1
A610
WCDMA DIGITAL MOBILE
PHONE MANAUL
2
1 The Basics
1.1 Overview
Thank you for choosing the GSM/GPRS digital mobile phone.
After reading this guide you will be able to fully master the use of your
phone and appreciate all its functions and ease of use.
Not only does the smartphone provide you with basic call
functions such as call Register, but also with many practical functions
and services, to improve the time you spend working and playing.
The color screen mobile phone complies with the GSM/GPRS
technology and has been approved by certification authorities both
domestically and abroad.
The availability of some services and features described in this
manual depends on the network and your subscription. Therefore,
some menu items may not be available in your phone. The shortcuts to
menus and features may also vary from phone to phone.
Our company reserves the right to revise this manual content
without prior notice.
1.2 Safety guide
If your mobile phone is lost or stolen, please contact the
telecommunications authorities or a sales agent immediately to
have a hold on the phone and the SIM card. This will prevent
economic loss caused by unauthorized calls made from your
mobile phone.
3
When you contact the telecommunications authorities or a sales
agent, they will need to know the IMEI number of our mobile
phone (remove battery to expose number located on the label on
back of phone). Please copy this number and keep in a safe place
for future use.
In order to avoid the misuse of your mobile phone please take
the following preventative measures:
- Set the PIN number of your mobile phone’s SIM card and
change this number immediately if it becomes known to a
third party.
- Please keep the phone out of sight when leaving it in a
vehicle. It is best to carry the phone with you, or lock it in the
trunk.
- Set call barring.
1.3 Safety warnings and notices
Before using your mobile phone, read and understand the following
notices carefully to ensure you will use it safely and properly.
1.3.1 General attention
Only the battery and battery charger specified by our
company should be used in your phone. Other products might
result in battery leakage, overheating, fire or explosion.
To avoid your phone malfunctioning, or catching fire, please
do not violently impact, jolt or throw your phone.
Please do not place the battery, mobile phone, or charger in a
microwave oven or high-pressure equipment. Otherwise it
could lead to unexpected accidents such as damage to the
4
circuitry or fire hazard.
Please do not use your phone near flammable or explosive
gases, otherwise it could cause malfunction of your phone or
fire hazard.
Please do not subject your phone to high temperatures, high
humidity or dusty places; otherwise this may lead to the
malfunction of your phone.
Keep your phone out of the reach of small children. Your
phone is not a toy. Children could hurt themselves.
To avoid your phone falling and malfunctioning or being
damaged, please do not place it on uneven or unstable
surfaces.
1.3.2 Notices when using your phone
Turn off your mobile phone where the phone is not allowed,
such as, on the airplane or in hospitals. Using the mobile
phone in those places may impact the normal operation of
electronic devices and medical instruments. Follow relevant
regulations when using your mobile phone in those places.
Your mobile phone has the auto turn-on feature. Check your
alarm clock settings to confirm that your mobile phone will
not be turned on automatically during flight.
Please do not use your mobile phone near the weak signal or
high precision electronic devices. RF interference might
cause malfunctioning of such electronic devices and other
problems. Special tips must be paid near the following
equipment: hearing aids, pace makers and other medical
5
electronic devices, fire detectors, automatic doors and other
automatic control installations. To find out the effect of mobile
phones on a pacemaker or other pieces of electronic medical
equipment please contact the manufacturers or local sales
agents of the equipment.
Please do not subject the LCD to impact or use the screen to
strike things, as this will damage the LCD board and cause
leakage of the liquid crystal. There is a risk of blindness if the
liquid crystal substance gets into the eyes. If this occurs rinse
eyes immediately with clear water (under no circumstances
rub your eyes) and go immediately to a hospital for
treatment.
Do not disassemble or modify your mobile phone, as it will
lead to damage to the phone such as battery leakage or
circuitry failure.
Under very rare circumstances using the mobile phone in
certain model cars may negatively affect the internal
electronic equipment. In order to assure your safety under
such circumstances please do not use the mobile phone.
Please do not use needles, pen tips, or other sharp objects
on the keypad as this may damage the mobile phone or
cause it to malfunction.
In the event of antenna malfunction, do not use your phone,
as it could be harmful to human body.
