User Manual
I
N
S
T
A
L
L
G
U
I
D
E
I
RE200-5 Honeywell Compatible Keyfob
Keyfob is a portable device used to remotely control a
security panel.
Features
• Support for up to 8 button functions
• Low battery indication
• 2 year warranty
Enroll by placing the panel into wireless enrollment mode
and pressing a keyfob button multiple times as instructed
by the panel’s installation manual. Alternately, the sensor
ID located on the back of the keyfob can be used to
manually enroll the keyfob.
Assign User
• For most security panels, keyfobs
must be assigned to a user to function
properly.
Loop Denitions
• Star = Loop 1
• Unlock = Loop 2
• Arm Away = Loop 3
• Arm Stay = Loop 4
To replace the battery, remove the screw on the back of
the keyfob and unsnap the back from the cover.
• After battery replacement, it may take
up to 10 button presses before the low
battery indication clears.
Pro Tips
Optional advanced button commands are sent by
pressing the lights button and another button at
the same time. Advanced button commands are
transmitted on a secondary ID which is the sensor’s
primary ID with the last digit replaced by a 1.
Advanced Button Commands
• Lights + Star = Loop 1
• Lights + Unlock = Loop 2
• Lights + Away = Loop 3
• Lights + Stay = Loop 4
Fob template programming on some panels requires
the STAY button (Loop 4) to be pressed to enroll the
keyfob.
Verify proper enrollment and operation using your security panel’s installation manual.
Screw
Loop 4
Loop 3
Loop1
Loop 2
LED
47-0016-02 • RevA • 2016-12-12
Tech Support Line (877) 260-5578
www.ResolutionProducts.com
WARRANTY
Resolution Products, Inc. will replace products that are defective in
their rst two (2) years.
IC NOTICE
This device complies with Industry Canada license-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference
that may cause undesired operation of the device.
Le présent appareil est conforme aux cnr d’Industrie Canada
applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes:
(1) L’appareil ne doit pas produire de brouillage, et
(2) L’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
IC: 8310A-RE2005
FCC NOTICE
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference that may be received,
including interference that may cause undesired operation.
Changes or modications not expressly approved by the Resolution
Products, Inc. could void the user’s authority to operate this
equipment.
FCC ID: U5X-RE200-5
TRADEMARKS
“Honeywell” is a trademark owned by Honeywell International, Inc.
Resolution Products, Inc. products will function with Honeywell
systems. However, no Resolution product is produced by, endorsed
by, or is ofcially associated with Honeywell.
Resolution recommends verifying proper enrollment and operation,
per security panel installation instructions, at installation.
Specications
Physical
Housing Dimensions
Weight with Battery
2.2 x 1.5 x 0.6 inches (5.6 x 3.8 x 1.4 centimeters)
0.66 ounces (19 grams)
Environmental
Operating Temperature
Maximum Humidity
32°F to 120°F (0°C to 49°C)
85% non-condensing relative humidity
Fob Specications
Frequency
Replacement Battery
Nominal Battery Life
Transmitted Indications
345 MHz
One Panasonic CR2032
5 years
Low Battery
Certication
RE200-5 FCC, IC
Specications subject to change without notice
