust. Never put the radio in water or in a damp place. Avoid exposure to
extreme temperatures.
Installing Batteries
To install or replace batteries:
1. Remove belt clip by releasing belt clip
latch and sliding clip up.
2. Pull up on the battery door latch to remove the
battery compartment cover.
3. Insert the supplied three AA rechargeable
batteries or non-rechargeable alkaline batteries.
Position batteries according to polarity markings.
4. Replace battery compartment cover and
belt clip.
• Do not attempt to charge alkaline batteries.
• Do not mix old and new batteries.
• Do not mix alkaline, standard (carbon-zinc), or
rechargeable (Ni-Cd, Ni-MH, etc.) batteries.
To charge batteries in radio:
1. Check to see that the batteries have been
inserted properly.
2. Insert the cable into the charge jack located at
the top of the radio.
3. Plug the cable into USB-compatible power port.
Use only the supplied rechargeable batteries and charger for recharging
your Cobra microTALK® radio.
Cobra recommends your radio is turned off while being charged.
Non-rechargeable alkaline batteries can also be used in your radio.
23456
Mode/Power
Mode/Power
Channel Button
Call Button
Lock Button
Battery Charge
Status
Quick Start
1. Press and hold the Mode/Power button
to turn on your radio.
2. Press the Channel Up or Channel Down
button to select a channel.
3. Press and hold the Talk button while
speaking into the microphone.
4. When nished talking, release the Talk
button and listen for a response.
Both radios must be tuned to the same
channel/privacy code to communicate.
Battery Low
Battery Save Mode
Talk Button
Two Inches (5 cm)
from Mouth
Channel Number
Battery Low
When battery power is low, the nal bar in the
Battery Low icon will blink and an audible tone will
sound twice before the radio shuts off. Your batteries
should be replaced or recharged, if using
rechargeable batteries.
Auto Battery Save
If there are no transmissions within 10 seconds, the
radio will automatically switch to Power Save mode
and the Power Saver icon will ash in the display.
This will not affect the radio’s ability to receive
incoming transmissions.
Communicating with Another Person
1. Press and hold the Talk button.
2. With the microphone about two inches (5 cm) from
your mouth, speak in a normal voice.
3. Release the Talk button when you are
nished talking and listen for a response.
You cannot receive incoming calls while
pressing the Talk button.
To Select a Channel
With the radio on, select any of the 22 channels by
pressing the Channel Up or Channel Down button.
Both radios must be tuned to the
same channel to communicate.
The radio will display ashing battery icon
while charging if the radio is on.
Both radios must be tuned to the
same channel to communicate.
Listening
Volume Level
Light/Max Range
Light/Max Range
Listening for a Response
Release the Talk button to receive incoming
transmissions. Your microTALK® radio is always
in Standby mode while the Talk or Call buttons
are not pressed.
To Adjust Volume
Press the Volume Up or Volume
Down button.
A double beep sound is used to indicate
the minimum and maximum volume levels
(1 through 8).
Call Button
Press and release the Call button.
The other person will hear a three second call
tone. This tone is used only to establish voice
communications.
To Illuminate Display
Press and release the Light/Max Range button
to illuminate the display.
Auto Squelch/Maximum Range
Your microTALK® radio will automatically shut off weak transmissions
and unwanted noise due to terrain, conditions or if you’ve reached
your Maximum Range limit.
You can temporarily turn off auto squelch or turn on maximum range
extender, allowing all signals to be received and extending the
maximum range of your radio.
See page 12 on how to select between
ve call tone settings.
Lock Icon
Maximum Range
Reduced Range
Reduced Range
Remember, you can achieve maximum
range by using maximum range extender.
See page 4 for details.
Scrolling Through the Mode Function
By scrolling through the Mode function, you will be able to
select or turn on preferred features of your microTALK® radio. When
scrolling through the Mode function, your radio features
will be displayed in the same predetermined order:
Set CTCSS Privacy Codes
Set DCS Privacy Codes
Set Vox On/Off
Set Vox Sensitivity
Set Channel Scan
Set CTCSS Privacy Code Scan
Set DCS Privacy Code Scan
Set Call Tones
Set Roger Beep On/Off
Privacy Codes
Your microTALK® radio incorporates two advanced coded squelch
systems that can help to reduce interference from other users
on any given channel. CTCSS (Continuous Tone Coded Squelch
System) provides 38 privacy codes and DCS (Digitally Coded Squelch)
provides 83 privacy codes. This provides a total of 121 Privacy
Codes. Either system can be used on all channels, but both systems
cannot be used on the same channel at the same time.
