AmbiCom WL151NUSB Wireless-N USB Dongle User Manual
AmbiCom Holdings, Inc. Wireless-N USB Dongle
AmbiCom >
User Manual
Quick Installation Guide
IEEE 802.11n
Wireless-N USB Dongle
WL150N-nUSB, WL150N-USBx, WL151N-USB,
WL250N-USB, WL300N-USB
(Read Me First)
Please install the driver before inserting the USB dongle
WiFi Protected Setup (WPS)
Pin-Code (Software WPS) or Push-Button Configuration
Your other existing wireless peripherals must support WPS
feature. After the driver has been installed, simply activate
WPS feature on both devices to automatically configure the
USB adapter wireless network security. See Page 4.
2
System Requirements
USB 2.0 port (May not work on certain USB 1.1 port, and
performance will be greatly reduced)
Windows 2000, XP, or Vista operating system
CD-ROM drive
At least 100MB of available disk space
Important Notice:
If you want to use all the features provided by the wireless
USB dongle or you are using Windows 2000, please select
“Install driver and AmbiCom Wireless Utility” or “Ralink
Configuration Tool” during setup.
Please note the “Install driver only” option will not install all
the wireless configuration features. Your new wireless USB
dongle will be configured and managed by “Microsoft Wireless
Zero Configuration Tool”. This tool provides minimal
configuration and only available on Windows XP and above
version.
3
Driver Installation
This guide will help you to install your USB dongle using the
minimum set of parameters. For a detail description of the
USB features, please refer to the digital manual on the CD.
1. Insert the Wireless Driver Setup CD into your CD-ROM
drive. The setup should start automatically.
Note:
If the Setup screen does not start automatically:
I.Click the Windows Start button, and then select Run.
II. Browse to the CD-ROM drive and select “setup.exe”
2. Select “Wireless-N Family” option and select the
corresponding driver.
3. Accept the License agreement. Follow the recommended
steps below for your specific model.
Note: Select “AmbiCom Wireless Utility” or “Ralink
Configuration Tool” only if you require certain special
features, such as WPS (software WPS) or changing WPS Pin
number. However, Windows 2000 operating system user
should select “AmbiCom Wireless Utility” or “Ralink
Configuration Tool”. Otherwise, see below:
4
5. Click “Finished” when the driver installation is done.
6. Insert the USB dongle into an available USB port and wait
for the driver to finish its configuration.
7. A new icon will appear at the bottom right corner. Double-
click on the icon and open the configuration menu.
Wi-Fi Protected Setup (WPS)
Pin-Code (Software WPS)/Push Button Configuration
Depends on your model, the USB adapter support either Pin-
Code WPS (software based WPS) or both Pin-Code and Push
Button WPS features. WPS is a standard for easy and secure
to add a new wireless device to your protected wireless home
network without typing or configure complex wireless security
setting with a compatible devices.
If your USB does not comes with a button on the USB dongle,
the WPS feature is configure using the “AmbiCom Wireless
Utility” or “Ralink Configuration Tool”. Otherwise, simply press
the WPS button on both the USB dongle and a WPS capable
wireless router devices for 2 seconds (refer to your router
manual) to automatically configure the wireless
5
security. Your new deivce will be joining your protected
wireless home network within minutes.
For a detailed information about features and functions, you
may refer to digital manual on the Driver installation CD.
Technical Support
Weekdays: 9:00a.m - 6:00p.m.
(Monday – Friday. Except holidays)
Phone: (408) 321 – 0822
Email: support@ambicom.com
Website: www.ambicom.com
Disclaimer
This product is design for indoor use only. AmbiCom Inc., is not liable for the personal
injury and property damage cause by misuse of this product. By using this product,
users agree to obey their local regulations, public safety laws, and maintaining safety
environment to other user. Specifications are subject to change without prior notice. All
other brands and names are the property of their respective owners.
Warranty - 1 Year Limited Warranty
AmbiCom, Inc. warrants its product to be free from defects in materials and
workmanship, under normal use and service, for 1 year from the date of purchase from
its Authorized Reseller with proof of purchase. This warranty gives you specific
legal rights. You may also have other rights that vary from state to state.
