Angelcare Canada AC1300R Video Baby Monitor

OWNER’S MANUAL

MOVEMENT, VIDEO,

& SOUND MONITOR

ES

39

FR

19

EN

2

& SOUND MONITOR

Model AC1300

ES

39

FR

19

EN

2

FOR YOUR PEACE OF MIND

TABLE OF CONTENTS

WARNINGS ..................................................................................................................................................3

AC1300 SETUP REQUIREMENTS ..................................................................................................................5

STEP 1 - Charging the Parent Unit (9 hours) .............................................................................................6

STEP 2 - Installing the Sensor Pad ...............................................................................................................7

STEP 3 - Setting up the Nursery Unit ..........................................................................................................9

STEP 4 - Turning on your monitor ................................................................................................................9

STEP 5 - Testing and getting to know your monitor ............................................................................10

STEP 6 - Activating and deactivating additional functions ............................................................... 13

Troubleshooting ................................................................................................................................................ 17

Limited warranty ............................................................................................................................................... 18

Technical specifications .................................................................................................................................. 18

FRANÇAIS ........................................................................................................................................................... 19

ESPAÑOL ............................................................................................................................................................ 39

OWNER’S MANUAL

KEEP YOUR OWNER’S MANUAL FOR FUTURE REFERENCE.

PLEASE READ THE WARNINGS AND INSTRUCTIONS CAREFULLY BEFORE

ASSEMBLING & USING THE PRODUCT.

FAILURE TO FOLLOW THE WARNINGS AND THE INSTRUCTIONS COULD

RESULT IN SERIOUS INJURY OR DEATH OR DAMAGES TO THE PRODUCT.

THE SENSOR PAD FEATURE IS NOT FOR USE WITH ADULTS, CHILDREN OR

INFANTS OLDER THAN 24 MONTHS.

THE SENSOR PAD IS NOT INTENDED TO BE USED TO DETERMINE

IF A CHILD IS OUT OF THE CRIB.

WARNING

Adult assembly required.

Keep small parts away from children when assembling.

We, at Angelcare®, stand behind all of our products.

If you are not completely satisfied or have any questions,

United States and Canada: Please contact us at: angelcare@cdecinc.ca

Other countries: Please contact your local distributor.

FCC AND IC REGULATIONS

RF radiation exposure statement

The Nursery Unit complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.

Caution: To maintain the compliance with the FCC’s and Industry Canada’s RF exposure guideline, install

the Nursery Unit at least 20 cm from ALL persons. The transmitter of this device must not be co-located or

operating in conjunction with any other antenna or transmitter.

Industry Canada

This product meets the applicable Industry Canada technical specifications.

CAN ICES-3 (B)/NMB-3 (B)

2

02mf8_Manuel_AC1300_NA_12301.indd 2 2015-10-09 11:11 AM

1.

THIS PRODUCT CANNOT REPLACE

RESPONSIBLE ADULT SUPERVISION. This product

is designed to aid in the monitoring of your child.

When using the monitor, you must still provide the

supervision necessary for the continued safety

of your child. Monitoring of premature babies,

or those considered to be at risk, should always

be carried out under the supervision of a health

professional. This monitor is not intended to be

used as a medical monitor.

2.

WARNING Strangulation Hazard — Children

have STRANGLED in cords. Keep adapter cords

out of the reach of

children (more than 3

feet [0.9 meter] away).

NEVER use Sensor

Pad(s) without the

protective cord covering.

Check protective cord

covering before each

use. Immediately

discontinue use of

Sensor Pad(s) if

protective covering is damaged or broken.

3.

Never use extension cords with adapters. ONLY

use the adapters provided.

4.

When an adapter is plugged into an electrical

outlet, DO NOT touch the exposed end.

5.

ALWAYS be sure that both the transmitter and

receiver are working properly and are within range

of each other. Test the monitor before ﬁ rst use,

periodically and when changing location of the

Nursery Unit.

6.

ALWAYS be sure to immediately check on baby

whenever an alarm sounds.

7.

DO NOT use monitor near water (such as bath

tub, sink, etc.).

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

DO NOT EXPOSE TO RAIN OR MOISTURE

8.

Keep monitor AWAY from heat sources (such

as stoves, radiators, etc.).

9.

ALWAYS place both the Nursery Unit and the

Parent Unit on a ﬂ at surface in an upright position

and allow for proper ventilation. DO NOT place

on sofas, cushions, beds, etc. which may block

ventilation.

