RE626 Series CryptiX™ HeliRazor™ Siren
HeliRazor is a siren warning device that produces high
volume warning sounds and low volume notication sounds.
Features
• Runs on user-replaceable alkaline AAA batteries
• Secure encrypted wireless communications
• 5 year warranty
Sounds a high volume warning for burglary, smoke and carbon
monoxide alarm conditions. Low volume notication
sounds are made for auxiliary alarm, status, and trouble
conditions.
Enroll by placing the Helix control panel into wireless
enrollment mode and then pressing the HeliRazor‘s
enrollment button located inside the battery compartment.
• Once enrolled, arm and disarm Helix to
verify HeliRazor is within range of Helix
and properly enrolled
Install by mounting the siren to a wall using the mounting
screw holes on the back plate.
To replace the batteries, remove bottom screw and pull
the bottom away from the back plate and slide downward.
Next, slide the battery door off to expose the batteries.
An optional AC adapter allows for the siren to be powered
from an electrical outlet. When an AC adapter is used the
batteries act as a backup power source.
AC Adapter Part Numbers
• RE012-9 USA and Canada
• RE012-10 Australia and New Zealand
• RE012-11 United Kingdom
• RE012-12 Europe
Use the Helix installation guide to verify proper system setup.
I
N
S
T
A
L
L
G
U
I
D
E
I
Bottom Screw
Enroll Button
Optional AC Adapter Port
Mounting
Screw Holes
AC Adapter
Cord Slots
47-0029-08 • RevA • 2017-02-10
Tech Support Line (877) 260-5578
www.ResolutionProducts.com
WARRANTY
Resolution Products, Inc. will replace products that are defective in
their rst ve (5) years.
IC NOTICE
This device complies with Industry Canada license-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference
that may cause undesired operation of the device.
Le présent appareil est conforme aux cnr d’Industrie Canada
applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes:
(1) L’appareil ne doit pas produire de brouillage, et
(2) L’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
IC: 8310A-RE626
FCC NOTICE
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference that may be received,
including interference that may cause undesired operation.
Changes or modications not expressly approved by the Resolution
Products, Inc. could void the user’s authority to operate this
equipment.
FCC ID: U5X-RE626
CE DECLARATION OF CONFORMITY
Hereby, Resolution Products, Inc. declares that this RE626-CE is
in compliance with the essential requirements and other relevant
provisions of directive 1999/5/EC.
(This declaration can be translated to other languages via a myriad
of translation tools found on the Internet.)
Specications
Physical
Housing Dimensions
Weight with Batteries
Mounting Fastener
4.1 x 2.6 x 1.2 inches (10.4 x 6.7 x 3.0 centimeters)
4.7 ounces (132 grams)
#4 or #6 screws
Environmental
Operating Temperature
Maximum Humidity
32°F to 120°F (0°C to 49°C)
85% non-condensing relative humidity
Sensor Specications
Frequency
Replacement Batteries
Nominal Battery Life
Battery Voltage
Current Draw
Sounder Loudness
Sounder Frequency
Transmitted Indications
2.4 GHz
Three Panasonic alkaline AAA
6 Months
4.5 VDC (Nominal) 3.6 VDC (Low)
100 mA (Maximum) 4.0 uA (Quiescent)
90 dBA at 10 feet
3.2 kHz to 4.0 kHz
Low Battery, Supervisions
Certication
RE626
RE626-CE
FCC, IC
EN60950-1, EN300 220, EN301 489, CE, RCM
Specications subject to change without notice
