User Manual
I
N
S
T
A
L
L
G
U
I
D
E
I
RE300-5 DSC Compatible Keyfob
Keyfob is a portable device used to remotely control a
security system.
Features
• Supports for up to 8 button functions
• Low battery indication
• 5 year warranty
Enroll by placing the panel into wireless enrollment mode
and pressing a keyfob button multiple times as instructed
by the panel installation manual. Alternately, sensor ID
located on the back of the fob can be used to manually
enroll the sensor.
Assign User
• For most security panels, keyfobs
must be assigned to a user to function
properly.
To replace the battery, remove the screw on the back of
the keyfob and unsnap the back from the cover.
• After battery replacement, it may take
up to 3 button presses before the low
battery indication clears.
Pro Tips
Optional advanced button commands are sent by
pressing the lights button and another button at
the same time. Advanced button commands are
transmitted on a secondary ID which is the sensor’s
primary ID with the last digit replaced by a 1.
Secondary ID Commands
• Lights + Star = Star on secondary ID
• Lights + Unlock= Unlock on secondary ID
• Lights + Away = Arm away on secondary ID
• Lights + Stay = Arm stay on secondary ID
Verify proper enrollment and operation using your control panel’s installation manual.
Screw
LED
Stay
Away
Star
Unlock
Lights
47-0016-03 • RevA • 2016-12-12
Tech Support Line (877) 260-5578
www.ResolutionProducts.com
WARRANTY
Resolution Products, Inc. will replace products that are defective in
their rst ve (5) years.
IC NOTICE
This device complies with Industry Canada license-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference
that may cause undesired operation of the device.
Le présent appareil est conforme aux cnr d’Industrie Canada
applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes:
(1) L’appareil ne doit pas produire de brouillage, et
(2) L’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
IC: 8310A-RE3005
Specications
Physical
Housing Dimensions
Weight with Battery
2.2 x 1.5 x .6 inches (5.6 x 3.8 x 1.4 centimeters)
.66 ounces (19 grams)
Environmental
Operating Temperature
Maximum Humidity
32°F to 120 °F (0 to 49 °C)
85% non-condensing relative humidity
Sensor Specications
Frequency
Replacement Battery
Nominal Battery Life
Transmitted Indications
433.92 MHz
One Panasonic CR2032
4 to 6 years
Low Battery
Certication
RE300-5 FCC, IC
Specications subject to change without notice
FCC NOTICE
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference that may be received,
including interference that may cause undesired operation.
Changes or modications not expressly approved by the
Resolution Products, Inc. could void the user’s authority to operate
this equipment.
FCC ID: U5X-RE300-5
TRADEMARKS
DSC is a trademark owned by TYCO Safety Products Canada LTD.
Resolution Products Inc. products will function with DSC systems.
However, no Resolution product is produced by, endorsed by, nor
is ofcially associated with TYCO. Resolution recommends verifying
proper enrollment and operation, per control panel installation
instructions, at installation.