10.

This monitor uses public airwaves to transmit

signals. The Parent Unit may pick up signals or

interference from other nursery monitors in your

area. Your monitor may even be picked up by

other households. To protect your privacy, make

sure both units are turned

OFF

when not in use. If

you experience interference, change the channel

on both units.

11.

This product is NOT a toy. DO NOT allow

children to play with it.

12.

This product contains small parts. Adult

assembly required. Exercise care when unpacking

and assembling the product and keep small parts

away from children.

13.

When using the monitor, the room temperature

should be between 50°F (10°C) and 104°F (40°C).

BATTERY WARNING

14.

Use ONLY the enclosed lithium rechargeable

battery that came with the Parent Unit. In the

Nursery Unit, DO NOT mix old and new batteries.

DO NOT mix alkaline, standard or rechargeable

batteries. Insert batteries with correct polarity. DO

NOT short-circuit supply terminals. ONLY use the

recommended batteries or equivalent (volts and

size) and the correct adapter. Remove batteries

in the Nursery Unit when product is stored for long

periods of time or when batteries are exhausted.

Dispose exhausted batteries properly. Keep all

batteries away from children.

15.

IMPORTANT SAFETY INSTRUCTIONS

15.1

Heed all warnings – All warnings on the

product and in the operating instructions should

be adhered to.

15.2

Follow all instructions – All operating and

use instructions should be followed.

15.3

Water and moisture - DO NOT use this

apparatus near water. For example, near a bath

tub, wash bowl, kitchen sink, laundry tub, in a wet

environment or near a swimming pool and the like.

Care should be taken so that objects

DO NOT

fall

onto units and that liquids are not spilled into

either unit or Sensor Pad through its openings.

15.4

Cleaning - Disconnect all units before

cleaning. DO NOT immerse in water any part of

the monitor. Clean only with dry cloth.

15.5

Ventilation - DO NOT block any ventilation

openings. Allow for proper ventilation when units

are in use. DO NOT cover the Nursery Unit or the

Parent Unit with any object such as a blanket.

DO NOT place it in a drawer or in any location

which would mufﬂ e the sound or interfere with

the normal ﬂ ow of air.

15.6

Heat sources - DO NOT install near any heat

sources such as radiators, heat registers, stoves,

TVs or other apparatus (including ampliﬁ ers)

that produce heat. Heat can damage the case or

electrical parts.

15.7

Power cord protection - Protect the Sensor

Pad cord and Adapter’s power cord from being

walked on or pinched by furniture or other items –

Power supply cords should be routed so that they

are not likely to be walked on or pinched by items

upon or against them, paying particular attention

to cords and plugs, convenience receptacle, and

the point where they exit from the product.

The socket outlet shall be installed near the

equipment and shall be easily accessible. Make

sure to plug the adapter to the socket outlet

nearest to the equipment and that is easily

accessible. To disconnect from mains, unplug

the adapter.

15.8

Accessories - Only use attachments/

accessories speciﬁ ed by the manufacturer. DO

NOT place this product on an unstable cart,

stand, tripod, bracket or table. The product may

fall, causing serious injury to a child or adult and

serious damage to the product. Use ONLY with a

WARNINGS

3

E

N

cart, stand, tripod, bracket or table recommended

by the manufacturer or sold with the product.

Any mounting of the product should follow the

manufacturer’s instructions.

15.9

Unplug this appliance during lightning storms

or when not used for long periods of time.

15.10

Servicing - DO NOT attempt to service

this product yourself as opening or removing

covers (except battery door) may expose you to

dangerous voltage or other hazards.

15.11

Replacement parts - When replacement

parts are required, be sure the replacement parts

speciﬁ ed by the manufacturer have the same

characteristic as the original part. Unauthorized

substitution may result in ﬁ re, electric shock or

other hazards.

15.12

Usage - This baby monitor is intended as

an aid. It is NOT a substitute for responsible and

proper adult supervision and should not be used

as such. Use this appliance ONLY for its intended

use as described in this manual.

15.13

Power Sources - Operate this product only

from the type of power source indicated on the

type plate of the adaptor.

If you are unsure of the

type of power supply to your home, consult your

dealer or local power company.

15.14

Overloading - DO NOT overload wall

outlets, extension cords or integral convenience

receptacles as this can result in a risk of ﬁ re or

electric shock.