To successfully communicate using a privacy code, both
the sending and receiving radios must be tuned to the same
channel and to the same privacy code system (CTCSS or DCS)
and privacy code number. Each channel will remember the
last privacy code system and number you select.
The privacy code 00 is not a privacy code, but allows all
signals to be heard on a channel that is set to 00 on both
the CTCSS and DCS systems.
Mode Functions (continued on back side)
Maximum range may vary and is based on
unobstructed line-of-sight communication
under ideal conditions.
1. Antenna
2. External Speaker/
Microphone/Charge Jack
3. Mode/Power Button
4. Weather/Lock Button
5. Channel Up/Down Buttons
6. Backlit LCD Display
7. Speaker/Microphone
8. Volume Up/Down Buttons
9. Light/Max Range Button
10. Talk Button
11. Call Button
12. Wrist Strap Connection
13. Belt Clip
14. Battery Compartment
15. Battery Door Latch
1. Battery Level Indicator
2. VOX Icon
3. Scan Icon
4. Roger Beep Icon
5. Lock Icon
6. Low Power Icon
7. DCS/CTCSS Icons
8. Weather Icon
9. Weather Alert Icon
10. DCS/CTCSS Privacy Code Numbers
11. Power Saver Icon
12. Channel Numbers
13. Receive/Transmit Icon
Operation
Mode Functions
12
13
14
15
2
1
3
7
11
8
4
5
10
6
9
1
2345
6
11
12
13
10
8
7
9
Volume Button
For any questions about operating this new Cobra branded product,
PLEASE CONTACT US FIRST… do not return this product to the retail
store. The contact information for support will vary depending on the
country in which you purchased and utilize the product.
To obtain warranty service or other information for products
purchased from Altis itself or through its authorized reseller or agent
and utilized in the U.S.A., please call our consumer support line at
(866) 721-3805, or email us at support@altistec.com. You will receive
instructions on how to ship the products at your expense to an Altis
Global Limited Authorized Service Center. To obtain service, you must
include: (a) a copy of your receipt, bill of sale or other comparable
proof of purchase; (b) a written description of the problem; and, most
importantly; (c) your address and telephone number.
For warranty and customer service information outside the US, please
contact your local dealer.
For further information needed on its features, please visit
www.cobrawalkietalkie.com for frequently asked questions and the
electronic manual. ©2017 Altis Global Limited
Berkeley Lake, GA US 30071
www.cobrawalkietalkie.com
12 13 14 15 16
Warranty & Trademark Acknowledgment
Operation
General Specications
8 9 10 117
Privacy Code
Set CTCSS Privacy Codes
To select a CTCSS privacy code:
1. After selecting a channel, press
the Mode/Power button until the CTCSS icon
appears and the small numbers next to the
channel number ash on the display.
2. Press using the Channel Up or Channel Down
button to select a privacy code. You can hold the
Up or Down button for fast advance.
3. When your desired CTCSS privacy code is
displayed, choose one of the following:
a. Press the Mode/Power button to enter the
new setting and proceed to other functions.
b. Press the Lock button to return to
Standby mode.
c. Do not press any buttons for 15 seconds
to return to Standby mode.
If DCS is turned on at the channel
selected, the display will ash the
CTCSS icon and “OFF.” To switch from
DCS to CTCSS, press the Channel Up
or Channel Down button while the display
is ashing “OFF.” The display will then
show the small numbers ashing and you
will then be able to proceed to step 2.
Operation
Mode Functions (continued)
Mode/Power
Mode/Power
Mode/Power
Mode/Power
Mode/Power
Weather Button
Weather Button
Scan Channels
Channel Scan
Your microTALK® radio can automatically scan channels.
To scan channels:
1. Press the Mode/Power button until the
Scan icon and the channel numbers appear
on the display.
