User Manual
OWNER’S MANUAL
DIGITAL VIDEO, MOVEMENT
& SOUND BABY MONITOR
Model AC1100
FOR YOUR PEACE OF MIND
Please DO NOT return this product to the store. For assistance please
contact our helpline on 0345 009 1789 or email helpline@babyhelpline.co.uk
Mon – Fri 10am – 4pm, excluding bank holidays.
Movement Alarm
Your monitor comes with the movement alarm activated.
When switching on your monitor it will alarm, with or without
the Sensor Pad plugged in, if no movement is detected.
Deactivate the movement function to use the monitor without
the Sensor Pad.
Batteries
Insert the enclosed rechargeable batteries into the Parent
Unit. If inserted incorrectly the Parent Unit will not charge
when placed in the charging cradle. The battery icon will flash
briefly on the Parent Unit screen to indicate charging.
Cord Safety
Ensure the Nursery Unit is at least 1 metre away from your
baby’s cot. The Sensor Pad cord must always be kept out of
reach of baby and secured using the cord cover kit provided.
DON’T
FORGET
IMPORTANT ADVICE FOR INITIAL SETUP
PLEASE FOLLOW THE INSTRUCTIONS CAREFULLY FOR CORRECT SETUP
TABLE OF CONTENTS
WARNINGS .................................................................................. 3
AC1100 SETUP REQUIREMENTS .................................................. 8
STEP 1 - Charging the Parent Unit ............................................... 9
STEP 2 - Installing the Sensor Pad ............................................ 10
STEP 3 - Setting up the Nursery Unit ........................................13
STEP 4 - Turning on your Monitor ..............................................14
STEP 5 - Testing and getting to know your Monitor ............15
STEP 6 - Activating and deactivating
additional functions .......................................................19
Troubleshooting ...............................................................................25
Limited warranty ..............................................................................27
Technical specifications ................................................................. 28
UK1014
OWNER’S MANUAL
KEEP YOUR OWNER’S MANUAL FOR FUTURE REFERENCE.
PLEASE READ THE WARNINGS AND INSTRUCTIONS CAREFULLY BEFORE
ASSEMBLING & USING THE PRODUCT.
FAILURE TO FOLLOW THE WARNINGS AND THE INSTRUCTIONS COULD RESULT
IN SERIOUS INJURY OR DEATH OR DAMAGES TO THE PRODUCT.
THE SENSOR PAD FEATURE IS NOT FOR USE WITH ADULTS, CHILDREN OR INFANTS
OLDER THAN 24 MONTHS.
THE SENSOR PAD IS NOT INTENDED TO BE USED TO DETERMINE IF A CHILD IS OUT
OF THE CRIB.
WARNING
Adult assembly required.
Keep small parts away from children when assembling.
This Angelcare Monitor is a Personal Care Product. Please DO NOT return this to the store
where you purchased it from. If you have any questions or require assistance please call the
Angelcare Helpline on 0345 009 1789 or email helpline@babyhelpline.co.uk.
The Baby Helpline is open Monday to Friday, 10am to 4pm. The helpline is closed on bank
holidays.
For additional FAQs and to download instruction manuals visit; www.angelcare.co.uk.
To order spare parts for your Angelcare Baby Monitor visit; www.megababy.co.uk.
2
1. THIS PRODUCT CANNOT REPLACE
RESPONSIBLE ADULT SUPERVISION. This
product is designed to aid in the monitoring
of your child. When using the monitor, you
must still provide the supervision necessary
for the continued safety of your child.
Monitoring of premature babies, or those
considered to be at risk, should always
be carried out under the supervision of a
health professional. This monitor SHOULD
NOT be used as a medical device, nor as
a device to prevent Sudden Infant Death
Syndrome (SIDS).
2. WARNING Strangulation Hazard —
Children have STRANGLED in cords. Keep
adapter cords out of
the reach of children
(more than 1 m away).