15.15

Object and Liquid Entry - NEVER push

objects of any kind into this product through

casing slots as they may touch dangerous voltage

points or short out parts that could result in a risk

of ﬁ re or electric shock. NEVER spill liquid of any

kind on the product.

15.16

Antenna - The antenna used for this

transmitter must be installed to provide a

separation distance of at least 7.9” (20 cm) from all

persons and must not be collocated or operating in

conjunction with any other antenna or transmitter.

15.17

Power Lines - An outside antenna system

should NOT be located in the vicinity of overhead

power lines or other electric light or power circuit,

or where it can fall into such power lines or circuits

as contact with them may be fatal.

15.18

Vibration Source - When the monitor is

in use, DO NOT use a crib mobile or other crib

accessories that may produce vibrations. Other

sources of vibrations may include fans, washing

machines, loud music, etc. These sources of

vibration may interfere with the performance of

your Angelcare

®

monitor and the alarm will not

sound if it continues to detect any movement

other than your baby’s. Be sure all vibration

sources are eliminated before using the monitor.

You may experience false alarms for several

reasons. The most common reason is the

Nursery Unit has not been turned

OFF

after

you have removed your baby from the crib.

Another reason is the Sensor Pad has not

been placed under the mattress properly.

Be sure the Sensor Pad is on a ﬂ at, ﬁ rm surface

with the printed side facing up. The sensitivity

level may also need to be adjusted. Refer to

Step

5.1

. Always be sure to immediately check on baby

whenever an alarm sounds.

15.19

Sensor Pad - Your Sensor Pad can be used in

any crib that is stationary. If the crib has a spring

or slat base, place a hard board between the crib

base and the Sensor Pad measuring at least 13” x

13” (33 x 33 cm) and 1/4 inch (6 mm) thick. Only use

your Angelcare

®

monitor in a stationary sleeping

environment such as a crib where the Sensor

Pad can rest on a completely ﬂ at, ﬁ rm surface.

The sensor pad is made of plastic and does not

permit the air to circulate. Therefore, mildew

build up could develop underneath the mattress

in the sensor pad area. We suggest rotating

the mattress regularly to prevent any mildew.

16.

IMPORTANT SAFETY INSTRUCTIONS

RELATED TO USE OF BATTERIES

16.1

Use ONLY the type and size of batteries

speciﬁ ed in the owner’s manual. There is a risk

of explosion if batteries are replaced with an

incorrect type.

16.2

Use ONLY the enclosed lithium rechargeable

battery and/or the adapter provided for the Parent

Unit. DO NOT attempt to replace the battery or

you will severely damage the unit.

16.3

Charge the battery for 9 hours prior to ﬁ rst

use. Be sure to have the monitor in the

OFF

position during this period. ONLY use the adapters

included with your monitor.

16.4

DO NOT use these adapters with any other

equipments.

16.5

When unplugging the adapter from the

Nursery Unit, be sure it is switched to the

OFF

position. If it isn’t, the unit will revert to battery

mode if batteries are installed.

16.6

DO NOT use rechargeable batteries in the

Nursery Unit. Use alkaline batteries ONLY.

16.7

DO NOT dispose batteries in ﬁ re. They may

explode. Check with local regulations for possible

special disposal instructions.

16.8

Exercise care in handling batteries in order

not to short out the batteries with conducting

materials such as rings, bracelets and keys.

Overcharging, short circuiting, reverse charging,

mutilation, or incineration of batteries must be

avoided to prevent one or more of the following

occurrences: release of toxic materials, release of

hydrogen and/or oxygen, gas and rise in surface

temperature.

16.9

DO NOT attempt to recharge batteries

provided with or identified for use with this

product that are not intended to be charged.

The batteries may leak corrosive electrolyte or

explode.

16.10

DO NOT attempt to rejuvenate the batteries

provided with or identified for use with this

product by heating them. Sudden release of

battery electrolyte may occur, causing burns or

irritation to eyes or skin.

16.11

If and when necessary, the batteries must

be replaced with identical new ones or equivalent

(volts and size). If a battery to be replaced is

connected with other batteries in series, replace

the other batteries at the same time as well. DO

NOT mix old and new batteries.

16.12

Reverse polarity installation of the batteries

in the end product must be avoided. Reverse

insertion of batteries can cause charging, and

that may result in leakage or explosion.

4

16.13 Remove batteries from the Nursery Unit if

you store the product over 30 days because the

batteries could leak and damage the product.