2. Press the Channel Up or Channel Down button to
begin scanning channels.
The Scan icon will continue to be displayed when
scan is on. Your radio will continue to scan all
channels and stop if an incoming transmission is
detected. Your radio will remain on that channel for
10 seconds.
During scanning (while receiving an incoming transmission),
you can choose from the following:
a. Press and hold the Talk button to communicate on that channel.
Your radio will remain on that channel and return to Standby mode.
b. Press the Channel Up or Channel Down button to resume
scanning channels.
c. Press the Lock button to return to Standby.
During scanning (while receiving an incoming transmission),
you can choose from the following:
a. Press and hold the Talk button to communicate on that channel/
privacy code. Your radio will remain on that channel/privacy code
and return to Standby mode.
b. Press the Channel Up or Channel Down button to
resume scanning privacy codes. If you do not press any button
within 10 seconds, your radio will automatically resume scanning
privacy codes.
c. Press the Lock button to return to Standby.
The radio ignores specic privacy
codes while scanning channels.
Select Channel
Scan Privacy Codes
Privacy Code Scan
Your microTALK® radio can automatically scan the Privacy Codes (either
CTCSS 01 through 38 or DCS 01 through 83) within one channel. Only
one set of privacy codes (CTCSS or DCS) can be scanned at a time.
To scan privacy codes:
1. While in Standby mode, press the Channel Up or
Channel Down button to choose the channel on
which you wish to scan privacy codes.
2. Press the Mode/Power button until either the
CTCSS or the DCS icon appears on the display
and the Scan icon and the privacy code numbers
ash on the display.
3. Press the Channel Up or Channel Down button
to begin scanning privacy codes within the
channel you selected.
During scanning (while receiving an incoming transmission),
you can choose from the following:
a. Press and hold the Talk button to communicate on that channel/
privacy code. Your radio will remain on that channel/privacy code
and return to Standby mode.
b. Press the Channel Up or Channel Down button to
resume scanning privacy codes. If you do not press any button
within 10 seconds, your radio will automatically resume scanning
privacy codes.
c. Press the Lock button to return to Standby.
Call Tone Setting
Roger Beep Off
Five Call Tone Settings
You can choose between ve different Call Tone Settings to transmit
a call alert.
To change a call tone setting:
1. Press the Mode/Power button until the
letter “C” and the current call tone number
(01 through 05) is displayed. The current
call tone will sound for one second.
2. Press the Channel Up or Channel Down button
to hear the other call tone settings.
3. Choose one of the following:
a. Press the Mode/Power button to
enter the new setting and proceed
to other functions.
b. Press the Lock button to return to Standby
mode.
Roger Beep Confirmation Tone
Your listener will hear an audible tone when you release the
Talk button. This alerts the other party that you are nished
talking and it is OK for them to speak.
To turn roger beep on or off:
1. Press the Mode/Power button until the
Roger Beep icon ashes. The current
on or off setting is displayed.
2. Press the Channel Up or Channel Down button
to select roger beep on or off.
3. Choose one of the following:
a. Press the Mode/Power button to
return to Standby mode.
b. Press the Lock button to return to Standby
mode.
Hazards Radio Icon
NOAA* All Hazards Radio Channels
You can use your microTALK® radio to listen to NOAA All Hazards Radio
channels transmitting in your area.
To listen to All Hazards Radio channels:
1. Press the Weather button until the All Hazards
Radio icon and the currently selected All Hazards
Radio channel are displayed.
2. Use the Channel Up or Channel Down
button to change All Hazards Radio channels.
3. The All Hazards Radio icon will continue to
be displayed when All Hazards Radio is on.
4. To exit All Hazards Radio, press and hold the
Weather button.
*National Oceanographic and Atmospheric Administration
Weather (WX) Alert Mode
Turning On the Weather Alert function will allow your radio to
automatically receive NOAA Hazard Alert radio signals and warnings from
designated NOAA broadcast stations. If the radio is turned ON, it will alert
to Weather and other emergency alerts broadcast by NOAA.
To turn Weather Alert On or Off:
1. Press the Weather/Lock button until the Weather
Alert icon ashes on the display. The current On
or Off setting is displayed.