NEVER use Sensor
Pad(s) without the
protective cord
covering. Check
protective cord
covering before each
use. Immediately discontinue use of Sensor
Pad(s) if protective covering is damaged
or broken.
3. Never use extension cords with AC
adapters. ONLY use the AC adapters
provided.
4. When an AC Adapter is plugged into
an electrical outlet, DO NOT touch the
exposed end.
5. ALWAYS be sure that both the transmitter
and receiver are working properly and are
within range of each other. Test monitor
before first use, periodically and when
changing location of the Nursery Unit.
6. ALWAYS be sure to immediately check
on baby whenever an alarm sounds.
7. DO NOT use monitor near water (such
as bath tub, sink, etc.).
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DO NOT EXPOSE TO RAIN OR MOISTURE
8. Keep monitor AWAY from heat sources
(such as stoves, radiators, etc.).
9. ALWAYS place both the Nursery Unit and
Parent Unit on a flat surface in an upright
position and allow for proper ventilation.
DO NOT place on sofas, cushions, beds,
etc. which may block ventilation.
10. This monitor uses public airwaves to
transmit signals. The Parent Unit may
pick up signals or interference from
other nursery monitors in your area. Your
monitor may even be picked up by other
households. To protect your privacy, make
sure both units are turned OFF when not in
use. If you experience interference, change
the channel on both units.
11. This product is NOT a toy. DO NOT allow
children to play with it.
12. This product contains small parts. Adult
assembly required. Exercise care when
unpacking and assembling the product
and keep small parts away from children.
13. When using the monitor, the room
temperature should be between 50°F
(10°C) and 104°F (40°C).
BATTERY WARNING
14. Use ONLY AAA RECHARGEABLE
batteries for the Parent Unit. DO NOT
mix old and new batteries. DO NOT
mix alkaline, standard or rechargeable
batteries. Insert batteries with correct
polarity. DO NOT short-circuit supply
terminals. ONLY use the recommended
batteries or equivalent (volts and size)
and the correct adapter. Remove batteries
when product is stored for long periods
of time or when batteries are exhausted.
Dispose exhausted batteries properly. DO
NOT recharge non-rechargeable batteries.
Rechargeable batteries are ONLY to be
charged under adult supervision. Keep all
WARNINGS
3
batteries away from children.
15. IMPORTANT SAFETY INSTRUCTIONS
15.1 Read these instructions - All the safety
instructions should be read before the
product is operated.
15.2 Keep these instructions. The safety
and operating instructions should be
retained for future reference.
15.3 Heed all warnings – All warnings on the
product and in the operating instructions
should be adhered to.
15.4 Follow all instructions – All operating
and use instructions should be followed.
15.5 Water and moisture - DO NOT use
this apparatus near water. For example,
near a bath tub, wash bowl, kitchen sink,
laundry tub, in a wet environment or near
a swimming pool and the like. Care should
be taken so that objects DO NOT fall onto
units and that liquids are not spilled into
either unit or Sensor Pad through its
openings.
15.6 Cleaning - Disconnect all units before
cleaning. DO NOT immerse in water any
part of the Nursery Unit, Parent Unit. Clean
only with dry cloth.
15.7 Ventilation - DO NOT block any
ventilation openings. Allow for proper
ventilation when units are in use. DO NOT
cover the Nursery Unit or Parent Unit with
any object such as a blanket. DO NOT place
it in a drawer or in any location which
would muffle the sound or interfere with
the normal flow of air.
15.8 Heat sources - DO NOT install near
any heat sources such as radiators, heat
registers, stoves, TVs or other apparatus
(including amplifiers) that produce heat.
Heat can damage the case or electrical
parts.
15.9 Power cord protection - Protect the
Sensor Pad cord and Adapter’s power
cord from being walked on or pinched by
furniture or other items – Power supply
cords should be routed so that they are not
likely to be walked on or pinched by items
upon or against them, paying particular
attention to cords and plugs, convenience
receptacle, and the point where they exit
from the product.
15.10 Accessories - Only use attachments/
accessories specified by the manufacturer.