16.14 Discard ‘dead’ batteries as soon as possible

since ‘dead’ batteries are more likely to leak in a

product. If a battery has leaked or vented, it should

be replaced immediately using protective gloves.

16.15 DO NOT store this product, or the batteries

provided with or identified for use with this

product, in high-temperature areas.

WARNING

17. (North America Only)

17.1 Warning: Changes or modifications to this

equipment not expressly approved by the party

responsible for compliance could void the user’s

authority to operate the equipment.

17.2 NOTE: This equipment has been tested

and found to comply with part 15 of the FCC

Rules and the Industry Canada license-exempt

RSS standard(s). These limits are designed to

provide reasonable protection against harmful

interference in a residential installation. This

equipment generates, uses and can radiate radio

frequency energy and, if not installed and used

in accordance with the instructions, may cause

harmful interference to radio communications.

17.3 However, there is n o gu a rantee tha t

inte rference will not occur in a pa rticular

installation. If this equipment does cause harmful

interference to radio or television reception, which

can be determined by turning the equipment OFF

and ON, the user is encouraged to try to correct

the interference by one or more of the following

measures:

• Reorient or relocate the receiving

antenna.

• Increase the separation between

the equipment and receiver.

• Connect the equipment into an

outlet on a circuit different from that

to which the receiver is connected.

• Consult the dealer or an experienced

radio/TV technician for help.

17.4 This device complies with the part 15 of

the FCC Rules and the Industry Canada license

- exempt RSS standards(s). Operation is subject

to the following two conditions:

(1) This device may not cause harmful interference,

and

(2) This device must accept any interference

received, including interference that may cause

undesired operation.

YOU MUST PREPARE:

One hardboard (not included)

Thickness: 1/4’’ (6 mm)

Minimum dimensions:

13’’ x 13’’ (33 x 33 cm)

Maximum dimensions:

equal to the mattress size

WHAT YOU WILL NEED (NOT INCLUDED):

Miniature Philips

Screwdriver

3 AA Alkaline

Batteries for Nursery

Unit

VIDEO, MOVEMENT

& SOUND MONITOR

Model AC1300

IMPORTANT

The hardboard must be larger than the Sensor Pad

surface area or in the case of the AC1300-2SP of

two Sensor Pads.

SETUP REQUIREMENTS

3X

INCLUDED:

Rechargeable Parent

Unit with enclosed

and non-detachable

lithium battery

Nursery Unit

6543 2 1

1 Sensor Pad (AC1300) or 2 Sensor Pads

(AC1300-2SP) with pre-installed cord covers

2 AC Adapters

2X

Hardboard

73 F

5

E

N

02mf8_Manuel_AC1300_NA_12301.indd 5 2015-10-09 11:11 AM

FCC

STEP 1 -

CHARGING THE PARENT UNIT (9 HOURS)

1)

Connect the adapter to the

Parent Unit and into an electrical outlet.

2)

Charge the unit for

9 continuous

hours (prior to first use).

IMPORTANT

The Parent Unit uses a non-

removable rechargeable

lithium battery. DO NOT

attempt to change it.

NOTE:

To optimize your battery

performance please refer

to Battery Guidelines in the

Troubleshooting section.

1

2

PARENT UNIT:

Front Side

Right Side

A)

3.5” LCD Screen

B)

Power

ON/OFF

Indicator

C)

VOX Indicator

D)

Sound Light Indicator

E)

Zoom button

F)

VIDEO ON/OFF

button

G)

MENU/SELECT button

H)

Brightness (+ or -)

I)

Power

ON/OFF

J)

UP/DOWN button

K)

Adapter Outlet

L)

Speaker (not shown)

M)

Tripod

K

M

L

WARNING

STRANGULATION HAZARD.

Children have STRANGLED in cords:

•

Keep adapter cords out of the reach of children (more

than 3 feet [0.9 meter] away).

•

Because of the serious strangulation risk to infants and

toddlers, parents and caregivers should never place the

Nursery Unit within 3 feet (0.9 meter) of a crib.

•

NEVER

use Sensor Pad without the cord covers. Check

cord covers before each use to ensure it is securely

placed under the leg of the crib. Discontinue use of

Sensor Pad if any cord covers are damaged or broken.

•

NEVER

use extension cords with adapters.

ONLY

use

the adapters provided. This product is not a toy. Never

allow children to play with it.

