User Manual
100mm
40mm
1. Amazfit Verge Smartwatch
2 . USB Charging Cable and Base
3. User Manual
Package Contents
Know the watch
The companion app is available for iOS in the Apple Store and for Android in the Google Play.
Please search for “Amazfit Watch” to download and install the app
Download the Amazfit Watch App
To turn on your watch, press and hold the buon on its top right side. Your watch screen
will light up and show a startup animation. The animation may play for several minutes
upon initial startup.
To turn off your watch, press and hold the same buon for more than six seconds to display
the turn off interface.
A QR code will display on your watch screen when it first turns on. This code will be used
to pair your watch with your mobile device.
When the screen is in the rest state aer being switched on, press the key to lighten the screen
shortly.
Turn Your Watch On/Off
Open the "Amazfit Watch" APP on your mobile phone, log in and scan the QR code displayed on the
watch for binding as prompted.
Binding your watch
Aach your watch to the charging base as shown below. Make sure to align the 4 charging
pins on the backside of the watch with the ones on the charging base. Connect the charging
base to a USB plug or computer via the provided USB cable. "Charging" will display on the
watch screen once clipped in. Please use a power adapter that is rated above 5V and 1.0A.
Charging your watch
The watch has the IP68 water and dust resistance rating, which can withstand soaking for 30
minutes in freshwater at 1.5 meters deep with normal temperature, but does not support showers,
saunas and swimming.
Please do not operate the watch underwater. Aer submerging, dry it with a so cloth before
operating or charging.
The watch is not waterproof against corrosive liquids such as acidic and alkaline solutions,
chemical reagents, etc. The damage or defect caused by misuse or improper use is not within the
scope of warranty.
Safety Notice
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
FCC ID:XXXXXXXXXXXXXX
Note: This product has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This product generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
product does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
Please take aention that changes or modification not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operation of the device.
IC: xxxxxxxxxxxxxxxxxxxxx ICAN ICES-3(B)/NMB-3(B)
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radioexempts de licence. L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromere le fonctionnement.
Under Industry Canada regulations, this radio transmier may only operate using an antenna of a
type and maximum (or lesser) gain approved for the transmier by Industry Canada. To
reduce potential radio interference to other users, the antenna type and its gain should be so
chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary
for successful communication.
Conformément à la réglementation d'Industrie Canada, le présent émeeur radio peut
fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour
l'émeeur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à
l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la
puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à
l'établissement d'une communication satisfaisante.
Regulatory Notice:
All Amazfit products are covered by a 1-year limited warranty. 
Official website: en.amazfit.com 
U.S . website : us.amazfit.com
Help: support.amazfit.com 
Email us at: support@amazfit.com
Warranty and Return Policy
Name: Amazfit Verge
Model: A1811
Baery Capacity: 390 mAh
Wireless Connectivity: Wi-Fi IEEE 802.11b/g 2.4GHz, Bluetooth 4.2BLE
Input Voltage: 5V 700mA(Max.)
Frequency: 2402-2480MHz
Max. Output: 9 dBm
Operating Temperatures: 32°F - 104°F / 0°C - 40°C
Water & Dust Resistance Rating: IP68
Compatible With: Android 4.4, iOS 9.0 or above
Specifications
The use of the WEEE Symbol indicates that this product may not be treated as household
waste. By ensuring this product is disposed of correctly, you will help protect the
environment. For more detailed information about the recycling of this product, please
contact your local authority, your household waste disposal service provider or the shop
where you purchased the product.
Disposal and Recycling Information
Hereby, Anhui Huami Information Technology Co., Ltd., declares that the radio equipment
type A1811 is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address:
hp://en.amazfit.com/support.html
For more regulatory information and product certification/compliance logos related to Amazfit Verge,
please go to Seings->About->Regulatory on your watch.
Certifications and Safety Approvals
Do not aempt to replace the device’s baery on your own or force open the built-in baery. Use only
the official charging base to charge your device.
Built-In Baery Precautions
Buon
Microphone
Watchband
Screen Horn hole
Heart rate sensor
Charging and data
transmission port
Max. Output: 5.42 dBmMax. Output: 12.13 dBm