DO NOT place this product on an unstable
cart, stand, tripod, bracket or table. The
product may fall, causing serious injury
to a child or adult and serious damage to
the product. Use ONLY with a cart, stand,
tripod, bracket or table recommended by
the manufacturer or sold with the product.
Any mounting of the product should follow
the manufacturer’s instructions.
15.11 Unplug this appliance during lightning
storms or when not used for long periods
of time.
15.12 Servicing - DO NOT attempt to
service this product yourself as opening
or removing covers (except battery doors)
may expose you to dangerous voltage or
other hazards.
15.13 Replacement parts - When
replacement parts are required, be sure
the replacement parts specified by the
manufacturer have the same characteristic
as the original part. Unauthorized
substitution may result in fire, electric
shock or other hazards.
15.14 Usage - This baby monitor is
intended as an aid. It is NOT a substitute for
responsible and proper adult supervision
and should not be used as such. Use this
appliance ONLY for its intended use as
described in this manual.
15.15 Power Sources - Operate this
product only from the type of power
source indicated on the type plate of the
adaptor. If you are unsure of the type of
power supply to your home, consult your
dealer or local power company.
15.16 Overloading - DO NOT overload
wall outlets, extension cords or integral
convenience receptacles as this can result
in a risk of fire or electric shock.
15.17 Object and Liquid Entry - NEVER
push objects of any kind into this product
through casing slots as they may touch
dangerous voltage points or short out
parts that could result in a risk of fire or
electric shock. NEVER spill liquid of any
kind on the product.
15.18 Antenna - The antenna used for this
transmitter must be installed to provide
4
a separation distance of at least 20 cm
(7.9”) from all persons and must not be
collocated or operating in conjunction with
any other antenna or transmitter.
15.19 Power Lines - An outside antenna
system should NOT be located in the
vicinity of overhead power lines or other
electric light or power circuit, or where it
can fall into such power lines or circuits as
contact with them may be fatal.
15.20 WARNING Strangulation Hazard —
Children have STRANGLED in cords. Keep
adapter cords out of
the reach of children
(more than 1 m away).
NEVER use Sensor
Pad(s) without the
protective cord
covering. Check
protective cord
covering before each
use. Immediately discontinue use of Sensor
Pad(s) if protective covering is damaged
or broken.
15.21 Interference - This monitor uses public
airwaves to transmit signals. The Parent
Unit may pick up signals or interference
from other nursery monitors in your area.
Your monitor may even be picked up by
other households. To protect your privacy,
make sure both units are turned OFF when
not in use. If you experience interference,
change the channel on both units.
15.22 Vibration Source - When the monitor
is in use, DO NOT use a crib mobile or
other crib accessories that may produce
vibrations. Other sources of vibrations
may include fans, washing machines, loud
music, etc. These sources of vibration may
interfere with the performance of your
Angelcare® monitor and the alarm will
not sound if it continues to detect any
movement other than your baby’s. Be sure
all vibration sources are eliminated before
using the monitor.
You may experience false alarms for several
reasons. The most common reason is the
Nursery Unit has not been turned OFF after
you have removed your baby from the crib.
Another reason is the Sensor Pad has not
been placed under the mattress properly.
Be sure the Sensor Pad is on a flat, firm
surface with the printed side facing up.
The sensitivity level may also need to be
adjusted. Refer to step 5.1.
15.23 Sensor Pad - Your Sensor Pad can
be used in any crib that is stationary. If
the crib has a spring or slat base, place a
hard board between the crib base and the
Sensor Pad measuring at least 13” x 13”
(33 x 33 cm) and 1/4 inch (6 mm) thick.
Only use your Angelcare® monitor in a
stationary sleeping environment such as
a crib where the Sensor Pad can rest on
a completely flat, firm surface.
15.24 The Sensor Pad is made of plastic
and does not permit the air to circulate.
Therefore, mildew build up could develop
underneath the mattress in the sensor pad
area. We suggest rotating the mattress
regularly to prevent any mildew.
