Amtran Technology Co SV422XVT-WL 802.11a/b/g/n Wireless LAN Module User Manual WU260 AM PS 20090805
Amtran Technology Co Ltd 802.11a/b/g/n Wireless LAN Module WU260 AM PS 20090805
User Manual
CyberTAN
Product Specification
WU260-AM
2.4/5GHz Draft 802.11n 2x2 MIMO WLAN USB Module
Preliminary
Release 0.4
Date:
August 5, 2009
Author:
Selina Liaw
Table of Contents
1. REVISION HISTORY ........................................................................................................................................................ 3
2. RELATED DOCUMENTS ................................................................................................................................................. 3
3. INTRODUCTION ............................................................................................................................................................... 4
4. FEATURES .......................................................................................................................................................................... 4
5. SPECIFICATION............................................................................................................................................................. 5
6. DRIVERS RELEASE PLAN.............................................................................................................................................. 6
7. COMPLIANT APPROVALS.................................................................................................................................................. 6
7.1 COMPLIANT APPROVALS ....................................................................................................................................................... 6
7.2 COMPLIANT PTT APPROVALS................................................................................................................................................ 6
8. PACKAGING SPECIFICATIONS ..................................................................................................................................... 7
9. WARRANTY......................................................................................................................................................................... 7
1. Revision History
Date Release Author Description
Nov 27th, 2008 0.1 Bryan Chou First Release
Jan 21th, 2009 0.2 Bryan Chou Pg3, Modulation revised
Pg4, Compliant Approvals revised
Mar 27, 2009 0.3 JC Liou Performance validation
Aug 5 , 2009 0.4 Selina liaw Adding package label
2. Related Documents
Date Author Document
IEEE.org Draft IEEE 802.11n specification
3. Introduction
The WU260 is a Draft IEEE802.11n-compatible USB module in a 2x2 MIMO configuration and operating in the 2.4 and
5GHz ISM band. This module allows an embedded host to use its USB 1.1 or 2.0 interface to connect to a Draft
IEEE802.11n compatible access point at unprecedented speeds.
The WU260 USB module is based on Broadcom’s BCM4323 65nm chipset. It provides greater than 100Mbps real world
throughput using high-speed spatial multiplexing modes. Configuration and testing of this module must be done on the host via
Broadcom provided software tools..
4. Features
• USB v2.0 compatible.
• Board-to-Board connector to the host PCB’s needs.
• Backward compatible with USB v1.1.
• Draft IEEE 802.11n version 2.0 compatible.
• Backward compatible with IEEE 802.11b/g standards.
• Wire-free access to networked resources from anywhere beyond the TV.
• Delivers data rate up to 300 Mbps.
• 802.11n: Dynamically shifts among 130, 117, 104, 78, 52, 39, 26 and 13Mbps in a 20MHz bandwidth and 270, 243,
216, 162, 108, 81, 54 and 27Mbps in a 40MHz bandwidth, based on signal strength, for maximum availability and
reliability of connection.
• 802.11a/g: Dynamically shifts among 54, 48, 36, 24, 18, 12, 9 and 6 Mbps network speed, based on signal strength,
for maximum availability and reliability of connection.
• 802.11b: Dynamically shifts among 11M, 5.5M, 2M, and 1 Mbps network speed, based on signal strength, for
maximum availability and reliability of connection.
• Uses 2.4 and 5GHz frequency band, which complies with worldwide non-license bands.
• Ensures great security by providing the 64/128 bits Wired Equivalent Privacy (WEP) and WiFi Protected Access
• Protected Access (WPA) defined in the IEEE standard.
