Amimon AMNPTRX01 Wireless Video Receive Module User Manual AMN DOC 004 ENx
Amimon Ltd. Wireless Video Receive Module AMN DOC 004 ENx
Amimon >
User Manual
1
AMIMON limited warranty
i. Limited Hardware Warranty. Subject to the terms of this warranty,
Amimon warrants the hardware product provided to you against any
defects and materials in workmanship when used in accordance with
Amimon’s published guidelines for a period of one year from the date of
original retail purchase by the end user purchaser (the “Warranty
Period”). Published guidelines include but are not limited to information
contained in technical specifications, user manuals and service
communications. If you purchase the Product through a reseller,
distributor or retailer, such entity may provide for additional or extended
warranties other than those set forth herein. In such event, you should
be in direct contact with such reseller, distributor or retailer to exercise
your rights under such additional or extended warranty. Amimon shall
have no obligation or liability in respect of such additional or extended
warranties.
ii. Exclusions. The Limited Hardware Warranty set forth in Section 1 shall
not apply in the event that a breach of such warranty the results of the
Product (including any Software), being (a) used other than in
accordance with this Agreement, or other Amimon published guidelines,
(b) modified, repaired, serviced, maintained or altered by anyone other
than Amimon without the prior written approval of Amimon in each
instance; for the avoidance of doubt, the modification of any software
embedded in the Products shall result in the immediate voiding of the
Limited Hardware Warranty and the opening of any enclosure of the
Product or the exposure of any inner Hardware of the Product shall also
result in the immediate voiding of the Limited Hardware Warranty; (c)
combined with or installed on/with operating systems, hardware or other
non-Amimon equipment not approved by Amimon; (e) installed not in
accordance with documentation or instructions of Amimon; or (f)
damaged by causes beyond the reasonable control of Amimon, such as
AMN_DOC_004_EN
2
a fire, flood or earthquake. The warranties do not apply (a) to
consumable parts, such as batteries, that are designed to diminish over
time, (b) to cosmetic damage, such as scratches and dents or (c) to
defects caused by normal wear and tear and the normal aging of the
Product. The warranties extend only to you and do not extend to any
other individual or entity. The warranties shall be voided if any serial
number shall be removed or defaced.
iii. Remedy. The product manual will provide you with directions on how to
submit a warranty claim to Amimon. Warranty claims should be
submitted via Amimon Support portal at www.amimon.com.
If during the Warranty Period you submit a valid claim under this
warranty to Amimon, Amimon will, at its option, (i) repair the Product
using new or previously used parts that are like new in performance and
reliability, (ii) replace the Product with a device that is at least functionally
equivalent to the Product and is formed from new and/or previously used
parts that are like new in performance and reliability, or (iii) exchange
the Product for a refund of your purchase price. Before receiving
warranty service, Amimon may require you to provide proof of purchase.
iv. Consumer Law. This warranty gives you specific legal rights, and you
may have other rights that vary according to your jurisdiction. Other than
as permitted by law, this warranty does not exclude, limit or suspend
other rights you may have under applicable law. For a full understanding
of your rights you should consult the laws of your jurisdiction.
v. Disclaimer. Except as expressly set out herein, Amimon does not make
any representations or warranties and expressly disclaims all other
warranties (including any implied or statutory warranties), including
without limitation any warranties of merchantability, fitness for a
particular purpose, title or non-infringement or any other warranties
arising by statute, operation of law, course of dealing or performance, or
usage of trade. Some jurisdictions do not allow disclaimers of implied
warranties, so this disclaimer may not apply to you.
3
Product Information
Any changes or modifications to the product not expressly approved by
AMIMON could void the user's authority to operate the equipment.
Antenna: The product is provided with an approved antenna. Use only
supplied or approved antenna by AMIMON. Any changes or modifications
to the Antenna may void the regulatory approvals obtained for the product.
Safety Instructions
When operating this equipment, read and follow all the instructions
in this manual.
Do not open unit.
Do not block the air ventilation openings.
Use only accessories/batteries/chargers specified or recommended
by Amimon.
When devices are switched on keep away at least 20 cm from your
body.
Do not expose to moisture, excessive heat or fire
Keep away from water and other liquids
Do not charge the device when it is wet or damp
Use the mains plug to disconnect the apparatus.
Clean with a dry cloth only.
Unplug this apparatus during lightning storms or when unused for
long periods of time.
To reduce the risk of fire or electric shock, refer servicing to qualified
service personnel.
Keep these instructions in a safe and accessible place for future use.
Declared maximum operating temperature: +50°C
4
Ground-Unit AC Power Adapter
All components must be dry before connecting to an external
power source.
Use ONLY a UL LISTED ITE (IEC/EN 60950-1, LPS and SELV) power
supply with electrical ratings: Output 12 V-DC, min 1 A, with ambient
temperature range of 0°C to 40°C. Use of alternative AC power adapter
will invalidate any approvals given to this unit and may be dangerous.
Battery
This device is not supplied with batteries. In case a battery is
used, please adhere to the following general battery usage
guidelines:
Use batteries with the rated voltage and current characteristics as
listed in the manual
Do not use incompatible/incorrect batteries. Use of an incompatible
battery may present a risk of fire, explosion, leakage, or other
hazard.