Avoid letting the phone come into close contact with
magnetic objects such as magnetic cards as the radiation
6
waves of the mobile phone may erase the information stored
on floppy disks, pay cards and credit cards.
Please keep small metal objects, such as thumbtacks far
away from the receiver. When the receiver is in use it
becomes magnetic and may attract these small metal objects
and thus these may cause injury or damage the mobile
phone.
Avoid having the mobile phone come into contact with water
or other liquids. If liquids enter the phone, this could cause a
short circuit, battery leakage or other malfunction.
1.3.3 Notices when using the battery
The battery has a limited service life. The remaining life gets
shorter as the times of charging increase. If the battery
becomes feeble even after the charging, this indicates the
service life is over and you have to use a new battery.
Do not dispose of old batteries with everyday domestic
garbage. Please dispose of old batteries at the directed
places with specific rules for their disposal.
Please do not throw batteries into a fire, as this will cause the
batter to catch fire and explode.
When installing the battery, do not use force or pressure, as
this will cause the battery to leak, overheat, crack and catch
fire.
Please do not use wires, needles or other metal objects to
short-circuit the battery. Also, do not put the battery near
necklaces or other metal objects, as this will cause the
7
battery to leak, overheat, crack and catch fire.
Please do not solder the contact points of the battery, as this
will cause the battery to leak, overheat, crack and catch fire.
If the liquid in the batteries goes into the eyes, there is a risk
of blindness. If this occurs do not rub the eyes, but
immediately rinse eyes with clear water and go to the
hospital for treatment.
Please do not disassemble or modify the battery, as this will
cause the battery to leak, overheat, crack and catch fire.
Please do not use or place the batteries near high
temperature places such as near a fire or heating vessel, as
this will cause the battery to leak, overheat, crack and catch
fire.
If the battery overheats, changes color, or becomes distorted
during use, charging, or storage, please stop using and replace it
with a new battery.
If the liquid from the battery comes in contact with skin or clothing
this could cause burning of the skin. Immediately use clear water
to rinse and seek medical tips if necessary.
If the battery leaks or gives off a strange odor, please remove the
battery from the vicinity of the open fire to avoid a fire or explosion.
Please do no let the battery become wet as this will cause the
battery to overheat, smoke and corrode.
Please do not use or place batteries in places of high temperature
such as in direct sunlight, as this will cause the battery to leak and
overheat, lower performance, and shorten the battery’s life.
8
Please do not continuously charge for more than 24 hours.
1.3.4 Charging your phone
Connect the connector of charger to the mobile phone. The
battery level indicator flashes on the screen. Even if the phone
has been turned off, the charging image still appears, indicating
that the battery is being charged. If the phone is overused when
the current is insufficient, it may take longer time for the charging
indicator to appear on the screen after the charging begins.
When the battery level indicator does not flash and indicates the
battery is full, this indicates the charging has been completed. If
the phone is off during charging, the charging being completed
image also appears on the screen. The charging process often
takes 3 to 4 hours. During the charging, the battery, phone and
charger gets warm, this is a normal phenomenon.
Upon the completion of charging, disconnect the charger from AC
power socket, and from the mobile phone.
Notes:
During charging, the phone must be placed in well-ventilated
environment of ＋5℃ ~ ＋40℃. Always use the charger supplied
by your phone manufacturer. Using an unauthorized charger
might cause danger and invalidate the authorization and warranty
clauses for your phone.
The standby time and call duration provided by the manufacturer
are based on ideal operating environment. In practice, the
battery's operating time varies depending on network conditions,
operating environment and usage methods.
9
Make sure the battery has been installed before charging. It is
best not to remove the battery while charging.
Upon completion of charging, disconnect the charger from your
phone and the power supply.
If you have not disconnected the charger from your phone and the
power supply, the charger will continue to charge the battery after about
5 to 8 hours when the batter level decreases substantially. We advise
you not to do like this, as it lowers your phone performance and
shortens your phone life.
Notices when using your charger
Please use AC 220 volts. The use of any other voltage will cause
battery leakage, fire and cause damage to the mobile phone and
charger.
It is forbidden to short circuit the charger, as this will cause
electrical shock, smoking and damage to the charger.
Please do no use the charger if the power cord is damaged, as
this will cause fire or electrical shock.
Please immediately clean any dust gathered on the electrical
outlet.