5. Specification
Specifications
Product Name 802.11a/b/g/n Wireless LAN Module
Interface USB ver 2.0 compatible
ROHS 4P header
Network Standards Draft IEEE802.11n and 11a/b/g -compliant
Data Rate
11b/g:
54, 48, 36, 24, 18, 12, 9, 6, 11, 5.5, 2,1 Mbps
11n:
20MHz BW: 130, 117, 104, 78, 52, 39, 26, and 13Mbps
40MHz BW: 270, 243, 216, 162, 108, 81, 54, and 27Mbps
Modulation 802.11a/g/n---- OFDM
802.11b---- CCK (11Mbps, 5.5Mbps), QPSK (2Mbps), BPSK (1Mbps)
Technique Direct Sequence Spread Spectrum(802.11b)
Network Architecture Infrastructure and ad hoc
Operating Frequency 2.4G 11b/g/n:
2.412
~
2.462
GHz:
North
America
5G 11a/n:
5.15
~
5.35GHz/
5.47
~
5.825
GHz:
North
America
UNII
Operating Channels
11b:
1~11
for
America
2.4GHz
11g/n:
1~11
for
America
5GHz
11a/n:
36-64,
100-161
North
America
RF Output Power
16dBm +/- 1.5dBm
(2.4GHz,
11Mbps,
CCK)
13.5Bm +/- 1.5dBm
(2.4GHz,
54Mbps,
OFDM)
13.5dBm
+/- 1.5dBm (5GHz,
54Mbps,
OFDM)
13.5dBm +/- 1.5dBm
(2.4GHz,
11n)
13.5dBm
+/- 1.5dBm (5GHz,
11n,
20MHz
BW)
12.5dBm
+/- 1.5dBm (5GHz,
11n,
40MHz
BW)
Antenna Hirose U.FL connector * 2
LED Indicators N/A
Coverage Area
Indoor:
20M@54Mbps,
35M@24Mbps,
60M@6Mbps,
100M@11Mbps
Receive Sensitivity
-84
dBm
@
11M
(CCK,
10%
PER)
-70
dBm
@
54M
(2RX
11g
OFDM,
10%
PER)
-70
dBm
@
54M
(2RX
11a
OFDM,
10%
PER)
-64
dBm
@
130Mbps
(2.4GHz,
2RX
11n
OFDM
with
20MHz
BW,
10%
PER)
-62
dBm
@
130Mbps (5GHz,
2RX
11n
OFDM
with
20MHz
BW,
10%
PER)
-62
dBm
@
270Mbps (2.4GHz,
2RX
11n
OFDM
with
40MHz
BW,
10%
PER)
-60
dBm
@
270Mbps (5GHz,
2RX
11n
OFDM
with
40MHz
BW,
10%
PER)
Power Consumption TX Power consumption: < 700 mA
RX Power consumption: < 460 mA
Operating Temperature 0 to 60 ℃
Humidity 20% to 95% Non-condensing
Dimensions (mm) (W) 37mm × (L) 50mm × (H) 1.1mm
Weight (g) 6.8 g
Voltage 5.0V
6. Drivers Release Plan
Driver Release time Utility Tools Release time
Windows 2000
Windows XP
Linux
VxWorks
7. Compliant Approvals
7.1 Compliant Approvals
FCC Part 15 Class B, C & E
7.2 Compliant PTT approvals
Supported by customer request: USA
8. Packaging Specifications
The following items will be required for the complete packaging of the WU260-AM USB module:
Item Comments
WU260 USB module YES
Protective bag Bubble bag
Carton Bulk packing
QIG N/A
CD-ROM N/A
9. Warranty
One year limited warranty.
9.1 Warning statement
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the radiator &
your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Operations in the 5.15-5.25GHz band are restricted to indoor usage only
IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to channels 1
through 11.
This device is intended only for OEM integrators under the following conditions:
The antenna must be installed such that 20 cm is maintained between the antenna and users, and
The transmitter module may not be co-located with any other transmitter or antenna,
For all products market in US, OEM has to limit the operation channels in CH1 to CH11 for 2.4G band by
supplied firmware programming tool. OEM shall not supply any tool or info to the end-user regarding to
Regulatory Domain change.
As long as 3 conditions above are met, further transmitter test will not be required. However, the OEM
integrator is still responsible for testing their end-product for any additional compliance requirements
required with this module installed (for example, digital device emissions, PC peripheral requirements,
etc.).
IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop
configurations or co-location with another transmitter), then the FCC authorization is no longer
considered valid and the FCC ID can not be used on the final product. In these circumstances, the OEM
integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a
separate FCC authorization.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be installed such that
20 cm may be maintained between the antenna and users. The final end product must be labeled in a
visible area with the following: “Contains FCC ID: MDZSV422XVT-WL”.
Manual Information To the End User
The OEM integrator has to be aware not to provide information to the end user regarding how to install or
remove this RF module in the user’s manual of the end product which integrates this module.
The end user manual shall include all required regulatory information/warning as show in this manual.