2. Press the Channel Up and Channel Down button
to turn Weather Alert On or Off.
3. Press and hold the Weather/Lock button again to
save the new setting and exit the Weather Alert
Mode and return to Standby mode.
This feature is set
to OFF by default.
Make sure the strongest
Weather channel is selected
for your area using the NOAA
All Hazards Radio Channels
selection in the previous menu.
FRS Frequency Allocation
A = Channel No. for 22 Channel FRS Mode
B = Frequency in MHz
A B C
1 462.5625 High
2 462.5875 High
3 462.6125 High
4 462.6375 High
5 462.6625 High
6 462.6875 High
7 462.7125 High
8 467.5625 Low
9 467.5875 Low
10 467.6125 Low
11 467.6375 Low
12 467.6625 Low
13 467.6875 Low
14 467.7125 Low
15 462.5500 High
16 462.5750 High
17 462.6000 High
18 462.6250 High
19 462.6500 High
20 462.6750 High
21 462.7000 High
22 462.7250 High
IMPORTANT NOTICE:
WARNING:
DCS Privacy Code
VOX Icon
Set DCS Privacy Codes
To select a DCS privacy code:
1. After selecting a channel, press the Mode/Power
button until the DCS icon appears and the small
numbers ash on the display (00 through 83).
2. Press using the Channel Up or Channel Down button to select a DCS
privacy code. You can hold the Up or Down button for fast advance.
3. When DCS privacy code is displayed, choose one of the following:
a. Press the Mode/Power button to enter the new setting and
proceed to other functions.
b. Press the Lock button to return to Standby mode.
c. Do not press any buttons for 15 seconds to enter the new settings
and to return to Standby mode.
Voice Activated Transmit (VOX)
In VOX mode, your microTALK® radio can be used “hands-free,” automatically
transmitting when you speak. You can set the VOX sensitivity level to t the
volume of your voice and avoid transmissions triggered by background noise.
To turn VOX mode on or off:
1. Press the Mode/Power button until the VOX
icon ashes on the display. The current On or Off
setting is displayed.
2. Press the Channel Up or Channel Down
button to turn VOX On or Off.
3. Choose one of the following:
a. Press the Mode/Power button to enter the
new setting and proceed to other functions.
b. Press the Lock button to return to Standby
mode.
If CTCSS is turned on at the channel selected,
the display will ash the DCS icon and “OFF.”
To switch from CTCSS to DCS, press the
Channel Up or Channel Down button while
the display is ashing “OFF.” The display will
then show the small numbers ashing and
you will then be able to proceed to step 2.
VOX Sensitivity Level
To set VOX sensitivity:
1. Press the Mode/Power button until the VOX icon
ashes and the current sensitivity level is displayed.
2. Press the Channel Up or Channel Down
button to change the setting.
3. Choose one of the following:
a. Press the Mode/Power button to enter the
selected setting and proceed to other functions.
b. Press the Lock button to return to Standby
mode.
The current VOX sensitivity level is
displayed with letters “L” and a Number 1
through 5, with Number 5 being the most
sensitive level and Number 1 being the
least sensitive level.
Channel Button
Channel Button
Channel Button
Channel Button
Channel Button
Channel Button
Channel Button
Channel Button
Mode/Power
Mode/Power
Mode/Power
Mode/Power
Trademark Acknowledgment
Manufactured, distributed, or sold by Altis Global Limited, official licensee for this product.
Cobra®, microTalk®, Nothing Comes Close to a Cobra®, and the snake design are registered
trademarks of Cobra Electronics Corporation, USA. Cobra Electronics Corporation™ is a
trademark of Cobra Elecronics Corporation, USA. All other product or service names are the
property of their respective owners.
©2018 Altis Global Limited, Berkeley Lake, GA, USA.
All rights reserved.
Limited One-Year Warranty
Altis Global Limited warrants to the original consumer purchaser only that this product and the
component parts thereof, will be free from defects in workmanship and materials for a period
of one year from the date of first consumer purchase. During this period, Altis will, repair or
replace, at its sole option and discretion, this product or any defective parts. Altis’ liability
hereunder shall be limited to repair or replacement of the defective part or parts, and such
correction shall constitute a fulfillment of all of Altis’ warranties hereunder.