5
16. IMPORTANT SAFETY INSTRUCTIONS
RELATED TO USE OF BATTERIES
16.1 Use ONLY the type and size of
batteries specified in the owner’s manual.
There is a risk of explosion if batteries are
replaced with an incorrect type.
16.2 Use ONLY AAA rechargeable
batteries and/or the AC Adapters provided
for the Parent Unit. You must use only
rechargeable batteries in the Parent Unit.
DO NOT use alkaline batteries or you will
severely damage the unit.
16.3 Charge the batteries for 15 hours prior
to first use. Be sure to have the monitor in
the OFF position during this period. ONLY
use the AC Adapters included with your
monitor.
16.4 DO NOT use these adapters with any
other equipments.
16.5 When unplugging the AC Adapter
from the Nursery Unit, be sure it is
switched to the OFF position. If it isn’t, the
unit will revert to battery mode if batteries
are installed.
16.6 DO NOT use rechargeable batteries
in the Nursery Unit. Use alkaline batteries
ON LY.
16.7 DO NOT dispose batteries in fire. They
may explode. Check with local regulations
for possible special disposal instructions.
16.8 Exercise care in handling batteries
in order not to short out the batteries
with conducting materials such as rings,
bracelets and keys. Overcharging, short
circuiting, reverse charging, mutilation, or
incineration of batteries must be avoided
to prevent one or more of the following
occurrences: release of toxic materials,
release of hydrogen and/or oxygen gas,
rise in surface temperature.
16.9 DO NOT attempt to recharge batteries
provided with or identified for use with
this product that are not intended to be
charged. The batteries may leak corrosive
electrolyte or explode.
16.10 DO NOT attempt to rejuvenate the
batteries provided with or identified for
use with this product by heating them.
Sudden release of battery electrolyte may
occur, causing burns or irritation to eyes
or skin.
16.11 If and when necessary, the batteries
must be replaced with identical new ones
or equivalent (volts and size). If a battery
to be replaced is connected with other
batteries in series, replace the other
batteries at the same time as well. DO
NOT mix old and new batteries.
16.12 Reverse polarity installation of the
batteries in the end product must be
avoided. Reverse insertion of batteries
can cause charging, and that may result
in leakage or explosion.
16.13 Remove batteries from this product
if you store the product over 30 days
because the batteries could leak and
damage the product.
16.14 Discard ‘dead’ batteries as soon as
possible since ‘dead’ batteries are more
likely to leak in a product. If a battery has
leaked or vented, it should be replaced
immediately using protective gloves.
16.15 DO NOT store this product, or the
batteries provided with or identified for
use with this product, in high-temperature
areas.
6
WARNING
(North America Only)
17.1 Modifications not authorized by the
manufacturer may void users authority to
operate this device.
17.2 NOTE: This equipment has been tested
and found to comply with part 15 of the
FCC Rules and the Industry Canada licence-
exempt RSS standard(s). These limits are
designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses
and can radiate radio frequency energy
and, if not installed and used in accordance
with the instructions, may cause harmful
interference to radio communications.
17.3 However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment OFF and ON, the
user is encouraged to try to correct the
interference by one or more of the following
measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between
the equipment and receiver.
• Connect the equipment into an
outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
17.4 This device complies with the part 15
of the FCC Rules and the Industry Canada
licence - exempt RSS standards(s). Operation
is subject to the following two conditions:
(1) This device may not cause harmful
interference, and
(2) This device must accept any interference
received, including interference that may
cause undesired operation.
FCC AND IC REGULATIONS
RF radiation exposure statement
The Nursery Unit complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. Caution: To maintain the compliance with the FCC’s RF exposure guideline,
install the Nursery Unit at least 20 cm from ALL persons. The transmitter of this device must
not be co-located or operating in conjunction with any other antenna or transmitter.
Industry Canada
This product meets the applicable Industry Canada technical specifications.