Please do no place vessels with water near the charger in order to
avoid water splashing onto the charger and causing an electrical
shortage, leakage or other malfunction.
If the charger comes in contact with water or other liquid the power
must immediately be switched off to avoid an electrical short or
shock, fire or malfunction of the charger.
Please do not disassemble or modify the charger, as it will lead to
10
bodily harm, electrical shock, fire or damage to the charger.
Please do not use the charger in the bathroom or other
excessively moist areas, as this will cause electrical chock, fire or
damage to the charger.
Please do not touch the charger with wet hands, as this will cause
electrical shock.
Do not modify or place heavy objects on the power cord, as this
will cause electrical shock or fire.
Before cleaning or carrying out maintenance please unplug the
charger from the electrical outlet.
When unplugging charger, do not pull on the cord, but rather hold
on to the body of the charger, as pulling on the cord will damage
the cord and lead to electrical shock or fire.
1.3.5 Cleaning and maintenance
The mobile phone, battery, and charger are not water resistant.
Please do not use them in the bathroom or other excessively
moist areas and likewise avoid allowing them to get wet in the
rain.
Use a soft, dry cloth to clean the mobile phone, battery and
charger.
Please do not use alcohol, thinner, benzene or other solvents to
wipe the mobile phone.
A dirty outlet will cause poor electrical contact, lose of power and
even inability to recharge. Please clean regularly
11
2.1.1 Icons
In the standby mode, the following icons may appear in standby
screen:
Icon Description
Indicate the intensity of network signals.
Show missed calls.
Location by satellite.
Receive a new message.
An application is being downloaded.
The downloading is over.
The alarm clock has been set and activated.
A call is in progress.
The phone is playing a song.
The application manager is on.
Show battery level.
Enable USB.
The access is blocked.
Get connected to the wireless network
Turn on the Bluetooth.
No SIM card is installed in the phone.
No storage card is installed in the phone.
12
2.2 Key explanations
Key Explanations
Return
key
●Return to the previous menu.
Menu key ●Show options of current menu.
Search key
●Generally press the key to open
google screen.
Home key
●At any status, press the key to return to
the standby screen.
Power key
● Hold down this key to turn your phone
off and on.
● Generally, press this key to lock the
mobile phone.
Side volume
keys
● During the conversation, press the
two keys to adjust the volume.
● While playing an audio file, press the
two keys to adjust the volume.
13
Note: In this guide, the phrase “press the key” refers to pressing and
thereafter releasing a key. “Hold down a key” refers to pressing a key
and keeping it depressed for 2 seconds or longer.
The descriptions and functions of keys depend on the model of
your phone.
2.3 Using the touchscreen
Your phone provides many touch keys in the Main screen. To use these
keys correctly, calibrate the touch screen in advance (see “Calibrator”).
Meanwhile please follow the instructions:
■Do not touch the screen with wet hands.
■Do not touch the screen with great forces.
■Do not touch the screen with metallic or conductive objects.
2.4 Connecting to the network
2.4.1 Inserting and removing the SIM card
Turn off the phone; remove the battery and unplug other external
power supplies. Insert the SIM card into the SIM holder as shown
in the phone.
When you need to remove the SIM card, turn off the phone,
remove the battery and then remove the SIM card from the holder.
Warning: Do turn off your phone before removing the SIM card. Never
insert or remove the SIM card when an external power supply is
connected, as this may cause damage to the SIM card.
2.4.2 Turning your phone on and off
To turn on the phone, hold down the POWER key on the top; to
turn off the phone, hold down the POWER key.
14
If you have turned on your phone without inserting the SIM card,
the phone will prompt you to install the SIM card. With the SIM card
already inserted, your phone automatically verifies the availability of the
SIM Card.
Then, the screen shows the following:
Enter PIN1 —— if your have set the SIM card password.
Enter phone password —— if you have set your phone password
Search for network—— the phone searches for the appropriate
network.
Notes：
If when you turn on the mobile phone, an exclamation mark appears on
the screen and does not disappear, this is possibly caused by
misoperation, that is, you press the Power key and the Volume Up key
at the same time. Such misoperation activates the recovery mode,
hence the occurrence of exclamation mark. If you just turn off the phone,
next time when you turn it on, it will still come to the recovery mode.