RMA number and Proof of Purchase are required for all warranty
service.
6
USA/Canada
During the warranty period, AmbiCom, Inc. will, at its option, either repair or replace
defective products with similar parts and products. Should the product be identified as
defective, the end user is responsible for returning the product to the place of purchase1
/ manufacturer2 and the cost of shipping and handling. Any replaced or repaired product
has a ninety-day (90-day) warranty or the remainder of the initial warranty period,
whichever is longer.
Outside USA/Canada
During the warranty period, AmbiCom, Inc. will, at its option, either repair or replace
defective products with similar parts and products. Should the product be identified as
defective, the end user is responsible for returning the product to the place of purchase1
/ manufacturer2 and the cost of shipping and handling for sending and returning the
product. Any replaced or repaired product has a ninety-day (90-day) warranty or the
remainder of the initial warranty period, whichever is longer. AmbiCom, Inc. shall not be
responsible for any software, firmware, information or memory data of customer
contained in, stored on, or integrated with any products returned to AmbiCom, Inc.
pursuant to any warranty.
1if within store return policy period. Check with the store policy.
2iif store return policy has expired or requesting for a warranty service.
Exclusion: The warranty on your products shall not apply to defect or damages resulting
from:
Improper or inadequate handling or installation of the product operation outside the
environmental specification for the products.
Incidental, contingent, or consequential charges.
Power spikes or other power related damage.
Compatibility problems with any other software of hardware products.
Installation of any other software of hardware products.
Physical damage causes by misuse, misapplication or negligence.
Warranty Limitations
The warranty set forth above is exclusive and no other warranty, whether
written or oral is expressed or implied. AmbiCom, Inc. specifically disclaims
the implied warranties of merchantability and fitness for a particular purpose.
7
AmbiCom, Inc. also specifically disclaims any responsibility for any incidental or
consequential damages that its products may cause. A buyer’s recourse shall be strictly
limited to those contained in this warranty. Some states do not allow these limitations
on the length of an implied warranty, so the above limitations or exclusions may not
apply to you. However, any implied warranty or merchantability of fitness for a
particular purpose is for a period of 1 year on this written warranty. AmbiCom, Inc.
reserves the right to change its warranty policy without prior notice. Information
provided in this manual is subject to change without prior notice. For last minute
warranty changes that is not printed as time of publishing, please contact
support@ambicom.com.
Federal Communication Commission - Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
4. Consult the dealer or an experienced radio technician for help.
FCC Caution
This device and its antenna must not be co-located or operating in conjunction with any
other antenna or transmitter. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Any changes or
modifications not expressly approved by the party responsible for compliance
could void the authority to operate equipment.
8
Federal Communication Commission (FCC) Radiation Exposure Statement
This equipment complies with SAR for general population/uncontrolled
exposure limits in ANSI/IEEE C95.1-1999 and had been tested in accordance
with the measurement methods and procedures specified in OET Bulletin 65
Supplement C.
The equipment version marketed in US is restricted to usage of the channels
1-11 only.
R&TTE Compliance Statement
This equipment complies with all the requirements of DIRECTIVE 1999/5/EC OF THE
EUROPEAN PARLIAMENT AND THE COUNCIL of March 9, 1999 on radio equipment and
telecommunication terminal Equipment and the mutual recognition of their conformity
(R&TTE)
The R&TTE Directive repeals and replaces in the directive 98/13/EEC
(Telecommunications Terminal Equipment and Satellite Earth Station Equipment) As of
April 8, 2000.
Safety
This equipment is designed with the utmost care for the safety of those who install and
use it. However, special attention must be paid to the dangers of electric shock and
static electricity when working with electrical equipment. All guidelines of this and of the
computer manufacture must therefore be allowed at all times to ensure the safe use of
the equipment.
EU Countries Intended for Use
The ETSI version of this device is intended for home and office use in Austria, Belgium,
Denmark, Finland, France, Germany, Greece, Ireland, Italy, Luxembourg, the
Netherlands, Portugal, Spain, Sweden, and the United Kingdom.
The ETSI version of this device is also authorized for use in EFTA member states:
Iceland, Liechtenstein, Norway, and Switzerland.
EU Countries Not intended for use
None.
Rev2.2