CAN ICES-3 (B)/NMB-3 (B)
This device was tested for typical body-worn operations using the supplied belt clip. To
maintain compliance with RF exposure requirements, body-worn operations are restricted
to the supplied belt clip. 7
E
N
01mf22_User_guideAC1100_NA_12004.indd 7 2015-08-07 4:25 PM
YOU MUST PREPARE:
One hardboard (not included)
Thickness: 6 mm
Minimum dimensions:
33 cm x 33 cm
Maximum dimensions:
equal to the mattress size
WHAT YOU WILL NEED (NOT INCLUDED):
Miniature Philips
Screwdriver
3 AAA Alkaline
Batteries
VIDEO, MOVEMENT
& SOUND MONITOR
Model AC1100
IMPORTANT
The hardboard must be larger than
the Sensor Pad surface area.
BABY’S ROOM:
SETUP REQUIREMENTS
3X
INCLUDED:
Rechargeable
Parent Unit
Nursery Unit Charging Cradle Belt Clip
65432 1
1 Sensor Pad (AC1100) or 2 Sensor Pads (AC1100-2SP)
with pre-installed cord covers
3 Rechargeable
AAA Batteries
3X
2 AC Adapters
2X
Hardboard
6
5432 1
Keep
at least
1 m.
IMPORTANT
Sensor Pad
IMPORTANT
Place the crib near a supporting wall and far from air currents. Install the Nursery
Unit on a flat, stable surface facing the crib at a distance of at least 1 meter.
Make sure to plug the adapter to the socket outlet nearest to the equipment
and that it is easily accessible.
8
STEP 1 - CHARGING THE PARENT UNIT
1 2
3 4
1) Remove the Belt Clip.
2) Remove the battery door and insert
the Rechargeable Batteries (included).
3) Connect the AC Adapter to the
Charging Cradle and
into an electrical outlet.
4) Charge the unit for 10 continuous
hours (prior to first use).
15
IMPORTANT
Never use regular
alkaline batteries
in the Parent Unit;
they may explode.
PARENT UNIT:
Front Side Left Side
F
B
C
A
D
E
G
J
I
H
A) LCD Touchscreen
B) POWER ON/OFF
C) Microphone
D) Speaker
E) Charging Cradle
F) Belt Clip
G) Speaker
Volume Buttons
H) Talk Back Button
I) Battery Door
J) AC Adapter Outlet
(not shown)
NOTE:
To optimize your battery performance
please refer to Battery Guidelines in the
Trouble Shooting section.
10h
9
STEP 2 - INSTALLING THE SENSOR PAD
WARNING
STRANGULATION HAZARD.
Children have STRANGLED in cords:
•Keep adapter cords out of the reach of children
(more than 1 m away).
•Because of the serious strangulation risk to infants
and toddlers, parents and caregivers should never
place the Nursery Unit within 1 meter of a crib.
•NEVER use Sensor Pad without the cord covers.
Check cord covers before each use to ensure it is
securely placed under the leg of the crib. Discontinue
use of Sensor Pad if any cord covers are damaged or
broken.
•NEVER use extension cords with AC adapters. ONLY
use the AC adapters provided. This product is not a
toy. Never allow children to play with it.
6
5432 1
Keep
at least
1 m.
IMPORTANT
65432 1
Cord covers 1, 2, 3, 4:
Position on floor
Cord cover 4:
Contains double sided
tape to securely install
beneath crib leg
Cord cover 5:
Position vertically
between mattress
support and floor
Cord cover 6:
Place under
the mattress
Sensor Pad with pre-installed cord covers
2.1 - SELECT A LOCATION FOR THE NURSERY UNIT
Select a location for the Nursery Unit that is
at least 1 meter away from the crib.
10
6
5
4
3
2
1
6
5
4
3
2
1
Fig 1
Fig 2
1) Use the crib leg by the wall closest to
the Nursery Unit (fig 1). In cases where
the Nursery Unit is across the room, use
the leg closest to the Nursery Unit to
position the covered wire (fig 2). It is
always preferable that the covered cord
run along a wall.