Solution：
Press the Home key （ ）when the exclamation mark and robot
appear, a menu will pop up. Use the Menu key （ ） to select
"reboot system now" to restart the phone.
2.4.3 Unlocking the SIM card
The PIN 1 (personal identification number) secures your SIM card
from being misused by others. If you have selected this function, you
must enter the PIN1 code each time you turn on the phone so that you
may unlock the SIM card and then make or answer calls. You can
15
deactivate SIM card protection (see “Safety settings”). In this case, the
misuse of your SIM card cannot be prevented.
Press the Hang Up key to turn on your phone;
Enter your PIN1 code. Clear the incorrect digits by using the right
soft key, and press OK for confirmation. e.g. if your PIN1 is 1234,
please enter:
1 2 3 4
If you enter incorrect numbers for three times in succession, your
SIM card will be locked and your phone will ask you to enter PUK 1
number. If you do not know the PUK1 code, do not try. Instead, contact
your network service provider. See “Safety settings”.
Note: your network service provider sets a standard PIN1 code (4 to 8
digits) for your SIM card. You should immediately change this number.
See “Safety settings”.
2.4.4 Unlocking your phone
To prevent unauthorized use, you can set phone protection. If you
have selected this function, you must draw unlocking pattern each time
you turn on your phone, to unlock the phone and then make or answer
calls. You may clear the unlocking pattern (see “Safety settings”). In this
case, the unauthorized use of your phone cannot be protected.
If you forget your phone password, you must contact the retailer or
local authorized service center to unlock your phone.
2.4.5 Connecting to the network
Once your SIM card is unlocked, your phone searches for
available network automatically (the screen will show the network
searching is underway). If your phone has found the available network,
the name of network service provider appears at the center of screen.
Note: Making an emergency call。Note: If “only for emergency calls”
appears on the screen, it indicates that you are beyond the network
coverage (service area), and that you can still make emergency calls
depending on the signal intensity.
16
2.4.6 Making a call
When the logo of network service provider appears on the screen,
you can make or answer a call. The bars at the upper left corner of
screen indicate the intensity of network signal.
Conversation quality is significantly affected by obstacles, thus
moving within a small area while making or answering a call can
improve the conversation quality.
2.4.7 Making a domestic call
In the Dial screen, enter a number, and press the Dial key to make
a call. To change the number, delete the digits you have entered.
During dialing, the animation appears on the screen. After the call is
picked up, the screen will show call status information. If the connection
alert tone has been set, your phone will ring the alert tone (network
dependent).
To end a call, press the Hang Up key.
Zone code Phone number Dial key
2.4.8 Making an international call
To make an international call, hold down the 0 key on the Dialing
screen until the international prefix "+” for appears. This allows you to
dial an international number without knowing its international fix (e.g. 00
for China).
Following the entry of international prefix, enter the country code
and complete phone number. For the country codes, follow the general
conventions, for example, 49 for Germany, 44 for UK, and 46 for
Sweden.
Like making an international call via a fixed telephone, omit the
“0” at the head of a city code.
For example, to call our hotline from another country, you can
dial:
17
+86 21 114
+ Country code Complete phone number Dial key
2.4.9 Making a call from the list
All calls dialed and received are stored within a list in your phone.
Those dialed and received recently are exhibited at the top of the list
(see “Call Register”). All the numbers are sorted by Dialed Calls,
Received Calls and Missed Calls. Your phone also provides options for
you to view all calls. When the call Register is full, the old numbers will
be deleted automatically. To view the list, do the following:
To view the dialed calls, press the Dial key
You can dial any number from the list by pressing the Dial key.
When the call list appears, press OK to see details, or go to
Options -> Save to place the number into your Phonebook.
2.4.10 Making an emergency call
If you are beyond the network coverage (see network-signal-intensity
bars at the upper left corner of the screen), you can still make
emergency calls. If your network service provider does not provide
roaming service to the area, the screen will show “only for emergency
calls”, alerting you that you can only make such calls. If you are within
the network coverage, you can also make emergency calls even
without the SIM card.
2.4.11 Call menu
The Call menu is only visible during an active call, and features
such as Call Waiting, Call Diverting, and Multiple-party Call are network
dependent. Contact your network service provider.
The call options include:
Mute
Do not send local voice.