B

C

D

A

E

F

G

H

I

J

6

STEP 2 -

INSTALLING THE SENSOR PAD

65432 1

Cord covers 1, 2, 3, 4:

Position on ﬂ oor

Cord cover 4:

Contains double sided tape to

securely install beneath crib leg

Cord cover

5:

Position vertically between

mattress support and ﬂ oor

Cord cover

6:

Place under the mattress

Sensor Pad with pre-installed cord covers

2.1 - SELECT A LOCATION FOR THE NURSERY UNIT

Select a location for

the Nursery Unit that

is at least

3 feet [0.9

meter] away from

the crib.

IMPORTANT

Place the crib near a supporting wall and far from air currents. Install the Nursery Unit on a ﬂ at, stable

surface facing the crib at a distance of at least

3 feet (0.9 meter)

. Make sure to plug the adapter to the

socket outlet nearest to the equipment and that is easily accessible.

6

5

4

3

2

1

6

5

4

3

2

1

Figure 1

Figure 2

1)

Use the crib leg by the wall closest to the Nursery Unit

(Figure 1)

. In cases where the

Nursery Unit is across the room, use the leg closest to the Nursery Unit to position the

covered wire

(Figure 2)

. It is always preferable that the covered cord run along a wall.

2.2 - SELECT THE CRIB LEG YOU WILL BE USING TO SECURE THE CORD COVERS

RECOMMENDED

OR

1)

Remove the mattress from

the crib.

2)

Place the Sensor Pad(s) –

printed side up –

on top

of the hardboard.

3)

Run the connection pin,

warning label and the ﬁ rst

5 cord covers down along

the backside of the crib

leg,

between the mattress

support and the inside

edge of the crib.

2.3 - INSTALL THE SENSOR PAD ON THE MATTRESS SUPPORT

1 Sensor Pad

(depending on model)

2

3

6

5

4

3

1

2

7

E

N

4

5

6

3”

6

7

4132

CLIC!

4

3

2

1

8

The Sensor Pad functions with any size

and type of mattress except memory-foam

mattresses and hollow frame mattresses.

The hardboard maintains a constant

pressure on the Sensor Pad, enabling it to

detect the baby’s movements even when

the baby is at the edges of the crib.

10

9

WARNING

STRANGULATION HAZARD

•

Remove all slack from Sensor Pad Cord.

•

When lowering the mattress support

as your child grows, slide the vertical

Cord Cover (5) upward so it remains

approximately in the center between

the mattress support and the ﬂ oor. Slide

the Sensor Pad Cord through the Floor

Cover to eliminate any additional slack.

•

The Sensor Pad is not designed for use

with adults, children or infants older

than 24 months.

•

Discontinue used of the Sensor Pad

when child is older than 24 months.

Remove Sensor Pad from crib and store

for future use.

•

BEFORE FIRST TIME USE: To test

that the unit is ready for use, refer to

instruction manual on how to test that

the installation has been done correctly.

4)

Bring the ﬁ rst 4 cord covers down

the ﬂ oor, and keep the 5

th

cord

cover vertically, along the backside

of the crib leg,

(between the

mattress and the inside edge of

the crib).

5)

Remove any cord slack to make

sure no parts of the cord are loose.

6)

Place the 6

th

cord cover approximately

3 po (8 cm) from the edge of the

mattress support.

7)

Snap together the remaining cord

covers that will run along the ﬂ oor.

8)

Remove any cord slack to make sure

no parts of the cord are loose.

9)

Peel off the double-sided tape on the

4

th

cord cover and place it securely

under the crib leg.

10)

Install the Nursery Unit on a ﬂ at, stable

surface facing the crib at a distance of

at least 3 feet (0.9 meter) and plug the

Sensor Pad cord into the Nursery Unit.

11)

Check to make sure the Sensor Pad has

not moved from position.

12)

Place the mattress back inside the crib.

8

STEP 4 -

TURNING ON YOUR MONITOR

1)

Remove the battery door and insert

3 AA Alkaline Batteries (not included).

2)

Place the Nursery Unit at a

minimum

of 3 feet (0.9 meter)

away from the crib.

3)

Connect the adapter to the Nursery

Unit and into an electrical outlet.

4)

Direct the angle of the camera toward

the crib using the rotating dial.

NOTE:

The batteries maintain power

supply in case of power outage.