This limited warranty is only valid for the original consumer purchaser in limited jurisdictions
and is not transferrable. This limited warranty will automatically terminate prior to expiration if
this product is sold or otherwise transferred to another party. The product must be purchased
from Altis or an authorized dealer or the warranty is void. This limited warranty is valid only for
products purchased and utilized in specific jurisdictions.
For Products Purchased Outside the U.S.A.
Please contact your authorized local reseller or agent for warranty information.
Please visit our website at www.cobrawalkietalkie.com for a list of jurisdictions wherein this
limited warranty is valid.
This limited warranty does not cover damage due to misuse, abuse, negligence, acts of God,
accident, commercial use or modification of, or to any part of this product. This warranty does
not cover damage due to improper operation, maintenance or installation; ordinary wear and
tear; or attempted alterations or repairs by anyone other than Altis or someone authorized by
Altis to do warranty work. Any unauthorized alterations or repairs will void this warranty. This
limited warranty does not cover product sold AS IS or WITH ALL FAULTS. This limited warranty
is invalid if the factory applied serial number or date stamp has been altered, defaced or
removed from this product. This limited warranty does not cover product purchased or utilized
in a jurisdiction not covered.
The procedure for obtaining service and support, and the applicability of this warranty, will
vary depending on the country or juristiction in which you purchase and utilize the product. For
details on obtaining product service, support and other warranty information please visit
www.cobrawalkietalkie.com.
This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state and country to country.
EXCEPT AS EXPRESSLY SET FORTH IN THIS WARRANTY, ALTIS MAKES NO OTHER
WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING ANY IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. ALTIS EXPRESSLY
DISCLAIMS ALL WARRANTIES NOT STATED IN THIS LIMITED WARRANTY. ANY IMPLIED
WARRANTIES THAT MAY BE IMPOSED BY LAW ARE LIMITED TO THE TERMS OF THIS
EXPRESSED WARRANTY.
LIMITATION OF REMEDIES AND DAMAGES. REPAIR OR REPLACEMENT AS PROVIDED
UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER. ALTIS SHALL NOT
BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT
LIMITED TO ATTORNEYS’ FEES AND/OR COSTS OF LITIGATION, FOR BREACH OF ANY
EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. ALTIS IS NOT LIABLE FOR ANY
DAMAGES CAUSED BY THE PRODUCT OR BY THE PRODUCT TO PERFORM, INCLUDING ANY
LOST PROFITS, LOST SAVINGS, INCIDENTAL DAMAGES, OR CONSEQUENTIAL DAMAGES.
ALTIS IS NOT LIABLE FOR ANY CLAIM MADE BY A THIRD PARTY OR MADE BY YOU FOR A
THIRD PARTY. THIS LIMITATION APPLIES WHETHER DAMAGES ARE SOUGHT, OR A CLAIM
MADE, UNDER THIS WARRANTY OR AS A TORT CLAIM (INCLUDING NEGLIGENCE OR STRICT
PRODUCT LIABILITY), A CONTRACT CLAIM, OR ANY OTHER CLAIM. THIS LIMITATION
CANNOT BE WAIVED OR AMENDED BY ANY PERSON. THIS LIMITATION OF LIABILITY WILL
BE EFFECTIVE EVEN IF ALTIS OR AN AUTHORIZED REPRESENTATIVE OF ALTIS HAS BEEN
ADVISED BY YOU OF THE POSSIBILITY OF ANY SUCH DAMAGES.
Some states and countries do not allow limitations on how long an implied warranty lasts and
do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitations may not apply to you. This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state and country to country.
Provided that the product was purchased from Altis itself or through its authorized reseller or
agent and utilized in the U.S.A., Altis will, without charge, repair or replace, at its option,
defective products, products or component parts upon delivery to the authorized Altis Global
Limited Authorized Service Center, accompanied by proof of the date of first customer
purchase, such as a duplicated copy of a sales receipt.
You must pay any initial shipping charges required to ship the product for warranty service, but
the return charges, to an address in the U.S.A, will be at Altis’ expense, if the product is under
warranty.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: 1) This device may not cause harmful interference, and 2) this device must
accept any interference received,including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