Handsfree
Switch on the loudspeaker to amplify the voice.
Hold
18
Put the current call on hold or retrieve the call on hold.
End a call.
End the current call.
More
*Start voice recording
Start voice recording.
*Turn on Bluetooth
The Bluetooth device, if any, can be used.
*New call
Make another new call.
3 Functional Menu
（※The following features depends on specific models）
3.1 backup and restore
This feature allows you to backup and restore.
notice,piease insert your SD card.
3.2 Browser
Browser enables you to surf the web via your phone, as if via a
computer. You may create a bookmark on your phone and synchronize
the bookmark with your computer. You can quickly go to your favorite
websites from the Main screen. You may select from the horizontal
and vertical modes to view a webpage. The phone automatically
changes the screen orientation to suit the webpage, depending on how
you are rotating your phone.
19
3.3 Calculator
Your phone provides a calculator with 4 basic functions so that you
can perform some simple calculations.
To clear the latest input or result, press the “Clear” key.
Note: The calculator is limited in accuracy and will result in
rounding error.
3.4 Calendar
Calendar allows you to view your schedules and events at any time.
You may view schedules one by one or at the same time.
Select to show calendar by day, week or month. If “by week”, the
calendar will be shown by week. This application is convenient for you
to add events or view schedule.
3.5 Camera
Your phone provides the camera and video recorder features. No
matter where you will go, you can take high-resolution photos and
videos. Press Options to set options.
3.6 Clock
■ clock
Enter the menu to display the current time
■ Alarms
Your phone provides many groups of alarm clocks. Select one of
them to edit and customize alarm clock.
20
3.7 Downloads
Here you can see the download on the web browser
download things, may cancel or suspend or delete etc.
3.8 Email
The Email application lets you to forward Emails to anyone who
has an Email address.
Enable the application, set up an Email account, and then you can
edit, delete, receive or send Emails, as if via a computer. You can also
add or enter another Email account. This application needs support
from the network.
3.9 File Manager
Enter the file management for replication, move, delete
operation
4.0 FM Radio
Wear your earpieces of radio before searching for channels.
Glossary：
Channel list：Display the list of FM radio channels. You can select
to play one of them. (The list can contain 20 channels maximum.)
Search：Select this option to automatically search for channels
and generate the list of channels.
Loudspeaker: Press the button to use the radio loudspeaker.
and : Tap to move to another channel.
►and: Tap to broadcast and pause.
21
4.1 Gallery
Gallery is a picture manager that typically exhibitsminiatures. Thanks
to the tool, you needn’t page up or down several even dozens of times
to find your favorite. Just a slight slide on the screen, lots of pictures
appear in your sight. In addition, the tool displays pictures in 3D manner,
and supports the features of “save picture”, “set picture as desktop”,
and “share picture”.
4.2 Gmail
The use of Google account synchronization to Google
download application market
4.3 Lock
Click this function can quickly lock screen.
4.4 Maps
Into the map can be positioned.
4.5 Messaging
Messaging lets you send text and multimedia messages to any
contact that has an SMS device. The multimedia messages include
photos, video clips (for iPhone 3GS or other new style phones),
contacts information, and voice memos. What’s more, you can send
messages to several contacts at the same time.
Note: Perhaps Messaging is not available in all countries and
regions. Probably you need pay for using Messaging. For more
22
information, consult your network operator.
As long as you are within the network, you can use “Messaging”.
As long as you can make a call, you can send messages. You probably
have to pay for sending or receiving messages, depending on your
network operator.
Send a message: Tap it, enter the number and name of the
contact or select the contact from Contacts. Tap the text box above
keypad, enter the information and then tap “Send”.
After selecting the number, you can select such options as Call,
Add subject, Attach, Insert facial expression, and more. Tap Settings to
set ringtone, Delivery reports, and maximum quantity of messages.
4.6 Music
Enter a play list of songs to play music.
4.7 People
The “People” lets you easily call your colleagues or friends, or
send emails or short messages to them. You may add contacts directly
from your phone, or synchronize “Contacts” with any application on
your computer. You may open “Contacts” directly from the Main screen,
or open it via the “Dialing” application.
Add a People：
To add a contact, directly enter the name and phone number, or
import the name and phone number from the SIM card. (The quantity of
contacts you can add is limited by the memory of your phone.)
