Alula RE152 Wireless Keypad, 319.5MHz User Manual RE152 GE Compat Code Keypad
Resolution Products, Inc. Wireless Keypad, 319.5MHz RE152 GE Compat Code Keypad
Alula >
User Manual
RE152_GE-Compat_Code_Keypad.doc Page 1 of 3 3-Aug-12
www.ResolutionProducts.com
Wireless
Security
Solutions
RE152 GE-Compatible Code Keypad
Features
• Secure, 4-digit Code to disarm
• 1-button arming
• Red/Green LED arming feedback
• Small, yet comfortable keypad
• Mounts on wall via VHB® tape, or screws
• Secure for carrying in purse or mounting on car visor
• Strong, reliable RF signal.
• 4-6 year battery life on CR2032 battery.
Key Instructions
• Code programming
Default access code is “1234”.
To change access code:
1. Enter current 4-digit access code.
2. Within 4 seconds, press and hold the “1” and “3” keys
simultaneously. After 3 seconds, Red LED will be lit.
3. Enter new 4-digit access code. After successfully changing
the code, the Green LED will be lit
4. Note new access code . BAD GUY CANNOT RESET CODE.
So it must be noted and remembered!
• Enrolling:
1. Refer to the GE control unit installation manual.
2. Put the control panel in RF Learning mode.
• Press both the Stay & Away buttons simultaneously
for 3 seconds.
3. …Or if using a Downloader in ID entry mode
• Enter the Download ID the device
(located on a label on the unit’s back or in unit).
Operation
Stay button Arms panel to STAY, keypad flashes double red.
Away button Arms panel to AWAY, keypad flashes double red twice.
Stay & Away buttons simultaneously for 3 seconds Panic Alarm.
Keypad flashes red 8 times.
Entering 4-digit code Disarms panel, keypad flashes double green.
RE152_GE-Compat_Code_Keypad.doc Page 2 of 3 3-Aug-12
www.ResolutionProducts.com
Specifications
More securely replaces: GE TX-3030-01-1 4-button Wall Touchpad
Crystal Compatibility
Not supervised.
Replacement Battery: CR2032 Lithium / Manganese Dioxide
Temperature Range: 0F to 120F
Housing dimensions: 2x2.25x0.33 inches
Specifications subject to change without notice.
Pictures
Battery Replacement
CR2032
Battery
+ Terminal up
Insert
Screwdriver here
to open
Red/Green
Status LED
Stay + Away
=
Panic (Enroll)
1
+
3
=
New Code
RE152_GE-Compat_Code_Keypad.doc Page 3 of 3 3-Aug-12
www.ResolutionProducts.com
Notices
“GE”, “Honeywell”, and “DSC” are trademarks owned by General Electric Company,
Honeywell International Inc., and Tyco Safety Products Canada LTD, respectively.
Resolution Products, Inc. products will function with one of either GE, DSC or Honeywell
systems. However, no Resolution product is produced by, endorsed by, nor is officially
associated with GE, Honeywell or DSC. Resolution recommends verifying operation at
installation.
Warranty
Resolution Products, Inc. will replace products that are defective in their first year.
FCC Notice
This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions:
This device may not cause harmful interference.
This device must accept any interference that may be received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by the Resolution Products, Inc. could
void the user's authority to operate this equipment.
FCC ID: U5X-RE152
IC Notice
This product meets the applicable Industry Canada technical specifications/Le présent
materiel est conforme aux specifications techniques applicables d’Industrie Canada.
IC: 8310A-RE152