Dispose of used batteries according to instructions and local
recycling guidance.
Do not disassemble or open, crush, bend or deform, puncture, or
shred.
Severe impact from dropping any battery-operated device on a hard
surface could cause the battery to overheat.
Do not short circuit a battery or allow metallic or conductive objects
to contact the battery terminals.
Do not modify or remanufacture, attempt to insert foreign objects into
the battery, immerse or expose to water or other liquids, or expose
to fire, explosion, or other hazard.
Do not leave or store the equipment in or near areas that might get
very hot, such as in a parked vehicle or near a radiator or other heat
source. Do not place battery into a microwave oven or dryer.
Battery usage by children should be supervised.
5
Do not dispose of batteries in fire.
Seek medical advice immediately if a battery has been swallowed.
In the event of a battery leak, do not allow the liquid to come in
contact with the skin or eyes. If contact has been made, wash the
affected area with large amounts of water and seek medical advice.
RF Exposure
The product complies with internationally recognized standards covering
human exposure to electromagnetic fields from radio devices.
To satisfy local RF exposure regulation requirements, the transmitting
product must operate with a minimum separation distance of 20 cm or
more from a person’s body.
Industry Canada Statement
IMPORTANT NOTE: NOTE IMPORTANTE:
Radiation Exposure
Statement:
This equipment complies with
IC radiation exposure limits
set forth for uncontrolled
environment. This equipment
should be installed and
operated with minimum
distance 20cm between the
radiator and your body.
Déclaration d'exposition aux
radiations:
Cet équipement est conforme aux
limites d'exposition aux
rayonnements IC établies pour un
environnement non contrôlé. Cet
équipement doit être installé et
utilisé avec un minimum de 20 cm
de distance entre la source de
rayonnement et votre corps.
FCC Statement
Radio Transmitters (Part 15) – Class B Digital Devices
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
6
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not in-stalled and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and receiver
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected
Consult the dealer or an experienced radio/TV technician for help.
Industry Canada Statement
This device complies with RSS-210
of the Industry Canada Rules.
Operation is subject to the
following two conditions: (1) This
device may not cause harmful
interference, and (2) this device
must accept any interference
received, including interference
that may cause undesired
operation.
Ce dispositif est conforme à la
norme CNR-210 d'Industrie
Canada applicable aux
appareils radio exempts de
licence. Son fonctionnement
est sujet aux deux conditions
suivantes: (1) le dispositif ne
doit pas produire de brouillage
préjudiciable, et (2) ce
dispositif doit accepter tout
brouillage reçu, y compris un
brouillage susceptible de
provoquer un fonctionnement
indésirable.
7
7
Caution: Avertissement:
i. the device for operation in the
band 5150-5250 MHz is only for
indoor use to reduce the
potential for harmful interference
to co-channel mobile satellite
systems;
ii. high-power radars are allocated
as primary users (i.e. priority
users) of the bands 5250-5350
MHz and 5650-5850 MHz and
that these radars could cause
interference and/or damage to
LE-LAN devices.
iii. for devices with detachable
antenna(s), the maximum
antenna gain permitted for
devices in the bands 5250-
5350 MHz and 5470-5725 MHz
shall be such that the equipment
still complies with the e.i.r.p.
limit;
iv. for devices with detachable
antenna(s), the maximum
antenna gain permitted for
devices in the band 5725-
5850 MHz shall be such that the
equipment still complies with the
e.i.r.p. limits specified for point-
i. Le dispositifs fonctionnant
dans la bande 5 150-5 250
MHz sont réservés
uniquement pour une
utilisation à l’intérieur afin
de réduire les risques de
brouillage préjudiciable aux
systèmes de satellites
mobiles utilisant les mêmes
canaux;
ii. De plus, les utilisateurs
devraient aussi être avisés
que les utilisateurs de
radars de haute puissance
sont désignés utilisateurs
principaux (c.-à-d., qu’ils
ont la priorité) pour les
bandes 5 250-5 350 MHz et
5 650-5 850 MHz et que
ces radars pourraient
causer du brouillage et/ou
des dommages aux
dispositifs LAN-EL.
8
to-point and non-point-to-point
operation as appropriate
CE Compliance Statement
Hereby, AMIMON Ltd, declares that this Radio
Transmitter is in compliance with the essential requirements and other
relevant provisions of Directives 1999/5/EC and 2011/65/EU.
https://connexuav.zendesk.com/hc/en-us/articles/204056509
This equipment may be operated in all EU countries.
Waste Electrical and Electronic
Equipment (WEEE)
English: Waste electrical and electronic equipment should
not be disposed of with household waste. Please recycle
where facilities exist. Check with you local authority or retailer for recycling
advice.
Français: Déchets d'équipements électriques et électroniques ne doit pas
être jeté avec les ordures ménagères. S'il vous plaît recycler où les
installations existent. consultez auprès de votre autorité locale ou le
détaillant pour obtenir des conseils de recyclage.
Deutsch: Elektro- und Elektronik-Altgeräte dürfen nicht mit dem Hausmüll
entsorgt werden. Bitte recyceln, wo Anlage vorhanden sind. Beraten Sie
sich bei Ihren lokale Behörde oder händler über Recycling information