Search for People：
23
To search for a contact, press the Search key in search screen, and
a search box will pop up. In the search box, enter the key words, such
as first name, second name, and company name. While you are
entering the key word, the matching contacts immediately appear.
Edit a People：
To edit details of a contact, select “Edit a contact”.
Delete a People：
To delete the current contact, select “Delete a contact”.
From the menu, you can also set the tone of incoming calls,
synchronize with or share an account, or import or export a contact.
4.8 Phone
In the dialing interface to input the number and then click
to dial. This interface can also view call records and set etc
4.9 Play Store
Play Store provides direct access to useful applications which
you can download and install on your phone.
5.0 Search
Google can be used to search the information you want.
5.1 Settings
Reach the menu, customize your phone settings.
Dual-SIM settings：Select SIM card 1 or SIM card 2.
Wireless and network：Set and apply the fly
mode, wireless network, Bluetooth, virtual
24
private network, and mobile network.
Call settings：Set some advanced features
such as fixed dialing number, voicemail box,
call diverting, call barring, and call cost, etc.
These features depend on the network operator.
Audio effect：Customized setting-up of the
sound effects.
Audio profiles：General, Silent, Meeting
and Outdoor optional. In the meanwhile, customized setting-up of
some scene modes are allowed.
Select one mode to enter the customized
setting-up, operational are vibration, volume, ring tones, notifications
and key beep, etc.
Display：Customized setting-up of the Phone
Orientation, Luminance and Screen Time-Out is allowed.
Location and Safety：Activate or deactivate
the connection to wireless network and GPS; set unlocking pattern;
lock the SIM card; set the SD card.
Applications：View, manage and delete the
applications on your phone.
Account and synchronization：Set the synchronization of your
phone account with your phone.
Privacy：Set the google services on your
phone. Back up the data of settings.
Restore factory settings to clear all
personal data on your phone.
25
SD card and phone storage: Display the
internal memory of the memory card and
phone memory.
Language and keypad：Select a language and input method.
Voice input and output: Available by downloading and installing
the voice data “Speech Synthesis Data Installer” from the e-market.
Accessibility：Turn on and off accessibility.
Date and time：Set current date and time.
Schedule power on/off：Set the time to turn
on or off your phone.
About phone：View the signal intensity,
battery level, service status, mobile software and hardware information,
etc.
Wallpaper settings：Press the Menu key in
the standby screen, and then select “Wallpapers”. There are many
pieces of wallpapers for you to select from. These wallwapers come
from five sources.
5.2 SIM Toolkit
Insert the SIM card, can manipulate the related
application
5.3 Sound Recorder
Voice Recorder is used for creating audio files.
To start voice recording：Tap .
To end voice recording：Tap .
26
To play back voice recording：Tap .
The audio files are automatically stored on your phone. They can
be viewed with ES browser. You can select from various players to play
the voices recorded.
5.4 ToDo
Enter to-do editing text.
5.5 Torch
Click on the menu to open or close the flashlight
5.6 Videos
Enter the video playlist click on any video files.
6. Text Input
Enter text via the keypad. Examples of text include contact details,
emails, short messages, and websites. The keypad provides the
functions of spelling prediction, spelling correction and learning while
using.
The smart keypad may give you prompts of correct spelling,
depending on which application you are using.
Enter text：
1 Tap the text box (memo, or new contact) to call the keypad.
2 Tap the keys on keypad.
At the initial stage, you can tap keys using either of your index
fingers. Once you get familiar with the keypad, you can try tapping keys
using both of your thumbs.
27
While tapping a key, the corresponding letter will appear above
your thumb or another finger. If you are tapping a wrong key, you may
slide to the correct one. Only when your tapping finger leaves a key,
can the corresponding letter be entered in the text box.
To delete a character
Tap 。
To enter an
upper-case letter Tap , and then tap that letter.
To enter a digit Tap , and then tap that digit.
To enter a symbol Tap , and then tap that
symbol.
Quickly enter a space
Press the space key twice
successively.
To toggle between
Chinese and English
input methods
Tap “Chinese” key.
28
7 SD Card Introduction
Your mobile phone supports SD card to expand the memory. Install the
SD card according to the indication.
