PRODUCT SPECIFICATION
BT V4.0 LE Dual Mode Bluetooth Stereo Audio Module
WB118C
User Manual
Change History
Revision
Date
Author
Change List
Version 1.0
2014/05/30
Ben J. Chen
Preliminary
* This document contains confidential proprietary information and is property of LTC. The contents of
this document should not be disclosed to unauthorized persons without the written consent of LTC.
Page 2/7
PRODUCT FEATURES
Bluetooth V4.0 specification compliant Backwards compatible with BT version
of 1.1, 1.2, 2.0, 2.1+EDR
Dual-mode Bluetooth low energy radio
80MHz RISC MCU and 80MIPS Kalimba DSP
BT using SPI interface
Multipoint HFP connection to 2 phones for voice
Multipoint A2DP connection enables a headset(A2DP) connection to 2 A2DP
source devices for music playback
Secure simple paring, CSR’s proximity pairing and CSR’s proximity connection
SBC, MP3 and AAC decoder support
Fast AGC for enhanced dynamic range
RoHS compliance
Low Halogen compliance
Page 3/7
PRODUCT SPECIFICATIONS
MAIN CHIPSET
CSR 8645
FUNCTIONAL SPECIFICATIONS
BT Function
Standard
Bluetooth V4.0 LE
Bus Interface
SPI
Data Rate
1 Mbps, 2Mbps and Up to 3Mbps
Modulation Scheme
GFSK, π/4-DQPSK and 8-DPSK
Frequency Range
2.402~2.480 GHz
Transmit Output Power
0 ≤ Output Power ≤ +4 ; Class 2 Device
Receiver Sensitivity
< 0.1% BER at -82dBm
Operating Voltage
3.3 V ±9% I/O supply voltage
Power Consumption
Stereo high quality SBC:
15 mA
Idle Mode:
280 uA
Antenna Type
Metal Antenna
Antenna General Information
Ant.Cat.
Ant. Type
Connector
Gain (dBi)
External
PIFA
U.FL
2.85
Page 4/7
FCC Statement:
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and receiver.
● Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
● Consult the dealer or an experienced radio/TV technician for help.
LABEL OF THE END PRODUCT:
The final end product must be labeled in a visible area with the following " Contains
TX FCC ID: MDZ-WB118C ".
Co-located
This device and its antenna(s) must not be co-located or operating in conjunction with
any other antenna or transmitter.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesired operation
The OEM integrator is still responsible for the FCC compliance requirement of the end
product, which integrates this module.
Appropriate measurements (e.g. 15 B compliance) and if applicable additional equipment
authorizations (e.g. Verification , Doc) of the host device to be addressed by the
integrator/manufacturer.
Page 5/7
IC Statement:
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux
conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2)
l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le fonctionnement.
IC Radiation Exposure Statement:
This equipment complies with IC RSS-102 radiation exposure limits set forth
for an uncontrolled environment
CAN ICES-3 (B)/NMB-3(B)
The final end product must be labeled in a visible area with the following:
“Contains transmitter module IC: 7825A-WB118C”.
Contient le module d'émission IC: 7825A-WB118C
Page 6/7
Baseband and Software
■ Internal ROM
■ Memory protection unit supporting accelerated VM
■ 56KB internal RAM, enables full-speed data
transfer, mixed voice/data and full piconet support
■ Logic for forward error correction, header error
control, access code correlation, CRC,
demodulation, encryption bit stream generation,
whitening and transmit pulse shaping
■ Transcoders for A-law, μ-law and linear voice from
host and A-law, μ-law and CVSD voice over air
CSR8600 ROM Series Configuration Tool
Configures the CSR8640 stereo ROM solution software
features:
■ Bluetooth v4.0 specification features
■ Reconnection policies, e.g. reconnect on power-on
■ Audio features, including default volumes
■ Button events: configuring button presses and
durations for certain events, e.g. double press on
PIO for last number redial
■ LED indications for states, e.g. headset connected,
and events, power on etc.
■ Indication tones for events and ringtones
■ HFP v1.6 supported features
■ Battery divider ratios and thresholds, e.g.
thresholds for battery low indication, full battery etc.
■ Advanced Multipoint settings
CSR8640 Stereo ROM Solution Development Kit
■ CSR8640 stereo ROM solution demonstrator board
(DB-8640-10085-1A)
■ Interface adapters and cables are available
■ Works in conjunction with the CSR8600 ROM
Series Configuration Tool and other supporting
Utilities
Page 7/7
Proximity Pairing
Proximity pairing is headset-initiated pairing and it simplifies the out-of-box pairing process. Proximity pairing
enables
the headset to find the closest discoverable phone. The headset then initiates the pairing activity and the user
simply
has to accept the incoming pairing invitation on the phone.
This means that the phone-user does not have to hunt through phone menus to pair with the new headset.
Depending on the phone UI:
■ For a Bluetooth v2.0 phone the headset pairing is with a PIN code
■ For a Bluetooth v2.1 (or above) phone the headset pairing is without a PIN code
Proximity pairing is based on finding and pairing with the closest phone. To do this, the headset finds the loudest
phone by carrying out RSSI power threshold measurements. The loudest phone is the one with the largest RSSI
power threshold measurement, and it is defined as the closest device. The headset then attempts to pair with
and
connect to this device.
Proximity pairing is configurable using the Headset Configurator tool available from www.csrsupport.com.