2.2 - SELECT THE CRIB LEG YOU WILL BE USING TO SECURE THE CORD COVERS
RECOMMENDED
1) Remove the mattress from the crib.
2) Place the Sensor Pad - printed side up
- on top of the hardboard at the center
of the crib.
3) Run the connection pin, warning label
and the first 5 cord covers down along
the backside of the crib leg, between
the mattress support and the inside
edge of the crib.
4) Bring the first 4 cord covers down
the floor, and keep the 5th cord cover
vertically, along the backside of the crib
leg, (between the mattress and the
inside edge of the crib).
5) Remove any cord slack to make sure
no parts of the cord are loose.
3
2.3 - INSTALL THE SENSOR PAD ON THE MATTRESS SUPPORT
654
3
1
2
OR
4
5
5
11
6
8 cm
6
7
4132
CLIC!
4
3
2
1
8
The Sensor Pad functions with any size
and type of mattress except memory-foam
mattresses and hollow frame mattresses.
The hardboard maintains a constant
pressure on the Sensor Pad, enabling it to
detect the baby’s movements even when
the baby is at the edges of the crib.
10
9
WARNING
STRANGULATION HAZARD
• Remove all slack from Sensor Pad Cord.
• When lowering the mattress support
as your child grows, slide the vertical
Cord Cover (5) upward so it remains
approximately in the center between
the mattress support and the floor. Slide
the Sensor Pad Cord through the Floor
Cover to eliminate any additional slack.
• The Sensor Pad is not designed for use
with adults, children or infants older
than 24 months.
• Discontinue used of the Sensor Pad
when child is older than 24 months.
Remove sensor pad from crib and store
for future use.
• BEFORE FIRST TIME USE: To test
that the unit is ready for use, refer to
instruction manual on how to test that
the installation has been done
6) Place the 6th cord cover approximately
8 cm from the edge of the mattress
support.
7) Snap together the remaining cord
covers that will run along the floor.
8) Remove any cord slack to make sure
no parts of the cord are loose.
9) Peel off the double-sided tape on the
4th cord cover and place it securely
under the crib leg.
10) Install the Nursery Unit on a flat, stable
surface facing the crib at a distance of
at least 1 m and plug the Sensor Pad
cord into the Nursery Unit.
11) Check to make sure the Sensor Pad has
not moved from position.
12) Place the mattress back inside the crib.
12
STEP 3 - SETTING UP THE NURSERY UNIT
1
1) Remove the battery door and insert
3 AAA Alkaline Batteries (not included).
2) Place the Nursery Unit at a minimum
of 1 m away from the crib.
3) Connect the AC Adapter to the Nursery
Unit and into an electrical outlet.
4) Direct the angle of the camera toward
the crib using the rotating dial.
NOTE:
The batteries maintain power
supply in case of power outage.
NURSERY UNIT:
Front Side Back Side
A
B
CD
E
F
G
H
I
K
L
M N
J
A) Night Light
B) Main Button
C) POWER ON/OFF
(Left ‘Wing’)
D) Night Light ON/OFF
(Right ‘Wing’)
E) Video Camera
F) 4 Infrared LEDs
(Night Vision Camera)
G) Power Indicator (green)
Low Battery Indicator (red)
H) Microphone
I) Speaker
J) Sensor Pad Outlet
K) AC Adapter Outlet
L) Roating Dial
for Camera Angle
M) Battery Door
(not shown)
N) Tripod Outlet*
(not shown)
* Nursery Unit may be installed on a tripod (not included).
3
4
6
5432 1
2
IMPORTANT
Keep at least
1 m
13
STEP 4 - TURNING ON YOUR MONITOR
OK
4
21) Press the Parent Unit ON/OFF button
for 2 seconds until blue screen appears.
2) The Parent Unit will display
Video mode screen.
3) Press the Menu icon to access
main menu.
4) The Parent Unit will display
Menu mode.