As one of storages for your phone, SD card has been set as the
default storage at factory. You can directly use it without making any
settings.
Use as flash disk: If “Phone——Data Wire——PC” is well connected,
the PC will prompt “New hardware is found”, and“MT65xx Android
Phone requires to be installed” will appear in the dialog box, see the
figure below:
Check the relevant menus in the phone are opened or closed, selecting
one by one as follows:
Main Menu - Settings - Application - Development - USB debugging.
Uncheck “USB debugging”.
After checking and confirmation, reconnect “Phone - Data Wire - PC”,
and make sure SD card has been inserted, the phone and SD Card
trough are normal. Follow the prompts appearing in the phone to
operate, so that data uploading and downloading with U disk can be
achieved.
。Note: The phone hard disk used as U disk not supported, SD card
supported only.
Your mobile phone supports the plug-in feature. However, if you insert
29
or remove the SD card without turning off your phone, we advise you to
turn on and off your phone, to ensure its normal operation. Generally, it
is not recommended to remove and install the SD card.
8 FAQs and Solutions
If you have any questions about the phone, please find the
solutions from the table below.
FAQs Causes Solutions
Poor
reception
When you use your
phone at poor
reception areas, for
example, near high
rise buildings or base
rooms, the radio wave
cannot be transmitted
effectively.
Avoid this as far as
you can.
When you use your
phone at network
traffic congestion,
such as working time
and off-duty time, the
congestion can result
in poor reception.
Avoid this as far as
you can.
This is related to the
distance to base
station in question.
You may ask the
network service
provider to provide
service coverage
map.
Echoes or
noises
The trunk line of
network is in bad
condition. It is a
regional problem.
Hang off the call and
dial again. Choose
another better line.
In some areas, the
call lines are in bad
condition.
30
Shorter
standby time
The standby time is
relevant to network
settings.
In poor reception
areas, turn off your
phone temporarily.
Replace the batteries
Change with a new
battery.
When no signals are
received, your phone
will continue
searching for base
stations, thus
consuming a large
amount of battery
power and reducing
standby time.
Use your phone at
strong signal areas or
Turn off the phone
temporarily.
Failed to turn
on your phone
The battery power is
used up.
Check the battery
power level or charge
the battery.
SIM card error
The SIM card is
damaged.
Contact your network
service provider.
The SIM card is not
properly installed.
Ensure the SIM card
is properly installed.
The metallic face of
the SIM card is
contaminated.
Wipe the face with a
clean cloth.
Failed to
connect to the
network
The SIM card is
invalid.
Contact your network
service provider.
Beyond the GSM
coverage.
Consult the network
service provider for
service areas.
The signal is feeble. Retry at a stronger
signal area.
Failed to
make a call
The call barring
feature is used.
Cancel the call
barring settings.
The fixed dialing
number feature is
used.
Cancel the fixed
dialing number
settings.
PIN code
error
Enter incorrect PIN
codes for three times
in succession.
Contact your network
service provider.
31
Failed to
charge the
battery
The battery or the
charger is damaged.
Change a new battery
or charger.
Charge the battery
when ambient
temperature is lower
than -10
℃
or above
55
℃
.
Change the
environment.
Poor connection. Check whether the
plug is properly
connected.
Failed to add
contacts to
phonebook
The storage space of
phonebook is used
up.
Delete some contacts
from the phonebook.
Failed to set
up some
features
Your network service
provider does not
provide the services,
or you haven’t
subscribed them.
Contact your network
service provider.
32
FCC Statement
1. This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference
that may cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which
33
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
SAR Information Statement
Your wireless phone is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radiofrequency
(RF) energy set by the Federal Communications Commission of the U.S.
Government. These limits are part of comprehensive guidelines and establish
permitted levels of RF energy for the general population. The guidelines are
based on standards that were developed by independent scientific
organizations through periodic and thorough evaluation of scientific studies.
The standards include a substantial safety margin designed to assure the safety
of all persons, regardless of age and health. The exposure standard for
wireless mobile phones employs a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. * Tests
for SAR are conducted with the phone transmitting at its highest certified
power level in all tested frequency bands. Although the SAR is determined at
the highest certified power level, the actual SAR level of the phone while
operating can be well below the maximum value. This is because the phone is
designed to operate at multiple power levels so as to use only the power
required to reach the network. In general, the closer you are to a wireless base
station antenna, the lower the power output.