2

1

3

3 ft

(0.9 m)

NURSERY UNIT:

Front Side

A

E

F

G

J

K

H

I

A)

Adjustable Camera

B)

Power

ON

Indicator

C)

Photo Sensor

D)

Microphone

E)

Rotating Dial

for Camera Angle

F)

Pager/Hold Button

G)

POWER ON/OFF

H)

Adapter Outlet

I)

Sensor Pad Outlet

J)

Battery door (Not shown)

K)

Tripod Outlet*(Not shown)

L)

Night Light

ON/OFF

* Nursery Unit may be installed on a tripod (not included).

STEP 3 -

SETTING UP THE NURSERY UNIT

1)

Press and hold the Parent Unit

ON/OFF

button for 2 seconds until LCD screen

is turned

ON

. Angelcare’s logo will be

shown for 1 second.

2)

Push and hold the Nursery Unit Power

ON/ OFF

button for 2 seconds.

3)

The Parent Unit will display

Video

mode

screen.

When Parent Unit is

turned

ON

and Nursery

Unit is

OFF

, Parent Unit

will display

Disconnected

mode and will turn itself

OFF

after 60 seconds.

1)

If there is a lost connection between

the 2 units after 1.5 minutes, the

Out-of-Range

alarm will sound

on the Parent Unit (refer to

troubleshooting):

•

The

Out-of-Range

icon will appear

on the screen.

•

The

Lost Connection

icon will appear

on the indicator bar.

2

1

9

E

N

Temperature icon:

Indicates room temperature

Temperature Alarm icon:

Indicates Temperature Alarm is active

Pendulum icon:

Indicates the Movement Sensor is active

Night View Mode icon

:Night View Mode

Sound icon:

Indicates that Sound function is active

Connection icon:

Indicates the connection quality between the Parent Unit and the Nursery Unit.

Good connection Poor connection Lost connection Out-of-Range

Battery Level icon:

Indicates battery level

Empty 1/3 Full 2/3 Full Full

INDICATION BAR IMPORTANT ICONS

Good connection Poor connection Lost connection Out-of-Range

Empty 1/3 Full 2/3 Full Full

STEP 5 -

TESTING AND GETTING TO KNOW YOUR MONITOR

IMPORTANT

When in menu or sub-menu modes, sound transmission between Parent and Nursery Units will be

temporarily deactivated. ONLY movement-detection alarm will remain active (if function is activated).

The Angelcare

®

monitor can be used with the pre-program factory settings or

you can also customize your settings to your preference. Main menu on the LCD

display shows the different operation settings. Use the direction keys to set or

check the different functions on the Parent Unit.

Press the

Menu/Select

button to select an icon. The light icon will change from

blue to green to show that the icon is selected. Press

VIDEO ON/OFF

button to

exit or to go back to main menu when in sub-menu.

5.1 - SENSOR PAD

1)

Press

Menu/Select

button to access

main menu.

2)

Select the

Movement

icon.

3)

Use the up and down arrows to

activate

or

deactivate

the

Movement Alarm

.

4)

Press

Menu/Select

button

to conﬁ rm.

TO ACTIVATE THE SENSOR PAD:

1

4

3

2

1)

Move your hand lightly on the mattress.

The

Pendulum

icon will appear on Parent Unit

indicator bar.

2)

Remove your hand from the mattress. After 15

seconds you will hear a ‘

TIC

’ pre-alarm sound, and

5 seconds later the

Movement Alarm

will trigger.

IF THE ALARM DOES NOT SOUND

•

Avoid contact with the crib while Sensor

Pad is in operation.

•

Place the crib near a supporting wall.

•

Adjust the Sensor Pad sensitivity level.

•

Turn

OFF

crib mobile, fans, loud

music or anything else that may cause

vibration.

1

2

The

indicator bar.

The

indicator bar.

The

indicator bar.

The

indicator bar.

The

indicator bar.

TO TEST THE SENSOR PAD:

MOVEMENT ALARM

•

Alarm activates when no

movement is detected by the

Sensor Pad for 20 seconds.

•

Both the Parent Unit and the

Nursery Unit speakers will emit

loud warning sound.

•

Movement

Alarm

icon will show on

the LCD screen.

10

Angelcare Canada AC1300R Video Baby Monitor - Parent Unit User Manual

Angelcare Monitors Inc. Video Baby Monitor - Parent Unit

User Manual

Navigation menu

Namespaces

Views

Navigation