5) Push and hold the Nursery Unit left
‘wing’ button for 2 seconds.
Temperature icon:
Indicates room temperature
Temperature Alarm icon: Indicates
Temperature Alarm is active
Pendulum icon: Indicates the
Motion Sensor is active
Sound icon: Indicates that Sound
function is active
Alarm icon: Indicates selected
alarm mode
Sound alarm
Sound alarm
and vibration
Vibration only
INDICATION BAR IMPORTANT ICONS
Connection icon: Indicates the
connection quality between the
Parent Unit and Nursery Unit.
Good connection
Poor connection
Lost connection
Out-of-Range
Battery Level icon:
Indicates battery level
Empty
1/3 Full
2/3 Full
Full
3
1
5
When Parent Unit is turned ON and
Nursery Unit is OFF, Parent Unit will
display Disconnected Mode and will
turn itself OFF after 60 seconds.
If there is a lost connection
between the 2 units (refer to
troubleshooting):
• The Out-of-Range icon will
appear on the screen.
• The Lost Connection icon will
appear on the indicator bar.
14
5.1 - SENSOR PAD
1) Press Menu icon to access
main menu.
2) Press Movement icon to activate
or deactivate Movement Alarm.
3) Press OK icon to confirm.
1) Move your hand lightly on the mattress.
The pendulum icon will appear
on Parent Unit indicator bar.
It will move as you move your
hand and trigger a ‘TIC’ sound.
2) Remove your hand from the mattress.
After 15 seconds you will hear a
‘TIC’ pre-alarm sound, and 5 seconds
later the Movement Alarm will trigger.
IF THE ALARM DOES NOT SOUND
• Avoid contact with crib while Sensor Pad is in operation.
• Place crib near a supporting wall.
• Turn OFF crib mobile, fans, loud music or anything else that may cause vibration.
• Adjust Sensor Pad sensitivity level.
ON OFF
1 2
TO ACTIVATE THE SENSOR PAD:
TO TEST THE SENSOR PAD:
MOTION ALARM
• Alarm activates when no movement is detected by Sensor Pad for 20 seconds.
• Both the Parent Unit and Nursery Unit speakers will emit loud warning sound.
• Motion Alarm icon will show on the LCD screen.
1
OK
2
STEP 5 - TESTING AND GETTING TO KNOW YOUR MONITOR
IMPORTANT
When in menu or sub-menu modes,
sound transmission between Parent
and Nursery Units will be temporarily
deactivated. ONLY movement-
detection alarm will remain active (if
function is activated).
OK
All changes and
adjustments made
in the main menu and
sub-menus will not be
activated unless you
confirm them by pressing
the OK icon.
The Angelcare® monitor can be used with the pre-program factory settings or you can
also customise your settings to your preference.
15
1) Press Menu icon to access
main menu.
2) Press settings icon
to access sub-menu.
3) Press movement sensitivity icon to choose
the desired sensitivity level (1 to 5).
4) Press OK icon to confirm.
TO ADJUST THE SENSOR PAD SENSITIVITY LEVEL:
TO ACTIVATE THE TIC FUNCTION:
Allows you to hear a TIC sound when Sensor Pad function is activated.
1
OK
1) Press Menu icon to access
the main menu.
2) Press TIC icon to activate or deactivate
the tic function.
3) Press OK icon to confirm.
2
ON OFF
TO STOP THE ALARM
Press the Parent
Unit Motion
Alarm icon
Press the Nursery
Unit’s Main button
Hold down left ‘wing’
button for two seconds
to turn OFF the Unit
Regular TIC sound will emit from Parent Unit
and a moving pendulum will appear
on Parent Unit indicator bar
OR
1
OK
2
OK
OFF
ON
ON
3
IMPORTANT
• The Sensor Pad is not designed for use with adults, children or infants older
than 24 months.
• Once you are finished using the Sensor Pad, please remove it from the baby’s
crib and store it away.
NOTE:
If you are receiving false alarms,
adjust the sensitivity level.
16