Before a phone model is available for sale to the public, it must be tested and
certified to the FCC that it does not exceed the limit established by the
government adopted requirement for safe exposure. The tests are performed in
positions and locations (e.g., at the ear and worn on the body) as required by
the FCC for each model. The highest SAR value for this model phone
34
when tested for use at the ear is 0.378W/Kg and when worn on the body, as
described in this user guide, is 0.752W/Kg(Body‐worn measurements differ
among phone models, depending upon available accessories and FCC
requirements). The maximum scaled SAR in hotspot mode is 0.752W/Kg.
While there may be differences between the SAR levels of various phones and
at various positions, they all meet the government requirement for safe
exposure. The FCC has granted an Equipment Authorization for this model
phone with all reported SAR levels evaluated as in compliance with the FCC
RF exposure guidelines. SAR information on this model phone is on file with
the FCC and can be found under the Display Grant section of
http://www.fcc.gov/ oet/fcc id after searching on
Body‐worn Operation
This device was tested for typical body‐worn operations. To comply with RF
exposure requirements, a minimum separation distance of 10mm must be
maintained between the user’s body and the handset, including the antenna.
Third‐party belt‐clips, holsters, and similar accessories used by this device
should not contain any metallic components. Body‐worn
accessories that do not meet these requirements may not comply with RF
exposure requirements and should be avoided. Use only the supplied or an
approved antenna.
FCC Hearing-Aid Compatibility (HAC)
Regulations for Wireless Devices
On July 10, 2003, the U.S. Federal Communications Commission (FCC) Report and Order in WT Docket 01-
309 modified the exception of wireless phones under the Hearing Aid Compatibility Act of 1988 (HAC Act) to
require digital wireless phones be compatible with hearing-aids. The intent of the HAC Act is to ensure
reasonable access to telecommunications services for persons with hearing disabilities. While some wireless
phones are used near some hearing devices (hearing aids and cochlear implants), users may detect a buzzing,
humming, or whining noise. Some hearing devices are more immune than others to this interference noise,
and phones also vary in the amount of interference they generate. The wireless telephone industry has
developed a rating system for wireless phones, to assist hearing device users find phones that may be
compatible with their hearing devices. Not all phones have been rated. Phones that are rated have the rating
on their box or a label located on the box. The ratings are not guarantees. Results will vary depending on
the user’s hearing device and hearing loss. If your hearing device happens to be vulnerable to interference,
you may not be able to use a rated phone successfully. Trying out the phone with your hearing device is the
best way to evaluate it for your personal needs.
Hearing devices may also be rated. Your hearing device manufacturer or hearing health professional may
help you find this rating. Higher ratings mean that the hearing device is relatively immune to interference
noise. The hearing aid and wireless phone rating values are then added together. A sum of 5 is considered
acceptable for normal use. A sum of 6 is considered for best use.
In the above example, if a hearing aid meets the M2 level rating and the wireless phone meets the M3 level
rating, the sum of the two values equal M5. This should provide the hearing aid user with “normal usage”
while using their hearing aid with the particular wireless phone. “Normal usage” in this context is defined as
a signal quality that is acceptable for normal operation. The M mark is intended to be synonymous with the
U mark. The M and T marks are recommended by the Alliance for Telecommunications Industries Solutions
(ATIS). The U marks is referenced in Section 20.19 of the FCC Rules. The HAC rating and measurement
procedure are described in the American National Standards Institute (ANSI) C63.19 standard.
For information about hearing aids and digital wireless phones
FCC Hearing Aid Compatibility and Volume Control:
http://www.fcc.gov/cgb/dro/hearing.html
Gallaudet University, RERC:
https://fjallfoss.fcc.gov/oetcf/eas/reports/GenericSearch.cfm
The Hearing Aid Compatibility rating is displayed on the wireless phone box.
A phone is considered Hearing Aid Compatible for acoustic coupling (microphone mode) if it has
an “M3” or “M4” rating. A digital wireless phone is considered Hearing Aid Compatible for
inductive coupling (telecoil mode) if it has a “T3” or “T4” rating.
The tested M-Rating and T-Rating for this device (FCC ID:2AD6VA610) are M4 and T3.
